Cannon 10390G Mk2 Technical manual

WINCHESTER Mk2
Use and Installation Instructions
The cooker must be installed in accordance with the regulations in force and
only used in a well ventilated space.
Read these instructions prior to installing or using the cooker and
retain them for future reference.
The Data Badge is located below the oven door.
Part no. 4466200011-02
PRINTED BY SIMLEX .FOUR ASHES, WOLVERHAMPTON.

CONTENTS PAGE
INTRODUCTION 2
FOR YOUR SAFETY 3
USER’S INSTRUCTIONS 5
Automatic Cooking 6
Electronic Clock Operation 7
Hotplate 12
Grill 14
Oven 15
Oven Cooking Chart 18
Care and Cleaning 20
Something Wrong With Your Cooker? 23
INSTALLATION INSTRUCTIONS 25
SERVICE INFORMATION Back Cover
CONTENTS
1

To help you make the best use of your cooker, PLEASE READ THIS BOOKLET
CAREFULLY.
Your new cooker is guaranteed and will give lasting service. The guarantee is only
applicable if the cooker has been installed in accordance with the Installation
Instructions.
The cooker is designed specifically for domestic use and responsibility will not be
accepted for use in any other installation.
When first using the cooker ensure that the room is well ventilated (e.g. open a
window or use an extractor fan) and that persons who may be sensitive to the odour
avoid any fumes. It is suggested that any pets be removed from the room until the
smell has ceased. This odour is due to any temporary finish and also any moisture
absorbed by the insulation.
2
INTRODUCTION
Our policy is one of continual improvement in design and development,
therefore strict accuracy of illustrations and descriptions cannot be
guaranteed.
This appliance conforms to the following EEC Directives:
Gas Appliances
90/396/EEC
Low Voltage Equipment
72/23/EEC
93/68/EEC
Electromagnetic Compatibility
89/336/EEC
92/31/EEC
93/68/EEC

Please read the precautions below before using your cooker.
ALWAYS make sure you understand the controls before using the cooker.
ALWAYS check that all controls on the cooker are turned off after use.
ALWAYS stand back when opening oven door to allow heat to disperse.
ALWAYS use dry, good quality oven gloves when removing items from the
ovens.
ALWAYS keep the oven door closed when the cooker is not in use.
ALWAYS place pans centrally over the hotplate burners and position them so
that the handles cannot accidentally be caught or knocked or become
heated by other burners.
ALWAYS keep the cooker clean, as a build up of grease or fat from cooking can
cause a fire.
ALWAYS allow the cooker to cool before cleaning.
ALWAYS follow the basic principles of food handling and hygiene to prevent the
possibility of bacterial growth.
ALWAYS turn off the electricity supply before cleaning or replacing the oven
lamp.
ALWAYS refer servicing to CORGI registered appliance service engineers.
3
FOR YOUR SAFETY

NEVER leave children unsupervised where the cooker is installed as all surfaces
will get hot during and after use.
NEVER allow anyone to sit or stand on any part of the cooker.
NEVER store items that children may attempt to reach above the cooker.
NEVER heat up unopened food containers as pressure can build up causing
the container to burst.
NEVER store chemicals, food stuffs, pressurised containers in or on the cooker,
or in cabinet immediately above or next to the cooker.
NEVER fill a deep fat frying pan more than 1/3 full of oil, or use a lid. DO NOT
LEAVE UNATTENDED WHILE COOKING.
NEVER place flammable or plastic items on or near the hotplate.
NEVER use proprietary spillage collectors on the hotplate.
NEVER use the cooker as a room heater.
NEVER dry clothes or place other items over or near to the hotplate or oven/grill
doors.
NEVER wear garments with long flowing sleeves whilst cooking.
NOTE: The use of a gas cooking appliance results in the production of heat and
moisture in the room in which it is installed. Always ensure that the kitchen is well
ventilated; keep natural ventilation holes open or install a mechanical ventilation
device (mechanical extractor hood).
In particular when using the grill or more than one hotplate burner, open a window if
a mechanical ventilation device is not operating.
4
FOR YOUR SAFETY

5
USER’S INSTRUCTIONS
Grill Top Cover
Grill Cover
Side Panels
Grill Pan
Grid
Timer
Splash Back
Side Trim
Pan Supports
Hotplate
Top
Control
Knobs
Outer
Side Panel
Grill Pan
Grill Shelf
Splashback
Hotplate
Burners
Hotplate Control
Fascia
Oven Door
Handle
Ignition Button
Oven Door
Glass Panel
Storage
Compartment
Plinth Panel

6
OVEN TIMER OPERATION
The oven timer offers you the following features:
1. Time of Day
2. Automatic Cooking
3. Minute Minder
AUTOMATIC COOKING
The main oven can be controlled automatically.
GUIDANCE ON AUTOMATIC COOKING
1. Select foods which will take the same time to cook.
2. Set the oven timer so that the food has just finished or is just about to finish
cooking on your return to the oven. This will ensure the food has not cooled
down and does not require reheating before serving.
3. Food should be as cold as possible when it goes into the oven, ideally
straight from the refrigerator. Frozen meat and poultry should be thawed
thoroughly before it is put in the oven.
4. We advise that warm food should never be placed in the oven if there is to be a
delay period. Stews prepared by frying the meat and vegetables should be
cooked as soon as possible.
5. We advise dishes containing left-over cooked poultry or meat, for example
Shepherds Pie, should not be cooked automatically if there is to be a delay
period.
6. Stews and joints should be cooked by the long slow method, so that the delay
period is kept to a minimum.
7. On warm days, to prevent harmful bacterial growth in certain foods (ie poultry,
joints, etc) the delayed start should be kept to a minimum.
8. Wine or beer may ferment and cream may curdle during the delay period, so it
is best to add these ingredients just before serving.
9. Foods which discolour should be protected by coating in fat or tossing in water
to which lemon juice has been added, prior to placing food in the oven.
10. Dishes containing liquid should not be filled too full to prevent boiling over.
11. Food should be well sealed (but not airtight) in a container to prevent the loss
of liquid during cooking. Aluminium foil gives a good seal.
12. Ensure food is cooked thoroughly before serving.
TIMER OPERATION
1. make sure all oven controls are turned OFF.
2. Check that the electricity supply to the cooker is turned ON.
3. Check that the timer is set to the correct time of day.

