Sony DSC-H55 - Cyber-shot Digital Still Camera User manual

DSC-H55_L2 Sony EMCS Co.
SERVICE MANUAL
Revision History
SERVICE NOTE (Check the following note before the service.)
LEVEL 2Ver. Date History Contents S.M. Rev.
issued
1.0 2010.03 Official Release — —
985278431.pdf
2010C0800-1
© 2010.03
Published by Tokai TEC
Ver. 1.0 2010.03
DIGITAL STILL CAMERA
The components identified by
mark 0or dotted line with mark
0are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0sont critiques pour
la sécurité.
Ne les remplacer que par une piè-
ce portant le numéro spécifié.
US Model
Canadian Model
AEP Model
UK Model
E Model
Australian Model
Hong Kong Model
Chinese Model
Korea Model
Brazilian Model
Argentine Model
1-1. PRECAUTION ON REPLACING THE SY-255 BOARD
1-2. METHOD FOR COPYING OR ERASING THE DATA IN INTERNAL MEMORY
1-3. HOW TO WRITE DATA TO INTERNAL MEMORY
1-4. SELF-DIAGNOSIS FUNCTION
1-5. PROCESS AFTER FIXING FLASH ERROR
1-6. ORNAMENTAL RING A OR BARRIER ASSY REPLACING METHOD
1-7. CAM TUBE BLOCK REPLACING METHOD
1-8. FINAL INSPECTION
Photo: BLACK
9-852-784-31
DSC-H55
Internal memory
ON BOARD
Internal memory
ON BOARD

DSC-H55_L2
– 2 –
SPECIFICATIONS
Camera
[System]
Image device: 7.76 mm (1/2.3 type)
color CCD, Primary color filter
Total pixel number of camera:
Approx. 14.5 Megapixels
Effective pixel number of camera:
Approx. 14.1 Megapixels
Lens: Sony G 10× zoom lens
f = 4.25 mm – 42.5 mm (25 mm –
250 mm (35 mm film equivalent))
F3.5 (W) – F5.5 (T)
While shooting movies (16:9):
30 mm – 300 mm
While shooting movies (4:3):
36 mm – 360 mm
Exposure control: Automatic exposure,
Scene Selection (11 modes)
White balance: Automatic, Daylight,
Cloudy, Fluorescent 1/2/3,
Incandescent, Flash, One Push
Recording interval for Burst mode:
Approx. 0.69 second
File format:
Still images: JPEG (DCF Ver. 2.0,
Exif Ver. 2.21, MPF Baseline)
compliant, DPOF compatible
Movies: MPEG-4 Visual
Recording media: Internal Memory
(Approx. 45 MB), “Memory Stick
Duo” media, SD memory cards,
SDHC memory cards (Class 4, 6, 10)
Flash: Flash range (ISO sensitivity
(Recommended Exposure Index) set to Auto):
Approx. 0.05 m to 4.1 m (W)
(2 inches to 13 ft 5 1/2 inches)
Approx. 1.0 m to 2.6 m (T)
(3 ft 3 3/8 inches to 8 ft 6 3/8 inches)
[Input and Output connectors]
Multi use terminal Type2b
(AV-out (SD/HD Component)/
USB/DC-in):
Video output
Audio output (Monaural)
USB communication
USB communication: Hi-Speed USB
(USB 2.0 compliant)
[LCD screen]
LCD panel: 7.5 cm (3.0 type) TFT drive
Total number of dots: 230 400 (960 × 240) dots
[Power, general]
Power: Rechargeable battery pack
NP-BG1, 3.6 V
NP-FG1 (sold separately), 3.6 V
AC-LS5 AC Adaptor (sold separately), 4.2 V
Power consumption (during shooting):
1.1 W
Operating temperature: 0 °C to 40 °C
(32 °F to 104 °F)
Storage temperature: –20 °C to +60 °C
(–4 °F to +140 °F)
Dimensions: 102.9 × 57.7 × 28.9 mm
(4 1/8 × 2 3/8 × 1 3/16 inches) (W/H/D,
excluding protrusions)
Mass (including NP-BG1 battery pack,
Memory card): Approx. 200 g (7.1 oz.)
Microphone: Monaural
Speaker: Monaural
Exif Print: Compatible
PRINT Image Matching III:
Compatible
PictBridge: Compatible
BC-CSGD/BC-CSGE battery
charger
Power requirements: AC 100 V to 240 V,
50/60 Hz, 2 W
Output voltage: DC 4.2 V, 0.25 A
Operating temperature: 0 °C to 40 °C
(32 °F to 104 °F)
Storage temperature: –20 °C to +60 °C
(–4 °F to +140 °F)
Dimensions: Approx. 55 × 24 × 83 mm
(2 1/4 × 3 1/32 × 3 3/8 inches)
(W/H/D)
Mass: Approx. 55 g (1.9 oz.)
Rechargeable battery pack
NP-BG1
Used battery: Lithium-ion battery
Maximum voltage: DC 4.2 V
Nominal voltage: DC 3.6 V
Maximum charge voltage: DC 4.2 V
Maximum charge current: 1.44 A
Capacity:
typical: 3.4 Wh (960 mAh)
minimum: 3.3 Wh (910 mAh)
Design and specifications are subject to change
without notice.

