Campomatic DW911ES User manual

DW911ES / DW911EB
INSTRUCTION MANUAL
:
WWW.CAMPOMATIC.COM
Dishwasher

TABLE OF CONTENT
English __________________________________________
1
French ___________________________________________
25
German
___________________________________________
50
Italian
__________________________________________
72

Thisappliance is intended tobeused in household
and similar applicationssuch as:
-staff kitchen areas in shops, offices andother
working environments;
-farm houses;
-by clients in hotels, motels and other residentialtype
environments;
-bedand breakfast type environments.
This appliance can be used by children aged from 8
years and above andpersons with reduced physical,
sensory or mental capabilities orlack of experience
and knowledgeif theyhave been givensupervision
or instruction concerning useof the appliance in a
safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children
withoutsupervision. For EN60335-1
This appliance is not intended for use by persons
(including children )with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge ,unless they have been givensupervision
or instruction concerning useof the appliancebya
personresponsiblefortheir safety. ForIEC60335-1
This appliance is for indoor useonly, for household
useonly.
To protect against the risk of electrical shock, do not
immerse the unit, cord or plug inwater orother liquid.
Please unplug before cleaningand maintenancethe
appliance.
Use a soft cloth moisten with mild soap, and then use
adryclothtowipeitagain.
（）
（）
When using your dishwasher,
follow the precautions listed below:
1

This appliance must be earthed. In the event of a
malfunction or breakdown, earthing will reduce the risk
of anelectric shock by providing a path of least
resistance of electric current. This appliance is equipped
with a cord having an equipment-earthing conductor
and a grounding plug.
The plug must be plugged into an appropriate outlet that
is installed and earthed in accordance with all local
codes and ordinances.
Improper connection of the equipment-earthing
conductor can result in the risk of an electric shock.
Check with a qualified electrician or service
representative if you are in doubt whether the appliance
is properly grounded.
Do not modify the plug provided with the appliance;
If it does not fit the outlet.
Have a proper outlet installed by a qualified electrician.
Do not abuse, sit on, or stand on the door or dish rack of
the dishwasher.
Do not operate your dishwasher unless all enclosure
panels are properly in place.
Open the door very carefully if the dishwasher is
operating, there is a risk of water squirting out.
Do not place any heavy objects on or stand on the door
when it is open. The appliance could tip forward.
When loading items to be washed:
1) Locate sharp items so that they are not likely to
damage the door seal;
2

2) Warning: Knives and other utensils with sharp points
must be loaded in the basket with their points down or
placed in a horizontal position.
Check that the detergent powder is empty after
completion of the wash cycle.
Do not wash plastic items unless they are marked
dishwasher safe or the equivalent.
For plastic items not so marked, check the manufacturer's
recommendations.
Use only detergent and rinse additives designed for
an automatic dishwasher.
Never use soap, laundry detergent, or hand washing
detergent in your dishwasher.
Children should be supervised to ensure that they do not
play with the appliance.
The door should not be left open, since this could increase
the risk of tripping.
If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.
During installation, the power supply must not be
excessively or dangerously bent or flattened.
Do not tamper with controls.
The appliance is to be connected to the water mains using
new hose sets and that old hose-sets should not be reused.
The maximum number of place settings to be washed
is 14.
The maximum permissible inlet water pressure is 1MPa.
The minimum permissible inlet water pressure is 0.04MPa.
3

Dispose of the dishwasher packaging material
correctly.
All packaging materials can be recycled.
Plastic parts are markedwith thestandard
international abbreviations:
PE for polyethylene,e.g. sheet wrapping material
PS for polystyrene, e.g. padding material
POM polyoxymethylene, e.g. plastic clips
PP polypropylene, e.g. Salt filler
ABS Acrylonitrile Butadiene Styrene, e.g. Control
Panel .
Packaging material could be dangerous for children!
For disposing ofpackage and theappliance please
go to a recycling centre.Therefore cut off the power
supply cableand make the door closing device
unusable.
Cardboard packaging ismanufactured from recycled
paper and should be disposed in the waste paper
collection for recycling.
By ensuringthis productis disposed of correctly, you
will help prevent potential negative consequences
for the environmentandhuman health, which could
otherwise becaused by inappropriate waste handling
of this product.
Formore detailed information aboutrecycling ofthis
product, please contactyour local city office andyour
household waste disposal service.
DISPOSAL:Do not dispose this product as unsorted
municipal waste. Collection of suchwaste separately
for special treatment is necessary.
4

