Canadian Heating Products Econo-Plus 36DV-RV Operating instructions

Page 1 of 11
09/96
INSTALLING AND OPERATING
YOURECONO-PLUS36DV-RV
GAS-BURNING FIREPLACE
Please leave this manual with the owner
CHECK LOCAL CODES PRIOR TO INSTALLATION
READINSTRUCTIONSCAREFULLYBEFOREINSTALLING
MODEL
ECONO-PLUS36DV-RV
ECONO-PLUS36DV-RV
FOR YOUR SAFETY FOR YOUR SAFETY:
IF YOU SMELL GAS:
1. OPENWINDOWS. DONOTSTOREORUSEANYFLAMMABLE
2.DON'TTOUCHELECTRICALSWITCHES VAPOURSORLIQUIDSNEARTHISORANY
3.EXTINGUISHANYOPENFLAME. OTHERGAS-BURNINGAPPLIANCE.
4.IMMEDIATELYCALLYOURGASSUPPLIER.
CANADIAN HEATING PRODUCTS INC.
12091 88th Avenue, Surrey, B.C. Canada; Phone: [phone] Fax: [phone]

Page 2 of 11
09/96
INSTALLING THE FIREPLACE
TheEconoPlus36DV-RVclearances to combustiblematerials are
0" back,1"sides,0"floorand4"top. TheEconoPlus36DV-RVmust
not be installed any closer than 8 inches to any unprotected
combustible wall perpendicular to the fireplace opening.
Forprotectionagainstfreezingtemperatures,itisrecommended that
the outer walls of the chase be insulated with a vapour barrier. This
will reduce the possibility of a cold-air convection current on the
fireplace.
THEFRAMINGDIMENSIONSARESHOWNBELOW:
INTRODUCTION
TheEconoPlus36DV-RVisratedat16,000BTUs.(4.16 Kilowatts)
for Natural & Propane gas.
The Econo Plus warranty will be voided by, and Econo Plus
disclaims any responsibility for, the following actions:
- Modification of the fireplace and/or components including
Direct-Vent assembly or glass doors.
- Use of any component part not manufactured or approved by
Econo Plus in combination with a Econo Plus fireplace system.
- Installation other than as instructed in this manual.
Consult your local Gas Inspection Branch about the particular
requirementsconcerninginstallationoffactory-builtgasfireplaces.
Installation&repairsshouldbedonebyaqualified contractor,
andinstallationmustconformwiththecurrentCAN/CGA
B-149.1 and .2 Gas Installation Code and local regulations.
CAUTIONS
* Due to its high operating temperatures, the appliance should be
located out of traffic & away from furniture and draperies.
* Children and adults should be alerted to the hazards of the high
surfacetemperature, which could causeburns or clothing ignition.
* Young children should be carefully supervised when they are in
thesame room as the appliance.
* Clothingorother flammable materials should not be placed on
orneartheappliance.
SELECTING YOUR FIREPLACE LOCATION
The fireplace may be installed in any location that is free of air
condition ducts, electrical wiring and plumbing. Safety, as well as
efficiency of operation, must be considered when selecting the
fireplace location. Try to select a location that does not interfere
withroomtraffic,hasadequate ventilation,and offersan accessible
pathway for Direct Vent & Combustion Air Kit installation.
The fireplace dimensions are shown below:
NOTE: SEEFIGURE2FORFRAMINGDIMENSIONS
FIGURE 1. FIREPLACE DIMENSIONS
19
16 1/4
10 1/4
37 1/2
33
39 1/2
17
36
25 1/2
12
12
37 1/2
12
12
36 25 1/2
17
37 1/2
FIGURE 2. FRAMING DIMENSIONS
37 1/2
59
16 1/4
19
12
42

Page 3 of 11
09/96
CAUTIONS
CAUTION
1). Extremly important: In heavy snow areas take extra care to
prevent against blocking vent termination with snow removal
equipment.
2). Flue gases exiting vent terminals are very hot and must not be
restricted to assure fireplace combustion is not affected.
3). Do not place, build any obstruction, plant any bushes or for any
reason attempt to conceal the vent termination. To do so will
affect the operation of the fireplaceand may be hazardous.
4). Do not recess vent terminals into walls or siding.
5). Terminals with components which exceed 180 F+ ambient
while under continuous operation are required by National
Standards to be protected with an additional screen on patio's,
decks and any areas accessible to public. For maximum safety
we recommend all terminals below 7' from grade level be
installed with a certified Econo Plus Heat Guard.