DSC-H55_L2
– 3 –
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINE WITH
MARK 0ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS
LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE
COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS
APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE
REMPLACER CES COMPOSANTS QUE PAR DES PIÈCES SONY
DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU
DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY.
Caution
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
Unleaded solder
Boards requiring use of unleaded solder are printed with the leadfree
mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with
the lead free mark due to their particular size.)
: LEAD FREE MARK
Unleaded solder has the following characteristics.
• Unleaded solder melts at a temperature about 40°C higher than
ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be
applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to
about 350°C.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!
• Strong viscosity
Unleaded solder is more viscous (sticky, less prone to flow) than
ordinary solder so use caution not to let solder bridges occur such
as on IC pins, etc.
• Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may
also be added to ordinary solder.
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer.
1. Check the area of your repair for unsoldered or poorly-soldered
connections. Check the entire board surface for solder splashes
and bridges.
2. Check the interboard wiring to ensure that no wires are “pinched”
or contact high-wattage resistors.
3. Look for unauthorized replacement parts, particularly transistors,
that were installed during a previous repair. Point them out to
the customer and recommend their replacement.
4. Look for parts which, through functioning, show obvious signs
of deterioration. Point them out to the customer and recommend
their replacement.
5. Check the B+ voltage to see it is at the values specified.
6. Flexible Circuit Board Repairing
• Keep the temperature of the soldering iron around 270°C
during repairing.
• Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
• Be careful not to apply force on the conductor when soldering
or unsoldering.

1-1
1. SERVICE NOTE
1-1. PRECAUTION ON REPLACING THE SY-255 BOARD
DESTINATION DATA
When you replace to the repairing board, the written destination data of repairing board also might be changed to original setting.
Start the Adjust Manual in the Adjust Station and execute the “DESTINATION DATA WRITE”.
RESTORE DATA
When you replace to the repairing board, get the data from the former one.
Start the Adjust Manual in the Adjust Station and perform “RESTORE DATA” to get the data.
The data getting for this model is as follows.
• USB SERIAL No.
• AWB standard data input & check, Color reproduction check
• Strobe adjustment
• Wide Limit adjustment
Regarding the PMB Portable
PMB Portable has been written in internal memory.
SY-255 board for service is supplied with written the PMB Portable.
USB SERIAL No.
The set is shipped with a unique ID (USB Serial No.) written in it.
This ID has not been written in a new board for service, and therefore it must be entered after the board replacement.
Start the Adjust Manual in the Adjust Station and execute the “USB SERIAL No. INPUT”.
Angular Velocity Sensor
When you replace to the repairing board, write down the sensitivity displayed on the angular velocity sensor (SE401).
Start the Adjust Manual in the Adjust Station and execute the “Angular velocity sensor sensitivity adj”.
SE401
PPP
YYY
PPP: PITCH sensor
sensitivity
YYY: YAW sensor
sensitivity
SY-255 BOARD (SIDE B)
Note: The sensor sensitivity of SE401 of SY-255 board is written only repair parts.
1-2. METHOD FOR COPYING OR ERASING THE DATA IN INTERNAL MEMORY
The data can be copied/erased by the operations on the HOME screen. (When erasing the data, execute formatting the internal memory.)
Note 1:When replacing the SY-255 board, erase the data in internal memory of the board before replacement.
Note 2:When replacing the SY-255 board, execute formatting and initialize the internal memory after replacement.
Method for Copying the Data in Internal Memory
Copy
Copies all images in the internal memory to a memory card.
1Insert a memory card with sufficient free capacity into the camera.
2MENU t(Settings) t(Memory Card Tool) t[Copy] t[OK]
tzon the control button
• Use a fully charged battery pack. If you attempt to copy image files using a battery pack with little
remaining charge, the battery pack may run out, causing copying to fail or possibly corrupting the data.
• Images cannot be copied individually.
• The original images in the internal memory are retained even after copying. To delete the contents of the
internal memory, remove the memory card after copying, then format the internal memory ([Format] in
[Internal Memory Tool]).
• A new folder is created on the memory card and all the data will be copied to it. You cannot choose a
specific folder and copy images to it.
Notes
Method for Formatting the Internal Memory or Memory Card media
Format
Formats the memory card or the internal memory. When you use a memory card with this
camera for the first time, it is recommended to format the card using the camera for stable
performance of the memory card before shooting. Note that formatting permanently erases all
data on the memory card, and is unrecoverable. Save precious data on a computer, etc.
1MENU t(Settings) t(Memory Card Tool) or (Internal
Memory Tool) t[Format] t[OK] tzon the control button
• Note that formatting permanently erases all data including even protected images.
Note
DSC-H55_L2

DSC-H55_L2
1-2
1-3. HOW TO WRITE DATA TO INTERNAL MEMORY
Usually, the camera has been set so as to disable the data writing from the PC to the internal memory of the camera.
This setting must be changed temporarily when the data is to be written to the internal memory such as a case after the board replacement.
To change settings is enabled with using the writing enabler tool (Write Enable Tool) on the Adjust Manual is activating from the Adjust
Station.
Data writing method
1) Start the Adjust Manual from the Adjust Station.
2) Click (Write Enable Tool) button.
3) Click “Activate Write Enable Mode” button.
4) Upon completion of the setting change, the following message will be displayed.
5) Return the driver to the original one, and connect the PC to the camera (USB mode: Mass Storage).
6) Write the data read out into the PC to the internal memory of the camera.
7) Disconnect the PC from the camera, and turn off the camera.
Note: By turning off the camera, the write enable setting is reset.
1-4. SELF-DIAGNOSIS FUNCTION
1-4-2. Self-diagnosis Display
When problems occur while the unit is operating, the LCD screen
shows a 4-digit display consisting of an alphabet and numbers, which
blinks at 3.2 Hz. This 5-character display indicates the “repaired
by:”, “block” in which the problem occurred, and “detailed code”
of the problem.
1-4-1. Self-diagnosis Function
When problems occur while the unit is operating, the self-diagnosis
function starts working, and displays on the LCD screen what to
do.
Details of the self-diagnosis functions are provided in the Instruc-
tion manual.
00
32C
Repaired by:
Refer to “1-4-3. Self-diagnosis Code Tabl e”.
Indicates the appropriate
step to be taken.
E.g.
13 ....
32 ....Turn on power again.
Block Detailed Code
Blinks at 3.2 Hz
C : Corrected by customer
E : Corrected by service
engineer
LCD screen
Format the memory card.

