Carico Ultra Cooker Guide

IMPORTANT SAFETY
INSTRUCTIONS
THE ULTRA COOKER IS INTENDED FOR HOUSEHOLD USE ONLY.
Before using your Carico Ultra Cooker for the first time, be sure to read and carefully fol-
low all of the instructions shown in this Owner’s Manual. Carefully unpack your electric
cooker and remove all packing material. Wash the interior pot thoroughly before using for
the first time and wipe the exterior base with a dry, soft cloth. We recommend cleaning
the inner pot with 1/4 cup of vinegar to 2 cups of water to remove any possible manufac-
turing oils or dirt. Always dry outside of cooker completely before connecting plug.
It is important that each time you use the Ultra Cooker, that basic safety precautions be
observed:
READ all instructions carefully before using the cooker. This appliance cooks under pres-
sure. Steam pressure is very powerful. Improper use may result in scalding injury. Make
sure the cooker is properly closed before operating.
NEVER leave the Ultra Cooker unattended or place it near water, fire, or underneath kitchen
cabinets while cooking. EXTREME CAUTION and close supervision is absolutely neces-
sary when your cooker is in use, especially, if children are within reach or in the vicinity.
NEVER use the Ultra Cooker if the gasket is not installed properly. To re-install the gasket,
the arrows must be pointing “up” and snugly pressed into the lid grooves. The rubber gas-
ket seal and the steam vent tube are the critical parts of this appliance. Make sure that the
gasket is clean, and do not use the cooker if the gasket is ripped, torn, sticky, brittle or
shows any signs of wear, cracking or tears. Be sure that the steam vent tube is clean and
clear, not clogged with food. Be sure to check these valves for clogging before each use.
NEVER fill the stainless steel removable cooking pot over two-thirds (2/3) full including liq-
uid and food. When cooking foods that foam or expand during cooking, such as rice or
dried beans do not fill the cooker over one-half (1/2) full. To reduce foaming add one table-
spoon of oil (olive, vegetable, etc.) The interior pot has been conveniently marked with
cup/metric measurements.
NEVER operate cooker under pressure without any liquid inside or allow cooker to a point
where the liquids boil dry. Manufacturer recommends at least 1 cup of liquid.
The digital function recommends the length of time required. This time can be changed,
however, be careful not to overcook the contents. You may override the cooking time by
pressing “cancel” then press the timer button and “+” or “–” for the desired cooking time,
then press start.
3
Dear Carico Owner,
We would like to congratulate you on your purchase of Carico’s Ultra Cooker. The
Ultra Cooker is not your grandmother’s pressure cooker! This all-in-one cooker
will pressure cook, slow cook, steam, and brown! The electric Ultra Cooker has
been developed with the most advanced technology to ensure the highest stan-
dard of safety and optimum performance. We know that this product will give you
many years of satisfaction and pleasure in your kitchen. Just put your ingredients
in and push the preprogrammed settings to receive all the benefits of speed and
convenience while maintaining nutritious and delicious meals.
You will soon depend on your Ultra Cooker to make quick and delicious meals for
you and your family. You will be able to cook your food with the guarantee of
keeping more vitamins, minerals and flavors, thus obtaining a healthier and better-
tasting meal.
We understand the demands of time on busy lifestyles, which is why we have cre-
ated the Ultra Cooker system, which is a tremendous time-saver in the kitchen.
With Carico’s Ultra Cooker, this is a reality since this system cooks up to 70 per-
cent faster saving you time as well as energy. Let Carico’s Ultra Cooker cook for
you!
Carico’s reputation of fine quality products, and unparalleled service warranties,
meets the needs of the most demanding customer. We wish you a lifetime of
wonderful cooking experiences with your new Ultra Cooker.
2

IMPORTANT: Should any of the following points occur, immediately pull the plug of the
Ultra Cooker and walk away until it has cooled down.
Excessive water (other than condensation) begins to drip from under the handle or lid.
Excessive steam begins to escape from the lid’s handle.
Excessive steam begins to release from under or around the edge of the lid.
The signaling valve seems to be clogged or does not rise. It may take up to 20 minutes
before reaching the desired cooking time.
The signaling valve does not drop down soon after the Ultra Cooker has automatically
timed and completed cooking your meal. (It may take up to 20 minutes before the pres-
sure drops of its own accord).
COMMON SENSE PRECAUTIONS:
Use only on a stable heat-resistant surface.
Do not handle or move the Ultra Cooker while in use.
Cook only in the provided stainless steel removable interior pot.
Keep face and hands away from the pressure release valve.
Check pressure release valve and the pressure release valve cover before each use to
assure that neither are blocked.
Let pressure drop of its own accord or use potholders when placing the pressure
release valve in the “up” position.
Never use the cooker if the gaskets are torn, worn, sticky, tacky or show any signs of
being weak.
Important Cord and Plug Information:
DO NOTUSE WITH AN EXTENSION CORD
Note: If the electrical circuit is overloaded with other appliances, your cooker may not
operate properly. The manufacturer strongly recommends that it should be operated on
aseparate electrical circuit from other appliances.
Plug the Ultra Cooker into an appropriate electrical polarized outlet only. As a safety fea-
ture, the 120V appliance has a polarized plug (one blade is wider than the other). This
plug will only fit in a polarized outlet one way. If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to
defeat this safety feature.
5
EXTREME CAUTION must be used when moving the Ultra Cooker containing hot liq-
uids, however; we strongly recommend that you DO NOT move the cooker while it’s cook-
ing or hot to the touch.
ALWAYS grasp your cooker by the handles using potholders to protect you from the hot
surface. When “browning” always use a potholder to grasp the inner pot when stirring
contents.
NEVER place the Ultra Cooker in a heated oven or use for other uses than its original
intent.
NEVER use your Ultra Cooker for deep frying in oil.
NEVER use force to open the lid. Let pressure drop of its own accord or use pothold-
ers when placing the release valve in the “up” position. If the handles are difficult to push
apart, this indicates that the cooker is still under pressure. Any pressure in the cooker
can be hazardous. Only open the lid when the cooker has cooled and all internal pres-
sure has been released.
WARNING: All lid parts must be assembled correctly to ensure safety. Improper lid
assembly could result in system malfunction and cause the cooker to stop operating.
NEVER place the Ultra Cooker under running water or immerse in water. Either let the
pressure drop of its own accord or use potholders when placing the release valve in the
“up” position.
NEVER reach into water if the cooker falls or accidentally becomes immersed in water.
Immediately unplug it from the wall outlet.
NEVER use the interior stainless steel removable cooking pot for anything else but cook-
ing inside the Ultra Cooker and, never replace or substitute the interior stainless steel cook-
ing pot with another pot.
NEVER use outdoors.
ALWAYS place the cooker on a solid, stable, heat resistant surface when cooking.
NEVER dangle the electrical cord at the edge or over the counter top.
4

