CANARY AUDIO CA-903 User manual

CANARY AUDIO®
Dual Mono Vacuum Tube Preamplifier
Handcrafted in California
CA-903
OWNER’S MANUAL
MADE IN USA

!This symbol is intended to alert the user to the presence
of important operating and maintenance (servicing)
instructions in the literature accompanying the unit.
The lightning flash with arrowhead symbol is intended to
alert the user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock
to persons.
Dear Customer:
Please allow us to take this opportunity to thank you for purchasing this
CANARY AUDIO product.
We strongly recommend that you carefully study the Safety Instructions before
attempting to operate the unit.
After you have finished reading the instructions, please save this manual for
future reference.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THE UNIT TO RAIN OR MOISTURE.
CAUTION:
TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS POLARIZED AC PLUG
WITH AN EXTERSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS
THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SER-
VICING TO QUALIFIED SERVICE PERSONNEL ONLY.

SAFETY INSTRUCTIONS
Power Source:
•The unit should be connected to an AC power source of the proper rated
voltage.
•Never replace the power supply’s line fuse with the one of incorrect
characteristics.
AC Cord Protection:
•Do not defeat the grounding or polarization feature of the AC cord.
•Make sure that the AC receptacle holds the AC cord plug firmly and securely.
•Keep the AC cord away from heating appliances.
•Never put heavy object on the AC cord.
•If smoke, malodors or noises are emitted from the unit, turn the power off and
disconnect the AC cord.
Keep Away from Water and Moisture:
•This unit should not be used near water.
•Keep the unit away from flower vases, bathtubs, washbowls, kitchen sinks,
laundry tubs, swimming pools, etc. If liquids are spilled into the unit, serious
damage could occur.
Ventilation:
•Slots and openings in the chassis and in the back or bottom are provided for
necessary ventilation.
•Do not place a cloth on top of the unit or block the provided ventilation slots
and openings in any other way.
•Do not place the unit on a bed, sofa, rug or other similar surface which may
block the slots and openings.
•Do not place the unit in a confined space, such as a bookcase or built-in
cabinet, unless proper ventilation is provided.
Non-Use Periods:
•When left unused for a long period of time, the unit should be unplugged from
the AC outlet.

PROPER CARE
Break-in Period:
•As with most audio components, the CA-903 requires a “break-in” period.
During this period the internal components will stabilize and reach their
normal operating parameters. There are no special procedures required for
this break-in period, just listening to your favorite music will accomplish this
task all by itself.
•The time required to break in the CA-903 is approximately 30 to 50 hours.
Upon completion of the break-in period you will hear an improvement in the
overall sound quality of the preamplifier.
No Fingers or Other Foreign Objects:
•Touching internal parts of this unit is dangerous and may cause serious
damage to the unit. Do not attempt to disassemble the unit.
•Do not put any foreign object into the unit through the ventilation slots and
openings.
Cleaning:
•A regular dusting with a soft, non-abrasive cloth will generally keep the finish
of the faceplate and chassis looking like new.
Packing Materials:
•The original packing materials and shipping boxes are custom designed to
prevent shipping damage from occurring.
•We recommend that you retain all of the packing materials and shipping
boxes for your CA-903 to be covered by warranty.
Registration Card:
•To ensure that your CA-903 is registered, please spend a moment now to
complete and return the Registration Card.
•Save a copy of the Registration Card and the bill of sale as proof of purchase
for future reference.

UNPACKING
•Open the shipping boxes.
•Remove the accessories that come with the unit.
•Grasp the underside of the preamplifier and lift it straight out of the box.
•Place the preamplifier in a safe location. Remove the packing foam and the
protective plastic wrapping.
•After unpacking the CA-903-L and CA-903-P, inspect them for any shipping
damage and contact us immediately if any is found. Do not plug the power
supply into any outlet if you find any shipping damage.
•Please keep all packing materials for future transport of your player. Shipping
the CA-903-L or CA-903-P in anything other than its original boxes may result
in damage that is not covered by warranty.
ACCESSORIES
The following items are included in the package aside from the main units:
•Owner’s manual
•Warranty card
•AC power cords
•DC power cables
PLACEMENT
•Do not place the unit near a heating device or in a location where it is
exposed to direct sunlight.
•Do not place the unit in an excessively humid or dusty location.
•Avoid placing the unit in the areas of vibration, impact or where the surface is
tilted as the internal parts may be seriously damaged.
•Avoid placing the unit next to kitchen counters or other locations where it is
subjected to oily fumes.
•Place the unit in a horizontal position, and do not place anything heavy on it.
•Do not place the unit on any other equipment which may become hot.

CONNECTION STEPS:
1. Place the CA-903-L and CA-903-P in a rack or on a shelf. The CA-903-L
and CA-903-P do not require a special rack or cabinet for installation.
2. Neatly arrange and organize wiring to and from the preamplifier and all
components. Separate the AC wires from any audio cables to prevent
hum or other unwanted noise from being introduced into the system.
3. Turn off any associated components prior to connecting the CA-903-L and
CA-903-P. This minimizes the chance of momentary electrical surges
disturbing your system.
4. Connect the supplied DC power cables to the left and right DC power
output receptacles on the back of the CA-903-P.
5. Connect the other end of the DC power cables to the left and right DC
power input receptacles on the back of the CA-903-L.
6. Connect the left and right analog audio outputs from all audio source
equipment to any of the inputs on the back of the CA-903-L.
7. Connect the left and right analog audio outputs from the back of the
CA-903-L to the inputs of an audio amplifier.
8. With the power switches in the OFF position, attach the power cords to the
CA-903-P and connect them to your AC outlet.
9. Turn on the main power switches. The CA-903 will take approximately 60
seconds to initialize before it is ready for use.
10.Select the desired input signal manually using the front panel input
selector knobs.
11.Use the front panel volume control knobs to set the volume to a
comfortable level.

