38YCC (50 Hz)
10 SEER Heat Pump
Export Model
S i z e s 1 8 --- 6 0
1---1/2to5NominalTons(7To17.5kW)
Product Data
The 38YCC Outdoor Section of Split--System Heat Pumps is
designed for quiet, reliable heating during the winter and cooling
during the summer. With EER ratings up to 9.0, this heat pump
system provides economy of operation through energy
conservation when used with components designated by Carrier.
The 38YCC recovers heat for indoor comfort from outdoor air
during the heating season and, by automatically reversing the
refrigerant system, removes indoor heat and excess humidity
during the cooling season.
FEATURES AND BENEFITS
Electrical Range
Single--phase units are available in sizes 018, 024, and 036 in 230v
50 Hz. Three--phase units are available in sizes 036, 048, and 060
in 400v 50 Hz.
Wide Range of Sizes
The 38YCC is available in nominal sizes 018, 024, 036, 048 and
060 to meet the needs of residential and light commercial
applications.
Unit Design
All units are equipped with totally enclosed fan motors for greater
reliability under adverse weather conditions. The large,
wrap--around coil uses copper tube and enhanced epoxy coated
aluminum fin and is designed for optimum heat transfer and
corrosion protection during heating and cooling. The vertical air
discharge carries the sound and air up and away from adjacent
patio areas and foliage. Coil can be cleaned with a common garden
hose.
Weather--Protective Cabinet
A weather protective cabinet of pre--painted steel is protected
underneath by a zinc galvanized coating for a finish that will last
for many years. All screws on cabinet exterior are coated for a
long--lasting, rust--resistant, quality appearance.
Compressor
Designed specifically for heat pump duty, with energy efficiency
during heating and cooling operation. The compressor is
hermetically sealed against contamination to assure long life and
dependable performance, internally sprung (units with
reciprocating compressor), and externally mounted on rubber
isolators for quiet operation. For improved serviceability, all
models are equipped with a compressor terminal plug.
Compressor Protection
Each compressor is protected with internal temperature-- and
current--sensitive overloads.
Reliable standard components
Includes a suction--tube accumulator that reduces the amount of
liquid refrigerant that reaches the compressor; a high pressure
switch to prevent excessive pressure build--up; a low--pressure
switch to stop the compressor if refrigerant charge is lost; a
crankcase heater to keep compressor oil warm and free of
refrigerant for maximum lubricity; an internal compressor relief
valve for high--pressure protection; and 5--minute compressor
delay.
3--phase monitor board (scroll compressor models)
Control board that monitors the electrical phase and prevents
compressor operation if wired incorrectly. Standard on 048 and
060 3 phase equipment.

2
FEATURES AND BENEFITS (CONT.)
External Service Valves
Service valves are brass, front seating type. The 38YCC has sweat
field connections. Valves are externally located so refrigerant tube
connections can be made quickly and easily. Each valve has a
service port for ease of checking operating refrigerant pressures.
Easy Serviceability
One panel provides access to electrical controls. Removal of wire
dome gives access to fan motor and removal of the top gives access
to the coil and compressor. All models are equipped with a
compressor terminal plug.
Discharge Muffler
Minimizes low frequency sound and pressure pulsation generated
by compressor discharge gas.
Defrost Control Board
This board incorporates a built--in 5--minute compressor
time--delay relay, defrost relay, defrost timer, and low--voltage
terminal board. The defrost control is a time/temperature initiation/
termination control which includes 4 field--selectable (DIP switch)
time periods of 30, 60, 90, and 120 minutes. This control also
includes a field selectable (DIP Switch) Quiet Shift defrost mode
which, if selected, maintains extremely quiet operation during
defrost.
PRODUCT NUMBER NOMENCLATURE
38YCC 018 7
10 SEER
Electric Heat Pump
Electrical Supply
7=230---1---50
9=400---3---50
Nominal Capacity
018 --- 1 --- 1 / 2 To n
024 --- 2 To n s
030 --- 2 --- 1 / 2 To n s
036 --- 3 To n s
042 --- 3 --- 1 / 2 To n s
048 --- 4 To n
060 --- 5 To n
3
Packaging
Series
A
REGISTERED
ISO 9001:2000
PHYSICAL DATA
UNIT SIZE 018--- 7A 024--- 7A 036--- 7A,9A 048--- 9A 060--- 9A
OPERATING WEIGHT (lb/kg) 130/59.0 140/63.5 215/97.5 226/102.5 259/117.5
COMPRESSOR TYPE Reciprocating Scroll
REFRIGERANT R --- 2 2
Control Piston
Charge (Lb/kg)
@15 Ft./4.6m 4.75 / 2.15 4.84 / 2.20 7.93 / 3.60 7.25 / 3.29 10.75 / 4.88
COND FAN Propeller Type, Direct Drive
Air Discharge Vertical
Air Qty (CFM/L/S) 2160 / 1020 2750 / 1300
Motor HP 1/10 1/4
Motor RPM 850 900
COND COIL Copper Tube, Aluminum Plate Fin
Face Area sq ft / sq m 9.1 / .84 12.4 / 1.15 22.4 / 2.08 18.7 / 1.74 22.4 / 2.08
Fins per in./Fins per cm 20 / 8
Rows 1
Circuits 3 4 6
VALVE CONNECTION Sweat
Vapor (in./mm)lD 5/8/15.88 3/4/19.05 7/8/22.23
Liquid (in./mm)lD 3/8/9.53
REFRIG. TUBES*(in./mm) OD
Vapor (0 ---50 ft/0---15.24m Tube) 5/8/15.88 3/4/19.05 7/8/22.3 1---1/8 / 28.58
Vapor (Max Diameter for Long
Line Applications) 3/4/19.05 7/8/22.23 1---1/8/28.58
Liquid (0---50 ft./0---15.24 m/ Tube
Length) 3/8/9.53
Liquid (For Long Line Applications) 3/8/9.53
* For tubing sets between 50 and 175 ft (15.24 and 53.34 m) horizontal and/or 20 ft (6.1 m) vertical differential, consult Residential Split Systems Long --- L i n e
Application Guideline.
NOTE: See unit Installation Instructions for proper installation.
38YCC

3
ELECTRICAL DATA
OUTDOOR
UNIT V/PH
OPER VOLTS* COMPRESSOR
FAN
FLA MCA
MIN
WIRE
SIZE**
60˚C/
75˚C
MAX
LENGTH
(Ft)‡
60˚C/
75˚C
MAX
LENGTH
(m)‡
60˚C/ 75˚C
MAX FUSE†
OR CKT
BKR AMPS
Max Min LRA RLA
018 --- 7A
230---1 253 207
55.0 8.8 0.52 11.5 14/14 66/62 20.1/18.9 20
024 --- 7A 68.0 11.5 0.52 14.9 14/14 55/39 16.7/11.9 25
036 --- 7A 94.0 16.5 1.6 22.2 12/12 65/47 19.8/14.3 35
036 --- 9A
400---3 440 360
42.0 6.4 0.7 8.7 14/14 260/247 79.2/75.3 15
048 --- 9A 63.0 7.9 0.7 10.7 14/14 165/157 50.3/47.9 15
060 --- 9A 74.0 9.0 0.7 11.9 14/14 165/157 50.3/47.9 20
* Permissible limits of the voltage range at which unit will operate satisfactorily. Operation outside these limits may result in unit failure.
{If wire is applied at ambient greater than 30˚C, consult Table 310---16 of the NEC (ANSI/NFPA 70). The ampacity of nonmetallic---sheathed cable (NM), trade
name ROMEX, shall be that of 60˚C conductors, per the NEC (ANSI/NFPA 70) Article 336---26. If other than uncoated (non ---plated), 60 or 75˚C insulation, cop-
per wire (solid wire for 10 AWG and smaller, stranded wire for larger than 10 AWG) is used, consult applicable tables of the NEC (ANSI/NFPA 70).
}Length shown is as measured 1 way along wire path between the unit and service panel for a voltage drop not to exceed 2%.
* * T i m e --- d e l a y f u s e .
FLA --- Fu l l L o a d A m p s
LRA --- L o c k e d R o t o r A m ps
MCA --- Minimum Circuit Amps
RLA --- RatedLoadAmps
NOTES:
1. Control circuit is 24v on all units and requires external power source.
2. Copper wire must be used from service disconnect to unit.
3. All motors/compressors contain internal overload protection.
METERING DEVICE
UNIT SIZE---SERIES OUTDOOR PISTON INDOOR PISTON*
REQUIRED SUB---COOLING
WITH TXV EXAPNSION
DEVICE
_F(_C)
018---7A 40 57 12 (6.7)
024---7A 49 63 12 (6.7)
036---7A 61 73 9 (5.0)
036---9A 61 73 11 (6.1)
048---9A 73 90 9 (5.0)
060---9A 76 96 10 (5.6)
* Piston listed is for any approved non ---capillary tube coil combination. Piston is shipped with outdoor unit and must be installed in an approved indoor coil.
A--WEIGHTED SOUND POWER (dB)
UNIT SIZE
SOUND
RATING
(dBA)
TYPICAL OCTAVE BAND SPECTRUM (dB, Without Tone Adjustment)
125 250 500 1000 2000 4000 8000
018 76 49.5 58.0 66.5 69.5 67.0 66.5 59.5
024 76 54.0 63.0 63.5 68.0 66.0 67.5 64.5
036 77 56.5 65.5 68.5 70.5 69.0 67.5 62.5
048 77 56.0 59.5 67.5 72.5 70.0 69.5 66.0
060 77 55.5 62.5 70.0 73.0 70.5 68.5 64.5
38YCC