Witheachwashcycle.
Compartment
For programmes with pre-wash only.
(Follow the user instructions!)
Electric indicator on control panel(if provided).
Check the rinse aid level
(On models with water softener system only.)
Electric indicator on control panel (if provided).
If there is no salt warning light in the control panel
(for some models), you can estimate when to fill the salt into
the softener by the number of cycles the dishwasher has run.
Check the regeneration
salt level
Load the baskets
Select a programme
Close the door, turn on the water tap . The machine will start working after about 10 seconds.
Running the dishwasher
Switch off the appliance
Turn off the water tap,
unload the baskets
Fill the detergent dispenser
Warning: wait a few minutes (about 15 minutes) before unloading the dishwasher to avoid handling
the dishes and utensils while they are still hot and more susceptible to break.
They will alsodry better.Unload the appliance, starting from the lower basket.
Changing the programme
Add forgottendishes in the
dishwasher.
Scrape off any large amount of leftover food. Soften remnants of burnt food in pans,
then load the baskets. Refer to the dishwasher loading instructions.
Press the programme button until the selected programme lights up.
( See the section entitled Operation instruction )“”
When the working cycle has finished, the buzzer of the
dishwasher will sound 8 times, then stop.
Turn off the appliance using the Power button.
If the appliance is switched
off during a wash cycle.
Open the door carefully.
Hotsteam may escape
when thedoorisopened!
If the appliance is switched off during a wash cycle, when switched
on again, please re-select the washing cycle and operate the dishwasher
according to the original Power-on state ).
Switch on the appliance Open the door,Press the Power switch button to switch on the appliance.
1.Open the door slightly,.
2.You can open the door completely until the spray arms stop .
3.Add the forgotten dishes.
4.Close the door, the dishwasher will start running again after 10 seconds.
For detailed operating method read the corresponding contentonthe instruction manual.
1. Arunning cycle can onlybe modified ifit has been running for a short time. Otherwise the detergent
may have already been released and the water already drained. If this is the case, the detergent
dispenser must be refilled.
2. Open the door slightly ,then press the program button more than 3 seconds to cancel the
running programme.
3. Select a new programme.
4. Close the door, restart the dishwasher.
5

beforeusingit forthe firsttime.
To get the best performance from your dishwasher, read all operating instructions
3
1
3
1
3. : to selectoption the Extra Drying or
Express function with the main program being selected.
Option Button
6. :To turn on/off the power supply. Power Button
4. : To touch the buttonto delay, delay time will be increased by discontinuous or continuous touch,
maximum 24 hours delay can be defined.
Delay Button
5. : To Press the button to select
appropriateProgram.
Program Button
1. : to show the reminding time, programm
irons, salt and rinse aid warning;
Display Screen
2.Alt Button: Dual zone wash function, press the button
toselect either upper basket or lower basket loaded, and
the responseindicators will light on
7. : to show the stateof dishwasher with the
door closing, it will be particularized at paragraph 6.
State Indicator
The glass outer door is breakable ornament, please do not impact.And a broken door dishwasher is harmful to
your family, please call for after service at once.
11 12
Back View
1
2
3
4
5
7
8
910
Front view
Lower basket
Salt container
Dispenser
Cupshelf
Spray arms
Filter assembly
Inlet pipe connector
Drain pipe
Upperbasket
Cutlery rack
Top spray arm
1
Innerpipe
5
6
7
8
9
10
12
11
3
24
6
ECO
6