DSC-H55_L2
1-3
1-4-3. Self-diagnosis Code Table
Self-diagnosis Code
Symptom/State Correction
Repaired by:
Block
Function
Detailed
Code
C1 3 0 1
The internal memory has experienced a
media error. Turn the power off and on again.
The internal memory has experienced a
format error. Format the internal memory.
Memory card is unformatted. Format the memory card.
Memory card is broken. Insert a new memory card.
Memory card type error Insert a supported memory card.
The camera cannot read or write dataon
the memory card.
Turn the power off and on again, or taking out and inserting the
memory card several times.
C 3 2 0 1 Trouble with hardware Turn the power off and on again.
E6 1 0 0
Difficult to adjust focus
(Cannot initialize focus)
Retry turn the power on by the power switch. If it does not
recover, check the focus reset sensor of lens block (pin 6of
CN401 on the SY-255 board). If it is OK, check the focus motor
drive IC (IC401 on the SY-255 board).
E6 1 1 0
Zoom operations fault
(Cannot initialize zoom lens.)
Retry turn the power on by the power switch. Check the zoom
reset sensor of lens block (pin 0of CN401 on the SY-255
board) when zooming is performed when the zoom button is
operated. If it is OK, check the zoom motor drive IC (IC401
on the SY-255 board).
E 6 2 0 2 Abnormality of IC for steadyshot. Check or replacement of the IC for steadyshot (IC401 on the
SY-255 board).
E 6 2 1 0 Lens initializing failure. Check or replacement of the IC for steadyshot (IC401 on the
SY-255 board).
E 6 2 1 1 Lens overheating (PITCH).
Check the HALL element (PITCH) of optical image stabilizer
(pin rk, t; of CN401 on the SY-255 board). If it is OK, check
PITCH angular velocity sensor (SE401 on the SY-255 board)
peripheral circuits.
E 6 2 1 2 Lens overheating (YAW).
Check the HALL element (YAW) of optical image stabilizer
(pin ef, eh of CN401 on the SY-255 board). If it is OK, check
YAW angular velocity sensor (SE401 on the SY-255 board)
peripheral circuits.
E 6 2 2 0 Abnormality of thermistor. Check the OIS temp sensor of optical image stabilizer (pin qs
of CN401 on the SY-255 board).
E 9 1 0 1 Abnormality when flash is being charged. Checking of flash unit or replacement of flash unit. (Note)
E 9 2 0 0 Non-standard battery is used. Use the compatible battery only.
E 9 4 0 0 Internal memory fault Inspect the internal memory (IC201 on the SY-255 board).
Note: After repair, be sure to perform “1-5. PROCESS AFTER FIXING FLASH ERROR”.
1-5. PROCESS AFTER FIXING FLASH ERROR
When “FLASH error” (Self-diagnosis Code E : 91 : 01) occurs, to prevent any abnormal situation caused by high voltage, setting of the flash
is changed automatically to disabling charge and flash setting.
After fixing, this setting needs to be deactivated. Flash error code can be initialized by the operations on the HOME screen.
Method for Initializing the Flash Error Code
Initialize
Initializes the setting to the default setting.
Even if you execute this function, the images are retained.
1MENU t(Settings) t(Main Settings) t[Initialize] t[OK] t
zon the control button
• Be sure not to turn off the camera while initializing.
Note

DSC-H55_L2
1-4
1-6 . ORNAMENTAL RING A OR BARRIER ASSY REPLACING METHOD
2Peel off release papers of Barrier Tapes.
3Install Ornamental Ring A and press it lightly.
Installation
5Remove Barrier Assy by disengaging four claws.
Removal
1Turn on the power switch and extend the lens.
2Detach the battery.
4Remove while turning the Ornamental Ring A right and left.
3Pour a solvent such as alcohol from four places Ato the tweezers or a needle shown below into a gap of Ornamental Ring A.
Barrier Tapes
Barrier Tapes Ornamental Ring A
1With four claws fitted in position, install the Barrier Assy.
Hole
Tweezers
Claws
Claws
Barrier Assy
A
A
Ornamental Ring A
Solvent
Barrier Assy
Claws
Claws
Barrier
Lever
Removal
1-7. CAM TUBE BLOCK REPLACING METHOD
1Remove the four soldering, and disconnect the flexible board form the connector.
2Remove the flexible board from the three tabs with peeling off the adhesive tapes.
3Remove the screw, and remove the zoom motor.
Flexible
Board
Flexible
Board
SoldersConnector
Flexible
Board
Adhesive Tapes
Adhesive Tapes
Tabs
Screw
Zoom Moto
r

