Carico ULTRA TECH CLEAN MACHINE User manual

EN 2
CARICO'S COMPLETE SANITIZING SYSTEM INDEX
1 OVERVIEW OF CARICO'S COMPLETE SANITIZING SYSTEM page 03
2 LIST OF ACCESSORIES page 04
3 SAFETY page 05
3.1 Safety Instructions page 05
3.2 Safety Features page 07
3.3 Technical Data page 07
4 LIST OF FEATURES page 08
4.1 Exclusive features: ULTRA FILTRATION SYSTEMTM,
CARICONECT SYSTEMTM, CARICO'S SDPTM page 08
5 GETTING STARTED page 09
5.1 Vacuum function page 11
5.2 Preparing the Boiler (for steam cleaning, ironing &
humidification) page 11
6 OPERATION page 12
6.1 Vacuuming - Wet & Dry with Water filter page 12
6.2 Steam Cleaning & Disinfection page 12
6.3 Steam Cleaning & Vacuuming at the same time page 12
6.4. Aroma Therapy page 13
7 USAGE OF ACCESSORIES AND FILTERS page 14
8MAINTENANCE page 19
8.1 Filters page 19
8.2 CARICO'S SDPTM page 20
8.3 Cleaning of Flex Tube page 21
8.4 Descaling the boiler and electronic sensor page 21
9WARRANTY STATEMENT page 23
10 DISPOSAL INFORMATION page 24
11 TROUBLESHOOTING page 25
12 USE OF ACCESSORIES - CHART page 26
WARRANTY CARD

EN 3
1 - OVERVIEW
Dear Carico Customer,
Congratulations on the outstanding investment you made in you and your
family's health with your new CARICO COMPLETE SANITIZING SYSTEM. Carico
loves helping people improve their health, and we take pride in doing it. Carico
approaches each of its products with a craftsman’s attention to detail and
a passion for making the best possible product. This unique cleaning system
uses dry vapor steam to clean and sanitize your home faster, more efficiently
and more cost-effectively than any other product. It protects you and your
family’s health and saves you money by allowing you to stop using dangerous
household cleaning products.
This manual shows you how to properly use your CARICO COMPLETE
SANITIZING SYSTEM so that you can get the most out of it.
CARICO'S COMPLETE SANITIZING SYSTEM is 4 units in 1:
1. Vacuuming - Wet & Dry with Water filtration
2. Steam Cleaning & Sanitizing
3. Steam Cleaning & Vacuuming at the same time
4. Aroma Therapy
Carefully read this Manual before operating the machine. Please also note the
safety instructions given in the guide.
Visit www.carico.com for videos and additional information about your CARICO
COMPLETE SANITIZING SYSTEM and other Carico products.
Sincerely,
Richard R. Cappadona
Founder & CEO of Carico International Inc.
www.carico.com
WE ARE SURE THAT YOU WILL ENJOY YOUR NEW
CARICO COMPLETE SANITIZING SYSTEM!
What is Dry Vapor?
Dry Vapor
CARICO’S COMPLETE SANITIZING SYSTEM is a high temperature "vapor" steam
cleaner, meaning it has approximately 5-6% moisture content in its steam. Other
less efficient products on the market have a much higher moisture content.
Why is drier better?
The steam given off by water boiling at 212° F (100° C) contains a great deal of
moisture. If you hold your hand about 6 inches over a boiling pot on the stove,
your hand will immediately become saturated and you’ll likely burn yourself if
you continued to hold it there. This is an example of “wet steam”.
Hold your hand 6 inches from CARICO’S COMPLETE SANITIZING SYSTEM and
the vapor is actually cool across your hands because it superheats the steam,
meaning it's drier and the saturation level is less.
Increasing the heat of the steam creates drier, lower moisture steam as it nears
its gaseous state which is correctly termed "dry". Most other companies like to
talk about how many bars of pressure they create. But that is only one part of
the story. You need to know the temperature of the steam as it exits the hose.
The steam from CARICO’S COMPLETE SANITIZING SYSTEM kills most dust mites,
mold, viruses and fungi on contact and begins to evaporate almost immediately
on the surface. A surface cleaned by CARICO’S COMPLETE SANITIZING SYSTEM
is usually dry within minutes, if not seconds, which means mold cannot begin
to take hold. Other traditional steam cleaners produce “wet” steam, leaving
upholstery, floors and other surfaces wet, which creates an environment that is
hospitable to all the mold and fungus that the user had to get rid of in the first
place.

EN 4
2 - LIST OF ACCESSORIES AND FILTERS
ACCESSORIES  SEE PAGES:
Extension Tubes with Rapid-Lock ............................................................................. 10, 14, 26
Carrier for Accessories: Big Brush ............................................................................................ 10
Carpet Accessory ..............................................................................................................14-16, 26
Liquid Accessory ..............................................................................................................14-16, 26
Small Nozzle........................................................................................................................ 16 -17, 2 6
Small Round Brush ........................................................................................................... 16 -17, 26
Triangular Brush with Single and Triple Steam Jet......................................................17, 26
Duster Brush ..............................................................................................................................17, 26
Funnel for filling the Boiler Tank .............................................................................................. 17
Cobra Brush......................................................................................................................... 17-18, 26
Cobra Brush with Rubber Squeegee......................................................................... 17-18, 26
Cobra Brush with Bristles............................................................................................... 17-18, 26
Window Cleaner............................................................................................................................. 18
FILTERS:
Air Intake Filter..........................................................................................................................18-19
Polyester Filter ..........................................................................................................................18-19
Motor Intake Filter .........................................................................................................................20

