Canon PowerShot SD100 User manual

CDI-E084-010 XX02XXX © 2003 CANON INC. PRINTED IN JAPAN
DIGITAL CAMERA Camera User Guide
Camera User Guide
ENGLISH
Please read the Read This First section (p. 7).
Please refer to the Software Starter Guide for information on
installing the software and downloading images.
Please also read the printer user guide included with your Canon
printer.

Flowchart and Reference Guides
This digital camera is designed to perform optimally when used with
genuine Canon-brand digital camera accessories (“Canon Brand
Accessories”).
You may use non-Canon brand accessories with this digital camera.
However, Canon makes no warranties concerning, and is not
responsible for damages resulting from, use of non-Canon brand
accessories.

1
Camera Body Temperature
If your camera is used for prolonged periods, the camera body may become
warm. Please be aware of this and take care when operating the camera for
an extended period.
About the LCD Monitor
The LCD monitor is produced with extremely high-precision manufacturing
techniques. More than 99.99% of the pixels operate to specification. Less
than 0.01% of the pixels may occasionally misfire or appear as red or black
dots. This has no effect on the recorded image and does not constitute a
malfunction.
Video Format
Please set the camera’s video signal format to the one used in your region
before using it with a TV monitor (p. 146).
Charging the Date/Time Battery
• The camera has a built-in rechargeable lithium battery that maintains the
date, time and other camera settings. This battery recharges when the
main battery pack is inserted into the camera. When you first purchase the
camera, place a charged battery pack in it or use the AC adapter kit (sold
separately) for at least 4 hours to charge the date/time battery. It will
charge even when the camera power is set to Off.
• If the Date/Time menu appears when the camera power is turned on, it
means that the date/time battery charge is depleted. Recharge it as
described above.

2
About This Guide
Conventions Used in the Text
Question? Look Here First
How do I navigate the menus?
See Selecting Menus and Settings (p. 44).
What settings are available under each function?
and
Will my settings remain in effect even after I’ve turned the camera off?
See Functions Available in Each Shooting Mode (p. 188).
How do I go about printing?
See About Printing (p. 116).
What functions are available through the menu?
See FUNC. Menu (p. 148).
See Rec. Menu (p. 150).
See Play Menu (p. 152).
See Set up Menu (p. 154).
See My Camera Menu (p. 158).
In this guide SD memory card (Secure Digital, a copyright protection
system) is referred to as SD card.
Icons on the right end of title bars show the applicable operating modes.
As in the example below, the procedure can be performed in (Auto),
(Manual), (Manual/Stitch Assist) or (Movie) mode.
: This mark denotes issues that may affect the camera’s operation.
: This mark denotes additional topics that complement the basic
operating procedures.
Using the Self-timer

3
Thumb Index
Quick Start 14
Preparing the Camera 16
Basic Functions 32
Shooting 58
Replaying 93
Erasing 113
Printing/Image Transfer Settings 116
Connecting the Camera to a Computer/TV 142
Lists of Menu Options and Messages 148
Appendices 166
Troubleshooting 168
Specifications 172

4
Table of Contents
Items marked with are lists or charts that summarize camera functions or
procedures.
Read This First .................................................. 7
Please Read ..........................................................................................7
Safety Precautions................................................................................8
Preventing Malfunctions.....................................................................13
Quick Start ......................................................14
Components Guide ............................................16
Preparing the Camera .........................................21
Charging the Battery Pack ..................................................................21
Installing the Battery Pack ..................................................................23
Installing the SD Card.........................................................................25
Setting the Date and Time...................................................................28
Setting the Language..........................................................................30
Basic Functions.................................................32
Turning the Power On/Off...................................................................32
Using the LCD Monitor .......................................................................34
Information Displayed on the LCD Monitor ........................................36
Using the Viewfinder...........................................................................40
Using the Zoom ..................................................................................41
Pressing the Shutter Button................................................................42
Selecting Menus and Settings ............................................................44
Customizing the Camera (My Camera Settings)...........53
Changing My Camera Settings............................................................53
Registering My Camera Settings ........................................................55
Shooting .........................................................58
Shooting in Auto Mode.......................................................................58
Reviewing an Image Right after Shooting...........................................60
Changing Resolution/Compression Settings.......................................61
Using the Flash..............................................................................63
/ Shooting Close-Ups/Infinity Shots..........................................65
Using the Digital Zoom .......................................................................67
Continuous Shooting ....................................................................68
Using the Self-timer......................................................................69
Shooting in Manual Mode...................................................................70