Pressure Release Valve
Pressure Indicator Rod
Lid Handle
Pressure Control
Removable Airtight Lid
Stainless Steel Removable
Cooking Pot
Base Handles
Base
Heating Plate with
Temperature Sensor
(inside bottom of cooker)
Detachable Power Supply Cord
Steam Rack
Measuring Cup
Ladle
Rice Paddle
FIG. 1
GETTING TO KNOW YOUR
ULTRA COOKER
7
Do not attempt to modify the plug in any way.
Always attach plug to appliance first, then plug cord into wall outlet. To disconnect, press
“cancel” then remove plug from wall outlet.
To protect against electrical shock or burns, do not immerse cord in water or other liquid.
Ashort power supply cord is provided to reduce the risk resulting from becoming entan-
gled in or tripping over a longer cord. Do not let cord hang over edge of table or counter
or touch hot surfaces.
Do not allow the cord to run underneath or around the unit since the cord may not detach
easily if the cord is positioned in this fashion.
Do not operate the cooker with a damaged cord or plug in the event the appliance mal-
functions or has been damaged in any manner.
In the event the appliance malfunctions or has been damaged in any manner never plug
the power cord into an electrical outlet or attempt to operate the cooker.
Do not allow children to handle or put electrical cords or plugs in their mouths.
Unplug from outlet and remove plug from appliance when not in use and before cleaning.
Allow appliance to cool before putting on or taking off parts, and before cleaning.
SAVE THESE INSTRUCTIONS
Carico and its manufacturer will not be responsible for any injuries
if the unit is not used as intended or the instructions have not been followed.
Cooker is intended for household use only.
6

BEFORE USING FOR THE FIRST TIME
1. Notice when the removable airtight lid is properly closed, the arrows on the base handle
and lid will be lined up. To remove the lid, holding the base handle firmly with one handle,
grasp the lid handle with the other hand and rotate counter-clockwise. Follow the arrow
on the lid handle (See Figure 4)
2. Remove and wash the stainless steel removable cooking pot, lid, silicone gasket and
gasket holder in warm soapy water and 1/4 cup of vinegar to 2 cups of water. (See Care
and Cleaning Instructions for disassembly details). Rinse with clean water and dry
thoroughly.
3. Replace clean silicone gasket. Make sure the silicone gasket is attached properly to the
gasket holder and is securely in place on the lid. (See Care and Cleaning Instructions for
assembly details).
WARNING: IMPROPER REMOVABLE AIRTIGHT LID ASSEMBLY COULD RESULT IN APPLIANCE
MALFUNCTION AND CAUSE THE UNIT TO STOP OPERATION AND POSSIBLY CAUSE INJURY.
4. Clean and dry the bottom of the removable cooking pot as well as the heating plate with
temperature sensor, making sure there are no unwanted materials on the surface. The
removable stainless steal cooking pot must sit flat on the heating plate with temperature
sensor to ensure proper control.
5. Place the Ultra Cooker on a flat heat resistant level surface, approximately 2 feet from a
standard 120V AC electrical outlet. DO NOT let cord hang over the edge of a table or
countertop.
6. When cooking under pressure, never place the Ultra Cooker under cabinets. When
releasing steam, make sure the area several feet above the pressure release valve is clear
from all lighting fixtures, furniture or cabinetry.
7. Connect the detachable power cord pushing firmly into the receptacle at the back of the
Ultra Cooker.
BEFORE EACH USE
Always check the removable airtight lid to ensure that the pressure release valve and pressure
indicator rod slides easily and is in good working order and that there are no foreign particles
blocking the valve openings on the underside of the lid. Check to see that the silicone gas-
ket is attached properly to gasket holder and the gasket holder is contained within the grips
along inside of the lid. (See Care and Cleaning Instructions for assembly details).
9
FIG. 4
Menu Default Setting Time Adjustable Time Pressure Temperature Gauge
Meats 15 minutes 5-60 minutes Yes Medium - High
Beans 20 minutes 5-60 minutes Yes Medium
Steamer 10 minutes 5- 60 minutes Yes Low
Browning 30 minutes 5-60 minutes No N/A
Baby Food 25 minutes 5-60 minutes Yes High
Rice 8 minutes 5-40 minutes Yes Medium
Oatmeal 10 minutes 5-40 minutes Yes Medium
Soup 15 minutes 5-40 minutes Yes High
Poultry 10 minutes 5-40 minutes Yes Medium
Slow Cooker 4 hours 2-10 hours No Medium
The following times are approximate times and may vary slightly. We always recommend that
you test that your meats and poultry to insure they are done satisfactorily.
Water
Collector
Power
Receptacle
Pressure Release
Valve Cove
Rubber Gasket
Gasket
Holder
Pressure Indicator
Valve and Rod
with Mini Gasket
FIG. 2
FIG. 3
GETTING TO KNOW YOUR
ULTRA COOKER
8

OPERATING INSTRUCTIONS (continued)
6. Using the small handle on the pressure release valve, follow the arrow on the stem and
rotate to the “Pressure” position. The valve will be lowered onto the lid. (See Fig. 8)
IMPORTANT: If the pressure release valve is not closed, the Ultra Cooker will not build
pressure for pressure cooking. The liquids may boil dry and cause the unit to overheat and
shut down.
7. Plug the cord into a 120V AC electrical wall outlet. The Ultra Cooker will emit 1 beep,
“0000” will be displayed on the control panel.
8. Turn the pressure control to HIGH, MEDIUM or LOW pressure. (See Fig. 9)
9. The Ultra Cooker offers timer control for every function.
10. To set the timer for cooking, press the function you want. For Slow Cooker and
Browning function, the default time will be shown on the panel when you select the
function. For other functions cooking under pressure, you will need to press TIME
button to see the default pressure time. (See section entitlted “Simple Cooking
Instructions” on page 16 for complete instructions)
11. Press + or – button to increase or decrease cooking time or keeping pressure time.
12. When desired cook time is displayed, press the START button and the unit will start
to work.
13. As the appropriate pressure/temperature is achieved, there will be a slight hissing of
steam from the pressure indicator valve, located on the back of the handle. The
pressure indicator will begin to rise as pressure mounts.
WARNING: There will be some normal hissing, if there is an excessive loud hissing and
water and steam are spurting from the pressure release valve, check to make sure the
pressure release valve is lowered on the lid and is rotated to the “pressure” position.
14. After approximately 10 minutes, (or more depending on the amount of liquid added to
the cooking pot) the pressure indicator rod will rise to its uppermost position.
The target cook time will begin to count down in minutes.
11
FIG. 8 FIG. 9
OPERATING INSTRUCTIONS
FUNCTION: HIGH/MEDIUM/LOW PRESSURE COOKING
1. Place food to be cooked into the removable cooking pot.
IMPORTANT: Do not fill the removable cooking pot higher than
Max line inside the cooking pot.
IMPORTANT: Do not exceed 8 cup line when pressure cooking
foods that expand such as rice, dried beans, grains and
legumes.
IMPORTANT: Add at least 1 cup (8 ounces) of liquid to the
removable cooking pot when cooking under pressure. You may
use water, broth, or juice, etc.
CAUTION: Never operate the appliance when it is empty.
Do not cook with food content below 1 cup line.
2. Make sure the cord is unplugged.
3. Check to see that the silicone gasket is attached properly to the
gasket holder and the gasket holder is contained within the grips
along inside of the lid. (See Care & Cleaning Instructions for
assembly details).
4. Place the lid on top of the base. Turn so that the pressure release
valve is at the “pressure” up position or “release” down position.
5. Holding the base handle firmly in one hand, firmly grasp the lid handle with the other hand
and rotate clockwise until the lid locks into place; the handle and the base handles will
be in perfect alignment. Follow the “close” arrow on the lid handle. (See Fig.6 & 7)
NOTE: Be sure the lid is assembled well. Incorrect lid assembly onto the unit will cause
the error “E3” to appear on the display.
10
FIG. 5
FIG. 6
FIG. 7