INSTALLING THE GAS LINE
The gas line must be installed before finishing the Econo Plus
36DV-RV Fireplace. Natural Gas requires an inlet pressure of
7" W.C. & a manifold pressure of 3.5" W.C. Propane Gas
requires an inlet pressure of 11" W.C. & a manifold pressure of
10.5" W.C. It is also required that provisions be made for a
1/8" N.P.T. plugged tapping and be accessable for test gauge
connection immediately upstream of the gas supply controls to
the appliance. The fireplace gas connection and the main
operating gas valve is located behind the removable brass trim
atthebottom of the unit and need only be attached to the gas line
withanapprovedfitting, as required by the CAN/CGAB-149.1
and .2 Gas Installation Code.
*After gas line is connected, it is a CAN/CGA B149.1 & .2. code
requirement (Section 8.25.3 (e)) that "each appliance connection,
valve, valve train, shall be checked while under normal operating
pressure with either a liquid solution, or leak detection device, to
locate any source of leak." Tighten any areas where bubbling
appears or leak is detected until bubbling stops completely or leak
is no longer detected. DoNOT use a flame of any kind to test for
leaks
VENT TERMINATION LOCATION
Refer to the section on selecting a fireplace location to determine
where your Econo Plus 36DV-RV will be installed.
Next, determine the vent terminal location. (see appendix A) for
allowed areas. The outlet must be framed with an 12" x 12" inside
dimension (see Figure 4).
VENT TERMINATIONSSHALLNOTBERECESSEDIN
WALLSORSIDING.
FOR DETAILED SKETCH OF ALLOWED
TERMINATION LOCATIONS SEE APPENDIX A
FORVINYLSIDINGAPPLICATIONS ALLETK
TERMINATIONSMUSTBE INSTALLEDWITHA
HEATSHIELD(MTKG) TOPROTECT THESIDING
FROMANY HEATDAMAGE. ETKOTERMINATIONS
DONOTREQUIREAHEAT SHIELD.
FIGURE 4. VENT TERMINATION FRAMING.
*
IMPORTANT:
When using ETK or ETKO with
MOSR: Framed opening must be
12" X 12"
When using ETK or ETKO:
Framed opening must be 11" X 11"
*12
12
*
ETK-5 or ETK-9 ETKO-5 or ETKO-9
INSTALLING DIRECT VENT
Note: DO NOT STRETCH flexible connectors to gain
extra length. These connectors are flexible only to allow
for directional changes, which must not exceed 90
degrees.
All vent pipes must maintain a minimum of 1"
clearance to combustible materials.
Note: It is imperative for satisfactory operation of the
EconoPlus36DV-RVfireplacethat no venting component
be modified in any way. All components have been
manufacturedto eliminate the need for modificationwhen
properly selected and installed.

Page 4 of 11
09/96
VENTING OF REAR VENT DV
The Econo Plus 36DV-RV has been designed for four possible
rear vent installations.
1). Standard 4" or 6" stud walls. For 4" walls use a stucco
frame and a 5" termination. For 6" walls use a stucco
frame and a 9" termination. (See figure 5).
3). 45 corner kit. Use a 45 elbow, stucco frame and a 5"
termination. (see figure 7).
MSR
ETK-5"
ETK-9"
EEL45
MSR
ETK-5"
ETK-9"
WallThickness
(4" - 12")
MSR
ETKFL-12"
ETKFL-18"
Outside wall
All vent pipes must maintain a minimum of 1"
clearance to combustible materials.
Note: It is imperative for satisfactory operation of
the Econo Plus 36DV-RV fireplace that no venting
component be modified in any way. All components
have been manufactured to eliminate the need for
modification when properly selected and installed.
CAUTIONS AND REQUIREMENTS
2). Extended vent kit. For extended vent use a stucco frame,
20" extended vent and a termination. Note: 20" kit may be
cut to desired length but must never exceed 20". (see figure 6).
ETK-5"
ETK-9"
MSR
EXT-1 (10" Section)
EXT-2 (20" Section)
20
INSTALLING THE REMOTE SWITCH
The Econo Plus 36DV-RV is equipped with a remote-operated
valve, located behind the removable brass grille, to the right of the
gas control valve (refer to figure 14.) The valve is pre-wired and
completely self contained to generate its own power DO NOT
connect any external power to it. Note: The switch location must
not exceed 30' from fireplace.
25 1/2
25 1/2
4). Corner installation of 45 or less: Use a Flexible section
(available in ETKFL 12", or 18") a stucco frame and
termination. Flex may be turned to obtain desired degree of
angle required but must not exceed 45 . (See figure 8).
