Car Black Box QT IR12 Wolf Eyes User manual

User manual
Product description
Product structure
1）UP button 2）MENU 3）DOWN button
4）USB interface 5）Camera 6）Speaker
7）OK button 8）MODE 9）Power button
10）Display screen 11）TF slot12）LED flash light
13）Bracket hole 14）Reset hole 15）MIC

Button and interface function description：
1）UP button
Short press on this button in standby and recording status can zoom out
digital.
Choose up function in MENU item
2）MENU button
Short press on this button to show function setting menu.
3）DOWN button
Short press on this button in standby and recording status can zoom in digital.
Choose down function in MENU option
4）USB data interface
Connect PC for Data transfer
Connect external power to charge battery or provide working power.
5）Camera
160°wide-angle Len；
6）Speaker
Video playback, voice monitor, operating sound warning
7）OK button
Confirmation button for video recording and taking photo;
In recording mode, press this button to start video recording, re-press to stop；
In photo mode, short press to take photo.
In menu mode means Confirmation button.
8）MODE
Short press on this button to shift among “photo mode-REC mode –playback
mode”
SOS function: short press this key to enforce saving the current video when
Video recording
9）POWER ON/OFF
Power switch: continuous press for power on/off, shortly press for flash light
on/off.

10）Screen
View window
11）TF slot
Slot for memory card
12）LED flash light
Night vision flash light which can be open by short press on “POWER”
button.
13）Bracket hole
Install vehicle bracket hole
14）Reset slot
Use this to restart when crash
15）MIC
Special function description
G-sensor function
When gravitational acceleration reach 6g(1g=9.80m/s), machine will save
present video as undeletable files
Automatic power on/off function
Support recording Start and shutdown synchronization with Auto and save the
video files After connect to the car power supply
Seamless loop recording, don’t leak second
SOS
Short press "M" to enforce saving the current video when video recording
REC/photo operation specifications
Power on/off
Long press on “power on/off” button to start, Indicator light will shine when
power on
Then long press again on “power on/off” button to shutdown and the indicator
light go out

Notice: video instrument will automatically power off after waning of low battery
REC mode
Short press on “M” button shift to REC mode, REC icon is on the top left corner
Short press on “OK” mode to start recording, flashing red dot on REC icon
indicate the recording is on the way
Photo mode
Short press on “M” button shift to photo mode, an photo icon is on the top left
corner
Then short press on “OK” button to take a photo, screen flash one time means
photo completed
Video/photo playback
Short press on “M” button, shift to playback mode, playback icon is on the top
left corner
Short press on key can choose files up
Short press on key can choose files down
Short press on “OK” button to play the selected video files
Menu setting
Short press on “menu” mode, enter video set status, and now the background
color is yellow in “video icon” column; then press “M” button again shift to set
status, the “set icon” column background is yellow.
In the setting items, press on keys can make shift up and down in sub
items, then press “OK” button to set sub items.
Short press on “MENU” or “MODE” button can exit the setting status.
Time settings
Short press “MENU” button to enter “setting status”, here short press on ‘menu”
button to set menu. Through keys to choose date time items, short
press “OK” to enter, short press on “OK” button can make shifts among
y/m/d/h/m/s.

Adjust figure through buttons, then press “OK” button to confirm
modification.
SOS
short press "M" to enforce saving the current video when video recording
USB mode
Separate USB cable and computer, press “power on” button, car DVR will automatically
show USB menu, two mode are available:
1：USB-Disk
In this mode we can access video files and photo files
2：PC-Camera
In this mode USB video equipment are shown, can take photo or make video chat
Battery instruction
Battery indication image：
Full battery slightly low battery low battery battery empty
There are three methods to charge, the red indicator light up when charging, the
entire charging time is about 180 minutes, and the red indicator light
automatically off when charging completed.
1. Use power adapter to charge
2. Use PC-USB to charge
3. Use car power to charge
Notice: Video instrument can only use 5V car power supply, or it may cause device
damage.
This products Car power can only be used in 12V/14V

Remark: when appear crash because of improper operation, we can remove battery or
press “reset” button to restart.
Products specifications
Features HD camera, HD video recording
G-sensor Built-in (car
accident case of emergency save, will not be
deleted)
LCD screen size 1.5LTPS
camera 160 A + grade high-resolution ultra wide-angle len
Language Russian, Japanese,
French, Italian, German, spanish, English,
Chinese (simplified), Chinese (Traditional), Korean, etc…
Files format AVI
Resolution Max 1080P
Recording video format M-JPEG
Color standard
Continuous loop video seamless loop recording, don’t leak second
Automatically power
on/off
Support auto ignition boot, turn off shutdown
Motion Detection
Function
support
Time synchronization Support (Y/M/D/H/M)
Carrier media Built-in memory ( total:32MB)
Photo mode 5million
Photo format JPEG
Memory card TF (max 32GB)
MIC Support
Built-in speaker Support
Infrared night vision Support

Video format PAL/NTSC
Current frequency 50HZ/60HZ
USB function 1：USB-Disk
2：PC-Camera
Power interface 5V 800mAh
Battery Built-in 240mAh
Trouble shooting:
For problems in normal operating situation ,please try these methods below:
Can’t take photo and recording
Check the if the TF card has enough space or locked
Automatically stop when recording
Use the compatible high-speed TF card with SDHC because of big HD video
data, the high-speed TF card have identifying of C4 and C6
Appear “files error” when replay photo or video
Uncompleted files because of TF card storage error, please use formatting
function to format your TF card
Unclear video
Checks if there are any dirt or fingerprint; and use lens paper to clear the camera
Len.
Black image when recording sky or water scene
Scenes with big contrast will influence the automatic exposure function of
camera; you can adjust “EV in setting mode to correct.
Color is not perfect in cloudy day and outdoor light
Set the “white balance” function to automatic
cross stripe interference in image
Because of wrong “light frequency”, please set it to 50Hz or 60Hz according to
the local power supply frequency
Crash
Restart by pressing shortly on” RESET” button after crash