EN 5
3.1 IMPORTANT SAFETY INSTRUCTIONS
Always follow basic safety precautions when using your CARICO COMPLETE
SANITIZING SYSTEM.
Carefully read these instructions as they provide important information
concerning how to install, use and care for your CARICO COMPLETE SANITIZING
SYSTEM.
• After removing the unit from the box, carefully check the unit
for any damage. Do not use the unit if it appears damaged. Properly discard
the packing material and keep it out of the reach of children. Use the Carico
Home Sanitizing System only for its intended use.
• Never aim the CARICO COMPLETE SANITIZING SYSTEM at
people or animals.
• While using the CARICO COMPLETE SANITIZING SYSTEM,
exercise care not to touch any of the stream jets from the accessories or hoses.
• Never aim the CARICO COMPLETE SANITIZING SYSTEM at electrical outlets
or boxes, or any other electrical devices. Do not use the CARICO COMPLETE
SANITIZING SYSTEM to clean TVs, computers, radios or other electronic
equipment which could suffer damage.
• The CARICO COMPLETE SANITIZING SYSTEM unit is equipped
with a hydraulically operated pressure relief valve and only an authorized
service personnel MUST service and/or replace it to prevent a safety hazard.
• The CARICO COMPLETE SANITIZING SYSTEM unit is equipped
with a high temperature safety cut-out and only an authorized service
personnel MUST service and/or replace it to prevent a safety hazard.
• To protect against a risk of electric shock, do not immerse the CARICO
COMPLETE SANITIZING SYSTEM in water or any other liquids.
•Always turn off the CARICO COMPLETE SANITIZING SYSTEM before plugging it
into or unplugging it from a wall outlet. Never pull the power cord to
disconnect it from the outlet; instead grasp the plug and pull to disconnect.
• Do not let the power cord touch hot surfaces.
• Wrap the power cord around the posts that are positioned in the rear of the
CARICO COMPLETE SANITIZING SYSTEM when not in use.
•Do not allow the power cord to rub against sharp edges; do not trap the power
cord between doors, windows or drawers.
• Do not operate the CARICO COMPLETE SANITIZING SYSTEM with a damaged
cord, plug, safety device, hose, trigger gun or if the Carico Complete Sanitizing
System was dropped or is damaged. Doing so voids any and all warranties.
For assistance or if you have questions, contact Carico at [phone]
for Customer Service or by email at: [e-mail].
• Keep away from children.
•Do not leave the CARICO COMPLETE SANITIZING SYSTEM on while unattended.
• Never overfill the water tank.
• High pressure hoses, connections and accessories are necessary to safely
operate this unit. Only use those hoses and accessories recommended by
Carico and never use the unit with any damaged hoses, connections
or accessories.
• Do not use this unit near explosives and/or flammable fumes.
• Keep ventilation slots free of dust.
• Never drop or insert any object into the ventilation slots.
• To prevent overheating, unravel the electrical cord completely.
• Do not operate where aerosol (spray) products are being used or where
oxygen is being administered.
•Never put your CARICO COMPLETE SANITIZING SYSTEM away while it is still hot.
•This product is intended for household use only. Follow all user instructions in
this manual.
• Handle might get hot during use.
• Do not freeze.
• When using the steam cleaner on an uneven surface ensure the machine is
blocked in place.
• Sound pressure levels do not exceed Lpa<71db (A).
• Each time the CARICO COMPLETE SANITIZING SYSTEM unit heats up from a
cold state, the air inside the appliance prevents the unit fom releasing dry
vapor. When the unit is ready, the steam indicator light turns blue. Then set the
3 - SAFETY
WARNING!
!
WARNING!
!
WARNING!
!
DANGER!
!
DANGER!
!
DANGER!
!

