Caple RBR7 User manual

Contact Caple on 0117 938 7420 for spare parts or www.caple.co.uk
Built-under Fridge with Ice Box
Instruction Manual
RBR7

2 3Instruction manual RBR7 Instruction manual RBR7Please keep this instruction manual for future reference Please keep this instruction manual for future reference
SAFETY INSTRUCTIONS
Read these instructions carefully and completely before
using your appliance. They provide you with important
information regarding the safe installation, use and
maintenance of the appliance as well as useful advice
for getting the best out of your fridge. Keep this booklet
in a safe place for future reference and pass on to any
future owner.
-This appliance is produced in accordance with all
applicable local and international standards and
regulations.
-This appliance is not designed for commercial use, it
is a household appliance only. It is not intended to be
used in:
› Staff kitchen areas in shops, offices and other
working environments.
› Bed and breakfast type environments.
› By clients in hotels, motels and other residential type
environments.
-This appliance may only be used by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, if
they are supervised whilst using it. They may only use
it unsupervised if they have been shown how to use it
in a safe manner. They must be able to recognise and
understand the dangers of misuse.
SAFETY WITH CHILDREN:
-This appliance can be used by children aged from 8
years and above.
CONTENTS
Warnings 3
Environmental Protection 11
Technical Fiche 11
Electrical Connection 12
Product Dimensions 13
Description of the Appliance 14
Using the Appliance 15
Operating your Fridge 16
Accessories 17
Food Storage 18
Cleaning and Maintenance 25
Defrosting 26
Replacing the LED light 27
Transport and Repositioning 27
Troubleshooting 28
Energy Saving Tips 30
Caple Contact Details 32

4 5Instruction manual RBR7 Instruction manual RBR7Please keep this instruction manual for future reference Please keep this instruction manual for future reference
-Children less than 8 years of age should be kept away
unless continuously supervised or they have been
shown how to use it in a safe manner. Children must
be able to understand and recognise the possible
dangers caused by incorrect operation.
-Children should be supervised in the vicinity of
the appliance.
-Never allow children to play with the appliance.
-Cleaning and user maintenance should not be carried
out by children without supervision.
-Children aged from 3 to 8 years are allowed to load
and unload refrigerating appliances.
-Materials used for packaging (nylon, staplers,
Styrofoam etc) may cause harmful effects to children,
they should be disposed of immediately.
-Children can injure themselves on an open door. Do
not let children sit on the open door, lean against it or
swing on it.
TECHNICAL SAFETY:
-Maintenance and repair work must be made only
by authorised Caple service technicians. Installation
and repair work that is carried out by unauthorised
technicians may endanger you.
-While the appliance is under warranty, repairs should
only be undertaken by a Caple authorised service
technician. Otherwise the warranty will be invalidated.
-It is dangerous to alter or modify the specifications of
the appliance in any way. The requirements for this
appliance are stated on the rating label.
-Risk of injury due to electric shock. Any contact with
live connections or tampering with the electrical
or mechanical components of the appliance will
endanger your safety and may lead to the appliance
malfunctioning.
-To maintain the efficiency and safety of your appliance,
we recommend you always use original spare parts
and to call only our authorised Caple Service agents in
case of need.
-Multi-socket adapters and extension leads should
not be used to connect the appliance to the mains
electricity supply.
-The electrical system of this appliance may be used
safely only when it is correctly connected to an
efficient earthing system in compliance with the safety
standards currently in effect.
-Insert the plug into a socket with an efficient ground
connection. If the socket has no ground contact or the
plug does not match, we recommend you consult a
qualified electrician for assistance.
-The appliance must be connected with a properly
installed fused socket. The power supply (AC) and
voltage at the operating point must match with the
details on the rating plate of the appliance.
-Consult a qualified electrician or service person if the
Grounding instructions are not completely understood,
or if you have doubts on whether the appliance is
properly grounded.
-The incorrect grounding may cause breakdown and
electric shock.