TUNER
121
3
5
19
715
913
11
23
220
OFF 22
418
6
814
10 12
VOLUME INPUT SELECT
17
16
LINE 1
CD
LINE 2
CANARY AUDIO®
MONO BLOCK
VACUUM TUBE PREAMPLIFIER
LINESTAGE
CA-903-L
Handcrafted in California
FRONT PANEL CONTROLS
CANARY AUDIO®
MONO BLOCK VACUUM TUBE PREAMPLIFIER
POWER SUPPLY
CA-903-P
Handcrafted in California
Power LED:
The blue power LED will
illuminate when the unit
is power on.
Power LED:
The blue power LED will
illuminate when the unit
is power on.
Power Switch:
Power on and off both the
CA-903-P and CA-903-L.
Volume Control:
Adjust the output volume
to the desired level.
Input Selector:
Select the desired input signal
from the 4 available inputs.

DC POWER IN
CD
LINE 1 LINE 2
TUNER
MADE IN USA
CANARY AUDIO®
MONO BLOCK VACUUM TUBE PREAMPLIFIER
LINESTAGE
CA-903-L
Handcrafted in California
AUDIO
OUT 1
AUDIO
OUT 2
CANARY AUDIO®
MONO BLOCK VACUUM TUBE PREAMPLIFIER
POWER SUPPLY
CA-903-P
Handcrafted in California
DC POWER OUT
GND
AC POWER IN
MADE IN USA
WARNING: LETHAL VOLTAGES WITHIN. DO
NOT OPERATE WITH COVER OFF. REFER
SERVICING TO QUALIFIED PERSONNEL.
REAR PANEL CONNECTIONS
DC Power Input:
Connect to the DC power output
of the CA-903-P with the supplied
DC cable.
DC Power Output:
Connect to the DC power input of
the CA-903-L with the supplied
DC cable.
Fuse and Fuseholder:
The fuseholder drawer houses
two line fuses: one is functional
and one is a spare.
Ground connection
for turntable or other
source equipment.
IEC Connector:
Connect with the IEC standard
15 Amp power cord.
Analog Inputs:
4 RCA inputs allow connection
for up to four external sources.
Analog Outputs:
Both RCA outputs are active at all
time. There is no sonic difference
between the two outputs.

SPECIFICATIONS
Model: CA-903
Input Impedance: 50,000 Ohms min
100,000 Ohms max
Output Impedance: 1,200 Ohms
Maximum Gain: 12.3 dB
Frequency Response: +/- 1 dB from 5 Hz to 118,000 Hz
Hum and Noise: -90 dB
Maximum Output Voltage before clipping: 43.9 Volts
Total Harmonic Distortion: < 0.01%
Power Consumption (both channels): 78 Watts (true RMS)
Tube Complement (per channel) - CA-903-L: 1-12AX7/ECC83,
1-12AU7/ECC82
Tube Complement (per channel) - CA-903-P: 1-EF86
1-12BH7
1-5Y3
Dimensions (per channel) - CA-903-L: 11” W x 15” D x 4.75” H
Dimensions (per channel) - CA-903-P: 11” W x 15” D x 4.75” H
Dimensions
Weight (per channel) - CA-903 -L: 12 lbs.
Weight (per channel) - CA-903 -P: 22 lbs.
Note:
Specifications are subject to change without notice. Weight and dimensions are approximate.

LIMITED WARRANTY
Canary Audio warrants to the original purchaser that each CA-903 dual mono
preamplifier is free of manufacturing defects for a period of three (3) years from
the date of purchase. To receive this warranty, the original purchaser must
complete the enclosed Warranty Registration Card and mail it to Canary Audio
within thirty (30) days from the date of purchase. Canary Audio will then validate
the warranty to the original purchaser.
This warranty does not cover cosmetic damage or damage due to acts of God,
accident, misuse, abuse or negligence. This warranty does not cover damage
due to improper operation or maintenance, use with incompatible accessory,
connection to improper voltage supply, or attempted repair, modify or upgrade by
anyone other than Canary Audio or a facility authorized by Canary Audio. This
warranty does not cove any damages to the vacuum tubes and does not cover
normal maintenance.
Canary Audio shall not be responsible in any way for consequential or indirect
damages or liabilities resulting from the use and operation of the product covered
herein or resulting from any breach of this warranty or any implied warranty
relating to said product. Under no circumstances does Canary Audio assume
liability or responsibility for injury or damages sustained in the use or operation of
this equipment or for damages to any other equipment connected to it.
During this stated period, Canary Audio will repair or replace any defective
components free of charge. A Return Authorization Number (RA Number) is
required before any product is returned to our factory for any reason. This
number must be visible on the exterior of the shipping container(s).
Units to be repaired by Canary Audio must be sent shipping and insurance
prepaid by the original purchaser in the original packing material. Canary Audio
will accept no responsibility for any damage occurring to the unit that is shipped
in packing material other than the original packing material. A written description
of the defect and a copy of the original bill of sale should be accompanied with
the returned product.
This warranty applies only to the first end-user purchaser of a CA-903 dual mono
preamplifier that is purchased and used in the United States of America and is
not valid for subsequent purchasers. All other warranties or conditions either
written or implied are void.
Canary Audio
P.O. Box 6216, Rosemead, CA 91770, USA
Telephone: [phone]
Http://www.canaryaudio.com
