Campomatic FR770M User manual

FR770M
INSTRUCTION MANUAL
:
WWW.CAMPOMATIC.COM
Made in China
Refrigerator

CONTENTS
Safety warnings
Meaning of safety warning symbols 2
Related warnings for use 2
Electricity related warnings 2
Warnings related to placing items 3
Warnings related to disposal 3
Proper use of refrigerators
Names of components 4
Machine 5
Illuminating lamp and replacement 5
placement 5
Start 5
Introduction of Your Refrigerator's Functions
Introduction of Your Refrigerator's Functions 6
Maintenance of refrigerators
Cleaning 8
Ice MachineCleaning 8
Defrost 8
Stop using 8
Install The Door Handle 9
Frequently asked questions
Frequently asked questions 10
DEAR CUSTOMER:
Thank you for buying this refrigerator-freezer . T o ensure that you get the best results from your new
refrigerator-freezer, please take time to read through the simple instructions in this booklet.
Please ensure that the packing material is disposed of in accordance with the current environmental
requirements.
When disposing of any refrigerator-freezer equipment please contact your local waste disposal
department for advice on safe disposal.
This appliance must be only used for its intended purpose.
Fr770m

Safety warnings
Meaning of safety warning symbols
Pr ohibition s ymbols
Warning symbols
Note symbols
The symbols indicate prohibited matters, and those
behaviors are forbidden. Non-compliance with the
instructions may result in product damages or endanger
the personal safety of users.
The symbols indicate matters that must be followed, and
those behaviors must be strictly executed in line with the
operation requirements. Non-compliance with the
instructions may result in product damages or endanger
the personal safety of users.
The symbols indicate matters to pay attention to, and
these behaviors shall be specially noted. Due
precautions are needed or minor or moderate injuries
or damages of the product will be caused.
This manual contains lots of important safety information
which shall be observed by the users.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that they do not play with the appliance.
Fr770m

Please turn o the valve of the leaking gas and then open the doors
and windows in case of leakage of gas and other ammable gases.
Do not unplug the refrigerator and other electrical appliances
considering that spark may cause a re.
Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type
recommended by the manufacturer.
Safety warnings
Electricity related warnings
Related warnings for use
Do not damage the refrigerant circuit.
Damaged power cord must be replaced by the manufacturer , its
maintenance department or related professionals in order to avoid
danger.
The surrounding of the appliances around or the embedded structure
shall not be obstructed while good ventilation shall be maintained.
The gaps between refrigerator doors and between doors and refrigerator
body are small, be noted not to put your hand in these areas to prevent
squeezing the nger. Please be gentle when switching o the refrigerator
door to avoid falling articles.
Do not pick foods or containers in the freezing chamber when the
refrigerator is running, especially metal containers in order to avoid frostbite.
Do not pull the power cord when pulling the power plug of the
refrigerator. Please rmly grasp the plug and pull out it from
the socket directly.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualied persons
in order to avoid a hazard.
Please use a dedicated power socket and the power socket shall
not be shared with other electrical appliances.
The power cord should be rmly contacted with the socket or else
res might be caused. Please ensure that the grounding electrode
of the power socket is equipped with a reliable grounding line.
Fr770m

Do not allow children to enter or climb the refrigerator to prevent that
children are sealed in the refrigerator or children are injured by the
falling refrigerator.
Do not spray or wash the refrigerator; do not put the refrigerator in
moist places easy to be splashed with water so as not to aect the
electrical insulation properties of the refrigerator.
Do not place heavy objects on the top of the refrigerator considering
that objectives may fall when switching the door, and accidental
injuries might be caused.
Please pull of the plug in case of power failure or cleaning. Do not
connect the freezer to power supply within ve minutes to prevent
damages to the compressor due to successive starts.
Do not put ammable, explosive, volatile and highly corrosive items
in the refrigerator to prevent damages to the product or re accidents.
Do not place ammable items near the refrigerator to avoid res.
Do not store explosive substances such as aerosol cans with
a ammable propellant in this appliance.
This appliance is intended to be used in household and similar
applications such as
-sta kitchen areas in shops,oces and other working environments;
-farm houses and by clients in hotels,motels and other residential
type environments;
-bed and breakfast type environments;
-catering and similar non-retail applications.
Please according to local regulations regarding disposal of the appliance for its
ammable refrigerant and blowing gas. Before you scrap the appliance, please
take o the doors to prevent children trapped.
Please abandon the refrigerator-freezer according to local regulators for it use amm
able blowing gas and refrigerant.
Safety warnings
Warnings related to disposal
Warnings related to placing items
Fr770m