The water softener must be set manually, using the water hardness dial.
The water softeneris designed to remove mineralsand salts fromthe water, which wouldhave
a detrimentalor adverse effect on the operation of the appliance.
The higher the content of these minerals and salts,the harder your water is.
The softener should be adjusted according to the hardness of the water in your area. Your local WaterAuthority
can advise you onthehardness ofthe waterinyourarea.
Adjusting Salt Consumption
The dishwasher isdesigned to allow for adjustment in the amount of saltconsumed based onthe hardness of
the waterused. Thisis intended tooptimise and customise thelevel of salt consumption.
WATER SOFTENER
Thehardness of the water variesfrom place to place.If hardwater is used inthe dishwasher, depositswill
form on the dishesand utensils.
Theapplianceis equipped with aspecial softener that uses a salt container specifically designed to eliminate
lime and minerals from the water.
Contact your local water board for information on the hardness of your water supply.
If your model does not have any water softener, you mayskip this section.
Clark:Britishdegree
fH: French degree
DH: German degree
dH=1.25Clarke=1.78fH=0.178mmol/l
1
The manufactory setting: H4 (EN 50242)
Before using your dishwasher for the first time:
A. Set the water softener
B. Add 1.5Kgdishwasher salt and then full fill the salt container with water
C. Filltherinseaiddispenser
D. Fill in detergent
1. Open the door ,Switch on the appliance;
2. Press the Program button for more than 5seconds to start the water softener
set model within 60seconds after theappliance was switched on( The Salt and
Rinse aidwarning lights will be onperiodicallywhen itgetin the setmodel );
3. Press the Program button to select the proper set according to your local environment,
the sets will change in the following sequence: H1->H2->H3->H4->H5->H6;
4. Press the Powerbutton to end thesetup model.
Please followthesteps below for adjustment insaltconsumption.
dH mmol/l
0~90~5 0~0.94 H1 0
10-20
6-11 1.0-2.0 H2 9
21-30
12-17 2.1-3.0
H3
12
H4 20
fH
0~6
7-14
15-21
Clarke
WATER HARDNESS
SelectorPosition Salt consumption
(gram/cycle)
18-22 31-40 22-28 3.1-4.0
41-60
23-34 4.1-6.0 H5 30
H6 60
29-42
35-55 61-98 43-69 6.1-9.8
7

1. The salt container must only be refilled when the salt warning light in the control panel comes on.
Depending on how well thesalt dissolves, the salt warning light maystill be on even though the
salt container is filled.
If there is no salt warning light in the control panel (forsome Models),you can estimate when to fill
the salt into the softener by the cycles that the dishwasherhas run.
2. If thereare spills of the salt,a soakor a rapid program should be run to removethe excessive salt.
Always use the salt intended for use with dishwasher.
The salt container is located beneath the lower basket and shouldbe filledasexplained
inthe following:
Attention!
Only use salt specifically designed for the use indishwashers! Every other type of
salt not specifically designed for theuse in adishwasher, especially table salt, will
damage thewater softener. In case of damages caused by the use of unsuitable
salt the manufacturerdoes not give any warranty nor is liable forany damagescaused.
Only fill withsalt just before starting one of thecomplete washingprograms.
This will prevent any grains of salt or salty water, which may have been spilled,
remaining on the bottom ofthe machine for any periodof time, which maycause
corrosion.
The rinse aid isreleasedduring the final rinse to prevent waterfrom forming droplets onyour dishes, which can
leave spots andstreaks. Italso improves dryingby allowing watertoroll offthe dishes. Your dishwasher is
designed to use liquid rinseaids. The rinseaid dispenser islocated inside the door next to the detergentdispenser.
To fill the dispenser,open the cap and pour the rinse aid into the dispenser until the level indicator turns completely
black. The volume ofthe rinseaidcontainer is about 110ml.
RinseAid Dispenser
Function of RinseAid
Rinse aid is automatically added during thelast rinse, ensuring thorough rinsing, and spotandstreak free drying.
Attention!
Only use branded rinse aid for dishwasher. Never fill therinse aid dispenser withanyother substances
(e.g. Dishwasher cleaning agent, liquid detergent).This would damagethe appliance.
Full fill the salt container with water,It is normal for a small amount of water to come out of the
saltcontainer.
AAfter the lower basket hasbeen removed, unscrew and remove the cap from the saltcontainer.
BPlace the end of thefunnel (supplied) intothe hole and introduce about 1.5kg of dishwasher salt.
C
DAfter filling the container , screw the cap tightly back clockwise.
EThe saltwarning lightwillstop being after thesalt containerhasbeenfilled withsalt.
FImmediately after filling the salt into the salt container, a washing program should be started
program Otherwise the filter system, pumpor other important parts of the machinemaybe damaged
bysalty water.This isoutofwarranty.
(Wesuggest to use a short
).
8

