Canarm XSA Series Parts list manual

XSA SERIES
SPUN ALUMINUM EXHAUSTER
OPERATION INSTRUCTIONS AND PARTS MANUAL
READ AND SAVE THESE INSTRUCTIONS
GENERAL SAFETY
1. All electrical work must be done in accordance with all applicable electrical codes by a
qualified electrician.
2. Prior to wiring ensure the power supply is locked in the OFF position and that the motor
nameplate voltage matches the supply voltage.
3. Do not install or operate this fan in an environment where combustible materials, gases or
fumes are present.
4. Caution: the fan contains rotating parts and electrical service. Appropriate safety
precautions should be taken during installation, operation and maintenance.
When servicing the fan motor may be hot, allow time for cooling down.
5. Before starting the unit, ensure the wheel rotates freely.
6. Check and tighten where necessary all nuts, bolts & set screws prior to fan start up (as
some may have loosened during shipment).
7. Please follow all applicable national, state/provincial and local codes, all of them will
supersede this manual.
8. Failure to follow the safety instructions in this manual may cause serious injury or
death due to electrical shock or high speed rotating parts.
The purpose of this manual is to aid in the proper installation and operation of the blowers. These instructions are intended to supplement good
general practices and are not intended to cover detailed instruction procedures.
IT IS THE RESPONSIBILITY OF THE PURCHASER TO ASSURE THAT THE INSTALLATION AND MAINTENANCE OF THIS EQUIPMENT IS
HANDLED BY QUALIFIED PERSONNEL.
Inspect all shipments carefully for damage. THE RECEIVER MUST NOTE ANY DAMAGE ON THE CARRIER’S BILL OF LADING AND FILE A
CLAIM IMMEDIATELY WITH THE FREIGHT COMPANY.
DO NOT LIFT THE UNIT BY THE HOOD OR MOTOR. PLEASE LIFT THE UNIT BY HORIZONTAL SUPPORTS.
DIMENSION & COMPONENT
XSA-M-10_04_16
Page 1 of 6
A
B
D
E
C
G
F
A
B
D
E
C
G
F
UPBLAST
MODELS
DOWNBLAST
MODELS
NOTE: DUE TO MOTOR MANUFACTURERS VARIANCES IN DESIGN,
PLEASE SEE PAGE 5 FOR MOTOR DIMENSIONAL GUIDELINES.
DOWNBLASTUPBLAST
Downblast Direct
Drive Shown
Note: Belt drive units are weighted without motor & drives.
Upblast Belt
Drive Shown
Motor plate detail varies
on different sizes
Model A B C D E F G Ø Wheel
Diameter
Roof
Opening
Net
Weight
(lbs)
XSA105-DD 18.00 25.00 19.00 2.50 1.50 3.50 0.38 10.50 15.00 33
XSA120-DD 19.00 25.00 19.00 3.50 1.50 3.50 0.38 12.25 15.00 35
XSA135-DD/DB 22.25 / 25.25 31.25 21.00 3.13 2.00 3.75 0.44 13.50 17.00 51 / 59
XSA150-DD/DB 23.13 / 26.13 31.25 21.00 3.75 2.00 3.75 0.44 15.00 17.00 56 / 65
XSA165-DD/DB 27.13 / 31.13 36.25 24.75 5.00 2.00 4.00 0.44 16.50 20.75 100 / 106
XSA180-DD/DB 27.75 / 31.75 36.25 24.75 5.50 2.00 4.00 0.44 18.25 20.75 104 / 110
XSA210-DB 36.25 43.75 33.13 5.25 2.50 4.00 0.44 21.25 29.00 176
XSA245-DB 37.00 43.75 33.13 5.88 2.50 4.00 0.44 24.50 29.00 181
Dimensions (inches)
Model XSA A B C D E F G Ø Wheel
Diameter
Roof
Opening
Net
Weight
(lbs)
XSA105-UD 17.63 25.00 19.00 13.00 1.50 3.50 0.38 10.50 15.00 35
XSA120-UD 18.63 25.00 19.00 13.00 1.50 3.50 0.38 12.25 15.00 37
XSA135-UD/UB 22.25 / 25.25 32.13 21.00 17.13 1.50 3.75 0.44 13.50 17.00 53 / 62
XSA150-UD/UB 23.13 / 26.13 32.13 21.00 17.13 1.50 3.75 0.44 15.00 17.00 58 / 67
XSA165-UD/UB 27.13 / 31.13 37.50 24.75 21.13 2.00 4.00 0.44 16.50 20.75 100 /108
XSA180-UD/UB 27.75 / 31.75 37.50 24.75 21.13 2.00 4.00 0.44 18.25 20.75 108 / 116
XSA10-UB 36.25 43.75 33.13 25.50 2.50 4.00 0.44 21.25 29.00 178
XSA245-UB 37.00 43.75 33.13 25.50 2.50 4.00 0.44 24.50 29.00 183
Dimensions (inches)
!

