Carnival King 382NCM160 User manual

nacho chip merchandiser
www.CarnivalKingSupplies.com
#382NCM160 03/2020
User manual

2
www.CarnivalKingSupplies.com .||||| [e-mail]
nacho CHIP MERCHANDISER
SAFETY PRECAUTIONS
1. This manual will outline safety warnings and precautions, operating, maintenance and cleaning. The
warnings and instructions reviewed in this manual cannot cover all possible conditions and situations that
may occur. Factors such as caution and common sense cannot be built into this product and it is trusted
the operator will follow these measures.
2. This merchandiser must never be modified and should only be used for its intended purpose.
3. Always check that this merchandiser is plugged into a grounded outlet with the appropriate electrical
supply. Ensure that the wall outlet being used is properly grounded. If it is not, you must install a grounded
outlet. Have the work performed only by a certified electrician who is properly qualified to meet local safety
and electrical codes.
4. Before disconnecting from the power source, be sure that all switches have been turned OFF. To unplug
the product, firmly grasp the plug and remove from the outlet – never pull on the cord itself.
5. Ensure that the power outlet, plug and cord being used are in good, working condition. Damaged
components should be repaired by a certified electrician who is qualified to meet local safety and
electrical codes. Even with a properly functioning power cord, keep water away from the cord and avoid
letting your power cord run over carpets or heating devices.
6. If missing or broken components are found, leave the merchandiser TURNED OFF. Do not attempt to use
the merchandiser. Contact a qualified service technician to make all repairs.
7. Use in the presence of flammable liquids, gases, dust or other explosive situations should be avoided.
8. Never directly touch the bottom of the heating cabinet when in use. Metal surfaces will be extremely hot
during and after use, and should be allowed to cool before transporting or putting the unit in storage.
9. It is not recommended the machine be used outdoors.
10. Manual cleaning required – unit and parts are not dishwasher safe.
Do not use abrasive cleaning products
Warmer/Merchandiser Specs
Item# 382NCM160
Unit Dimensions 15.5” x 12.5” x 22.5”
Voltage 120V
Total Wattage 160W
Bulb Wattage 60W
Heating Deck
Wattage 100W
Plug 5-15P
Cord Length 5’
Certications ETL

3
www.CarnivalKingSupplies.com .||||| [e-mail]
nacho CHIP MERCHANDISER
Parts Key
1Top Cover Handle 10 Bulb Holder 19 Drop Down Door 28 Tray Holder Bottom Plate
2 Top Cover 11 Front Stand 20 Bottom Plate 29 Tray
3 Top Plate 12 Bulb 21 Warmer Wire Box Cover 30 Bottom
4 Bulb Cover 13 Side Glass 22 Warmer Holder Cover 31 Warmer Wire Box Cover Shim
5 Side Glass Holder 14 Back Stand 23 Warmer Element 32 Fuse
6 Front & Back Glass Holder 15 Magnet 24 Warmer Wire Box 33 Feet
7 Front Glass 16 Bottom Glass Holder 25 Thermostat 34 Switch
8 Back Glass 17 Magnet Holder 26 Tray Holder 35 Power Line and Plug
9 Bulb Wire 18 Deection Plate 27 Warmer Shim 36 Scoop
Exploded Parts

4
www.CarnivalKingSupplies.com .||||| [e-mail]
nacho CHIP MERCHANDISER
Wiring Diagram
switch
AC120V
switch:开关，6A,125VAC
Heater:电热管，120VAC，100W
lamp:灯，120VAC，60W
Thermostat :恒温器，120VAC,12A,65℃
L
N
佛山市伊登电器有限公司
电路图
标记
设计
制图
校对 审核
审定
标准
文件号处数 签名
爆米花保温箱
重量 数量 比例
共 张 第 张
120V
Heater
lamp
Thermostat
Electrical Components
Switch 6A, 125VAC
Heater 120VAC, 100W
Lamp 120VAC, 60W
Thermostat 120VAC, 12A, 149°F/65°C