FIGURE 5. STANDARD INSTALLATION
FIGURE 6. EXTENDED INSTALLATION
FIGURE 8. FLEXIBLE INSTALLATION
FIGURE 7. CORNER INSTALLATION

Page 5 of 11
09/96
FIREPLACE MANTEL AND FACING
Combustible mantels and mouldings may be safely installed
over the top and on the front of the fireplace provided that they
do not project beyond shaded area shown in figure 9. Side wall
clearancesare0". Combustiblesurrounds maybe installedwith
0" clearance to the side of the fireplace as shown in figure 10.
FIREPLACE FACING
MANTELS & SURROUNDS
FIGURE 9. COMBUSTIBLE MANTLES & FACINGS
FIGURE 10. COMBUSTIBLE SURROUNDS
Whenselecting thefinish materialfor yourfireplace,it isimportant
to remember the following: BRASS TRIMS MUST NOT BE
OBSTRUCTEDINANYWAY-todosorestrictstheairsupply
forthecontrolcompartmentsandheatexchangeritalsoprevents
access for servicing controls.
The face of the fireplace may be painted to match the room decor,
providedyouuseaheat-resistant paint. Decorativefacingmustnot
extendpastthefireplaceopeningatall,becauseitwillinterferewith
the access to retainers for removal of glass panel and
combustion door.
NOTE: National Canadian Gas Association mantel test
requirements are for fire hazard prevention to combustible
materials.
New technology, to meet consumer and government demands for
the wise use of energy, has prompted us to manufacture many
models of fireplaces which are hot, fuel and energy efficient.
Please be aware; temperatures over the mantel will rise above
normal room temperature and walls above fireplace may be hot
to touch.
.
We recommend careful consideration be given to the effects of
elavated mantel temperatures which may be in excess of product
design, for example: candles, plastic or pictures. This can cause
melting, deformation, discoloration or premature failure of T.V.
and radio components.
Painting: Special care is recommended by the Master Painters
and Decorators Association, when painting the fireplace
surrounds, to select and apply a quality Alkyd sealer prior to the
applying of latex paints. This is to prevent leaching of water
from evaporation and causing a brownish staining effect to paint
over coats.

Page 6 of 11
09/96
REMOVAL OF OUTER DOOR
Lift panel upwards
and outwards until
panel releases from
mounting pins.
FIGURE 13. SAFETY LOCK
Easily removed for cleaning and servicing. Although this pane is
madeofa verytoughtemperedglass,always handleit carefullyand
place in a safe location where it will not be broken or damaged.
Toremovetheouterglasspanelliftupwardsandoutwards. Thiswill
release the panel from the mounting pins. See Figure 11.
REMOVAL OF INNER DOOR
Toremove inner glassdoor, outer glassdoor must firstberemoved.
Nextturnthesafetydoorlocks outwardsasillustrated inFigure12.
Note: When turning and unlocking the safety door locks a small
additional pressure is required to start the unlocking procedure.
Thisisbecausealatchpinofthesafetydoorlockisseatedintoalatch
plate notch (see Figure 13). This ensures the safety door lock is in
its correct position, maintaining the door seal is under constant
spring pressure.
IMPORTANT: For your safety when replacing in-
ner door to its original position always assure the
safetydoorlatchpinis correctlypositionedwiththe
notch in the latch plate. (see Figure 13).
TurnTurn
FIGURE 12. INNER GLASS DOOR
Knotch
Door
FIGURE 11. OUTER GLASS DOOR
The EC-Plus 36DV-RV is supplied with four(4) very attractive
cultured oak logs. To install simply place log "A's" rectangular
shaped extension into the log mounting slot located on rear wall
of the burner assembly. Place log "B" onto front log slots.
Place log "C" and log "D" onto pins on the burner bar as shown
below.
A
D
C
B
Wire to
wall switch Control Valve
LIGHTINGPILOTANDMAINBURNER
To light pilot it is necessary that you remove outer and inner glass
door(refertosectionsonglassdoorremoval).Thegascontrolvalve
is located behind the brass trim in the centre of the fireplace (see
Figure14 below). Before lighting the pilot,make sure that the gas
line is connected and the gas shut-off valve is turned to the ON
position. To light the pilot we recommend the use of a long match
or removal of log“D”:
a) Partially depress and turn dial on gas control valve to “OFF”
position and wait 5 minutes.
b) Turn dial to pilot position, depress dial and light pilot burner,
hold for1 minute, then release. If pilot does not remain
ignited, repeat, allowing a longer time to elapse before
releasing dial.
c) Re-install inner and outer glass door.
