Carrier 50JS Assembly Instructions

NOTETO INSTALLER:THIS MANUAL SHOULD BE LEFTWITHTHE EQUIPMENT USER.
50JS, JX
Single-Package Heat Pump
A GuideTo Operating and MaintainingYour
Single-Package Heat Pump Unit
Visit www.carrier.com
WELCOMETO EFFICIENT
YEAR-ROUND COMFORT
Congratulations on your excellent choice and sound invest-
ment in year-round home comfort!
Your new heat pump represents both the latest in engineering
development and the culmination of many years of experience
from one of the most reputable manufacturers of comfort
systems.
Your new unit is among the most energy-efficient and reliable
heat pump products available today. To assure its dependabili-
ty, spend just a few minutes with this booklet now. Learn about
theoperationofyour heat pump, and the smallamountofmain-
tenance it takes to keep it operating at its peak efficiency.
With minimal care, your new heat pump will provide you
with year-round home or office comfort—both now and for
years to come.
SAFETY CONSIDERATIONS
Recognize safety information. This is the safety-alert symbol
. When you see this symbol on the unit and in instructions
or manuals, be alert to the potential for personal injury.
!
Understand the signal words DANGER, WARNING, and
CAUTION. These words are used with the safety-alert symbol.
DANGER identifies the most serious hazards which
will result
in severe personal injury or death. WARNING signifies hazards
which
could result in personal injury or death. CAUTION is
used to identify unsafe practices which
would result in minor
personal injury or product and property damage. NOTE isused
to highlight suggestions which will result in enhanced installation,
reliability, or operation.
WARNING
Improper installation, adjustment, alteration, ser-
vice, maintenance, or use can cause explosion,
fire, electrical shock, or other conditions which
may cause serious injury, death or property dam-
age. Consult a qualified installer, service agency,
or your distributor or branch for information or as-
sistance. The qualified installer or agency must
use factory-authorized kits or accessories when
modifying this product.
!
Fig. 1—50JS/JX Unit

2
which allows individual control over the temperatures of sep-
arate areas of your home or office.
• Your heat pump will remove humidity from your home or
office during the cooling season. After a few minutes of oper-
ation, you should be able to see water trickle from the conden-
sate drain. Check this occasionally to be sure the drain system
is not clogged. Of course, don’t expect to see much drainage if
you live in a very dry environment.
• During the heating cycle, air from your registers may seem
cooler than you might first expect. This is because your heat
pump delivers a constant flow of air at around 90°F to 105°F
instead of sudden bursts of hot air as with a conventional fur-
nace. This air may feel cool because it is slightly cooler than
your skin temperature. However, it is sufficiently warm to
keep you comfortable.
• Ice or frost will tend to form on the coil during the winter heat-
ing operation.Your heat pump is designed to automatically melt
the ice.When in this defrost cycle, it is normal for steam or fog to
rise from the outdoor unit. Do not be alarmed!
• Do not operate your unit in the cooling mode when outdoor
temperatures are below 55°F unless your unit was modified
for low-ambient operation.
• Do not operate your unit in the heating mode when outdoor
temperatures are above 66°F unless you set your thermostat
to emergency heat mode.
OPERATINGYOUR HEAT PUMP
The operation of your heat pump system is controlled by the
indoor thermostat.You simply adjust the thermostat and it
maintains the indoor temperature at the level you select. Most
thermostats for heat pump systems have 3 controls: a temper-
ature control selector, a FAN control, and a SYSTEM or
MODE control. Refer to your T-stat owner’s manual for more
information.
Fig. 2—Typical Installation
INDOOR
THERMOSTAT
DISCONNECT
PER NEC
FROM
POWER
SOURCE
RETURN
AIR
TOP COVER
YOUR COMFORT SYSTEM
IdentifyingYour System
Take the time to familiarize yourself with your packaged heat
pump system.This knowledge will be of use in understanding
the basic operation of your new heat pump.
