Carinci evolution User manual

TABLE OF CONTENTS
Preface .................................................................................................................................. pag. 6
Preliminary warnings............................................................................................................... pag. 6
1.0 Presentation of the Thermo Fireplace CARINCI .........................................................pag. 7
1.1 Technical specifications and dimensions of the Thermo Fireplace CARINCI SYSTEM........................ pag. 8
1.2 Combustion chamber............................................................................................................... pag. 10
2.0 Positioning of the Thermo Fireplace inside the room ................................................pag.11
2.1 Displacement of the Thermo Fireplace ....................................................................................... pag. 11
2.2 Checking the bearing plate ...................................................................................................... pag. 11
2.3 Checking the walls adjacent to the Thermo Fireplace................................................................... pag. 11
3.0 Flue ........................................................................................................................pag.12
3.1 Flue functions.......................................................................................................................... Pag. 13
3.2 Flue features .......................................................................................................................... pag. 13
3.3 Chimney stack ........................................................................................................................ pag. 14
4.0 Air scoop ................................................................................................................pag.15
5.0 Presentation of the Thermo Fireplace CARINCI EVOLUTION SYSTEM..........................pag.16
5.1 Technical specifications and dimensions of the Thermo Fireplace CARINCI EVOLUTION SYSTEM ..... pag. 17
5.2 KIT SYSTEM position on the Thermo Fireplace CARINCI EVOLUTION............................................ pag. 17
6.0 Installation of the Thermo Fireplace CARINCI EVOLUTION.........................................pag.18
6.1 Open-vented simple installation diagram.................................................................................... pag. 18
6.2 Expansion vessel..................................................................................................................... pag. 19
6.3 Sanitary hot water................................................................................................................... pag. 19
6.4 Process control and shut-off valve .............................................................................................. pag. 19
6.5 Check valve ........................................................................................................................... pag. 19
6.6 Filling the Thermo Fireplace...................................................................................................... pag. 19
6.7 Suction .................................................................................................................................. pag. 19
6.8 Water hammer ....................................................................................................................... pag. 19
6.9 Installation instructions for the Thermo Fireplace CARINCI SYSTEM or IDROKIT............................... pag. 19
6.10 Installation combined with a gas boiler(Equipped with expansion tank and safety valve) [for SYSTEM and IDROKIT]...................... pag. 20
6.10 Installation combined with a gas boiler(not equipped with expansion vessel and safety discharge valve) [for SYSTEM and IDROKIT] ........ pag. 20
6.12 Installation combined with a gas boiler[for SYSTEM and IDROKIT] ............................................................... pag. 20
6.13 Double circuit installation with CARINCI IDROKIT ....................................................................... pag. 22
6.14 Installation of the inspection grill on the hood ............................................................................. pag. 23
6.15 Installation of the inspection side door (to Thermo Fireplace CARINCI SYSTEM).............................. pag. 23
6.16 Overflow pipe for the expansion tank........................................................................................ pag. 23