NOTE: For your protection and safety, main gas burner can not
be activated until inner glass door has been re-installed to activate
a safety cut off switch.
d) To light the main burner, turn dial to “ON”, then turn on
remote switch.
e) Turn off flame with remote switch. For complete shut down,
slightly depress gas control valve dial and turn to “OFF”
position.
FIGURE14. ROBERTSHAWGASCONTROLVALVE
FORALTERNATE
GASVALVESEE
FIGURE16ONTHE
NEXTPAGE.
INSTALLING LOG SET

Page 7 of 11
09/96
PILOT BURNER ADJUSTMENT
The following is a troubleshooting chart of possible problems:
PROBLEM CORRECTIVE ACTION
Noisy Pilot Flame Remove pilot adjuster cap, located
next to gas shut off valve. Flame is
decreased by turning adjustment
screwclockwise.
Pilot won’t ignite Disconnect remote wires and try to
light pilot. If pilot now works,
remote connections are faulty.
Check wiring diagram figure 14.
Main burner will 1. Check wiring (see figure 14.)
not light 2. Check wall switch for proper
connection.
3. Check door safety switch located
center of bottom door rail
4. Burner ignites, adjust activating
pin bottom center of inner glass door.
5. Burner does not ignite, check
electrical contacts of the door safety
switch.
TROUBLESHOOTING
MAINTENANCE
Theapplianceshouldbeinspectedbeforeuseandatleastannually
by a professional service person. More frequent cleaning may be
required due to excessive lint from carpeting, bedding material,
etc. Itisimperativethatburnercontrolcompartments,burnersand
circulating air passageways of the appliance be kept clean. For
your convenience a 1/8" pressure tap is supplied on the gas valve
foratestgaugeconnection. SeeFigure14. ForNaturalgasthegas
line requires an inlet pressure of 7" W.C. and a manifold pressure
of3.5"W.C. ForPropanegasthegaslinerequiresaninletpressure
of11"W.C.andamanifoldpressureof10.5"W.C.Alwayskeepthe
fireplace area clear and free of combustible materials, as well as
gasoline and other flammable vapours and liquids.
CLEANING
Whenfireplace isfirst activatedsomesmoking andvisible filmon
the glass may occur, this is a normal condition of heat burning of
protective coatings on new metal.
-Products of combustion do deposit a visable film on the glass
which must be cleaned periodically. Film can easily be
removed by removing inner and outer doors, handling
carefully, and cleaning with normal liquid household products.
WARNING: Do not attemptto clean glasswhen hot.
Do not clean glass with abrasive materials as any glass
etching may cause premature glass failure.
- Silicone seals on inner door during initial firing will "off gas",
leaving a visual deposit of a white substance on combustion
chamber walls. This can easily be removed using normal
household products.
- Use a vacuum cleaner or whisk broom to keep the control
compartment, burner, and firebox free from dust and lint.
- Logs may be cleaned periodically with soap and water to
remove soot.
CAUTIONS
* Fireplace gas control must be in the “OFF” position and
pilotandmain burners extinguished when cleaning
appliance with a vacuum.
* Doorsand logscangetveryhot, handleonlywhenlogs are
cool.
FIGURE15. PILOTBURNERADJUSTMENT
3/8 to 1/2 Inch
PowerGenerator Pilot
Burner
1. Remove Pilot Adjustment Cap. (see figure 14)
2. Adjust pilot key to provide properly sized flame. SeeFigure 15
for properly sized flame.
3. Replace pilot adjustment cap.
4. Leak test with a soap solution after installing or servicing with
main burner on. Coat pipe and tubing joints, gasket etc. with
soap solution. Bubbles indicate leaks. Tighten any areas where
the bubbles appear until the bubbling stops completely.
If your Econo Plus 36DV-RV still does not operate correctly,
consult your dealer or the manufacturer.
All service and repairs should be performed by a qualified
agency.
All spare parts, optional fans (see optional fan instruction guide),
and optional trim finishes are available from Canadian Heating
Products Inc. or your local dealer.
TheEcono Plus 36DV-RV has a ten-year limitedwarranty
onthefirebox,afive-yearwarrantyon themainburner,pilot
burner, and cultured oak logs; and a one-year warranty on
the gas control valve and glass doors.
