Canon IXUS 115 HS User manual

Camera User Guide
ENGLISH
• Make sure you read this guide, including the “Safety
Precautions” section, before using the camera.
• Reading this guide will help you learn to use the camera
properly.
• Store this guide safely so that you can use it in the future.
COPY

2
Check if the following items are included in your camera package.
If anything is missing, contact the retailer where you purchased the camera.
Using the PDF Manuals
The following PDF manuals are included in the Readme folder of the CD-ROM:
When the software is installed on your computer, the PDF manuals will be copied to
the computer and you can refer to them by clicking the shortcuts on the desktop.
•Camera User Guide (This Guide)
Once you have mastered the basics, use the camera’s many
features to shoot more challenging photos.
•Software Guide
Read when you want to use the included software.
•A memory card is not included.
•Adobe Reader is required to view the PDF manuals.
Checking the Package Contents
Battery Charger
CB-2LV/CB-2LVE
Camera Battery Pack NB-4L
(with Terminal Cover)
AV Cable
AVC-DC400
Interface Cable
IFC-400PCU
Wrist Strap
WS-DC11
Warranty
Card
Getting Started
DIGITAL CAMERA
Solution Disk
COPY

3
Test Shots and Disclaimer
Take some initial test shots and play them back to make sure the images
were recorded correctly. Please note that Canon Inc., its subsidiaries and
affiliates, and its distributors are not liable for any consequential damages
arising from any malfunction of a camera or accessory, including memory
cards, that results in the failure of an image to be recorded or to be recorded
in a way that is machine readable.
Warning Against Copyright Infringement
The images recorded with this camera are intended for personal use. Do not
record images that infringe upon copyright laws without the prior permission
of the copyright holder. Please be advised that in certain cases the copying
of images from performances, exhibitions, or commercial properties by
means of a camera or other device may contravene copyright or other legal
rights even if the image was shot for personal use.
Warranty Limitations
This camera’s warranty is only effective in the country of sale. If there is a
problem with the camera while abroad, please return it to the country of sale
before proceeding with a warranty claim to a Canon Customer Support Help
Desk. For Canon Customer Support contacts, please see the customer
support list supplied with your camera.
LCD Monitor (Screen)
•The LCD monitor is produced with extremely high-precision manufacturing
techniques. More than 99.99% of the pixels operate to specification, but
occasionally non-performing pixels may appear as bright or dark dots. This
is not a malfunction and has no effect on the recorded image.
•The LCD monitor may be covered with a thin plastic film for protection
against scratches during shipment. If so, remove the film before using the
camera.
Camera Body Temperature
Please take care when operating the camera for an extended period as the
camera body may become warm. This is not a malfunction.
Read This First
COPY

4
What Do You Want to Do?
4
zShoot, leaving it to the camera to make settings .........................24
O tS
Take good people shots
Shoot various other scenes
Shoot with special effects
IwP V
Portraits
(p. 64)
Facial expressions
(p. 81)
Kids and pets
(p. 64)
At the beach
(p. 65)
Against snow
(p. 66)
NightScene
(p. 65)
Underwater
(p. 65)
Low Light
(p. 65)
Foliage
(p. 65)
Fireworks
(p. 66)
Fish-eye Effect
(p. 69)
Toy Camera Effect
(p. 74)
Miniature Effect
(p. 70)
Monochrome
(p. 73)
Super vivid colors
(p. 68)
Poster Effect
(p. 68)
Shoot
z Focus on faces ..................................................................24, 65, 95
zShoot in places where I cannot use the flash
(turn off the flash) .........................................................................54
zTake pictures with me in them too (self-timer) .................58, 59, 77
zInsert the date and time into my shots .........................................57
zTake a picture while shooting a movie .........................................67
COPY

What Do You Want to Do?
5
1
zLook at my pictures ......................................................................27
zAutomatically play back pictures (slideshow).............................122
zLook at my pictures on a TV ......................................................130
zLook at my pictures on a computer. .............................................32
zQuickly search pictures ..............................................................118
zErase pictures ......................................................................28, 138
View
E
zShoot movies .......................................................................29, 107
zView movies .................................................................................31
zShoot fast moving subjects and play them back
in slow motion ............................................................................110
Shoot/View Movies
2
zEasily print pictures ....................................................................152
Print
zSave images to a computer .........................................................32
Save
3
zTurn off sounds ............................................................................48
zUse the camera abroad........................................................15, 171
zUnderstand what is displayed on the screen .............................186
Other
COPY