DSC-H55_L2
1-5
6Rotate the Naruto Gear and the lens is drawn out.
7Pass the Flexible Board through the hole of the Fixed Stationary Tube.
8Rotate the Naruto Gear and the lens is retracticle.
9Remove the Naruto Gear.
4Remove the spring from the hook.
5Remove the five screws, and remove the Rear Mirror Plate.
Naruto Gear
Naruto Gear
Naruto Gear
Flexible
Board
Fixed Stationary Tube
Hook
Spring
Screws
Screws
Rear Mirror Plate
qg Rotate the Straight Tube B.
qh Remove the 2 Group Assy.
qj Remove the Straight Tube B.
2 Group Assy
Straight Tube B
Straight Tube B
Cam Tube Block Assy
0Remove the Fixed Stationary Tube.
qa Rotate the Cam Tube Block Assy.
qs Remove the 1 Group Assy.
qd Rotate the Straight Tube B.
qf Remove the Shutter Assy, and remove the 3 Group Assy.
Fixed
Stationary Tube
Cam Tube
Block Assy
Shutter Assy
Straight
Tube B
1 Group Assy
3 Group Assy

DSC-H55_L2
1-6
7Install the 1 Group Assy so that the Coma attached white part match the opposite side groove of triangle-shaped projection.
Installation
1Install Straight Tube B to Cam Tube Block Assy with aligning the positions as shown in figure.
2Install the 2 Group Assy to Cam Tube Block Assy so that white part of 2 Group Assy becomes opposite position of gear portion
of Cam Tube Block Assy.
3Rotate the Straight Tube B.
4Install the 3 Group Assy.
5Install the Shutter Assy. (floating slightly)
6Rotate the Straight Tube B.
2 Group Assy White part
Straight Tube B
Straight Tube B
Cam Tube
Block Assy
Gear portion of
Cam Tube Block Assy
Coma attached
white part
Triangle-shaped
projection
Shutter Assy Straight
Tube B
3 Group Assy
8Install the Cam Tube Assy to 1 Group Assy with aligning gear edge of Cam tube Assy
with triangle-shaped projection of 1 Group Assy.
9Rotate the 1 Group Assy with tucking it slightly.
0Rotate the straight tube B only.
qa Rotate the Cam Tube Block Assy only. (lens tube is dropped.)
Fixed Stationary
Tube Block
qs Insert the lens tube to Fixed Stationary Tube Block.
qd Rotate the Cam Tube Block Assy slightly, insert it into the lens tube.
Triangle-shaped
projection
Gear edge
Straight
Tube B
Cam Tube
Block Assy
1 Group Assy
Cam Tube
Block Assy
Cam Tube
Block Assy

DSC-H55_L2
1-7
qj Install the Rear Mirror Plate with the five screws in the order of numbers.
Up side
Down side
Screws
Screws
Rear mirror plate
1
3
4
52
Fixed Stationary
Tube Block
Flexible boards
Naruto Gear
Naruto Gear
Holding part
qf Install the Naruto Gear. (up side is shallow hole side.)
qg Extension the lens by turning the Naruto Gear.
qh Eject the Flexible Board from Fixed Stationary Tube Block, set the selvage of Flexible Board into the holding part.
ws Connect the Flexible board to the connector, and solder the four locations.
wd Perform the Flange Back Adjustment after the assembling.
w; Install the Zoom Motor with the screw.
wa Install the Flexible board with the five Adhesive Tapes and three claws.
qk Install the spring to hook.
ql Rotate the Naruto Gear and the lens is retracticle.
Solders
Flexible
board
Flexible
board
Flexible
board
Hook
Spring
Screw
Zoom Motor
Claws
Adhesive tapes
Adhesive tapes

DSC-H55_L2
1-8E
1-8. FINAL INSPECTION
1-8-1. Confirm There Is No Fault In Actual Motion/Actual Screen
Inspect it as follows when you exchange parts in the lens block.
1Zoom motion (Check five postures: horizontal, upward/downward, upper/lower oblique 45º)
No abnormal sound or motion must be found over full stroke between TELE end and WIDE end.
2Zoom image
No abnormality such as a skipped image or wavy image must be found in the image through LCD or finder over full stroke betwee
n
TELE end and WIDE end.
3Barrier (Check five postures: horizontal, upward/downward, upper/lower oblique 45º)
The barrier must be opened and closed fully, free from a sticking in the midway.
No abnormal sound must be heard during the operation.
4Appearance condition
Scratches or stains must not be noticeable, except that the customer permits them.
5Foreign matters on the lens
The lens condition must not be worse than that when the camera was received from the customer.
Downward
Lower oblique 45º
Lower oblique 45º
Horizontal
Upward
Full stroke check
Lens at TELE end
Lens at WIDE end
1-8-2. Inspection When Cam Tube Block Is Replaced
Focus check
1Preparation
• Camera installed re-assemble lens.
• Chart (Printed PDF file at the same magnification) (Refer to <Reference>)
• Tripod
• Mirror (ex. CD)
• Memory card
• PC
2Shoot setting
(1) Paste the chart.
• Chart should be on the flat wall.
• Illuminance level in the chart should be the same.
• Make the tripod’s height and the center of the chart to the same height.
• Enough space needed for shooting.
(2) Set the camera.
• Set [P] mode
• Set [Maximum] size
• Set ISO lowest level
• Set Steady Shot [OFF]
• Set Flash [OFF]
(3) Set the camera on a tripod.
(4) Adjust the position of the camera and the chart.
1. Set the zoom position of the camera at Wide end.
2. Attach the mirror onto the center of the chart.
* The mirror should not tilt on the chart.
3. Set the camera to display the chart on LCD like in the following picture.
4. Adjust the camera position to the center of the chart.
* Adjust the tripod height and the position (Lateral direction).
5. Adjust the camera angle to the frame of the chart with tripod.
Remove the mirror.
3Shooting
(1) Set [Self-Timer]
(2) Shot
4Check the shot image.
(1) Check the shot image on PC.
100% Display (Display at the same magnification of its Pixel.)
Compare the image with the sample you set.
No extreme focus blurring
It should be distinguished the black and white by the sharpness between them.
If it is in NG level, replace the lens unit.
<Reference>
• How to Print the Chart
Print “Forcus-Chart_A3.pdf” with printer.
Print at the same magnification (It means 100 % size).
Check the settings of printer to print in proper size.
• Check of chart size.
Make charts together and check if the size of charts is the following size.
* The chart consists of 2 pcs.

