Canon PIXMA MX870 Series User instructions

Setting Up Your MX870 In
Default Mode (Tel Priority Mode)
Without An Answering Machine
DSL/Cable Modem Connection
Next

Connecting The Phone Lines
NextPrevious

Fax to Phone Line Connection
NextPrevious 3
Before
Hand Set
(Phone)
(Existing Phone Cord)
Wall jack
DSL/Cable
Modem P
C
(Existing Phone Cord)
(Existing Phone Cord)
After
(Phone Cord included with
Canon printer)
(Existing Phone Cord)
Wall jack DSL/Cable
Modem
P
C
Hand Set
(Phone)

Fax to Phone Line Connection
NextPrevious 4
(Existing Phone Cord)
Hand Set
(Phone)
(Existing Phone Cord)
Wall Jack
DSL/Cable
Modem P
C
•Plug the provided phone cord into the DSL/Cable Modem
(Phone Cord included
with Canon printer)

Fax to Phone Line Connection
NextPrevious 5
(Existing Phone Cord)
(Existing Phone Cord)
Wall jack
DSL/Cable
Modem P
C
(Phone Cord included
with Canon printer)
Hand Set
(Phone)
•Plug the provided phone cord into the “L” jack in the rear of the
multifunction

Fax to Phone Line Connection
NextPrevious 6
(Existing Phone Cord)
(Existing Phone Cord)
Wall jack
DSL/Cable
Modem P
C
(Phone Cord included
with Canon printer)
Hand Set
(Phone)
•Remove the white plug from the upper jack

Fax to Phone Line Connection
NextPrevious 7
(Existing Phone Cord)
(Existing Phone Cord)
Wall jack
DSL/Cable
Modem P
C
(Phone Cord included
with Canon printer)
Hand Set
(Phone)
•Plug the second phone cord into the jack marked with an image of a
“telephone” located on the rear of the multifunction.

Fax to Phone Line Connection
NextPrevious 8
(Existing Phone Cord)
(Existing Phone Cord)
Wall jack
DSL/Cable
Modem P
C
(Phone Cord included
with Canon printer)
Hand Set
(Phone)
•Plug the existing phone cord into the phone

Setting Up The Receive Mode
NextPrevious

Step 1
Turn on the MX870 by pressing the
ON button.
Step 2
Press the FAX button.
NextPrevious 10

Step 3
The fax standby screen will appear.
Step 4
Press the center FUNCTION button.
NextPrevious 11

Step 5
The Receive mode settings screen
will appear.
Step 6
Use the UP or DOWN button to
select “TEL priority mode”.
NextPrevious 12

NextPrevious 13
Step 7
Ensure that “TEL priority mode” is
highlighted.
Step 8
Press the OK button.

Step 9
Your MX870 is now set to Tel
priority mode. Notice that the mode
is listed on the fax standby screen.
NextPrevious 14

Receiving A Fax
To receive a fax:
•Pick up the handset on the phone connected to the MX870.
•Listen for fax tones.
•When the tones stop hang up the handset.
•The MX870 will receive the fax document.
IMPORTANT:In order to receive a fax, you must pick up the handset on a
phone that is connected to the multifunction.
Previous 15