6
Chapters 1 – 3 explain the basic operations and frequently used functions of
this camera. Chapters 4 onward explain the advanced functions, letting you
learn more as you read each chapter.
Checking the Package Contents .......2
Read This First ..................................3
What Do You Want to Do? ................4
Table of Contents ..............................6
Conventions Used in This Guide .......9
Safety Precautions...........................10
Charging the Battery........................14
Compatible Memory Cards
(Sold Separately)...........................16
Inserting the Battery and
Memory Card.................................16
Setting the Date and Time ...............19
Setting the Display Language..........21
Formatting Memory Cards ...............22
Pressing the Shutter Button.............23
Taking Pictures (Smart Auto)...........24
Viewing Images ...............................27
Erasing Images................................28
Shooting Movies ..............................29
Viewing Movies................................31
Transferring Images to
a Computer for Viewing .................32
Accessories .....................................37
Separately Sold Accessories ...........38
Components Guide..........................42
Screen Display.................................44
Indicator ...........................................45
FUNC. Menu – Basic Operations ....46
MENU – Basic Operations...............47
Changing the Sound Settings ......... 48
Adjusting the Screen Brightness ..... 50
Returning the Camera to Default
Settings ......................................... 51
Power Saving Function
(Auto Power Down)....................... 52
Clock Functions............................... 52
Turning the Flash Off ...................... 54
Zooming in More Closely on
Subjects (Digital Zoom)................. 55
Inserting the Date and Time............ 57
Using the Self-Timer ....................... 58
Changing the Recording Pixel
Setting (Image Size) ..................... 61
Changing the Compression Ratio
(Image Quality) ............................. 61
Shooting in Various Conditions ....... 64
Making Short Movies Automatically
(Movie Digest) ............................... 67
Adding Effects and Shooting........... 68
Detecting a Face and Shooting
(Smart Shutter) ............................. 75
Shooting Long Exposures............... 79
High-Speed Continuous Shooting
(High-speed Burst)........................ 80
Capturing the Best Facial
Expressions (Best Image
Selection) ...................................... 81
Table of Contents
1 Getting Started................... 13
2 Learning More.................... 41
3 Shooting with Commonly
Used Functions ..................53
4 Adding Effects and Shooting
in Various Conditions........63
COPY

Table of Contents
7
Shooting Stitch Assist Images ........ 82
Shooting in Program AE ................. 84
Adjusting the Brightness
(Exposure Compensation) ............ 85
Turning the Flash On ...................... 85
Adjusting the White Balance ........... 86
Changing the ISO Speed................ 88
Correcting the Brightness and
Shooting (i-Contrast)..................... 89
Changing the Aspect Ratio ............. 90
Continuous Shooting....................... 91
Changing the Tone of an Image
(My Colors) ................................... 92
Shooting Close-ups (Macro) ........... 94
Shooting Far Away Subjects
(Infinity) ......................................... 94
Changing the AF Frame Mode........ 95
Choosing the Subject to
Focus On (Tracking AF) ............... 97
Magnifying the Focal Point.............. 98
Shooting with the AF Lock .............. 99
Shooting with Servo AF ................ 100
Changing the Metering Method..... 101
Shooting with the AE Lock............ 102
Shooting with the FE Lock ............ 102
Shooting with Slow Synchro ......... 103
Red-Eye Correction ...................... 104
Checking for Shut Eyes ................ 105
Shooting Using a TV
as the Display ............................. 105
Shooting Various Kinds of
Movies ........................................ 108
Shoot Movies That Look Like a
Miniature Model (Miniature
Effect) .......................................... 109
Shooting Super Slow Motion
Movies ......................................... 110
Changing the Image Quality.......... 112
Other Shooting Functions.............. 113
Editing ........................................... 114
Quickly Searching Images............. 118
Viewing Images in Filtered
Playback...................................... 120
Viewing Slideshows....................... 122
Checking the Focus....................... 124
Magnifying Images ........................ 125
Viewing Each Image in a Group.... 126
Displaying Various Images
(Smart Shuffle) ............................ 128
Changing Image Transitions .........129
Viewing Images on a TV ............... 130
Protecting Images ......................... 134
Erasing All Images ........................ 138
Tagging Images as Favorites........ 140
Organizing Images by Category
(My Category) ............................. 142
Rotating Images ............................ 145
Resizing Images............................ 146
Trimming ....................................... 147
Adding Effects with the My Colors
Function ...................................... 148
Correcting the Brightness
(i-Contrast) .................................. 149
Correcting the Red-Eye Effect.......150
Printing Images ............................. 152
5 Choosing Settings
Yourself...............................83
6 Using Various Functions for
Shooting Movies ..............107
7 Using Various Playback and
Editing Functions............ 117
8 Printing............................. 151
COPY

