Overview
From Canon’s long history of optical excellence, advanced image processing, superb performance
and technological innovation in photographic and broadcast television cameras comes the latest in
camcorders.
Now, with the light, compact Canon FS10, you can have stunning video with the ease and numerous
benefits of Flash Memory, at an affordable price. Flash Memory is used in some of the world’s most
innovative electronic products such as laptop computers, MP3 players, PDAs and cell phones. Canon
offers the best in Flash Memory with Dual Flash Memory- record to both the camcorder’s 8GB internal
memory and a removable SDHC card, extending your available recording space and offering added
flexibility in file transfer and playback. It’s just the thing for catching more of your life’s most special
moments.
Add to that the FS10’s Canon Exclusive features such as Canon 48x Advanced Zoom and our DIGIC
DV II Image Processor, combined with a 1.07 Megapixel CCD image sensor, Image Stabilization and
a 2.7” Widescreen LCD -- and you truly have a Flash Memory camcorder that’s both hard to beat and
unmistakably Canon.
© 2008 Canon U.S.A., Inc. All rights reserved. Duplication in whole or in part without permission is prohibited. Page 1

© 2008 Canon U.S.A., Inc. All rights reserved. Duplication in whole or in part without permission is prohibited. Page 2

© 2008 Canon U.S.A., Inc. All rights reserved. Duplication in whole or in part without permission is prohibited. Page 3
Features
Flash Memory in a Compact Size
The FS10 is one of Canon’s first and most affordable Flash
Memory camcorders.
In addition to the advantage of added recording time, Flash
Memory offers more to you as well. You’ll appreciate its quick
response time, because it doesn’t have to wait for moving parts.
Press the record button and your FS10 starts recording video
faster than you’ve ever seen before. In addition, when you review
your footage, it will start playing more quickly as well.
Another plus is the FS10’s lower power consumption rate, allowing your battery to last longer. It’s just
what you need so you don’t miss that pivotal play on the field or the moment when they say “I do”.
While we certainly hope you keep your FS10 securely in your hand while shooting, if it happens
to slip, or you accidentally knock it against something, you’ll be happy to know that Flash Memory
makes your camcorder more shock resistant than other recording storage systems. It also minimizes
the chance of data loss due to damage to your recording media or the moving parts in other
camcorders.
Making this new technology even more convenient to use is the FS10’s compact size and light
weight. Measuring only 2.3” wide, 2.4” high and 4.9” deep, it combines big video storage capacity in a
small, easy to carry body.
A Class 2 or higher card is recommended. Also, movie recording requires cards with 128 MB of
memory or more. Cards made by Toshiba, SanDisk or Matsushita are recommended. No particular
restrictions apply for still images.

© 2008 Canon U.S.A., Inc. All rights reserved. Duplication in whole or in part without permission is prohibited. Page 4
What makes the FS10 stand out in the category of Flash Memory
camcorders is its Dual Memory capability. You can capture video on both
the camcorder’s internal 8 GB Flash Memory as well as onto an SDHC
Memory Card.
Video stored on the internal memory can also be copied onto the memory card which can then be
inserted into your computer or televisions card reader slot for immediate viewing. It is also possible to
transfer still images recorded to the SDHC card to the internal memory.
Additionally, you can use higher capacity memory cards to further increase the video storage of your
FS10. A Class 2 or higher card is recommended. Also, movie recording requires cards with 128 MB
of memory or more. Cards made by Toshiba, SanDisk or Matsushita are recommended. No particular
restrictions apply for still images.
Dual Flash Memory: 8GB internal flash drive and SDHC card slot
With the FS10 you get a powerful 1.07 Megapixel CCD image sensor. The video you shoot will be
sharp, clear and more true to life, as will your still photos. You’ll capture every dramatic color in a
sunset at the beach and see more clearly than ever the happiness on the face of your child as she
scores the winning goal in the big game. Relive your memories, just as they happened.
Megapixel Performance

© 2008 Canon U.S.A., Inc. All rights reserved. Duplication in whole or in part without permission is prohibited. Page 5
Canon Exclusive: Genuine Canon 48x Advanced Zoom
The Genuine Canon 48x Advanced Zoom on the FS10
is just the kind of exclusive Canon feature you’ve
come to expect from the leader in imaging and optics.
Advanced Zoom extends the power of your zoom and is
the longest zoom Canon has ever offered. In both wide
angle and telephoto positions, there is virtually no loss in image quality throughout the range. How is
this accomplished? With a Genuine Canon lens which remains in constant motion through the entire
extended zoom range aided by our proprietary DIGIC DV II image processor.
There’s practically no loss in image quality through an extraordinary range of zoom, so you’ll get
good, clear shots as you follow that sailboat race around the harbor or catch every step of that toddler
scrambling across the lawn.
The FS10 offers you more flexibility to get just the shot you need by giving you the choice of
Advanced Zoom in default mode or you can select a 37x Optical Zoom or a 2000x Digital Zoom. You
will always be able to get the shot you need, no matter how close or far away and always with the
quality you expect from Canon.

