Canary CLE-106X User manual

CLE-106X
UTP-to-Fiber
Multi-mode Bridging
Media Converters
CLE-106XS
UTP-to-Fiber
Single-mode Bridging
Media Converters
Features:
512 MAC Address
look up table
IEEE 802.1D
10/100 Mbs UTP-to-Fiber Bridging
Media Converters
Illustrated: LAN Extender Family
Canary’s LAN Extender, CLE-106X, UTP-to-Fiber Bridging Media Converters are longtime
standards for 10/100Mbs UTP media conversion to multi-mode or single-mode fiber. With
the CLE-106X series, the transition between 10 Mbs and 100 Mbs is very straightforward.
They easily make simple connections linking legacy 10 Mbs networks and newer 100 Mbs
segments into a unified network.
Functioning as Collision Domain Extenders, a pair of CLE-106X units allows users of 100
Mbs networks containing older half-duplex equipment with distance limitations to extend
their effective reach by segmenting the network into two separate 100 Mbs half-duplex
collision domains. Better yet, the network can be segmented into half-duplex and full-
duplex segments with a CLE-106X bridging and buffering the data traffic between
them. Each segment is free to operate within its optimal performance envelope without
negatively impacting each other.
Setting the standard … installed success.
The standard for
10/100Mbs UTP media
conversion to multi-
or single-mode fiber.

Canary Communications, Inc.
18655 Madrone Pkwy, #100
Morgan Hill, CA 95037
Tel: [phone]
Fax: [phone]
Web: www.canarycom.com
© 2004 Canary Communications. Canary is
a trademark of Canary Communications, Inc. All
trademarks and registered trademarks are the
properties of their respective companies.
ISO 9001 : 2000
Canary Communications is an
ISO 9001 : 2000 registered company.
Power Supply:
•Input Voltage: 120 VAC
•Output: 12VDC 800mA
(External power adapter)
•Frequency: 60 Hz
Environmental:
•Operating Temp.: 0 to 50ºC
•Storage Temp.: -20 to 70ºC
•Relative Humidity: 5% to 95%
non-condensing
Mechanical:
•Height: 0.9” (2.3 cm)
•Length: 4.3” (10.9 cm)
•Width: 2.9” (7.4 cm)
•Ship Weight: 2.0 lb (0.9 Kg)
•Single Unit: 1.2 lb (0.5 Kg)
Regulatory:
•Designed in compliance with CE, UL, CSA
& TUV standards
•IEEE 802.3 10BASE-T, 802.3u, 100BASE-TX
100BASE-FX, 802.1D MAC Layer Bridging
•Class 1 lasers conform to US 21CFR(J), EN
60825-1, UL 1950 and IEC-825
Warranty:
•Three (3) years Parts & Labor
All information contained within this document is subject
to change without notice at Canary Communications’
sole and absolute discretion. Customer agrees that
Canary Communications is not liable for any actual,
consequential, exemplary or other damages arising from
any use of the information contained herein.
Canary warrants the performance of its products only in
accordance with its stated Five-year or Three-year
standard warranties. Canary Communications disclaims
any and all other warranties including express, implied,
statutory; and including warranties of merchantability
or fitness for a particular purpose – except where
prohibited by law. Canary Communications does not
transfer rights to any copyrighted software code
contained within or used by Canary Products.
Product Specifications Standalone 10/100 Mbs UTP-to-Fiber Bridging Media Converters
The page that follows provides ordering
information for Canary’s Standalone 10/
100Mbs UTP-to-Fiber Bridging Media
Converter products:
•UTP-to-Fiber, Multi-mode Bridging
Media Converters
CLE-106X
•UTP-to-Fiber, Single-mode Bridging
Media Converters
CLE-106XS

Standalone 10/100 Mbs UTP-to-Fiber Bridging Media Converters
CLE-106X – Standalone UTP-to-Fiber Bridging Media Converters
•Converters are Compliant with IEEE 802.3, 802.3u 10/100
Mbs Ethernet standards
•148,800 packets/second forwarding rate at 100 Mbs and
14,880 pps at 10 Mbs
•Switch for hard-setting (Forced) Full-duplex or Half-duplex
operation on fiber port
•Models with Fiber connectors are compatible with
100BASE-FX
•Converters are transparent to Full and Half-duplex traffic
•UTP port connectors have MDI / MDI-X crossover switch
•Full array of status / diagnostic LEDs
•512 MAC address lookup table
•Store-and-forward operation
•MAC Layer Bridge
•5K Byte buffer
•IEEE 802.1D
•Auto-sensing, 110 / 230 VAC Power Supply
•Additional models include: Single-Fiber Bi-Directional single-
mode and Extended Reach single-mode are available as special
order
Ordering Information
Fast Ethernet Media Min. Tx Max. Tx Rx Min. PWR Max.PWR Max. Input Connector Wavelengths Transmit
Model Numbers Types PWR PWR Sensitivity Budget Budget PWR Type (ηm) Distance
CLE-1061 UTP / MM -20.0 dBm -14.0 dBm -31.0 dBm 11.0 dB 17.0 dB -8.0 dBm SC 1310 ηm2000 m
CLE-1062 UTP / MM -20.0 dBm -14.0 dBm -31.0 dBm 11.0 dB 17.0 dB -8.0 dBm ST 1310 ηm2000 m
Specifications above in blue are for multi-mode, fiber connectors. Specifications below for single-mode, fiber connectors.
CLE-1061S UTP / SM -15.0 dBm -8.0 dBm -34.0 dBm 19.0 dB 26.0 dB -7.0 dBm SC 1310 ηm30 Km
CLE-1062S UTP / SM -15.0 dBm -8.0 dBm -34.0 dBm 19.0 dB 26.0 dB -7.0 dBm ST 1310 ηm30 Km
CLE –106X models are available with long-reach single-mode connectors and Single-Fiber, Bi-Directional Connectors as special order. Please contact Canary for correct model numbers
and additional ordering information.
Optical Specifications
Illustrated: Bridging Media Converter
