INTRODUCTION
Thank you for choosing Carpenter Mfg. Co. Inc. Wire Processing Equipment.
For over 50 years Carpenter has been a leader in
Wire Processing Technology and Service.
Our desire has always been to bring you reliable products.
We look forward to a long healthy relationship with you and our company.
The Model 93 can process a wide range of cables as referenced on the following page.
These stripping specifications are based upon the
most commonly manufactured cables.
Special applications may arise with cables that are
within the specification limits of the machine but are very difficult
or unsuccessful to strip.
Likewise, cables that exceed the specified limits
of the machine can sometimes be processed.
Because there are many variables involved in Wire Processing
we strongly recommend a free Wire Evaluation at our factory
followed by a demonstration from a Carpenter representative
to insure the ultimate success of your Wire Processing Application.
This operating manual explains how to operate
the Model 93 as well as some troubleshooting tips.
To ensure the best performance of your machine,
read this manual carefully until you familiarize yourself
thoroughly with its operation and features.
After you have read through the manual, keep it available for reference.
Use this manual as a quick and handy reference
tool for clarifying any questions that may arise.
If you have any questions about this
machine or service please let us know.
Our phone number is 315.682.9176, fax number 315.682.9160.
Carefully unpack the Carpenter Model 93.
We recommend that you keep the original box and packaging
as it will protect the machine for future transportation if necessary.

CARPENTER MODEL 93 COMPU-STRIP Phone: [phone] Fax: [phone] Page 3
Revised 08/23/13 Website: www.carpentermfg.com E-mail: [email protected]
CARPENTER MODEL 93 COMPU-STRIP
IMPORTANT NOTICE
The products in this shipment left our facility in good working condition.
Their safe delivery is the responsibility of the carrier that
delivered this shipment to you.
Our stated shipping terms are F.O.B. our facility at
110 Fairgrounds Drive, Manlius, NY 13104.
According to applicable laws, the responsibility for this
shipment was transferred to you as soon as the carrier
accepted the goods at our warehouse.
If concealed damage is discovered after unpacking this shipment,
you must submit a damaged freight claim with the carrier.
Carpenter Mfg. Co., Inc. cannot submit your claim for you.
In order for you to collect for concealed damage,
the carrier must be notified with 5 days
of the date you receive this shipment.
You must leave the damaged items and packing material as is
(i.e. return all merchandise and all packing material to the shipping container)
until the claim has been inspected by the carrier.
Also, the carrier will not accept a claim if the goods have
been moved from the point of the
carriers delivery to another street address.
If you have any questions or problems,
please give us a call at 315.682.9176.

CARPENTER MODEL 93 COMPU-STRIP Phone: [phone] Fax: [phone] Page 4
Revised 08/23/13 Website: www.carpentermfg.com E-mail: [email protected]
CARPENTER MODEL 93 COMPU-STRIP
CAUTION
This equipment comes equipped with a
LEXAN safety guard,
containing a safety interlock switch.
The machine will not operate unless
the guard is in the closed position.
**IMPORTANT**
Do not attempt to defeat the function
or purpose of the safety interlock switch.
Serious injury to the operators’ eyes, fingers or other body
parts may result from attempts to operate this equipment
with the safety guard in the raised position.

CARPENTER MODEL 93 COMPU-STRIP Phone: [phone] Fax: [phone] Page 5
Revised 08/23/13 Website: www.carpentermfg.com E-mail: [email protected]
CARPENTER MODEL 93 COMPU-STRIP
MACHINE CONTENTS
Machine comes complete with the following:
1pc. #8019 Power Cord
1pc. #8393 Single Plane Wire Straightener
1pc. #8836 Guide Tube Holder
7pcs. #8500 1-7 Input Guide Tubes
7pcs. #8815 1-7 Exit Guides
1pc. #8858 9/64” Hex Wrench
1pc. #2934 3/32” Hex Wrench
1pc. Operators Manual
PLEASE REFER TO PAGE 6 FOR INSTALLATION INSTRUCTIONS.
#8019
Power Cord
#3947 Screws
#1810 Washers
2 pcs. each
#2934 3/32” Hex Wrench
#8858 9/64” Hex Wrench
#8500
Input Guide Tubes
1mm - 7mm
#8815
Exit Guides
1mm - 7mm
#8393 Wire Straightener
#8836 Guide Tube Holder

