NMPJ Ver. 1.1 User’s Manual

2
Table of Contents
Safety Instructions........................ 4
Federal Communication Commission
Notice ...................................................... 4
Canadian Radio Interference
Regulations ............................................ 4
Open Source Software ................. 7
Networked Multi-Projection
Overview...................................9
Introduction to Networked Multi-
Projection .................................... 10
Installation ................................... 12
System Requirements ......................... 12
Installation ............................................ 13
Uninstallation .............................. 15
From Startup to Shutdown......... 19
Operation in Each Mode........25
Using the Projector in Direct
Mode............................................. 26
Procedure ............................................. 26
Direct Mode Window............................ 28
Using the Projector in Meeting
Mode............................................. 30
Creating a Session............................... 30
Joining a Session ................................ 35
Meeting Mode Window ........................ 36
Using the Projector in Classroom
Mode............................................. 38
Leading a New Session ....................... 38
Joining an Existing Session ............... 42
Classroom Mode Window (Starting a
Session) ................................................ 44
Classroom Mode Window (Joining a
Session) ................................................ 46
Using the Projector in Broadcast
Mode............................................. 48
Procedure ............................................. 48
Broadcast Mode Window .................... 50
Functions................................53
Using the Session Selection
Menu............................................. 54
Session Selection Menu...................... 54
Finding Sessions ................................. 55
Using the Projector Selection
Menu .............................................56
Projector Selection Menu.................... 56
Using Layout Functions .............60
Completing Software Projection
Settings ........................................66
Reducing Windows to a Compact
Size ...............................................68
Split-Screen Display With Non-
Network Sources .........................69
Tips for Better Networked
Projection.....................................70
Restrictions..................................71

3
Use of this manual
This manual does not provide the detailed description of basic operation and
functions for computer, web browser, projector and network. For instructions
about each piece of equipment or software, please refer to the respective
manual.
Trademarks
Ethernet is a registered trademark of Xerox Corporation. Microsoft, Windows,
Windows Vista, Windows 7 and Windows 8 are registered trademarks of
Microsoft Corporation in the United States and other countries. Internet
Explorer is a registered trademark of Microsoft Corporation. JavaScript is a
registered trademark or trademark of Oracle Corporation and its subsidiaries
and affiliates in the United States and other countries.
Mac, Mac OS and Macintosh are registered trademarks of Apple, Inc. in the
USA and other countries. PowerPC is a registered trademark of IBM
Corporation. Intel Core is a registered trademark of Intel Corporation in the
USA and other countries.
Other product or brand names in this manual are registered trademarks or
trademarks of their respective owners.
*Unauthorized use of a part or whole of the contents in this manual is
prohibited.
*The contents of this manual are subject to change without notice.
Symbols Used in This Manual
Meanings of the symbols used in this manual are as follows.
A precaution about operation or restriction is given here.
Indicates supplemental information to note in use.

4
Safety Instructions
Federal Communication Commission Notice
Multimedia Projector, Model: WUX6000
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio / TV technician for help.
The cable with a ferrite core provided with the projector must be used with this
equipment in order to comply with Class B limits in Subpart B of Part 15 of the
FCC rules.
Use of a shielded cable is required to comply with class B limits in Subpart B of
Part 15 of FCC Rules.
Do not make any changes or modifications to the equipment unless otherwise
specified in the instructions. If such changes or modifications should be made,
you could be required to stop operation of the equipment.
Canon U.S.A. Inc.
One Canon Park, Melville, New York 11747, U.S.A.
Tel No. [phone]

5
Safety Instructions
Safety Instructions
CAUTION IN USING THE PROJECTOR VIA
NETWORKS
•When you find a problem with the projector, remove the power cable immediately
and inspect the unit. Using the projector with failure may cause fire or other
accidents.
•If you remotely use the projector via networks, carry out a safety check regularly
and take particular care to its environment. Incorrect installation may cause fire or
other accidents.
Caution in using network function
•We assume no responsibility for the loss or damage of data, or damage of the
computer caused by using this projector. Making back-up copies of valuable data
in your computer is recommended.
Safety instructions
Please read and understand all instructions thoroughly before using.
About safety symbols
The following symbols are used in this manual to alert you to important safety
information. Always observe the instructions to reduce the risk of injury and
property damage.
Indicates a potentially hazardous situation which, if not avoided,
may cause death or serious injury.
Indicates a potentially hazardous situation which, if not avoided,
may cause minor or moderate injury.

Safety Instructions
6
Safety information
Always mount and operate the product in accordance with the safety instructions
specified by the projector and peripheral equipment makers.
•Do not attempt to disassemble or service the product yourself. Doing so may
result in a fire, an electric shock, or product damage.
•If the projector emits a strange odor, or makes a strange noise, immediately
turn the power and peripheral equipment off, unplug these devices, and
contact your dealer.
•Do not drop the projector or subject it to strong shocks. Doing so may result
in damage to the internal parts, an electric shock, a fire, or product damage.
•Do not touch the projector with wet hands when the power cord plugs of the
projector or peripheral equipment inserted into the electrical outlet.
Otherwise, an electric shock may result.