Table of Contents
8
Choosing Images for Printing
(DPOF) ........................................159
Changing Camera Settings............166
Changing Shooting Function
Settings........................................173
Changing Playback Function
Settings........................................176
Using Household Power ................178
Using an Eye-Fi Card.................... 179
Troubleshooting ............................ 181
List of Messages That Appear
on the Screen.............................. 184
Information Displayed
on the Screen.............................. 186
Functions Available in Each
Shooting Mode............................ 190
Menus ........................................... 196
Playback Mode FUNC. Menu........ 200
Handling Precautions .................... 201
Specifications ................................ 202
Index ............................................. 206
9 Customizing Camera
Settings ............................ 165
10Useful Information........... 177
COPY

9
•Icons are used in the text to represent the camera buttons and switches.
•Language that displays on the screen appears inside [ ] (square brackets).
•The directional buttons and FUNC./SET button are represented by the
following icons.
•: Things you should be careful about
•: Troubleshooting tips
•: Hints for getting more out of your camera
•: Supplemental information
•(p. xx): Reference pages (“xx” stands for a page number)
•This guide assumes all functions are at their default settings.
•The various types of memory cards that can be used in this camera are
collectively referred to as memory cards in this guide.
Conventions Used in This Guide
Right button
FUNC./SET button
Up button
Left button
Down button
COPY

10
•Before using the product, please ensure that you read the safety precautions described
below. Always ensure that the product is used correctly.
•The safety precautions noted on the following pages are intended to prevent injuries to
yourself and other persons, or damage to the equipment.
•Be sure to also check the guides included with any separately sold accessories you
use.
Warning Denotes the possibility of serious injury or death.
•Do not trigger the flash in close proximity to people’s eyes.
Exposure to the intense light produced by the flash could damage eyesight. In particular,
remain at least one meter (39 inches) away from infants when using the flash.
•Store this equipment out of the reach of children and infants.
Strap: Putting the strap around a child’s neck could result in asphyxiation.
•Use only recommended power sources.
•Do not attempt to disassemble, alter or apply heat to the product.
•Avoid dropping or subjecting the product to severe impacts.
•To avoid the risk of injury, do not touch the interior of the product if it has been
dropped or otherwise damaged.
•Stop using the product immediately if it emits smoke, a strange smell, or
otherwise behaves abnormally.
•Do not use organic solvents such as alcohol, benzine, or thinner to clean the
equipment.
•Do not let the product come into contact with water (e.g. sea water) or other
liquids.
•Do not allow liquids or foreign objects to enter the camera.
This could result in electrical shock or fire.
If liquids or foreign objects come into contact with the camera interior, immediately turn
the camera power off and remove the battery.
If the battery charger becomes wet, unplug it from the outlet and consult your camera
distributor or a Canon Customer Support Help Desk.
•Use only the recommended battery.
•Do not place the battery near or in direct flame.
•Unplug the power cord periodically, and using a dry cloth, wipe away any dust
and dirt that has collected on the plug, the exterior of the power outlet, and the
surrounding area.
•Do not handle the power cord with wet hands.
•Do not use the equipment in a manner that exceeds the rated capacity of the
electrical outlet or wiring accessories. Do not use if the power cord or plug are
damaged, or not fully plugged into the outlet.
•Do not allow dirt or metal objects (such as pins or keys) to contact the terminals
or plug.
The battery may explode or leak, resulting in electrical shock or fire. This could cause
injury and damage the surroundings. In the event that a battery leaks and the battery acid
contacts eyes, mouth, skin or clothing, immediately flush with water.
Safety Precautions
COPY

Safety Precautions
11
•Turn the camera off in places where camera use is prohibited.
The electromagnetic waves emitted by the camera may interfere with the operation of
electronic instruments and other devices. Exercise adequate caution when using the
camera in places where use of electronic devices is restricted, such as inside airplanes
and medical facilities.
•Do not play the supplied CD-ROM(s) in any CD player that does not support data
CD-ROMs.
It is possible to suffer hearing loss from listening with headphones to the loud sounds of
a CD-ROM played on a music CD player. Additionally, playing the CD-ROM(s) in an audio
CD player (music player) could damage the speakers.
Caution Denotes the possibility of injury.
•Be careful not to bang the camera or subject it to strong impacts or shocks when
hanging it by the strap.
•Be careful not to bump or push strongly on the lens.
This could lead to injury or damage the camera.
•Be careful not to subject the screen to strong impacts.
If the screen cracks, injury may result from the broken fragments.
•When using the flash, be careful not to cover it with your fingers or clothing.
This could result in burns or damage to the flash.
•Avoid using, placing or storing the product in the following places:
- Places subject to strong sunlight
- Places subject to temperatures above 40 °C (104 °F)
- Humid or dusty areas
These could cause leakage, overheating or an explosion of the battery, resulting in
electrical shock, fire, burns or other injuries.
High temperatures may cause deformation of the camera or battery charger casing.
•The slideshow transition effects may cause discomfort when viewed for
prolonged periods.
Caution Denotes the possibility of damage to the equipment.
•Do not aim the camera at bright light sources (such as the sun on a clear day).
Doing so may damage the image sensor.
•When using the camera on a beach or at a windy location, be careful not to allow
dust or sand to enter the camera.
This may cause the product to malfunction.
COPY