EN 6
CARICO COMPLETE SANITIZING SYSTEM knob to maximum and pull the
trigger on the handle for a few seconds to purge the air from the boiler.
• Only put water or Carico fragrances into the tank
Do not use this machine in the presence of flammable liquids.
Adequately instruct all operators on the use of this steam
cleaner.
RISK OF BURNS
This appliance produces steam at a very high temperature. The steam cleaner
and its accessories can get very hot. Always use appropriate precautions. Avoid
direct skin contact.
CARICO'S COMPLETE SANITIZING SYSTEM is a powerful tool so
use it with care. Certain surfaces, fabrics, materials and finishes are water and
heat sensitive and dry vapor can damage or discolor them. ALWAYS check with
the manufacturer of the surface or product you wish to clean before using dry
vapor. TEST a small, hidden surface to make sure the surface is suitable for use
with the CARICO COMPLETE SANITIZING SYSTEM. Use a minimal amount of dry
vapor on silicone joints and immediately dry.
DO NOT leave steam in one spot on any surface for any period of time with a wet
cleaning cloth/pad attached as this will damage the surface.
DO NOT use on unsealed wood, on wood or tile floors that are highly worn,
unfinished or have a wax or oil finish. CARICO COMPLETE SANITIZING SYSTEM
may damage surfaces treated with wax or no-wax floors.
ALWAYS use care when cleaning leather, synthetic fabrics, velvet or other
delicate, steam-sensitive materials. Follow the manufacturer's instructions. Color
test small, out of view area before using on the entire item.
DO NOT use the CARICO COMPLETE SANITIZING SYSTEM for any other purpose
than what is described in the instructions manual. In no event is Carico liable
for incidental or consequential damages to anyone, of any nature whatsoever.
Some states/provinces do not permit the exclusion or limitation of incidental or
consequential damages, so the above may not apply to you.
ELECTRICAL INSTRUCTIONS
To avoid a circuit overload, do not operate another high-wattage appliance
on the same circuit simultaneously with the CARICO COMPLETE SANITIZING
SYSTEM.
If an extension cord is necessary, only use a 15-amp rated cord
with a 3-prong grounded plug. Cords rated for less may overheat and cause
damage.
3-PRONG GROUNDED PLUG
The 110 volt version of this system features a 3-prong grounded plug. As a safety
feature, this plug will fit into a grounded outlet only one way. If the plug does
not fit fully into the power outlet, contact a qualified electrician. Do not attempt
to defeat this safety feature.
WATER INSTRUCTIONS
Your CARICO COMPLETE SANITIZING SYSTEM was designed for use with normal
tap water. To extend the life of this product, if the water is very hard where you
live, we recommend using half normal tap water combined with half distilled
water.
MAINTENANCE:
• Always follow the instructions and keep your appliance in good working
condition.
•Repairs must be performed only by an authorized Carico Service Center and in
accordance to national and local safety regulations. Unauthorized repairs
could cause injury or machine damage. Carico is not responsible for
unauthorized work.
DISPOSAL:
•At the end of its lifecycle, we recommend making the machine safe by cutting
off the power cord. Do so only after unplugging it from the power source! Do
not dispose of the machine as ordinary rubbish, but leave it with personnel
qualified to collect such material. In this way it will be properly disposed of and
recycled. This is a valuable aid for safeguarding our environment!
• Save these instructions for future reference!
WARNING!
!
WARNING!
!
WARNING!
!
CAUTION!
!
CAUTION!
!

EN 7
2
1
4
3
3.2 SAFETY FEATURES
3.2.1. Mechanical safety features:
•The safety pressure valve exit is located on the bottom of the machine, and
releases steam if the pressure inside gets too high. The steam is released
underneath the device to avoid harming anyone. The working pressure
in the boiler is 5.5 Bar (80 psi) and the safety valve will only open within a
range of maximum +2 Bar (29 psi).
•The unit has 2 INCOLOY 800 heat coils which are extremely resistant
to high temperatures and against limestone deposits.
•Intake and outtake air for the vacuum motor are kept in separate
directions to keep the motor cool.
3.2.2. Electric safety features:
•The boiler has a pressure sensor which guarantees that it maintains
pressure around 5.5 Bar (80 psi).
•The multi pin construction of the power cord means that by simply
inserting the plug, a special sequence ensures that electricity properly
passes the commands to the hose.
•If the sequence is correct, the unit will begin operating. If something is
wrong, the unit will not operate. A resistor in the command center
responds within a very small tolerance range that your accessory is
properly connected and will not recognize a foreign accessory or object.
•The self check takes approximately 7 seconds pass (delay) prior to
freeing the electric circuit.
3.3 TECHNICAL DATA
Data plate characteristics
WARNING! Make sure the technical data on the data plate matches that of
your electricity system.
TECHNICAL CHARACTERISTICS
Boiler Power (1050+1050 W) / (1000+750 W)
Motor Vacuum Power 1200 W Higher technology gives
same power as 1600 W motor but: Quieter, lower energy
consumption, higher reliability and higher air volume.
Steam Pressure
Steam Flow
Max. steam Temperature in the Boiler
Effective Air flow
Vacuum pressure
Time of heating after turning on the steam to reach
peak dry steam, just a few seconds with refill
Boiler Volume
Boiler Capacity
Recovery Tank Volume
Lengh of Flexible Tube (Hose)
Working Reach
Lengh of Power Lead
Working Noise
Safety heat insulation extension tubes:
Separate tubes for 1steam and 2vacuuming,
3 outer tube protects from burning and
isolates the electric part 4.
Safety features:
•Safety thermostat: 170 °C (338 °F)
•Boiler safety valve: 7 bar +/- 0.5 (101 psi +/- 7.2 psi)
•Extra-low voltage handle commands: 5 Volt
•Heat insulation in extension tubes
•Steam safety lock
Patented systems:
•ULTRA FILTRATION SYSTEMTM
• CARICONECT SYSTEMTM
• CARICO'S SDPTM
• RAIN SILVER SYSTEM (RSS)
• INTELLIGENT BOILER TECHNOLOGY
Product code: STM110 / STM220
• Weight: 9.7 kg (21.4 lbs)
• Size: 336x332x479 mm
230 VOLTS
2100 W
1200 W
5.5 Bar (550 kPa)
55 g/min
159 C / 318 F
23.51 l/sec
2290 mm H2O
4 min
0.8 Liters
0.5 Liters
1.2 Liters
2.0 M
8.0 M
5.0 M
71 DB(A)
120 VOLTS
1750 W
1200 W
5.5 Bar (550 kPa)
1.94 oz/min
318 F
23.51 l/sec
2290 mm H2O
6 min
0.21 Gallon
0.13 Gallon
0.32 Gallon
6.56 ft
26.24 ft
16.40 ft
71 DB(A)