4
ACCESSORIES
ORDERING NUMBER DESCRIPTION
KAATD0101TDR Time---Delay Relay — All Sizes
KSALA0201R22 Low --- Ambient Pressure Switch — All Sizes
KSALA0401AAA MotorMaster®Control — Sizes 018, 024, 036 (7A)
KSALA0501AAA MotorMaster®Control — Sizes 036 (9A), 048, 060
KAAFT0101AAA[Evaporator Freeze Thermostat — All Sizes
KHAIR0101AAA[Isolation Relay — All Sizes
KSAHS1001AAA Start Assist — Capacitor and Relay — Size 018, 024
KSAHS1301AAA Start Assist — Capacitor and Relay — Size 036 (7A)
KAACS0101PTC Start Assist — PTC — Size 018, 024
KAACS0201PTC Start Assist — PTC — Size 036 (7A)
KHAOT0301FST Outdoor Thermostat — All Sizes
KHAOT0201SEC Secondary Outdoor Thermostat — All Sizes
KSATX0601HSO]Bi--- Flow TXV (Hard Shutoff) — Sizes 018, 024, 036
KSATX0701HSO]Bi--- Flow TXV (Hard Shutoff) — Sizes 048
KSATX1001HSO Bi--- Flow TXV (Hard Shutoff) — Size 060
KHATX0101RPB Bi---Flow TXV (RPB) — Size 018
KHATX0201RPB Bi---Flow TXV (RPB) — Size 024
KHATX0401RPB Bi---Flow TXV (RPB) — Size 036
KHATX0601RPB Bi---Flow TXV (RPB) — Size 048
KHATX0701RPB Bi---Flow TXV (RPB) — Size 060
P504-- 8083S (RCD) Bi---Flow Filter Drier — Sizes 018, 024, 036
P504-- 8163S (RCD) Bi---Flow Filter Drier — Sizes 048, 060
KHALS0101LLS Liquid---Line Solenoid Valve (LSV) — All Sizes
{Fan motor with ball bearings required.
}Use with low ---ambient controller.
ACCESSORY THERMOSTATS
THERMOSTAT / SUBBASE PKG. DESCRIPTION
TSTATCCPRH01 --- B* ThermidistattControl — Non---Programmable/Programmable Thermostat with Humidity Control (For use in Dual
Fuel, AC, HP, and 2S applications. Includes Outdoor Air Temperature Sensor.)
TSTATCCPHH01 --- B* HybridHeatt(Dual Fuel) Thermostat — Auto Changeover, 7---Day Programmable, °F/°C, Includes Outdoor Sensor
(TSTATXXSEN01---B)
TSTATCCPHP01--- B Thermostat — Auto Changeover, 7---Day Programmable, °F/°C , 2 --- S t a g e H e a t , 1 --- S t a g e C o o l
TSTATCCNHP01--- C Thermostat — Auto Changeover, Non---Programmable, °F/°C , 2 --- S t a g e H e a t , 1 --- S t a g e C o o l
TSTATCCSHP01 Standard Programmable Thermostat—Manual Changeover, 5---2 Day Programmable, °F/°C , 1 --- S t a g e H e a t / 1 --- S t a g e
Cool
TSTATCCBHP01* --- B Builder’s Thermostat — Heat Pump, Non---Programmable, °F/°C, 2---Stage Heat, 1---Stage Cool, Manual Changeover
TSTATXXSEN01--- B** Outdoor Air Temperature Sensor
TSTATXXNBP01 Backplate for Non---Programmable Thermostat
TSTATXXPBP01 Backplate for Programmable Thermostat and ThermidistattControl
TSTATXXSBP01 Backplate for Standard Programmable Thermostat
TSTATXXBBP01 Backplate for Builder’s Thermostat
TSTATXXCNV10{Thermostat Conversion Kit (4 to 5 Wire) — 10 Pack
T B --- P H P --- 0 1 Base Series Programmable HP Stat
T B --- N H P --- 0 1 Base Series Non---programmable HP Stat
* Do not use in zoning heat pump applications.
** Outdoor temperature sensor is an accessory for all Carrier electronic thermostats, except the non---programmable air conditioner version and builder;s
thermostats. It allows the temperature at a remote location (outdoors) to be displayed on the thermostat. The outdoor air temperature sensor must be used
with the HybridHeatt(dual fuel) thermostat.
{Thermostat conversion kit is a 24---vac accessory that can turn a 4---wire thermostat application into a 5---wire application. This kit can also be used to re
place a broken thermostat wire, or add an extra wire when needed. The outdoor air temperature sensor is included with the Thermidistat Control and
HybridHeatt(dual fuel) thermostat.
38YCC

5
ACCESSORY USAGE GUIDELINE
ACCESSORY
REQUIRED FOR
LOW--- AMBIENT APPLICATIONS
(Below 55°F / 12.78°C)
REQUIRED FOR LONG LINE
APPLICATIONS*
(Over 80 Ft. / 24.38 m)
REQUIRED FOR SEA COAST
APPLICATIONS
(Within 2 miles / 3.22 km)
Accumulator No No No
Ball Bearing Fan Motor Ye s {No No
Compressor Start Assist
Capacitor and Relay Ye s {Ye s No
Crankcase Heater Ye s {Ye s No
Evaporator Freeze Thermostat Ye s {No No
Isolation Relay Ye s {No No
Liquid Line Solenoid Valve No See Long Line Application
Guideline No
Motor Master®Control
or Low---ambient Pressure Switch Ye s{No No
Support Feet Recommended No Recommended
* For tubing line sets between 80 and 200 ft. (24.38 and 60.96 m) and/or 20 ft. vertical (6.09 m) differential, refer to Residential Split System Long Line
Application Guideline.
{Required for Low ---Ambient Controller MotorMasterrControl only.
Accessory Description and Usage (Listed Alphabetically)
1. Ball--Bearing Fan Motor
A fan motor with ball bearings which permits speed reduction
while maintaining bearing lubrication.
Usage Guideline:
Required on all units when MotorMasterris used.
2. Compressor Start Assist -- Capacitor and Relay
Start capacitor and relay gives a ”hard” boost to compressor motor
at each start up.
Usage Guideline:
Required for reciprocating compressors in the following
applications:
Long line
Low ambient cooling
Hard shut off expansion valve on indoor coil
Liquid line solenoid on indoor coil
Required for single--phase scroll compressors in the
following applications:
Long line
Low ambient cooling
Suggested for all compressors in areas with a history of
low voltage problems.
3. Compressor Start Assist — PTC Type
Solid state electrical device which gives a ”soft” boost to the
compressor at each start--up.
Usage Guideline:
Suggested in installations with marginal power supply.
4. Crankcase Heater
An electric resistance heater which mounts to the base of the
compressor to keep the lubricant warm during off cycles. Improves
compressor lubrication on restart and minimizes the chance of
liquid slugging.
Usage Guideline:
Required in low ambient cooling applications.
Required in long line applications.
Suggested in all commercial applications.
5. Cycle Protector
The cycle protector is designed to prevent compressor short
cycling. This control provides an approximate 5--minute delay after
power to the compressor has been interrupted for any reason,
including power outage, protector control trip, thermostat jiggling,
or normal cycling.
6. Evaporator Freeze Thermostat
An SPST temperature--actuated switch that stops unit operation
when evaporator reaches freeze--up conditions.
Usage Guideline:
Required when low ambient kit has been added.
7. High Pressure Switch
A high pressure switch that protects unit against excessive pressure.
Usage Guideline:
Required in all heat pumps operated in dual fuel
applications.
8. Isolation Relay
An SPDT relay which switches the low--ambient controller out of
the outdoor fan motor circuit when the heat pump switches to
heating mode.
Usage Guideline:
Required in all heat pumps where low ambient kit has
been added.
9. Liquid--Line Solenoid Valve (LLS)
An electrically operated shutoff valve which stops and starts
refrigerant liquid flow in response to compressor operation. It is to
be installed at the outdoor unit to control refrigerant off cycle
migration in the heating mode.
Usage Guideline:
An LLS is required in all long line heat pump
applications to control refrigerant off cycle migration in
the heating mode. See Long Line Guideline.
10. Low--Ambient Pressure Switch Kit
A long life pressure switch which is mounted to outdoor unit
service valve. It is designed to cycle the outdoor fan motor in order
to maintain head pressure within normal operating limits
(approximately 100 psig to 225 psig). The control will maintain
working head pressure at low--ambient temperatures down to 0_F
(--17.8_C) when properly installed.
Usage Guideline:
A Low--Ambient Pressure Switch or MotorMasterr
Low--Ambient Controller must be used when cooling
operation is used at outdoor temperatures below 55_F
(12.8_C).
38YCC

6
Accessory Description and Usage (Listed Alphabetically) -- CONTINUED
11. MotorMasterrLow--Ambient Controller
A fan--speed control device activated by a temperature sensor,
designed to control condenser fan motor speed in response to the
saturated, condensing temperature during operation in cooling
mode only. For outdoor temperatures down to --20_F (--28.9_C), it
maintains condensing temperature at 100_F±10_F (37.8_C±
5.5_C).
Usage Guideline:
A MotorMasterrLow Ambient Controller or
Low--Ambient Pressure Switch must be used when
cooling operation is used at outdoor temperatures
below 55_F (12.8_C).
Suggested for all commercial applications.
12. Outdoor Air Temperature Sensor
Designed for use with Carrier Thermostats listed in this
publication. This device enables the thermostat to display the
outdoor temperature. This device also is required to enable special
thermostat features such as auxiliary heat lock out.
Usage Guideline:
Suggested for all Carrier thermostats listed in this
publication.
13. Outdoor Thermostat
An SPDT temperature--actuated switch which turns on
supplemental electric heaters when outdoor air temperature drops
below a user--selected set point.
Usage Guideline:
Electric supplemental heat applications in non--variable
speed indoor units when electric heat staging is desired.
Usage Guideline:
Some local codes may require limiting the heating head
pressure in the vapor line in some applications.
14. Secondary Outdoor Thermostat
An SPDT temperature--actuated switch which turns on third--stage
of supplemental electric heaters when outdoor air temperature
drops below the second--stage set point.
Usage Guideline:
Outdoor thermostat applications where electric heater is
capable of 3--stage operation.
15. Snow Stand
Coated wire rack which supports unit 18 in. (457.2 mm) above
mounting pad to allow for drainage from unit base.
Usage Guideline:
Suggested in the following applications:
Heat pump installations in heavy snowfall areas.
Heat pump installations in snow drift locations.
Heat pump installations in areas of prolonged
subfreezing temperatures.
All commercial installations.
16. Sound Hood
Wraparound sound reducing cover for the compressor. Reduces the
sound level up to 2 dBA.
Usage Guideline:
Suggested when unit is installed closer than 15 ft
(4.57 m) to quiet areas, bedrooms, etc.
Suggested when unit is installed between two houses less
than 10 ft (3.05 m) apart.
Usage Guideline:
Suggested in the following applications:
Heat pump installations in heavy snowfall areas.
Heat pump installations in snowdrift locations.
Heat pump installations in areas of prolonged
subfreezing temperatures.
All commercial installations.
17. Thermostatic Expansion Valve (TXV) Bi--Flow
A modulating flow--control valve which meters refrigerant liquid
flow rate into the evaporator in response to the superheat of the
refrigerant gas leaving the evaporator.
Usage Guideline:
Required in all heat pump applications
18. Time--Delay Relay
An SPST delay relay which briefly continues operation of indoor
blower motor to provide additional cooling after the compressor
cycles off.
Note: Most indoor unit controls include this feature. For those that
do not, use the guideline below.
Usage Guideline:
Accessory required to meet ARI rating, where indoor
not equipped.
38YCC