7
Open Source Software
Open Source Software
The NMPJ software incorporates third-party software modules. For details, refer to
the “Third-Party Software” PDF file on the included installation CD-ROM, in
[thirdparty_software] > [NMPJ] > [LICENSE]. Each module’s license conditions are
also available in the same folder.
NO WARRANTY
BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO
WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY
APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE
COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM
“AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE
ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE PROGRAM
IS WITH YOU. SHOULD THE PROGRAM PROVE DEFECTIVE, YOU ASSUME
THE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECTION.
IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN
WRITING WILL ANY COPYRIGHT HOLDER, OR ANY OTHER PARTY WHO MAY
MODIFY AND/OR REDISTRIBUTE THE PROGRAM AS PERMITTED ABOVE, BE
LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL, SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR
INABILITY TO USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS
OF DATA OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED
BY YOU OR THIRD PARTIES OR A FAILURE OF THE PROGRAM TO OPERATE
WITH ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY
HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
NO SUPPORT
Canon Inc., and all its subsidiaries or its dealers do not make any support service
regarding the source code. Canon Inc., and all its subsidiaries or its dealers shall
not respond to any questions or enquiries, from you or any other customers,
regarding the source code.

8

9
Networked Multi-Projection
Overview
Operation in Each Mode
Functions
Networked Multi-
Projection
Overview

10
Introduction to Networked Multi-Projection
Networked Multi-Projection (NMPJ) is a projector function enabling projection of
computer screens over a local network.
■Projection Over a Network
Using this software, you can link multiple computers and multiple projectors, for a
variety of projection scenarios.
■Split-Screen Projection of Multiple Images
Images from multiple computers can be projected at once, with the images
projected in separate areas of a single screen.
■Projection of an Image from Multiple Projectors at Once
Images from a single computer can be projected from multiple projectors at once.
Links computers and projectors via a network connection.
• Direct Mode
LAN
Projection of multiple computer screens in split-screen display.
• Meeting Mode, Classroom Mode
LAN
LAN
Projection of one computer screen from multiple projectors.
• Meeting Mode, Classroom Mode, Broadcast Mode

11
Introduction to Networked Multi-Projection
Networked Multi-Projection Overview
For multi-monitor computers, you can project either the primary or secondary monitor.
■Selecting the Projection Monitor
For each computer, you can select the monitor to project.
• With some computers, it may not be possible to switch between projection of the
primary and secondary monitor.
• Software responsiveness may decline when many computers and projectors are
connected over the network.
• For computers that support three or more monitors, the monitor used for projection
varies depending on the model of computer.
.#0
㧭
㧭
$
$
%
%
&
&
$
$
$
$
$
$
$
$
A
mong multiple computers in a network, projection of one computer screen from multiple projectors.
• Classroom Mode, Meeting Mode
Select the primary or secondary monitor for projection
• Direct Mode, Meeting Mode, Classroom Mode, Broadcast Mode
LAN
Select the primary or secondary monitor of each computer
• Classroom Mode
LAN

12
Installation
To use the NMPJ function, you must install the NMPJ software (hereafter, “the
software”) on the computers to be used.
Instructions in this manual are for installation in a Windows 7 environment.
System Requirements
Software system requirements are as follows.
CPU Core 2 Duo P8600, 2.4 GHz or higher (32- or 64-bit)
Memory 1 GB or more
HDD 32 GB or more
Monitor Resolution: 1024x768 dots or more
Operating System
Windows Vista (Business) SP2
Windows 7 (Home/Professional/Ultimate) SP1
Windows 8 (Pro)
Windows 8.1 (Pro)
* Windows Vista compatibility is limited to 32-bit editions.
* Both 32- and 64-bit editions of Windows 7 and later are supported.
Network In TCP/IP network environments, projectors can be connected to
computers via the following LAN connections.
Wired LAN (1000BASE-T, 100BASE-TX)
Magnification Display magnification:
Cannot be installed on computers with display magnification set
higher than 200%.
Cannot be installed on computers without a minimum resolution of
1024x768. Additionally, operation is not ensured if the resolution is
switched to less than 1024x768 after installation.
• Operation is not ensured in other operating systems or editions.
• Menus are in English in all cases, except in Japanese and Simplified
Chinese versions of the software.
• Operation is not ensured in operating systems other than English,
Japanese, or Simplified Chinese OSes.
• Although the software also supports computer-projector
communication over a router, operation is only ensured over one
router hop. Additionally, to use Broadcast mode (P48) with projectors
in other subnets, the router must support IPv4 multicast routing. Note
that the router must be set up to route multicast addresses used by
the software.
• If you are using an Aero style in Windows, this message may be
displayed: “Do you want to change the color scheme to improve
performance?”