DSC-H55_L2
2-1
2. REPAIR PARTS LIST
Follow the disassembly in the numerical order given.
AC- DIS-
IDENTIFYING PARTS
Link ACCESSORIESDISCHARGING OF THE CHARGING CAPACITOR
• Abbreviation
AR : Argentine model
AUS : Australian model
BR : Brazilian model
CND : Canadian model
CH : Chinese model
HK : Hong Kong model
KR : Korea model
ASSEMBLY
NOTE:
• -XX, -X mean standardized parts, so they may have some differences from the original
one.
• Items marked “*” are not stocked since they are seldom required for routine service.
Some delay should be anticipated when ordering these items.
• The mechanical parts with no reference number in the exploded views are not sup-
plied.
• Due to standardization, replacements in the parts list may be different from the parts
specified in the diagrams or the components used on the set.
• CAPACITORS:
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA...: μA... , uPA... , μPA... ,
uPB... , μPB... , μPC... , μPC... ,
uPD..., μPD...
• Color Indication of Appearance Parts
Example:
(SILVER) : Cabinet’s Color
(Silver) : Parts Color
The components identified by mark 0
or dotted line with mark 0are critical for
safety.
Replace only with part number specified.
Les composants identifiés par une marque
0sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
1Cabinet Bottom
2Cabinet (Horizontal)
3Cabinet (Rear) Assy
4SW-567 Board
5Main Frame
6LCD Block Assy
7Capacitor Holder
8Cabinet (Upper) Assy
• RL-098 Board
• AF-129 Flexible Board
• RL-099 Flexible Board
q; SY-255 Board
qa SY Fixed Plate
qs Multi Fixed Plate
qd MS-436 Board
qf Tripod Screw
qg BT Frame
qj Cabinet
(Front) Assy
qh Lens Block Section
[Disassembly]
[Exploded View]
• CD-785 Flexible Board
Right View
Left View
Front View
Bottom View
Top View
Back View
View Position

DSC-H55_L2
2-2
The charging capacitor (C901) of the RL-098 board is charged
up to the maximum 315 V potential.
There is a danger of electric shock by this high voltage when the
capacitor is handled by hand. The electric shock is caused by the
charged voltage which is kept without discharging when the main
power of the unit is simply turned off. Therefore, the remaining
voltage must be discharged as described below.
Preparing the Short Jig
To preparing the short jig, a small clip is attached to each end of
a resistor of 1 kΩ/1 W (1-215-869-11).
Wrap insulating tape fully around the leads of the resistor to
prevent electrical shock.
NOTE FOR REPAIR
• Make sure that the flat cable and flexible board are not cracked
of bent at the terminal.
Do not insert the cable insufficiently nor crookedly.
• When remove a connector, don’t pull at wire of connector. It is
possible that a wire is snapped.
• When installing a connector, don’t press down at wire of con-
nector.
It is possible that a wire is snapped.
• Do not apply excessive load to the gilded flexible board.
DISCHARGING OF THE CHARGING CAPACITOR (C901)
Cut and remove the part of gilt
which comes off at the point.
(Be careful or some
pieces of gilt may be left inside)
Wrap insulating tape.
Note: High-voltage cautions
Discharging the Capacitor
Short-circuit between two points
with the short jig about 10 seconds.
R:1 k
Ω /1 W
(Part code : 1-215-869-11)
C901 RL-098 board

DSC-H55_L2
2-3
2-1. EXPLODED VIEWS
2-1-1. REAR SECTION
Ref. No. Part No. Description Ref. No. Part No. Description
1 4-177-694-11 LID, BT
2 4-177-706-11 CABINET (HORIZONTAL)
*3 4-177-714-01 CUSHION (M)
*4 4-177-698-01 HOLDER, CAPACITOR
*5 4-177-702-01 FRAME, MAIN
*6 4-177-717-01 CUSHION (G)
*7 4-177-715-01 PLATE (AKY), GROUND (Note 2)
8 4-177-707-01 BOTTOM, CABINET
9 X-2547-135-1 CABINET REAR ASSY (360SL) (SILVER)
9 X-2547-136-1 CABINET REAR ASSY (360BK) (BLACK)
10 A-1768-823-A SW-567 BOARD, COMPLETE
11 1-880-483-11 SW-568 FLEXIBLE BOARD
LCD901 A-1771-479-A LCD BLOCK ASSY (SERVICE USE)
#65 2-635-591-01 SCREW (M1.4), NEW TRUSTAR P2 (Note 1)
#147 2-662-396-41 SCREW (M1.4), NEW, TRUSTAR, P2 (Note 1)
#177 3-208-537-21 0+Z M1.4X2 NEW TORASUTA
1. Remove to numerical order (1to 7) in the left figure.
DISASSEMBLY
1#65 / #147 X 2
Screw
Note
Note 2: Refer to "Assembly-2: Check the claw of Ground Plate is
completely caught" when replacing this part.
2#65 / #147 X 1
3#65 / #147 X 4
#65
#147
#177
1
2
4
3
6
5
7
9
10
11
8
LCD901
1
2
3
5
7
4
6
#65
#147 #65
#147
#65
(Note 2)
(Note 1)
(Note 1)
(Note 1) (Note 1)
#147
Top Section
(See page 2-4)
#65
#147
Bottom View Bottom View
#65
#147
Right View Left View
#65
#147 #65 #147
#65: M1.4 X 3.5
(Silver)
2-635-591-01
3.5
1.4
3.5
1.4
#147: M1.4 X 3.5
(Black)
2-662-396-41
#177: M1.4 X 2.5
(Red)
3-208-537-21
2.5
1.4
Note 1
THE COMBINATION OF
CABINET’S COLOR AND SCREW
Screw's
Ref. No. (Parts Color.)
#65 (Silver) SILVER
#147 (Black) BLACK
Cabinet's Color
Ta b l e 2 - 1
The screw pointed is different according to the
cabinet's color.
For the combination of cabinet's color and screw, please
refer to Table 2-1.