7
DIMENSIONS (ENGLISH)
38YCC

8
DIMENSIONS (S.I.)
38YCC

9
38YCC BALANCE POINT WORKSHEET (ENGLISH)
BUILDING HEAT LOSS, 1000 BTU/HR
UNIT INTEGRATED HEATING CAPACITY, 1000 BTU/HR
-- 1 0 01 0 20 30 40 50 60 70 80
70 60 50 40 30 20 10
BASED ON INDOOR ENT. AIR AT
70_F AND AT RATED CFM
80
38YCC024 FB4BS02
4
38YCC036 FB4BS036 38YCC048 FB4BS048
38YCC060 FB4BS060
Printed in U.S.A.
38YCC018 FB4BS018
OUTDOOR TEMPERATURE, _F
38YCC

10
38YCC BALANCE POINT WORKSHEET (S.I.)
BUILDING HEAT LOSS, KW
UNIT INTEGRATED HEATING CAPACITY,KW
Printed in U.S.A.
-- 2 0 -- 1 0 0 1 0 20
30
20
10
40
BASED ON INDOOR ENT. AIR AT 21_C
AND AT RATED CFM
38YCC024 FB4BS024
38YCC036 FB4BS036
38YCC048 FB4BS04
8
38YCC060 FB4BS060
25
38YCC018 FB4BS018
OUTDOOR TEMPERATURE, _C
38YCC

11
COMBINATION RATINGS*
OUTDOOR
UNIT
S I Z E ---
SERIES
INDOOR UNIT
NOMINAL
A I R --- F L O W
Cooling Capacity @ 95˚F(35˚C) Heating Capacity
Rated
BTUH
Capacity
kW
Power
kW
Rated
EER
H i g h --- Te m p @ 4 7 ˚F(8˚C) L o w --- Te m p @ 1 7 ˚F ( --- 8 ˚C)
CFM L/S Rated
BTUH
Capacity
kW
Power
kW
Rated
BTUH
Capacity
kW
Power
kW
018--- 7A FB4BSF018
FB4BSF024
600
600
280
280
17000
17600
4.9
5.16
2.00
1.96
8.50
9.00
17400
17800
5.10
5.22
1.76
1.74
9000
9200
2.64
2.70
1.39
1.42
024--- 7A FB4BSF024
FB4BSF030
800
800
380
380
23000
23600
6.74
6.91
2.56
2.62
9.00
9.00
23000
23600
6.74
6.91
2.41
2.47
14000
14400
4.10
4.22
1.71
1.76
036--- 7A, 9A FB4BSF036
FB4BS(F,B)042
1200
1200
550
550
35000
35500
10.25
10.40
3.89
3.94
9.00
9.00
36000
37000
10.55
10.84
3.40
3.50
22100
22100
6.48
6.48
2.65
2.65
048--- 7A, 9A FB4BS(F,B)048
FB4BS(F,B)060
1600
1600
750
750
46500
47000
13.62
13.77
5.17
5.22
9.00
9.00
47000
47000
13.77
13.77
4.28
4.28
28000
28000
8.20
8.20
3.71
3.71
060--- 9A FB4BS(F,B)060
FB4BSF070
1850
1850
850
850
57000
58000
16.70
16.99
6.33
6.44
9.00
9.00
59000
59000
17.29
17.29
5.21
5.21
39000
39000
11.43
11.43
4.45
4.45
* Ratings are net values reflecting the effects of circulating fan heat. Supplemental electric heat is not included.
Ratings are based on:
Cooling Standard: 80_F(27_C) db 67_F(19_C) wb indoor entering air temperature and 95_F(35_C) db air entering outdoor unit.
High---Temp Heating Standard: 70_F(21_C) db indoor entering air temperature and 47_F(8_C) db 43˚F(6_C) wb air entering outdoor unit.
Low--- Temp Heating Standard: 70_F(21_C) db indoor entering air temperature and 17_F(±9_C) db 15˚F(±10_C) wb air entering outdoor unit.
SEER — Seasonal Energy Efficiency Ratio
COP — Coefficient of Performance
TDR — T i m e --- D e l a y R e l a y
HSPF — Heating Seasonal Performance Factor
EER — Energy Efficiency Ratio
38CKC

12
DETAILED COOLING CAPACITIES* (S.I.)
COIL AIR CONDENSER ENTERING AIR TEMPERATURE _F
L/S (C)
EWB
24 29 35 41 46 52
Capacity kW{Sys.
Power
kW**
Capacity kW{Sys.
Power
kW**
Capacity kW{Sys.
Power
kW**
Capacity kW{Sys.
Power
kW**
Capacity kW{Sys.
Power
kW**
Capacity kW{Sys.
Power
kW**
To t a l Sens}To t a l Sens}To t a l Sens }To t a l Sens}To t a l Sens}To t a l Sens}
38YCC018--7A Outdoor Section With FB4BSF018 Indoor Section
250
14 4.73 4.73 1.68 4.50 4.50 1.78 4.27 4.27 1.88 4.02 4.02 1.99 3.76 3.76 2.09 3.48 3.48 2.19 17 19
4.96 5.56
4.41 3.76
1.69 1.73
4.67 5.21
4.26 3.60
1.80 1.85
4.38 4.88
4.12 3.46
1.90 1.95
4.07 4.55
3.96 3.32
1.99 2.05
3.76 4.20
3.76 3.17
2.09 2.15
3.48 3.82
3.48 3.02
2.19 2.24
22 6.15 3.06 1.76 5.87 2.95 1.88 5.50 2.81 2.01 5.12 2.66 2.12 4.75 2.52 2.23 4.36 2.37 2.33
285
14 4.94 4.94 1.73 4.70 4.70 1.84 4.45 4.45 1.94 4.19 4.19 2.05 3.92 3.92 2.15 3.62 3.62 2.25 17 19
5.08 5.70
4.72 3.98
1.74 1.77
4.79 5.33
4.57 3.83
1.85 1.89
4.49 4.98
4.40 3.68
1.95 2.00
4.19 4.63
4.19 3.54
2.05 2.10
3.92 4.27
3.92 3.39
2.15 2.20
3.62 3.89
3.62 3.23
2.25 2.29
22 6.22 3.16 1.80 5.99 3.08 1.93 5.63 2.95 2.05 5.22 2.79 2.17 4.83 2.65 2.28 4.43 2.50 2.38
320
14 5.12 5.12 1.78 4.87 4.87 1.89 4.60 4.60 2.00 4.33 4.33 2.11 4.05 4.05 2.21 3.75 3.75 2.31 17 19
5.20 5.79
5.01 4.19
1.79 1.81
4.89 5.44
4.83 4.05
1.89 1.93
4.60 5.06
4.60 3.89
2.00 2.05
4.33 4.70
4.33 3.75
2.11 2.15
4.05 4.33
4.05 3.60
2.21 2.25
3.74 3.94
3.74 3.43
2.31 2.34
22 6.28 3.25 1.84 6.07 3.20 1.97 5.72 3.08 2.10 5.30 2.92 2.22 4.90 2.77 2.33 4.48 2.62 2.43
Cooling Indoor Model Capacity Power
FB4BSF024 1.03 0.98
COIL AIR CONDENSER ENTERING AIR TEMPERATURE _F
L/S (C)
EWB
28 32 36 40 44 48 52
Capacity kW{Sys.
Power
kW**
Capacity kW{Sys.
Power
kW**
Capacity kW{Sys.
Power
kW**
Capacity kW{Sys.
Power
kW**
Capacity kW{Sys.
Power
kW**
Capacity kW{Sys.
Power
kW**
Capacity kW{Sys.
Power
kW**
To t a l Sens}To t a l Sens}To t a l Sens}To t a l Sens}To t a l Sens}To t a l Sens}To t a l Sens}
38YCC024--7A, 9A Outdoor Section With FB4BSF036 Indoor Sections
340
22 7.83 3.94 2.56 7.50 3.81 2.68 7.17 3.69 2.80 6.84 3.57 2.91 6.50 3.44 3.02 6.16 3.32 3.13 5.81 3.20 3.23 20 7.32 4.64 2.49 7.01 4.51 2.61 6.70 4.39 2.72 6.38 4.26 2.83 6.06 4.14 2.93 5.73 4.01 3.03 5.40 3.88 3.13 18 6.84 5.33 2.43 6.55 5.20 2.54 6.25 5.06 2.65 5.96 4.93 2.75 5.66 4.79 2.85 5.36 4.64 2.95 5.05 4.48 3.05 16 6.46 5.89 2.38 6.19 5.74 2.49 5.93 5.58 2.59 5.66 5.42 2.70 5.39 5.25 2.80 5.12 5.06 2.90 4.84 4.84 2.99 14 6.25 6.22 2.35 6.03 6.00 2.46 5.80 5.79 2.57 5.57 5.56 2.68 5.34 5.33 2.79 5.09 5.09 2.89 4.84 4.84 2.99
380
22 7.96 4.09 2.61 7.62 3.96 2.73 7.28 3.84 2.85 6.93 3.71 2.96 6.58 3.59 3.07 6.23 3.47 3.18 5.88 3.35 3.28 20 7.45 4.86 2.54 7.12 4.74 2.66 6.80 4.61 2.77 6.47 4.48 2.88 6.14 4.35 2.99 5.80 4.23 3.09 5.47 4.10 3.18 18 6.97 5.62 2.48 6.67 5.48 2.59 6.36 5.34 2.70 6.06 5.20 2.81 5.76 5.04 2.91 5.46 4.86 3.01 5.17 4.67 3.11 16 6.61 6.20 2.43 6.34 6.03 2.54 6.06 5.87 2.65 5.79 5.69 2.76 5.52 5.49 2.86 5.26 5.26 2.96 5.00 5.00 3.07 14 6.47 6.45 2.41 6.23 6.22 2.53 6.00 5.99 2.64 5.76 5.75 2.75 5.51 5.51 2.86 5.26 5.26 2.96 5.00 5.00 3.07
420
22 8.06 4.23 2.66 7.72 4.11 2.78 7.37 3.98 2.89 7.01 3.86 3.01 6.65 3.73 3.12 6.29 3.61 3.23 5.93 3.49 3.33 20 7.55 5.08 2.59 7.22 4.95 2.70 6.88 4.82 2.82 6.54 4.70 2.93 6.21 4.57 3.03 5.87 4.44 3.13 5.52 4.31 3.23 18 7.08 5.89 2.53 6.77 5.75 2.64 6.46 5.60 2.75 6.16 5.43 2.86 5.86 5.24 2.96 5.56 5.05 3.07 5.26 4.84 3.17 16 6.74 6.48 2.48 6.46 6.30 2.59 6.18 6.11 2.70 5.91 5.90 2.81 5.65 5.65 2.92 5.39 5.39 3.03 5.12 5.12 3.13 14 6.65 6.64 2.47 6.41 6.40 2.59 6.16 6.15 2.70 5.91 5.91 2.81 5.65 5.65 2.92 5.39 5.39 3.03 5.13 5.13 3.13
Cooling Indoor Model Capacity Power
FB4BSF024 1.00 1.00 FB4BSF030 1.02 1.00
See notes on page 14
38YCC