To open the dispenser,turn the cap to the "open" (left) arrow and lift it out.
Pourthe rinse aid into the dispenser,being careful not to overfill.
Replace the cap by inserting italigned with "open" arrow and turningit to the closed (right) arrow.
Adjusting RinseAid Dispenser
The rinse aid dispenser hassix or four settings.Always startwith the dispenser
set on "4". If spots and poor dryingare a problem, increase the amount of rinse
aid dispensedby removing the dispenser lid and rotating the dial to "5". If the
dishes still are not drying properly or are showspots,adjustthe dial to the next
higher lever until your dishes are spot-free. The recommended setting is "4".
(Factory value is "4".)
Increase the dose if there are drops of wateror limespotsonthedishes after washing.
Reduce it ifthereare sticky whitishstains on your dishes ora bluish film on glasswareor
knife blades.
1
2
3
As the rinse aid diminishes, the sizeof the black dot
onthe rinse aidlevel indicator changes, as illustratedbelow.
Full
3/4full
1/2full
1/ 4full -Should refilltoeliminate spotting
Empty
When to Refill the RinseAid Dispenser
Ifthereis no rinse-aid warning lightin thecontrolpanel, you can estimatethe amount from the colour
of the optical level indicator C located next to the cap. Whenthe rinse-aidcontainer isfull, the whole
indicator will be dark .As the rinse-aid diminishes, thesize of the dark dot decreases. You should never let
the rinse aid level fall 1 / 4 full.
during the next wash. Don'tforget to replacethe cap before you closedishwasher door.
Clean up any rinse aid spilled while during filling with an absorbent cloth to avoid excessive foaming
Detergents with its chemical ingredients arenecessary to remove dirt, crushdirtandtransport it outof the dishwasher.
Mostof the commercial quality detergents are suitable forthispurpose.
""
Proper Use of Detergent
Useonly detergent specificallymade for the use in dishwashers. Keep your detergent fresh and dry.
Don't putpowdered detergent into the dispenser untilyou'reready to wash dishes.
Attention!
9

Amount ofDetergent to Use
Based on their chemical composition, detergentscan be splitin two basic types:
Detergent tabletsof different brandsdissolve at different speeds. For thisreasonsome
detergenttablets cannot dissolve and develop theirfull cleaning power during short
programs. Therefore please use long programs whenusing detergent tablets, to
ensure the complete removal of detergent residuals.
The dispenser must berefilledbefore the start of each wash cycle following the instructions
provided in the wash cycle table . Your dishwasher useslessdetergent and rinseaid than
Conventional dishwasher.Generally, only one tablespoon of detergent is needed for
anormal washload. Moreheavily soileditemsneedmore detergent.Alwaysaddthe
detergentjustbefore starting the dishwasher, otherwise it couldget damp and will not
dissolve properly.
Concentrated Detergent
DetergentTablets
Detergent Dispenser
conventional, alkaline detergents with caustic components
low alkaline concentrated detergents with natural enzymes
Normally new pulverised detergent is without phosphate.Thus the water softener function of
phosphate is not given. In this case we recommend to fill salt in the salt container even when
the hardness of water is only 6 dH. If detergentswithout phosphate are used in the case of hard water
often white spots appear on dishes and glasses. In this case please add more detergent to reach
better results. Detergents without chlorine do only bleach a little. Strong and coloured spots will not
be removed completely. Inthiscase pleasechoosea program with a higher temperature.
°
Detergents
There are 3 sorts of detergents
1.With phosphate and withchlorine
2.With phosphate andwithout chlorine
3.Without phosphate and without chlorine
Always add the detergent just before starting eachwash cycle.
Only use branded detergentaid for dishwasher.
If the lid isclosed: press release button.The lid will spring open.
Dishwasherdetergentis corrosive!
Takecaretokeepitoutofreachofchildren.
10