18. Check the food to see if it has been sufficiently cooked. If not, replace the lid and lock into
position following the manual’s Simple Cooking Instructions on how to use the “timer
function”. Cook under pressure for an additional 2-3 minutes if necessary.
19. Once cooking is complete, unplug the cord from the outlet first. Then remove the cord from
the Ultra Cooker.
20. Allow the appliance to cool before cleaning. Follow the Care and Cleaning Instructions
outlined in this instruction manual.
USER MAINTENANCE
INSTRUCTIONS
CLEANING THE ULTRA COOKER
To maintain the beauty and cooking efficiency of this Ultra Cooker, it is important that it be
cleaned thoroughly after each use. Food films left on the interior cooking surface will cause dis-
coloration when the cooker is reheated.
Although durable, stainless steel is not indestructible. Pitting may result if salt remains in the
interior pot. Salt should be added just before serving foods. Liquids should be stirred immedi-
ately to completely dissolve the salt. Do not allow seasoned foods or high acid foods to remain
in the interior pot for long periods.
IMPORTANT: Allow cooker to cool before cleaning. Always detach the cord before cleaning.
Clean interior pot in hot soapy water with a sponge, dishcloth or nylon pad (not plastic). Do not
use a metal scouring pad, any sharp edge utensil such as a knife or abrasive scouring powder
on the stainless steel finish. Rinse the interior pot thoroughly with clear hot water. Dry prompt-
ly to prevent water spots. Wipe electric cord with a damp cloth, and dry thoroughly.
Persistent overheating may cause blue or brown heat tints inside your cooker. Stains may also
result from minerals in certain foods. To remove both heat tints and stains, make a paste with
water and a non-abrasive stainless steel cleaner. There are various types of non-abrasive stain-
less steel cleansers that can be found at most supermarkets. (We only recommend use on the
interior stainless steel cooking pot.) Do not use a cleanser which contains chlorine bleach.
Apply paste with a cloth or sponge and rub lightly in a circular motion. Wash interior pot again,
rinse then dry promptly.
Remove minor scratches from the stainless steel cooking pot with a non-abrasive stainless steel
cleaner, following the instructions above. To prevent scratches, do not cut, scrape or chop food
with sharp-edged kitchen tools in your stainless steel interior pot.
13
CAUTION: Keep hands and face clear of the pressure release valve and the pressure
indicator rod when the appliance is in operation. Hot steam and liquid may be emitted
during use.
CAUTION: WHEN COOKING UNDER PRESSURE, THE APPLIANCE CANNOT BE
OPENED ONCE PRESSURE IS REACHED. DO NOT TRY TO FORCE THE LID OPEN.
15. You can press the Warm/Cancel button to start the keep warm function or cancel the
keep warm mode. When cooking is completed, the pressure cooker will automatically
turn into a warming mode for 24 hours indicated by four dashes (----) on the display.
Four zeros (0000) indicates that the function is cancelled.
16. After cooking is completed there are two ways of releasing the pressure:
Option one: You can wait for the pressure cooker to cool down without any assistance
until the pressure drops. This natural release normally takes 20 minutes.
Option two: You can release the pressure by hand using a silicon mitt without waiting
(fast release). (See Fig. 10) To fast release the pressure, wearing the silicone mitt, rotate
the pressure release valve to the “Release” position at its uppermost position. As it is
raised, steam will begin to pour out of the top of the handle.
WARNING:
1. Use caution when opening lid. There may be a minimal suction of the interior pot to
the gasket.
2. Use caution when separating because steam escapes as soon as the lid is opened.
3. Never place your face or hands over the Ultra Cooker when removing the lid.
4. Always use the silicone mitt when handling the hot cooking pot.
17. After the steam has been fully released, the lid may be removed. Hold the base
handle firmly using silicone mitt in one hand, grasp the lid handle with the other hand
and rotate the lid clockwise.
CAUTION: After making soups and stock, allow several minutes before releasing the
pressure by hand using silicone mitt and remove the lid to avoid the hot liquid from
boiling over.
12
FIG. 10

10. After cleaning, reassemble the Ultra Cooker lid by
replacing the plastic gasket holder and silicone gasket.
Start by pressing the clean gasket holder into the lid. Turn
counter clockwise so that the 6 grips are positioned over
the plastic tabs. This will ensure the holder is secure. The
arrows on the plastic gasket holder point toward the pot
away from the lid. (See Fig. 14)
11. The silicone gasket has a narrow top, a channel for the holder, and a wide bottom that
fits into the lid. (See Fig. 15).Press the clean gasket into the lid so that the holder fits
securely into the gasket’s channel.
IMPORTANT: The silicone gasket must always be properly
positioned with the wide bottom into the underside of the
lid. If the gasket is not assembled properly, the Ultra
Cooker will not operate. An alarm will sound and the error
“E3” will be displayed. To correct, remove the silicone
gasket, reverse and replace.
12. When necessary, gently pull the water collector
downwards to remove from the back of the unit. Discard
any water that may collect after each use. Rinse and
replace the water collector before the next use.
13. Wipe the base clean with a damp soft cloth or sponge. Do not pour any liquid into the
Ultra Cooker’s interior base and do not wet the plug outlet on the base. Do not wet the
Ultra Cooker control panel.
14. Never use harsh chemical detergents, scouring pads or abrasive powders on any of the
parts or components.
15. In order to maintain optimal performance of your Ultra Cooker, the heating plate inside
must be free of dirt, food or residue. If necessary, wipe with a soft, damp cloth and be
sure to dry thoroughly.
16. To prevent aromas, molds and off flavors, never store your Ultra Cooker closed with the
lid locked in place. Pack and store the Ultra Cooker with the lid resting upside-down
on the removable cooking pot.
17. Store the Ultra Cooker in a cool, dry place.
15
FIG. 14
FIG. 15
CARE AND CLEANING INSTRUCTIONS
1. Unplug and let the Ultra Cooker cool to room temperature before cleaning.
2. Wash the removable cooking pot with warm soapy water and a clean soft cloth or sponge.
Rinse with clean water and dry thoroughly.
NOTE: After cooking rice or larger pot meals, some cooking liquid may pool under the lid at
the top of the unit around the cooking pot. This is normal. Use a paper towel or kitchen cloth
to clean after every use. Use small brush or cotton swab if necessary.
3. Removable of gasket and release valve. (See Fig.12)
4. Gently pull the silicone gasket out from under the gasket holder. (See Fig. 11)
Check periodically to make sure that it is clean, flexible and not cracked or torn. If damaged,
do not use this appliance. Contact your local distributor or Carico for replacement parts
and cost.
NOTE: There are 6 triangular metal cut-out grips around the inside of the lid that keep the
plastic gasket holder in place.
5. To remove the plastic gasket holder, turn the holder clockwise so that grips are positioned
over the holder’s cut-outs. (See Fig. 12) Remove the gasket holder by pulling straight up and
out of the lid. (See Fig. 13)
6. Wash gasket and holder in warm, soapy water. Rinse with clean water and dry thoroughly.
The silicone gasket and holder may be washed in the top rack of a dishwasher to eliminate
odors from spices and food.
7. Wash the inside of the lid with a wet, soapy sponge or cloth. Use a brush to remove oil
residue if necessary. Wipe dry with a clean, damp cloth.
8. Remove the pressure release valve cover from the lid by twisting and lifting up and off the
cooker lid. Check valve for blockage and use a toothpick if necessary to remove blockage.
Rinse well and replace.
9. Check the pressure indicator valve for blockage from underneath the lid. Grasping the rod’s
mini-gasket, inspect to make sure it is in good condition, and test that the rod moves up and
down freely. DO NO REMOVE EITHER THE ROD OR THE MINI GASKET.
14
FIG. 11 FIG. 12 FIG. 13