EN 8
1 2
1
2
3
4
5
6
23 5 6
4 - LIST OF FEATURES
CARICONECT SYSTEMTM
Insert the hose with its connection into the CARICONECT SYSTEM™ socket at the
front of the unit and push the plug into the socket (Pict. 1). An audible alarm will
tell you that the hose was properly connected to the power.
The patented design of CARICO'S COMPLETE SANITIZING SYSTEM makes
the machine surprisingly easy to handle. The small front wheels and the hose
connection both swivel to allow you maximum freedom of movement and also
prevents the hose from wearing out. (Pict. 2).
Several features make CARICO'S COMPLETE SANITIZING SYSTEM your special
agent in the war against dirt and grime.
4.1 EXCLUSIVE FEATURES:
ULTRA FILTRATION SYSTEM, CARICONECT SYSTEMTM,
CARICO'S SIMPLE DESCALING PROCESS (SDP)TM
CARICO'S COMPLETE SANITIZING SYSTEM is equipped with the exclusive
ULTRA FILTRATION SYSTEMTM, a sophisticated system of filtration using
highly efficient nebulized water (cloud like) which captures even the finest
particles by binding them to the water particles which gravity then pulls into
the container.
Moreover, it has an environmentally aware 4-level filtering system: no more
paper bags to buy and then dispose of. As well as saving on operating costs,
CARICO'S COMPLETE SANITIZING SYSTEM also saves you time, as you do not
need to use any cleaning chemicals or dust bags, producing less waste.
➊CARICO'S COMPLETE SANITIZING SYSTEM vacuums any dust and dirt. ➋
Water is sprayed in a micro-sized mist that instantly bonds to dirt and dust
particles deep inside the CARICO’S COMPLETE SANITIZING SYSTEM removing
them from the air, and ➌ sucking them into the water tank. ➍- ➎The 4-level
lter system traps any remaining particles. ➏The air that comes out is clean,
fresh, and breathable.
Nebulization Clean airTrapped dirt
CARICO'S SDPTM See Chapter 9 - Maintenance

EN 9
1
2
5 - GETTING STARTED
IMPORTANT! Follow these instructions when using the CARICO COMPLETE
SANITIZING SYSTEM for the first time.
Make sure the power cord is not plugged in before you start any operation.
Lay the appliance on the floor and open the tank lid as shown in Pict.1 and 2.
For safety reasons, never vacuum any toxic or highly flammable substances,
explosives, embers or lit cigarettes, detergents, or foam of any kind. Do not use
the appliance to clean the chimney or to remove oily substances, which could
lead to serious danger and to a possible machine breakdown!
Fill the CARICO COMPLETE SANITIZING SYSTEM with soft tap water. Never
use demineralized/distillated water. Demineralized/distillated water is not
suitable for this appliance and its use can result in the product malfunctioning.
If tap water is hard, we recommend using a mixture of half tap water and half
distillated water in order to protect the device against excessive calcification.
Before you turn on the machine, open the flaps (Pict. 1 and 2), remove the top of
the bucket (Pict. 3 next page). Remove the tank (Pict. 5 next page) and fill it with
0.7 liters (0.18 gal) of cold water, paying attention that the level corresponds to
the mark printed on the separator (Pict. 4 next page).
Take off the boiler tank cap and fill the tank with about 0.9 liters (0.24 gal) water
(Pict. 6 overleaf). Close the tank lid and refasten it. Now you can plug in the unit.
If an extension cord is necessary, only use a 15 amp rated cord with a 3 prong
grounded plug. Cords rated for less may overheat and cause damage.
WARNING!
!
WARNING!
!
CAUTION!
!
CAUTION!
!
CAUTION!
!

EN 10
56
3 4
910
78
Water level
Hose and accessories fitting
Insert the hose into the CARICONECT SYSTEMTM socket at the front of the unit by
pushing it firmly. (See Chapter 4.1: Patented Features, CARICONECT SYSTEMTM).
To clean floors, insert the desired accessory onto the special extension tube
(Pict.7) by using the proper fit/release button (Pict. 8) and then connect to the
grip handle by simply pressing them together.
When the hose is attached and the unit is connected to a power source, the blue
steady light will light up, to signal that the machine is powered.
The tank lid fasteners are designed so that if they are hit when open, they will
not damage. They might come apart, but it is very easy to put them back into
place, by fitting the forks onto the support pins (Pict. 9).
Your CARICO COMPLETE SANITIZING SYSTEM comes with 2 tube-carriers on
each side of the device in which you can insert the extension tubes so they can
stand free whenever you need your hands free for something else (refill the
boiler-tank, move furniture around, etc.), (Pict. 10).