6 7Instruction manual RBR7 Instruction manual RBR7Please keep this instruction manual for future reference Please keep this instruction manual for future reference
-We do not accept responsibility for any damages that
occur due to ungrounded usage.
-If the socket does not match the refrigerator plug, it
must be replaced by the manufacturer, a service agent
or similarly qualified persons in order to avoid
a hazard.
-A specially grounded plug has been connected to the
power cable of your refrigerator. This plug should be
used with a specially grounded socket of 13 amperes.
If there is no such socket in your house, please have
one installed by an authorised electrician.
INSTALLATION WARNINGS:
-Prior to installation, ensure that the local distribution
conditions (electricity voltage and frequency) and the
requirements of the appliance are compatible.
-In order to avoid any hazards resulting from the
instability of the appliance, it must be fixed in
accordance with the following instructions.
-This appliance is not intended for use at altitudes
exceeding 2000m.
-During installation the appliance must be completely
disconnected from the mains electricity supply.
-Do not operate the appliance before it is fully installed.
-The appliance must be installed by an authorised
technician.
-Your appliance must be at least 50cm away from
stoves, gas ovens and heater cores, and at least 5 cm
away from electrical ovens.
-If your appliance is placed next to a deep freezer,
there must be at least 2cm between them to prevent
humidity forming on the outer surface.
-Do not cover the body or top of fridge freezer
with lace. This will affect the performance of your
fridge freezer.
-Clearance of at least 150 mm is required at the top
of your appliance. Do not place anything on top of
your appliance.
-Caple is not responsible for any damage that may
be caused by defective placement and installation by
unauthorised persons.
-When unpacking the appliance, make sure that it is not
damaged during transportation.
-Check the appliance for any damage.
-In the case of any defect; do not use the appliance and
contact your retailer or Caple Service immediately.
-WARNING: When positioning the appliance, ensure the
supply cord is not trapped or damaged.
-If the supply cord is damaged, it must be replaced by a
Caple service technician or similarly qualified persons
in order to prevent a hazard.
-Never touch the power cord/plug with wet hands.
This may cause a short circuit or electric shock.
-The plug must be accessible after installation.
-WARNING: Do not locate multiple portable
socket-outlets or portable power supplies at the rear of
the appliance.

8 9Instruction manual RBR7 Instruction manual RBR7Please keep this instruction manual for future reference Please keep this instruction manual for future reference
-Protect your appliance against atmospheric effects. Do
not expose it to effects such as sun, rain, snow etc.
DURING USE:
-Place drinks with high alcohol content vertically in
the fridge compartment and make sure their tops are
tightly closed.
-If you know you will not be using the appliance for a
while switch it off from the main supply and unplug it.
-WARNING: Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear of
obstruction.
-Do not place your appliance on a carpeted surface as
this will prevent adequate ventilation.
-When the appliance is not in use, we recommend you
turn it off, and isolate it from the electrical supply.
-This appliance must be used in the vertical position on
a flat surface.
-WARNING: Do not use electrical appliances inside
the food storage compartments of the appliance,
unless they are of the type recommended by the
manufacturer.
-The manufacturer will not be held liable for any
damages that might arise out of incorrect or improper
use of the appliance.
-Do not touch frozen goods with wet hands. Your hands
may freeze to the frozen food.
-Do not eat ice-cream or ice cubes immediately after
they are removed from the freezer compartment.
Frozen food can cause frost burn to the lips and
tongue.
-Do not re-freeze partially or fully thawed food. This
may cause health issues such as food poisoning.
Defrosted food may only be re-frozen after it has been
cooked.
-Do not place glass bottles or cans containing
carbonated drinks in the freezer compartment as they
will burst when the contents freezes.
-If using the appliance to quickly cool drinks, do not
leave bottles inside the freezer compartment for more
than 1 hour, otherwise they could burst.
-Two-star frozen-food compartments are suitable for
storing pre-frozen food, storing or making ice cream
and making ice cubes.
-One-, two- and three-star compartments are not
suitable for the freezing of fresh food.
CLEANING AND MAINTENANCE:
-Clean the appliance thoroughly before use.
-Always switch off the appliance from the mains
isolating the electrical supply before any cleaning
or maintenance.
-WARNING: Do not use mechanical devices or other
means to accelerate the defrosting process, other than
those recommended by the manufacturer.