5
Shooting a Movie ............................................................................... 71
Shooting in Stitch Assist .................................................................... 73
Locking the Focus (AF Lock) .............................................................. 76
Locking the Exposure Setting (AE Lock) ............................................ 78
Locking the Flash Exposure Setting (FE Lock).................................... 79
Switching between Autofocus Modes ................................................ 80
Switching between Light Metering Modes.................................... 81
Adjusting the Exposure Compensation............................................... 82
Shooting in Long Shutter Mode ......................................................... 83
Setting the White Balance .................................................................. 85
Changing the Photo Effect.................................................................. 88
Adjusting the ISO Speed .................................................................... 89
Setting the Auto Rotate Function........................................................ 90
Resetting the File Number .................................................................. 91
Replaying ..................................................... 93
Displaying Images Individually........................................................... 93
Magnifying Images....................................................................... 94
Viewing Images in Sets of Nine (Index Replay)............................ 95
Viewing Movies .................................................................................. 97
Editing Movies.................................................................................. 100
Rotating Images in the Display......................................................... 102
Attaching Sound Memos to Images ................................................. 104
Automated Playback (Slide Shows).................................................. 107
Protecting Images ............................................................................ 112
Erasing ......................................................... 113
Erasing Single Images................................................................ 113
Erasing All Images ........................................................................... 114
Formatting SD Cards........................................................................ 115
Printing ........................................................ 116
About Printing .................................................................................. 116
Connecting a Printer......................................................................... 120
Printing ............................................................................................ 124
Setting the Print Settings (Direct Print Function) ............................. 126
Setting the DPOF Print Settings ....................................................... 131
Image Transmission Settings (DPOF Transfer Order) .. 140
Selecting Images for Transferring .................................................... 140

6
Downloading Images to a Computer ...................... 142
Connecting the Camera to a Computer via the USB cable.................142
Downloading Directly from an SD Card ............................................145
Shooting/Replaying with a TV .............................. 146
Lists of Menu Options and Messages ..................... 148
FUNC. Menu .....................................................................................148
Rec. Menu ........................................................................................150
Play Menu.........................................................................................152
Set up Menu .....................................................................................154
My Camera Menu .............................................................................158
Resetting Settings to Their Default Values........................................161
List of Messages...............................................................................162
Appendices.................................................... 166
Using an AC Adapter Kit (Sold Separately) .......................................166
Camera Care and Maintenance .........................................................167
Troubleshooting .............................................. 168
Specifications................................................. 172
Index ........................................................... 179
Functions Available in Each Shooting Mode ............. 188

7
Read This First
Test Shots
Before you try to photograph important subjects, we highly recommend that
you shoot several trial images to confirm that the camera is operating and
being operated correctly.
Please note that Canon, its subsidiaries and affiliates, and its distributors
are not liable for any consequential damages arising from any malfunction
of a camera or accessory, including SD memory cards, that results in the
failure of an image to be recorded or to be recorded in a format that is
machine readable.
Warning Against Copyright Infringement
Please note that Canon digital cameras are intended for personal use and
should never be used in a manner that infringes upon or contravenes
international or domestic copyright laws and regulations. Please be advised
that in certain cases the copying of images from performances, exhibitions,
or commercial properties by means of a camera or other device may
contravene copyright or other legal rights even if the image was shot for
personal use.
Warranty Limitations
This camera’s warranty is only effective in the country of sale. If a problem
arises while the camera is in use abroad, please convey it back to the
country of sale before proceeding with a warranty claim to a Canon
Customer Support Help Desk.
For Canon Customer Support contacts, please see the Canon Limited
Warranty supplied with your camera.
Please Read

