Canzy CZ-I62 Operator's manual

User Instruction Manual
DOUBLE INDUCTION COOKER MODEL:CZ-I62
CONTENTS
SAFTY INSTRUCTIONS............................................................................................................................................... 3
INSTALLATION...............................................................................................................................................................4
ELECTRICAL CONNECTION.......................................................................................................................................4
BEFORE USE..................................................................................................................................................................5
INSTRUCTION FOR USE............................................................................................................................................. 5
TECHNICAL INFORMATION........................................................................................................................................7
CLEANING.......................................................................................................................................................................7
TROUBLESHOOTING GUIDE..................................................................................................................................... 8
NOISES MADE BY THE HOB...................................................................................................................................... 8
AFTER-SALES SERVICE............................................................................................................................................. 8

2
SAFTY INSTRUCTIONS
YOUR SAFETY AND THAT OF OTHERS IS VERY IMPORTANT
This manual and the appliance itself provide important safety messages, to be read and always observed.
This is the warning / caution-safety symbol, regarding safety, warning of potential risks to users
and other
All messages relevant to safety specify the potential risk to which they refer and indicate how to reduce the
risk of injury, damage and electric shocks due to incorrect use of the appliance. Make sure to comply with
the following:
The appliance must be disconnected from the power supply before carrying out any installation
operation.
Installation and maintenance must be carried out by a specialized technician, in compliance with the
manufacturer’s instructions and the local safety regulations in force. Do not repair or replace any part of
the appliance unless specifically stated in the user manual.
The appliance must be earthed.
The power cable must be long enough for connecting the appliance, fitted in the cabinet, to the power
supply.
For installation to comply with the current safety regulations, an omnipolar switch with minimum contact
gap of 3mm is required.
Do not use multi-sockets or extension cords.
Do not pull the appliance’s power cable.
The electrical parts must not be accessible to the user after installation.
The appliance is designed solely for domestic use for cooking food. No other use is permitted (e.g.
heating rooms). The Manufacturer declines any liability for inappropriate use or incorrect setting of the
controls.
WARNING: The appliance and its accessible parts become hot during use. Care should be taken to
avoid touching heating elements. Children less than 8 years old shall be kept away unless continuously
supervised.
The accessible parts can become very hot during use. Children must be kept away from the appliance
and watched over to ensure they do not play with it.
Do not touch the appliance heating elements during and after use. Do not allow the appliance to come
into contact with cloths or other flammable materials until all the components have cooled sufficiently.
Do not place flammable materials on or near the appliance.
Overheated oils and fats catch fire easily. Pay attention when cooking food products rich in fat and oil.
This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and understand hazards
involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made
by children without supervision.
An air switch or circuit breaker (not supplied) should be installed in the compartment under the
appliance.
If the surface is cracked, switch off the appliance to avoid the possibility of electric shock.
The appliance is not intended to be operated by means of an external timer or separate remote control
system.
WARNING: Unattended cooking on a hob with fat or oil can be dangerous and may result in fire.
NEVER try to extinguish a fire with water, but switch off the appliance and then cover flame e.g. with a
lid or a fire blanket.
WARNING: Danger of fire: do not store items on the cooking surfaces.
Do not use steam cleaners.
Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since
they can get hot.
After use, switch off the hob element by its control and do not rely on the pan detector.

3
INSTALLATION
After unpacking the product, check for any damage during transport. In case of problems, contact the dealer
or the After-Sales Service.
For built-in dimensions and installation instruction, see in below figures
The distance between the underside of the appliance and the separator panel must respect the
dimensions given in the figure (mini. 50mm).
In order to ensure the correct operation of the product, do not obstruct the minimum required
clearance (min. 20 mm) on the worktop for air flow out.
If an oven is installed, make sure the oven is equipped with a cooling system.
Do not install the hob above a dishwasher or washing-machine, so that the electronic circuits do not
come into contact with steam or moisture which could damage them.
ELECTRICAL CONNECTION
Disconnect the appliance from the power supply.
Installation must be carried out by qualified personnel who know the current safety and
installation regulations.
The manufacturer declines all liability for injury to persons or animals and for damage to property
resulting from failure to observe the regulations provided in this chapter.
The power cable must be long enough to allow the hob to be removed from the worktop.
Make sure the voltage specified on the rating label located on the bottom of the appliance is the same
as that of the home.