P ro per use o f r ef ri g er at o rs
Na mes o f co mpone nts
The features and accessories of the refrigerator you bought may be not
entirely consistent with the legend, please refer to the Material object
.
Refrigerating chamber
Freezing chamber
The low temperature freezing chamber may keep food fresh for a long time and it is mainly used to
store frozen foods and making ice.
The freezing chamber is suitable for storage of meat, sh, rice balls and other foods not to be
consumed in short term.
Chunks of meat are preferably to be divided into small pieces for easy access. Please be noted food
shall be consumed within the shelf time.
The temperature should be set to quick-freeze , when you want to refrigerate foods quickly.
The freezer chamber is suitable for storage of a variety of fruits, vegetables, beverages and
other food consumped in the short term.
Cooking foods shall not be put in the refrigerating chamber until cooled to room temperature.
Foods are recommended to be sealed up before putting into the refrigerator.
The glass shelves can be adjusted up or down for a reasonable amount of storage space and easy use.
F g la s s s he lf
la rge tra y
s ma ll tra y
ve ge table b a s k et
Ic e te mpera ture d ra wer
Ic e m a c hine
S e a l b ox
Te mpering block
glas s s helf
g la s s s he lf
la rge tra y
F s ma ll tra y
s ma ll tra y
Chill compartment
It can meet your diversied storage demand. And, it is suitable to store fresh and cold foods for
short time. It is unnecessary to thaw these foods, and it can lock nutrition and keep good
mouthfeelMeanwhile, it can adjust the temperature state of ice green house by adjusting the
size of air gap of ice green house based on dierent food needs.
Rapid cooling of beer, drinks can
Fr770m

P lac e ment
S tart
The refrigerator is placed in a
well-ventilated indoor place;
the ground shall be at, and
sturdy (rotate left or right to
adjust the wheel for leveling if
unstable).
The refrigerator shall stay
for half an hour before
connecting power when
it is rstly started.
The refrigerator shall run
2 to 3 hours before loading
fresh or frozen foods; the
refrigerator shall run for
more than 4 hours in
summer in advance
considering that the
ambient temperature is
high.
Before using the
refrigerator, remove all
packaging materials
including bottom
cushions and foam pads
and tapes inside the
refrigerator, tear o the
protective lm on the door
and the refrigerator body.
Please leave enough space to
ensure feasible opening and
drawer removal.
Dimensions shown are for
reference only.
Keep away from heat and
avoid direct sunlight. Do not
place the freezer in moist or
watery places to prevent rust
or reduction of insulating
eect.
The top space of the refrigerator
shall be greater than 30cm, and
The refrigerator should be placed
against a wall with a free distance
more than 5cm and not exceeding
7.5mm to facilitate the opening and
closing and heat dissipation.
Wipe the refrigerator inside and
outside with warm moist rag (add
a small amount of Neutral detergent
in the warm water and wipe clean
nally with clean water).
P ro per u se o f r ef ri ger at o rs
Ic e M a c hine
1) Drinking water is lled in a measuring cup rstly.
The maximum amount of water is up to the mark
MAX ;
2) Cold water in the measuring cup is added into the
ice machine according to the method shown in Fig.1.
Ice blocks will be formed several hours later after the
door of the freezing chamber is closed.
3) Turning clockwise knob on the ice machine 110
can make separation of ice block with ice box.
Please close the door gently in order to avoid water spilling from
the ice machine
Lamp replacement by professionals
Me a suring c up Ic e m a c hine
Ic e m a c hine Knob
1270mm
750mm
1240mm
652mm
Fig.1 Fig.2
Illumina ting la mp a nd r e pla ce me nt
Fr770m

1 2
34
56
A
C
B
1. Control buttons
A.F Temperature control
B.R Temperature control
C.Function buttons(Lock/Quick-freezing )
2. Led display
Quick-freezing icon Lock icon F temperature zone icon F temperature display
R temperature zone icon R temperature display
3. Locking and unlocking
Under unlocked status, push down C key for three seconds enter into lock status and it displays icon .
Under locked status, push down C key for three seconds to unlock and the icon disappears .
Below functions shall be carried out under unlocked status.
4. Quick-freezing mode
Short press function key C to enter quit/quick-frozen mode and light up icon . The refrigerator will operate
through setting mode after lock.
5. R's temperature setting
Press R temperature button B. The temperature can be set when R's temperature is shown twinkling with range
of 2 ~8 . The R will operate in accordance with settings. The temperature shall be adjusted to: 8 7
2 7 8 .
6. F temperature setting
Press F temperature button A, The temperature can be set when F's temperature is shown twinkling with range
of -16 ~-24 . The F will operate in accordance with settings. The temperature shall be adjusted to:-16 -17
-24 -16 .
Note: If quick-frozen mode is set when the F's temperature is changed, the related modes shall be
quitted /cancelled immediately.
Introduction of Your Refrigerator's Functions
Fr770m

7. Outage memory
When outage occurs, the instantaneous working state will be locked. The working state can be
preserved until power is on.
8. Open prompts and open alert control
When the refrigerator or refrigerating room's door opens, an open music tune will be played. If the door
hasn't been closed after 120 seconds, the buzzer will give alarm and after that, 1 alarm per second until the
door is closed. Press button to cancel buzzing.
9. Fault indication
When following prompts appear on display screen, it indicates malfunction in refrigerator. The refrigerator
can still refrigerate under some malfunctions, yet user shall contact maintenance for refrigerator's
optimized operation.
E6
C ommunication
ci rcuit
Dis pla y
E1 E2 E5
E7
Ma lfunc tion
Refrigerator
temperature sensor
circuit
Freezer defrost
sensor
Ambient temperature
sensor
Dis pla y
Ma lfunc tion
Freezer room
temperature sensor
circuit
Fr770m