10 11Instruction manual RBR7 Instruction manual RBR7Please keep this instruction manual for future reference Please keep this instruction manual for future reference
TRANSPORT:
-Always transport the appliance in its original packaging
and in an upright position.
-WARNING: Do not damage the refrigerant circuit.
-If your appliance uses R600a as a refrigerant (this
information will be provided on the label of the
appliance) you should take care during transportation
and installation to prevent the cooler elements from
being damaged. R600a is an environmentally friendly
and natural gas, but it is explosive. In the event of a
leak due to damage of the cooler elements, move your
appliance away from open flames or heat sources and
ventilate the room where the appliance is located for a
few minutes.
-Never use the door handles for lifting.
-The appliance is heavy and could cause injury, it must
be transported by two people.
DISPOSAL OF OLD APPLIANCE:
-Old fridges and freezers contain isolation material and
refrigerant with CFC. Therefore, take care not to harm
environment when you are discarding your old fridges.
-If your old fridge or freezer has a lock, break or
remove the lock before discarding it, because children
may get trapped inside it and may cause an accident
-Be careful to avoid damaging the pipework before
disposal, e.g. by puncturing coolant channels, bending
pipework, scratching the surface coating.
Symbol ISO 7010 W021
Warning; Risk of fire / flammable materials
7
RI5505 Fridge Freezer Instruction Manual.indd 7RI5505 Fridge Freezer Instruction Manual.indd 7 05/02/2020 14:3005/02/2020 14:30
Symbol ISO 7010 W021
Warning; Risk of fire / flammable materials
- The appliance is heavy and could cause injury, it must
be transported by two people.
DISPOSAL OF OLD APPLIANCE:
- Old fridges and freezers contain isolation material and
refrigerant with CFC. Therefore, take care not to harm
environment when you are discarding your old fridges.
- If your old fridge or freezer has a lock, break or remove
the lock before discarding it, because children may get
trapped inside it and may cause an accident.
- Be careful to avoid damaging the pipework before
disposal, e.g. by puncturing coolant channels, bending
pipework, scratching the surface coating.
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste. Please recycle
where facilities exist. Check with your Local Authority or retailer for recycling advice. This
appliance is marked according to the European directive on Waste Electrical and Electronic
Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused
by inappropriate waste handling of this product. The symbol on the product indicates that
this product may not be treated as household waste. Instead it shall be handed over to the
applicable collection point for the recycling of electrical and electronic equipment. Disposal
must be carried out in accordance with local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this product, please
contact your local council, your household waste disposal service or the retailer where you
purchased the product.
CE DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies with all
applicable legislation, Low Voltage Directive (LVD) and Electromagnetic Compatibility (EMC).
TECHNICAL FICHE
This appliance conforms to all current and applicable energy regulations. To view the Technical
Fiche that supports the energy labelling data, please visit the product page on our website
www.caple.co.uk

12 13Instruction manual RBR7 Instruction manual RBR7Please keep this instruction manual for future reference Please keep this instruction manual for future reference
ELECTRICAL CONNECTION
For your safety please read the following information
WARNING: THIS APPLIANCE MUST BE EARTHED.
This appliance operates from 220-240 volts and should be protected by a 13 amp fuse in
the plug.
The appliance is supplied with a standard 13 amp 3-pin mains plug fitted with a 13-amp fuse.
Should the fuse require replacement, it must be replaced with a fuse rated at 13 amp and
approved to BS1362.
If the mains plug which is fitted is unsuitable for the socket outlet in your home or is removed
for any other reason, please follow the instructions below on how to wire a 13amp 3 pin plug.
HOW TO WIRE A 13 AMP PLUG.
IMPORTANT
The wires in the mains lead on this appliance are
coloured in accordance with the following code:
Green and Yellow - Earth
Blue – Neutral
Brown – Live
As the colours may not correspond with the markings identifying the terminals in your plug
proceed as follows.
The green and yellow wire must be connected to the terminal in the plug which is marked with
the letter E or with the earth symbol or coloured green and yellow.
The blue wire must be connected to the terminal marked N.
The brown wire must be connected to the terminal marked L.
You must make sure the lead is firmly secured under the cord clamp.
Instruction manual RBF4
Please keep this instruction manual for future reference
26
ELECTRICAL CONNECTION
For your safety please read the following information
WARNING: THIS APPLIANCE MUST BE EARTHED.
This appliance operates from 220-240 volts and should be protected by a 13 amp
fuse in the plug.
The appliance is supplied with a standard 13 amp 3-pin mains plug fitted with a
13-amp fuse. Should the fuse require replacement, it must be replaced with a fuse
rated at 13 amp and approved to BS1362.
If the mains plug which is fitted is unsuitable for the socket outlet in your home or
is removed for any other reason, please follow the instructions below on how to
wire a 13 amp 3 pin plug.
HOW TO WIRE A 13 AMP PLUG.
IMPORTANT
The wires in the mains lead on this appliance are
coloured in accordance with the following code:
Green and Yellow - Earth
Blue – Neutral
Brown – Live
As the colours may not correspond with the
markings identifying the terminals in your plug
proceed as follows.
The green and yellow wire must be connected to the terminal in the plug which is
marked with the letter E or with the earth symbol or coloured green and yellow.
The blue wire must be connected to the terminal marked N.
The brown wire must be connected to the terminal marked L.
You must make sure the lead is firmly secured under the cord clamp.
GREEN/YELLOW
Earth
BROWN
Live
FUSE
13 Amps
BLUE
Neutral
Cord Clamp
RBF4 - Instruction Manual.indd 26 15/08/2018 09:52
PRODUCT DIMENSIONS
DIMENSIONS
548mm
min. 820-890mm
600mm
595mm
595mm
min. 550mm
812-882mm
min.25mm
715mm
100-170mm
NOTE:
Please refer to seperate installation sheet for details on how to install your appliance.

