Welcome to Capital Cooking’s outdoor collection.
Our products speak to the heart and mind, conveying the fact that emotion will always be
at the center of our vision. Our high-end grills deliver the highest levels of control,
power and grace in their category. They allow you to express untapped resources of creativity, freeing your
imagination to invent, experiment and create joy. Discover how Capital’s Performance SeriesTM transforms
ordinary grilling into extraordinary living.
PERFORMANCE SERIES
™
C38897.indd 4C38897.indd 4 10/24/06 3:23:58 PM10/24/06 3:23:58 PM

celebrate
PSQ52RCSB
C38897.indd 5C38897.indd 5 10/24/06 3:23:58 PM10/24/06 3:23:58 PM

PSQ52RCSB
No matter how you define performance, it is simply the art of living better.
C38897.indd 6C38897.indd 6 10/24/06 3:24:07 PM10/24/06 3:24:07 PM

52II
They’re the flagship of Capital’s grills, combining awe-inspiring
power and control with breathtaking levels of sophistication. Featuring
an exclusive sear-zone infrared burner, lights for nighttime cooking,
and lifetime stainless steel burners. Also featuring flare-up reducing
stainless steel grill racks with a grease management design, and our
distinguished seamless body construction. With reinforced hoods and
exclusive zone-cooking system, we created these grills to perform.
Choose the 52" all-grill (shown), or the 52" w/ integrated side burners
and you’ll soon discover unbridled cooking pleasure.
the most commanding and
celebrated grills in the high-end category
THE 52" PERFORMANCE SERIES GRILLS: POWER UNLIKE ANY OTHER
PSQ52RC
C38897.indd 7C38897.indd 7 10/24/06 3:24:07 PM10/24/06 3:24:07 PM

40II
your luxury outdoor kitchen awaits
THE BUILT-IN GRILL SERIES: VERSATILITY BEYOND COMPARISON
Indulge your senses with our incomparable line of built-in products
and accessories. Each Performance Series model can be built into
masonry enclosures and outfitted with an array of complimentary
products. With our double side burner, cocktail station, 24" power wok
and smoker box, we have everything you need to transform your
backyard paradise into the perfect outdoor kitchen.
PSQ40RBI
C38897.indd 8C38897.indd 8 10/24/06 3:24:11 PM10/24/06 3:24:11 PM

FUNCTION / FORM
fig: 1 25,000 BTU “Infrared-Zone
™
”
burner
fig: 2 25,000 BTU “W” shaped SS
Performance burner
fig: 3 15,000 BTU Flush mounted
infrared rotisserie burner
fig: 4 30,000 BTU Total sealed double
side burner
fig: 5 20 Watt integrated lights
fig: 6 Tru-Side
™
SS grates with
grease channeling design
fig: 7 Seamless construction
Function:
• 20 Watt built in lights
• Infrared-Zone
™
burner at 25,000 BTUS w/ SS Zone Cover
• “W” Stainless steel burner at 25,000 BTUS
• 15,000 BTU infrared rotisserie burner
• 30,000 BTU total sealed double side burner w/ SS Cover
• Rapid-Fire
™
electronic ignition (batteries required)
• Stainless steel wave shaped radiant system
• 50 LB capacity rotisserie motor
• Heavy duty cast stainless steel rotisserie forks
• Zone-Cooking
™
allows optimization of cooking areas into zones
for LO, MED, and HI settings
• Tru-Side
™
: Double-sided two position stainless steel channel
grates minimize flare-ups and manage grease flow.
• Double lined hood minimizes discoloration and warping
• Cart storage drawers on easy glides for smooth operation
• Trays within a tray drip pan system for easier grease management
• Collapsible side tray shelves
• Removable warming rack
Form:
• Finest 304 Stainless Steel in elegant brush finish
• All seamless construction means no sharp corners
• Chrome plated knobs, bezels, handle end caps, and cart handles
• Accent stripes on lid
• Lid handle with knurling
• Rounded bull-nose, cart drawers and side shelves
• Hidden casters
52" Performance Built-In Gas Grill
PSQ52RBI
40" Performance Built-In Gas Grill
PSQ40RBI
30" Performance Built-In Gas Grill
PSQ30ZRBI, PSQ30RBI
52" Performance Built-In Gas Grill
PSQ52RSBI
52" Performance Gas Grill
PSQ52RC
40" Performance Gas Grill
PSQ40RC
30" Performance Gas Grill
PSQ30ZRC, PSQ30RC
52" Performance Gas Grill
PSQ52RCSB
fig: 1 fig: 2 fig: 3 fig: 4 fig: 5 fig: 6 fig: 7
Built-In Models
Cart Style
C38897.indd 9C38897.indd 9 10/24/06 3:24:14 PM10/24/06 3:24:14 PM