III.Steam: Recommended for Fish and Vegetables
1. Place the steaming rack into the removable cooking pot.
2. Add 1 cup (8ounces) of liquid – Water, Broth, Juice, etc.
3. Place the food on the rack. Food must be large enough not to fall through the rack.
For best results do not overfill. Close lid, position pressure release valve in the down
pressure position.
4. Press the “Steam” function key on the control panel and press start. A built-in thermostat
will automatically steam your food or you may choose to use the Manual Time for
controlling the texture of what you are steaming.
This cooking time CANNOT be changed once it’s set.
IV. Slow Cooker: Cooks exactly like a regular slow cooker with cooking time up to 10 hours.
1. Follow the recipe, add food, and close lid.
2. Pressure/Release valve should be in the “up” position or you may remove it when using the
Slow Cooker function.
3. Press “Slow Cooker” function key.
4. Default time will show four (4) hours in the panel. You may increase or decrease the time
by pressing either the “+or “-” button.
5. Once desired cooking time has been selected press the “Start” button.
This cooking time CANNOT be changed once it’sset.
IV. Preset Function: The preset function allows you to delay cooking from 2 to 10 hours.
When using the “Preset” function you must first select one of the menu buttons on the wheel.
For fowl press “Poultry” then press “Preset”; then “Start” to begin the process. Two hours will
automatically show on the wheel when you press the “Preset” button. You need to press the
“+” button to increase the delay time. The preset function can be set up to 10 hours. When
cooking time is completed the cooker will shut off automatically and go into a warming mode
–four dashes will appear on the front panel (----).
It should be noted that the “Preset” function includes the cooking time. If you set the “Preset”
for 4 hours the time will immediately begin to countdown. For instance, assuming you want to
delay the cooking time for 4 hours. The “automatic” pressure cooking time for your ingredients
may be 30 minutes. When the “Preset” function time gets to 3:30 the pressure will begin to
rise and at the end of the 4 hours your food is cooked.
The “Preset” function does NOT mean you have to wait 4 hours before your food begins cook-
ing. It means that at the end of the 4 hours your food is cooked.
IMPORTANT: Since overcooked food cannot be corrected, it is advisable to err on the undercooked
side by cooking an unfamiliar food for a shorter period of time than you may think necessary. You
can always go back and continue cooking if needed.
17
SIMPLE COOKING
INSTRUCTIONS
Simple cooking instructions: Place your ingredients in the pot, push only one function
key on the control panel (poultry, meats, beans, etc.), press start and soon you will
enjoy a delicious home-cooked meal!
I. Browning: All browning should be done without the lid
1. To brown food you must use at least 1 tablespoon of oil in the bottom of the interior
stainless steel cooking pot.
2. Add oil to bottom of the interior pot press the “Browning” function key. An automatic
number of 30 minutes will appear in the front panel.
3. Press the plus “+” or minus “-” button to increase or lower your desired cooking time.
4. Press the “Start” button.
5. Allow the oil to heat up for at least 2 minutes before browning food , then add food.
6. When turning the food for browning we recommend using the silicone heat resistant glove
to secure the interior pot.
7. As usual be cautious and aware of any oil splatter when browning food.
II. Pressure Function:
1. Automatic Time: When using the pressure function key there is no need to set the timer.
Abuilt-in thermostat automatically adjusts the heat and triggers the timer. These
computerized functions eliminate the need to make manual heat adjustments.
a. Select and press only one function key on the front of the Ultra Cooker control panel.
b. Press “Start” button to begin cooking.
c. Rotating “red dashes” will appear in the panel
d. A built in thermostat automatically adjusts the cooking time.
e. As the appropriate pressure/temperature is achieved, there will be a slight hissing of
steam from the pressure indicator valve, located on the back of the handle. The pre
pressure indicator will begin to rise as pressure mounts.
f. When pressure mounts the desired cooking time will display and your food will
begin cooking.
This cooking time CANNOT be changed once it’s set.
2. Manual Time:
a. Follow the recipe and add food; close lid. Position pressure release valve in the down
pressure position.
b. Select and press only one function key on the front of the Ultra Cooker control panel.
c. Press “Timer” button.
d. Press the plus “+” or minus “-” button to increase or lower your desired cooking time.
e. Press the “Start” button - the cooking time will be present and begin to count down.
This cooking time CANNOT be changed once it’s set.
16

