Carefree of Colorado RV SIDE-OUT SOKII Series Operating and safety instructions

052950-001r1 1 June, 2005
CAREFREE
SIDE-OUT CANOPY REPLACEMENT
RV Kits
These instructions are for canopy replacement only for
•SOKII W/DEFLECTOR OR FULL CASE;
•S
UMMIT;AND,
•A
&ESLIDE TOPPER
WARNING
THESE PROCEDURES DEAL DIRECTLY WITH THE PRE-WOUND SPRING TENSION IN THE ROLL BAR.FAILURE TO EXCERCISE CARE AND/OR
FAILURE TO FOLLOW THE INSTRUCTIONS CAN RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE.
SOKII CANOPY REPLACEMENT
REMOVING THE OLD FABRIC
1. Open the slide out room 10"-12".
2. Remove the screws and end caps from the pivot brackets and set
aside.
3. Remove the screws and deflector or full case and set aside.
4. Remove the fabric retaining screws from the awning rail. Do not
discard.
5. On the left side of the rollbar align the holes in the rollbar with the
holes in the pivot bracket inside the rollbar. It may be necessary
to rotate the rollbar to align the holes.
6. Insert the furnished 2 inch cotter pin through the holes. Insert the
pin as far as possible.
7. (See Figure 1) Grasp the roll bar and loosen the spring attach bolt on
the outside of the LH pivot bracket. Loosen only 2-3 turns, DO NOT
REMOVE. The rollbar can now spin freely.
NOTE: When rotating the roll bar the bolt may have a
tendency to tighten. Loosen as needed.
8. Unroll the fabric off of the roll bar by rotating the roll bar toward the
coach.
9. (See Figure 2) Holding or supporting the RIGHT end of the roll
bar; remove the attaching screws and remove the RIGHT pivot
bracket from the mounting bracket and roll bar and set aside.
10. Simultaneously slide the fabric to the right from the awning rail and rollbar.
INSTALLING THE NEW FABRIC
11. Check that the awning rail and roll bar grooves are clean. If necessary spread open the end of the awning rail slightly;
deburr the awning rail. Lightly spray the inside of the awning rail and roll bar grooves with a silicone lubricant.
12. Carefully insert the new fabric into the awning rail approximately 6 to 8 inches. The edge with the larger polyrod
goes into the awning rail.
13. Carefully insert the new fabric into the roll bar groove. The edge with the smaller polyrod goes into the roll bar.
14. Simultaneously slide the new fabric into the awning rail and roll bar until the fabric is centered in the roll bar.
15. Insert the right pivot bracket into the roll bar and mounting bracket. Secure with the screws removed previously.
16. Slowly roll up the fabric onto the roll bar. Ensure that the fabric is rolling straight. Adjust the fabric position as required.
17. After the fabric has been rolled up, tighten the spring attach bolt on the outside of the LH pivot bracket.
18. While firmly holding the rollbar remove the cotter pin. Slowly allow the spring to take up any slack in the material
and apply tension.
19. Replace the fabric retaining screws in the awning rail.
20. Install the defector or full case.
21. Install the end caps.
Fabric Retainer
Screws (2)
SOK2022
Cotter Pin
to Lock Spring
Roller Spring
Attach Bolt
Figure 1.
SOK2022a
RH Pivot Bracket
Pivot Bracket
Retaining Screws
(2 per bracket)
Figure 2.
Manual Compliments of
Northwest RV Supply
Printed From
http://www.nwrvsupply.com