6.17 Advice for the installer ............................................................................................................. pag. 23
6.18 Advice for the user .................................................................................................................. pag. 23
6.19 Electronic control unit of the Thermo Fireplace CARINCI .............................................................. pag. 24
6.20 Electronic control unit of the Thermo Fireplace CARINCI SYSTEM.................................................. pag. 26
7.0 First start-up with wood burning of THERMO FIREPLACE CARINCI .............................pag.26
7.1 Fuel quality ............................................................................................................................ pag. 26
7.2 Fuel dimensions ...................................................................................................................... pag. 27
8.0 Adjustments............................................................................................................pag.27
8.1 Circulator adjustment and system balancing ............................................................................... pag. 27
8.2 Combustion adjustment............................................................................................................ pag. 27
8.3 Secondary air adjustment......................................................................................................... pag. 29
8.4 Tertiary air adjustment ............................................................................................................. pag. 29
8.5 Inspections ............................................................................................................................. pag. 30
8.6 Proper functioning................................................................................................................... pag. 30
9.0 Covering .................................................................................................................pag.30
10.0 Recommendations for use .......................................................................................pag.31
10.1 Using the Thermo Fireplace CARINCI EVOLUTION in adverse weather conditions .......................... pag. 31
10.2 Door opening ......................................................................................................................... pag. 31
10.3 Use of the Thermo Fireplace CARINCI EVOLUTION with open door.............................................. pag. 31
10.4 Sudden switching-off of Thermo Fireplace CARINCI EVOLUTION.................................................. pag. 31
10.5 Overheating........................................................................................................................... pag. 31
10.6 Possible malfunctions............................................................................................................... pag. 31
11.0 Cleaning of the Thermo Fireplace CARINCI ...............................................................pag.31
11.1 Glass cleaning........................................................................................................................ pag. 31
11.2 Boiler compartment ................................................................................................................. pag 31
12.0 Routine maintenance...............................................................................................pag.32
12.1 Heat exchangers cleaning........................................................................................................ pag. 32
12.2 Proper functioning verification .................................................................................................. pag. 34
13.0 Extraordinary maintenance.....................................................................................pag.34
13.1 Glass replacement .................................................................................................................. pag. 34
13.2 Handle replacement ................................................................................................................ pag. 34
13.3 Sliding mechanism lock ........................................................................................................... pag. 35
14.0 Technical specifications............................................................................................pag.36
Certification of warranty .......................................................................................................... pag. 38

4
FOREWORD
Dear Customer, Carinci Group S.p.A. thanks you for having chosen the Innovative Thermo Fireplace
CARINCI EVOLUTION, the last technological innovation in the heating industry.
The new Thermo Fireplace is available in two versions ,EVOLUTION G with cast iron-covered
combustion chamber and EVOLUTION R , with refractory material-covered combustion chamber.
This Manual provides all the information and practical recommendations for the correct installation, use
and maintenance of the product in compliance with the regulations in force.
PRELIMINARY WARNINGS
a) Each local regulation, including those referring to National and European Standards, must be re-
spected during the installation of the appliance;
b) Do not use the appliance as an incinerator or in any way other than for its intended purposes;
c) Do not use fuels other than the ones recommended;
d) Do not use liquid fuels;
e) When operating, the boiler, and particularly its external surfaces, reach very high temperatures;
handle with care when touching to avoid scalding;
f) Do not perform any unauthorized modification on the appliance;
g) Only use original spare parts as recommended by the manufacturer;
h) In the case of the flue catching fire, close the Thermo Fireplace door and use a wet fireproof fabric
to block up the airshaft window (air inlet) located in the upper part of the door and wait for the
combustion to extinguish.
i) To avoid any holes in the boiler body, it is necessary to install adequate protection against power
streams like electrochemical, electrostatic, etc.
heating system innovations

5
The only real alternative
to the same old thermo fireplace
1.0 PRODUCT PRESENTATION
The CARINCI EVOLUTION Thermo Fireplace is built to satisfy the needs of the customer. Its design allows the placement
in any environment. The innovation of our product is in the technical enhancements, which provide an efficiency like
no other.
The CARINCI Thermo Fireplace, in fact, has been designed as a real boiler for sanitary hot water production and as
a heating appliance.
The boiler, inside which the water (thermo courier fluid) circulates, uses special exchangers located within
the combustion chamber, easy to inspect for their cleaning.
These exchangers ensure proper circulation of thermo courier fluid even at very high temperatures, eliminating the bother
of the boiling noise and ensuring the maximum safety of the user in any condition, even during a temporary lack of power.
The efficiency is optimized by the presence of an “air restrictor” located in the upper-front of the Thermo Fireplace-boiler that
allows the entrance of premixed air, giving rise to a steady and homogeneous flame. Also the base of the Thermo Fireplace-
boiler affects the yield being made of refractory (fire-resistant) bricks 1350°C vertically positioned with 11 cm thickness
gauge, allowing it to maintain a constant temperature.