8
• Before using the camera, please ensure that you read and understand the
safety precautions described below. Always ensure that the camera is
operated correctly.
• The safety precautions noted on the following pages are intended to
instruct you in the safe and correct operation of the camera and its
accessories to prevent injuries or damage to yourself, other persons and
equipment.
• In the next few pages, the term equipment refers primarily to the camera
and its power supply accessories, such as the battery charger and
compact power adapter (sold separately).
Warnings
Safety Precautions
•Do not aim the camera directly into the sun or at other intense light
sources that could damage your eyesight.
•Do not trigger the flash in close proximity to human or animal eyes.
Exposure to the intense light produced by the flash may damage eyesight.
In particular, remain at least one meter (39 inches) away from infants
when using the flash.
•Store this equipment out of the reach of children and infants. Accidental
damage to the camera or batteries by a child could result in serious injury.
In addition, placement of the strap around the child’s neck could result in
asphyxiation.
•Do not attempt to disassemble or alter any part of the equipment that is
not expressly described in this guide. Disassembly or alteration may
result in high-voltage electrical shock. Internal inspections, alterations and
repairs should be conducted by qualified service personnel authorized by
your camera distributor or a Canon Customer Support Help Desk.
Storing SD cards
Store the SD memory card out of the reach of children and infants. It
may be swallowed accidentally. If this occurs, consult a doctor
immediately.

9
•To avoid the risk of high-voltage electrical shock, do not touch the flash
portion of the camera if it has been damaged. Similarly, never touch
internal portions of the equipment that become exposed as a result of
damage. There is a risk of high-voltage electrical shock. Please take the
first opportunity to consult your camera distributor or the closest Canon
Customer Support Help Desk.
•Stop operating the equipment immediately if it emits smoke or noxious
fumes. Failure to do so may result in fire or electrical shock. Immediately
turn the camera power off, remove the camera battery or unplug the
power cable from the power outlet. Confirm that smoke or fume
emissions have ceased. Please consult your camera distributor or the
closest Canon Customer Support Help Desk.
•Stop operating the equipment if it is dropped or the casing is damaged.
Failure to do so may result in fire or electrical shock. Immediately turn the
camera power off, remove the camera battery or unplug the power cable
from the power outlet. Please consult your camera distributor or the
closest Canon Customer Support Help Desk.
•Do not allow the equipment to come into contact with, or become
immersed in, water or other liquids. Do not allow liquids to enter the
interior. The camera has not been waterproofed. If the exterior comes into
contact with liquids or salt air, wipe it dry with a soft, absorbent cloth. If
water or other foreign substances enter the interior, immediately turn the
camera power off and remove the camera battery or unplug the power
cable from the power outlet. Continued use of the equipment may result in
fire or electrical shock. Please consult your camera distributor or the
closest Canon Customer Support Help Desk.
•Do not use substances containing alcohol, benzene, thinners or other
flammable substances to clean or maintain the equipment. The use of
these substances may lead to fire.
•Remove the power cable on a regular periodic basis and wipe away the
dust and dirt that collects on the plug, the exterior of the power outlet
and the surrounding area. In dusty, humid or greasy environments, the
dust that collects around the plug over long periods of time may become
saturated with humidity and short-circuit, leading to fire.