DSC-H55_L2
2-4
2-1-2. TOP SECTION
ns: not supplied
Ref. No. Part No. Description Ref. No. Part No. Description
51 X-2547-133-1 CABINET (UPPER) ASSY (360)
52 4-178-706-01 PLATE, MODE (360)
53 4-192-388-01 KNOB (SERVICE), MODE
54 1-880-484-11 RL-099 FLEXIBLE BOARD
55 4-177-709-01 SCREEN, WINDOW
56 4-177-708-01 RUBBER, MICROPHONE
57 A-1768-824-A RL-098 BOARD, COMPLETE
*58 4-177-712-01 RETAINER, RL
59 A-1764-316-A AF-129 FLEXIBLE BOARD, COMPLETE
*60 4-181-034-01 CUSHION (BB)
*61 4-181-646-01 HOLDER (NA), AF
*62 1-480-482-11 FLASH UNIT
C901 1-114-592-21 CAP, ELECT 87uF 99% 315V
#23 3-080-204-11 SCREW, TAPPING, P2
#65 2-635-591-01 SCREW (M1.4), NEW TRUSTAR P2
#177 3-208-537-21 0+Z M1.4X2 NEW TORASUTA
DISCHARGING OF THE CHARGING CAPACITOR
1. Remove to numerical order (8to 9) in the left figure.
DISASSEMBLY
9
8Disconnect Flexible board (8-1) →#23 X 1 →Slide top section (8-2)
Screw
#23
Back View Back View Back View
#23: M1.7 X 4.0 (Tapping)
(Black)
3-080-204-11
4.0
1.7
#177: M1.4 X 2.5
(Red)
3-208-537-21
2.5
1.4
#23
#23
ns
C901
#177
#65
Front Section
(See page 2-5)
51
52
53
54
55
56
57
58
62
60
59
8
9
61
8-1
8-2
#65: M1.4 X 3.5
(Silver)
2-635-591-01
3.5
1.4

DSC-H55_L2
2-5
Ref. No. Part No. Description Ref. No. Part No. Description
101 X-2547-004-1 CABINET (FRONT) ASSY (460BK) (BLACK)
101 X-2547-131-1 CABINET (FRONT) ASSY (360SL) (SILVER)
*102 4-177-701-01 SCREW, TRIPOD
103 4-177-718-01 CUSHION, LENS
104 4-177-693-01 SPRING, BT DISCHARGE
*105 4-177-695-01 COVER, DC (BLACK)
*105 4-177-695-21 COVER, DC (SILVER)
*106 4-177-692-01 FRAME, BT
107 1-880-482-11 BT-059 FLEXIBLE BOARD
108 1-880-481-11 MS-438 FLEXIBLE BOARD
109 A-1764-313-A MS-436 BOARD, COMPLETE
*110 4-177-699-01 PLATE, MULTI FIXED
*111 4-177-700-01 PLATE, SY FIXED
112 A-1773-701-A SY-255 BOARD, COMPLETE (SERVICE)
*113 4-187-546-01 SHEET (L) (Note)
114 4-181-033-01 SHEET (SZ)
BT001 1-756-813-11 LITHIUM RECHARGEABLE BATTERY
BT901 1-780-764-11 TERMINAL BOARD, BATTERY
SP901 1-858-343-31 LOUDSPEAKER (1.0CM)
#23 3-080-204-11 SCREW, TAPPING, P2
2-1-3. FRONT SECTION
ns: not supplied
1. Remove to numerical order (0to qj) in the left figure.
DISASSEMBLY
qs #23 X 1
Screw
#23: M1.7 X 4.0 (Tapping)
(Black)
3-080-204-11
4.0
1.7
qg
Claws
Claw
Back View
Note
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
Note : Refer to “Assembly-1: Precaution During of attachment
Sheet (L)” when replacing this part.
SY-255
#23
BT901
BT001
ns
SP901
Lens Block Section
(See page 2-6)
101
102
104
111
112
103
113
105
106
107
108 109
110
q;
qa
qs
qf
qg
qh
qj
qd
: BT001 (LITHIUM RECHARGEABLE BATTERY)
Board on the mount position.
(Seepage6-13)
(Note)
114
#23
Back View