FIGURE16.WHITEROGERSGASCONTROLVALVE

Page 8 of 11
09/96
Canadian Heating Products Inc. and/or Montigo DelRay Corp. reserves the right to make changes at any time, without notice, in
design, materials, specifications, prices and also to discontinue colors, styles and products.
MONTIGO DEL RAY CORP.
6925 Salashan Parkway, Ferndale, WA 98248
Tel: [phone] Fax: [phone]
CANADIANHEATINGPRODUCTS INC.
13120 76th Avenue, Surrey, B.C. Canada V3W 2V6
Telephone [phone] Fax
[phone]
ECONO-PLUS36DV-RV
GASFIREPLACEWARRANTY
THE WARRANTY
The Companies warrants the Montigo Gas Appliance to be free from defects in materials and workmanship at the time of manufacture. On the
Montigo, there is a ten-year warranty on the firebox and its components, a five-year warranty on the main burner, pilot burner and a one-
year warranty on the gas control valve and glass doors.
REMEDY AND EXCLUSIONS
The coverage of this Warranty is limited to all components of the Gas Appliance manufactured by The Companies.
This Warranty only covers Montigo Gas Appliances installed in the United States or Canada.
If the components of the Gas Appliance covered by this Warranty are found to be defective within the time frame stated (see The Companies
right of investigation outlined below). The Companies will, at its option, replace or repair defective components of the Gas Appliance
manufactured by The Companies at no charge, and will also pay for reasonable labour costs incurred in replacing or repairing components. If
repair or replacement is not commercially practical, The Companies will, at its option, refund the purchase price of the Montigo Gas
Appliance.
This Warranty covers only parts and labour as provided above. In no case shall The Companies be responsible for materials, components,
or construction which are not manufactured or supplied by The Companies, or for the labour necessary to install, repair or remove such
materials, components or construction. All replacement or repair components will be shipped F.O.B. the nearest The Companies
factory.
QUALIFICATIONS TO THE WARRANTY
The Gas Appliance Warranty outlined above is further subject to the following qualifications:
(1) The Gas Appliance must be installed in accordance with The Companies installation instructions and local building codes. The Warranty
on this Montigo Gas Appliance covers only the component parts manufactured by The Companies. The use of components manufactured by
others with this Montigo Gas Appliance could create serious safety hazards, may result in the denial of certification by recognized national
safety agencies, and could be in violation of local building codes. This warranty does not cover any damages occurring from the use of
any components not manufactured or supplied by The Companies
(2)The Montigo Gas Appliance must be subjected to normal use. The Gas Appliances are designed to burn gas only.
Burning conventional fireplace fuels such as wood, coal or any other solid fuel will cause damage to the Gas Appliance, will produce
excessive temperatures and will result in a fire hazard.
LIMITATIONS ON LIABILITY
It is expressly agreed and understood that The Companies sole obligation, and purchaser's exclusive remedy under this
Warranty, under any other warranty, expressed or implied, or in contract, tort or otherwise, shall be limited to replacement,
repair, or refund, as specified above.
In no event shall The Companies be responsible for any incidental or consequential damages caused by defects in its prod ucts,
whether such damage occurs or is discovered before or after replacement or repair, and whether or not such damage is
caused by The Companies negligence. Some states do not allow the exclusion or limitation of incidental or conse-
quential damages, so the above limitation or exclusion may not apply to you. The duration of any
implied warranty with respect to this Montigo Gas Appliance is limited to the duration of the foregoing war-
ranty. Some states do not allow limitation on how long an implied warranty lasts, so the above may not apply to you.
INVESTIGATION OF CLAIMS AGAINST WARRANTY
The Companies reserves the right to investigate any and all claims against this Warranty and to decide upon method of settlement.
THE COMPANIES ARE NOT RESPONSIBLE FOR WORK DONE WITHOUT WRITTEN CONSENT
The Companies shall in no event be responsible for any warranty work done without first obtaining The Companies written consent.
DEALERS HAVE NO AUTHORITY TO ALTER THIS WARRANTY
The Companies employees and dealers have no authority to make any warranties nor to authorize any remedies in addition to or
inconsistent with those stated above.
HOW TO REGISTER A CLAIM AGAINST WARRANTY
In order for any claim under this Warranty to be valid, The Companies must be notified of the claimed defect in writing or by telephone, as
soon as reasonably possible after the defect is discovered. Claims against this Warranty in writing should include the date of installation, and a
descrip tion of the defect.
OTHER RIGHTS
This Warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
NOTE: The Companies as stated above refer to - Canadian Heating Products Inc. and/or Montigo Del Ray Corp.