Fill the detergent dispenser with detergent.
The marking indicates the dosing levels , as
illustrated on the right:
Theplaceof main wash cycle detergent placed.
Theplaceof pre-wash cycle detergent placed.
Please observe the manufacturers dosing and storage
Recommendations as statedonthedetergent packaging.
Close the lid and press until it locks in place.
If the dishes are heavily soiled, place anadditional
detergent dose in the pre-wash detergent chamber. This detergent will take effect during the pre-wash phase.
A
B
Fill in Detergent
You find information about the amount ofdetergent for thesingle programme onthe last page.
Pleaseaware, that according tothe level soiling and the specific hardnessof water differencesarepossible.
Pleaseobserve themanufacturer's recommendationsonthe detergent packaging.
AB
11

Cutlery withwooden,horn china or
mother-of-pearl handles
Plasticitems that arenot heat resistant
Older cutlerywith glued parts thatarenot
temperatureresistant
Bonded cutlery items or dishes
Pewter or cooper items
Crystal glass
Steel items subject to rusting
Wooden platters
Items madefromsynthetic fibres
Some types of glasses canbecome
dull aftera large number of washes
Silver and aluminum parts have a
tendencyto discolourduring washing
Glazed patterns may fade if machine
washed frequently
Are not suitable Are oflimited suitability
Dishesanditemsof cutlerymust notlie insideoneanother, orcover each other.
To avoiddamage to glasses, theymust not touch.
Load large items which are most difficult to clean into the lower basket.
The upper basket isdesigned to hold more delicate and lighter dishware such as glasses, coffee
andtea cups
Long bladed knives stored in an upright position are a potential hazard!
Long and/or sharp items of cutlery such as carving knives must be positioned
horizontallyin the upperbasket.
Please do not overload your dishwasher. This is important forgood resultsandfor
reasonable consumption of energy.
Load hollow items such as cups, glasses, pans etc. With the opening facing downwards so that
water cannot collect in the container or a deep base.
Consider buyingutensils which are identifiedas dishwasher-proof.
Usea mild detergent thatis described as'kind todishes'. If necessary, seek further
information fromthedetergent manufacturers.
Forparticular items,select a programwithas low atemperatureaspossible.
To prevent damage, do not take glassand cutlery out of the dishwasher immediately
after the programmehas ended.
(For best performance of the dishwasher, follow these loading guidelines.
Features and appearance of baskets and cutlerybasketsmay vary from your model.)
Scrape off any largeamounts ofleftover food. Soften remnants of burnt food inpans.
It is not necessary torinse the dishes under running water.
Place objects inthe dishwasher in following way:
1.Items such as cups, glasses, pots/pans, etc. are faced downwards.
2.Curved items, or ones with recesses, should be loaded aslant so that water can run off.
3.All utensils are stacked securely and can not tipover.
4.All utensils are placed in the way that the spray arms can rotate freely duringwashing.
Very small items should not be washed in the dishwasher as they could easily fall out of the basket.
To prevent water dripping from the upper basket into the lower basket, we recommend thatyou
empty the lower basket first and thenthe upper basket.
12