CARPENTER MODEL 93 COMPU-STRIP Phone: [phone] Fax: [phone] Page 6
Revised 08/23/13 Website: www.carpentermfg.com E-mail: [email protected]
CARPENTER MODEL 93 COMPU-STRIP
INSTALLATION INSTRUCTIONS
SAFETY GUARDING
The Model 93 comes equipped with a LEXAN guard containing a safety interlock switch. The machine will not run unless
the guard is in the closed position **IMPORTANT** DO NOT ATTEMPT TO DEFEAT THE FUNCTION OR PURPOSE OF
THE SAFETY INTERLOCK SWITCH. SERIOUS INJURY TO THE OPERATORS EYES, FINGERS OR OTHER BODY
PARTS MAY RESULT FROM ATTEMPTS TO OPERATE THE MODEL 93 WITH THE SAFETY GUARD IN THE RAISED
POSITION.
WIRE GUIDE HOLDER / WIRE STRAIGHTENER
The Model 93 comes equipped with #8836 Guide Tube Holder with #8393 Wire Straightener attached. Install holder to
the left side of the cabinet with (2) #3947 Screws and (2) #1810 Washers. After installation place the Input
Guide Tubes and
Exit Guides into the holes. The Wire Straightener is used to remove or reduce the memory (curvature) in the wire. Adjust
the rollers to allow for straightening without restricting movement.

CARPENTER MODEL 93 COMPU-STRIP Phone: [phone] Fax: [phone] Page 7
Revised 08/23/13 Website: www.carpentermfg.com E-mail: [email protected]
CARPENTER MODEL 93 COMPU-STRIP
**IMPORTANT**
PLEASE READ ENTIRE INSTRUCTIONS BEFORE OPERATING MACHINE
APPLICATIONS
The Model 93 Compu-Strip is designed to cut and strip solid or stranded wire, multi conductor cable and flat cable with any
of the following applications.
Cut wire or tubing to length only.
Cut and full strip single or both ends.
Cut and partial strip single or both ends.
Cut and full strip single or both ends with window strip on right.
Cut and partial strip single or both ends with window strip on right.
NOTE: A motorized Prefeed, Carpenter Model 56A or 58B, may be necessary to assist the Model 93.
SPECIFICATIONS
ELECTRICAL CONNECTION 88-264 VAC, 47-63 Hz Self Adjusting
AIR BLAST CONNECTION 30-50 P.S.I. **CLEAN & DRY AIR ONLY**
MAIN FUSES 2 - 5 x 20mm 6AMP Fast Action
MAXIMUM CABLE DIAMETER .275 inches or 7mm
STRANDED COPPER WIRE 32AWG through 12AWG
SOLID COPPER WIRE 32AWG through 12AWG
FLAT CABLE Up to .520” width
LENGTH 0.01 through 9,999.99inches or 0.2 through 99,999.9mm(longer lengths obtainable in
inches)
BLADE DEPTH .001 through .350 inches or 0.01 through 8.9mm
QUANTITY 1 - 999,999 pcs.
LEADING END STRIP LENGTH 0.01 through 2.00 inches or 0.2 through 152.4mm
TRAILING END STRIP LENGTH 0.01 through 2.00 inches or 0.2 through 76.2mm
UNIT OF MEASURE Inches or mm User selectable
TRANSPORT SPEEDS 4 Programmable
PULL SPEEDS 5 Programmable
BLADE SPEEDS 4 Automatic Default or User selectable
MEMORY 500 Programs
PROGRAM STACKING 5 Programs
PASSWORD PROTECTION User Programmable
NOISE LEVEL 70 dB
DIMENSIONS LxDxH 14.75 x 13.37 x 11.0 inches or 374.6 x 339.6 x 275.0 mm
WEIGHT 55 lb. or 25 kg.
PRODUCTION RATES
20 AWG Stranded Copper Wire
with #8961C HSS Coated “V” Blades
LENGTH STRIPPED BOTH ENDS
2.5” 4200 Pcs./Hr.
4.0” 3840 Pcs./Hr.
10.0” 3120 Pcs./Hr.

