Canon Kh16ex5.7 irse User manual

F-Number

2/3” Lens

KJ20x8.5B LO32BMT

Zoom Ratio: 20x

Wide Focal Length: 8.5mm

F-Stop: F1.8

1/2” HD Lens

KH20x6.4

Zoom Ratio: 20x

Wide Focal Length: 6.4mm

F-Stop: F1.4

2/3” HD Lens

KJ20x8.5B with LO-32BMT

Zoom Ratio: 20x

Wide Focal Length: 8.5mm

F-Stop: F1.8

1/2”

Lens

Since neither the focal length nor the effective aperture has changed, the F-number remains the same,

F1.8. Thus, there is no optical sensitivity “loss” involved when using a 2/3” native lens with the LO-32BMT

on a 1/2” camera. As a comparison, if instead of using the 2/3”KJ20x8.5B lens and LO-32BMT adapter,

you were to substitute a 1/2” KH20x6.4 HDTV lens, the adapter would no long be necessary. By applying

the same formula, F-Number = f/D, to the 1/2” KH20x6.4 lens, the lens will have a faster F-Number, F1.4,

compared to the 2/3” lens and LO-32BMT combination.

Focal Length

When using a 2/3” lens with a LO-32BMT adapter mounted to a 1/2” camera, the actual focal length

of the lens does not change. However, the angle of view associated with that focal length changes.

In this case, the lens will visually be more telephoto, by a factor of 1.38x. As an example, the 2/3”

KJ20x8.5B HDTV lens (58.90angle of view at 8.5mm when mounted on a 2/3” camera) will visually

appear to have a 44.60angle of view, that equates to an equivalent focal length of 11.7mm

(8.5mm x 1.38 = 11.7mm)

The actual F-Number of a lens does not change when mounted on a different format size camera.

Using the 2/3” KJ20x8.5B HDTV lens as an example, its maximum aperture is F1.8. When that lens is

mounted on the 1/2” camera with the LO-32BMT adapter, the focal length and effective aperture of

the lens do not change.

The Canon LO-32BMT adapter allows you to mount a 2/3” B4bayonet lens onto

any Sony 1/2” proprietary mount camera such as the new XDCAM HD series,

PDW-F330/F350 while not affecting the optical quality of the lens. It is important to consider

the following information when using a 2/3” lens with a LO-32BMT adapter mounted to a 1/2” camera.

2/3” HD Lens

KJ20x8.5B Focal Length

at Wide Angle

8.5mm

2/3” HD Camera

Angle of View

58.90

1/2” HD Camera

Angle of View

with LO-32BMT

44.60

Visual Equivalent

Angle of View

in 2/3”

11.7mm

The formula for deriving the F-Number of any lens is as follows:

F-Number = f / D f = Focal Length D = Effective Aperture

Canon’s New HDgc Lenses

for Sony’s XDCAM HD

Canon USA Inc.

Broadcast and Communications Division

65 Challenger Road, Ridgefield Park, NJ 07660

1-201-807-3300 / 1-800-321-4388

[email protected]

www.canonbroadcast.com

1. The images produced will appear visually more telephoto by a factor of 1.38x.

2. The actual F-Number of a lens does not change when mounted on a different format size camera.

If the lens is F1.9 in the 2/3” format, the lens is also F1.9 in the 1/2” format.

3. The Focal Length and F-Stop markings on the 2/3” lens are correct in either format.

4. It is highly recommended that HDTV lenses always be employed on HDTV cameras.

The Canon LO-32BMT

The 2/3” KJ20x8.5B lens

with LO-32BMT as compared

to the 1/2” KH20x6.4 lens.

2/3” HD Camera Angle of View

58.90

1/2” HD Camera Angle of View

with LO-32BMT

44.60

Specifications subject to change without notice. Errors and omissions excepted.

Weight and dimensions are approximate.

CNB3000-00609-78