13
Installation
Networked Multi-Projection Overview
Installation
The software is stored in the projector’s internal memory. To install it on a computer,
use a web browser on the computer to access the projector and download the
software.
1On the computer, start a web browser and connect to the projector.
For instructions on accessing the projector’s web screen from a browser, refer
to the projector user’s manual.
For instructions on checking the projector’s IP address, refer to the projector
user’s manual.
2Click [Network Multiple Projection Download].
3Click [Download].
4When a confirmation message is displayed, click [Run].
For instructions on connecting the projector to a network, refer to the projector user’s
manual.

Installation
14
5If a [User Account Control] message is displayed, click [Yes].
6Next, follow the instructions displayed to complete the installation
process.
■Updating the Software
If the version of the software installed is older than a version available on a
projector, you can update it by following the normal installation procedure.
During the installation process, the version available is compared to the version
installed, and if it is newer, the current version is overwritten as the new version is
installed. If overwriting is not necessary, the installation process ends.
• Confirmation or warning messages may be displayed during installation or
uninstallation.
These messages request administrator credentials from the current user. If you are
logged in as a user with administrator credentials, click [Yes] (or [Continue]) to
continue.
• Depending on the software, you may not be able to continue without administrator
credentials. If you are logged in as a standard user, switch to an administrator account
and try again.
• You may need to restart the computer to complete the installation process. If restarting
is requested, be sure to restart the computer.
• The software cannot be installed when the following setting is used in Windows 8.1.
Control Panel > All Control Panel Items > Display > “Let me choose one scaling level
for all my displays” selected > “Extra Large - 200%” selected.
Install the software using a setting other than “Extra Large - 200%.”
Software Versions
The version of the software stored on the projector’s internal memory is 1.1.
• Any projectors purchased previously may have been shipped with version 1.0 of the
software stored internally.
• The software will automatically detect if a newer version of the software is available on
a projector. In this case, a message is displayed to notify you.

15
Networked Multi-Projection Overview
Uninstallation
■Windows 7 or Earlier
These instructions are for uninstallation in Windows 7 or earlier versions of
Windows.
1Select [Start] > [All Programs] > [Canon NMPJ] > [Uninstall network
multiple projection].
2If a [User Account Control] message is displayed, click [Yes].
3After the confirmation message is displayed, click [OK].

Uninstallation
16
4After uninstallation is finished, click [OK] when the confirmation message
is displayed.
5Delete the following folder manually.
Windows Vista
C:\Users\<User Name>\AppData\Local\Canon\NMPJ
Windows 7
C:\Users\<User Name>\AppData\Local\Canon\NMPJ
You may need to restart the computer to complete the uninstallation process. If restarting
is requested, always restart the computer.
These files are hidden. To view hidden files, follow these steps.
Windows Vista
To view hidden files in Windows Explorer, select [Folder options] > [View] > [Show hidden
files, folders, and drives].
Windows 7
In Windows Explorer, select [Tools] > [Folder Options] > [View] > [Show hidden files,
folders, and drives].

17
Uninstallation
Networked Multi-Projection Overview
■Windows 8 or Later
These instructions are for uninstallation in Windows 8 or later versions of Windows.
1On the [Apps] screen, right-click the [Canon NMPJ] application icon.
2In the menu displayed at the bottom of the [Apps] screen, click
[Uninstall]. Otherwise, click [Uninstall] in the app bar and then [Uninstall]
again on the screen displayed next.
3In the [Programs and Features] screen that is displayed, select [Canon
NMPJ].
Windows 8/8.1
Windows 8.1 Update

Uninstallation
18
4Select [Uninstall/Change].
5After the confirmation message is displayed, click [OK].
6Delete the following folder manually.
Windows 8
C:\Users\<User Name>\AppData\Local\Canon\NMPJ
Windows 8.1
C:\Users\<User Name>\AppData\Local\Canon\NMPJ
You may need to restart the computer to complete the uninstallation process. If restarting
is requested, always restart the computer.
These files are hidden. To view hidden files, follow these steps.
Windows 8 or later
In Windows Explorer, select [Tools] > [Folder Options] > [View] > [Show hidden files,
folders, and drives].

19
Networked Multi-Projection Overview
From Startup to Shutdown
The procedure from software startup to shutdown is as follows. Example windows
shown here are from Direct mode.
(Windows 8 or Later)
1Select [Start] > [Apps] > [Canon NMPJ] > [Network Multiple Projection].
(Windows 7 or Earlier)
1Select [Start] > [All Programs] > [Canon NMPJ] > [Network Multiple
Projection].

From Startup to Shutdown
20
Windows Firewall
The following alert may be displayed the first time you start the software, depending on
your Windows Firewall settings.
To enable communication with projectors, select all check boxes and click the [Allow
access].
To change the settings after closing the alert, open the [Start] menu and select [Control
Panel] > [System and Security] > [Windows Firewall] > [Allow an app through Windows
Firewall].
Select [CANON Network Multiple Projection] in the list of allowed apps and features, and
then select each check box.