EN 11
12
12
11
5.1 VACUUM FUNCTION
Once the hose is properly attached, start the vacuum function by pressing the
motor push button (A), the blue light will come on to signal that the motor is set
on medium speed ( Pict. 11). To start the motor, press the speed button (Pict. 12)
on the hose grip handle. To change motor speed, press the button and keep it
pressed until you feel the speed change, and then release.
To switch off the motor, press and then quickly release the motor push button.
Water Level
Steam
Connection Motor Push
Button
B. A.
Speed Button
Steam Power Button
5.2 PREPARING THE BOILER FOR STEAM CLEANING
AND SANITIZING
To use the steam function, press the steam function button to switch on the
boiler (Pict.11).
The steam blue light will start flashing, to signal that the boiler is building up
pressure. As the right pressure is reached, the flashing blue light becomes
steady, and steam is ready to use.
Insert the desired cleaning accessory directly into the hose grip handle or with
one or more extension tubes in between. To deliver steam, just push the steam
power button on the handle (Pict. 12).
To avoid involuntary release of steam, lock the steam lever by pushing the
steam safety lock towards the "Closed" position.
A blue water level light means the boiler is out of water.
Fill the tank with water (see Pict. 6), then press the button twice - once to
disable the warning and twice to re-enable the function.
Steam Safety Lock
CAUTION!
!

EN 12
1a 1b
6.1 VACUUMING  WET & DRY WITH WATER FILTER
Only vacuum non-flammable liquids such as water and
spilled beverages. Always clean the unit after using per the instructions
below.
To vacuum up liquids, you can begin with an empty tank!
If you need to vacuum large amounts of water use either medium speed
or maximum speed. The appliance can suckup up to 1.2 liters of liquid.
In excess of this quantity, the electronic safety switch is enabled making
a noise and the motor noise becomes more acute. At this point, turn the
vacuum function off immediately and empty the water tank before using.
Fill the water tank as described in Chapter 5 to vacuum solids or a mix of solid
and liquid waste. Choose the best accessory for the job. See Chapter 7.
To change vacuum power, hold the vacuum speed button on the grip (Pict.1a)
until the desired level is reached. If you are vacuuming dust or other kinds of
dirt, replace the tank water frequently.
Vacuuming
Follow the instructions above and then choose the accessory best indicated for
what it is you want to do (Section 7). Turn on and choose the desired speed.
Use the lowest speed for delicate materials and medium or high speed for most
other jobs.
Vacuuming liquids only
If you want to vacuum liquids, such as spilled water, there is no need to add
water first. You can start vacuuming directly. For best results use the following:
Medium speed - large amounts of liquids (e.g. a siphon).
High speed - small amounts of liquids.
Intelligent Boiler Technology (IBT)
The Carico Sanatizing System is the only unit available with IBT. IBT manages
power use between the steam and vacuum to save electricity and time. With the
steam function off, the vacuum has three (3) speeds. When the steam function is
on, the system has two (2) speeds.
6 - OPERATION
6.2 STEAM CLEANING & SANITIZING
Once the necessary boiler pressure is reached, the flashing blue light becomes
steady, and the steam function is ready to use. Insert the desired cleaning
accessory directly into the hose grip handle or with one or more extension tubes
in between. To deliver steam, just pull the steam power button on the handle
(Pict. 1a). To get the best steam output and turn vacuum off, start with the steam
regulator (Pict 1b) at minimum (-), then slowly turn up (towards +) until you
reach the perfect steam-pressure for your work. For further instructions see
Chapter 7 Accessories & Filters.
6.3 STEAM CLEANING & VACUUMING AT THE SAME TIME
When operating the steam and vacuum functions together you must FIRST
heat the boiler and do some steam cleaning in order to heat up the Flex Tube,
the Extension tubes and the accessory you are using. Only when the device is
fully heated (i.e., the blue light stays on) should you add the vacuum-function
to the steam function.
Speed
Button
Steam Power Button
WARNING!
!
CAUTION!
!
Steam Regulator

EN 13
2
3
6.4 AROMA THERAPY
The quality of the air we breathe is certainly one of the most important factors
affecting our health and well-being. With CARICO'S COMPLETE SANITIZING
SYSTEM you can add a few drops of Carico's Aroma Fragrance to the water in
the water tank when vacuum cleaning. You can now enjoy the fragrance and
invigoration of aroma therapy while working and for many hours afterward.
Aroma therapy:
•Open the tank lid and take out the purification tank (Pict. 2).
•Make sure the tank is clean.
•Refill the tank with clean water, as described in Chapter 6,
adding 1 liter (0.26 gal) of water.
•Add a few drops of Carico approved concentrated fragrance to the
water (Pict. 2). Only use Carico approved fragrances. Using any other product or
oil will damage the plastic parts.
•Reassemble the purification tank and the lid.
•Plug in. Switch on the appliance at low or medium speed, by pressing the
motor button once.
•Pure and perfumed air will come out of the grill at the back, quickly
refreshing all rooms in the house, and getting rid of stuffiness and bad
odors. (Pict. 3).
Only put water in the boiler. Do not put fragrances or any other
chemicals in the boiler.
Boiler Tank
WARNING!
!
CAUTION!
!

