Camsat iConstruction-CAM User manual

TECHNICAL
SUPPORT
tel.[phone]
Mon–Fr 8.00 AM–4.00 PM
Full instructions available on www.camsat-cctv.com
Mobile monitoring system with LTE module
and buffer battery supply powered from 230V
compatible with any IP camera
QUICK START
ver. 1.1
Feature
Full instructions available on www.camsat-cctv.com
The mobile camera in transport should be turned off.
During start-up of iConstruction-CAM system, follow these steps:
EUEU
POLAND
MADE IN
• iConstruction-CAM
• LTE Antenna x2pcs
• Gel battery
• Quick-connector mounting socket + mounting accessories
• Steel safety cable
• Quick Start User Manual and CE Declaration
Producer:
CAMSAT Gralak Przemysław
Ogrodowa 2a
86-050 Solec Kujawski
Poland
[e-mail]
[phone]
[phone]
[phone]
Sales:
[e-mail]
[phone]
(ext. 21 and 22)
Mon.-Fri. from 8.00 to 16.00
European websites:
www.camsat.com
www.camsat-cctv.com
Technical support / Service:
[email protected]
[phone]
(ext. 25 and 26)
Basic information
The iConstruction-CAM device is a mobile observation system designed for monitoring of construction
sites, in places that are particularly difficult to secure due to unfavorable conditions.
It enables very fast installation of the device on the site without complicated installations and projects.
In case of a power failure, the power supply is ensured by a gel battery that allows the device to
operate for a minimum of one hour with a rotating camera(up to 30W) or two hours with an tubular
or dome camera (up to 12W). The integrated LTE wireless module with two SIM card sockets allows
you to view the image from the camera from any place in the world and provides connection with the
recorder in your office or server room.
Starting at the destination point
The iConstruction-CAM system with the IP camera should be mounted only for permanent, stable
construction of walls and masts. The holder should be mounted vertically, the handle/padlock must be
at the bottom. Additionally, you should install steel safety cable to a separate anchors or any other part
of the pole. Safety cable must be mounted to a solid, robust construction, which will guarantee the device
with the camera will be held in case of an emergency. The power plug should be plugged into a socket
adapted to the conditions of use, such as an external hermetic socket or a socket with a plug closed in
another hermetic housing or box. The installer is responsible for correct camera installation in accordance
with these instructions and safety standards!
Slide the camera (antenna up) into the holder, and then attach the safety cable and padlock to secure the
camera or twist two caps on the bolts to prevent unauthorized assembly.
After turning the ignition to the "I" it should light up green LED on the internal panel for a while.
iConstruction-CAM starts to record the image, and full remote access to the device will be possible.
WARNING
After mounting iConstruction-CAM, push ON switch inside, leaving it in position "1"
and close the case to prevent the shutdown of the system by third parties.
Actions taken during each system start-up
Package content
TECHNICAL
SUPPORT
tel.[phone]
Mon–Fr 8.00 AM–4.00 PM
www.camsat-cctv.com
The camera will be started after pushing ON/OFF switch inside case.
Push switch into "I" state to turn on device. Push "O" to switch off.
Battery charging should take at least 12h for 0-100% charging.

www.camsat-cctv.com
Full instructions available on www.camsat-cctv.com Full instructions available on www.camsat-cctv.com
First start-up
WARNING
Before any start-up, connect both antennas! Trying to run the machine without connected antennas
may cause damage to the radio module.
Connecting the power supply and computer
Connect iConstruction-CAM plug into the power socket before first use.
Remove cover from LAN port, and connect this device with Ethernet cable directly to your
computer or through network switch. Configure network card of your computer and add IP address
in 192.168.1.x network subnet. You are now able to turn on the device with internal switch.
WARNING
If you use on internet browser you will need to install camera plugin for watching live preview online and
for playback. You will see pop-up that after confirming will download and install plugin before first login.
The default settings
Local IP address 192.168.1.1
Subnet mask 255.255.255.0 (CIDR /24)
80 (83)
User name admin
Password camsat
2 3
Standard Onvif
IP address 192.168.1.108
ONVIF and HTTP port 80
LTE module
IP camera (in option)
HTTP port (external)
APN m2m.plusgsm.pl
RTSP port 554
admin
Password admin123
User name
WARNING
Prior to starting up the system, you must obtain a special SIM card
that has a public IP address and enables port forwarding. To make
this possible you should take out appropriate additional service
in contract plans. In order to activate these services, contact your
telecommunications service provider.
Installing the SIM card
Remove the cover with the camera by unscrewing the 4 allen screws.
This will allow access to the card slot SIM1 and SIM2. After placing
the SIM card, attach cover back and tighten the screws.
LTE module configuration
Complete the basic configuration of the LTE module. In the Network >> Mobile menu, complete
the fields for the APN access point name and SIM card PIN number, and then save changes.
WARNING
Using an incorrect APN access point name will make IP address private, istead of public static
IP address we want to use. Internet access still exists, but with an undesired IP address.
Check APN name with telecommunications service provider.
Public IP address is displayed in the menu Status > Network > WAN.
After correct configuration, it will be possible to access the device from the public IP address of
the SIM card. Example of the default configuration and IP address 100.100.100.100:
IP camera: http://100.100.100.100:80/
LTE module: http://100.100.100.100:83/
IP Camera configuration
Access your camera at local (default 192.168.1.108) or remote IP address and login using:
Login: admin
Password: admin123
Now you are able to preview live and playback video image. If you need to rotate or zoom in, use
PTZ setting at configuration page.
Start the iConstruction-CAM system by turning the internal switch. Go to LTE module IP addres
in browser on your computer (default 192.168.1.1) and then log in by typing login and password:
Login: admin
Password: camsat
Change the user's password in the System >> Administration menu.
Choose a strong login password to protect against unauthorized access.
CAMSAT is not responsible for hacking unsecured devices and networks.
The configuration of mobile applications to control the camera
You can access the recorder via mobile devices. Applications are available for download from the platform
Google Play or Apple App Store. To connect to a mobile camera system, you must have access to internet
The connection can be established by using camera manufacturer applications or third party software.
Example applications: gDMSS (for Dahua IPC); Hik-Connect (for Hikvision IPC).