DSC-H55_L2
2-6
2-1-4. LENS BLOCK SECTION
ns: not supplied
Ref. No. Part No. Description Ref. No. Part No. Description
151 1-856-013-11 OPTICAL UNIT (BE006) (Note 1, 2)
152 4-174-736-01 TUBE (BE006), CAM
153 4-174-733-01 GEAR (BE006), NARUTO
154 4-174-734-01 SPRING (BE006), FG LEAF
155 1-487-859-11 MOTOR GEAR BLOCK, ZOOM (BE006)
156 4-174-735-01 RING (A (BE006)), ORNAMENTAL
157 X-2546-574-1 BARRIER ASSY (BE006)
158 1-856-059-11 OPTICAL FILTERBLOCK (OFB-02-41) (Note 4)
159 4-176-702-01 FILTER SPACER (Note 4)
160 A-1768-825-A CD-785 FLEXIBLE BOARD, COMPLETE
(including IC001(CCD Imager)) (Note 3)
#30 3-086-156-11 SCREW B1.2
Note
1. The meaning of the sign in left figure is as follows. Be careful when it removes.
◇: Solder
DISASSEMBLY
Screw
#30: M1.2 X 3.5 (Tapping)
(White)
3-086-156-11
3.5
1.2
Note 1
PRECAUTIONS WHEN HOLDING THE LENS BLOCK
•Hold the Lens Block at the
center of both sides.
•Do not hold the following part.
Hold here.
Hold here.
Focus LensFlexible Board
solder portion
Flexible Board
holding portion
Zoom Motor
Focus Motor
F Reset Sensor
Z Reset Sensor
Note 2: Refer to the following each item when you exchange parts
of Lens Block.
• 1-6. ORNAMENTAL RING A OR BARRIER ASSY RE-
PLACING METHOD (page 1-4)
• 1-7. CAM TUBE BLOCK REPLACING METHOD (page
1-4)
• 1-8. FINAL INSPECTION (page 1-8)
Note 3: Be sure to read “Precautions for Replacement of Imager”
on page 6-1 when changing the imager.
Note 4: Refer to “Assembly-3: Precaution During of attachment
Filter Spacer and Optical Filter Block” when replacing this
part.
#30
#30
#30
#30
#30
#30
151
(Note 1, 2)
(Note 4)
(Note 4)
ns
ns
ns
ns
ns
ns
(including IC001
(CCD imager))
(Note 3)
ns
ns
156 155
158
159
160
154
157
152
153


DSC-H55_L2
2-7
Checking supplied accessories.
Conversion Adaptor
01-569-008-33 (E (Latin America))
USB, A/V cable for
multi-use terminal
1-836-364-11
Wrist strap
2-050-981-01 (Gray) (SILVER)
2-050-981-11 (Black) (BLACK)
Power cord (mains lead)
(EXCEPT US, CND)
01-832-121-51 (CH)
01-837-420-11 (AR)
01-837-421-11 (UK, HK, E (Saudi))
01-837-427-11 (AEP, E, BR)
01-837-428-11 (KR)
01-837-429-11 (AUS)
Battery charger
(BC-CSGD/BC-CSGE)
01-487-170-21 (US, CND)
01-487-170-51 (EXCEPT US, CND)
Instruction Manual
4-172-684-11 (ENGLISH)
4-172-684-21 (ENGLISH, SPANISH)
4-172-684-31 (ENGLISH, FRENCH)
4-172-684-41 (ENGLISH, RUSSIAN, UKRAINIAN)
4-172-684-51 (ENGLISH, FRENCH, ITALIAN, SPANISH,
PORTUGUESE, GERMAN, DUTCH, TURKISH, GREEK,
POLISH, CZECH, HUNGARIAN, SLOVAK, SWEDISH,
FINNISH, NORWEGIAN, DANISH, CROATIAN, ROMANIAN)
4-172-684-61 (ENGLISH, TRADITIONAL CHINESE,
SIMPLIFIED CHINESE, MALAY, INDONESIAN, THAI,
ARABIC, PERSIAN)
4-172-684-71 (ENGLISH, SPANISH, PORTUGUESE)
4-172-684-81 (ENGLISH, TRADITIONAL CHINESE,
SIMPLIFIED CHINESE, INDONESIAN, ARABIC,
PERSIAN)
4-172-685-11 (ENGLISH, TRADITIONAL CHINESE, SIMPLIFIED CHINESE)
4-172-685-21 (KOREAN)
4-172-685-31 (SPANISH, PORTUGUESE)
4-182-809-11 (ENGLISH, ARABIC, PERSIAN)
CD-ROM
(Cyber-shot application software /
“Cyber-shot Handbook”)
4-172-677-01
Cyber-shot Handbook (PDF)
The CD-ROM supplied contains all of language version of
the Instruction Manual in pdf (Cyber-shot Handbook.pdf) for printing.
The printed matter is not supplied. If required,
please order it with the part number below.
4-172-679-11 (ENGLISH)
4-172-679-21 (FRENCH)
4-172-679-31 (ITALIAN)
4-172-679-41 (SPANISH)
4-172-679-51 (PORTUGUESE)
4-172-679-61 (GERMAN)
4-172-679-71 (DUTCH)
4-172-679-81 (TRADITIONAL CHINESE)
4-172-679-91 (SIMPLIFIED CHINESE)
4-172-680-11 (RUSSIAN)
4-172-680-21 (ARABIC)
4-172-680-31 (PERSIAN)
4-172-680-41 (KOREAN)
4-172-680-51 (POLISH)
4-172-680-61 (CZECH)
4-172-680-71 (HUNGARIAN)
4-172-680-81 (SLOVAK)
4-172-680-91 (SWEDISH)
4-172-681-11 (FINNISH)
4-172-681-21 (NORWEGIAN)
4-172-681-31 (DANISH)
4-172-681-41 (THAI)
4-172-681-51 (MALAY)
4-172-681-61 (TURKISH)
4-172-681-71 (GREEK)
4-172-681-81 (UKRAINIAN)
4-172-681-91 (CROATIAN)
4-172-682-11 (ROMANIAN)
4-172-682-21 (INDONESIAN)
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
Rechargeable battery pack
(NP-BG1)
(Battery case is not supplied separately.)
0A-1567-198-A (US, CND)
0A-1641-431-A (EXCEPT US, CND)