XSA SERIES
SPUN ALUMINUM EXHAUSTERS
XSA-M-10_04_16
Page 2 of 6
1. A qualified electrician in accordance with all local and National Electrical Codes should do all wiring.
2. Ensure power supply is disconnected and locked out prior to making electrical connections.
3. Wire the motor according to the wiring diagram on motor label or on the sticker inside the motor wrap. All motors should be wired to
the same rotation as indicated on the sticker on the top plate.
4. Leave enough slack in the wiring to allow for motor movement when adjusting the belt tension.
5. Excess wire must be restrained in order to prevent it from entering the pulley, shaft or wheel rotating area.
6. Disconnect switches are recommended and should be located near the fan in order to, swiftly cut off power in case of an emergency
and maintain complete control of the power source.
Some single phase direct drive motor’s running RPM can be adjustable with a variable speed control (please contact factory for more
information). The speed control knob starts at off position, then high to low adjust range. At high speed, the speed control would allow the
motor running at its maximum RPM. Dial the knob to the low side would let the speed control regulate the voltage on the motor to reduce
the RPM.
A minimum speed adjustment is needed to limit the motor RPM range. Follow this procedure to set the minimum speed.
1. Motor must be in servicing status to allow the minimum speed setting. Motor would not slow down unless proper load is applied.
Motor RPM would be changed under different system (static pressure).
2. Turn the main control knob to the lowest speed position.
3. Locate and adjust the minimum speed setting, it can be found on the control box itself.
4. Motor RPM range would be from full RPM to the RPM just set.
The lowest minimum voltage that may be applied to the motors is 65VAC. Running at lower voltage can cause premature failure
to the motor.
For 3 phase motors, a variable frequency drive (VFD) is required to adjust motor speed.
VARIABLE SPEED CONTROL – SINGLE PHASE
VARIABLE FREQUENCY DRIVE – THREE PHASE
INSTALLATION
RECOMMENDED
ROOF OPENING
WIREDTOPOWER
BY OTHERS
ROOF
DECK
OPTIONAL DISCONNECT CAN
BE MOUNTEDINSIDE THE
HOUSINGOR OUTSIDE
MINIMUM 12”
RECOMMENDED
ROOF OPENING
ROOF
DECK
MINIMUM 12”
WIRE OPTION 2:
WIRE THROUGH
THE VENT TUBE
WIRE OPTION 1:
THROUGH CONDUIT
GENERAL CLEAN AIR APPLICATION (UP BLAST)
GENERAL CLEAN AIR APPLICATION, DOWN BLAST
Note: XSA105 and XSA120 has only wiring option 1, XSA210 and larger has
only wiring option 2 available.
STANDARD WIRING INSTRUCTIONS
1. Install roof curb, caulk and flash to ensure the water tightness.
2. Rotate the blower wheel by hand. Wheel should not be rubbing against the housing inlet. If rubbing occurs, loosen the set screws on
the wheel hub and shift the wheel to obtain clearance. Then re-tighten all set screws.
3. Complete all subsequent duct connections.
4. Secure the fan to the curb cap. Do not lift the unit by the hood or motor. Lift the unit by horizontal supports on direct drive or by motor
mounting plate for belt drive unit.
5. Use at least 8 proper fasteners to connect the blower base to the roof curb.
6. Verify if the power supply is compatible with the equipment.
7. Make sure the power line is shut down before wiring the motor to power line.
8. Remove top cap, connect power line to the motor/disconnect switch as indicated.
9. For all up blast units, the electrical supply enters the motor compartment through the vent tube.
10. Ensure all fasteners and set screws are tightened.
11. Place the top cap back on the hood.
12. Caulk and flash the fan base including the fan base corners and roof curb to ensure good water tightness.

MESSAGE DISPLAYED...
Spd- followed by the instantaneous speed in rpm
dE- followed by S + demand in %
E1- No communications
E2- Under Voltage
All up-blast models are UL/cUL listed, they are capable to meet UL762 for Commercial Kitchen application:
• The National Fire Protection Association (NFPA) publication NFPA 96 is the primary source for this application. Also consult local
authorities for all other applicable codes and guidelines before installation.
• Exhaust fans used in kitchen ventilation applications must have external wiring. (Wiring must not be installed in the airstream).