The unit has a rating plate affixed to it which provides neces-
saryinformationforspecificidentificationofaunit.Youshould
familiarize yourself with the product, model, and serial num-
bers listed on each rating plate. Record them for future refer-
ence on the last page of this booklet.
IMPORTANT FACTS
To betterprotectyourinvestmentand to eliminate unnecessary
service calls, familiarize yourself with the following facts:
• Your heat pump system should never be operated without a
clean air filter properly installed. Plan to inspect the filter peri-
odically. A clogged air filter will increase operating costs and
shorten the life of the unit.
• Supply-air and return-air registers should not be blocked.
Drapes, furniture, and toys are some of the items commonly
found obstructing registers. Restricted airflow lessens the
unit’s efficiency and life span.
• The outdoor unit must have unrestricted airflow. Do not cov-
er the unit, lean anything against it, or stand on it. Do not allow
grass clippings, leaves, or other debris to accumulate around
or on top of the unit. Maintain a 12-in. minimum clearance
between the outdoor unit and tall grass, vines, shrubs, etc.
• Your multipurpose indoor thermostat is the control center
for your heat pump system.You should familiarize yourself
with its proper operation.Attempting to control the system by
other means—for instance, switching the electrical supply
power ON and OFF—may cause damage to the unit. (See
Fig. 3.)
• During heating, increasing the thermostat setting more than
2º may cause the supplemental heaters to be turned on for a
short period of time to satisfy the thermostat. Needless use of
the supplementary heat reduces potential energy savings.
• You may find that you can maintain greater personal com-
fort by running the fan continuously. “Air pockets” can form
due to the structure of your home or office, placement of reg-
isters, etc.These air pockets may be too cool or warm for your
liking. Continuous fan operation minimizes any temperature
differences. Also, systems equipped with electronic or
mechanical air cleaners and/or humidifiers offer the added
benefits of having the air continuously cleaned year-round and
humidified during the winter season.
• A system equipped with a heat or energy recovery ventilator
offers the advantage of exhausting stale air from your home or
office and allowing fresh air in from the outdoors while mini-
mizing heat loss.
• Your system may also be equipped with a zoning system
WARNING
To prevent serious injury, death, or property dam-
age, read and follow all instructions and warnings,
including labels shipped with or attached to unit
before operating your new heat pump.
!
Fig. 3—Carrier Non-ProgrammableT-stat

3
COOLING MODE
When operating in cooling mode, your heat pump will run in
cooling mode until the indoor temperature is lowered to the
level you have selected. On extremely hot days, your heat
pump will run for longer periods at a time and have shorter
“off” periods than on moderate days.
The following are typical conditions that add extra heat and/or
humidity to your home or office.Your heat pump will work
longer to keep your home or office comfortable under these
conditions:
• Entrance doors are frequently opened and closed
• Laundry appliances are being operated
• A shower is running
• Morethan theusualnumber of peopleare present inthehome or
office
• More than the normal number of electric lights are in use
• Drapes are open on the sunny side of the home or office
HEATING MODE
With the SYSTEM or MODE control of your indoor thermo-
statsettoHEAT,yourheatpumpwillrunin heating mode until
room temperature is raised to the level you have selected. Of
course, your heat pump will have to operate for longer periods
to maintain a comfortable environment on cooler days and
nights than on moderate ones.
SUPPLEMENTAL HEAT
Your heat pump is your primary heating source.Your system
mayalso be equipped withasupplementalheating source such
aselectricheat.Oncolddaysand nights, your systemwillauto-
matically turn on the supplemental heat in order to maintain
the level of comfort you have selected.
When your heat pump needs additional heat to keep you com-
fortable, your Carrier electronic thermostat will turn on the
supplemental heat (if equipped) and will display the “AUX
HT” message.
