Caple VER100 Assembly instructions

Installation and
Care Guide
VER100
Contact Caple on 0117 938 7420 for spare parts or www.caple.co.uk

2Installation Guide VER100 Please keep this instruction manual for future reference
INSTALLATION GUIDE
Thank you for purchasing your Caple sink.
This sink have been manufactured with the finest quality stainless steel and inspected to exacting
standards and is guaranteed to give years of trouble free operation providing our care and installation
guidelines have been followed.
[01]
[02]
[03]
1
5
2
6
Place the sink upside down in the position where
it is to be installed, and trace the outline of the sink on the
worktop with a pencil.
Apply the seal tape around the under side of the edge of the
sink, being careful to lay it smoothly.
Draw another line 9mm inside the first line,
to mark the cut out area.
Place the sink into the worktop.
NOTE: Please see back page for care and maintenance instructions

Installation Guide VER100 3Please keep this instruction manual for future reference
20-25mm
25-40mm
3
7
4
Using the fixing clips provided, secure the sink to the worktop by clipping these into the brackets under the sink, and screwing
until the clip is tight against the worktop as shown.
The corners radius are to be 10mm. Cut a hole in the worktop following this second
inner line. Alternatively use the template provided
with the sink.
[01] x 1 [02] x 2 [03] x 12
CAUTION: SINK EDGES MAY BE SHARP, HANDLE WITH CARE

SINK MAINTENANCE TIPS – STAINLESS STEEL SINKS
-By following these maintenance tips, you can maintain the finish of your
stainless steel sink for longer:
-Scratching on the surface of sinks will occur over time through normal
usage. Scratches cannot be removed only made less noticeable by using
stainless steel polishing creams and cleaning products. The best form of
maintenance is frequent, regular cleaning. A little bit of cleaning on a
regular basis is preferable to a major clean on a sporadic basis.
-The best method of preventative maintenance is to ensure the sink is clean
and dry. Rinse and towel dry the sink after each use in order to minimise
major cleaning, keeping it shiny and relatively free of water spots.
-Keep the sink free of any standing water, which may build up mineral
deposits. The quality of your water can affect the sinks appearance and this
water quality will vary from household to household.
-To clean your sink use the mildest cleaning procedure that will do the job
effectively. Exercise extreme care with household cleaners in particular
detergents or bleaches.
-Always rinse the sink after using a cleaning agent and wipe the sink dry to
discourage water spotting.
-Metallic scouring pads and steel wool pads should not be used to clean
your sink or any utensils in the sink. They will not only scratch the sink but
also leave a residue of small iron particles, these may not be visible but
they will most certainly lead to rusting and corrosion on the sink surface.
-Do not leave any mild steel, cast iron cookware or implements anywhere on
the sink for extended periods of time. The combined presence of iron and
moisture with stainless steel leads to surface corrosion and sink staining.
-Do not leave wet sponges or cleaning pads in the sink overnight as they
will trap water which could lead to staining or discolouration of the sink
surface. The unique properties of stainless steel are dependent upon
exposure of the surface to the atmosphere.
-We recommend that you do not use chlorine bleach in your stainless
steel sink, as chlorine will attack the protective layer that makes stainless
steel truly stainless. Any drain cleaning products containing sulphuric or
hydrochloric acid will also attack the sink.
-For the occasional treatment of grime and mineral deposits that may build
up over time, use cleaning products specifically designed for stainless steel
following the manufacturer’s instructions.
-If rusting or spotting occurs it can easily be removed with the use of a
cutting compound, a soft scrubber (such as nylon or plastic) and a little
elbow grease.
STAINLESS STEEL SINK PRODUCT CARE AND CLEANING INSTRUCTIONS
-Always wipe the sink down with warm soapy water and a cloth.
This will remove general everyday stains from your sink.
-In hard water areas limescale deposits can build up on the sink over time.
The limescale can become strongly coloured by such foods as coffee and
red wine etc, we recommend the use of lemon juice or vinegar to remove
this. Simply apply, leave for a few minutes and rinse away with water.
-If stains become ingrained in the bowl, an overnight soak using diluted
biological washing powder should remove the marks easily. Ensure you
thoroughly rinse the sink with water afterwards.
-For further advise on cleaning products please contact our Customer
Service team on Tel: [phone] or email: [email protected]
-We recommend the use of baskets, grids and chopping boards to help
reduce the risk of accidental damage.
-You must not pour strong chemicals down the sink such as bleach,
ammonia, caustic soda, white spirit and sterilising solutions. If this should
accidentally happen, quickly wipe the spill away and rinse with plenty of
water.
-We do not recommend the use of a plastic washing up bowl, as particles
of grit which may be impregnated in the base of the bowl could scratch
surface of the sink.
-Do not chop food directly on the sink surface, as this will cause damage.
Wooden chopping boards are available for this purpose.
-Avoid dropping sharp objects into the sink, as this may scratch or damage
the surface.
-Leaving neat bleach in the sink can cause damage to all sinks even
stainless steel. If neat bleach should come into contact with this product,
please rinse thoroughly with warm soapy water.
LIFETIME SINK GUARANTEE
-Caple products are manufactured to the highest standard. Should any defect
in the material or construction arise within the guarantee period and in
the judgment of Caple or an authorised representative is agreed as being
defective, we will replace the product free of charge providing the item has
been used in a solely domestic application and fitted in accordance with
the installation instructions provided. The care and cleaning guides must be
observed at all times.
-Caple reserves the right to inspect any product reported to be defective prior
to replacement and Caple’s decision is final.
EXCLUSIONS
-Normal wear and tear or any damage or defect due to improper installation
or abuse of fitting or damage from misuse, negligence or accident.
-Consequential damage resulting prior to or as a result of agreement to
replace the product.
-Damage resulting from transportation.
-Accidental damage caused by foreign objects or substances.
-Damage or alterations carried out by third parties.
-Products installed in a commercial environment.
-Calls to put right incorrectly installed products.
-Use outside of designated markets.
-Labour and transport.
-Wastes.
CONDITION
-This guarantee applies to the original purchaser only and cannot be
transferred.
-The original installation was completed by a qualified tradesman.
CLAIMS
-A claim will only be recognised by Caple if accompanied by a copy of
invoice/receipt confirming the date and proof of ownership. This guarantee
is in addition to and does not diminish your statutory or legal rights.
PRODUCT IMPROVEMENT
-Due to our continued product development policy, we reserve the right to
modify product specifications and/or dimensions without notice.
-This guarantee is in addition to and does not diminish your statutory or
legal rights.
CAPLE GUARANTEES
-Sinks: Lifetime guarantee against
manufacturing defects
AFTER SALES SUPPORT
-Please contact your retailer, call Caple on
0117 938 1900, email [email protected]
or visit our website at www.caple.co.uk for
further product information.
In conformity with (EC)1935/2004
Caple
Fourth Way
Avonmouth
Bristol
BS11 8DW
EN 13310:2015
Kitchen Sinks
Cleanability
Durability
Pass
Pass
