Camtree Hunt CH-MOD-SRK User manual

Mod Cage Shoulder Rig Kit for
Blackmagic Pocket Camera
(CH-MOD-SRK)
CAMTREE HUNT
INSTRUCTION MANUAL
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any
means, electronic, mechanical, photocopying, recording, or otherwise, except as may be expressly permied by
the applicable copyright statutes or in wring by the Publisher.

CAMTREE HUNT MOD CAGE SHOULDER RIG FOR BLACKMAGIC POCKET CAMERA 2
I N T R O D U C T I O N
Use our brand-new CAMTREE HUNT MOD SHOULDER RIG FOR BLACK MAGIC POCKET CAMERA to
get shots as desired every me you are on the move. Sophiscated in design and funconality
but easy to set up and use, this Cage with an A-Box, truly is a value added producon tool,
second to none.
I N T HE BO X
Please inspect the contents of your shipped package to ensure you have received all that is
pictured and listed below.
MOD Cage 15mm Adapter
Sliding Base Plate
Top Handle Handle Set
Hot Shoe
Adapter
Shoulder Pad
4x 300mm Female Rods 3x Wire Organizers
A-Box
Camtree X9 Follow Focus

CAMTREE HUNT MOD CAGE SHOULDER RIG FOR BLACKMAGIC POCKET CAMERA 3
 Now insert camera into the cage and ghten the screw with help of screw driver.
 Then, aach top handle onto cage and
ghten the knob to secure.
 Aach 15mm rod adapter to Mod cage with help of provided knob and Slide the cage to
sliding base plate, ghten properly as shown below.
A S S E M B LING YO U R C A M T R E E H UNT MOD CAGE SHOULDER RIG KIT

CAMTREE HUNT MOD CAGE SHOULDER RIG FOR BLACKMAGIC POCKET CAMERA 4
 Now insert straight bracket at back of
rails and ghten with provided knob.
 Insert 2x 300mm rails into rod adapter and ghten with provided knob as shown.
 Aach camera set-up onto your tripod plate, now mount the set-up onto tripod and ghten
the knob to secure.

CAMTREE HUNT MOD CAGE SHOULDER RIG FOR BLACKMAGIC POCKET CAMERA 5
 Then clip A-Box wire to rails with help
of wire clamp.
 Loosen front cage knobs via allen key and insert A-Box wire to it.
 Insert other two rails into straight bracket and ghten the knob to secure. Now insert
A-Box into rails and ghten the knob as shown below.

CAMTREE HUNT MOD CAGE SHOULDER RIG FOR BLACKMAGIC POCKET CAMERA 6
 Now insert handle set to front of rail system and secure with provided levers. You can also
adjust the posion of handles with the help of provided knobs.
 Now insert the shoulder pad as
shown.
 Aach gear ring to the camera lens and then aach Follow Focus by matching the teeth of
gear belt with the drive gear as shown below.

CAMTREE HUNT MOD CAGE SHOULDER RIG FOR BLACKMAGIC POCKET CAMERA 7
YOUR CAMTREE H U N T MOD CAG E SHOULDER C A G E R I G K I T
ALL DR ESS E D U P A N D GOOD TO G O
(SHOWN WITH OPTIONAL ACCESSORIES)
WARRANTY
We oer a one year warranty for our products from the date of purchase.
We will repair or replace your product, free of charge, in the event of a defect in materials or
crasmanship obtained during normal use or handling based on the user manual. Please note
that we will not cover any shipping costs for returning the product to us. If any VAT or import
dues are applied to the return, we will also charge these costs to the customer.
The warranty does not include, by the way of example, damage caused by products that we do
not supply or from mishandling in transit, accident, misuse, neglect, lack of care of the product ,
or service by anyone other than our company.
We are not liable for incidental or consequenal damages resulng from the use of the unit or
occurring due to any breach of this warranty.
Replacement parts of the product will be provided at nominal cost (covering the cost price of the
replacement parts only) to the customers aer the Warranty Period has expired. We will cover
the complete cost of sending replacement parts within the warranty period. Aer that, Nominal
cost of the product & Actual shipping cost will be charged.
Do not send the unit to us without rst geng a response and geng the approval to send back
the item.
In case of any kind of dissasfacon, we urge you to Contact us immediately and we shall do our
Best to help you out. For any other assistance you can reach us via email.