Theupper basket is designed to holdmore delicate
and lighter dishware such as glasses, coffee and
teacups and saucers, aswell asplates, small bowls
andshallowpans (as long astheyare not toodirty).
Position thedishes andcookwaresothatthey will
notgetmoved bythespray ofwater.
We suggest that you place large items and the most
difficult to cleanitemsaretobe placedintothelower
basket: suchaspots, pans, lids, serving dishes and
bowls, as shown in the figure below. It is preferable to
place serving dishes and lids on the side of the racks
in order to avoid blocking the rotation of the top spray
arm.
Pots,servingbowls,etc,mustalwaysbeplacedtopdown.
Deep pots should be slanted to allow water to flow out.
Please bereminded that:
The Bottom Basket features folding spikes so that larger or more pots and pans can be loaded.
Folding Spikes of Lower Basket
Forbetter stacking of pots and pans,
the spikescanbe folded down as
show in the picture right.
Adjusting the Upper Basket
The heightof the upper basket can be adjusted in order to
create morespace for largeutensilsboth for the upper
/lowerbasket. The height of the upper basket can be
adjusted by placingthewheelson differentheight of the
rails. Long items, serving cutlery, salad servers and knives
shouldbeplaced ontheshelfsothat they donotobstruct
therotationofthesprayarms..
Folding back the cup shelives
For better stacking of pots and pans,
the spikes can be folded down as
show in the picture right.
Cutleryshouldbe placed inthecutlery rackseparately
from each other in the appropriate positions, and do
make sure the utensils do not nest together,this may
causebadperformance.
Donot letany item extend through thebottom.
Always load sharp utensils with the sharp
point down!
13

Intensive
Normal
Rapid
60 min
*EN 50242 : Thisprogramme is the test cycle. The information for comparability test
in accordance withEN 50242, as follows:
Capacity: 14 setting
PositionUpper basket: upper wheels onrails
Rinse aid setting: 6
Pl:0.49w; Po:0.45w.
Starting a cycle wash
Draw out the lower and upper basket, load the dishes and pushthem back.
It is commended to load the lower basketfirst, then the upper one (see the section entitled
Loading the Dishwasher ).
Pour in thedetergent (see the section entitled Salt, Detergent and Rinse Aid ).
Insert the plug into the socket. The power supply is 220-240 VAC /50 HZ, the specification
of thesocket is 10A 250VAC. Make sure that the water supply is turned on to full pressure.
“”
“”
1
2
3
5/30g
5/30g
20g
To rinse dishes that you plan
to wash later that day
Soak
80.01
4
Means:need to fill rinse into the Rinse-Aid Dispenser.
()
For normally soiled loads,
such as , plates,glasses
andlightly soiled pans.
pots
For heaviest soiled crockery,
andnormally soiled pots
pans dishes etc with dried
onsoiling.
、
、
Ashorter wash for lightly
soiled loadsthat do not
need drying.
For lightly soiled loads that
do not need excellent drying
efficiency.
Prewash 50
Wash 65
Rinse
Rinse
Rinse 65
Drying
（℃）
（℃）
（℃）
Prewash(45 )
Wash (55 )
Rinse
Rinse (65 )
Drying
℃
℃
℃
Prewash
Wash (50 )
Rinse(65 )
Drying
℃
℃
Wash (40 )
Rinse
Rinse (45 )
℃
℃
Prewash 50
Wash(60 )
Rinse (60 )
Drying
（℃）
℃
℃
Prewash
ECO
(*EN 50242)
This is standard programme,it is
suitable to clean normally soiled
tableware and it isthe most efficient
programme in terms of its combined
energy and water consumption for
that type of tableware.
Glass
Pre-wash
wash(40 )
Rinse
Rinse(60 )
Drying
℃
℃
For lightly soiled crockery
andglass
8.4~12.70.9~1.3 120~180
Pre-wash (45 )
Autowash(45-55 )
Rinse
Rinse (62 )
Drying
℃
℃
℃
Auto sensingwash,lightly,
normally or heavily soiled
crockery, with or with out
dried-on food
Auto
185
175
175
40
1.3
0.93
1.6
0.6
17
14
10
10
60 101.15
115 0.87 14
(Or )3in1
5/30g
(Or )3in1
5/30g
(Or )3in1
5/30g
(Or )3in1
5/30g
For a top quality cleaning, place the silverware in the basket
makingsurethat:
They donot nest together.
Silverware is placed with the maleface up.
Long utensils in the middle.
14