4
BEFORE USE
IMPORTANT: The cooking zones will not switch on if pots are not the right size. Only use pots bearing the
symbol “INDUCTION SYSTEM” (Figure below). Place the pot on the required cooking zone before switching
the hob on.
EXISTING POTS AND PANS
Use a magnet to check if the pot is suitable for the induction hob: pots and pans are unsuitable if not
magnetically detectable.
Make sure pots have a smooth bottom, otherwise they could scratch the hob. Check dishes.
Never place hot pots or pans on the surface of the hob’s control panel. This could result in damage.
The bottom diameter of pots or pans should be at least 10cm.
INSTRUCTION FOR US
GENERAL OVERVIEW
To avoid permanently damaging the glass-ceramic top, do not use:
Pots with bottoms that are not perfectly flat.
Metal pots with enamelled bottom.
CONTROL PANEL LAYOUT

5
Switching the hob On/Off
•To switch the hob on, press the button and the cooking zone displays light up.
•If within 120 seconds of switching on, no heating zone is selected, the hob switches off
•automatically.
Adjusting cooking zones
Once the hob is switched on and the pan is positioned on the chosen cooking zone, select the zone using
the corresponding button: the display shows level 0.
Each cooking zone has various power levels, adjustable with the buttons, going from low power to high
power.
Booster & Double ring function
Select the induction cooking zone , and press this button;
The cooking zone will work in 2400W continuously 5 minutes.
Push this button again, Then the cooking zone will recover to previous level.
Select the ceramic hob zone and press this button, will turn and off the outer ring
Child lock
• This function locks the controls to prevent accidental switching on of the hob.
• To activate the child lock function, switch on the hob and hold button for three
seconds; the timer shows" Lo". Then the control panel is locked.
•
• To deactivate the control panel lock, repeat the activation procedure.
•The" Lo" goes off and the hob is active again.
Timer
The timer can be used to set cooking time for a maximum of 99 minutes (1 hour and 39 minutes)
for all cooking zones.
Select the cooking zone to be used with the timer, press the button with the clock
symbol then set the desired cooking time using the buttons of the timer function
(see figure).
Menu
The light of the first button power is flashing, the power of the furnace is displayed, and
the addition and subtraction can be adjusted.
The second button is stir fry lights. The furnace shows the temperature, you can adjust
the addition and subtraction
The third button, the stewing light is shining, the furnace shows a fixed power of 1800W
The fourth button, Steam's light is shining, the furnace shows a fixed power of 1600W
By pressing the Steam & Stewing function, you can't change the power anymore.

6
Auto switch off
The hob will automatically switch off when you did not set cooking time, forgot to switch off the hob, and
did not operate the hob at all.
CONTROL PANEL WARNINGS
Residual heat indicator
The hob is fitted with a residual heat indicator for each cooking zone.
These indicators alert the user when cooking zones are still hot.
If the display shows , the cooking zone is still hot.
If the residual heat indicator of a given cooking zone is lit, that zone can be used ,for example,
to keep a dish warm or to melt butter.
When the cooking zone cools down, the display goes off.
Incorrect or missing pot indicator
If you are using a pot that is not suitable, not correctly positioned or not of the correct
dimensions for your induction hob, the message “E0” will appear in the display (see figure
at side).
If no pot is detected within 120 seconds, the hob switches off.
TECHNICAL INFORMATION
Voltage: 220 - 240 V 50/60 Hz
Model: CZ-I62 Max. power: 4800W
CLEANING
Do not use steam cleaners.
Before cleaning, make sure the cooking zones are switched off and that the residual heat
indicator (“H”) is not displayed.
IMPORTANT: Do not use abrasive sponges or scouring pads. Their use could eventually ruin the glass.
After each use, clean the hob (when it is cool) to remove any deposits and stains due to food residuals.
Sugar or foods with a high sugar content damage the hob and must be immediately removed.
Salt, sugar and sand could scratch the glass surface.
Use a soft cloth, absorbent kitchen paper or a specific hob cleaner (follow the Manufacturer’s
instructions).

7
TROUBLESHOOTING GUIDE
Read and follow the instructions given in the section “Instructions for use”.
Check that the electricity supply has not been shut off.
Dry the hob thoroughly after cleaning it.
If, when the hob is switched on, alphanumeric codes appear on the display, consult the following table
for instructions.
If the hob cannot be switched off after using it, disconnect it from the power supply.
Error
code
Possible Cause
Remedy
E0
No Pan or did not detect the pan
Put on the pan
E2
NTC short or open
Call the after-sales service and specify the error
code
E3
High voltage
Call the after-sales service and specify the error
code
E4
Low voltage
Call the after-sales service and specify the error
code
NOISES MADE BY THE HOB
Induction hobs can make whistling or crackling sounds during normal operation, these actually come from
the pots and pans as a result of the characteristics of the bottoms (for example, bottoms made of several
layers of material, or uneven bottoms). These noises vary depending on the pots and pans used and the
amount of food they contain, and are not indicative of a defect of any kind.
In addition, the induction hob is equipped with an internal cooling system to control the temperature of
electronic parts; as a result, during operation and for several minutes after the hob has been switched off,
the noise of the cooling fan will be audible. This is perfectly normal and indeed essential for proper
functioning of the appliance.