CARPENTER MODEL 93 COMPU-STRIP Phone: [phone] Fax: [phone] Page 8
Revised 08/23/13 Website: www.carpentermfg.com E-mail: [email protected]
CARPENTER MODEL 93 COMPU-STRIP
SETUP
MACHINE SETUP
Plug female end of Power Cord into the Power Entry Module, located on the left side of machine. Plug the male end into a
proper electrical outlet. Turn on power switch.
INPUT GUIDE TUBE SELECTION
The Model 93 comes equipped with seven different Input Guide Tubes 1-7 (sizes are stamped on each guide).
An Input Guide Tube must be used in all cases. Select the guide tube with the smallest inside diameter that slips freely
over the outside diameter of the wire to be stripped. To change an Input Guide Tube simply loosen #8087 Thumb Screw.
After replacement make sure the Thumb Screw is securely tightened.
EXIT GUIDE SELECTION
The Model 93 comes equipped with seven different Exit Guides 1-7 (sizes are stamped on each guide). Select the
Exit Guide that is numbered the same as the Input Guide Tube selected above. Example: A #2 Input Guide Tube will use
a #2 Exit Guide. NOTE: The Exit Guide must be removed when processing wire in the Short Wire Mode (see Page 16).
To change an Exit Guide simply loosen #5459 Thumb Screw. After replacement make sure the Thumb Screw is securely
tightened.

CARPENTER MODEL 93 COMPU-STRIP Phone: [phone] Fax: [phone] Page 9
Revised 08/23/13 Website: www.carpentermfg.com E-mail: [email protected]
CARPENTER MODEL 93 COMPU-STRIP
SETUP
cont.
LOADING WIRE
Open the Leading Strip and Trailing Strip Rollers far enough to allow the wire to pass through freely. Feed the wire
through the Wire Straightener, underneath the Out of Material Rod, through the Centering Rollers, through the
Leading Strip Rollers and just into the entrance of the Input Guide Tube. Adjust the Centering Rollers up to the
wire but not touching the wire. Adjust the Leading Strip Rollers until they make contact with the wire. Select LOAD WIRE
key and keep it pressed down until the wire is completely fed through the machine. Once the wire has exited, release the
switch. The LCD screen will display CHECK TRAILING STRIP ROLLER PRESSURE, THEN CLOSE GUARD AND
PRESS ENTER. Adjust the Trailing Strip Rollers until they make contact with the wire, close the Safety Guard and then
Press ENTER. This will cut the wire and feed the slug from the machine. The Model 93 is now ready to program and
process your wire.
PLEASE NOTE THE MODEL 93 IS PICTURED WITHOUT THE SAFETY GUARD FOR DEMONSTRATION PURPOSES ONLY.
#5459 Thumb Screw
#8815 Exit Guide
#8500 Input Guide Tube
#8087 Thumb Screw
Centering Rollers Adjustment Knob
Out of Material Rod
Leading Strip Roller
A
d
j
ustment Knob
Trailing Strip Roller
A
d
j
ustment Knob
LOAD
WIRE

CARPENTER MODEL 93 COMPU-STRIP Phone: [phone] Fax: [phone] Page 10
Revised 08/23/13 Website: www.carpentermfg.com E-mail: [email protected]
CARPENTER MODEL 93 COMPU-STRIP
PROGRAMMING
LCD DISPLAY SAMPLES
Program
Stacking
A
ctivated
Leading
Blade
Depth
Trailing
Blade
De
p
th
A
mountBatching
Activated
Pull Speed
Unit of
Measure
Batching
Current # / Total
Program
Number
Feed
Speed
Wire Marker
Activated
Trailing
Strip
Step Back
Trailing
Pull Wire
Gau
g
e
Wire Type
S– Solid
M– Multi/Stranded
F-Flat
Length Leading
Pull Leading
Strip