14 15Instruction manual RBR7 Instruction manual RBR7Please keep this instruction manual for future reference Please keep this instruction manual for future reference
USING THE APPLIANCE
› Before using your fridge, wipe all parts with a solution of warm water and a teaspoon of
sodium bicarbonate. Then, rinse with clean water and dry. Return all parts to the fridge after
cleaning.
› Remove all transport tapes and foam protection pieces. Clean the interior with a cloth
dampened in lukewarm soap and water. Rinse with clean water and dry.
› The adjustable front legs should be stabilised at an appropriate height to allow your fridge
to operate in a stable and proper way. You can adjust the legs by turning them clockwise (or
in the opposite direction). This should be done before placing food in the fridge.
› Your fridge may have an odour when it is operated for the first time. This is normal and the
odour will fade when your fridge starts to cool.
WARNING
Connect to the electrical socket but do not switch the power to the fridge on for at least 12
hours. The coolant within the product needs time to settle after it has been transported and put
into position, failure to do this will affect the cooling performance of your appliance.
DESCRIPTION OF THE APPLIANCE
This presentation is only for information about the parts of the appliance. Parts may vary
according to the appliance model.
Ice box
Freezer door
Open/Close indicator
Thermostat box
Freezer room door
Fridge light
Light
On/Off button
Fridge shelf
Crisper cover
Crisper
Egg holder
Butter cheese
shelf
Bottle shelf

16 17Instruction manual RBR7 Instruction manual RBR7Please keep this instruction manual for future reference Please keep this instruction manual for future reference
OPERATING YOUR FRIDGE
THERMOSTAT SETTING
IMPORTANT NOTE
Do not try to rotate knob beyond 1 position it will stop your appliance.
› The thermostat automatically regulates the inside temperature of the refrigerator
compartment and freezer compartment. By rotating the knob from position 1 to 5, colder
temperatures can be obtained.
› For short-term storage of food in the fridge and freezer compartment, you can set the knob
between minimum and medium position (1-3).
› For long-term storage of food in the fridge and freezer compartment, you can set knob
medium position (3-4).
› Note that; the ambient temperature, temperature of the freshly stored food, and how often
the door is opened, affects the temperature in the refrigerator and freezer compartments. If
required, change the temperature setting.
› When you first switch on the appliance, you should ideally try to run it without any food in
for 24 hours and not open the door. If you need to use it straight away, try not to put much
food inside.
› If the unit is switched off or unplugged, you must allow at least 5 minutes before restarting
in order not to damage the compressor.
SUPER FREEZING
For maximum freezing capacity, press this switch 24 hours before
placing food in the freezing compartment. In order to save energy,
please turn the switch Off 24 hours after placing food in the freezer.
Your fridge is designed to operate in the ambient temperature intervals stated in the standards,
according to the climate class stated in the information label. We do not recommend operating
your fridge out of stated temperatures value limits in terms of cooling effectiveness.
This appliance is designed for use at an ambient temperature within the 10°C - 32°C range.
ACCESSORIES
“DOOR OPEN” INDICATOR
› The “Door Open” indicator on the handle
shows whether the door has closed properly or
whether it is still open.
› If the indicator is red, the door is still open.
› If the indicator is white, the door is
properly closed.
› Observe that the freezer’s door should always be kept closed. This will prevent food
products from defrosting; it will avoid heavy ice and frost build-up inside the freezer and an
unnecessary increase in energy consumption.
ICE TRAY
› Fill the ice tray with water and place in freezer compartment.
› After the water has completely turned into ice, you can twist the tray as shown below to
release the ice cubes.
Instruction manual RBF4
Please keep this instruction manual for future reference
13
- When making ice cubes, fill the ice tray with water and place in freezer
compartment. After the water has completely turned into ice, you can twist the
tray as shown below to release the ice cubes.
Storage: If you want to use the maximum net capacity, you can remove the
drawers and store the items directly on the cooling tubes. This will enable you to
make use of the entire volume of the compartment.
CLEANING AND MAINTENANCE
-Disconnect unit from the power supply before cleaning.
- Do not clean the appliance by pouring water on it.
- The freezer compartment should be cleaned periodically using a solution of
bicarbonate of soda and lukewarm water.
- Clean the accessories separately with soap and water. Do not
clean them in the washing machine.
- Do not use abrasive products, detergents or soaps. After
washing, rinse with clean water and dry carefully. When the
cleaning operations have been completed reconnect the plug of
the unit with dry hands.
Instruction manual RBR6
Please keep this instruction manual for future reference
10
BEFORE USING YOUR FRIDGE
-When the appliance is situated for the first time or after
transportation, keep your fridge in the upright position for 12 hours
before connecting to the mains electricity. Otherwise, you may
damage the compressor.
-Your fridge may have a smell when it is operated for the first time;
the smell will fade away when your fridge starts to cool.
HOW TO OPERATE THE APPLIANCE
Thermostat setting
IMPORTANT NOTE:
Do not try to rotate knob beyond 1 position it will stop your appliance.
- The thermostat automatically regulates the inside temperature of the refrigerator
compartment and freezer compartment. By rotating the knob from position 1 to
5, colder temperatures can be obtained.
- For short-term storage of food in the freezer compartment, you can set the knob
between minimum and medium position (1-3).
- For long-term storage of food in the freezer compartment, you can set knob
medium position (3-4).
- Note that; the ambient temperature, temperature of the freshly stored food, and
how often the door is opened, affects the temperature in the refrigerator and
freezer compartments. If required, change the temperature setting.
- When you first switch on the appliance, you should ideally try to run it without
any food in for 24 hours and not open the door. If you need to use it straight
away, try not to put much food inside.
“Door Open” Indicator
Super Freeze Switch
CLIMATE CLASS AMBIENT TEMPERATURE
TBetween 16 and 43 (°C)
ST Between 16 and 38 (°C)
NBetween 16 and 32 (°C)
SN Between 10 and 32 (°C)