13
DETAILED COOLING CAPACITIES* (S.I.) (CONT.)
COIL AIR CONDENSER ENTERING AIR TEMPERATURE _F
L/S (C)
EWB
28 32 36 40 44 48 52
Capacity kW{Sys.
Power
kW*
Capacity kW{Sys.
Power
kW*
Capacity kW{Sys.
Power
kW*
Capacity kW{Sys.
Power
kW*
Capacity kW{Sys.
Power
kW*
Capacity kW{Sys.
Power
kW*
Capacity kW{Sys.
Power
kW*
To t a l Sens}To t a l Sens}To t a l Sens}To t a l Sens}To t a l Sens}To t a l Sens}To t a l Sens}
338YCC036 --- 7A,9A Outodoor Section With FB4BSF036 Indoor Section
500
22 11.9 6.04 3.60 11.4 5.86 3.77 10.9 5.68 3.94 10.4 5.50 4.11 9.92 5.32 4.27 9.42 5.14 4.42 8.90 4.96 4.58 20 11.1 7.14 3.51 10.6 6.95 3.67 10.2 6.77 3.83 9.69 6.58 3.99 9.21 6.40 4.14 8.73 6.21 4.29 8.25 6.03 4.43 18 10.3 8.21 3.42 9.91 8.01 3.58 9.48 7.81 3.74 9.04 7.61 3.89 8.60 7.40 4.04 8.17 7.16 4.18 7.73 6.90 4.32 16 9.78 9.05 3.36 9.39 8.82 3.51 8.99 8.58 3.67 8.60 8.34 3.82 8.21 8.07 3.96 7.82 7.77 4.11 7.43 7.43 4.26 14 9.51 9.47 3.32 9.18 9.15 3.48 8.85 8.83 3.64 8.51 8.49 3.80 8.16 8.15 3.95 7.80 7.80 4.11 7.43 7.43 4.26
560
22 12.1 6.29 3.68 11.6 6.11 3.85 11.1 5.93 4.02 10.6 5.75 4.18 10.1 5.56 4.35 9.53 5.38 4.50 8.99 5.20 4.65 20 11.3 7.51 3.58 10.8 7.32 3.75 10.3 7.13 3.91 9.83 6.94 4.07 9.33 6.75 4.22 8.84 6.56 4.37 8.34 6.37 4.51 18 10.5 8.67 3.49 10.1 8.47 3.65 9.65 8.25 3.81 9.21 8.03 3.97 8.77 7.77 4.12 8.33 7.49 4.27 7.90 7.20 4.42 16 10.0 9.53 3.43 9.61 9.28 3.59 9.21 9.02 3.75 8.81 8.74 3.90 8.43 8.40 4.06 8.04 8.04 4.21 7.66 7.66 4.36 14 9.84 9.82 3.41 9.49 9.47 3.58 9.14 9.13 3.74 8.78 8.77 3.90 8.42 8.41 4.06 8.04 8.04 4.21 7.66 7.66 4.36
640
22 12.3 6.61 3.77 11.8 6.43 3.94 11.3 6.24 4.11 10.7 6.06 4.28 10.2 5.87 4.44 9.65 5.69 4.60 9.10 5.50 4.75 20 11.5 7.98 3.67 11.0 7.78 3.84 10.5 7.59 4.00 9.98 7.40 4.16 9.47 7.20 4.32 8.96 7.01 4.47 8.45 6.81 4.61 18 10.8 9.24 3.59 10.3 9.00 3.75 9.85 8.75 3.91 9.41 8.46 4.07 8.98 8.16 4.23 8.53 7.86 4.38 8.08 7.56 4.53 16 10.3 10.1 3.53 9.87 9.79 3.69 9.47 9.47 3.86 9.09 9.09 4.02 8.70 8.70 4.18 8.31 8.31 4.34 7.91 7.91 4.49 14 10.2 10.2 3.52 9.84 9.84 3.69 9.47 9.47 3.86 9.09 9.09 4.02 8.70 8.70 4.18 8.31 8.31 4.34 7.92 7.92 4.49
Cooling Indoor Model Capacity Power
FB4BSF036 1.00 1.00 FB4BSF042 1.02 0.99
COIL AIR CONDENSER ENTERING AIR TEMPERATURES ˚C
L/S (C)
EWB
28 32 36 40 44 48 52
Capacity kW† Sys.
Power
kW**
Capacity kW† Sys.
Power
kW**
Capacity kW† Sys.
Power
kW**
Capacity kW† Sys.
Power
kW**
Capacity kW† Sys.
Power
kW**
Capacity kW† Sys.
Power
kW**
Capacity kW† Sys.
Power
kW**
To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡
38YCC048 --- 9A Outdoor Section With FB4BSF048 Indoor Section
650
22 20 18 16 14
15.4 14.5 13.6 12.9 12.6
7.87 9.38 10.8 12.0 12.6
4.50 4.41 4.32 4.25 4.21
14.9 14.0 13.2 12.5 12.3
7.69 9.19 10.7 11.8 12.3
4.79 4.69 4.59 4.52 4.49
14.4 13.5 12.7 12.1 12.0
7.51 9.00 10.5 11.5 11.9
5.09 4.98 4.88 4.80 4.78
13.9 13.0 12.3 11.7 11.6
7.32 8.81 10.3 11.3 11.6
5.41 5.29 5.18 5.11 5.09
13.3 12.5 11.8 11.3 11.2
7.13 8.62 10.1 11.0 11.2
5.75 5.63 5.51 5.43 5.41
12.8 12.0 11.3 10.9 10.8
6.94 8.42 9.82 10.7 10.8
6.11 5.97 5.84 5.75 5.75
12.3 11.5 10.8 10.4 10.4
6.75 8.23 9.56 10.4 10.4
6.48 6.33 6.19 6.09 6.09
750
22 20 18 16 14
15.6 14.7 13.9 13.3 13.1
8.26 9.96 11.6 12.8 13.1
4.60 4.51 4.42 4.35 4.34
15.1 14.2 13.4 12.9 12.8
8.08 9.78 11.4 12.5 12.7
4.89 4.79 4.69 4.63 4.62
14.6 13.7 13.0 12.5 12.4
7.89 9.59 11.2 12.2 12.4
5.19 5.08 4.98 4.92 4.91
14.1 13.2 12.5 12.0 12.0
7.71 9.39 10.9 12.0 12.0
5.51 5.39 5.29 5.22 5.22
13.5 12.7 12.0 11.6 11.6
7.51 9.19 10.7 11.6 11.6
5.86 5.73 5.62 5.56 5.56
13.0 12.2 11.6 11.2 11.2
7.32 9.00 10.4 11.2 11.2
6.22 6.08 5.97 5.90 5.90
12.4 11.7 11.1 10.8 10.8
7.13 8.80 10.1 10.8 10.8
6.59 6.44 6.32 6.25 6.25
850
22 20 18 16 14
15.8 14.9 14.1 13.6 13.5
8.64 10.5 12.3 13.4 13.5
4.70 4.60 4.51 4.45 4.45
15.3 14.4 13.6 13.2 13.1
8.45 10.3 12.0 13.1 13.1
4.99 4.88 4.79 4.73 4.73
14.8 13.9 13.2 12.8 12.8
8.27 10.2 11.8 12.8 12.8
5.29 5.18 5.08 5.03 5.03
14.2 13.4 12.7 12.4 12.4
8.08 9.96 11.5 12.4 12.4
5.61 5.49 5.40 5.34 5.34
13.7 12.9 12.3 11.9 11.9
7.89 9.75 11.1 11.9 11.9
5.95 5.83 5.74 5.68 5.68
13.1 12.3 11.8 11.5 11.5
7.69 9.55 10.8 11.5 11.5
6.31 6.18 6.09 6.04 6.04
12.5 11.8 11.3 11.1 11.1
7.50 9.35 10.5 11.1 11.1
6.69 6.54 6.45 6.40 6.40
Cooling Indoor Model Capacity Power
FB4BSF048 1.00 1.00 FB4BSF060 1.03 1.01
See notes on page 14
38YCC

