Candy 37000142 User manual

37000142 CFU271AFF -8
Service Manual

50n
IEFR2090
70a-51
49g
76m 27h
50z
80-82
111e
114d
114b
114c

IEFR2092
143
144
383 383t
132
135b
135a
162
161
161q
160d
161p
131b
131a
159d
251
284
422u
422a
8a
113d
422a

253
8a
IEFR2091
28
44
30
42b
1
125a
126
45a
360
1c
124
31
321b
113d
115
130a 127b
128
320
270b
130d
428
251d
115a
109b
109c
422h
252
257

Copyright 2006 Gias S.r.L.
Ricambio
Part No.
Piece
E-Teil
Pieza
Inizio
Beginning
Debut
Begin
Inicio
Fine
Ending
Fin
End
Fin
Ref. Descrizione - Description - Beschreibung - Descripcion
Mod: 37000142 CFU271AFF -8 0521 (19/05/2005)
1Compressor 41015477
1c Run capacitor 97058820
8a Adjustable front foot 92690593
27h Door cap lens 91602600
28 Condenser 91750118
30 Clip-Clamp 92663442
31 Wall spacer 92678234
42b Compressor fixing plate 92854157
44b Drip evap.tray ZEM 41009011
45a Rear foot 92473404
49g Door trade-mark plate 41015533
50n Freezer door complete (Tall end cap) 41014360
50z Rod 41014361
51 Door handle 41015138
76m Door cap rear Insert 41015482
82 Freezer gasket 41014382
109 Upper hinge (R/H) 41009508
109a Upper hinge (L/H) 41010020
111 Door sleeve for hinge pin 92144161
111e Upper door sleeve for hinge 41010605
113d Lower hinge 92888072
115 Spacer 92433309
124b 3 ways Dryer Filter 41012883
125a Insulating foam tube 92607720
126 Compress.shock absorber 92607290
127b Freezer evaporator 41014790
128 Defrostin.heating element 41014789
128b Drain hose heating strip 92894609
130a Freezer evaporat.support 41014520
130d Evaporator insulating piece 41014521
131a Right support 41014498

Copyright 2006 Gias S.r.L.
Ricambio
Part No.
Piece
E-Teil
Pieza
Inizio
Beginning
Debut
Begin
Inicio
Fine
Ending
Fin
End
Fin
Ref. Descrizione - Description - Beschreibung - Descripcion
Mod: 37000142 CFU271AFF -8 0521 (19/05/2005)
131b Left support 41014499
132 Inner divider 41014967
132c Push-in plastic rivet 41015474
135a Evaporator freezer door 41014146
135b 4 stars evapor.door assy 41014519
143 R/H evaporator door supp. 92942192
144 L/H evaporator door supp. 92942200
159d Freezer Aluminum shelf 41015506
160d Middle/upper Freezer drawer body 41014139
161o Large lower basket 41014142
161p Roller basket 41014144
161q Pin for basket wheel 41014143
162e Middle bask. front piece 41003951
251 Evaporator cover panel 41014522
251d Evapora.cover-Lower panel 41014527
251e Cover gasket (Evaporator/fan support) 92058304
252 Fan motor 41015505
253b Refrigerator Fan Buffer 91620020
257 Fan 92633213
270b Defrost sensor and thermal fuse assy 41003551
284 Dashboard 41015310
284a Stopper for screw hole 41010657
320 Water drip outlet 41015473
321b Freezer drain hose 41015507
341a Handle holes plug 92144179
360 Compressor cross piece 92871789
422a Dashb.circuit plate key 41015530
422h Freezer Board,PC 41014985
422u Control panel frame 41015529
428d Freez.tempe.reading probe 91212936
999 Wiring diagram 41014968