18 19Instruction manual RBR7 Instruction manual RBR7Please keep this instruction manual for future reference Please keep this instruction manual for future reference
FOOD STORAGE
REFRIGERATOR COMPARTMENT
› To reduce humidity and avoid the consequent formation of frost, always store liquids in
sealed containers in the refrigerator. Frost tends to concentrate in the coldest parts of the
evaporating liquid and, in time, your appliance will require more frequent defrosting.
› Never place warm food in the refrigerator. Warm food should be allowed to cool at room
temperature and should be arranged to ensure adequate air circulation in the refrigerator
compartment.
› Make sure no items are in direct contact with the rear wall of the appliance as frost will
develop and packaging will stick to it. Do not open the refrigerator door frequently.
› We recommend that meat and clean fish are loosely wrapped and stored on the glass
shelf just above the vegetable bin where the air is cooler, as this provides the best storage
conditions.
› Store loose fruit and vegetable items in the crisper containers.
› Storing fruit and vegetables separately helps prevent ethylene-sensitive vegetables (green
leaves, broccoli, carrot, etc.) being affected by ethylene-releaser fruits (banana, peach,
apricot, etc.).
› Do not put wet vegetables into the refrigerator.
› Storage time for all food products depends on the initial quality of the food and an
uninterrupted refrigeration cycle before refrigerator storage.
› To avoid cross-contamination do not store meat products with fruit and vegetables. Water
leaking from meat may contaminate other products in the refrigerator. You should package
meat products and clean any leakages on the shelves.
› Do not put food in front of the air flow passage.
› Consume packaged foods before the recommended expiry date.
NOTE:
Potatoes, onions and garlic should not be stored in the refrigerator. The table below is a quick
guide to show you the most efficient way to store the major food groups in your refrigerator
compartment.
To avoid contamination of food, please respect the following instructions:
› Opening the door for long periods can cause significant increase of the temperature in the
compartments of the appliance.
› Regularly clean surfaces that can come in contact with food accessible drainage systems.
› Store raw meat and fish in suitable containers in the refrigerator, so that it is not in contact
with or drips onto other food.
› If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry and
leave the door open to prevent mould developing within the appliance.
FOOD MAXIMUM STORAGE
TIME*
HOW AND WHERE
TO STORE
Vegetables and fruits 1 week Vegetable bin
Meat and fish 2-3 days
Wrap in plastic foil, bags, or in a
meat container and store on the
glass shelf
Fresh cheese 3-4 days On the designated door shelf
Butter and margarine 1 week On the designated door shelf
Bottled products
e.g. milk and yoghurt
Until the expiry date recommended
by the producer On the designated door shelf
Eggs 1 month On the designated egg tray
Cooked food 2 days All shelves
* These are guidelines only, always refer to the expiry date, or best before date recommended
by the producer.

