Harmony Barrel Sauna
Assembly Instructions
Requirements:
2 People (recommended)
¾” (19mm) Wrench/Nut Driver Bit
Rubber Mallet
Carpenter’s Hammer
Carpenter’s Level
Carpenter’s Square
Cordless Drill (we supply the bit)
•Phillips & Robertson Screwdrivers
2” (51mm) hole saw
Step Ladder
View the assembly process
tel: [phone] | [e-mail]| web: www.leisurecraft.com
Manufactured by:

Harmony Barrel Sauna
Assembly Instructions
Optional Heater
Electric Heater
Wood Heater
Parts List
Optional Roof Kit
602010 Trim Kit for Barrel Saunas (9pcs for 1 Side)
602011 Trim Kit for Barrel Saunas (18pcs for 2 Sides)
ARBK240 Black Asphalt Shingle Roof - 8’ (244cm)
tel: [phone] | [e-mail]| web: www.leisurecraft.com 2
Part # Description
Quantity
601001 79" Standard Sauna Staves 46
601002 79" Top Stave (Concave on both sides) 1
601003 79" Bottom Stave (Convex on both sides) 1
602001 48" Barrel Cradles 2
603001 Half Moon Wall Sections with Bench Mount Brackets 4
603002 Front Middle Wall Section 1
603003 Back Middle Wall Section 1
604105 71" Pre Assembled Bench (1"x6") 2
604106 29-1/2" x 71" Flat Floor 1
604100 Bench Support Brackets (Corner) 4
BANDS80 2 Meter Barrel Sauna Bands 3
BOLT15 15" Barrel Sauna Bolt with 2 Nuts 3
603020 Outside Sauna Door Handle (Small) - White Cedar 1
603021 Inside Sauna Door Handle (Large) - White Cedar 1
603022 Single Towel Hook - White Cedar 1
VENT1 Sauna Vent (Includes 2 Grills and Inside Slider 1
BAHARDWARE Barrel Sauna Hardware Package 1
CT22MANUAL CT Harmony Owners Manual 1
603004 2 Meter Sauna Door with Frame & Hinges 1
Manufactured by:

Index
Parts List
Base Preparation
Barrel Assembly
Adding a spacer to the Top Stave
Making a Top Stave Narrower
Bench Installation
Electric Heater Installation (Option)
Harvia M3 Wood Heater Installation (Chimney out the top) (Option)
Harvia M3 Wood Heater Installation (Chimney out the back wall) (Option)
Asphalt Shingle Roof Installation
Care &Maintenance
Warranty
tel: [phone] | [e-mail]| web: www.leisurecraft.com
Manufactured by:
3
Harmony Barrel Sauna
Assembly Instructions

Sauna Base Preparation
Make sure the base for your sauna is level with a slight slope to the back for drainage.
A solid base for your sauna is recommended and can be made from any of the following.
Concrete Pad Wood Deck
Crushed Stone Patio Stone/Paver Blocks
It is recommended to build a base larger than required to provide a sitting area for cooling
off during your sauna session.
tel: [phone] | [e-mail]| web: www.leisurecraft.com
Manufactured by:
4
Harmony Barrel Sauna
Assembly Instructions

Barrel Assembly
Place the 2 cradles onto the sauna base.
Locate bottom stave (convex on either side).
The long part before the groove will face the front.
tel: [phone] | [e-mail]| web: www.leisurecraft.com
Manufactured by:
Center the stave onto the cradle and measure 12”
(30cm) from the end of the stave to the edge of the
cradle.
Secure the stave with a 2 ½” (76mm) screw.
Ensure that the stave is square and add 3 more 3”
(64mm) screws into each corner of the cradle.
*Always ensure that you have the correct screw length so that
there will be enough thread to hold, and especially, so that the
screw does not go all the way through the material and come
out the other side.
5
Harmony Barrel Sauna
Assembly Instructions

Barrel Assembly
Repeat this process for the front of the Sauna.
tel: [phone] | [e-mail]| web: www.leisurecraft.com
Manufactured by:
Place 2- 2 ½” (64mm) screws into the 3rd stave on
either side lining up with the cradle underneath.
Do not go all the way through the stave at this point.
(This will help align where cradles are in future steps)
Repeat at opposite end.
6
Barrel Assembly
Place 3 staves on either side of the bottom stave and
align the grooves.
Grab the door and place it in the grooves on the front
wall.
Ensure the logo is to the bottom and facing inwards.
Harmony Barrel Sauna
Assembly Instructions