Safety Precautions
12
•In regular use, small amounts of smoke may be emitted from the flash.
This is due to the high intensity of the flash burning dust and foreign materials stuck to the
front of the unit. Please use a cotton swab to remove dirt, dust or other foreign matter from
the flash to prevent heat build-up and damage to the unit.
•Remove and store the battery when you are not using the camera.
If the battery is left inside the camera, damage caused by leakage may occur.
•Before you discard the battery, cover the terminals with tape or other insulators.
Contacting other metal materials may lead to fire or explosions.
•Unplug the battery charger from the power outlet after charging is complete, or
when you are not using it.
•Do not place anything, such as cloth on top of the battery charger while it is
charging.
Leaving the unit plugged in for a long period of time may cause it to overheat and distort,
resulting in fire.
•Do not place the battery near pets.
Pets biting the battery could cause leakage, overheating or explosion, resulting in fire or
damage.
•Do not sit down with the camera in your pocket.
Doing so may cause malfunctions or damage the screen.
•When putting the camera in your bag, ensure that hard objects do not come into
contact with the screen.
•Do not attach any hard objects to the camera.
Doing so may cause malfunctions or damage the screen.
COPY

13
Getting Started
This chapter explains preparations before shooting, how to shoot in
Amode, and then how to view and erase the images you take. The
latter part of this chapter explains how to shoot and view movies and
transfer images to a computer.
Attaching the Strap/Holding the Camera
•Attach the included strap and wrap it around your wrist to avoid dropping
the camera during use.
•Keep your arms tight against your body while holding the camera firmly by
the sides when shooting. Be sure that your fingers do not block the flash.
1
Strap
COPY

14
Use the included charger to charge the battery. Be sure to charge the battery
as it is not charged at the time of purchase.
Remove the cover.
Insert the battery.
zAlign the omarks on the battery and
charger, then insert the battery by sliding it
in ( ) and down ( ).
Charge the battery.
zFor CB-2LV: Flip out the plug ( ) and
plug the charger into a power outlet ( ).
zFor CB-2LVE: Plug the power cord into
the charger, then plug the other end into a
power outlet.
XThe charge lamp lights orange and
charging starts.
XThe charge lamp will light green when
charging has finished. Charging takes
approx. 1 hour and 30 minutes.
Remove the battery.
zUnplug the battery charger from the power
outlet, then remove the battery by sliding it
in ( ) and up ( ).
Charging the Battery
CB-2LV
CB-2LVE
To protect the battery and prolong its life, do not charge it for longer than
24 hours continuously.
COPY

Charging the Battery
15
Number of Possible Shots
•The number of shots that can be taken is based on the Camera & Imaging Products
Association (CIPA) measurement standard.
•Under some shooting conditions, the number of shots that can be taken may be less
than mentioned above.
Battery Charge Indicator
An icon or message will appear on the screen indicating the battery’s charge
state.
Number of Shots Approx. 230
Playback Time Approx. 5 hours
Display Summary
Sufficient charge.
Slightly depleted, but sufficient.
(Blinking red) Nearly depleted. Charge the battery.
“Change the battery pack.” Depleted. Recharge the battery.
Using the battery and charger effectively
•Charge the battery on the day, or the day before, it will be used.
Charged batteries continue to discharge naturally even if they are not used.
•How to store the battery for long periods:
Deplete and remove the battery from the camera. Attach the terminal cover and
store the battery. Storing a battery for long periods of time (about a year) without
depleting it may shorten its life span or affect its performance.
•The battery charger can also be used when abroad.
The charger can be used in regions that have 100 – 240 V (50/60 Hz) AC power.
If the plug does not fit the outlet, use a commercially available plug adapter. Do
not use electrical transformers for foreign travel as they will cause damage.
•The battery may develop a bulge.
This is a normal characteristic of the battery and does not indicate a problem.
However, if the battery bulges to the point where it will no longer fit into the
camera, please contact a Canon Customer Support Help Desk.
•If the battery is quickly depleted even after charging, it has reached the end of
its life span. Purchase a new battery.
Attach the cover to a charged battery so that
the omark is visible.
COPY