Lentil Soup
1Package of lentils, 6 oz.
1 Cup of smoked ham cut into cubes (optional)
2 Tbsp. of olive oil
3 Bay leaves
2 Carrots cut into cubes
1 Lg. onion, chopped
2 Stalks of celery, chopped
Salt and pepper to taste
Red pepper flakes to taste (optional)
Water or clear broth (following lentil package directions)
DIRECTIONS:
1. Using the “Browning Function”, heat the interior pot of the cooker and add the olive
oil, ham, and onions; brown until golden brown.
2. Add the rest of the vegetables, bay leaves, salt, pepper, and red pepper flakes.
3. Add liquid just below the 2/3 limit line.
Close lid and lock setting Pressure Release Valve to the “down pressure” position. Turn
the pressure control to “Medium”- Press the “Soup” function button and then start.
Cooker will automatically choose the correct cooking time. When soup is finished the
cooker will shut off automatically and go into a warming mode – four dashes will appear
on the front panel (----). Allow pressure to drop naturally, when the release valve drops
it is safe to open the cooker.
19
ULTRA COOKER
RECIPES
SOUPS
Chicken Soup with Escarole
1Whole chicken (cut into 8 pieces)
2 Tbsp. of olive oil
2 Cups of celery, diced
2 Cups of carrots, diced
1 Medium onion, diced
3 Cloves of garlic, diced
1 Head of escarole, chopped (optional)
Salt and pepper to taste
Water (fill just below the 3/4 mark)
DIRECTIONS:
1. Sprinkle chicken with salt and pepper.
2. Heat the olive oil in the bottom of the cooker and brown the chicken until
golden brown.
3. Add vegetables except the escarole; then add the water up to the maximum mark
2/3 fill line.
Close lid and lock setting Pressure Release Valve to the “down pressure” position. Turn
the pressure control to “High”- Press the “Soup” function button and then press start.
Cooker will automatically choose the correct cooking time. When soup is finished the
cooker will shut off automatically and go into a warming mode. Release the pressure using
the silicone mitt, turn the pressure release valve in the “up position”, when the release valve
drops it is safe to open the cooker. Remove the chicken from the cooker.
4. Add the escarole to the cooker and stir until all of the escarole is emerged in the soup
and cook for approximately 5 minutes. Place lid back on the cooker to keep warm.
When chicken is cooled remove all the skin and bones. Shred chicken into bite-size
pieces and add the shredded chicken to the soup. You may serve over small pasta or rice.
18

MEATS
Easy Cuban Roast Pork
4lbs. Boneless pork roast
2 Tbsp. of olive oil
1 bottle of Mojo, (look in ethnic aisle)
Salt and pepper to taste
1. Using the “Browning Function” heat olive oil in the interior pot.
2. Add roast to hot oil and brown until golden.
3. Add liquid
Close lid and lock setting Pressure Release Valve to the “down pressure” position. Turn
the pressure control to “Medium”- Press the “Meat” function button and then press start.
Cooker will automatically choose the correct cooking time. When roast is finished the
cooker will shut off automatically and go into a warming mode – four dashes will appear
on the front panel (----). Release the pressure using the silicone mitt, turn the pressure
release valve in the “up position”, and when the release valve drops it is safe to open the
cooker. Remove the roast from the cooker to stop cooking. Slice and serve.
21
Pasta Fagioli
1 Can of diced tomatoes, (approximately 12 ounces)
1 Can of cannellini beans, (approximately 13 ounces)
1/2 Cup of pancetta, diced (optional or may substitute with a cured ham)
4 Garlic cloves, diced
2 Tbsp. of olive oil
1 Tbsp. of dried basil
1 lb. Small pasta (Ditallini)
Salt and pepper to taste
Parmesan cheese (Optional)
DIRECTIONS:
1. Press the “Browning” button and heat the olive oil in the bottom of the cooker for
1minute.
2. Add diced garlic to hot oil until golden brown.
3. Add dried basil and stir.
4. Add Cannellini beans and cook for 1 minute.
5. Add diced tomatoes and stir.
Close lid and lock setting Pressure Release Valve to the “down pressure” position. Turn
the pressure control to “Medium”- Press the “Soup” function button and then press
start. Cooker will automatically choose the correct cooking time. When the soup is fin-
ished the cooker will shut off automatically and go into a warming mode – four dashes
will appear on the front panel (----). Release the pressure using the silicone mitt, turn
the pressure release valve in the “up position”, and when the release valve drops it is
safe to open the cooker.
Cook pasta according to package directions. Before draining the pasta remove one
cup of water and add to the fagioli mixture, drain pasta and pour into the soup. Serve
hot and sprinkle with Parmesan cheese (optional).
20

Easy Pot Roast
4lbs. Beef chuck roast
2 Tbsp. vegetable oil
1 Package of dried onion soup
1 Can of beef broth (14.5 ounce) or water
1. Using the “Browning Function” heat olive oil in the interior pot.
2. Add the meat to hot oil and sauté until brown.
3. Remove meat and set aside.
4. Add dried onion soup mix and liquid, stir.
5. Return meat to the pot.
Close lid and lock setting Pressure Release Valve to the “down pressure” position. Turn the
pressure control to “High”- Press the “Meat” function button and then press start. Cooker
will automatically choose the correct cooking time. When roast is finished the cooker will
shut off automatically and go into a warming mode – four dashes will appear on the front
panel (----). Allow pressure to drop naturally, when the release valve drops it is safe to open
the cooker.
Steak Pizzaiolli
4lbs. Beef chuck roast
1 Can diced tomatoes with juice (15 ounces)
1 Package mushrooms sliced, (8 ounces)
3 Garlic cloves, minced
1 Medium onion, chopped
1/4 Cup of coarsely chopped fresh basil leaves
(You may substitute with 1 Tablespoon dry basil)
Salt and pepper to taste
1. Using the “Browning Function” heat olive oil in the interior pot.
2. Add the meat to hot oil and sauté until brown.
3. Remove meat and set aside.
4. Add dried onion, and mushrooms and brown until all the vegetables are tender.
5. Add the tomatoes with their juice, wine, and basil.
6. Return meat to the pot.
Close lid and lock setting Pressure Release Valve to the “down pressure” position. Turn the
pressure control to “High”- Press the “Meat” function button and then press start. Cooker
will automatically choose the correct cooking time. When roast is finished the cooker will
shut off automatically and go into a warming mode – four dashes will appear on the front
panel (----). Allow pressure to drop naturally, when the release valve drops it is safe to open
the cooker.
23
Cuban Roast Pork
4lbs. Boneless pork roast
1 lb. Mushrooms, sliced
2 Tbsp. of olive oil
6 Cloves of garlic
1 Small onion, diced
2 Bay leaves
1/2 Cup of Mojo, (look in ethnic aisle)
1/2 Cup of any type of white wine (not cooking wine – cooking wine is very salty)
1/2 Cup of water
Seasonings: Adobo, (look in ethnic aisle)
Salt and pepper to taste
Corn Starch/Flour to thicken gravy
DIRECTIONS:
1. Slice four (4) garlic cloves and with the point of your knife insert the garlic into the
meat by cutting small incisions in the entire port roast.
2. Sprinkle roast with Adobo, salt and pepper.
3. Using the “Browning Function” heat olive oil in the interior pot.
Add roast to hot oil and brown until golden.
4. Remove roast and add mushrooms, remaining garlic, and diced onion and cook until
golden brown.
5. Add bay leaves and liquid.
Close lid and lock setting Pressure Release Valve to the “down pressure” position. Turn
the pressure control to “Medium”- Press the “Meat” function button and then press
start. Cooker will automatically choose the correct cooking time. When roast is finished
the cooker will shut off automatically and go into a warming mode – four dashes will
appear on the front panel (----). Release the pressure using the silicone mitt, turnthe
pressure release valve in the “up position”, and when the release valve drops it is safe
to open the cooker. Remove the roast from the cooker to stop cooking. Add thicken-
ing agent to thicken the gray. Slice and serve.
22