5
www.CarnivalKingSupplies.com .||||| [e-mail]
nacho CHIP MERCHANDISER
Operating Instructions
1. Before use, securely station the Merchandiser on a dry, level surface that is away from any water. Be sure to clean
the glass surfaces and wipe down the interior with a clean, damp sponge.
2. This unit comes with 3 options for decals- Popcorn, Nacho Chips and Peanuts. If you decide to use the decals, it’s
recommended to use them on different sides of the merchandiser to give it versatility. You can then have whatever
you’re serving that day face the customers.
3. Plug the power cord into a properly grounded electrical outlet.
4. Turn the power switch on which will activate the light and warming deck. The switch is located on the side of the
unit near where the power cord connects.
5. Allow the merchandiser to preheat for 3-4 minutes, or until you can feel the heat coming from the unit.
6. Open the top lid and add the contents you want to keep warm. If using Nacho chips, there is a guard that helps
the chips from breaking. Ensure that guard is installed properly.
7. When ready to serve, the door pulls out from the top latch and towards the user. You can now reach in and serve
the popcorn, nachos or peanuts using a scoop.
8. When finished, be sure to turn off and unplug the machine from its power supply.
Cleaning & Maintenance
** ONCE YOU ARE FINISHED, UNPLUG THE POWER SUPPLY AND ALLOW AMPLE TIME FOR THE UNIT TO
COOL. IT MAY STILL BE HOT. **
Clean the cabinet after every 3 or 4 uses, or before it is going to be stored for an extended period of time.
1. With the switch off and the unit cooled, use a degreaser such as Noble Chemical’s Formula D Decarbonizer and
Degreaser (147FORMULAD) and a damp cloth to wipe the interior and exterior. Make sure the cabinet glass stays
clean and clear by wiping with a window cleaner, such as Noble Chemical’s Reflect Glass Cleaner (147REFLECT).

6
www.CarnivalKingSupplies.com .||||| [e-mail]
nacho CHIP MERCHANDISER
Equipment Limited Warranty
To Make a Warranty Claim:
For Warranty Inquiries contact the location where you purchased the product:
• WebstaurantStore.com: Contact [e-mail]. Please have your order number ready.
• The Restaurant Store: If you purchased this unit from your local store, please contact your store directly.
• TheRestaurantStore.com: Online purchases, call 717-392-7261. Please have your order number ready.
Failure to contact the designated location prior to obtaining equipment service may void your warranty.
Carnival King makes no other warranties, express or implied, statutory or otherwise, and HEREBY DISCLAIMS ALL
IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND OF FITNESS FOR
A PARTICULAR PURPOSE.
This Limited Warranty does not cover:
• Equipment sold or used outside the Continental United States
• Use of unfiltered water (if applicable)
• Carnival King has the sole discretion on wearable parts not covered under warranty
• Equipment not purchased directly from an authorized dealer
• Equipment used for residential or other non-commercial purposes
• Equipment that has been altered, modified, or repaired by anyone other than an authorized service agency
• Equipment where the serial number plate has been removed or altered.
• Damage or failure due to improper installation, improper utility connection or supply, and issues resulting from
improper ventilation or airflow.
• Defects and damage due to improper maintenance, wear and tear, misuse, abuse, vandalism, or Act of God.
Any action for breach of this warranty must be commenced within 6 months of the date on which the breach
occurred. No modification of this warranty, or waiver of its terms, shall be effective unless approved in a writing
signed by the parties. The laws of the Commonwealth of Pennsylvania shall govern this warranty and the parties’
rights and duties under it. Carnival King shall not under any circumstances be liable for incidental or consequential
damages of any kind, including but not limited to loss of profits.
Carnival King warrants its equipment to be free from defects in material and workmanship for a period of 6 months.
This is the sole and exclusive warranty made by Carnival King covering your Carnival King brand equipment.
A claim under this warranty must be made within 6 months from the date of purchase of the equipment.
Only the equipment’s original purchaser may make a claim under this warranty. Carnival King reserves the right to
approve or deny the repair or replacement of any part or repair request. The warranty is not transferable.
Carnival King Equipment installed in/on a food truck or trailer will be limited to a period of 30 days from the
original date of purchase.