Barrel Assembly
tel: [phone] | [e-mail]| web: www.leisurecraft.com
Manufactured by:
7
Barrel Assembly
Using a level and rubber mallet, tap the door until it is
centered and level.
Repeat the process for the back wall panel.
Ensure the tongue and grooves are opposite each
other from the front and back panels.
Use the top stave (concave on either side) to go from
the front wall to the back wall to help stabilize the
sauna.
Harmony Barrel Sauna
Assembly Instructions

Barrel Assembly
tel: [phone] | [e-mail]| web: www.leisurecraft.com
Manufactured by:
8
Barrel Assembly
Install one of the rear wall half moon panels.
Ensure the bench support is facing inwards.
Harmony Barrel Sauna
Assembly Instructions
Please note:
Panels may be not be exact size to middle wall.
Center the half moon panels vertically on the middle
wall and secure in place.
Secure the half wall panel to the middle Panel using
2 ½” (64mm) screws in the pre drilled holes at the top
and bottom.
Repeat the process with the other rear wall half
moon panel.

Barrel Assembly
tel: [phone] | [e-mail]| web: www.leisurecraft.com
Manufactured by:
9
Barrel Assembly
Harmony Barrel Sauna
Assembly Instructions
Repeat the process for the front half moon panels.
Ensure the bench supports are facing inwards.
Continue adding staves on either side of the sauna a
few at a time, alternating sides.
Use the rubber mallet to finesse into place.
Secure every 2nd stave on the bottom of the sauna
with the provided nails to hold staves in place.
( If required)
Once past the middle point of sauna, nails should no
longer be needed.
When installing the staves, tap tightly together
while leaving as much of a gap as possible
between stave and wall using the pencil line as a
guide as in picture.
* This will make the tightening of the bands easier.

Barrel Assembly
tel: [phone] | [e-mail]| web: www.leisurecraft.com
Manufactured by:
10
Barrel Assembly
Harmony Barrel Sauna
Assembly Instructions
At this point, Remove the top stave and put it aside
while continuing to add staves on both sides to the
top.
Use the top stave to wedge with the last stave to
create a “V” shape.
• If it doesn’t create a “V” shape or there is a gap, you will
need to add one of the spacer boards to the top stave.
• In rare instances, your sauna staves will be too tight not
allowing the staves to settle into the correct position and
you will need to make the top stave narrower.

Adding a Spacer to Top Stave (if required)
In your sauna package you will find a spacer stave
that is square on both sides that is only required If
there happens to be a “gap” after installing all the
staves like in the picture on the left.
To add the spacer, start by removing all of the screws
from the top stave.
tel: [phone] | [e-mail]| web: www.leisurecraft.com
Manufactured by:
With the top stave in 2 pieces secure the spacer stave
to the half of the top stave without the screws with 2”
(51mm) screws.
Now screw the other side of the top stave back to the
other half top stave and it should now make a “V”
shape when wedged with the last stave on the sauna.
11
Harmony Barrel Sauna
Assembly Instructions

Making the Top Stave Narrower (if required)
In rare instances, your sauna staves will be too tight
not allowing the staves to settle into the correct
position. (as in picture to the left)
This doesn’t happen often, and the sauna staves and
bands are always better being as tight as possible.
To make the top stave narrower, start by removing all
of the screws from the top stave.
tel: [phone] | [e-mail]| web: www.leisurecraft.com
Manufactured by:
Once top stave is apart, Measure from flat edge 3/4 “
(2cm) on each piece and safely cut to make staves
thinner.
Now screw the 2 cut pieces of the top stave back
together.
Reinstall the top stave and it should now make a “V”
shape when wedged with the last stave on the sauna.
12
Harmony Barrel Sauna
Assembly Instructions

Barrel Assembly
tel: [phone] | [e-mail]| web: www.leisurecraft.com
Manufactured by:
13
Barrel Assembly
Pre-assemble the 2 bands and thread the nut on just
enough to hold it together.
Place one band over the front of the sauna.
Repeat the process and place the second band over
the back of the sauna.
Ensure the front band is 2” (51mm) from the edge of
the sauna all the way around.
Repeat for the back band.
Feed the center band over and under the sauna and
secure it with a rod and nut.
Ensure all fasteners are the same height.
Harmony Barrel Sauna
Assembly Instructions