Carefree of Colorado Side-Out Canopy Replacement
052950-001r1 2 June, 2005
SUMMIT CANOPY REPLACEMENT
REMOVING THE OLD FABRIC
1. Open the slide out room 10"-12".
2. Remove the fabric retaining screws from the awning rail. Do not
discard.
3. Remove the front cover.
3.1 For covers 14 feet and longer: Locate the latch lever at the
center of the cover. Using a screw driver or similar tool,
push the lever to the left and hold; carefully pull the center
of the cover out until the latch pin cannot engage the locking
channel.
3.2 Using a small pin through the lower access hole in one end
cover, press in the lower attach pin then pivot the cover until
the pin clears the hole. Repeat for other side.
3.3 Repeat steps 3.2 for the top retainer pins. Remove cover.
For early models with the ratchet latch inside the right end cap, go to step 4. For later models, go directly to step 5.
4. (Refer to Detail A) Remove the screw and latch retainer and set aside. Rotate the latch lever back and out of the way.
5. Insert a 3 inch cotter pin through the roll bar and spring on the right end of the roll bar. It may be necessary to twist the roll
bar to align the holes.
6. Remove the 1/4-20 x 3/4 socket head cap screw from the left end cap. Lift the left end of the roll bar and pull the roll
bar out of the right end cap.
7. Hold the rollbar and slide the fabric out of the awning rail.
INSTALLING THE NEW FABRIC
8. On a suitable work surface, unroll the fabric from the roll bar and slide the fabric out of the groove in the roll bar.
Make note of which end is left and right and the orientation of the fabric when it was rolled.
9. Carefully insert the new fabric into the roll bar groove. The edge with the smaller polyrod goes into the roll bar.
10. Slide the fabric into the roll bar until the fabric is centered. Roll the fabric onto the rollbar. Make sure that the
fabric rolls up straight.
11. Slide the polyrod and fabric into the awning rail. Center the fabric over the room.
12. Roll up the slack material onto the roll bar.
13. Slide the right end of the roll bar into the right end cap then set the left end of the roll bar into the left end cap.
Attach with the 1/4-20 x 3/4 socket head screw removed previously.
NOTE: On later units without the latch lever, the roll bar cogs engage a protrusion in the right end cap.
14. For early models with the ratchet latch:
•Rotate the ratchet latch to engage the cogs of the roll bar.
•Ensure the latch is fully engaged and attach the retainer using one #10 x 3/4 screw. The retainer mounts over
the latch.
15. Remove the cotter pin.
16. Reinstall the fabric retaining screws in the awning rail.
17. Install the front cover.
1/4-20 x 3/4
Screw SOK3011c
A
DETAIL A
Latch
Retainer
Spring
Locking Pin
Retainer Installed
Rachet Catch
Lever
Figure 4.
Access Holes
Spring Loaded
Attach Pin
SOK3005
Pin
Center Latch Pin
14’ or Longer Covers Only
Latch Lever
Fi
g
ure 3.
Manual Compliments of
Northwest RV Supply
Printed From
http://www.nwrvsupply.com

Carefree of Colorado Side-Out Canopy Replacement
052950-001r1 3 June, 2005
A&ETOPPER CANOPY REPLACEMENT
REMOVING THE OLD FABRIC
1. Fully extend the room out.
2. Firmly grasp the roll bar and twist toward the coach until
all the fabric is off the roll bar.
3. Align the holes in the roll bar end cap and the pivot bar
inside the roll bar. Insert a 3" cotter pin. Repeat for other
side.
4. Remove the fabric retaining screws from the awning rail.
If the A & E aluminum wrap is installed, spread open the
slat holding the fabric.
5. It will be necessary to trim or remove the sealing tape
around the rollbar where it covers the fabric slot.
6. The anti-billow lever is mounted on one side, if it is not
possible to move the fabric out the opposite side, it will
be necessary to remove the lever from the roll bar end.
7. Simultaneously slide the fabric out of the roll bar and awning rail (or aluminum wrap).
INSTALLING THE NEW FABRIC
8. Check that the awning rail and roll bar grooves are clean. If necessary spread open the end of the awning rail slightly and
deburr the awning rail. Lightly spray the inside of the awning rail and roll bar grooves with a silicone lubricant.
9. Carefully insert the new fabric into the awning rail approximately 6 to 8 inches. The edge with the larger polyrod
goes into the awning rail.
10. Carefully insert the new fabric into the roll bar groove. The edge with the smaller polyrod goes into the roll bar.
11. Simultaneously slide the new fabric into the awning rail and roll bar until the fabric is centered in the roll bar.
12. While firmly holding the rollbar remove the cotter pin. Slowly allow the spring to take up any slack in the material
and apply tension.
13. Ensure that the fabric rolls up straight. Adjust the fabric as required.
14. Replace the fabric retaining screws in the awning rail. If the aluminum wrap is installed, crimp the aluminum as
required.
15. If previously removed, reinstall the anti-billow lever.
Cotter Pin
to Lock Spring
SOK2023
Fabric Retainer
Screws (2)
Sealing Tape
Anti-Billowing Lever
Figure 5.
Manual Compliments of
Northwest RV Supply
Printed From
http://www.nwrvsupply.com