DEFROST MODE
When your heat pump is providing heat to your home or office and
the outdoor temperature drops below 45°F, moisture may begin to
freezeonthesurfaceofthecoil.Ifallowedtobuildup,thisicewould
impede airflow across the coil and reduce the amount of heat
absorbed from the outside air. So, to maintain energy-efficient
operation, your heat pump has an automatic defrost mode.
The defrost mode starts at a preset time interval of 90 minutes,
although, it may be reset to either 30 or 50 minutes. Defrost
will start at the preset time only if the ice is sufficient to inter-
fere with normal heating operation.
After the ice is melted from the coil, or after a maximum of 10
minutes in defrost mode, the unit automatically switches back
to normal heating operation.
Do not be alarmed if steam or fog appears at the outdoor unit
during defrost mode. Water vapor from the melting ice may
condense into a mist in the cold outside air.
During certain weather conditions such as heavy snow and
freezing rain it is not uncommon for ice to build up on the unit
grille. This is normal for these weather conditions. Do not
attempt to remove the ice from the unit grille. This condition
will not affect the proper function of the unit and will clear
within a few days.
EMERGENCY HEAT MODE
This allows your supplemental heating source to keep your
homeorofficewarmuntil your heatpumpcanbeserviced.Also,
if the electricity to your heat pump has been off for more than
30 minutes, switch your thermostat to EHEAT mode before
restarting your heat pump. Leave the system in EHEAT mode
for an amount of time equal to the power outage. It is not neces-
sary to exceed 12 hrs. (If your cannot determine how long the
power has been off, leave the system in EHEAT mode for 8 hrs.)
PERFORMING ROUTINE
MAINTENANCE
With the proper maintenance and care, your heat pump will
operate economically and dependably. Maintenance can be
accomplished easily by referring to the following directions.
However, before performing maintenance, consider these
important safety precautions:
CHECKTHE AIR FILTER
A dirty air filter will cause excessive strain on the compressor
and blower motor. This can cause the components to over-heat
and automatically shut down. In the worst case, the compo-
nents will fail and need to be replaced. To avoid inefficient or
failed operation of your unit, CHECK THE FILTER(S)
EVERY 3 TO 4 WEEKS. Replace filter(s) when necessary, or
clean the filter(s) if you have the reusable type.
WARNING
Disconnect all electrical power to the indoor air han-
dler or furnace before removing access panels to per-
form any maintenance. Disconnect power to the unit.
Note: There may be more than 1 electrical disconnect
switch. Electrical shock could cause severe injury or
death.
CAUTION
Although special care has been taken to minimize
sharp edges in the construction of your unit, be ex-
tremely careful when handling parts or reaching into
the unit.
Fig. 4—Main Electrical Disconnect
MAIN
ON
OFF
!
!

4
below room temperature and the SYSTEM or MODE control
is set to COOL or AUTO. If you require warmth, make sure
that the temperature control selector is set above room temper-
ature and the SYSTEM or MODE control is set to HEAT or
AUTO. The FAN control should be set to ON for continuous
blower operationorAUTOifyou wish blowerto functiononly
while your heat pump is operating.
If your comfort system still fails to operate, turn your system
off and contact your servicing dealer for troubleshooting and
repairs. Specify your apparent problem, and state the model
and serial number of your equipment. (You should have them
recorded on the last page of this booklet.) With this informa-
tion, your dealer may be able to offer helpful suggestions over
the phone or save valuable time through knowledgeable prep-
aration for the service call.
REGULAR DEALER MAINTENANCE
In addition to the routine mainte-
nancethatyouperform, your home
comfort system should be inspect-
ed regularly by a properly trained
service technician. The inspection
(preferably twice each year, but at
least once every year) should
include the following:
• Routine inspection of air filter(s). Replacement or cleaning
as required.
• Inspection and cleaning of the blower wheel, housing, and
motor as required.
• Inspection and, if required, cleaning of coils.
• A check of all electrical wiring and connections.
• A check for secure physical connections of individual com-
ponents within unit.
• Operational check of the heat pump system to determine
actual working condition. Necessary repair and/or adjustment
should be performed at this time.