CARPENTER MODEL 93 COMPU-STRIP Phone: [phone] Fax: [phone] Page 11
Revised 08/23/13 Website: www.carpentermfg.com E-mail: [email protected]
CARPENTER MODEL 93 COMPU-STRIP
PROGRAMMING
NORMAL MODE
**IMPORTANT**
DO NOT USE SHARP OBJECTS ON KEYBOARD SWITCHES. FINGER TIP PRESSURE IS SUFFICIENT.
Turn on power switch located at the left side of machine. Red LED next to NORMAL MODE wire sample will light.
LCD DISPLAY PROMPT ACTION REQUIRED
CARPENTER MFG. Press ENTER.
MODEL 93 COMPU STRIP
VERSION
PLEASE PRESS ENTER
Press TRAILING STRIP key. This value is the length of insulation to be stripped from
the left end (trailing end) of wire.
0.00 Enter dimension. Press ENTER.
PLEASE ENTER
TRAIL STRIP LENGTH
PLEASE ENTER Enter number of strip steps. Press ENTER. NOTE: The Step Stripping feature
enables NUMBER OF PULL STEPS the user to program the Model 93 to remove the desired insulation
in a series of steps STEPS = 1 from 1 to 9. Step Stripping can be of benefit when doing long strips or when
processing wire with hard to slide insulation. If more than 1 step is desired the Model 93 will
automatically calculate the amount of insulation to be removed at each step to achieve
the overall programmed strip length.
IMPORTANT: Caution should be used when using the Step Strip feature as the more
steps used to remove the insulation, the more the wire is shuttled back and forth
increasing the chance of wire slippage, resulting in inconsistent wire lengths.
Press TRAILING PULL key. This value is the distance the slug of insulation is pulled
on the trailing end of the wire
0.00 Enter dimension. For a full strip enter a value greater than the overall trailing strip
PLEASE ENTER length. For a partial strip enter a value less than the overall trailing strip length.
TRAIL PULL LENGTH Press ENTER.
Press WIRE LENGTH key. This value is the overall length of pieces being processed.
0.00 Enter dimension. Press ENTER.
PLEASE ENTER
OVERALL WIRE LENGTH
TRAILING
STRIP
TRAILING
PULL
WIRE
LENGTH

CARPENTER MODEL 93 COMPU-STRIP Phone: [phone] Fax: [phone] Page 12
Revised 08/23/13 Website: www.carpentermfg.com E-mail: [email protected]
CARPENTER MODEL 93 COMPU-STRIP
PROGRAMMING
NORMAL MODE
cont.
LCD DISPLAY PROMPT ACTION REQUIRED
Press LEADING STRIP key. This value is the length of insulation to be stripped from
the right end (leading end) of the wire.
0.00 Enter dimension. Press ENTER.
PLEASE ENTER
LEAD STRIP LENGTH
PLEASE ENTER Enter number of strip steps. Press ENTER.
NUMBER OF PULL STEPS NOTE: The same notes and warning under PLEASE ENTER NUMBER OF PULL
STEPS = 1 STEPS on the previous page, apply to this set up also. Please reread them.
Press LEADING PULL key. This value is the distance the slug of insulation is
pulled on the leading end of the wire.
0.00 Enter dimension. For a full strip enter a value greater than the overall leading strip
PLEASE ENTER length. For a partial strip enter a value less than the overall leading strip length.
LEAD PULL LENGTH Press ENTER.
Press BLADE DEPTH key. This key allows access to answer questions about the wire
being processed. Ex. Wire Type, Wire Gauge, Strip Depth, Stepback, Blade Speed,
Guide Tube Size.
SELECT WIRE TYPE Use the number keys to select wire type. Arrow will indicate current setting.
1 – SOLID (S) Press ENTER. When Flat Cable is selected proceed to Page 30 for specific
2 – STRANDED (M) programming instructions.
3 – FLAT (F)
PLEASE ENTER WIRE Enter wire gauge of cable, 32 to 12 gauge. Press ENTER.
GAUGE HERE OR STRIP NOTE: If processing multi conductor or flat cable proceed to next screen.
DEPTH ON NEXT MENU.
WIRE GAUGE=
PLEASE ENTER LEAD The Model 93 will default to a preset nominal blade depth based upon wire gauge
BLADE STRIP DEPTH previously entered. You may accept this or change according to cable being
processed.
OR PRESS ENTER To open blades enter a higher value and to close blades enter a lower value.
STRIP DEPTH = To process multi conductor cable enter strip depth dimension based upon overall
dimension of inner conductors. Press ENTER.
LEADING
STRIP
LEADING
PULL
BLADE
DEPTH