EN 14
22.1
11b 1c
2.2
abc
2.1
7 - ACCESSORIES AND FILTERS
7.1 EXTENSION TUBES
Your unit comes with two extension tubes with rapid lock system allowing you
to choose the desired length. They are thermally insulated to protect against
scalding.
One of the wands has an adjustable handle to make it easier to use (Pic 1b). If
you are right handed or left handed, you can adjust the handle to the side that
suits you. (Pic 1c). You can also adjust the height of the handle by loosening the
handle and sliding the tube up or down to the desired position.
Max length 3.0 m. (9.8 ft), includes hose and both extension tubes.
7.2 BIG BRUSH
Reliable and robust, it is suitable for any kind of floor surface. This multipurpose
brush is supplied with other attachments to give you the best cleaning results
on every kind of surface:
7.2.1 CARPET ACCESSORY WITHOUT BRISTLES (Steam, Vacuum or Steam
& Vacuum)
7.2.2 LIQUID ACCESSORY (Steam, Vacuum or Steam & Vacuum)
Choosing to use steam only, vacuum only or both, will tell you which of the brushes
you should use for cleaning: for stubborn dirt (2.1 & 2.2), use steam and afterwards
vacuum.
For quick, light cleaning or to dry vacuum use (2, 2.1 & 2.2).
Simply snap the desired brush into place (Picts. A - C). The brush is equipped with
four handy grippers to attach a cloth if required. It also has a slider for locking the
joint. The swivel joint allows for easy use even in tight spaces (e.g. underneath
furniture).
USEFUL TIPS
How to use the Carpet Accessory 7.2.4
The side intakes on the brushes provide excellent vacuuming, even along
walls or in corners. Use it to vacuum or steam clean (use both together on
smaller surfaces without heavy dirt). To avoid scratching a delicate surface,
attach a clean micro fiber cloth to the brush. Always clean one piece at a
time, first passing with low steam to loosen and trap the dirt in the cloth if
required and afterwards pass again quickly with the vacuum. This will leave
the surface clean and dry. Rinse your cloth as you need and continue or use
clean dry cloths.
How to use the Liquid Accessory 7.2.5
Quickly clean up spills and puddles from the floor with the liquid accessory
(Pict 2.1). You can also use this accessory on tiles and non delicate floors
to first steam a patch of floor, also using the maximum steam output, and
then vacuuming up (do not steam while vacuuming except on small and
almost clean surfaces, because most of the steam is sucked up before it can
penetrate the dirt or kill micro-organisms).
Use the rear bristles on the brush itself to soften and remove heavy dirt and
grime if necessary.

EN 15
2.2
ATTENTION
Parquet and other delicate floor surfaces
When steam cleaning parquet or other delicate floor surfaces, check with the
manufacturer if it is suitable for steam cleaning. Use only a small amount of
steam to avoid causing damage. Always test in a discreet, small area before
doing the entire surface. Work on a small area out of the way in order to see
how the parquet reacts to steam cleaning. Do not place the brush directly
on the wooden surface but kept at a distance. See how the wood reacts.
There are many different types of parquet and each may react differently. If
the surface has no negative reaction from the steam, then you may slowly
start working with the brush on the floor and slowly add more steam, always
keeping in mind that the parquet may not show negative sign of reaction to
the steam right away.
If you find resistant dirt, work the localized area with steam in order to soften
the dirt until it can simply be removed.
Give the dirt time to soften or liquefy prior to removal. After following
these steps you can now easily vacuum up the dirt by tilting the brush
back to the parallel position.
How to use the floor accessory with bristles
Use for vacuuming all delicate surfaces such as parquet where you wish to
avoid scratches from the rougher profile of the Carpet Accessory 7.2.1.
Use brushes to loosen dust and dirt before vacuuming. Use it on tiles to
remove dust and light dirt. Always use delicately and without any liquid on
the floor so that the bristles stay clean and do not wear down quickly. Do
not use to scrub.
ATTENTION! Never attempt to use this accessory with steam!
GENERAL USE
Very dirty surfaces
First use an attachment with the bristles without steam to remove most of
the dirt, then use the steam, allow the steam time to dissolve the dirt. Lastly,
turn on the vacuum and go over the surface by tilting the brush forward,
drying and vacuuming the dirt.
Medium dirty surfaces
Operate with both steam and vacuum (depending on the accessory used;
remember to heat up the unit first to deliver perfect steam), then turn off the
steam. The brush must always be tilted forward (to facilitate vacuuming). After
finishing work, do not stop the vacuum immediately, to allow the dirty water
still inside the tube and hose to reach the recovery tank. Tilt the brush face up to
avoid any dripping.
Carpets and rugs
Attention – always thoroughly vacuum your carpet or rug before using
steam to avoid any dirt getting moist and sinking deeper into the carpet. The
appliance can clean and disinfect any kind of carpet or rug with the exception
of long-haired rugs, these will tend to close the water jets and lead to bad
filtration. With rugs made of sheep's wool please test on a small section
before steam cleaning the whole rug, the heat may cause a change of color
in the wool or lead to shrinking. Steam cleaning will revive color, restore the
original thickness and eliminate impurities from the carpet bottom layer. If
your carpets and rugs are dusty on top, start by using the big brush with
vacuum only. After vacuuming, use the appliance with simultaneous action
(steam+vacuum), according to the same procedure recommended for
medium dirty surfaces. With particularly stubborn and crusty stains, we
recommend the use of 1 Hole Dress-Fit (8.3) + Brush (7.3.2).
If you want to pre-treat a spot, use only natural, safe products.
CAUTION!
!

