Canon BJC-S830D User guide

V2
Application
Guide

2
Table of Contents
Printing with ImageBrowser .....................................................................................4
Basic Operation Procedure ......................................................................................7
What are Canon Utilities? ......................................................................................12
Starting ImageBrowser ...........................................................................................13
Using ImageBrowser .............................................................................................15
Using the Browser Window .................................................................................... 16
Changing the Appearance of the Browser Area .....................................................19
Organizing Images ................................................................................................. 22
Editing Image Using Image Viewer ........................................................................ 26
Slide Show .............................................................................................................30
Time Tunnel ...........................................................................................................36
Adding Sound to Image ..........................................................................................37
Creating Image Files Attached to E-mail ................................................................40
Creating Panoramic Photo Using PhotoStitch ........................................................44
Opening Image Selected in the Browser Area from Other Applications .................46
Importing Images ...................................................................................................48
Importing Images with the Automation Wizard .......................................................49
Importing Images Using the Camera Window ........................................................55
Using the Camera Window .....................................................................................58
Setting Up Your Canon Digital Camera ..................................................................66
Table of Contents

3
Table of Contents
Printing ..................................................................................................................69
Custom Layout Printing .......................................................................................... 70
Fixed Photo Size Printing ....................................................................................... 84
Tiled Photo Printing (Borderless Printing) .............................................................. 89
Canon Perforated Paper Printing ........................................................................... 95
About Canon Perforated Paper ............................................................................102
Starting Printing ....................................................................................................103
Index Printing .......................................................................................................107
Page Artwork .......................................................................................................115
Editing the Layout Format .................................................................................... 116
Inserting Text ........................................................................................................125
Cropping an Image ...............................................................................................130
How to Use Online Help ......................................................................................133
Index ....................................................................................................................134

4
Printing with ImageBrowser
Printing with ImageBrowser
ImageBrowser enables you to import image data captured with digital cameras or scanners into a
computer and produce photo-quality printouts in a quick and easy fashion. Using ImageBrowser
with a Canon BJ printer and a scanner or digital camera, you can enjoy superb-quality photo prints.
Custom Layout Printing
You can quickly reorganize the selected images. The
trimming and text insertion tasks are also easy.
Index Printing
You can print a photo index that contains thumbnails
automatically arranged in a suitable layout for the
selected thumbnail size (large, medium, or small).

5
Printing with ImageBrowser
Fixed Photo Size Printing Tiled Photo Printing (Borderless Printing)
You can print images with no margins around each
image, so that a single image is printed borderless along
the paper edges and multiple images are arranged like
tiles with no space between them (available with BJ
printers that support the borderless printing feature).
You can print images in the specified photo size.

6
Printing with ImageBrowser
Canon Perforated Paper Printing
You can easily make your images fit in a sheet of Canon
perforated paper.

7
Basic Operation Procedure
The basic operation steps to capture, import, edit, and print photo images are summarized below.
1
Acquiring images with a camera or scanner
Capture your favorite images with your digital camera or scanner.

8
2 Importing images
The Automation wizard provides easy means of
importing images.
Start ImageBrowser. Import images stored in the memory card or
the digital camera into the Camera Window.
ImageBrowser supports some simple
image editing features.

9
3 Selecting a layout
* The windows shown above are from BJ S330.
Select a layout you want to use and specify the type, orientation, and size of paper.
The wizard allows you to easily choose the free layout option, the image index (list) format, or the perforated paper.

10
4 Page Artwork
Changing the image size, trimming, and inserting of text are also easy tasks. Remember, however, you can rearrange the
images or change the image size only when you have selected the Custom layout printing option.

11
5 Printing
The images can be printed on Canon perforated paper (such as Photo Paper Pro <PR-101S> or
Glossy Photo Cards <FM-101>). Borderless printing is also supported.
* Some features and paper sizes may not be supported depending on the models of printers.

12
What are Canon Utilities?
Canon Utilities are application software included in the “BJ Solution Disk” or
“Setup & User’s Guide” in the CD-ROM, which is supplied with Canon BJ series printers. These
utilities enable you to display, save (import) to hard disk, edit, print the images captured by digital
cameras or scanners.
• ImageBrowser
ImageBrowser allows you to display a list of thumbnails (images stored in the internal memory
card), import them to your computer, and print them in photo-quality using the BJ printer. With
ImageBrowser, you can easily display, edit, and manage images stored in your computer’s hard disk
as well.
• PhotoStitch
PhotoStitch is an utility program for image merging and allows you to quickly create panoramic
photos by merging multiple images captured with your digital camera.
With PhotoStitch, you can merge any number of images vertically or horizontally, producing unique
posters or other photo-prints.The wide-mode merging feature is also useful when you want to create
a wide panoramic photo of a building or straight-lined object with straight lines as natural as the
original.