CARPENTER MODEL 93 COMPU-STRIP Phone: [phone] Fax: [phone] Page 13
Revised 08/23/13 Website: www.carpentermfg.com E-mail: [email protected]
CARPENTER MODEL 93 COMPU-STRIP
PROGRAMMING
NORMAL MODE
cont.
LCD DISPLAY PROMPT ACTION REQUIRED
PLEASE ENTER TRAIL The trailing strip depth will always default to the same as the leading strip depth. This
BLADE STRIP DEPTH value may be changed if necessary.
OR PRESS ENTER
STRIP DEPTH =
PLEASE ENTER This controls the length of time the blades will pause at both the Leading and Trailing
BLADE DWELL TIME Strip depths. When stripping thick or hard to cut insulation a longer dwell time may
0.00 SECONDS be necessary to allow the blades to cut through the insulation and provide a clean strip.
Enter a value between 0.01 – 2.50 seconds. Press ENTER.
PLEASE ENTER The step back controls the amount which the blades retract after cutting the wire
STEP BACK DISTANCE insulation and before pulling the insulation off the wire. Example: After running a test
STEP BACK = wire through the Model 93 you see that the inner conductor has been scraped. You
would now enter a value (.001”-.050”) to retract the blades. This value is automatically
added to the entered Blade Depth so that a clean strip can be obtained. IMPORTANT:
There is a big difference between “nicking” and “scrapping” the inner conductors of the
wire. Nicking is when the blades cut too deep into the insulation, and is observed right
at the shoulder of the stripped wire. Scraping is observed not at the shoulder of the
strip, but along the length of the inner conductor as the insulation slug is stripped from
the wire. Nicking is corrected using the Blade Strip Depth feature and scrapping is
corrected using the Step Back feature.
Press ENTER.
PLEASE ENTER BLADE The Model 93 will default to a blade speed appropriate to the type of wire/cable being
SPEED(1 THRU 4) processed. You may accept or change this value.
DEFAULT IS 1 Press ENTER
SPEED =
PLEASE ENTER Enter the Guide Tube Size previously determined and installed on machine.
GUIDE TUBE SIZE Press ENTER. NOTE: It is important to enter the correct Guide Tube number because
GUIDE TUBE = this entry controls the blade opening.
Press FEED SPEED key. This setting determines the speed of the wire passing
through the machine.
PLEASE ENTER FEED Select 1-slow, 2-slow/medium, 3-medium ,4 -fast. Press ENTER.
SPEED (1 THRU 4) NOTE: When selecting speed 1 or 2 the maximum Pull Speed that can be selected is
4.
SPEED =
Press PULL SPEED key. This setting determines the pull force of insulation being
removed.
FEED
SPEED
PULL
SPEED