EN 16
33.1
3.33.2
2.4
7.3 CARRIER FOR ACCESSORIES: DRESSFIT SINGLE JET
7.3.1 SMALL NOZZLE (Also fits on Dress-fit triple jet 4)
7.3.2 STAINLES STEEL BALLS
7.3.3 SMALL ROUND BRUSH
Use the Dress-Fit Single Jet (Pict. 3) on its own or with a brush (place it on the
nozzle and push until it holds) to remove grease, or with vacuum nozzles, to
suck up grease or dust when using with vacuum. Use Small Nozzle (3.1) for
a specific area. It is particularly recommended to clean and to remove grease:
•Between tiles
•Inside and outside ovens and grills
•Steel or enamel sinks
•Wash basin, bidet, toilet, shower, bath
•Taps and fittings (to remove scale)
First treat the area with steam.
Stop the steam and switch to vacuum with the nozzle.
For cleaning radiators: use steam, the dust will fall on the floor which you can
then vacuum.
For doors/windows frames: place a clean micro fiber cloth on the edge of the
frame and tilt the Dress-Fit nozzle while operating steam; position the cloth so
it gathers the dirt.
For cleaning the toilet: use steam on the edge where water descends from, to
remove scale. (See also 7.9)
Adding a cloth
Use a clean micro fiber cloth on the brush when you clean
delicate materials with steam, fabric surfaces, delicate surfaces like parquet or
marble, or when you want to dissolve and spread wax. (Pict. 2.4).
CAUTION!
!

EN 17
7
1
7.1
2
7. 2
3
44.1
5
6
7.7 COBRA BRUSH: Used in conjunction with:
7.7.1 COBRA BRUSH SQUEEGEE
7.7.2 COBRA BRUSH ACCESSORY WITH BRISTLES
7.7.1 COBRA BRUSH WITH SQUEEGEE (Pict. 7 & 7.1)
For spilled liquids, cleaning glass surfaces of all kinds with steam as well as
smooth surfaces which are heat resistant, in the kitchen, on counter tops, on
stainless steel and tiles.
7.7.2 COBRA BRUSH ACCESSORY WITH BRISTLES (Pict. 7 & 7.2)
For cleaning armchairs, sofas, coats or vacuuming dust off uneven surfaces. Very
good for cleaning in the car.
How to attach the squeegee and bristle attachment: Tilt desired attachment so
that you can slide the corresponding end of the Cobra brush into it. Make sure
the tab is facing the back of the Cobra Brush. (Pict. 1). Rotate the attachment
(Pict. 2) and snap it into place (Pict. 3).
7.7.3 LARGE COBRA BRUSH (Optional)
An optional Large Cobra Brush is available. The Large Cobra Brush is more than
double the size and is perfect for sanitizing a large areas, such as floors, windows
and mattresses. It comes with the same attachments as the regular Cobra Brush.
7.4 TRIANGULAR BRUSH (Pict. 4.1, Optional)
Use this special brush with the Dress-Fit Single Jet (Pict. 4) to reach difficult and
awkward places.
7.5 DUSTER BRUSH (Pict. 5)
Removes dust from contoured or irregular surfaces. Use this brush on sensitive
and delicate surfaces.
NOTICE: Property Damage Risk. Do not use Duster Brush on television screens.
Failure to follow these warnings may result in property damage.
7.6 FUNNEL (Pict. 6)
This is a useful accessory for refilling the boiler with water through the refill tank.

EN 18
1
2
8
3
4
FILTERS
2. POLYESTER FILTER
CARICO'S COMPLETE SANITIZING SYSTEM has a
washable polyester filter. Keep the filter clean
(See Chapter 8 for cleaning instruction) and
ready for maximum performance and inspect
it monthly. The Polyester lter at the rear air-
outlet is designed to trap particles, catching
anything that escaped the previous lter(s).
The Polyester lter also makes the CARICO’S
COMPLETE SANITIZING SYSTEM one of the most
silent appliances in its class, in the world (Pict.2).
1. AIR INTAKE FILTER
The Air Intake Filter function designed to prevent
particles from carpets, dust or dirt present in
the air from reaching and damaging the motor
(Pict.1).
7.8 WINDOW CLEANING
Window, glass or smooth surface cleaning is easy using the Cobra Brush with
the squeegee.
In winter, pre-heat the windowpanes using steam, at a 3 to
4 inch distance, before proceeding with any cleaning operation. Operate
the two functions, steam and vacuum, at the same time by slightly tilting the
window cleaner and moving down the window edges.
7.9 TOILET BOWL CLEANER (Pict. 8)
Sanitizing toilet bowls is easy using the long stainless steel power nozzle.
3. MOTOR INTAKE FILTER
The Motor Intake Filter prevents various
particles (from carpets, dust or dirt present in
the air) from reaching the motor. It also filters
the motor cooling air, a unique function found
only with CARICO’S HOME SANITIZING SYSTEM
(Pict. 3).
4. UPPER LID FILTER
The Upper Lid Filter prevents any particle not
completely filtered by water from reaching
the motor (Pict.4).
CAUTION!
!