© 2008 Canon U.S.A., Inc. All rights reserved. Duplication in whole or in part without permission is prohibited. Page 6
Canon Exclusive: DIGIC DV II Image Processor
The Canon DIGIC DV II Image Processor is the next generation of Canon’s exclusive DIGIC DV
signal processing technology. Designed specifically for HD, DIGIC DV II ensures optimal image
quality. It also ensures optimal image quality for still images, even though video and still images have
different color requirements. DIGIC DV II is just another one of Canon’s advanced technologies that
make the FS10 an exceptional performer.
Thanks to Canon DIGIC DV II image processing, the FS10 produces video with improved color
reproduction -- especially in skin tones, and dark and light scenes. It also uses a hybrid noise
reduction system that employs two types of noise reduction -- for video images that are crystal clear.
Regardless of your subject or setting, there’s no worry about capturing them more closely to the way
they appear in front of you.
Plus, the Canon DIGIC DV II Image Processor features improved continuous shooting of digital
photographs with the FS10. You can shoot five 1152 x 648 still images per second, and enjoy faster
processing of your images to both the FS11’s internal memory as well your memory card. It also helps
lower power consumption for longer battery life.

© 2008 Canon U.S.A., Inc. All rights reserved. Duplication in whole or in part without permission is prohibited. Page 7
2.7” Widescreen LCD
The 2.7” Hi-Res Widescreen LCD on the FS10 lets you see more of what your
camcorder is recording. There’s no need to imagine what your final image will look
like on your widescreen television because it’s squeezed into a small space while
you’re shooting. What you see will be what you get.

© 2008 Canon U.S.A., Inc. All rights reserved. Duplication in whole or in part without permission is prohibited. Page 8
Superb Shooting Control
Joystick Control
The Joystick makes using the camcorder easier than ever. Extra buttons
have been eliminated, allowing you to access many functions from one
convenient place. The Joystick lets you control Play, Stop, Fast Forward,
and Rewind functions during playback. It also controls exposure lock and
exposure compensation during recording.
Variable Zoom Speed Control
Another sure sign of amateur video is the unsteady zoom shot. But with the FS10’s zoom control, you
simply select one of three pre-set zoom speeds for smooth, steady, professional looking zooms.
Level and Grid Markers
With the Level Marker feature, it’s easy to keep your
camera level for more professional looking video.
Line up any horizontal lines in your shot -- such as
the horizon -- to the marker and you can be sure your
camcorder is level.
The FS10’s Grid Marker feature lets you compose your
shot accurately, according to the grid in your viewfinder.
You can even choose from two different colors for the
grid. This ensures that you see the grid, no matter what
the background color of your shot is.
Program AE Mode
For the best exposure for various situations, the FS10’s Program AE mode will
automatically adjust the settings to compensate for the conditions and subject.
Choose from Portrait, Sports, Night, Snow, Beach, Sunset, Spotlight and
Fireworks. You won’t have to guess if you’re capturing all the action just the way
you want it because the FS10 will do it for you.

© 2008 Canon U.S.A., Inc. All rights reserved. Duplication in whole or in part without permission is prohibited. Page 9
Quick Start
Never miss a quickly unfolding shot again. Push the Quick Start button between shots and it places
the FS10 in standby mode. When the action starts, push the Quick Start button again to begin
recording in less than one second. You’ll also help extend your battery life over leaving the camcorder
in regular recording mode.
Low Light Performance
Some of the most magical shots are taken at the end of the day or long after
the sun has set. You won’t miss any of them, thanks to the FS10’s mini video
light. The light lets you shoot subjects in color in low light up to 4.9 feet away.
So, whether it’s a shot of a sleeping baby, or a dramatic skyline at night, the
FS10 captures all the moments you want to record.
DVD Burner Compatible
You can also easily burn DVDs of the video shot with your FS10 as it is compatible with Canon’s new
DW-100 DVD Burner. A one cable connection is all it takes to send the files across and with the click
of a few buttons, your videos will be burned to a disc ready to play in a compatible DVD player.