Barrel Assembly
tel: [phone] | [e-mail]| web: www.leisurecraft.com
Manufactured by:
14
Barrel Assembly
Lightly snug up the front and back fasteners.
Tap out all the staves to even them out.
Tighten fasteners on the front and back bands while a
helper continues to tap on the staves.
Ensure the middle band is centered and tighten,
Give all fasteners a final tightening.
* Don’t worry about making them too tight, you cannot
overtighten!
Harmony Barrel Sauna
Assembly Instructions

Bench Installation
Place the flat floor piece inside the sauna towards the
back wall.
Center it in the middle of the sauna.
Ensure the floor pieces is level.
tel: [phone] | [e-mail]| web: www.leisurecraft.com
Manufactured by:
Once level, Secure the floor with 1 ½” (38mm) screws
in the 4 corners and 2 in the middle of the flat floor
screwing between the floor boards so the screws are
not as visible.
15
Bring in the benches and place on bench brackets.
Ensure they are tight against the walls.
Harmony Barrel Sauna
Assembly Instructions

Place 2 – 1 ½” (38mm) screws into the pre-drilled
holes on each bench bracket.
Bench Installation
tel: [phone] | [e-mail]| web: www.leisurecraft.com
Manufactured by:
16
Secure the benches to the bench brackets with 1 ½”
(38mm) screws in each of the corners of the bench
screwing between the bench slats so the screws are
not as visible.
Line the bracket up with the support on the bottom of
the bench and secure it with the pre-placed screws.
Square up the bench support and use a 1 ½” (38mm)
screw in the pre-drilled hole to secure it to the sauna
floor.
Repeat this process for the remaining bench
supports.
Harmony Barrel Sauna
Assembly Instructions

Door Handles & Accessories Installation
Install the outer door handle (small) at the desired
height using 2 – 3” (76mm) screws in the pre-drilled
holes.
Install the inner door handle (large) horizontally at the
desired height. Ensure the handle is level and secure
using 2 – 3” (76mm) screws in the pre-drilled holes.
tel: [phone] | [e-mail]| web: www.leisurecraft.com
Manufactured by:
Place the towel hook at desired location and secure
with 4- 1 ½” (38mm) screws.
Install the optional sand timer using 2 – 1 ½” (38mm)
screws.
Ensure it can rotate without hitting the wall.
17
Harmony Barrel Sauna
Assembly Instructions

Electric Heater Installation (Optional)
Measure the width of the stove mounting holes.
Measure the height of the mounting holes and add 6”.
(152mm)
tel: [phone] | [e-mail]| web: www.leisurecraft.com
Manufactured by:
Transfer the measurements to the back wall of sauna.
Ensure the heater will be centered between the
benches.
Install the two ¼" x 1 ½" (6mm x 38mm) hex head lag
screws (supplied with the heater) into the holes.
18
Harmony Barrel Sauna
Assembly Instructions

Electric Heater Installation (Optional)
Hang the heater on the 2 screws and tighten to
secure stove in position.
Locate the pieces for your heater guard.
Stand the 2 Assembled side pieces of the heater
guard on edge with pre-drilled holes on the bottom.
tel: [phone] | [e-mail]| web: www.leisurecraft.com
Manufactured by:
Screw heater guard support to either side using
(2) – 1 ½” (38mm) screws per side.
Repeat for the bottom heater guard support.
Place 2- 2 ½” (64mm) screws into the pre-drilled holes
on either side of heater guard to prepare for
mounting.
19
Harmony Barrel Sauna
Assembly Instructions

Electric Heater Installation (Optional)
Center the guard around the heater and secure to
wall with the pre placed screws.
Ensure the guard is level and secure the other side.
tel: [phone] | [e-mail]| web: www.leisurecraft.com
Manufactured by:
Wash the layer of rock dust off of the sauna rocks
before using them.
When your sauna is set up and working you should
“break-in” the sauna before using it for the first time
by turning on the heater to its highest setting and
operate it for about 1 hour.
This is recommended to burn off any oils impurities
from manufacturing, and it also “cures” the
woodwork.
• All wiring should be installed according to the heater manufacturers instructions and by a
licensed electrician.
•Do NOT use a G.F.I breaker
20
Harmony Barrel Sauna
Assembly Instructions