Whenthe working cycle has finished, the buzzer of the dishwasher will soundfor8 seconds, then stop.Turn off
the appliance using the Power switch button, shut off the water supply and open the door of the dishwasher.
Wait for afew minutes before unloadingthedishwasherto avoidhandlingthedishes and utensils while they
are still hot and more susceptible to breakage. Theywill alsodry better.
Switch Off the Dishwasher
Front indicatorshowswhitelight
1.Open the door, switch off the dishwasher by pressing the button.
2.Turnoffthewatertap!
, only in this case the programme has ended.
Power
Open the door carefully.
Hot dishes are sensitive to knocks. The dishes should thereforebeallowedto cooldown around 15 minutes
before removingfrom the appliance.
Open thedishwasher's door, leave it ajar and wait a few minutes before removing the dishes. In this way they
will be cooler andthe drying will be improved.
Unloadingthe dishwasher
It is normal that the dishwasher is wet inside.
Empty the lower basket first and then the upperone. This will avoid water dripping from the upper Basket onto
the dishes in the lower one.
If you open the door , the machine will pause. The program lightwill
stop blinking and the buzzer will mooing every minute unless you close the door .After
you close the door ,the machine will keep on working after 10 seconds.
duringawashcycle
Premise:
Acycle that is underwaycan only be modified if it hasonly been running for a short time. Otherwise, the
detergent may have already been released, and the appliancemay have already drained the wash water.
If thisis the case, the detergent dispenser must be refilled (see the section entitled " Loading the
Detergent" ).
Openthe door,the machine will bein standby state, press theprogram button more than 3s then you can
change the program to the desiredcycle setting (seethe section entitled " Starting a washcycle. . ." ).
1
2
Aforgotten dish can be added any time before the detergent cup opens.
Add forgotten dishes.
Close the door, the dishwasher will run
after about 10 seconds.
After the spray arms stop working,you can open the door
completely.
2
3
14
Open the door slightly
Press the program button , thewash program will be changed as follows direction:
If a program is selected, the responseprogram indicator will light, then you can also choose the Extra Drying or
Express function, close the door ,the dishwasher will begin work after about 10 seconds.
ECO->Glass 60min->Rapid ;-> ->Soak->Auto->Intensive->Normal
4
5
The front indicator show the state of dishwasher:
a).blue light with blinking: running;
b).blue light without blinking: pause;
c).white light: end of process(open the door ,the white light will extinguish);
d).no light: stand by
It is dangerous toopen the door when washing,
because the hot water may scald you.
15

The filter prevents larger remnants of food or other objects from getting insidethepump.
Theresidues may blockthefilter, in this case they must be removed.
The filter system consists of a coarse filter,a flat (Mainfilter)
And a microfilter(Fine filter).
Food and soil particles trapped in thisfilterarepulverizedby a
special jet on the lower spray arm andwashed down to drain.
Larger items, such as pieces of bonesor glass, that couldblock
the drainaretrappedin the coarse filter. To remove theitems
caught by the filter,gently squeeze the tap on thetop of this
filterandliftout.
This filter holds soil and food residuesin the sumpareaand
preventsit frombeing redepositon the dishes during washcycle.
Main filter
1
Coarse filter
2
Fine filter
3
2
3
1
Filterassembly
Thefilter efficiently
For best performance and results, the filter must be cleaned regularly. this reason, it is a goodideato
remove the larger food particlestrappedin the filter aftereach wash cyclebyrinsing the semicircular filterand
cup under runningwater. To remove thefilter device, pull thecup handle in the upwarddirection.
removes food particles from the wash water, allowing it to be recycled during the cycle.
For
The dishwasher must never be used without the filters.
Improper replacementof the filter may reduce the performance level ofthe appliance
and damage dishesand utensils.
1
2
Step 1 Turn the filter in anti-clockwisedirection,：
Step 2 lift the filter assy up：
When following this procedure from step1 to step 2, the filter system will be removed;
when following it from Step 2 to Step 1, the filter system will be installed.
16