• Your servicing dealer may offer an economical service
contract that covers seasonal inspections.Ask for further details.
WARRANTIES
You have purchased either a 50JS or 50JX series unit. Each
has a separate warranty at the back of this booklet. Be sure
to read the warranty carefully to determine the coverage for
your unit.
FORTHE RECORD
Record the model, product, and serial numbers of your new
equipment in the spaces provided. This information, along
with the other ready-reference facts requested will be
necessary should you ever require information or service.
Filter SizeTable
UNIT SIZE
50JX 024 030 036 042 048 060
RETURN-AIR
FILTERS (in.)
Throwaway
20 x 20 20 x 20 20 x 24 24 x 30 24 x 30 24 x 30
UNIT SIZE
50JS 018 024 030 036 042 048 060
RETURN-AIR
FILTERS (in.)
Throwaway
20 x 20 20 x 20 20 x 20 20 x 24 24 x 30 24 x 30 24 x 30
Disposable filters should be replaced by similar, new filters of
the same dimensions.
Reusable, permanent filters should be washed in a solution of
cold water and mild detergent, then rinsed and thoroughly
dried. THE FILTER MUST BE COMPLETELY DRY
BEFORE BEING REINSTALLED. To avoid prolonged shut-
down of your unit while a filter is drying, you should have an
extra filter on hand. This allows you to rotate between the 2
with minimal downtime for your comfort system. Extra filters
may be purchased from your dealer.
The filters(s) and filter rack for a packaged system are supplied
andinstalledbythecontractorordealer.Typically,thefilter(s)and
rackare located inthereturn-airductat the outdoorunitorbehind
the return-air grille(s). Have your dealer show you the location of
your filter(s) and the procedures for removal and replacement.
If your system includes a high efficiency or electronic air
cleaner, refer to air cleaner User’s Manual for proper filter
cleaning or replacement.
OUTDOOR COIL
If grass clippings, leaves, shrubbery, and debris are kept away
from the unit, minimal care should be sufficient to keep the
system functioning properly. However, if the outdoor coil
becomes dirty, use a vacuum cleaner or shop vac with soft
brush attachment to clean the exterior surface. Vacuum coil
surface using an up and down motion. Be careful not to bend
or damage fins.
If dirt is deep in the coil, contact your dealer for service. Do
not attempt this yourself.
OUTDOOR COIL—SEA COAST
If your unit is located near the ocean, special maintenance is
required. Ocean mist/breeze carries salt, which is corrosive to
mostmetals.Although your newunit is made out of galvanized
metal and is protected by top-grade paint, you should take the
precaution of additional maintenance which consists of peri-
odicallywashingtheunit.Bywashingallexposedsurfacesand
coil, you will be adding additional life to your unit. Please con-
sult your installing contractor for proper intervals/procedures
for your geographic area or service contact.
UNIT SUPPORT
Your packaged heat pump unit should be maintained at a level
position. If its support should shift or settle so that the unit is
no longer level, you should correct the condition. Relevel it
promptly to assure water drains out of the unit. If you notice
that water or ice collects beneath the unit, arrange for it to be
drained away from the unit.
BEFOREYOU REQUEST A
“SERVICE CALL”
CHECK FORTHESE EASILY SOLVED
PROBLEMS:
• Check the indoor and outdoor disconnect switches.Verify
that circuit breakers are ON or that fuses have not blown.
• Check for sufficient airflow. Check the air filter(s) for any
accumulations of dirt. Check for blocked return-air or supply-
air registers. Be sure registers are open and unobstructed.
• Check the settings on your indoor thermostat. If you desire
cooling, make sure that the temperature control selector is set

5
First Name Initial Last Name Street  City
Apt. No. 