10
•Do not cut, damage, alter or place heavy items on the power adapter
cable. Any of these actions may cause an electrical short circuit, which
may lead to fire or electrical shock.
•Do not handle the power cable if your hands are wet. Handling it with
wet hands may lead to electrical shock. When unplugging the cable,
ensure that you hold the solid portion of the plug. Pulling on the flexible
portion of the cable may damage or expose the wire and insulation,
creating the potential for fires or electrical shocks.
•Use only recommended power accessories. Use of power sources not
expressly recommended for this equipment may lead to overheating,
distortion of the equipment, fire, electrical shock or other hazards.
•Do not place the batteries near a heat source or expose them to direct
flame or heat. Neither should you immerse them in water. Such exposure
may damage the batteries and lead to the leakage of corrosive liquids, fire,
electrical shock, explosion or serious injury.
•Do not attempt to disassemble, alter or apply heat to the batteries.
There is serious risk of injury due to an explosion. Immediately flush with
water any area of the body - including the eyes and mouth, or clothing -
that comes into contact with the inner contents of a battery. If the eyes or
mouth contact these substances, immediately flush with water and seek
medical assistance.
•Avoid dropping or subjecting the batteries to severe impacts that could
damage the casings. It could lead to leakage and injury.
•Do not short-circuit the battery terminals with metallic objects, such as
key holders. It could lead to overheating, burns and other injuries. Use
the supplied terminal cover to transport or store the battery pack.
•Before you discard a battery, cover the terminals with tape or other
insulators to prevent direct contact with other objects. Contact with the
metallic components of other materials in waste containers may lead to
fire or explosions. Discard the batteries in specialized waste facilities if
available in your area.
•Use only recommended batteries and accessories. Use of batteries not
expressly recommended for this equipment may cause explosions or
leaks, resulting in fire, injury and damage to the surroundings.

11
•Use the specified battery charger to charge Battery Pack NB-3L. Use of
other chargers may lead to overheating, distortion of the equipment, fire
or electrical shock.
•Disconnect the battery charger and compact power adapter from both
the camera and the power outlet after recharging and when they are not
in use to avoid fire and other hazards. Continuous use over a long period
may cause a unit to overheat and distort, resulting in fire.
•The camera terminal of the supplied compact power cord is designed
for exclusive use with your camera. Do not use it with other products or
batteries. There is a risk of fire and other hazards.
Caution about magnetic fields
Keep objects that are sensitive to magnetic fields (such as credit cards)
away from the speaker of the camera. Such items may lose data or stop
working.

12
Cautions
•Avoid using, placing or storing the equipment in places subject to
strong sunlight or high temperatures, such as the dashboard or trunk
(boot) of a car. Exposure to intense sunlight and heat may cause the
batteries to leak, overheat or explode, resulting in fire, burns or other
injuries. High temperatures may also cause deformation of the casing.
Ensure that there is good ventilation when using the compact power
adapter to charge the battery pack or power the camera.
•Do not store the equipment in humid or dusty areas. Storage in such
areas could lead to fire, electrical shock or other damage.
• Be careful not to bang the camera or subject it to strong impacts or
shocks that could lead to injury or damage the equipment when
wearing or holding it by the strap.
•Be careful not to cover the flash with your fingers when shooting. In
addition, do not touch the surface of the flash after taking several pictures
in rapid succession. Either action could result in burns.
•Do not operate the flash with dirt, dust or other items stuck to its lens.
The resulting heat build-up could damage the flash.
•Ensure that the battery charger is plugged into a power outlet of the
specified rating, not over the specified rating. The plug of the battery
charger varies according to region.
• Do not use the battery charger if the cable or plug is damaged, or if the
plug is not fully inserted into the power outlet.
• Do not allow metal objects (such as pins or keys) or dirt to contact the
charger terminals or plug.
•If your camera is used for prolonged periods, the camera body may
become warm. Please take care when operating the camera for extended
periods as your hands may experience a burning sensation.

13
Avoid Strong Magnetic Fields
Never place the camera in close proximity to electric motors or other
equipment generating strong electromagnetic fields. Exposure to strong
magnetic fields may cause malfunctions or corrupt image data.
Avoid Condensation Related Problems
Moving the equipment rapidly between hot and cold temperatures may
cause condensation (water droplets) to form on its external and internal
surfaces. You can avoid this by placing the equipment in an airtight,
resealable plastic bag and letting it adjust to temperature changes slowly
before removing it from the bag.
If Condensation Forms Inside the Camera
Stop using the camera immediately if you detect condensation. Continued
use may damage the equipment. Remove the SD card and battery or
Compact Power Adapter (if connected) from the camera and wait until the
moisture evaporates completely before resuming use.
Extended Storage
When not using the camera for extended periods of time, remove the
battery pack and store the equipment in a safe place. Storing the camera for
extended periods with a battery pack installed will run down the battery
pack and may damage the camera. Please note, however, that the date, time
and other camera settings may reset to the default settings if the battery
pack has been removed for more than three weeks. Follow the instructions
in this guide to reset the desired settings.
Preventing Malfunctions