20 21Instruction manual RBR7 Instruction manual RBR7Please keep this instruction manual for future reference Please keep this instruction manual for future reference
FREEZER COMPARTMENT
› The freezer is used for storing frozen food, freezing fresh food, and making ice cubes.
› To freeze fresh food, ensure that as much of the surface of the food as possible is in contact
with the cooling surface.
› Do not store fresh food next to frozen food as it can thaw the frozen food.
› Before freezing fresh food, divide it into portions that can be consumed in one sitting.
› Consume thawed frozen food within a short period of time after defrosting
› Never place warm food in the freezer compartment as it will thaw the frozen food.
› Always follow the manufacturer’s instructions on food packaging when storing frozen food.
If no information is provided food, should not be stored for more than 3 months from the
date of purchase.
› When purchasing frozen food, make sure that it has been stored under appropriate
conditions and that the packaging is not damaged.
› Frozen food should be transported in appropriate containers and placed in the freezer as
soon as possible.
› Do not purchase frozen food if the packaging shows signs of humidity band abnormal
swelling.
› It is probable that it has been stored at an unsuitable temperature and that the contents
have deteriorated.
› The storage life of frozen food depends on the room temperature, the thermostat setting,
how often the door is opened, the type of food, and the length of time required to transport
the product from the shop to your home. Always follow the instructions printed on the
packaging and never exceed the maximum storage life indicated.
› The maximum amount of fresh food (in kg) that can be frozen in 24 hours is indicated on
the appliance label.
› To use the maximum capacity of the freezer compartment, use the glass shelves for the
upper and middle section, and use the lower basket for the bottom section.
NOTE:
If you attempt to open the freezer door immediately after closing it, you will find that it will not
open easily. This is normal. Once equilibrium has been reached, the door will open easily.
IMPORTANT NOTE:
› Never refreeze thawed frozen food.
› The taste of some spices found in cooked dishes (aniseed, watercress, vinegar, assorted
spices, ginger, garlic, onion, mustard, thyme, black pepper, etc.) changes and they assume a
strong taste when they are stored for a long period of time. Therefore, add small amounts of
spices to food to be frozen, or the desired spice should be added after the food has thawed.
› The storage time of food is dependent on the type of oil used. Suitable oils are margarine,
calf fat, olive oil and butter. Unsuitable oils are peanut oil and pig fat.
› Food in liquid form should be frozen in plastic cups and other food should be frozen
in plastic or bags or containers. The table below is a quick guide to show you the most
efficient way to store the major food groups in your freezer compartment.

22 23Instruction manual RBR7 Instruction manual RBR7Please keep this instruction manual for future reference Please keep this instruction manual for future reference
VEGETABLES AND FRUITS PREPARATION MAXIMUM STORAGE
TIME (MONTHS)
String beans and beans Wash, cut into small pieces and boil
in water 10 - 13
Beans Hull, wash and boil in water 12
Cabbage Clean and boil in water 6 - 8
Carrot Clean, cut into slices and boil in
water 12
Pepper Cut the stem, cut into two pieces,
remove the core and boil in water 8 - 10
Spinach Wash and boil in water 6 - 9
Cauliflower
Remove the leaves, cut the heart
into pieces and leave it in water with
a little lemon juice for a while
10 - 12
Aubergine Cut into pieces of 2cm after washing 10 - 12
Sweetcorn Clean and pack with its stem or as
sweetcorn 12
Apple and pear Peel and slice 8 - 10
Apricot and Peach Cut into two pieces and remove the
stone 4 - 6
Strawberry and Blackberry Wash and hull 8 - 12
Cooked fruits Add 10 % of sugar to the container 12
Plum, cherry, raspberry Wash and hull the stems 8 - 12
MEAT & FISH PREPARATION MAXIMUM STORAGE
TIME (MONTHS)
Steak Wrap in foil 6 - 8
Lamb Meat Wrap in foil 6 - 8
Veal roast Wrap in foil 6 - 8
Veal cubes In small pieces 6 - 8
Lamb cubes In pieces 4 - 8
Minced meat In packaging without using
spices 1 - 3
Giblets (pieces) In pieces 1 - 3
Bologna sausage/salami Should be kept packaged even if
it has a membrane
Chicken and turkey Wrap in foil 4 - 6
Goose and duck Wrap in foil 4 - 6
Deer, rabbit, wild boar In 2.5 kg portions or as fillets 6 - 8
Freshwater fish (Salmon, Carp,
Crane, Catfish) After cleaning the bowels and
scales of the fish,wash and dry
it. If necessary, remove the tail
and head.
2
Lean fish (Bass, Turbot, Flounder) 4
Fatty fishes (Tuna, Mackarel,
Bluefish, Anchovy) 2 - 4
Shellfish Clean and in a bag 4 - 6
Caviar In its packaging, or in an aluminium
or plastic container 2 - 3
NOTE:
Thawed frozen meat should be cooked as fresh meat. If the meat is not cooked after defrosting,
it must not be re-frozen.