The control panel can be cleaned by using a lightly dampened cloth.
After cleaning, make sure to dry it thoroughly.
For the exterior, use agood appliance polish wax.
Neveruse sharp objects, scouring pads orharsh cleaners onany part of the dishwasher.
ProtectAgainst Freezing
1.Cut offthe electrical power to the dishwasher.
2.Turn off the water supply and disconnect the water inlet pipe from the water valve.
3.Drain the water from the inlet pipe andwater valve. (Use a pan to gather thewater)
4.Reconnect the water inlet pipe tothe water valve.
5.Remove the filter at the bottomof the tub and use a spongeto soak up water in the sump.
please take frost protection measuresonthe dishwasher in winter. Every fter washingcycles,
please operate as follows time a
：
Cleaning the Filter
Cleaning the Door
To clean the coarse filter and the fine filter, use a cleaning brush. Reassemble thefilter parts as shown in the figures
on thelast page and reinsert the entire assembly in the dishwasher, positioning itin itsseat and pressing downwards.
When cleaning the filters, don't knock on them. Otherwise, the filters could be
contorted andthe performance ofthe dishwashercouldbe decreased.
To clean theedge around thedoor, you shoulduseonly a soft warm, dampcloth.
To avoid penetrationof waterinto thedoor lock and electrical components,do not
use a spray cleaner of any kind.
Never use a spray cleaner toclean the door panel as it may damage the door lock
and electricalcomponents.
Abrasive agents or some paper towels should not be used because of theriskof
scratching or leaving spots on the stainless steel surface.
Cleaning the SprayArms
If your dishwasher cannot work because of the ice,
please contact professional service persons.
It is necessary to clean the spray arms regularly for hard
waterchemicalswillclogthe sprayarmjetsandbearings.
- Inspect the filters for blockingafter every timethe dishwasher has been used.
- By unscrewing the coarsefilter, you can remove the filter system. Removeany foodremnants and
cleanthefilters underrunningwater.
Remarks:
The entire filter assembly shouldbe cleaned once a week.
To remove thelower spray arm, pullout the spray arm upward.
To remove the upper sprayarm, hold the nut, rotate the arm
clockwisetoremoveit.
Wash the arms in soapyandwarm water and use a soft brushto
clean thejets. Replace them after rinsingthem thoroughly.
17

Itis recommend thatyourun a washcycle withthe
dishwasher empty andthen remove the plugfromthe
socket, turn off the water supply and leave the door of
the appliance slightly open. This will help the door
sealstolastlonger andpreventodours fromforming
withintheappliance.
If the appliance must be moved, try to keep it in the
verticalposition.If absolutelynecessary,itcanbe
positioned on its back.
Oneofthefactorsthatcauseodourstoforminthe
dishwasher is food that remains trapped in the seals.
Periodic cleaning with adamp sponge will preventthis
from occurring.
Ensure the voltage and frequency of the power being corresponds to
those on the rating plate. Only insert the plug into an electricalsocket which is earthed
properly. If the electrical socket to which the appliance must be connected is not
appropriate fortheplug , replace the socket, ratherthan usingaadaptors or thelike as
they couldcause overheating andburns.
Pleaselook at the rating label to know the rating voltage and connect the dishwasher to the appropriate power supply.
Use the required fuse 10 amp,timedelay fuse or circuit breakerrecommended and provide separate circuit serving
only this appliance.
Position the appliance in the desired location.The back should rest against the wall behind it, and the sides,
along the adjacent cabinetsor walls.The dishwasher is equippedwith water supply and drain hoses that can
be positioned either tothe rightor the left sides to facilitate proper installation.
Once the applianceis positioned for levelling, the height of the dishwasher
may be altered via adjustment of the screwing level ofthe feet. In any case,
theappliance should not be inclined more than 2 .
Before cleaning orperforming maintenance, always
remove the plug from the socket.
Tocleantheexteriorandrubberparts ofthedishwasher,
donot use solventsor abrasivecleaningproducts.
Only use acloth with warm soapy water.
To remove spots or stains from the surface of the
interior, use a clothdampened withwater an a little
vinegar, or a cleaning product madespecificallyfor
dishwashers.
Remove the Plug
No Solvents orAbrasive Cleaning Moving theAppliance
Seals
After every wash, turn off the water supply to the
appliance and leave the door slightlyopen sothat
moisture and odours arenot trapped inside.
After EveryWash
When not inUse for aLongTime
For personal safety:
Do not use an extension cord or an adapter plug
with this appliance.
Do not, under any circumstances, cut or remove the
earthing
Connection from the power cord.
18