CARPENTER MODEL 93 COMPU-STRIP Phone: [phone] Fax: [phone] Page 14
Revised 08/23/13 Website: www.carpentermfg.com E-mail: [email protected]
CARPENTER MODEL 93 COMPU-STRIP
PROGRAMMING
NORMAL MODE
cont.
LCD DISPLAY PROMPT ACTION REQUIRED
PLEASE ENTER PULL Select pull speed 1(maximum pulling force),2 & 3(medium pulling force),
SPEED (1 THRU 5) 4 & 5(minimum pulling force). Press ENTER.
SPEED =
Press AMOUNT key. This value is the number of wires to be processed. Also allows
access to Multiple Batch Processing mode.
CHANGE CURRENT NOTE: If using the multiple batch feature; during initial programming this entry can
AMOUNT be ignored and proceed to next screen. During the actual processing this screen may
OR PRESS ENTER be used to change the current batch total without affecting any subsequent batches.
PLEASE ENTER The batch feature allows you to process required pieces in a single or multiple
NUMBER OF BATCHES batch(es). To process required pieces in one batch enter “1”. Press ENTER.
TO RUN To process total amount in multiple batches, enter number of batches to process.
Press ENTER.
PLEASE ENTER Enter amount of pieces to process per batch. Press ENTER.
AMOUNT TO PROCESS
PER BATCH
PLEASE SELECT Use the arrow keys to select BATCH or TOTAL display mode. Press ENTER.
AMOUNT TO DISPLAY BATCH mode will count DOWN the number of pieces per batch. TOTAL mode will
DISPLAY = BATCH count UP the number of pieces per batch. Both modes will display on the screen
BATCH TOTAL the descending or ascending piece count of the current batch being processed. The
display will also show the current batch number being processed/total batches to be
processed.
PRESS CLEAR TO This screen will display the running total number of pieces that have been processed
RESET TOTAL COUNTER from the current batch sequence. This amount maybe reset to zero or left alone.
OR PRESS ENTER Press ENTER.
TOTAL=
ROLLER PRESSURE
Roller pressure is adjusted by turning the knobs on the front of the machine labeled LEADING STRIP PRESSURE and
TRAILING STRIP PRESSURE. The goal is to achieve enough pressure to hold the wire and remove any insulation. Too
little pressure allows the wire to slip between the Feed Rollers. Slippage may cause incorrect “slug pull” dimension. Too
much pressure may result in wire not tracking straight through the machine. You may have to adjust the pressure a couple
of times to achieve the desired grip.
AMOUNT

CARPENTER MODEL 93 COMPU-STRIP Phone: [phone] Fax: [phone] Page 15
Revised 08/23/13 Website: www.carpentermfg.com E-mail: [email protected]
The Model 93 is now programmed to process your wire. You are now ready to run a sample wire and check for initial strip
quality. The following will assist you in processing your sample.
CARPENTER MODEL 93 COMPU-STRIP
PROGRAMMING
NORMAL MODE
cont.
SINGLE CYCLE
Select SINGLE CYCLE key to produce one complete sample wire to check for accuracy. If corrections are necessary for
anything but overall length, then select the corresponding key on the Control Panel and make your adjustments. If length
corrections are necessary then proceed to LENGTH CORRECTION.
LENGTH CORRECTION
The Model 93 has a Length Correct feature that allows the operator to make adjustments from the preprogrammed length
versus the actual sample length. Small variations are normal due to differences in material, tension, friction, wire diameter
etc. If the sample wire was not the correct length select the LENGTH CORRECT key for adjustments.
LCD DISPLAY PROMPT ACTION REQUIRED
PLEASE ENTER Measure the length of the sample wire produced; enter this value for length.
MEASURED WIRE LENGTH Press ENTER. The Model 93 will automatically calculate the correction necessary.
The 0.00 next sample should be the exact length you programmed.
The possible range of correction is +/- 10% of the overall wire length. If a value outside of this range is entered an error
message will appear and display the acceptable range of values.
The length correct value may be changed multiple times but typically a single entry is all that is required if the sample wire
was measured accurately and the data entered correctly.
RUN PROGRAM
After you have produced a satisfactory sample wire and all settings are correct press RUN. This will process your current
program.
STOP PROGRAM
If at any time you need to stop your processing press STOP. This action will stop the processing and wire feed.
UNLOADING WIRE
SINGLE
CYCLE
LENGTH
CORRECT
RUN
STOP
UNLOAD
WIRE