24 25Instruction manual RBR7 Instruction manual RBR7Please keep this instruction manual for future reference Please keep this instruction manual for future reference
CLEANING AND MAINTENANCE
Disconnect the unit from the power supply before cleaning.
Do not wash your appliance by pouring water on it.
Do not use abrasive products, detergents or soaps for cleaning the appliance. After washing,
rinse with clean water and dry carefully. When you have finished cleaning, reconnect the plug
to the mains supply with dry hands.
› Make sure that no water enters the lamp housing and other electrical components.
› The appliance should be cleaned regularly using a solution of bicarbonate of soda and
lukewarm water.
› Clean the accessories separately by hand with soap and water. Do not wash accessories in
a dishwasher.
› Clean the condenser with a brush at least twice a year. This will help you to save on energy
costs and increase productivity.
NOTE:
The power supply must be disconnected during cleaning.
MAXIMUM
STORAGE TIME
(MONTHS)
THAWING TIME AT
ROOM TEMPERATURE
(HOURS)
THAWING TIME IN
OVEN (MINUTES)
Bread 4 - 6 2 - 3 4-5 (220-225 °C)
Biscuits 3 - 6 1 - 1.5 5-8 (190-200 °C)
Pastry 1 - 3 2 - 3 5-10 (200-225 °C)
Pie 1 - 1.5 3 - 4 5-8 (190-200 °C)
Filo dough 2 - 3 1 - 1.5 5-8 (190-200 °C)
Pizza 2 - 3 2 - 4 15-20 (200 °C)
DAIRY
PRODUCTS PREPARATION MAXIMUM STORAGE TIME (MONTHS)
STORAGE
CONDITIONS
Packet
(Homogenized) Milk In its own packet 2 - 3 Pure Milk – in its own
packet
Cheese
- excluding white cheese In slices 6 - 8
Original packaging may
be used for short-term
storage. Keep wrapped in
foil for longer periods.
Butter, margarine In its packaging 6

26 27Instruction manual RBR7 Instruction manual RBR7Please keep this instruction manual for future reference Please keep this instruction manual for future reference
DEFROSTING
REFRIGERATOR COMPARTMENT
› Defrosting occurs automatically in the refrigerator compartment during operation. The water
is collected by the evaporation tray and evaporates automatically.
› The evaporation tray and the water drain hole should be cleaned periodically with the
defrost drain plug to prevent the water from collecting at the bottom of the refrigerator
instead of flowing out.
› You can also clean the drain hole by pouring half a glass of water down it.
FREEZER COMPARTMENT
The frost accumulated in the freezer compartment should be removed periodically (using the
plastic scraper provided). The freezer compartment should be cleaned in the same way as the
refrigerator compartment, with the defrost process being completed twice a year.
› The day before you defrost, set the thermostat dial to position “5”, to freeze the
food completely.
› During defrosting, frozen foods should be wrapped in several layers of paper and kept in a
cool place. The inevitable rise in temperature will shorten their storage life. Remember to
use these foods within a relatively short period of time.
› Set thermostat knob to position “.” or unplug the unit; leave the door open until
completely defrosted.
› To accelerate the defrosting process, one or more basins of warm water can be placed in
the freezer compartment.
› Dry the inside of the unit carefully and set the thermostat knob to position “5”.
REPLACING THE LED LIGHT
The LED light must be replaced by an authorised engineer or similar only. For more information
please contact Caple service - 0117 938 7420 or [email protected].UK
HOLIDAY
SHORT HOLIDAYS
Leave the freezer operating during holidays of less than three weeks.
LONG HOLIDAY
If the appliance will not be used for several months, remove all items and turn off the
appliance. Set the thermostat to “•” position, defrost and clean your freezer. To prevent odour
and mould growth, leave the door open slightly (blocking it open if necessary).
TRANSPORT AND REPOSITIONING
› The original packaging and foam may be kept for re-transportation (optional).
› Fasten your appliance with thick packaging, bands or strong cords and follow the
instructions for transportation on the packaging.
› Remove all movable parts (shelves, accessories, vegetable bins, and so on) or fix them into
the appliance against shocks using bands/tape when re-positioning or transporting.
› Always carry your appliance in the upright position.
Instruction manual RBR6
Please keep this instruction manual for future reference
13
DEFROSTING
Refrigerator compartment;
- Defrosting occurs automatically in refrigerator during operation; the defrost water
is collected by the evaporating compartment and evaporates automatically.
- The defrost water drain hole should be cleaned periodically with the defrost
drain plug removed to prevent the water from collecting in the bottom of the
refrigerator instead of flowing out.
- You can also pour ½ glass of water into the drain hole to clean inside.
Freezer compartment;
The frost, accumulated in the freezer compartment, should be removed periodically.
(Use the plastic scraper provided) The freezer compartment should be cleaned
in the way as the refrigerator compartment, with the defrost operations of the
compartment at least twice a year.
For this;
- The day before you defrost, set the thermostat dial to “5” position to freeze the
foods completely.
- During defrosting, frozen foods should be wrapped in several layers of paper and
kept in a cool place. The inevitable rise in temperature will shorten their storage
life. Remember to use these foods within a relatively short period of time.
- Set thermostat knob to position « . » or unplug the unit; leave the door open until
completely defrosted.
- To accelerate the defrosting process one or more basins of warm water can be
placed in the freezer compartment.
- Dry the inside of the unit carefully and set the thermostat knob to MAX position.
RBR6 - Instruction Manual.indd 13 15/08/2018 10:15

