Candy CTAS 127 User manual

17
EN
This Instruction Manual
contains everything you need
to know about the everyday
running of your machine.
Keep it for future reference.
An Installation and
Maintenance Manual is also
provided which you should
consult during the installation
and routine maintenance of
your washing machine. The
manual also contains
information about possible
working problems, advice
about the wash load, an
explanation of label symbols
and hints about how to remove
stubborn stains.
INTRODUCTION
Read this manual carefully as it offers practical advice to help you get the most from your
washing machine.
1.- CONTROL PANEL
2.- LID
3.- DRUM
4.- DETERGENT COMPARTMENT
5.- FILTER DOOR
6.- FILTER
7.- WHEEL TROLLEY
When contacting a CANDY or one of its Technical Assistance Cen-
tre always refer to the model (see control panel) and the registration
and series numbers which are indicated at the bottom of the machine
under the lower panel or on the warranty certificate. That is to say,
everything that appears in the box.
Providing this information will ensure a faster and more efficient service.

18
INDEX
GUARANTEE.............................................................................. 19
TECHNICAL DATA ....................................................................... 20
OPENING THE LID – LOADING ................................................ 21
DETERGENT DISPENSER ........................................................ 22
AUTOMATIC VARIABLE CAPACITY - FUZZY LOGIC
ELECTRONICS ...........................................................................
23
PROGRAMME SELECTION ....................................................... 24
CONTROL DESCRIPTION .......................................................... 25
TABLE OF PROGRAMMES ....................................................... 29
page
Place the attached «program label»
in the corresponding language in the
rear slot of the panel window.

19
SERVICE
A
GUARANTEE
1.
The appliance comes with a guarantee certificate.
2.
Complete part Aand keep it in a safe place. It should
be presented to the Technical Assistance Centre in
the event of a repair being necessary along with the
legal receipt issued by the dealer on purchase.

20
5
230
125
400
30
1.950
2.200
10
0,05 min.
0,8 max.
1200
45
0,95
A
CTAS 127
TECHNICAL DATA
Load capacity ........................................................................ kg.
Voltage ..................................................................................... V.
Wash motor power rating ........................................................ W.
Spin motor power rating .......................................................... W.
Electropump power rating ....................................................... W.
Heating element power rating ................................................. W.
Max. power input ..................................................................... W.
Fuse ........................................................................................ A.
Water pressure ................................................................... MPa
Spin speed .............................................................. r.p.m./min
Water consumption (60º C programme) ................................ lit.
Energy consumption (60º C programme)/5 kg................... kWh
Energy efficiency rating ..............................................................

21
OPENING THE DRUM
1.
Lift the lid ( A ) and open it completely. Next, open the drum
door following these instructions:
2.
Place your hand on the rear door ( D ).
Hold the catch (
B ) down.
Press the front door (
C ) to unlock the two doors ( C and
D ).
3.
Open the rear door ( D ). Open the front door ( C ).
Place the washing in the drum.
4.
Close the front door ( C ).
Close the rear door (
D ) so that the front door ( C )
fasteners fit perfectly into the slots.
5.
Ensure that the doors fit together perfectly and are
properly closed.
ATTENTION:
CLOSE THE DRUM CAREFULLY. OTHERWISE, THE
MACHINE OR THE LAUNDRY COULD GET
DAMAGED.
WASHING
MACHINE LID
FRONT OF THE
WASHING MACHINE
2 min. ATTENTION:
A special safety device
prevents the lid from
being opened immediately
after the wash has
finished. Once the spin
cycle has finished, wait for
2 minutes before trying to
open the lid.
FRONT OF THE
WASHING MACHINE
FRONT OF THE
WASHING MACHINE
FRONT OF THE
WASHING MACHINE

22
Note: WE RECOMMEND USING DETERGENT IN POWDER FORM WHENEVER
A PRE-WASH IS PROGRAMMED.
DETERGENT DISPENSER
The detergent dispenser is divided into 4 compartments:
• Compartment I, is for prewash powder detergent. The recommended quantity is
60 gm of detergent (for 5 kg of laundry).
• Compartment II, is for wash powder detergent. The recommended quantity is 120
gm of detergent (for 5 kg of laundry).
• The compartment is for bleach. The recommended quantity is 7 cl.
• The compartment is for fabric conditioners, scenting agents and special
additives. The recommended quantity is 5 cl.
The detergent compartment has two guidance lines:
• RECOMMENDED (lower line).This indicates the recommended level for the prewash
and wash compartments.
• MAX. This indicates the maximum level which should never be exceeded.
MAXIMUM
(wash)
MAXIMUM
(bleach and scenting agent)
MAXIMUM
(prewash)
RECOMMENDED