Maintenance of refrigerators
Cleaning
Defrost
Stop using
Do not use hard brushes, clean steel balls, wire brushes,
abrasives, such as toothpastes, organic solvents (such as
alcohol, acetone, banana oil, etc.), boiling water, acid or
alkaline items clean refrigerator considering that this may
damage the fridge surface and interior .
Do not rinse with water so as not to the electrical insulation
properties.
Please unplug the refrigerator for defrost and cleaning.
Foods can be preserved for a couple of hours even in summer in case of power failure; it is
recommended to reduce the frequency of opening door and do not put fresh foods into the freezer.
Please unplug the refrigerator left unused for a long time for cleaning. Keep the door open to avoid
the bad odor.
Before moving the refrigerator, please emove all items in the refrigerator and fasten the glass
partitions, fruit and vegetable boxes, freezer drawers with taps lest the door opens during
displacement; Do not turn upside, horizontally place or vibrate the refrigerator, the carrying angle can
not be greater than 45 .
Continuous operation is recommended when the refrigerator is started. Please do not move
Dusts behind the refrigerator and on the ground shall be timely cleaned to improve the cooling
Soft towels or sponge dipped in water and non-corrosive neutral detergents are suggested for
natural drying before the power is turned on.
Auto-defrost for Frost-free Refrigerator
The cleanness of the ice machine
Disassembly of the ice machine
The ice machine is hung in the door
by means of two suspension loops
on the side. So, it can be removed
from the door integrally, as shown
in the below
Cleanness of the ice machine
Water-guiding gutter on the top of the
ice machine can be removed directly
for cleaning. Ice tray can be drawn with
icetray rack. Ice storage box can also
be drawn singly for cleaning. See below
:
suspension loops
Ice storage box
Ice tray rack
and ice tray
Water-guiding
Fr770m

Note: Figures inthe user manualare only forreference. Theactual product may
slightly.
The refrigeratormust bedisconnected fromthe sourceof electrical supply before
attempting theinstallation ofaccessory.
the hol e
the scre w
INSTALL THE DOOR HANDLE
take out the two crisscross-screw;and install them into the door holes;
turn the screws till to the bottom;
aim at screws to install the handle;
the screws in the hole at the side of the handle and turn the screws till
them very tight;
Screw cap should be put on the screw .
Fr770m

Frequently asked questions
Inoperation
Odor
Long-term operation
of compressor
Illuminating light
does not shine
The refrigerator door
can not be properly
closed.
Loud noises
Whethe r the fre ezer is p lugged a nd connected to power;
Low voltage;
Failure p ower or tripping circuit
Odorous foods s hould closely wr apped;
Whethe r foods a re rotten;
Whethe r the inte rior shal l be clea ned.
It is norm al that re frigerator operat es for lo nger time in
summer when th e ambie nt temperature is higher;
Do not p ut too much food in the fr eezer at one tim e;
Do not p ut foods until they are co oled;
Frequen t opening of refri gerator d oor.
The free zer door is stuck by food packag es;
Too much food;
Tilt refrigerator.
Whethe r the foo d is leve led, whe ther the refrigera tor is
balance d;
Whethe r the refr igerator parts are properly placed.
The following simple issues can be handled by the user. Please call the after-sale service
department if the issues are not settled.
Warm tips:
The refrigerator enclosure may emit heat during operation specially in summer, this is caused by
the radiation of the condenser, and it is a normal phenomenon.
Condensation: condensation phenomenon will be detected on the exterior surface and door
seals of the freezer when the ambient humidity is large, this is a normal phenomenon, and the
condensation can be wiped away with a dry towel.
Buzz: Buzz will be generated by running compressor specially when starting up or shutting down.
Whether the refrigerator is connected to power,
whether the illuminating light is damaged.
Fr770m

TECHNICAL DATA
Net weig
Rated Power(W)
Temperature rise value(min)
Overall space required for product (mm)
Overall space required for use(mm)
Model
FR770M
89
99
/
/
750 *735*1825
Fr770m
ht(kg)

WARNNING
Caution:risk of re
RECOMMENDATIONS
1) WARNING Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of
obstruction.
2) WARNING Do not damage the refrigerant circuit.
3) WARNING Do not use electrical appliances inside the food storage compartments of the appliance,
unless they are of the type recommended by the manufacturer.
4) The appliance has to be unplugged after use and before carrying out user maintenance on the
appliance.
5) This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
6) Children should be supervised to ensure that they do not play with the appliance.
7) If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualied persons in order to avoid a hazard.
8) Please abandon the refrigerator-freezer according to local regulators for it use ammable blowing gas
and refrigerant.
9 Please according to local regulations regarding disposal of the appliance for its ammable refrigerant
and blowing gas. Before you scrap the appliance, please take o the doors to prevent children trapped.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environment or human health
from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse
of material resources. To return your used device, please use the return and collection
systems or contact the retailer where the product was purchased. They can take this
product for environmental safe recycling.