Close lid and lock setting Pressure Release Valve to the “down pressure” position. Turn
the pressure control to “Medium”- Press the “Poultry” function button and then press
start. Cooker will automatically choose the correct cooking time. When chicken is fin-
ished the cooker will shut off automatically and go into a warming mode – four dashes
will appear on the front panel (----). Allow pressure to drop naturally, when the release
valve drops it is safe to open the cooker. Remove the chicken from the cooker to stop
cooking.
Easy Chicken Adobo
1Whole chicken cut into 8 pieces
4 Cups of water to cover chicken
1/2 Cup of soy sauce
1/4 Cup vinegar
1 Onion, diced
1 Garlic clove
1Square-inch of ginger (do not cut up)
3 Bay Leaves
DIRECTIONS:
1. Add all ingredients into the inner pot.
Close lid and lock setting Pressure Release Valve to the “down pressure” position. Turn
the pressure control to “Medium”- Press the “Poultry” function button and then press
start. Cooker will automatically choose the correct cooking time. When chicken is fin-
ished the cooker will shut off automatically and go into a warming mode – four dashes
will appear on the front panel (----). Release pressure using the silicone mitt, turn the
pressure release valve in the “up position”, when the release valve drops it is safe to
open the cooker. Remove the chicken from the cooker to stop cooking. You may want
to thicken the gravy and serve over rice.
25
POULTRY
Easy Whole Chicken:
1 Whole chicken
2 Tbs. olive oil
1 1/2 Cups of chicken broth
DIRECTIONS:
1. Rinse chicken and pat dry. Season with Salt and Pepper
2. Press the “Browning” button and heat the olive oil in the bottom of the cooker for
1 minute. Add chicken to hot oil and brown until golden.
4. Remove chicken
5. Add rack and broth
6. Place chicken on rack
Close lid and lock setting Pressure Release Valve to the “down pressure” position. Turn
the pressure control to “Medium”- Press the “Poultry” function button and then press
start. Cooker will automatically choose the correct cooking time. When chicken is fin-
ished the cooker will shut off automatically and go into a warming mode – four dashes
will appear on the front panel (----). Allow pressure to drop naturally, when the release
valve drops it is safe to open the cooker. Remove the chicken from the cooker to stop
cooking.
Stuffed Whole Chicken:
1Whole chicken
2 Tbs. olive oil
1 Medium onion - chopped
1 1/2 Cups of clear chicken broth
1 package of stuffing (any brand, prepare following package directions)
DIRECTIONS:
1. Rinse chicken and pat dry. Season with Salt and Pepper
2. Stuff chicken cavity with prepared stuffing.
3. Press the “Browning” button and heat the olive oil in the bottom of the cooker for
1 minute. Add chicken and onion to hot oil and brown until golden.
4. Remove chicken
5. Add rack and broth
6. Place chicken on rack
24

BEANS
Cooking Instructions:
As a general rule, beans should be soaked at least 4 hours before cooking.
Rinse the soaked beans before pressure cooking.
Add enough water, or use a flavoring liquid, to cover beans by 2 inches, but
do not exceed the half-fill rule.
Add 1-2 tablespoons cooking oils to minimize foaming.
Press the “Bean” Function key.
Press “Start”
In all cases, beans should be finished by allowing the pressure to drop of its accord.
Close lid and lock setting Pressure Release Valve to the “down pressure” position. Turn the
pressure control to “Medium”- Press the “Bean” function button and then press start. Cooker
will automatically choose the correct cooking time. Since various types of beans have differ-
ent textures you may want to use the manual “Timer” pressing the “+” or “-” to either increase
or decrease the cooking time.
When beans are finished the cooker will shut off automatically and go into a warming mode –
four dashes will appear on the front panel (----). Allow pressure to drop naturally, when the
release valve drops it is safe to open the cooker.
27
NAME CHARACTERISTICS AND USES SOAK TIME
Anasazi Minimum 8 minutes
4hours
Black Eyed No 10 minutes
Peas
Canellini Minimum 12 minutes
4hours
Fava Minimum 4 minutes
8hours
Garbonzo Minimum 14 minutes
8hours
Great Northern Minimum 12 minutes
4hours
Lentils No 7 minutes
Kidney Minimum 12 minutes
4hours
Pinto Minimum 12 minutes
4hours
Use in any recipe that calls for pinto beans. Very
digestible due to 25% less complex sugars.
These beans are characterized by a small eye
originally from Africa.
Excellent in Italian minestrone soup and salads
Huge, substantial beans with tough outer skin.
Use in soups or puree.
Originating in the Middle East, they have a firm
texture with a flavor of chestnuts and walnuts
Also called white kidney beans, these beans have
asmooth texture and delicate flavor.
Very versatile lentils have a mild often earthy flavor.
Alarge, kidney-shaped bean with a subtle sweet
flavor. Used in Southwestern dishes.
Afavorite for Mexican dishes. Pintos are medium
ovals with an earthy flavor.
Italian Chicken Cacciatore
1Whole chicken cut into 8 pieces
1 Large red bell pepper, chopped
1 Lg. onion, chopped
3 Garlic cloves, chopped
3 Tbsp. of drained capers (optional)
1 Cup of black or green olives
3 Tbsp. of olive oil
1 Cup of white wine
1 Can diced tomatoes with juice (approximately15 ounces)
1/2 Cup of all purpose flour for dredging
1/4 Cup of coarsely chopped fresh basil leaves
(You may substitute with 1 Tbsp dry basil)
Salt and pepper to taste
DIRECTIONS:
1. Sprinkle chicken with salt and pepper.
2. Dredge chicken pieces in the flour to coat lightly.
3. Heat olive oil in the interior pot. Add the chicken pieces to hot oil and sauté
until brown.
4. Remove chicken and set aside
5. Add bell pepper, onion and garlic until all the vegetables are tender.
6. Add the tomatoes with their juice, the wine, capers, and basil.
7. Return chicken to the pot.
Close lid and lock setting Pressure Release Valve to the “down pressure” position. Turn
the pressure control to “Medium”- Press the “Poultry” function button and then press
start. Cooker will automatically choose the correct cooking time. When chicken is fin-
ished the cooker will shut off automatically and go into a warming mode – four dashes
will appear on the front panel (----). Release pressure using the silicone mitt, turn the
pressure release valve in the “up position”, when the release valve drops it is safe to
open the cooker. Remove the chicken from the cooker to stop cooking – season with
salt and pepper.
26