14
DETAILED COOLING CAPACITIES* (S.I.) (CONT.)
COIL AIR CONDENSER ENTERING AIR TEMPERATURES ˚C
L/S (C)
EWB
28 32 36 40 44 48 52
Capacity kW† Sys.
Power
kW**
Capacity kW† Sys.
Power
kW**
Capacity kW† Sys.
Power
kW**
Capacity kW† Sys.
Power
kW**
Capacity kW† Sys.
Power
kW**
Capacity kW† Sys.
Power
kW**
Capacity kW† Sys.
Power
kW**
To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡
38YCC060 --- 9A Outdoor Section With FB4BSF060 Indoor Section
850
22 19.1 9.97 5.49 18.5 9.74 5.88 17.9 9.52 6.30 17.2 9.28 6.76 16.5 9.05 7.25 15.8 8.80 7.78 15.1 8.55 8.33 20 18.0 12.0 5.35 17.4 11.7 5.73 16.8 11.5 6.15 16.2 11.3 6.60 15.5 11.0 7.09 14.9 10.8 7.60 14.2 10.5 8.15 18 16.9 13.9 5.22 16.4 13.7 5.60 15.8 13.4 6.02 15.2 13.2 6.46 14.7 12.9 6.95 14.1 12.5 7.47 13.5 12.1 8.01 16 16.1 15.4 5.13 15.6 15.1 5.51 15.2 14.8 5.93 14.6 14.4 6.37 14.1 14.0 6.86 13.6 13.6 7.38 13.0 13.0 7.93 14 15.9 15.9 5.10 15.5 15.4 5.49 15.0 15.0 5.91 14.6 14.6 6.36 14.1 14.1 6.86 13.6 13.6 7.38 13.1 13.1 7.93
900
22 19.2 10.2 5.55 18.6 9.94 5.94 17.9 9.71 6.36 17.3 9.48 6.82 16.6 9.25 7.31 15.9 9.00 7.84 15.2 8.76 8.39 20 18.1 12.3 5.41 17.5 12.0 5.79 16.9 11.8 6.21 16.2 11.6 6.66 15.6 11.3 7.15 14.9 11.1 7.66 14.3 10.8 8.21 18 17.0 14.3 5.28 16.5 14.1 5.66 15.9 13.8 6.08 15.4 13.5 6.52 14.8 13.1 7.01 14.2 12.8 7.53 13.6 12.3 8.08 16 16.3 15.8 5.19 15.8 15.5 5.58 15.3 15.1 5.99 14.8 14.7 6.44 14.3 14.3 6.93 13.8 13.8 7.46 13.2 13.2 8.01 14 16.1 16.1 5.17 15.7 15.7 5.56 15.2 15.2 5.98 14.8 14.8 6.44 14.3 14.3 6.94 13.8 13.8 7.46 13.2 13.2 8.01
950
22 19.3 10.4 5.61 18.7 10.1 6.00 18.1 9.92 6.42 17.4 9.68 6.88 16.7 9.45 7.37 16.0 9.20 7.90 15.2 8.95 8.45 20 18.2 12.6 5.46 17.6 12.3 5.85 17.0 12.1 6.26 16.3 11.9 6.71 15.7 11.6 7.20 15.0 11.4 7.72 14.3 11.1 8.26 18 17.1 14.7 5.33 16.6 14.4 5.72 16.0 14.1 6.13 15.5 13.8 6.58 14.9 13.4 7.08 14.3 13.0 7.60 13.7 12.6 8.15 16 16.5 16.1 5.25 16.0 15.8 5.64 15.5 15.4 6.06 15.0 15.0 6.51 14.5 14.5 7.01 13.9 13.9 7.53 13.4 13.4 8.09 14 16.3 16.3 5.24 15.9 15.9 5.63 15.4 15.4 6.05 15.0 15.0 6.51 14.5 14.5 7.01 13.9 13.9 7.53 13.4 13.4 8.09
1000
22 19.4 10.6 5.66 18.8 10.3 6.06 18.1 10.1 6.47 17.4 9.87 6.93 16.7 9.64 7.43 16.0 9.39 7.95 15.3 9.14 8.50 20 18.3 12.9 5.51 17.6 12.6 5.90 17.0 12.4 6.32 16.4 12.2 6.77 15.7 11.9 7.26 15.1 11.7 7.77 14.3 11.4 8.32 18 17.3 15.0 5.39 16.7 14.7 5.78 16.2 14.4 6.19 15.6 14.0 6.65 15.0 13.6 7.14 14.4 13.2 7.66 13.8 12.8 8.21 16 16.6 16.4 5.31 16.1 16.0 5.70 15.6 15.6 6.12 15.1 15.1 6.58 14.6 14.6 7.08 14.1 14.1 7.60 13.5 13.5 8.16 14 16.6 16.5 5.31 16.1 16.1 5.70 15.6 15.6 6.12 15.1 15.1 6.58 14.6 14.6 7.08 14.1 14.1 7.60 13.5 13.5 8.16
Cooling Indoor Model Capacity Power
FB4BSF060 1.00 1.00 FB4BSF070 1.02 1.02
NOTE: When the required data falls between the published data, interpolation may be performed. Extrapolation is not an acceptable practice. * Detailed cooling capacities are based on indoor and outdoor unit at the same elevation and connected by 4.55 m of tubing. If other than 4.55 m of tubing is used and/or indoor unit is located above outdoor unit, a slight variation
in capacity may occur.
{Total and sensible capacities are net capacities. Blower motor heat has been subtracted. }Sensible capacities shown are based on 27˚C entering air at the indoor coil. For sensible capacities at other than 27˚C, deduct 245 kW per 480 L/S of indoor coil air for each degree below 27˚C, or add 245 kW per 480 L/S of
indoor coil air per degree above 27˚C.
** System kW is total of indoor and outdoor unit kilowatts. EWB --- Entering Wet Bulb
38YCC

15
DETAILED COOLING CAPACITIES* (ENGLISH)
COIL AIR CONDENSER ENTERING AIR TEMPERATURES ˚C
L/S (C)
EWB
75 85 95 105 115 125
Capacity MBtuh† Sys.
Power
kW**
Capacity
MBtuh†
Sys.
Power
kW**
Capacity
MBtuh†
Sys.
Power
kW**
Capacity
MBtuh†
Sys.
Power
kW**
Capacity
MBtuh†
Sys.
Power
kW**
Capacity
MBtuh†
Sys.
Power
kW**
To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡
38YCC018--7A Outdoor Section With FB4BSF018 Indoor Section
525
57 62 67 72
16.15 16.92 18.99 20.98
16.15 15.05 12.82 10.44
1.68 1.69 1.73 1.76
15.36 15.94 17.79 20.03
15.36 14.55 12.29 10.08
1.78 1.80 1.85 1.88
14.57 14.93 16.67 18.78
14.57 14.04
11.81
9.59
1.88 1.90 1.95 2.01
13.73 13.89 15.53 17.49
13.73 13.50
11.32
9.08
1.99 1.99 2.05 2.12
12.83 12.84 14.33 16.21
12.83 12.84 10.82
8.60
2.09 2.09 2.15 2.23
11.87 11.87
13.05 14.88
11.87 11.87
10.29
8.10
2.19 2.19 2.24 2.33
600
57 62 67 72
16.85 17.35 19.44 21.25
16.85
16.11
13.60 10.78
1.73 1.74 1.77 1.80
16.03 16.33 18.19 20.44
16.03 15.58 13.07 10.52
1.84 1.85 1.89 1.93
15.19 15.32 17.00 19.21
15.19 15.02 12.57 10.07
1.94 1.95 2.00 2.05
14.31 14.31 15.82 17.81
14.31 14.31 12.08
9.53
2.05 2.05 2.10 2.17
13.37 13.37 14.58 16.49
13.37 13.37
11.57
9.04
2.15 2.15 2.20 2.28
12.37 12.37 13.27 15.12
12.37 12.37
11.03
8.54
2.25 2.25 2.29 2.38
675
57 62 67 72
17.46 17.74 19.76 21.44
17.46 17.09 14.30
11.09
1.78 1.79 1.81 1.84
16.62 16.69 18.56 20.71
16.62 16.48 13.83 10.91
1.89 1.89 1.93 1.97
15.71 15.71 17.26 19.51
15.71 15.71 13.29 10.50
2.00 2.00 2.05 2.10
14.79 14.79 16.03 18.08
14.79 14.79 12.79
9.96
2.11 2.11
2.15 2.22
13.82 13.82 14.77 16.71
13.82 13.82 12.27
9.46
2.21 2.21 2.25 2.33
12.78 12.78 13.45 15.29
12.78 12.78
11.72
8.96
2.31 2.31 2.34 2.43
Cooling Indoor Model Capacity Power
FB4BSF024 1.03 0.98
COIL AIR CONDENSER ENTERING AIR TEMPERATURES ˚C
L/S (C)
EWB
75 85 95 105 115 125
Capacity
MBtuh†
Sys.
Power
kW**
Capacity MBtuh† Sys.
Power
kW**
Capacity MBtuh† Sys.
Power
kW**
Capacity MBtuh† Sys.
Power
kW**
Capacity MBtuh† Sys.
Power
kW**
Capacity MBtuh† Sys.
Power
kW**
To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡
38YCC024--7A Outdoor Section With FB4BSF024 Indoor Section
700
72 67 62 57
27.9 25.4 23.1 21.9
13.5 16.7 19.9 21.9
2.43 2.35 2.27 2.22
26.4 24.0 21.8 20.8
12.9 16.1 19.3 20.8
2.60 2.51 2.42 2.38
24.8 22.6 20.5 19.8
12.3 15.5 18.7 19.8
2.76 2.66 2.56 2.53
23.3 21.1 19.2 18.7
11.7
14.9 18.0 18.7
2.92 2.81 2.70 2.68
21.7 19.6 17.8 17.6
11.2
14.3 17.3 17.6
3.08 2.95 2.84 2.83
20.0 18.1 16.5 16.5
10.6 13.7 16.5 16.5
3.22 3.08 2.97 2.97
800
72 67 62 57
28.5 26.0 23.7 22.8
14.1 17.7 21.3 22.8
2.49 2.40 2.32 2.29
26.9 24.5 22.3 21.7
13.5 17.1 20.6 21.7
2.66 2.56 2.48 2.45
25.3 23.0 21.0 20.6
12.9 16.5 19.9 20.6
2.83 2.72 2.63 2.61
23.6 21.5 19.6 19.5
12.3 15.9 19.2 19.5
2.98 2.87 2.77 2.76
22.0 19.9 18.3 18.3
11.7
15.3 18.3 18.3
3.14 3.01 2.91 2.91
20.3 18.3 17.1 17.1
11.1
14.7 17.1 17.1
3.28 3.15 3.05 3.06
900
72 67 62 57
29.0 26.4 24.2 23.6
14.6 18.7 22.6 23.6
2.54 2.46 2.38 2.36
27.3 24.9 22.8 22.5
14.0 18.1 21.9 22.5
2.71 2.62 2.53 2.52
25.7 23.4 21.4 21.3
13.4 17.5 21.1 21.3
2.88 2.77 2.68 2.68
23.9 21.8 20.1 20.1
12.8 16.8 20.1 20.1
3.04 2.93 2.83 2.83
22.2 20.2 18.9 18.9
12.3 16.2 18.9 18.9
3.19 3.07 2.99 2.99
20.5 18.6 17.6 17.6
11.7
15.6 17.6 17.6
3.34 3.20 3.13 3.13
Cooling Indoor Model Capacity Power
FB4BSF024 1.00 1.00 FB4BSF030 1.02 1.00
See notes on page 17
38YCC