28 29Instruction manual RBR7 Instruction manual RBR7Please keep this instruction manual for future reference Please keep this instruction manual for future reference
TROUBLESHOOTING
BEFORE CALLING FOR SERVICE
Reviewing the information below may save you from calling for service.
THE APPLIANCE DOES NOT OPERATE CHECK IF:
› There is power to the unit
› The mains is connected
› The thermostat setting is on the “•” position
› The socket is defective. To check this, plug another working appliance into the same socket.
THE APPLIANCE PERFORMS POORLY CHECK IF:
› The appliance is overloaded
› The doors are closed properly
› There is any dust on the condenser
› There is enough space near the rear and side walls.
THE APPLIANCE IS NOISY
The cooling gas which circulates in the refrigerator circuit may make a slight noise (bubbling
sound) even when the compressor is not running. Do not worry, this is normal. If you hear a
different sound, check whether:
› The appliance is level
› Anything is touching the rear of the appliance
› Objects in the appliance are vibrating.
THE DOOR IS NOT PROPERLY OPENED OR CLOSED CHECK IF:
› Food packages preventing the door from being closed.
› Door compartments, shelves and drawers have been properly placed.
› The door seals are defective or torn?
› The refrigerator is standing on an even ground.
THERE IS WATER IN THE LOWER PART OF THE REFRIGERATOR CHECK IF:
› The drain hole for the water is not clogged (use defrost drain plug to clean the drain hole).
RECOMMENDATIONS
› If the appliance is switched off or unplugged, wait at least 5 minutes before plugging the
appliance in or restarting it in order to prevent damage to the compressor.
› The cooling unit of your refrigerator is located at the rear of the appliance. Therefore, water
droplets or ice may form on the rear surface of your freezer due to the operation of the
compressor at specified intervals. This is normal, there is no need to perform a defrosting
operation unless there is excessive ice.
› The appliance you have purchased is designed for domestic use only. It is not suitable
for commercial or common use. If the consumer uses the appliance in a way that does
not comply with this, we emphasise that the manufacturer and the dealer will not be
responsible for any repair and failure within the guarantee period.
If the problem persists or more help is required, please contact our Caple service team on
0117 938 7420 or via email [email protected].UK.

30 31Instruction manual RBR7 Instruction manual RBR7Please keep this instruction manual for future reference Please keep this instruction manual for future reference
ENERGY SAVING TIPS
1. Install the appliance in a cool, well ventilated room, but not in direct sunlight and not near a
heat source (such as a radiator or oven) otherwise an insulating plate should be used.
2. Allow warm food and drinks to cool before placing them inside the appliance.
3. Place thawing food in the refrigerator compartment. The low temperature of the frozen food
will help cool the refrigerator compartment while the food is thawing. This will save energy.
Frozen food left to thaw outside of the appliance will result in a waste of energy.
4. Drinks or other liquids should be covered when inside the appliance. If left uncovered,
the humidity inside the appliance will increase, therefore the appliance uses more energy.
Keeping drinks and other liquids covered helps preserve their smell and taste.
5. Avoid keeping the doors open for long periods and opening the doors too frequently as
warm air will enter the appliance and cause the compressor to switch on unnecessarily often.
6. Keep the covers of the different temperature compartments (such as the crisper and chiller)
closed.
7. The door gasket must be clean and pliable. Replace gaskets if worn.
NOTES

Caple Service
Fourth Way
Avonmouth
Bristol
BS11 8DW
T: 0117 938 1900
E: [e-mail]
www.caple.co.uk