• Installation must include a means for inspecting, cleaning and servicing the exhaust fan. (Curb hinge, grease collector and outdoor
disconnect switches are available for purchase as accessories)
• No dampers can be used in the system.
UL762 RESTAURANT EXHAUST APPLICATION
Power is connected to the motor and control module through
the junction box and wiring harness provided.
Note: For 115VAC operation the blue jumper provided (taped
to wire harness) must be inserted into motor power
connector. See diagram.
Caution: Operating the motor at 208-230VAC with the jumper will cause significant damage to the motor.
AC Supply - 115/208-230VAC
EC motors are equipped with a control module that allows for accurate
manual adjustment of motor speed. Motor speed range is from 300 to
1800rpm or maximum rpm for that model.
The control module features a 4 digit LED display that indicates %
demand of full speed and motor speed in rpm. The display also indicates
an error code message for minor diagnostics if required.
Motor speed can be changed by adjusting the speed control pot located
on the control module. A small screwdriver can be used to make the
speed adjustment.
XSA SERIES
SPUN ALUMINUM EXHAUSTERS
XSA-M-10_04_16
Page 3 of 6
EC (Electronically Controlled) MOTOR SPEED CONTROL
Note: EC motors have a soft start feature. When the power is turned on the control module gathers information from the motor then begins
the start up process. After a few seconds the motor will start to turn and reach full set speed in 10-15 seconds.
Remote Speed Control Option (please contact factory for further information)

XSA SERIES
SPUN ALUMINUM EXHAUSTERS
XSA-M-10_04_16
Page 4 of 6
RECOMMENDED
ROOF OPENING
WELDEDDUCT
BY OTHERSGREASE
COLLECTOR
(OPTIONAL)
MINIMUM 20”
FROM ROOF TOP
VENTEDCURB
DISCONNECT MOUNTED
OUTSIDE OF THE HOUSING,
WIREDTHROUGH THE VENT
TUBE BY OTHERS
WIREDTOPOWER
BY OTHERS
ROOF
DECK
WALL
WALL MOUNT BRACKET
(OPTIONAL)
RECOMMENDED
ROOF OPENING
WELDEDDUCT
BY OTHERS
DISCONNECT MOUNTED
OUTSIDE OF THE HOUSING,
WIREDTHROUGH THE VENT TUBE
1. Lock out all power sources.
2. Inspect all fasteners and set screws and tighten as required.
3. Inspect belt alignment and tension where applicable.
4. Confirm power source voltage and motor voltage are the same and that the motor is wired correctly.
5. Rotate the wheel to ensure that neither the fan blade nor the belts come into contact with the housing.
6. Inspect the fan and the ductwork to ensure they are free of debris.
7. Check to ensure that all guards and accessories are securely mounted.
PRE-START INSPECTION
Turn the fan on and inspect for the following:
1. Direction of rotation.
2. Improper motor amperage.
3. Excessive vibration.
4. Unusual noise.
5. Improper belt tension or alignment (only applicable on belt-drive unit).
If a problem is discovered shut off the fan and refer to the section on troubleshooting to discover the cause of the problem. The fan should
be inspected after 30 minutes, 8 hours & 24 hours of operation to ensure all fasteners are tight and belts are properly tensioned and aligned.
START UP
Disconnect and secure to the OFF position all electrical power to the fan prior to inspection or servicing. Failure to comply with this safety
precaution could result in serious injury or death.
1. Ventilator should be checked at least once a year. For critical or severe applications a routine check every two to three months is
suggested.
2. When moving or installing a belt, don’t force the belt over the sheave. Loosen the motor mount so that the belt can be easily slipped
over the sheave.
3. The belt, on belt driven units, should be removed and carefully checked for cracks, ply separation or irregular wear. A small
irregularity in the contact surface of the belt will result in noisy operation. If any of these defects are apparent the belt should
be replaced. At the same time check the sheaves for chips, dents or rough surfaces that could damage the belt.
4. The correct belt tension is important. Too tight a belt will result in excess bearing pressure, which can cause premature bearing failure
and may cause the motor to overload. Too loose a belt will result in slippage, which will burn out belts. Proper belt deflection should
be 1/64” (half way between sheave centers) for each inch of belt span when a force of approximately 5 lbs. is applied.
5. The belt alignment should be checked to be sure that the belt is running perpendicular to the rotating shafts. Motor and drive shafts
must be parallel.
6. A periodic inspection of all fasteners should be carried out to ensure they have not loosened due to vibration. Particular attention
should be paid to fasteners attaching the wheel to the shaft and those attaching the shaft to the bearing.