16
DETAILED COOLING CAPACITIES* (ENGLISH) CONTINUED
COIL AIR CONDENSER ENTERING AIR TEMPERATURES ˚C
L/S (C)
EWB
75 85 95 105 115 125
Capacity MBtuh† Sys.
Power
kW**
Capacity MBtuh† Sys.
Power
kW**
Capacity MBtuh† Sys.
Power
kW**
Capacity MBtuh† Sys.
Power
kW**
Capacity MBtuh† Sys.
Power
kW**
Capacity MBtuh† Sys.
Power
kW**
To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡
38YCC036--7A, 9A Outdoor Section With FB4BSF036 Indoor Section
1050
72 67 62 57
42.5 38.6 35.0 33.5
20.8 25.9 31.0 33.5
3.43 3.31 3.20 3.15
40.2 36.5 33.1 31.9
19.9 25.1 30.0 31.9
3.67 3.54 3.42 3.37
37.9
34.3 31.2 30.4
19.1 24.2 29.1 30.4
3.91 3.76 3.63 3.60
35.6 32.1 29.2 28.8
18.2 23.3 28.1 28.8
4.14 3.98 3.83 3.81
33.2 29.9 27.3 27.1
17.4 22.4 27.0 27.1
4.36
4.18 4.04 4.03
30.7 27.6 25.4 25.4
16.5 21.5 25.4 25.4
4.57 4.38 4.24 4.24
1200
72 67 62 57
43.4 39.4 35.9 34.9
21.7 27.6 33.1 34.9
3.52 3.39 3.28 3.25
41.1 37.2 33.9 33.2
20.9 26.7 32.1 33.2
3.76 3.62 3.51 3.48
38.6
35.0 31.9 31.6
20.0 25.8 31.0 31.6
4.00 3.85 3.72 3.71
36.2 32.6 30.0 29.9
19.1 24.9 29.8 29.9
4.23 4.07 3.93 3.93
33.7 30.3 28.1 28.1
18.3 23.9 28.1 28.1
4.45
4.27 4.15 4.15
31.1 28.0 26.3 26.3
17.4 23.0 26.3 26.3
4.67 4.47 4.36 4.36
1350
72 67 62 57
44.1 40.1 36.6 36.0
22.6 29.1 35.1 36.0
3.60 3.47 3.37 3.35
41.7 37.8 34.6 34.3
21.8 28.2 33.9 34.3
3.84 3.70 3.59 3.58
39.2
35.4 32.6 32.6
20.9 27.3 32.6 32.6
4.08 3.93 3.81 3.81
36.7 33.1 30.8 30.8
20.0 26.4 30.8 30.8
4.31 4.15 4.04 4.04
34.0 30.7 29.0 29.0
19.2 25.4 29.0 29.0
4.54
4.36 4.26 4.26
31.4 28.4 27.1 27.1
18.3 24.5 27.1 27.1
4.75 4.56 4.48 4.48
Cooling Indoor Model Capacity Power
FB4BSF036 1.00 1.00 FB4BSF042 1.02 0.99
COIL AIR CONDENSER ENTERING AIR TEMPERATURES ˚C
L/S (C)
EWB
75 85 95 105 115 125
Capacity MBtuh† Sys.
Power
kW**
Capacity MBtuh† Sys.
Power
kW**
Capacity MBtuh† Sys.
Power
kW**
Capacity MBtuh† Sys.
Power
kW**
Capacity MBtuh† Sys.
Power
kW**
Capacity MBtuh† Sys.
Power
kW**
To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡
38YCC048 --- 9A Outdoor Section With FB4BSF060 Indoor Section
1400
72 67 62 57
54.5 50.1 46.0 44.4
27.0 34.3 41.3 44.4
4.24 4.12 4.00 3.96
52.3 48.0 44.1 42.8
26.2 33.4 40.4 42.8
4.62 4.49 4.36 4.32
49.9 45.8 42.1 41.2
25.3 32.5 39.4 41.2
5.04 4.88 4.75 4.71
47.5 43.6 40.1 39.5
24.4 31.6 38.4 39.5
5.48 5.31 5.17 5.15
44.9 41.2 38.0 37.8
23.5 30.7 37.3 37.8
5.96 5.78 5.61 5.60
42.4 38.8 35.7 35.8
22.7 29.8 35.7 35.8
6.48 6.27 6.08 6.08
1600
72 67 62 57
55.4 51.0 46.9 46.0
28.2 36.3 44.1 46.0
4.34 4.21 4.10 4.07
53.1 48.8 45.0 44.4
27.4 35.5 43.1 44.4
4.72 4.58 4.46 4.44
50.6 46.5 43.0 42.6
26.5 34.6 42.0 42.6
5.13 4.98 4.85 4.84
48.1 44.1 41.0 40.9
25.6 33.7 40.7 40.9
5.58 5.41 5.27 5.27
45.4 41.7 39.0 39.0
24.7 32.7 39.0 39.0
6.06 5.88 5.74 5.74
42.8 39.3 37.0 37.0
23.8 31.8 37.0 37.0
6.58 6.37 6.23 6.23
1800
72 67 62 57
56.1 51.6 47.8 47.4
29.4 38.4 46.6 47.4
4.43 4.30 4.19 4.18
53.7 49.4 45.8 45.7
28.5 37.5 45.4 45.7
4.81 4.67 4.55 4.55
51.2 47.1 43.9 43.8
27.6 36.6 43.9 43.8
5.22 5.07 4.95 4.95
48.6 44.6 41.9 42.0
26.8 35.6 41.9 42.0
5.67 5.50 5.39 5.39
45.9 42.1 40.0 40.0
25.8 34.7 40.0 40.0
6.15 5.97 5.86 5.86
43.1 39.7 38.0 38.0
24.9 33.7 38.0 38.0
6.67 6.47 6.37 6.37
Cooling Indoor Model Capacity Power
FB4BSF048 1.00 1.00 FB4BSF060 1.03 1.01
See notes on page 17
38YCC

17
DETAILED COOLING CAPACITIES* (ENGLISH) CONTINUED
COIL AIR CONDENSER ENTERING AIR TEMPERATURES ˚C
L/S (C)
EWB
75 85 95 105 115 125
Capacity MBtuh† Sys.
Power
kW**
Capacity MBtuh† Sys.
Power
kW**
Capacity MBtuh† Sys.
Power
kW**
Capacity MBtuh† Sys.
Power
kW**
Capacity MBtuh† Sys.
Power
kW**
Capacity MBtuh† Sys.
Power
kW**
To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡
38YCC060--9A Outdoor Section With FB4BSF060 Indoor Section
1750
72 67 62 57
67.5 61.9 56.8 55.2
33.7 43.0 52.0 55.2
5.11
4.91 4.74 4.69
64.7 59.3 54.5 53.3
32.7 41.9 50.9 53.3
5.61 5.41 5.24 5.20
61.8 56.5 52.0 51.3
31.6 40.8 49.6 51.3
6.18 5.97 5.79 5.76
58.6 53.7 49.5 49.1
30.5 39.7 48.3 49.1
6.81 6.59 6.41 6.39
55.5 50.8 47.0 46.9
29.4 38.6 46.8 46.9
7.51 7.27 7.09 7.09
52.0 47.6 44.4 44.4
28.2 37.3 44.4 44.4
8.27 8.02 7.84 7.84
1900
72 67 62 57
68.1 62.5 57.6 56.4
34.6 44.6 54.2 56.4
5.19 4.99 4.83 4.79
65.2 59.8 55.2 54.5
33.6 43.5 53.0 54.5
5.70 5.49 5.32 5.30
62.1 57.0 52.8 52.3
32.5 42.4 51.7 52.3
6.26 6.05 5.88 5.87
59.0 54.1 50.2 50.1
31.4 41.3 50.1 50.1
6.89 6.67 6.50 6.50
55.8 51.2 47.9 47.8
30.3 40.1 47.9 47.8
7.59 7.36 7.19 7.20
52.3 47.9 45.2 45.3
29.1 38.9 45.2 45.3
8.36
8.11
7.96 7.96
2000
72 67 62 57
68.6 62.8 58.0 57.2
35.2 45.7 55.6 57.2
5.24 5.04 4.88 4.86
65.6 60.1 55.6 55.1
34.2 44.6 54.3 55.1
5.75 5.54 5.38 5.36
62.6 57.3 53.1 53.0
33.1 43.5 52.8 53.0
6.32 6.10 5.93 5.93
59.3 54.4 50.8 50.7
32.0 42.4 50.8 50.7
6.95 6.72 6.56 6.57
56.0 51.3 48.4 48.4
30.9 41.1 48.4 48.4
7.65 7.41 7.26 7.26
52.5 48.0 45.7 45.7
29.7 39.9 45.7 45.7
8.41 8.16 8.03 8.03
2150
72 67 62 57
69.0 63.3 58.7 58.2
36.1 47.2 57.5 58.2
5.32 5.12 4.96 4.95
66.0 60.5 56.2 56.1
35.1 46.1 55.9 56.1
5.83 5.62 5.46 5.46
62.9 57.7 53.9 53.9
34.0 45.0 53.9 53.9
6.39 6.18 6.03 6.03
59.6 54.7 51.6 51.5
32.9 43.9 51.6 51.5
7.03 6.80 6.66 6.66
56.2 51.6 49.1 49.1
31.8 42.7 49.1 49.1
7.73 7.49 7.36 7.36
52.7 48.3 46.5 46.5
30.6 41.4 46.5 46.5
8.49 8.24 8.13 8.13
Cooling Indoor Model Capacity Power
FB4BSF060 1.00 1.00 FB4BSF070 1.02 1.02
NOTE: When the required data fall between the published data, interpolation may be performed. Extrapolation is not an acceptable practice. * Detailed cooling capacities are based on indoor and outdoor unit at the same elevation per ARI standard 210/240 ---94. If additional tubing length and/or indoor unit is located above outdoor unit, a slight variation in capacity may
occur.
{Total and sensible capacities are net capacities. Blower motor heat has been subtracted. }Sensible capacities shown are based on 80˚F(27˚C) entering air at the indoor coil. For sensible capacities at other than 80˚F(27˚C), deduct 835 Btuh (245 kW) per 1000 CFM (480 L/S) of indoor coil air for each degree below
80˚F(27˚C), or add 835 Btuh (245 kW) per 1000 CFM (480 L/S) of indoor coil air per degree above 80˚F(27˚C).
** Unit kW is total of indoor and outdoor unit kilowatts. EWB --- Entering Wet Bulb
38YCC