Remember that whole grains such as wheat berries and brown rice always remain a bit chewy,
even when thoroughly cooked.
Grains that have the same cooking time may be cooked together (such as beans and rice).
Leftover grains may be frozen in convenient portion sizes. Defrost them in the microwave.
Precautions when cooking grains:
When cooking dried grains alone (rather than in a soup or stew), never fill Ultra Cooker more
than the one half (1/2) line on the interior measurement guide.
To reduce excess foaming as grains cook, always add one tablespoon of oil per cup of dried
beans.
Do not cook more than 3 rice measuring cups (2 cups of dried grains) at a time.
Clean the pressure release valve, pressure indicator valve and rod, and silicone gasket thor-
oughly after cooking grains.
Close lid and lock setting Pressure Release Valve to the “down pressure” position. Turn the
pressure control to “Low”- Press the “Rice” function button and then press start. Cooker will
automatically choose the correct cooking time. When rice is finished the cooker will shut off
automatically and go into a warming mode – four dashes will appear on the front panel (----).
Allow pressure to drop naturally, when the release valve drops it is safe to open the cooker.
Wild Mushroom Risotto:
1Package of mushrooms, chopped (8 ounces)
2 Cups Arborio rice
4 Cups chicken or vegetable broth
1/4 Cup dry vermouth or white wine, (not cooking wine – cooking wine is very salty)
2 Tbsp. shallots, chopped
1/4 Cup Parmesan cheese
3 Tbsp. olive oil
Salt and pepper to taste
DIRECTIONS:
1. Using the “Browning Function” heat olive oil in the interior pot.
2. Add shallots and mushrooms sauté until soft, do not brown.
3. Add Arborio rice stirring constantly for an additional minute.
4. Add broth and wine and stir mixture together.
Close lid and lock setting Pressure Release Valve to the “down pressure” position. Turn the
pressure control to “Low”- Press the “Rice” function button and then press start. Cooker will
automatically choose the correct cooking time. When rice is finished the cooker will shut off
automatically and go into a warming mode – four dashes will appear on the front panel (----).
Allow pressure to drop naturally, when the release valve drops it is safe to open the cooker.
29
RICE
Cooking Instructions:
Preparation of rice may vary from the instructions on package (see chart below).
Do not exceed the half-fill rule.
Add 1-2 tablespoons cooking oils to minimize foaming.
Press the “Rice” Function key.
Press “Start”
In all cases, rice should be finished by allowing the pressure to drop of its accord
Rice Cooking Chart:
Important: To reduce excess foaming add one tablespoon of oil (olive, vegetable, etc.)
Note: Use measuring cup for both rice and water to ensure the correct ratio. See chart.
Natural grain and wholesome rice such as:
White long and short grain, Basmati and Arborio cook at
MEDIUM PRESSURE
Natural grain and wholesome rice such as:
Brown long and short grain and Texmati cook at
HIGH PRESSURE
*Actual cooking times and ratios may vary depending on the type and age of the grain such as
converted and processed rice.
Please review the “Manual Timing” instructions to regulate cooking time for rice.
Pressure Cooked Grains:
Whole grains cook very quickly in the Ultra Cooker.
Here are a few things to keep in mind:
Timing varies from one batch of grains to the next, depending upon age and storage conditions.
28
RAWRICE LIQUID PRESSURE
2Cups 2 Cups Medium
3 Cups 3 Cups Medium
4Cups 4 Cups Medium
5Cups - Max. Capacity 5Cups - Max. Capacity Medium
RAW RICE LIQUID PRESSURE
2Cups 2 Cups High
3 Cups 3 Cups High
4Cups 4 Cups High
5Cups - Max. Capacity 5Cups - Max. Capacity High

Steamed Vegetables
You may use any vegetable for steaming. Be sure there is at least one cup of liquid in the pot
and place the vegetables on the provided rack Cut vegetables into large enough pieces that
they do not fall through the rack.
1. Add the provided “Rack” in the pot and place vegetables on top of the rack.
Close lid and lock setting Pressure Release Valve to the “down pressure” position. Turn the
pressure control to “Low”- Press the “Steamer” function button and then press start. When
the vegetables are finished the cooker will shut off automatically and go into a warming mode
–four dashes will appear on the front panel (----). Release the pressure using the silicone mitt,
turn the pressure release valve in the “up position”, and when the release valve drops it is safe
to open the cooker.
Since various types of vegetables have different textures you may want to use the manual
“Timer” pressing the “+” or “-” to either increase or decrease the cooking time.
31
STEAM
Steamed Salmon
2Salmon filets (approximately 1/2 lb each and 1” thick)
1 Small onion, chopped
2 Cloves of garlic, whole
2 Bay leaves
1 Cup of lemon juice
1 Cup of water
Salt and pepper to taste
1 Tbsp. of olive oil to anoint cooked salmon
Pour water in the bottom of the cooker add onion, garlic, bay leaves, and lemon. Add the pro-
vided “Rack” in the pot and place Salmon filets on top of the rack.
Close lid and lock setting Pressure Release Valve to the “down pressure” position. Turn the
pressure control to “Low”- Press the “Steamer” function button and then press start. When
the fish is finished the cooker will shut off automatically and go into a warming mode – four
dashes will appear on the front panel (----). Release the pressure and when the release valve
drops it is safe to open the cooker. Plate fish and anoint with olive oil before serving.
Steamed Asian Chilean Sea Bass
2lb. Chilean Sea Bass Filets (approximately 1” thick)
2 Sprigs of green scallions, chopped
2 Cloves of garlic, whole
1 Small piece of fresh ginger, whole
1 Frozen package of pea pods (approximately 10 ounces)
1/2 Cup of light soy sauce
1/2 Cup of water
Salt and Pepper to taste
DIRECTIONS:
1. Pour water and soy sauce in the bottom of the cooker add scallions, garlic, ginger, and pea pods.
2. Add the provided “Rack” in the pot and place sea bass filets on top of the rack.
Close lid and lock setting Pressure Release Valve to the “down pressure” position. Turn the
pressure control to “Low”- Press the “Steamer” function button and then press start. When
the fish is finished the cooker will shut off automatically and go into a warming mode – four
dashes will appear on the front panel (----). Release the pressure and when the release valve
drops it is safe to open the cooker.
30