DSC-H55_L2
2-8E
Ref. No. Part No. Description Ref. No. Part No. Description
Ref. No. Part No. Description
2-2. ELECTRICAL PARTS LIST
A-1764-316-A AF-129 FLEXIBLE BOARD, COMPLETE
******************************
< DIODE >
*D001 6-501-861-01 DIODE CL-360S-TD4-X-TL
************************************************************
1-880-482-11 BT-059 FLEXIBLE BOARD
********************
(BT901 is not included in BT-059 flexible board.)
< BATTERY TERMINAL BOARD>
BT901 1-780-764-11 TERMINAL BOARD, BATTERY
************************************************************
A-1764-313-A MS-436 BOARD, COMPLETE
**********************
BT001 1-756-710-12 LITHIUM RECHARGEABLE BATTERY(Note)
< CAPACITOR >
*C003 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C005 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN002 1-822-837-21 CARD CONNECTOR
*CN003 1-817-828-81 CONNECTOR, FPC (ZIF) 25P
< RESISTOR >
R001 1-218-945-11 METAL CHIP 220 5% 1/16W
************************************************************
1-880-481-11 MS-438 FLEXIBLE BOARD
************************************************************
A-1768-824-A RL-098 BOARD, COMPLETE
**********************
(MIC202 is not supplied, but this is included in RL-098 complete board.)
*1-480-482-11 FLASH UNIT
< CAPACITOR >
C101 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
*C102 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C104 1-164-850-11 CERAMIC CHIP 10pF 0.5pF 50V
C105 1-100-758-11 CERAMIC CHIP 0.047uF 10% 250V
C901 1-114-592-21 ELECT 87uF 99% 315V
< CONNECTOR >
*CN201 1-821-500-11 CONNECTOR, FPC (ZIF) 45P
< DIODE >
D102 6-501-096-01 DIODE CRF02 (TE85R)
D201 6-500-594-01 DIODE CL-196SYG-CD-T
< IC >
*IC101 6-712-975-01 IC BD4215NUV-E2
< COIL >
*L101 1-400-820-11 INDUCTOR 2.2uH
< MICROPHONE >
MIC202 (Not supplied) MICROPHONE
(MIC202 is supplied included in RL-098 complete board.)
< TRANSISTOR >
*Q101 6-551-922-01 TR RJP4002ASA-00-Q0
< RESISTOR >
R102 1-216-121-11 METAL CHIP 1M 5% 1/10W
R103 1-218-989-11 METAL CHIP 1M 5% 1/16W
R104 1-218-935-11 METAL CHIP 33 5% 1/16W
R201 1-240-690-91 METAL CHIP 390 5% 1/20W
R202 1-240-729-91 METAL CHIP 1M 5% 1/20W
R203 1-240-729-91 METAL CHIP 1M 5% 1/20W
R204 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB201 1-234-376-11 RES, NETWORK 2.2K (1005X4)
RB203 1-234-376-11 RES, NETWORK 2.2K (1005X4)
< SWITCH >
S201 1-786-914-31 TACTILE SWITCH
S203 1-798-314-11 TACTILE SWITCH (ZOOM SWITCH)
S204 1-798-312-11 ROTARY SWITCH
< TRANSFORMER >
*T101 1-445-491-21 D.C.-D.C.CONVERTER TRANSFORMER
************************************************************
1-880-484-11 RL-099 FLEXIBLE BOARD
************************************************************
A-1768-823-A SW-567 BOARD, COMPLETE
************
< CONNECTOR >
*CN001 1-821-857-51 CONNECTOR, FPC (LIF (NON-ZIF))
< RESISTOR >
R015 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB001 1-234-376-11 RES, NETWORK 2.2K (1005X4)
< SWITCH >
*S001 1-786-914-31 SWITCH, TACTILE
*S002 1-786-914-31 SWITCH, TACTILE
*S003 1-786-914-31 SWITCH, TACTILE
*S004 1-786-914-31 SWITCH, TACTILE
*S005 1-786-914-31 SWITCH, TACTILE
*S006 1-786-914-31 SWITCH, TACTILE
RL-099 SW-567
Caution
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
Please refer to LEVEL 3 about the ELECTRICAL PARTS LIST of
CD-785 flexible board or SY-255 board.
AF-129 MS-436 MS-438BT-059 RL-098
*S007 1-786-914-31 SWITCH, TACTILE
*S008 1-786-914-31 SWITCH, TACTILE
< THERMISTOR >
TH001 1-805-194-21 THERMISTOR, NTC (SMD)
***********************************************************
1-880-483-11 SW-568 FLEXIBLE BOARD
***********************************************************
SW-568

DSC-H55_L2
3-1E
3. ASSEMBLY
Assembly-1: Precaution During of attachment Sheet (L).
Sheet (L)
Sticking standard
Mountain fold
In case of improper attaching in this part,
push this part by the power of the extent
lightly touched.
Assembly-2: Check the claw of the Ground Plate
is completely caught.
Claw
Main Frame
Ground Plate
Assembly-3: Precaution During of attachment
Filter Spacer and Optical Filter Block.
Filter Spacer
Cutting portion Optical Filter Block