18
HEAT PUMP HEATING PERFORMANCE (S.I.)
INDOOR AIR OUTDOOR COIL ENTERING AIR TEMPERATURES ˚C
--- 1 9 --- 1 4 --- 8 --- 3 3 8 14 19
(C)
EDB L/S Capacity kW To ta l
Power
kW*
Capacity kW Tota l
Power
kW*
Capacity kW To t a l
Power
kW*
Capacity kW Tota l
Power
kW*
Capacity kW To t a l
Power
kW*
Capacity kW Tota l
Power
kW*
Capacity kW To t a l
Power
kW*
Capacity kW Tota l
Power
kW*
Tot al Integ† Tota l Integ† To ta l Integ† Tot al Integ† To ta l Integ† To t a l Integ† Tot al Integ† To ta l Integ†
38YCC018---7A Outdoor Section With FS4BSF018 Indoor Section
18
250 285 320
1.50 1.55 1.59
1.38 1.43 1.47
1.14 1.17 1.20
2.05 2.11 2.15
1.88 1.93 1.98
1.24 1.27 1.30
2.67 2.74 2.80
2.43 2.50 2.55
1.35 1.37 1.40
3.39 3.48 3.56
3.01 3.09 3.16
1.46 1.48 1.50
4.20 4.31 4.39
3.82 3.92 4.00
1.58 1.60 1.62
5.09 5.23 5.33
5.09 5.23 5.33
1.72 1.73 1.75
6.13 6.26 6.28
6.13 6.26 6.28
1.88 1.87 1.86
7.22 7.20 7.12
7.22 7.20 7.12
2.03 1.99 1.97
21
250 285 320
1.41 1.46 1.50
1.30 1.34 1.38
1.15 1.18 1.21
1.96 2.01 2.06
1.80 1.85 1.89
1.26 1.28 1.31
2.56 2.64 2.70
2.34 2.40 2.46
1.36 1.39 1.42
3.28 3.37 3.44
2.92 2.99 3.06
1.48 1.50 1.53
4.07 4.18 4.27
3.70 3.80 3.88
1.61 1.62 1.64
4.97 5.10 5.20
4.97 5.10 5.20
1.75 1.76 1.78
5.99 6.14 6.21
5.99 6.14 6.21
1.91 1.91 1.91
7.10 7.14 7.08
7.10 7.14 7.08
2.08 2.05 2.03
24
250 285 320
1.32 1.36 1.40
1.21 1.25 1.29
1.15 1.18 1.22
1.86 1.91 1.96
1.71 1.76 1.80
1.26 1.29 1.32
2.46 2.53 2.59
2.25 2.31 2.36
1.38 1.41 1.43
3.16 3.25 3.33
2.81 2.89 2.96
1.50 1.52 1.55
3.95 4.06 4.14
3.59 3.69 3.77
1.63 1.65 1.67
4.84 4.97 5.07
4.84 4.97 5.07
1.78 1.79 1.81
5.83 5.98 6.10
5.83 5.98 6.10
1.94 1.95 1.95
6.96 7.05 7.03
6.96 7.05 7.03
2.12 2.09 2.08
Cooling Indoor Model Capacity Power
FB4BSF024 1.02 0.99
INDOOR AIR OUTDOOR COIL ENTERING AIR TEMPERATURES ˚C
--- 1 6 --- 8 0 4 8 12 16 20
(C)
EDB L/S Capacity kW Tot al
Power
kW*
Capacity kW Tot al
Power
kW*
Capacity kW Tot al
Power
kW*
Capacity kW Tot al
Power
kW*
Capacity kW Tot al
Power
kW*
Capacity kW Tot al
Power
kW*
Capacity kW Tot al
Power
kW*
Capacity kW Tot al
Power
kW*
Tot al Integ† Tota l Integ† To ta l Integ† Tot al Integ† To ta l Integ† To t a l Integ† Tot al Integ† To ta l Integ†
38YCC024---7A Outdoor Section With FS4BSF024 Indoor Section
12
340 380 420
3.39 3.44 3.49
3.12 3.17 3.21
1.39 1.41 1.43
4.44 4.51 4.56
4.04 4.10 4.15
1.63 1.65 1.66
5.64 5.73 5.80
5.08 5.16 5.21
1.90 1.91 1.92
6.32 6.42 6.49
5.90 5.99 6.05
2.05 2.06 2.07
7.04 7.15 7.22
7.01 7.11 7.18
2.22 2.22 2.23
7.87 7.98 8.06
7.87 7.98 8.06
2.42 2.42 2.43
8.75 8.88 8.97
8.75 8.88 8.97
2.64 2.64 2.65
9.67 9.82 9.93
9.67 9.82 9.93
2.88 2.88 2.89
15
340 380 420
3.28 3.33 3.37
3.01 3.06 3.10
1.41 1.43 1.45
4.33 4.39 4.45
3.94 4.00 4.05
1.66 1.68 1.69
5.51 5.60 5.66
4.96 5.04 5.09
1.94 1.95 1.96
6.18 6.28 6.34
5.76 5.85 5.91
2.10 2.11 2.12
6.89 6.99 7.07
6.86 6.96 7.03
2.27 2.28 2.28
7.70 7.82 7.90
7.70 7.82 7.90
2.47 2.48 2.48
8.57 8.70 8.79
8.57 8.70 8.79
2.70 2.70 2.71
9.48 9.63 9.73
9.48 9.63 9.73
2.95 2.95 2.95
18
340 380 420
3.16 3.21 3.26
2.91 2.95 3.00
1.43 1.45 1.47
4.21 4.27 4.33
3.83 3.89 3.94
1.69 1.71 1.72
5.38 5.46 5.53
4.84 4.92 4.97
1.98 1.99 2.01
6.04 6.13 6.20
5.63 5.71 5.78
2.14 2.15 2.17
6.74 6.84 6.92
6.71 6.81 6.89
2.32 2.33 2.34
7.54 7.65 7.74
7.54 7.65 7.74
2.53 2.54 2.54
8.39 8.52 8.61
8.39 8.52 8.61
2.76 2.77 2.77
9.28 9.43 9.54
9.28 9.43 9.54
3.01 3.01 3.02
21
340 380 420
3.05 3.10 3.14
2.80 2.85 2.89
1.44 1.47 1.49
4.10 4.16 4.21
3.73 3.78 3.83
1.72 1.74 1.75
5.25 5.33 5.39
4.73 4.80 4.85
2.02 2.03 2.05
5.89 5.98 6.06
5.49 5.58 5.65
2.19 2.20 2.21
6.59 6.69 6.77
6.56 6.66 6.74
2.37 2.38 2.39
7.37 7.49 7.58
7.37 7.49 7.58
2.59 2.59 2.60
8.21 8.34 8.44
8.21 8.34 8.44
2.83 2.83 2.83
9.08 9.23 9.35
9.08 9.23 9.35
3.08 3.08 3.09
24
340 380 420
2.92 2.98 3.02
2.69 2.74 2.78
1.46 1.48 1.50
3.98 4.04 4.10
3.63 3.68 3.73
1.75 1.76 1.78
5.12 5.19 5.26
4.61 4.68 4.73
2.06 2.07 2.09
5.75 5.84 5.91
5.36 5.44 5.51
2.23 2.25 2.26
6.43 6.53 6.61
6.40 6.50 6.58
2.42 2.43 2.44
7.20 7.32 7.41
7.20 7.32 7.41
2.64 2.65 2.66
8.02 8.15 8.26
8.02 8.15 8.26
2.89 2.89 2.89
8.88 9.03 9.14
8.88 9.03 9.14
3.14 3.14 3.15
Cooling Indoor Model Capacity Power
FB4BSF024 1.00 1.00 FB4BSF030 1.00 0.99
See notes on page 20
38YCC

19
HEAT PUMP HEATING PERFORMANCE (S.I.) (CONT.)
INDOOR AIR OUTDOOR COIL ENTERING AIR TEMPERATURES ˚C
--- 1 6 --- 8 0 4 8 12 16 20
(C)
EDB L/S Capacity kW Tot al
Power
kW*
Capacity kW Tot al
Power
kW*
Capacity kW Tot al
Power
kW*
Capacity kW Tot al
Power
kW*
Capacity kW Tot al
Power
kW*
Capacity kW Tot al
Power
kW*
Capacity kW Tot al
Power
kW*
Capacity kW Tot al
Power
kW*
Tot al Integ† Tota l Integ† To ta l Integ† Tot al Integ† To ta l Integ† To t a l Integ† Tot al Integ† To ta l Integ†
38YCC036---7A, 9A Outdoor Section With FS4BSF036 Indoor Section
12
500 560 640
5.42 5.49 5.60
4.98 5.05 5.15
2.22 2.26 2.31
7.03 7.13 7.26
6.40 6.49 6.60
2.49 2.52 2.56
8.86 9.00 9.15
7.98 8.10 8.23
2.78 2.80 2.83
9.93 10.1 10.2
9.26 9.40 9.54
2.95 2.97 2.99
11.1 11.2 11.4
11.0 11.2 11.4
3.14 3.14 3.16
12.3 12.5 12.7
12.3 12.5 12.7
3.36 3.36 3.37
13.7 13.9 14.1
13.7 13.9 14.1
3.61 3.60 3.62
15.1 15.3 15.6
15.1 15.3 15.6
3.88 3.87 3.88
15
500 560 640
5.22 5.30 5.41
4.80 4.87 4.97
2.25 2.28 2.34
6.84 6.94 7.06
6.22 6.32 6.43
2.54 2.57 2.61
8.65 8.78 8.93
7.79 7.90 8.03
2.84 2.86 2.90
9.70 9.84 10.0
9.04 9.17 9.32
3.02 3.04 3.06
10.8 11.0 11.1
10.8 10.9 11.1
3.21 3.22 3.24
12.1 12.2 12.4
12.1 12.2 12.4
3.44 3.44 3.46
13.4 13.6 13.8
13.4 13.6 13.8
3.69 3.69 3.70
14.8 15.0 15.2
14.8 15.0 15.2
3.97 3.96 3.97
18
500 560 640
5.02 5.11 5.21
4.62 4.69 4.79
2.27 2.31 2.37
6.65 6.75 6.87
6.05 6.14 6.25
2.58 2.61 2.66
8.44 8.57 8.71
7.60 7.71 7.84
2.91 2.93 2.96
9.46 9.60 9.76
8.82 8.95 9.10
3.09 3.11 3.13
10.6 10.7 10.9
10.5 10.7 10.8
3.29 3.30 3.32
11.8 12.0 12.2
11.8 12.0 12.2
3.52 3.52 3.54
13.1 13.3 13.5
13.1 13.3 13.5
3.78 3.78 3.79
14.4 14.7 14.9
14.4 14.7 14.9
4.06 4.05 4.06
21
500 560 640
4.83 4.91 5.02
4.44 4.52 4.61
2.30 2.34 2.40
6.46 6.56 6.68
5.88 5.97 6.08
2.63 2.66 2.71
8.23 8.35 8.49
7.40 7.52 7.64
2.97 2.99 3.03
9.22 9.37 9.53
8.60 8.73 8.88
3.16 3.18 3.21
10.3 10.5 10.6
10.2 10.4 10.6
3.36 3.38 3.40
11.5 11.7 11.9
11.5 11.7 11.9
3.60 3.61 3.62
12.8 13.0 13.2
12.8 13.0 13.2
3.86 3.86 3.88
14.1 14.3 14.6
14.1 14.3 14.6
4.14 4.14 4.15
24
500 560 640
4.61 4.70 4.81
4.24 4.32 4.42
2.33 2.37 2.42
6.26 6.36 6.48
5.70 5.79 5.90
2.67 2.70 2.75
8.01 8.14 8.28
7.21 7.32 7.45
3.03 3.05 3.09
8.99 9.13 9.29
8.38 8.51 8.66
3.22 3.24 3.28
10.0 10.2 10.4
9.99 10.1 10.3
3.44 3.45 3.48
11.2 11.4 11.6
11.2 11.4 11.6
3.68 3.69 3.71
12.4 12.7 12.9
12.4 12.7 12.9
3.95 3.95 3.96
13.7 14.0 14.2
13.7 14.0 14.2
4.23 4.23 4.24
Cooling Indoor Model Capacity Power
FB4BSF036 1.00 1.00 FB4BSF042 1.00 0.97
INDOOR AIR OUTDOOR COIL ENTERING AIR TEMPERATURES ˚C
--- 1 6 --- 8 0 4 8 12 16 20
(C)
EDB L/S Capacity kW Tot al
Power
kW*
Capacity kW Tot al
Power
kW*
Capacity kW Tot al
Power
kW*
Capacity kW Tot al
Power
kW*
Capacity kW Tot al
Power
kW*
Capacity kW Tot al
Power
kW*
Capacity kW Tot al
Power
kW*
Capacity kW Tot al
Power
kW*
Tot al Integ† Tota l Integ† To ta l Integ† Tot al Integ† To ta l Integ† To t a l Integ† Tot al Integ† To ta l Integ†
38YCC048---9A Outdoor Section With FS4BSF048 Indoor Section
12
650 750 850
6.41 6.48 6.56
5.89 5.96 6.03
3.05 3.08 3.13
8.38 8.49 8.58
7.63 7.72 7.81
3.25 3.27 3.31
10.9 11.0 11.1
9.79 9.92 9.99
3.48 3.49 3.50
12.3 12.4 12.5
11.5 11.6 11.7
3.61 3.60 3.61
13.9 13.9 14.2
13.8 13.9 14.2
3.75 3.72 3.74
15.8 15.9 16.1
15.8 15.9 16.1
3.92 3.89 3.88
17.8 18.1 18.2
17.8 18.1 18.2
4.12 4.08 4.05
20.1 20.4 20.4
20.1 20.4 20.4
4.34 4.30 4.25
15
650 750 850
6.35 6.43 6.50
5.84 5.91 5.98
3.19 3.23 3.27
8.33 8.42 8.52
7.58 7.67 7.75
3.40 3.42 3.45
10.8 10.9 11.0
9.71 9.82 9.90
3.64 3.64 3.66
12.2 12.3 12.4
11.4 11.5 11.6
3.78 3.77 3.77
13.8 13.8 14.1
13.7 13.8 14.0
3.93 3.89 3.91
15.6 15.8 15.9
15.6 15.8 15.9
4.11 4.07 4.06
17.7 17.9 18.0
17.7 17.9 18.0
4.32 4.27 4.24
19.9 20.1 20.2
19.9 20.1 20.2
4.55 4.49 4.45
18
650 750 850
6.29 6.37 6.44
5.79 5.86 5.92
3.34 3.37 3.41
8.27 8.36 8.45
7.52 7.61 7.69
3.55 3.57 3.60
10.7 10.8 10.9
9.62 9.72 9.81
3.80 3.80 3.81
12.1 12.2 12.3
11.3 11.4 11.5
3.95 3.93 3.94
13.6 13.7 13.9
13.6 13.7 13.8
4.10 4.07 4.07
15.5 15.6 15.8
15.5 15.6 15.8
4.30 4.25 4.24
17.5 17.7 17.8
17.5 17.7 17.8
4.52 4.46 4.43
19.7 19.9 20.0
19.7 19.9 20.0
4.76 4.69 4.65
21
650 750 850
6.24 6.31 6.39
5.73 5.80 5.87
3.48 3.51 3.54
8.21 8.30 8.39
7.47 7.55 7.63
3.70 3.71 3.74
10.6 10.7 10.8
9.54 9.63 9.72
3.96 3.96 3.97
12.0 12.1 12.2
11.2 11.3 11.4
4.11 4.09 4.10
13.5 13.6 13.7
13.4 13.6 13.7
4.28 4.25 4.24
15.3 15.5 15.6
15.3 15.5 15.6
4.48 4.44 4.42
17.3 17.5 17.7
17.3 17.5 17.7
4.72 4.65 4.62
19.4 19.6 19.8
19.4 19.6 19.8
4.96 4.88 4.84
24
650 750 850
6.20 6.27 6.34
5.70 5.76 5.83
3.64 3.66 3.70
8.18 8.25 8.31
7.44 7.51 7.57
3.86 3.87 3.89
10.5 10.6 10.7
9.46 9.55 9.63
4.13 4.12 4.13
11.9 12.0 12.1
11.1 11.2 11.3
4.29 4.27 4.27
13.4 13.5 13.6
13.3 13.4 13.6
4.46 4.43 4.42
15.1 15.3 15.5
15.1 15.3 15.5
4.67 4.63 4.61
17.1 17.3 17.5
17.1 17.3 17.5
4.91 4.85 4.82
19.2 19.4 19.6
19.2 19.4 19.6
5.18 5.09 5.05
Cooling Indoor Model Capacity Power
FB4BSF048 1.00 1.00 FB4BSF060 0.99 0.96
See notes on page 20
38YCC