23
AUTOMATIC VARIABLE CAPACITY – FUZZY LOGIC ELECTRONICS
This machine has electronics that automatically process all stages of the wash to
ensure exceptional results and at the same time save you time and money.
Once a programme has been selected, the machine optimises the following elements
depending on the wash load and type of fabric:
-quantity of water and power consumption
-wash time
-drum rotation rate
-rinse efficiency
The washing machine also:
-detects suds and increases the amount of rinse water if necessary
-adjusts spin speed according to load distribution, thus forestalling any imbalance in
the mechanism.
HALF LOAD
APPROX.
5%
20%
20%
EXAMPLE: COTTONS PROGRAMME AT 60º
LOAD
POWER KWH
TIME MIN.
WATER LITRES
FULL LOAD
(5 KG)*
0,95
135
45
SMALL LOAD
APPROX.
30%
30%
50%
The programme duration indicated is APPROXIMATE.
GAIN WITH REGARD TO
5 kg CYCLE
GAIN WITH REGARD TO
5 kg CYCLE

24
PROGRAMME SELECTION
Select as follows:
• Check the programme table and set the desired programme using selector
(A)
• Select the options as permitted: the options available via the keys depend on
which programme is selected. If a key flashes when pressed, the options it offers are
not available. If it remains lit, they are. Options can be seen on the display (V).
• Press the Start/ Pause button. The door lock lamp will light up and the display will
show three dashes (- - -) and then the average duration of the programme selected.
After 10-15 minutes, during which time the water temperature, amount of washing,
etc. are determined, the display will show the time remaining to the end of the wash
cycle.
• Because the machine is electronic, the programme may take up to one minute to
commence. Its fuzzy logic programming technology gives this machine smart
monitoring capabilities, enabling it to adapt water levels, washing rates and spin
speeds with no further intervention by the user.
NOTE: A special memory unit stores the programme choice in case of power failure, so that
the machine will resume washing at the point where it left off when power is restored.
END OF CYCLE: At the end of the cycle the lights go out and the display reads (0 0 0). After
2 minutes, the display begins to flash. This means that the washing can be removed.
Press Start/ Pause and set the control to OFF.

25
PROGRAMME/ TEMPERATURE SELECTOR ...........................
DISPLAY: Delayed start, Spin-speed, Temperature,
Time remaining ...........................................................................
SPIN REGULATION button ........................................................
SUPER FAST button...................................................................
ACTIVA RINSE button ................................................................
EASY IRON button .....................................................................
DELAYED START button ............................................................
Door secure ................................................................................
START/ PAUSE button ................................................................
Reference indicator .....................................................................
A
V
D
E
F
I
K
G
H
p
CONTROLS
CTAS 127

26
A . PROGRAMME/ TEMPERATURE SELECTOR
THIS CONTROL TURNS BOTH WAY
Use this control to select the desired wash programme/
temperature. Turn the control to bring the marker dot (p)
into line with the number or symbol of the desired
programme. Temperature selection depends on the
programme selected. The display shows the temperature
or the relevant readings for special programmes.
For programme selection, follow the programme table.
To change settings or programmes when a programme
is under way, proceed as follows:
-Press Start/ Pause. The display will read (0 0 0).
-Select the new programme with the selector.The temperature of the programme selected
or the relevant indication for special programmes will appear.
-Press Start/ Pause again.
-The machine will run the new programme.
To add more washing when the programme is under way, proceed as follows:
- Hold down Start/ Pause until the display shows three dashes (- - -).
-When the Door Secure lamp goes off, open the door and add more washing.
-Close the doors of the drum and the outer cover.
-Press Start/ Pause.
V .DISPLAY: Delayed start, Spin speed,Temperature, Time remaining.
Display as per function indicated.
NOTE: Only lit buttons are enabled: if a button flashes the options it offers are not available
in the programme selected.
To change options when a programme is under way, proceed as follows:
-Press Start/ Pause until the display shows three dashes (---), then flashes the
temperature of the programme selected.
-Make the change desired (e.g. reduction of spin speed).
-Press Start/ Pause.The time remaining to the end of the programme will appear on the
display.
-The machine will resume the programme with the new setting.
USE OF THE SELECTION CONTROLS

27
D . SPIN REGULATION BUTTON
This key selects the spin speed for the last rinse.
When it is pressed, the display shows the options permitted under the
programme selected.
The display reads 0 for no spin and a sequence from 4 to 12 for speeds of 400 to 1200 rpm.
For cotton programmes the options available are 1200 to 400 and 0 (no spin).
For mixed/ synthetics programmes the options are 800 to 400 and 0 (no spin).
For delicates programmes the options are 400 and 0 (no spin).
For wool programmes the options are 800 to 400 and 0 (no spin).
For the hand wash programme the options are 800 to 400 and 0 (no spin).
For the rinse programme the options are 800 to 400 and 0 (no spin).
For the spin programme the options are 1200 to 400 and 0 (no spin).
For the emptying programme there is no spin option.
For the Mix & Wash System programme the options are 1000 to 400 and 0 (no spin).
For the 32 minute cycle programme the options are 800 to 400 and 0 (no spin).
E. SUPER FAST BUTTON
When this button is engaged programme times are cut by as much
as 50 minutes, depending on the wash programme and temperature
selected. This button works only with loads of between 2 and 5 kg. of
washing, and with the Cottons and Mixed Synthetics programmes.
F . SUPER RINSE BUTTON
The new electronic system engaged by this button activates a special
rinse cycle. More water and a new combination of drum rotation
movements during filling and emptying ensure that washing is perfectly
rinsed.
This function is designed for people with sensitive, delicate skins
in whom even tiny amounts of bleach could cause irritation or
allergic reactions.
It is also recommendable for washing baby clothes, heavily soiled
clothes which need large amounts of bleach and spongy articles
which tend to retain bleach.
USE OF THE SELECTION CONTROLS