ACCESSORIES
COMPLEMENTS
BURNER POWER-WOK COOLER
Create your own style!
For special sauces and special memories, choose our stylish
and powerful double side burner. Like every item we create
it transforms ordinary cooking into something extraordinary.
With style, power, efficiency and control you’ll sauté and
sear, boil and simmer like a true professional.
Features:
• 304 Stainless Steel construction
• Two 15,000 BTU sealed burners
• Electronic ignition (batteries required)
• Cast-iron top grate w/ matte porcelain finish
• Rounded bullnose
• Chrome plated knobs and bezels
• Stainless Steel cover included
Note:
• Available in LP or Natural Gas
• For combustible enclosures please use an insulated jacket
Accessories:
• PSQSB2VCBI Vinyl Cover
• PSQSB2IJS Double Side Burner Insulated Jacket
• Conversion Kits From LP to NG or NG to LP
Features:
• 304 stainless steel construction in elegant brush finish
• Insulated lid and body
• Removable internal condiment section with four trays
• Drainage plug
• Rounded bull-nose to match Performance Series grills
• Wide mouth front cavity for additional storage
Accessories:
• Vinyl Cover
Because form should never follow function, our
grilling accessories raise the bar in terms of beauty
and functionality. Every detail is carefully considered,
every curve and line a statement of great design.
26" Stainless Steel Cooler
26CLRBI
30,000 BTU Double Side Burner
PSQSB2000
20x30
PSQ30ADS
20x40
PSQ40ADS
17x24
PSQ24ADVS
14x20
PSQ20ADVS
Smoker Box
PSQ-SBX
ACCESS DOORS CHOPPING BLOCK/SMOKER BOX
See your authorized dealer for details.
ACCESS DOORS/DRAWER SYSTEMS CHOPPING BLOCK/SMOKER BOX
24" Power-Wok at 35,000 BTU
PSQ24WK
24" High LP/Trash Drawer
CCEPD24SS
30" Wide Cooler Drawer
w/ 48 Quart Cooler
CCECD30SS
1 Drawer SS
Built in System
CCE1DRWSS
2 Drawer SS
Built in System
CCE2DRWSS
3 Drawer SS
Built in System
CCE3DRWSS
Chopping Block
PSQ-CHBX
C38897.indd 10C38897.indd 10 10/24/06 3:24:24 PM10/24/06 3:24:24 PM

SPECIFICATIONS
0312# ALLGRILLWROTISS33BURNERSSEARZONELIGHTSCART          
0312#3" GRILLWROTISS33BURNERSSEARZONELIGHTSSIDEBURNERSCART          
0312# WROTISS33BURNERSSEARZONELIGHTSCART          
031:2# GRILLWROTISS33BURNERSEARZONELIGHTSCART          
0312# GRILLWROTISS33BURNERSLIGHTSCART          
#!24-/$%,   #//+).'!2%!).31). ! " # $ % & ' ( )
03182# GRILLWROTISS33BURNERSLIGHTSCARTWSINGLEACCESSDOORANDSHELF #!,,&/2$%4!),%$30%#3
s#APITALWILLPRODUCENONROTISSERIEVERSIONSOFTHEGRILLSONLYASSPECIALORDERITEMS,ONGERLEADTIMESWILLAPPLY
0312") BUILTINALLGRILLWROTISS33BURNERSSEARZONELIGHTS     .! .! .!  .! 
03123") BUILTINGRILLWROTISS33BURNERSSEARZONELIGHTSSIDEBURNERS     .! .! .!  .! 
0312") BUILTINGRILLWROTISS33BURNERSSEARZONELIGHTS     .! .! .!  .! 
031:2") BUILTINGRILLWROTISS33BURNERSEARZONELIGHTS     .! .! .!  .! 
0312") BUILTINGRILLWROTISS33BURNERSLIGHTS     .! .! .!  .! 
"5),4).-/$%,   #//+).'!2%!).31). ! " # $ % & ' ( )
&
(
I
%
PSQ30RC Side
0312#


!
$
"
#
'
PSQ30RC Front
C38897.indd 11C38897.indd 11 10/24/06 3:25:06 PM10/24/06 3:25:06 PM

BUILT-IN DIMENSIONS
CUTOUT A B C D E F G H I J K L M N O
WIDTH 26-3/4" 23" 11" 50-1/2" 38-1/2" 28-1/2" 17-3/8" 14-3/8" 16" 16" 16" 27-1/2" 14-1/4" 37-3/16" 27-3/16"
HEIGHT 10" 7-1/2" 8-3/4" 8-3/4" 8-3/4" 8-3/4" 24-3/8" 20-3/8" 19" 13" 6-13/16" 17-1/2" 21-1/4" 20-1/4" 20-1/4"
DEPTH 19-1/2" 23-1/8" 24-3/4" 24-3/4" 24-3/4" 24-3/4" N/A N/A N/A N/A N/A N/A N/A N/A N/A
C38897.indd 12C38897.indd 12 10/24/06 3:25:08 PM10/24/06 3:25:08 PM

We fashion our products by selecting the highest quality stainless steel, the most
reliable components, and handcrafting each grill one at a time. Every item we create reflects
the utmost standards of engineering excellence and craftsmanship. It’s the reason why our products are
more durable, more proficient and in a class all their own.
the performance series family:
form and function like none other.
C38897.indd 13C38897.indd 13 10/24/06 3:25:08 PM10/24/06 3:25:08 PM

PSQ30RC
C38897.indd 14C38897.indd 14 10/24/06 3:25:16 PM10/24/06 3:25:16 PM

differences you can see, touch, taste and feel.
Unlike any other grill, the Performance Series speaks to the essence of pure outdoor
entertaining. We welcome you to our family, where the joy of improving the quality of your culinary life is
our number one priority.
C38897.indd 15C38897.indd 15 10/24/06 3:25:24 PM10/24/06 3:25:24 PM

NOTE:
C38897.indd 16C38897.indd 16 10/24/06 3:25:25 PM10/24/06 3:25:25 PM

Toll Free: 866.402.4600
www.capital-cooking.com
WARRANTY:
Capital provides a limited lifetime
warranty against rust on all 304
stainless steel components.
One Year Full Warranty (parts and labor)
covers the entire product, and a 5 Year
Warranty on infrared burners.
Due to ongoing product improvements,
these specifications may change
without notice.
Please check with your local dealer for
a complete line of Capital Performance
Series Accessories.
Made in the U.S.A.
