C&H Digital Multimeter Module PX454S User manual

Rev. A
C&H Technologies, Inc. •445 Round Rock West Drive •Round Rock, TX 78681-5012
[phone] •FAX [phone] •www.chtech.com
Resolution:
10 Hz sampling: 22.5 bits
50/60 Hz sampling: 20 bits
1 KHz sampling: 11 bits
Input Connector: 5W5S DSUB
Airflow (min): 10m3/h
Temperature:
Operating: 0°C to 60°C
Storage: -20°C to 70°C
Power: +5V @ 1.1 A with DC/DC
CPCI/PXI Compliance
Complies with PCI spec. 2.0 R3.0
and PCI spec 2.2
5V and 3.3V signaling voltage (VIO)
supported
5V only power supply
33MHz PCI data bus
Five trigger lines compliant with PXI
Specification 2.1
Form Factor: Size 3U
Applications
•DMM Instrument Functions
•Factory Test
Ordering Information
Part Number 11030230-0001
Additional Information
User Manuals for C&H carriers and
this module can be found on our
website at
www.chtech.com
.
Specifications:
General Characteristics:
•DC or AC voltage and current
•2 or 4 wire resistance measurement
•Up to 22 bits accuracy (6.5 digits)
•Max. resolution of 50nV, 5nA, 50_Ω
•DC Voltage: ±125 mV to ±500V
•DC Current: ±12.5mA to ±2.5A
•AC Vrms:250mV to 250V
•AC Irms:25mA to 2.5A
•Ohms: 0 to 250Ωto 2.5MΩ
•True RMS measurements
•Auto calibration
PX454S
Digital
Multimeter
Module
The PX454S is a full function DMM
suitable for use on a variety of
platforms with the family of C&H
carriers. This DMM is based upon a
24 bit Sigma-Delta A/D converter
with on-chip notch filter. This
technology allows sampling
frequencies (or filter frequencies)
between 10 Hz and 1 KHz providing
varying resolutions. The core
measurement section is optically
isolated and shielded.
This unit also features a position for
adding one single-wide M-Module.

Rev. A
C&H Technologies, Inc. •445 Round Rock West Drive •Round Rock, TX 78681-5012
[phone] •FAX [phone] •www.chtech.com
DC Voltage Measurement:
Maximum Voltage Input:
•HV Input: 500VDC for 500V range
•Normal Input: 125VDC for other ranges
Measuring Ranges:
•±125mV, ±1.25V, ±12.5V, ±125V, ±500V
Measuring Accuracy:
•24 hours, 23°C ±1°C: error < 0.025%
•90 days, 23°C ±5°C: error < 0.05%
•Temp Coefficient, 0 to +55°C: error < 0.01%
Input Impedance:
•500V input (HV) 40 MΩ
•125V and 12.5V ranges 10 MΩ
•1.25V and 125 mV ranges >1 GΩ
Input Current: 10 pA max @ 23°C
CMRR: 100dB @ 50/60 Hz
NMRR: 60 dB @ 50/60 Hz
AC Voltage Measurement:
Maximum Input Voltage:
•High Voltage Input: 250V AC
•Normal Input: 60V AC
Measuring Ranges:
•250mVrms, sine 40 Hz-100KHz: error < 5%
•2.5Vrms, sine 40 Hz-100KHz: error < 1%
•25Vrms, sine 40 Hz-100KHz: error < 1%
•250Vrms (HV in) sine 40 Hz-100KHz: error < 1%
Crest Factor: 4 max
Measuring Accuracy @ 50/60 Hz:
•24 hours, 23°C ±1°C: error < 0.5%
•90 days, 23°C ±5°C: error < 1.0%
•Range Error: < 1%
Input Impedance:
•High-voltage input: 40 MΩ
•Normal Input: 1 MΩ
Input Current: 10 pA max @ 23°C
CMRR: 100dB @ 50/60 Hz
DC Current Measurement:
Maximum Voltage: 60 V on all ranges
Measuring Ranges: ±12.5mA, ±125mA, ±1.25A, ±2.5A
Measuring Accuracy:
•24 hours, 23°C ±1°C: error < 0.025%
•90 days, 23°C ±5°C: error < 0.05%
•Temperature Coefficient, 0 to +55°C: error < 0.01%
Shunt:
•12.5mA and 125mA ranges: 1 Ω
•1.25A and 2.5A ranges: 0.1 Ω
AC Current Measurement:
Maximum Voltage: 42 V on all ranges
Measuring Ranges: 25mA, 250mA, 2.5A all RMS
Crest Factor: 4 max
Measuring Accuracy:
•24 hours, 23°C ±1°C: error < 0.5%
•90 days, 23°C ±5°C: error < 1.0%
Shunt:
•25mA and 250mA ranges: 1 Ω
•2.5A ranges: 0.1 Ω
Resistance Measurement:
Measuring Ranges: 250_, 2.5K_, 25K_, 250K_, 2.5M_
Measuring Accuracy (All but 2.5M_ range):
•24 hours, 23°C ±1°C: error < 0.1%
•90 days, 23°C ±5°C: error < 0.2%
•Temperature Coefficient, 0 to 55°C: error < 1%
Measuring Accuracy (For 2.5M_ range):
•24 hours, 23°C ±1°C: error < 1.0%
•90 days, 23°C ±5°C: error < 2.0%
•Temperature Coefficient, 0 to 55°C: error < 0.1%
Measuring Modes: 2- or 4-wire
Maximum Measuring Voltage: 2.5V