MAINTENANCE
UP-BLAST UL762 RESTAURANT EXHAUST INSTALLATION UP-BLAST WALL MOUNTED UL762 RESTAURANT EXHAUST INSTALLATION

XSA SERIES
SPUN ALUMINUM EXHAUSTERS
XSA-M-10_04_16
Page 5 of 6
FAN TROUBLESHOOTING
FAN MOTOR DIMENSIONAL
GUIDELINES XSA
PROBLEM POSSIBLE ISSUE SOLUTION
Wheel rubbing inlet Adjust wheel, loosen set screw(s) and move the wheel, acquiring
clearance between inlet and wheel, then re-tighten set screw(s)
Wheel unbalance Check wheels for debris or dirt build up and clean when necessary
Object in rotation area or housing Remove object
Motor compartment loose Re-tighten the fasteners
Malfunction of electrical supply Check supply voltage, fuse and switch
Malfunction of motor Check wiring and overload protector
Motor overload/overheat Wrong wheel rotation Re-wire the motor to change direction of rotation
Damper Malfunction Check opening side of back draft damper, check operation status of
controlled damper
Wrong wheel rotation Re-wire the motor to change direction of rotation
Improper Duct System Check obstruction of duct in the duct or dirty filter
Fan does not operate
Reduced airflow
Excessive noise/vibration
WARNING
MAKE SURE THE UNIT IS NOT CAPABLE OF OPERATION
DURING REPARATION.
A
D
C
B
FAN XSA FRAME SIZES MAX "A" MAX
"B"
MAX
"C"
MAX
"D"
RESILIENT
BASE
MAX SHEAVE
DIA.
XSA135UB/DB 48, 56 8.5 6.5 10.5 7 NO 5.5
XSA150UB/DB 48, 56 8.5 6.5 10.5 7 NO 5.5
XSA65UB/DB 48, 56, 143, 145 8.5 8 13 7 NO 5.5
XSA180UB/DB 48, 56, 143, 145 8.5 8 13 7 NO 5.5
XSA210UB/DB 56, 143, 145, 182, 184 11.5 11 12 8 YES 8
XSA245UB/DB 56, 143, 145, 182, 184 11.5 11 12 8 YES 8
FAN MAX
"A"
MAX
"B"
MAX
"C"
C-FACE
ONLY
XSA105/120UD 14 14 8.5 56 FRAME
XSA105/120DD 10 10 7.5 56 FRAME
XSA135/150UD 15 15 15 56 FRAME
XSA135/150DD 15 15 15 56 FRAME
XSA165UD 16 16 15.5 56 FRAME
XSA165DD 16 16 15.5 56 FRAME
1 HP ADAPTER PLATE
48 OR 56 FRAME
BOTH SIDES 48, 56, 143-145 FRAME 48, 56, 143-145, 182-184 FRAME
MOTOR MOUNTING
XSA135/XSA150 XSA165/XSA180 XSA210/XSA245

XSA SERIES
SPUN ALUMINUM EXHAUSTERS
1
1
1
2
3
4
4
6
5
7
8
9
1
2
1
4
2
4
1
0
1
1
3
XSA SERIES SPUN ALUMINUM
UPBLAST EXHAUSTERS - EXPLODED
VIEW
ITEM # DESCRIPTION QTY
1TOP CAP 1
2MOTOR WRAP 1
3MOTOR SUPPORT PLATE 1
4VIBRATI ON ELIMINATOR 4
5TOP PLATE 1
6UPBLAST APRON1
7VENT 1
8VERTICAL BRACKET 4
9INLET BAFFLE 4
10DRAIN 4
11 MOTOR SUPPORT RAIL 2
12HORIZONTAL BRACKET 4
13BASE1
14 BLOWERWHEEL 1
5
6
1
7
3
2
3
2
8
9
4
4
1
4
11
12
10
13
XSA SERIES SPUN ALUMINUM
DOWNBLAST EXHAUSTERS - EXPLODED
VIEW
ITEM # DESCRIPTION QTY
1MOTOR WRAP 1
2BEARING 2
3MOTOR SUPPORT PLATE 1
4VERTICAL BRACKET 4
5TOP CAP 1
6VENT TUBE 1
7DOWNBLAST APRON1
8MOTOR SUPPORT RAIL 2
9VIBRATI ON ELIMINATOR 4
10SHAFT 1
11 TOP PLATE 1
12INLET BAFFLE 1
13BASE1
14 BLOWERWHEEL 1
NOTE: General
models are
shown above.
Actual unit might
vary according
to size.