EN 19
1
3
2
8 - MAINTENANCE
After intense use (or at least once every six (6) months) check all filtering
elements. Clean the appliance's outer surfaces with a cloth. Should the
appliance fall or overturn, switch off immediately and disconnect from the
power. If the machine comes in contact with water, dry it with a dry cloth and
wait a few minutes before switching on again. Do not put away the appliance
while the tank still contains dirty water, which may cause bad smells from mold
and encrustations forming inside the tank.
Do not direct jets of water or high pressure steam at the appliance to
clean it! (even when disconnected from the power)
IMPORTANT! Before carrying out any type of maintenance, turn the
machine off and disconnect from the power.
8.1 FILTERS
Immediately replace any filter if you notice any damage to them! Contact
your authorized Carico Service Center for new filters.
Do not use the appliance until all filters are perfectly dry.
Using a damp filter could damage the appliance. If stains or mold appear
on the filters, replace them with new ones from an authorized Carico Service
Center. The life of this filter is strongly influenced by how much the appliance
is actually used.
AIR INTAKE FILTER
The air intake filter keeps particles from reaching the motor. Check the
efficiency of filter when you are cleaning the purification tank.
To do this, remove and rinse the filter
repeatedly, separating it from the cover
and the machine body (Pict.1). Use small
pliers (eyebrow tweezers will do). Wash
the filter element with plenty of cold
water. Do not leave the filter to dry on
heaters or radiators!
If stains or mold appear on the filter
surface, replace them with new ones, from an authorized Carico Service Center.
The life of this particular component is strongly influenced by how much the
appliance is actually being used.
POLYESTER FILTER
To keep the filter clean and ready for maximum performance, inspect it
monthly.
To inspect the filter:
1) Remove the exhuast filter cover, at the back of the CARICO COMPLETE
SANITIZING SYSTEM B (Pict. 2). The polyester filter is fitted inside. Lay the
exhaust filter cover, on the floor and extract the filter as shown (Pict. 3).
2) Check the filter; if there are traces of dust or dirt, wash with plenty of warm
water to remove.
3) Allow the filter to dry naturally (not on radiators or heaters).
Do not use the appliance until the filter is perfectly dry. Use of a damp
filter could damage the appliance.
4) After cleaning, put the filter back into place and reassemble the cover,
making sure to properly fit the exhuast filter cover hooks
onto the slits on the appliance body. Once the filter cover is in place,
rotate it upwards for the final fixing with the stopping tongue.
Replace the polyester filter if torn or damaged.
CAUTION!
!

EN 20
75
8
6
9
1210 11
FILTER REPLACEMENT:
Air Intake Filter: Replace yearly or earlier according to condition.
Polyester Filter: Replace yearly or earlier according to condition.
Motor Intake Filter: Replace yearly or earlier according to condition.
Low Noise Filter: Replace yearly or earlier according to condition.
Upper Lid Filter: Replace yearly or earlier according to condition.
8.2 CARICO'S RSSTM
After each use, clean the purification tank which is all that is required for
maintaining CARICO'S COMPLETE SANITIZING SYSTEM efficiency. When you
are done cleaning, empty the liquid waste of the purification tank as shown in
Pict. 10 and rinse thoroughly.
The CARICO COMPLETE SANITIZING SYSTEM has two nebulizers (Pict. 12). The
nebulizers include silver rings which inhibit the growth of bacteria and odors
in the tank.
To make this operation easier, remove the divider inside the tank (Pict. 11).
Remove the nebulizers (Pict. 12). Rinse tank, divider and nebulizers with hot
water until all residues and stains on the tank walls are removed.
When you take off the divider, make sure to put it back correctly into the proper
guides with its curved side facing forwards and upwards and that it touches the
bottom (otherwise it won’t slide in). Please be careful, these are delicate pieces.
If one gets broken or lost, immediately obtain a spare part from an authorized
Carico Service Center. Do not use the CARICO'S COMPLETE SANITIZING SYSTEM
without it. Allow all pieces to dry or dry them yourself before replacing them in
the machine and closing the cover. Moisture left inside could create mildew and
unpleasant odors.
TIP: Here is an easy way to clean your attachments:
Empty the tank and vacuum 1 liter of clean tap water through the accessories
you used, repeat as needed.
CAUTION!
!
MOTOR INTAKE FILTER
Prevents various particles (from carpets, dust or dirt present in the air)
from reaching the motor and filters the motor cooling air.
1. Check that the motor intake filter is clean at least once a month.
2. If needed, remove and rinse the motor intake filter frequently. To remove
it, first remove the tank. Find the lower cover and remove it by undoing the
central screw, using your hands or a coin. Remove the filter (Pict. 5-6-7) and
wash it with water.
Before using the vacuum cleaner again, make sure the filters are dry, so that
they can operate at their best.
Do not leave the motor intake filter to dry on heaters or radiators!
UPPER LID FILTER
Check the Upper Lid Filter when you clean the
purification tank. If necessary, remove and rinse the
filter. To check the Upper Lid Filter:
1. Loosen the knob on the cover by turning
countericlockwise (Pict.8).
2. Remove the cover from the lid, grabbing it with
your hands (Pict.9).
3. Remove the filter.
4. Wash the filter with cold water.
Do not leave the sponge filter to dry on heaters or
radiators! Replace the filter if it has stains that you
cannot remove.