20
HEAT PUMP HEATING PERFORMANCE (S.I.) (CONT.)
INDOOR AIR OUTDOOR COIL ENTERING AIR TEMPERATURES ˚C
--- 1 6 --- 8 0 4 8 12 16 20
(C)
EDB L/S Capacity kW To ta l
Power
kW*
Capacity kW To ta l
Power
kW*
Capacity kW Tota l
Power
kW*
Capacity kW To ta l
Power
kW*
Capacity kW To ta l
Power
kW*
Capacity kW To ta l
Power
kW*
Capacity kW Tota l
Power
kW*
Capacity kW To ta l
Power
kW*
Tot al Integ† Tota l Integ† To ta l Integ† Tot al Integ† To ta l Integ† To t a l Integ† Tot al Integ† To ta l Integ†
38YCC060---9A Outdoor Section With FS4BSF060 Indoor Section
12
850 900 950
1000
9.46 9.50 9.54 9.59
8.70 8.73 8.77 8.81
3.51 3.53 3.55 3.57
11.7 11.7 11.7 11.8
10.6 10.7 10.7 10.7
3.72 3.73 3.74 3.76
14.3 14.3 14.4 14.4
12.8 12.9 12.9 13.0
4.00 4.00 4.01 4.02
15.7 15.8 15.9 15.9
14.7 14.7 14.8 14.9
4.17 4.17 4.18 4.19
17.4 17.4 17.5 17.6
17.3 17.3 17.4 17.5
4.37 4.36 4.37 4.38
19.4 19.4 19.5 19.6
19.4 19.4 19.5 19.6
4.65 4.64 4.64 4.65
21.6 21.8 21.7 21.7
21.6 21.8 21.7 21.7
4.98 4.97 4.96 4.97
24.0 24.3 24.0 24.0
24.0 24.3 24.0 24.0
5.34 5.33 5.32 5.32
15
850 900 950
1000
9.42 9.46 9.51 9.55
8.66 8.70 8.74 8.78
3.73 3.75 3.77 3.79
11.6 11.7 11.7 11.7
10.6 10.6 10.6 10.7
3.96 3.97 3.98 4.00
14.2 14.3 14.3 14.4
12.8 12.8 12.9 12.9
4.25 4.25 4.26 4.27
15.7 15.7 15.8 15.9
14.6 14.7 14.7 14.8
4.43 4.43 4.43 4.44
17.3 17.3 17.4 17.5
17.2 17.3 17.3 17.4
4.64 4.63 4.64 4.64
19.2 19.3 19.4 19.4
19.2 19.3 19.4 19.4
4.93 4.91 4.91 4.91
21.4 21.5 21.5 21.6
21.4 21.5 21.5 21.6
5.26 5.24 5.23 5.23
23.7 23.9 23.7 23.8
23.7 23.9 23.7 23.8
5.63 5.61 5.60 5.60
18
850 900 950
1000
9.38 9.43 9.47 9.51
8.63 8.67 8.70 8.74
3.95 3.97 3.99 4.01
11.6 11.6 11.6 11.7
10.5 10.6 10.6 10.6
4.20 4.20 4.21 4.23
14.1 14.2 14.2 14.3
12.7 12.8 12.8 12.9
4.51 4.50 4.51 4.52
15.6 15.6 15.7 15.8
14.5 14.6 14.6 14.7
4.69 4.69 4.69 4.69
17.2 17.3 17.3 17.4
17.1 17.2 17.2 17.3
4.91 4.90 4.90 4.90
19.1 19.2 19.2 19.3
19.1 19.2 19.2 19.3
5.20 5.18 5.18 5.18
21.2 21.3 21.3 21.4
21.2 21.3 21.3 21.4
5.54 5.52 5.51 5.50
23.4 23.6 23.5 23.6
23.4 23.6 23.5 23.6
5.91 5.89 5.88 5.87
21
850 900 950
1000
9.34 9.39 9.43 9.47
8.59 8.63 8.67 8.71
4.17 4.19 4.21 4.23
11.5 11.6 11.6 11.6
10.5 10.5 10.6 10.6
4.44 4.44 4.45 4.46
14.1 14.1 14.2 14.2
12.7 12.7 12.8 12.8
4.76 4.76 4.76 4.77
15.5 15.6 15.6 15.7
14.4 14.5 14.6 14.6
4.96 4.95 4.94 4.95
17.1 17.2 17.2 17.3
17.0 17.1 17.2 17.2
5.19 5.17 5.16 5.16
18.9 19.0 19.1 19.2
18.9 19.0 19.1 19.2
5.48 5.46 5.45 5.44
21.0 21.0 21.1 21.2
21.0 21.0 21.1 21.2
5.82 5.79 5.78 5.77
23.1 23.2 23.3 23.4
23.1 23.2 23.3 23.4
6.20 6.17 6.15 6.14
24
850 900 950
1000
9.29 9.34 9.38 9.43
8.54 8.59 8.62 8.67
4.40 4.42 4.43 4.45
11.5 11.5 11.6 11.6
10.5 10.5 10.5 10.6
4.69 4.69 4.70 4.71
14.0 14.1 14.1 14.2
12.6 12.6 12.7 12.7
5.03 5.02 5.02 5.02
15.4 15.5 15.5 15.6
14.4 14.4 14.5 14.5
5.23 5.21 5.21 5.21
16.9 17.0 17.1 17.1
16.9 16.9 17.0 17.1
5.46 5.44 5.43 5.43
18.8 18.9 18.9 19.0
18.8 18.9 18.9 19.0
5.77 5.74 5.72 5.72
20.8 20.9 21.0 21.0
20.8 20.9 21.0 21.0
6.12 6.09 6.07 6.06
22.9 23.0 23.1 23.2
22.9 23.0 23.1 23.2
6.52 6.48 6.45 6.44
Cooling Indoor Model Capacity Power
FB4BSF060 1.00 1.00 FB4BSF070 0.99 0.95
NOTE: When the required data falls between the published data, interpolation may be performed. Extrapolation is not an acceptable practice. * The kW values include the compressor, outdoor fan motor, and indoor blower motor. The kw from supplement heaters should be added to these values to obtain total system kilowatts. {The kW heating capacity values shown are net integrated values from which the defrost effect has been subtracted. The kW heating from supplement heaters should be added to those values to obtain total system capacity. EDB --- E n t e r i n g D r y B u l b
38YCC