© 2008 Canon U.S.A., Inc. All rights reserved. Duplication in whole or in part without permission is prohibited. Page 10
Stunning Digital Photography
The FS10 has many advanced photo features which make it
a camera that rivals other state-of-the-art digital cameras. You
get the best of both video and photos.
Megapixel Photos
The same Megapixel CCD that ensures sharp, vivid video also gives you
brilliant digital photographs. You will be able to capture outstanding digital
photographs with a resolution of 1152 x 684 for sharp, crisp still images.
Canon DIGIC DV II Image Processor
Canon’s exclusive DIGIC DV II Image Processor features improved
continuous shooting of digital photographs with the FS10. You can shoot
5 1152 x 684 still images per second, and enjoy faster processing of your
images to both the FS11’s internal memory as well as your memory card.
Focus Features
Auto Intelligent Auto Focus (AiAF) ensures sharp images and gives creative flexibility. Even when
your subject isn’t in the center of the frame, the FS10’s 9 Point AiAF will automatically select from 9
metering frames on the screen to help bring images into sharp focus.
Auto Exposure Modes
Like any good digital still camera, the FS10 lets you choose
from a range of exposure modes. Auto mode automatically
sets the exposure, letting you concentrate on your subject.
TV (shutter priority) mode lets you select the shutter speed
for sharp, action shots. In P (program) mode, the camcorder
adjusts camera settings automatically.

© 2008 Canon U.S.A., Inc. All rights reserved. Duplication in whole or in part without permission is prohibited. Page 11
Program AE Mode
Your life happens everywhere, so the FS10 gives you settings that
automatically result in the best exposure settings for different conditions and
different subjects.
Portrait mode ensures shallow depth of field for a pleasing background to
your shots of friends and family. Sports mode stops the action with faster
shutter speeds. Night mode is designed to give you great shots after the
sun goes down. Snow and Beach modes compensate for bright surroundings and give you the proper
exposure on your subject. Sunset mode results in vibrant, well-exposed colors for one of the toughest
subjects to capture. Use Spotlight mode when your child is on stage and in the spotlight -- literally
-- and you want to make sure the exposure is right for them. And, Fireworks mode records brilliant
images of another tough subject: the holiday fireworks display.
Level and Grid Markers
With the Level Marker feature, it’s easy to keep
your camera level for more professional looking
photographs. Line up any horizontal lines in your shot
-- such as the horizon -- to the marker and you can be
sure your camcorder is level.
The FS10’s Grid Marker feature lets you compose
your shot accurately, according to the grid in your
viewfinder. You can even choose from two different
colors for the grid. This ensures that you see the grid,
no matter what the background color of your shot is.

© 2008 Canon U.S.A., Inc. All rights reserved. Duplication in whole or in part without permission is prohibited. Page 12
Share Your Photos
Your FS10 comes with features that make it simple to share your still photos.
Print/Share
Print/Share turns your FS10 into a photo lab in the palm of your hand. Simply
connect your camcorder directly to select Canon printers or any PictBridge-
compatible printer with the supplied USB cable. Then, with a simple touch of
the Print/Share button, print directly from your FS10 without going through a
computer.
Print/Share also makes it easy to transfer your still images to your computer. Simply connect your
FS10 and your computer, press the Print/Share button and your photos are downloaded to your
computer.
SDHC Memory Card
The FS10 makes it easy to store digital photos onto an SDHC Memory Card.
DVD Burner Compatible
You can also easily burn DVDs of your still photos taken with your FS10 as it is compatible with
Canon’s new DW-100 DVD Burner. A one cable connection is all it takes to send the files across and
with the click of a few buttons, your photos are ready to share with all.

© 2008 Canon U.S.A., Inc. All rights reserved. Duplication in whole or in part without permission is prohibited. Page 13
Bundled Pixela ImageMixer Software
Enjoy the flexibility and versatility of your Canon Flash Memory camcorder with the supplied Pixela
ImageMixer software. This powerful software lets you organize, enhance, and share your video.
An easy-to-use application launcher makes it easy to transfer your video to your computer, burn
an AVCHD DVD or Standard Definition DVD. A sophisticated catalog system keeps all your videos
indexed and organized-so you can always find them quickly. Inside ImageMixer lives feature packed
video editing software, allowing you to trim, reorder, or combine scenes. To give your movies a
professional touch, simply add scene transitions, music, and titles. And when you’re finished, burn
an AVCHD DVD or Standard Definition DVD to relive the memories on your TV. A built-in video
player allows you to play your AVCHD or MPEG-2 data files on your computer. For added versatility,
Pixela ImageMixer can convert your movie to a file format compatible with web video sharing sites.
Additionally, your movie can be resized for online posting, and viewed on portable entertainment
devices.