CARPENTER MODEL 93 COMPU-STRIP Phone: [phone] Fax: [phone] Page 16
Revised 08/23/13 Website: www.carpentermfg.com E-mail: [email protected]
Unload wire by pressing the UNLOAD WIRE key. Wire will automatically feed backwards through machine as long as the
key is depressed.
CARPENTER MODEL 93 COMPU-STRIP
SHORT MODE
MACHINE SETUP
The Model 93 has the capability of processing wire with stripping specifications of two inches or less of insulation left
between the stripped ends. To process wire in SHORT MODE you must first prepare the Model 93. Please refer to the
following instructions and photograph for this procedure.
1. Turn machine off and unplug.
2. Remove the Exit Guide.
3. Separate the Trailing Strip Rollers via the Trailing Strip Pressure Knob.
4. Remove #6134 Clamp Collar on both Rollers.
5. Remove both Trailing Strip Rollers.
Proceed to the next page and follow the programming instructions for SHORT MODE.
#6134 Clamp Collar
Trailing Strip Rollers
Note: Shown with optional
Knurled Metal Feed
Trailing Strip
Pressure Knob
Exit Guide Holder

CARPENTER MODEL 93 COMPU-STRIP Phone: [phone] Fax: [phone] Page 17
Revised 08/23/13 Website: www.carpentermfg.com E-mail: [email protected]
CARPENTER MODEL 93 COMPU-STRIP
PROGRAMMING
SHORT MODE
The Model 93 has the capability of processing wire with stripping specifications of two inches or less of insulation left
between the stripped ends. The LCD display will read SHORT when the short wire mode is activated based upon the
stripping parameters you have entered.
LCD DISPLAY PROMPT ACTION REQUIRED
CARPENTER MFG. Press ENTER.
MODEL 93 COMPU STRIP
VERSION
PLEASE PRESS ENTER
Press TRAILING STRIP key. This value is the length of insulation to be stripped from
the left end (trailing end) of wire.
0.00 Enter dimension. Press ENTER.
PLEASE ENTER
TRAIL STRIP LENGTH
PLEASE ENTER Machine will default to “1”. Press ENTER. When operating machine in SHORT MODE
NUMBER OF PULL STEPS only one pull step is allowed due to the short processing lengths.
STEPS = 1
Press WIRE LENGTH key. This value is the overall length of pieces being processed.
0.00 Enter dimension. Press ENTER.
PLEASE ENTER
OVERALL WIRE LENGTH
Press LEADING STRIP key. This value is the length of insulation to be stripped from
the right end (leading end) of the wire.
0.00 Enter dimension. Press ENTER.
PLEASE ENTER
LEAD STRIP LENGTH
PLEASE ENTER Machine will default to “1”. Press ENTER. When operating machine in SHORT MODE
NUMBER OF PULL STEPS only one pull step is allowed due to the short processing lengths.
STEPS = 1
TRAILING
STRIP
WIRE
LENGTH
LEADING
STRIP