7
CLOCKFACE
The timer incorporates a 24 hour clock.
Ensure correct time of day is always set, before using your cooker.
PLEASE NOTE THAT THE DISPLAY WILL DIM BETWEEN 22.00
HOURS AND 06.00 HOURS TO PREVENT GLARE.
However, should you operate the timer during these hours the display will
return to normal brightness for a few seconds and then dim again.
SYMBOLS
will light up when you select a Minute Minder Period and will remain
lit for the period set. At the end of the Minute Minder Period, the timer
will emit an audible tone for 2 minutes, the symbol will start to flash
and will continue to flash until the Minute Minder function is cancelled.
This “Cookpot” symbol will light up either:–
– When you press the Cook Period Button and set a length of time for
an Auto Cooking Programme. (It will go out again a few seconds after
you release the timer buttons).
– During the actual Cook Period.
“AUTO” will light up:–
– When the timer is first turned on it will flash. (It will go out when a
time of day is set.
– When an Auto Cooking Programme has been set.
The “Auto” symbol will flash at the end of an Auto Cooking programme
to indicate that the programme has finished.
(When the “Auto” symbol is flashing, to return the oven to Manual
operation, turn the oven controls off, ensure that the correct time
of day is set, and press the “Manual” button twice – The “Auto”
symbol will go out.
Here you can set a time period of up to 23 hours 59 minutes, that will count down.
When it reaches zero, the timer will emit an audible tone.
For Example: If you set 20 minutes, the audible tone will occur 20 minutes later.
Cook Period is the actual length of time for which, the timer will switch the oven(s)
on as part of an “Auto Cooking” programme.
(e.g. If you set 2 hours, the food will be cooked for 2 hours).
The time of day at which you want an “Auto Cooking” programme to end.
For Example: If you set a “Cook Period” for 2 hours, and “End Time” of 11:00. The
timer will switch the oven(s) on at 9:00 and turn the oven(s) off at 11:00. You will
hear a audible tone at 11:00, to indicate that the Auto
Cooking Programme has finished.
Notes:
– When setting an Auto Cooking programme you will need to set the oven con-
trols(s) to the required temperature(s) when you set the timer.
_ If an Auto Cooking programme has been set the oven(s) will only operate during
the pre-programmed time.
Needs to be pressed to cancel an Auto Cooking programme and return the
ovens(s) to Manual operation.
Used to adjust the various timer function settings.
Minute Minder
Button
Cook Period Button
End Time Button
Manual Button
“+” and “–” Buttons
Minute
Minder Cook
Period End Time Manual
A
U
T
O
A
U
T
O
Minute
Minder Cook Period End Time Manual
TIMER FUNCTION BUTTONS
AUTO COOKING PROGRAMME
KNOW YOUR TIMER

SETTING THE TIME OF DAY
Step 1 Make sure all oven controls are turned Off.
Step 2 Check the electricity supply to the cooker is turned on.
Step 3 When switched on the display will show 0.00 and Auto symbol
will be flashing intermittently.
Step 4 Press & hold in both the “Minute Minder” & “Cook Period” button
together.
Step 5 With the “Minute Minder” & “Cook Period” buttons still held in,
press either the “+” or “–” buttons to set the correct time of day.
Step 6 Release all the buttons simultaneously.
THE TIME OF DAY IS NOW SET.
To change the time of day repeat Steps 4, 5 & 6 above.
Note: You cannot adjust the time of day if the timer has been set
for an Auto Cooking Programme.
SETTING THE MINUTE MINDER
Step 1 Ensure the time of day is set correctly.
Step 2 Press and hold the Minute Minder Button, a symbol will light up.
Step 3 With the “Minute Minder” button held in, set the required Minute
Minder time using the “+” and “–” buttons.
Release all buttons and the timer display will revert back to the time of day.
Bell symbol will remain lit to signify that a Minute Minder period has been set.
At the end of the set time a bleeping sound will be heard, and the
symbol will flash for approximately 2 minutes.
After approximately 2 minutes the bleeping sound will stop and the
symbol will go out automatically.
Step 4 To cancel the bleeping sound within the two minutes press the
Minute Minder button.
A
U
T
O
Minute
Minder Cook Period End Time Manual
Minute
Minder Cook Period End Time Manual
Bell Symbol
Minute
Minder Cook Period End Time Manual
Minute
Minder Cook Period End Time Manual
Note 1 When the Minute Minder has been set, the time remaining can be
checked at any time by simply pressing the Minute Minder button.
Note 2 If necessary the Minute Minder can be cancelled before the tone sounds
by pressing and holding the Minute Minder button and then at the same
time pressing the “–” button until 0.00 appears in the display window.
8
ELECTRONIC CLOCK & AUTOMATIC OVEN
TIMER OPERATION