© 2008 Canon U.S.A., Inc. All rights reserved. Duplication in whole or in part without permission is prohibited. Page 14
Additional Features
■The Intelligent Lithium-ion battery which powers the FS10 is a major,
and useful, advance. It not only more accurately tracks remaining
battery life, it also gives a display in minutes remaining. It will allow
you to better plan your shooting, so you won’t be caught out with a
battery that suddenly goes from “half” to “empty”.
■The Built-in Electronic Lens Cover means you never have to go looking for your lens cover again.
Turn your camcorder on and the lens cover automatically opens. Turn it off, and the cover closes.
■USB 2.0 Hi-Speed Terminal for digital video streaming and ultra-fast transfer of movies and
photos.
■With the FS10’s Microphone Terminal you can attach an external microphone if you need to record
audio more accurately from a specific source.
■Wireless Remote Control lets you operate your FS10 from a distance, so you
don’t have to be left out of the picture.
■1 Year Parts And Labor Limited Warranty provides protection long after other
manufacturers’ warranties expire.

© 2008 Canon U.S.A., Inc. All rights reserved. Duplication in whole or in part without permission is prohibited. Page 15
Specifications
Digital Video
Power Consumption TBA
Image Sensor 1/6” CCD Sensor
Total Pixels Approx. 1,070,000 pixels
Effective Pixels Movies:
16:9 - approx. 550,000 pixels (ADV.Z off)
16:9 - approx. 710,000 pixels (ADV.Z on, wide)
16:9 - approx. 410,000 pixels (ADV.Z on tele)
Photos: approx. 800,000 pixels
Maximum recording time 8GB Internal Flash Drive:
LP (3 Mbps): 5 hours, 10 minutes
SP (6 Mbps): 2 hours, 45 minutes
XP (9 Mbps): 1 hour, 50 minutes
Greater capacity is possible by adding an SDHC Memory Card.
Lens Zoom Ratio 48 Advanced Zoom (16:9 mode)
37x Optical/2000x Digital
Focal Length f=2.6-96.2mm
Zoom Speed Variable/3 Fixed Zoom Speeds
Max. F/Stop f/2.0-5.2
Programmed AE Auto, Program, Tv, Portrait, Sports, Night, Snow, Beach, Sunset, Spotlight,
Fireworks
Max Shutter Speed 1/2000
1/500 (card)
Minimum Focusing Distance 10 mm (wide)/1m (tele)
White Balance Daylight, Tungsten, Auto, Manual
Image Stabilization Electronic
LCD Screen 2.7” Widescreen LCD (Approx. 123,000 pixels)
Recording Media Internal Flash Memory (8GB) or SD/SDHC Memory Card
Audio Dolby Digital 2ch (AC-3 2 ch)
Microphone Terminal 3.5 mm Stereo Mini-jack
Dimensions (WxHxD) 2.3 x 2.4 x 4.9 in/58 x 60 x 124mm
Weight (not including lens and
battery pack)
9.2 oz. (260g)
Note: A Class 2 or higher card is recommended. Also, movie recording requires cards with 128 MB of memory or more.
Cards made by Toshiba, SanDisk or Matsushita are recommended. No particular restrictions apply for still images.

© 2008 Canon U.S.A., Inc. All rights reserved. Duplication in whole or in part without permission is prohibited. Page 16
Supplies & Accessories
STV-250N Mini Plug to RCA
Used to connect to a TV or VCR.
Battery Charger CG-800
Charges Li-Ion Battery 800 Series
Shoulder Strap SS-600
SC-A30 Genuine Leather Carrying Case
Once you finish recording, keep your camcorder and all your accessories in this professional-looking,
genuine leather soft carrying case.
SC-A40 Genuine Leather Carrying Case
Once you finish recording, keep your camcorder and all your accessories in this professional-looking,
genuine leather soft carrying case.
SC-A60 Genuine Leather Carrying Case
Once you finish recording, keep your camcorder and all your accessories in this professional-looking,
genuine leather soft carrying case.
Soft Case SC-A70
Battery Pack BP-808
890mAh Lithium Ion
DW-100
DVD Burner and Player - Key to enjoying the superb video produced by the latest Canon High
Definition and Standard Definition camcorders is sharing that video with family and friends. Now, it’s
easier than ever to transfer and backup footage from your camcorder onto DVDs with the Canon DW-
100 DVD Burner.
Can’t find the part or accessory you’re looking for? Customer Support can help.
Call 1-800-828-4040 for assistance.

© 2008 Canon U.S.A., Inc. All rights reserved. Duplication in whole or in part without permission is prohibited. Page 17
What’s in the Box
FS10 Kit Contents:
1. FS10 Camcorder
2. WL-D88 Wireless Controller
3. CR2025 Lithium Coin Battery
4. BP-808 Battery Pack
5. CA-590 Compact Power Adapter
6. AC Cable
7. Interface Cable
8. STV-250N Stereo Video Cable
9. WS-30 Wrist Strap
10.Pixela ImageMixer™ 3SE Disc
11. Digital Video Solutions Disc for Windows
and Macintosh