Fruit
All fruit should be peeled, cored and cut into quarters.
1 Cup of purified water or organic juice
DIRECTIONS:
1. Place fruit and liquid in interior pot.
Close lid and lock setting Pressure Release Valve to the “down pressure” position. Turn the
pressure control to “Medium”- Press the “Baby Food” function button and then press start.
When the content is finished the cooker will shut off automatically and go into a warming mode
–four dashes will appear on the front panel (----). Release the pressure and when the release
valve drops it is safe to open the cooker.
2. Remove contents and use the remaining liquid to puree the mixture into the desired texture.
SLOW COOKER
Corned Beef and Cabbage
5lb. Corned beef
1 Head of cabbage cut into quarters
6 Small red potatoes, whole
Water (fill just below the 3/4 mark)
1. Rinse Corned Beef under cold water.
2. Place meat in cooker and cover with cold water.
3. Add packaged spices.
4. Add cabbage and potatoes.
Close lid but be sure that the pressure release valve is in the up position. You do not want to
use “pressure” when using the slow cooker function. Press the “Slow Cooker” function button
and then press start. The timer will show 4 hours. You need to press the “+” on the timer for
at least 8 hours to slow cook contents. When time is completed the cooker will shut off auto-
matically and go into a warming mode – four dashes will appear on the front panel (----).
33
BABY FOOD
Food safety is crucial when preparing foods for baby. Be sure all your foods are handled with
utmost care to not cross contaminate items. Completely clean all products before use. When
using water at any stage, be sure to use purified water, as tap water is full of contaminants,
such as chlorine, lead, and mercury – which can all negatively impact your growing child.
Puree Vegetables
For baby food you may use any vegetable that is age appropriate for the child. To cook veg-
etables place in the bottom of the interior pot with at least 1 cup of liquid. Water can be sub-
stituted with any type of organic juice.
Chicken with Yellow Squash and Carrots
1Skinless and boneless chicken thigh cut in small pieces
1 Cup yellow squash, chopped
1 Cup carrots, chopped
1 Cup of pure apple juice
DIRECTIONS:
1. Combine all ingredients into the bottom of the interior pot.
Close lid and lock setting Pressure Release Valve to the “down pressure” position. Turn the
pressure control to “Medium”- Press the “Baby Food” function button and then press start.
When the content is finished the cooker will shut off automatically and go into a warming mode
–four dashes will appear on the front panel (----). Release the pressure and when the release
valve drops it is safe to open the cooker.
2. Remove contents and use the remaining liquid to puree the mixture into the desired texture.
32

TROUBLE SHOOTING YOUR
ULTRA COOKER
(Before calling Customer Service)
Ican’t open the lid.
The pressure has not been released.
Using the silicone mitt, turn pressure release valve “up” to release.
While inspecting my valves, I noticed the pressure indicator rod is stuck in down position
The valve needs to slide easily as the lid is tipped back and forth. If this does not happen,
there must be food residue making the valve stick. Cleaning with a toothpick slide through
vent to free the valve.
Ican’t close the lid.
Check the gasket it may need to be reversed. Arrow on the gasket should point down away
from the lid. Is the gasket smoothly fitting into the grooves of the lid? If not, run your fingers
around the gasket with a little pressure to make sure that it is snugly fitting in the grooves.
Now check the pressure indicator valve by poking gently to assure it is working properly.
Lastly, check to see if the pressure release valve is in the “release up” position.
Iheard a strange noise like a “puff”.
No need for concern, your cooker is just adjusting between cycles.
The food isn’t thoroughly cooked.
Were your measurements correct? For example, was the proportion of the rice-to-water
correct?
Did you open and close the lid frequently? It is not recommended to open the lid during
cooking times which have been previously set. Was the pressure release valve open or
closed? Check that the pressure release valve is in the down pressure release position and
not up for release.
Ajet of steam erupted from the pressure release valve.
The pressure release valve is in the “up” release position. Turn it to the “down” seal position.
35
Red Bean Chicken
4Frozen skinless chicken breasts
1 Can of red beans (approximately 15 ounces)
1 Salsa (approximately 8 ounces)
DIRECTIONS:
1. Add all ingredients together.
Close lid but be sure that the pressure release valve is in the up position. You do not want
to use “pressure” when using the “slow cooker” function. Press the “Slow Cooker” func-
tion button and then press start. The timer will show 4 hours. You need to press the “+”
on the timer for at least 8 hours to slow cook contents. When time is completed the cook-
er will shut off automatically and go into a warming mode – four dashes will appear on the
front panel (----).
OATMEAL
Oatmeal
4Cups of water
1 Cup of steel cut oatmeal
DIRECTIONS:
1. Combine all ingredients and mix thoroughly into the bottom of the interior pot.
Close lid and lock setting Pressure Release Valve to the “down pressure” position. Turn
the pressure control to “Medium”- Press the “Oatmeal” function button and then press
start. When the content is finished the cooker will shut off automatically and go into a
warming mode – four dashes will appear on the front panel (----). Allow pressure to drop
naturally, when the release valve drops it is safe to open the cooker.
34

WARRANTY
LIMITED TEN YEAR WARRANTY
Carico International, Inc. warrants your Ultra Cooker to be free from defects in material and
workmanship from date of purchase. Should defects in material or workmanship occur, return
it to Carico International*, and the item will be repaired or replaced free of charge. A $42.00**
processing, shipping and handling charge applies.
ONE YEAR WARRANTY
Silicone Gasket Seal, Gasket Holder, Pressure Release Valve and Detachable Power
Supply Cord are warranted for one year from the purchase date. Should any item become
defective, it will be replaced free within the first year of purchase, a $5.00* processing, shipping
and handling charge applies, for each piece.
FULL LIFETIME HAZARD WARRANTY
Carico International, Inc. agrees to replace all or any piece destroyed by fire, flood, storm earth-
quake or misuse, neglect, accident, or altered in any such way that its performance is affect-
ed for one half of the current retail purchase price at the time of replacement. Proof of purchase
and proof of loss must be submitted to Carico International, Inc. within sixty (60) days of occur-
rence.
** International shipments may incur additional charges. All funds are in U.S. currency.
Proof of purchase required. Please contact your local distributor or order on line at:
www.shop.carico.ws or contact Carico customer service department to place an order.
All warranties are backed by the integrity of Carico International, Inc. These warranties (with the
exception of the FULL LIFETIME HAZARD WARRANTY), do not apply to any part or compo-
nent that has been subject to misuse, neglect or altered in any such way that its performance
is affected, and does not apply to commercial use. These warranties apply only to the original
purchaser. Proof of purchase is required.
*All returns require a Return Authorization Number (RA#). All funds are in U.S. currency.
Please contact your local distributor or Carico’s Customer Service Department to obtain an
RA#. You must include a packing slip, along with the RA# written on the outside of the box.
All approved items must be returned prepaid and properly packaged. Carico International, Inc.
will not be liable for merchandise damaged in transit, lost in transit or damaged caused by
improper packaging.
Carico International, Inc.
2851 Cypress Creek Road
Fort Lauderdale, FL 33309 U.S.A.
1-800-440-1434 954-973-3900
www.carico.com
[email protected]
37
LED shows E2 on the read-out screen.
The interior pot was removed or not sitting properly on the Ultra Cooker’s heating plate with
temperature sensor. If the interior pot is not sitting correctly on the cooker, it is not receiving
the information it needs to calibrate. Please unplug the electric cord for 5-10 seconds, then
carefully re-open the lid rotating the interior pot until it sits properly then re-plug the cord. This
should “reset” the cooker. If this does not work, another reason could be that the tempera-
ture sensor is not working properly. If this is the situation, you will want to contact your local
distributor or Carico’s Customer Service Department for assistance.
You can expect years and years, of great meals from your Ultra Cooker.
The key elements of trouble free cooking are: Do not overload your cooker; the gasket must be
properly installed and the valves must be clean and ready to perform
their function. You must follow all care, use and precaution instructions to have many years of
fun-trouble-free cooking.
36

38
NOTES
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
38
NOTAS
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
_____________________________