Starting ImageBrowser 13
Starting ImageBrowser
ImageBrowser automatically starts through its automatic execution feature. You can also start
ImageBrowser by double-clicking its icon in the same way as you would for other applications.
ImageBrowser supports the following image file types:
Automatic execution by the Automation wizard
ImageBrowser automatically starts when it detects a digital camera connected to your computer. At
the same time, the Automation wizard starts.
Note
➤
The Canon ImageBrowser Auto Launch control panel allows you to specify whether
ImageBrowser automatically starts or not when the digital camera is detected.
When this option is not selected, ImageBrowser will not automatically launch even
if the digital camera is detected.
Joint Photographic Experts Group (JPEG) CIFF
Tagged Image File Format (TIFF) PICT
EXIF Windows Bitmap (BMP)
The digital camera is
detected.
Importing Images with the Automation Wizard

Starting ImageBrowser 14
Starting ImageBrowser manually
As with other applications, ImageBrowser can be started by double-clicking its icon.
When you install ImageBrowser onto you computer, you can select the option to create the Canon
ImageBrowser icon (alias) on the desktop.
Double-clicking the Canon ImageBrowser icon (alias) on the desktop will start ImageBrowser, and
the initial window is displayed as shown below. Then the Browser Window appears.
When the Canon ImageBrowser alias icon is not displayed on the desktop, open the ImageBrowser
folder, in which the ImageBrowser program has been installed, and double-click the ImageBrowser
icon in the folder to launch.
Refer to Using the Browser Window for more information on this window.
Canon ImageBrowser on the desktop

15
Using ImageBrowser
This section provides an overview of ImageBrowser and its functions.
•Using the Browser Window
•Changing the Appearance of the Browser Area
•Organizing Images
•Editing Image Using Image Viewer
•Slide Show
•Time Tunnel
•Adding Sound to Image
•Creating Image Files Attached to E-mail
•Creating Panoramic Photo Using PhotoStitch
•Opening Image Selected in the Browser Area from Other Applications

Using the Browser Window 16
Using the Browser Window
This section describes the names and functions of the areas and buttons in the Browser Window,
the main window of ImageBrowser.
(1) Explorer
View
(2) Browser
area
(3) Control
panel
(4) CANON CAMERA
button
(6) The number of images
contained in the folder is
displayed.
(7) Thumbnails
(5) SELECT ALL
button

Using the Browser Window 17
(1) Explorer View
This view presents the names of your hard drives and the folders contained in the hard drives.
When your Canon digital camera is connected, double-click the Canon Camera icon to open
the Camera Window, where the images stored in your digital camera are displayed.
(2) Browser area
The Browser area presents the images in thumbnail format contained in the folder currently
selected in the Explorer View.
The View menu allows you to change display settings such as the size of thumbnails, the
items displayed, and the display mode.
Refer to Changing the Appearance of the Browser Area.
(3) Control panel
This area contains several buttons to manipulate the images in the Browser Window.
(4) CANON CAMERA button
Click this button to access your Canon digital camera connected to your computer, and
download the images in the camera to display in the Camera Window.
Refer to Using the Camera Window.
(5) SELECT ALL button
Clicking this button selects all images in the Browser area.
(6) The number of images contained in the folder is displayed.
(7) Thumbnails
Thumbnails are reduced images contained in the selected folder in the Explorer View. Click a
thumbnail to select its associated image.
To select multiple images, click each thumbnail while pressing the Shift key.

Using the Browser Window 18
(1) SEND TO TRASH button
Click this button to delete the selected images (image files) in the Browser area.
(2) REDUCE button
Click this button to reduce the size of thumbnails displayed in the Browser area. You can also
use the Reduce and Enlarge commands in the View menu to change the size of thumbnails
displayed in the Browser area.
(3) ENLARGE button
Click this button to increase the size of thumbnails displayed in the Browser area.You can also
use the Reduce and Enlarge commands in the View menu to change the size of thumbnails
displayed in the Browser area.
(4) DISPLAY IMAGE button
Click this button to display the selected image (thumbnail) in the Image viewer.
Refer to Editing Image Using Image Viewer.
(5) PRINT button
Clicking this button opens the submenu from which you can select either the Layout printing
or Index printing . Refer to Printing.
(1) SEND TO TRASH button
(2) REDUCE button
(3) ENLARGE button
(4) DISPLAY IMAGE button
(5) PRINT button

Changing the Appearance of the Browser Area 19
Changing the Appearance of the Browser Area
The Browser area of ImageBrowser presents the images and their associated information
contained in the selected folder in the Explorer View.
The information on the image appears.
The display format can be changed. Refer to Changing Display Options.
Browser area
The display format can be
changed.
Refer to Switching to the Preview
Display.
Thumbnail
The size can be changed.

Changing the Appearance of the Browser Area 20
Switching to the Preview Display
The selected image can be previewed. In this mode, the image is sized and displayed so that it fits
in the Browser area.
Select the View Mode from the View menu, and then select the Preview from the submenu that
appears. The mode switches to the preview display mode.
Select the List from the submenu to return to the list mode.