16
The cards below can be used without restrictions on their capacities.
•SD memory cards*
•SDHC memory cards*
•SDXC memory cards *
•MultiMediaCards
•MMCplus memory cards
•HC MMCplus memory cards
•Eye-Fi Cards
* This memory card complies with the SD standards. Some cards may not operate
properly depending on the brand of card used.
About Eye-Fi Cards
This product is not guaranteed to support Eye-Fi card functions (including
wireless transfer). In case of an issue with an Eye-Fi card, please check with
the card manufacturer.
Also note that an approval is required to use Eye-Fi cards in many countries
or regions. Without approval, use of the card is not permitted. If it is unclear
whether the card has been approved for use in the area, please check with
the card manufacturer.
Insert the included battery and a memory card (sold separately).
Check the card’s write-protect tab.
zIf the memory card has a write-protect tab,
you will not be able to record images if the
tab is in the locked position. Slide the tab
up until you hear a click.
Open the cover.
zSlide the cover ( ) and open it ( ).
Depending on your computer’s OS version, SDXC memory cards may not
be recognized even when using a commercially available card reader.
Check to make sure that your OS supports SDXC memory cards
beforehand.
Compatible Memory Cards (Sold Separately)
Inserting the Battery and Memory Card
COPY

Inserting the Battery and Memory Card
17
Insert the battery.
zPress the battery lock in the direction of the
arrow, then insert the battery as shown
until it locks into place with a click.
zBe sure to insert the battery in the correct
direction or it will not properly lock into
place.
Insert the memory card.
zInsert the memory card as shown until it
locks into place with a click.
zBe sure the memory card is oriented
correctly. Inserting the memory card in the
wrong direction could damage the camera.
Close the cover.
zClose the cover ( ), and press downward
as you slide it until it clicks into place ( ).
Terminals Battery
lock
Terminals
What if [Memory card locked] appears on the screen?
SD, SDHC, SDXC memory cards, and Eye-Fi cards have a write-protect tab. If
this tab is in the locked position, [Memory card locked] will appear on the screen
and you will not be able to take or erase images.
COPY

Inserting the Battery and Memory Card
18
Removing the Battery and Memory Card
Remove the battery.
zOpen the cover and press the battery lock
in the direction of the arrow.
XThe battery will pop up.
Remove the memory card.
zPush the memory card in until you hear a
click, then slowly release it.
XThe memory card will pop up.
Number of Shots per Memory Card
•Values are based on the default settings.
•The number of shots that can be taken will vary depending on camera settings, the
subject and the memory card used.
Memory Card 4 GB 16 GB
Number of Shots Approx. 1231 Approx. 5042
Can you check the number of shots that can be taken?
You can check the number of shots that can be taken when the camera is in a
Shooting mode (p. 24).
Number of shots that can be taken
COPY

19
The Date/Time settings screen will appear the first time the camera is turned
on. Since the dates and times recorded into your images are based on these
settings, be sure to set them.
Turn on the camera.
zPress the power button.
XThe Date/Time screen will appear.
Set the date and time.
zPress the qr buttons to choose an option.
zPress the op buttons to set a value.
Complete the setting.
zPress the mbutton.
XOnce the date and time have been set, the
Date/Time screen will close.
zPressing the power button will turn off the
camera.
Setting the Date and Time
Reappearing Date/Time screen
Set the correct date and time. If you have not set the date and time, the Date/Time
screen will appear each time you turn on the camera.
Daylight saving time settings
If you choose in Step 2 and press the op buttons to choose , you will set
the time to daylight saving (1 hour ahead).
COPY

Setting the Date and Time
20
Changing the Date and Time
You can change the current date and time settings.
Display the menu.
zPress the nbutton.
Choose [Date/Time].
zMove the zoom lever to choose the 3tab.
zPress the op buttons to choose [Date/
Time], then press the mbutton.
Change the date and time.
zFollow Steps 2 and 3 on p. 19 to adjust the
setting.
zPress the nbutton to close the menu.
Date/Time battery
•The camera has a built-in date/time battery (backup battery) that allows the
date/time settings to be retained for about three weeks after the battery pack
has been removed.
•By inserting a charged battery or connecting an AC adapter kit (sold separately,
p. 38) the date/time battery can be charged in about 4 hours even if the camera
is not turned on.
•If the date/time battery is depleted, the Date/Time screen will appear when you
turn the camera on. Follow the steps on p. 19 to set the date and time.
COPY