14
Quick Start
Quick Start
1Charge the Battery Pack (p. 21)
Charge the battery pack using the supplied
battery charger. The charging is complete
when the charge indicator turns from
orange to green.
2Install the Battery Pack (p. 23)
Slide the SD card slot/battery cover open
and press the battery lock while you insert
the battery pack.
3Install the SD Card (p. 25)
• Insert the SD card as shown on the
bottom of the camera until you hear it
click into place.
• Do not touch or allow metal objects to
contact the terminals.
4Turn the mode switch to (Auto)
(p. 20)
5Turn on the power (p. 32)
Press the ON/OFF button until the power
lamp lights.
Charge Indicator
Battery Lock
Back
Terminals
Power Lamp

15
Quick Start
To Immediately Delete the Displayed Image
1. Press the button while the image is
displayed.
2. Confirm that [Erase] is selected and
press the SET button.
•
Set the date and time if the Date/Time
menu appears (p. 28).
• You can change the language in which menus are displayed
(p. 30).
• To view the other images you have photographed, refer to the
Replaying section (p. 93).
• After you finish using the camera, press the ON/OFF button to shut
the power off.
6Focus (p. 42)
Aim the camera and lightly press (halfway)
the shutter button. Two beeps will sound
when the autofocus is set.
7Shoot (p. 43)
Press the shutter button fully. The shutter
sound will sound when the shot is
complete.
8View the Recorded Image (p. 60)
The recorded image displays for
approximately 2 seconds. To continue
displaying the image, keep the shutter
button pressed or hold the shutter button
until you press the SET button and then
release both.

16
Components Guide
Front View
Viewfinder Window (p. 40)
AF-assist Beam (p. 43)
Red-Eye Reduction Lamp (p. 63)
Self-timer Lamp (p. 69)
Flash (p. 63)
DIGITAL Terminal
(pp. 121, 143)
A/V OUT (Audio/Visual
OUT) Terminal (p. 146)
Terminal Cover
Lens
Microphone (p. 104)
The following cables are used to connect the camera to a computer or
printer.
• Computer (p. 143)
USB Interface Cable IFC-300PCU (supplied with camera)
• Direct Print Compatible Printer (CP series, sold separately) (p. 121)
Direct Interface Cable DIF-100
(supplied with direct print compatible printers)
• Direct Print Compatible Bubble Jet Printer (sold separately) (p. 122)
Please refer to your Bubble Jet printer Quick Start Guide.
Please refer to the System Map supplied with the camera for direct print
compatible printers.

17
Preparing the Camera
* Be careful not to wave the camera about or catch it on other items when
dangling it from the wrist strap.
Back View
Viewfinder (p. 40)
Wrist Strap Mount
LCD Monitor (p. 34)
Tripod Socket
SD Card Slot/
Battery Cover (pp. 23, 25)
DC Coupler Terminal Cover (p. 166)
Attaching the Wrist Strap*
Speaker

18
Operation Panel
Power Lamp
Lights when the power is on or transmission preparations
are complete when connected to a computer
Mode Switch (p. 20)
Zoom Lever
Shooting: (Telephoto)/
(Wide Angle)
(p. 41)
Replay: (Magnify)/
(Index)
(pp. 94, 95)
Shutter Button (p. 42)
ON/OFF Button (p. 32)
DISP. (Display) Button (p. 34)
SET Button
MENU Button (p. 46)
(Light Metering)/ Button (p. 81)
FUNC. (Function)/ (Single Image Erase) Button
(pp. 44, 113)
(Macro)/ (Infinity)/ Button (p. 65)
(Continuous)/ (Self-timer)/ Button (pp. 68, 69)
(Flash)/ Button (p. 63)
Indicators (p. 19)