CARPENTER MODEL 93 COMPU-STRIP Phone: [phone] Fax: [phone] Page 18
Revised 08/23/13 Website: www.carpentermfg.com E-mail: [email protected]
CARPENTER MODEL 93 COMPU-STRIP
PROGRAMMING
SHORT MODE
cont.
LCD DISPLAY PROMPT ACTION REQUIRED
Press LEADING PULL key. This value is the distance the slug of insulation is pulled
on the leading end of the wire.
0.00 Enter dimension. For a full strip enter a value greater than the overall leading strip
PLEASE ENTER length. For a partial strip enter a value less than the overall leading strip length.
LEAD PULL LENGTH Press ENTER.
Press BLADE DEPTH key. This key allows access to answer questions about the wire
being processed. Ex. Wire Type, Wire Gauge, Strip Depth, Stepback, Blade Speed,
Guide Tube Size.
SELECT WIRE TYPE Use the number keys to select wire type. Arrow will indicate current setting.
1 – SOLID (S) Press ENTER. When Flat Cable is selected proceed to Page 29 for specific
2 – STRANDED (M) programming instructions.
3 – FLAT (F)
PLEASE ENTER WIRE Enter wire gauge of cable, 32 to 12 gauge. Press ENTER.
GAUGE HERE OR STRIP NOTE: If processing multi conductor or flat cable proceed to next screen.
DEPTH ON NEXT MENU.
WIRE GAUGE=
PLEASE ENTER LEAD The Model 93 will default to a preset nominal blade depth based upon wire gauge
BLADE STRIP DEPTH previously entered. You may accept this or change according to cable being
processed.
OR PRESS ENTER To open blades enter a higher value and to close blades enter a lower value.
STRIP DEPTH = To process multi conductor cable enter strip depth dimension based upon overall
dimension of inner conductors. Press ENTER.
PLEASE ENTER This controls the length of time the blades will pause at both the Leading and Trailing
BLADE DWELL TIME strip depths. When stripping thick or hard to cut insulation a longer dwell time may
0.00 SECONDS be necessary to allow the blades to cut through the insulation and provide a clean strip.
Enter a value between 0.01 – 2.50 seconds. Press ENTER.
PLEASE ENTER The step back controls the amount which the blades retract after cutting the wire
STEP BACK DISTANCE insulation and before pulling the insulation off the wire. Example: After running a test
STEP BACK = wire through the Model 93 you see that the inner conductor has been scraped. You
would now enter a value (.001”-.050”) to retract the blades. This value is automatically
added to the entered Blade Depth so that a clean strip can be obtained. IMPORTANT:
There is a big difference between “nicking” and “scrapping” the inner conductors of the
wire. Nicking is when the blades cut too deep into the insulation, and is observed right
at the shoulder of the stripped wire. Scraping is observed not at the shoulder of the
LEADING
PULL
BLADE
DEPTH

CARPENTER MODEL 93 COMPU-STRIP Phone: [phone] Fax: [phone] Page 19
Revised 08/23/13 Website: www.carpentermfg.com E-mail: [email protected]
strip, but along the length of the inner conductor as the insulation slug is stripped from
the wire. Nicking is corrected using the Blade Strip Depth feature and scrapping is
corrected using the Step Back feature.
Press ENTER.
CARPENTER MODEL 93 COMPU-STRIP
PROGRAMMING
SHORT MODE
cont.
LCD DISPLAY PROMPT ACTION REQUIRED
PLEASE ENTER BLADE The Model 93 will default to a blade speed appropriate to the type of wire/cable being
SPEED(1 THRU 4) processed. You may accept or change this value.
DEFAULT IS 1 Press ENTER
SPEED =
PLEASE ENTER Enter the Guide Tube Size previously determined and installed on machine.
GUIDE TUBE SIZE Press ENTER. NOTE: It is important to enter the correct Guide Tube number because
GUIDE TUBE = this entry controls the blade opening.
Press FEED SPEED key. This setting determines the speed of the wire passing
through the machine.
PLEASE ENTER FEED Select 1-slow, 2-slow/medium, 3-medium ,4 -fast. Press ENTER.
SPEED (1 THRU 4) NOTE: When selecting speed 1 or 2 the maximum Pull Speed that can be selected is
4.
SPEED =
Press PULL SPEED key. This setting determines the pull force of insulation being
removed.
PLEASE ENTER PULL Select pull speed 1(maximum pulling force),2 & 3(medium pulling force),
SPEED (1 THRU 5) 4 & 5(minimum pulling force). Press ENTER.
SPEED =
Press AMOUNT key. This value is the number of wires to be processed. Also allows
access to Multiple Batch Processing mode.
CHANGE CURRENT NOTE: If using the multiple batch feature; during initial programming this entry can
AMOUNT be ignored and proceed to next screen. During the actual processing this screen may
OR PRESS ENTER be used to change the current batch total without affecting any subsequent batches.
PLEASE ENTER The batch feature allows you to process required pieces in a single or multiple
NUMBER OF BATCHES batch(es). To process required pieces in one batch enter “1”. Press ENTER.
TO RUN To process total amount in multiple batches, enter number of batches to process.
Press ENTER.
PLEASE ENTER Enter amount of pieces to process per batch. Press ENTER.
FEED
SPEED
PULL
SPEED
AMOUNT