28
USE OF THE SELECTION CONTROLS
I. EASY IRON BUTTON
This function helps reduce creasing, depending on the programme
selected and the type of fabric washed.
MIXED FABRICS:
- the water is cooled gradually to prevent heat shock
- the drum is not moved mechanically during emptying
- a mild spin is used to ensure that fibres are smoothed out as much
as possible.
DELICATE FABRICS (OTHER THAN WOOLLENS):
-The machine operates as indicated above and stops with the drum full of water after the
last rinse.
WOOLLENS:
-The machine stops with the drum full of water.
To complete the cycle for delicates and woollens, proceed as follows
1.- Disengage the Easy Iron (wrinkle reduction) button.The cycle will then run to completion,
with emptying and spin.
2.- Or just empty the drum:
- stop the machine by pressing Start/ Stop.
- set the programme control to OFF.
- select programme .
- wait 5 seconds.
- start up the machine.
K . DELAYED START BUTTON
From 0 to 23 hours. Available on all programmes. When this button is
pressed the display shows the number of hours’ delay before the
programme starts. The delay increases by one hour each time the key is
pressed.
G. DOOR SECURE
H. START/PAUSE BUTTON

29
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
RINSE
SPIN
EMPTY
MIX & WASH
FAST-32 MIN.
•
•
•
•
—
—
—
170
32
—
—
—
40º
50º
50
50
50
50
100
85
75
70
70
65
2
2
2
2
2
2
FAST COLOUREDS WITH PRE-WASH
FAST COLOUREDS
FAST COLOUREDS
DELICATE COLOUREDS
DELICATE COLOUREDS
DELICATE COLOUREDS
(cold wash, water at 15 ºC)
60º
60º
50º
40º
30º
P
140
160
135
105
100
95
5
5
5
5
5
5
90º
60º
60º
40º
30º
—
—
—
5
2
•
•
•
•
•
•
•
•
•
•
•
•
DELICATES
WOOLMARK WOOLLENS
WOOLMARK WOOLLENS
(cold wash, water at 15 ºC)
HAND WASH
•
•
•
•
1,5
1
1
1
MAX.
LOAD
•
•
•
•
•
•
•
•
•
•
•
•
•
•
WHITES
FAST COLOUREDS WITH PRE-WASH
FAST COLOUREDS
FAST COLOUREDS
DELICATE COLOUREDS
DELICATE COLOUREDS
(cold wash, water at 15 ºC)
PROGRAMME FOR
TABLE OF PROGRAMMES
III
•
PROG.
DETERGENT
LOAD
•
•
•
ºC
P
40º
30º
30º
Programme *, as per EN standard 60456.
The programme times indicated are approximate.
*
There are four programme groups (COTTONS, SYNTHETICS,
DELICATES and SPECIFIC PROGRAMMES). The first programmes
in each group are the longest, and therefore those that ensure the
most effective wash results. Use the remaining programmes only
for lightly soiled washing and especially delicate garments.
COTTONS
BUTTON
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
SYNTHETICS
•
•
•
•
•
•
•
•
•
•
•
•
DELICATES
SPECIFIC
PROGRAMMES
•
APPROX
TIME (min.)
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
MIX
WASH
CTAS 127

30
REMARKS
1.For very heavily soiled washing, use loads of no more than 3 kg.
2.With the Cottons programmes (WHITES 90º - FAST COLOUREDS 60º) automatic whitening can
be obtained by adding bleach to dispenser .
3.The machine is designed to add fabric softener automatically during the last rinse in all wash
cycles.‘
SPECIFIC PROGRAMMES
HAND WASH
This machine has a hand wash programme which enables you to machine-wash clothes which
are intended to be washed by hand. The programme runs at 30 ºC and ends with 3 rinses and a
spin specifically designed for highly delicate garments.
SPECIAL RINSE PROGRAMME
This programme runs through three rinses and a spin at 800 rpm (spin speed can be reduced or
spin can be eliminated completely). This can be used to rinse all types of fabric, e.g. after hand
washing.
SPECIAL VIGOROUS SPIN PROGRAMME
This runs through a spin cycle at 1200 rpm (spin speed can be reduced)
EMPTY ONLY
This empties the water from the machine.
MIX & WASH
The MIX & WASH programme enables all types of fabric to be washed together.
- Never mix coloureds that dye.
- New coloured items should be washed separately the first time.
32’ FAST PROGRAMME
This programme runs through a full wash cycle for a maximum of 2 kg of washing at 50 ºC in just
32 minutes.
Put the detergent in dispenser II. Use no more than approximately 1/4 of the recommended
amount of bleach (35 g. at most).
The 32’ fast programme can also be used as a pre-wash cycle for particularly heavily soiled
garments before the regular wash programme desired.