State ZIP Code

1. Mr. 2. Mrs. 3. Ms. 4. Miss
Date of Installation: Month Day Year
Date of birth of person whose name appears above: Month Year
Important! For proper registration, please fill in the  model number, and serial number of this product: A. Model Number:  B. Serial Number: What type of product is this? A. Price paid for this product (excluding installation charges and sales tax): B. Price paid for installation: Name of company that sold you this product: When did you acquire your product? 1. Upon purchase of a new dwelling. 2. To replace an older system of the same brand. 3. To replace an older system of another brand. 4. Within a year after purchasing a dwelling with no central air. 5. 2-4 years after buying a dwelling with no central air system. 6. Over 4 years after buying a dwelling with no central air system.
If you replaced an older system, approximately how old was that system? 1. Don’t know 2. 1-5 years 3. 6-8 years 4. 9-11 years 5. 12-14 years If this is a replacement, what brand did you previously own? 1. Central Air Conditioner 2. Gas Furnace 3. Oil Furnace 4. Electric Furnace 5. Heat Pump
$ .00 $ .00
1. Amana 2. Bryant 3. Carrier 4. Day & Night 5. Heil
6. Janitrol 7. Lennox 8. Payne 9. Rheem 10. Ruud
11. Snyder 12. Tempstar 13. Trane 14. York 15. Other __________
6. 15-17 years 7. 18-20 years 8. 21-24 years 9. Over 24 years
What factors most influenced your selection of this product? (Check a maximum of two.) 1. Brand reputation 2. Dealer reputation 3. Previous experience with products of this brand 4. Previous experience with this dealer 5. Price
Excluding yourself, what is the SEX and AGE (in years) of children and other adults living in your household? Marital Status:   Occupation: Which group describes your annual family income? 1. Under $15,000 2. $15,000-$19,999 3. $20,000-$24,999 4. $25,000-$29,999 5. $30,000-$34,999 6. $35,000-$39,999 Education: (please check those which apply) Which credit cards do you use regularly? For your primary residence, do you: 
1. No one else in household
1. Married 2. Divorced/Separated 3. Widowed
4. Never Married (Single)
Homemaker Professional/Technical Upper Management/Executive Middle Management Sales/Marketing Clerical or Service Worker Tradesman/Machine Oper./Laborer Retired Student
. . . . . . . . . . . .
. . . . . . . .
. . . . .
. . . . . . . . .
. . . . . . . . . . .
. . . . . . .
. . .
. . . . . . . . . . . . . .
. . . . . . . . . . . . . .
Self Employed/Business Owner
7. $40,000-$44,999 8. $45,000-$49,999 9. $50,000-$59,999 10. $60,000-$74,999 11. $75,000-$99,999 12. $100,000 & over
Some High School or Less Completed High School Vocational/Technical School Some College Completed College Some Graduate School Completed Graduate School 1. American Express, Diners Club 2. MasterCard, Visa, Discover 3. Department Store, Oil Company, etc. 4. Do not use credit cards 1. Own a House? 2. Own a Townhouse or Condominium? 3. Rent a House? 4. Rent an Apartment, Townhouse or Condominium?
10.
. . . . . .
. . . . . . . .
. . . . . .
. . . . . . . . . . .
. . . . . . . . .
. . . . . . . .
. . . . . .
10
9 8 7 6 5 4 3 2 1
18 17 16 15 14 13 11
6. Energy efficiency 7. Location of dealer 8. Dealer’s installation policy 9. Friend’s/relative’s recommendation 10. Contractor’s/dealer’s recommendation 11. Other ____________________
1. 1.
Age
years
Female
2.
Male
2. years
You 1.
2. 3. 4. 5. 6. 7.
Spouse
12
6. Heat Recovery Ventilator 7. Thermostat 8. Zoning 9. Humidifier 10. Electronic Air Cleaner
You 1.
2. 3. 4. 5. 6. 7. 8. 9.
Spouse
1. 1.
Age
years
Female
2.
Male
2. years
®
19
Fold Along This Line Last
Tape Here
Remove From Booklet or Tear Along Dotted Line
®
Please send products and other correspondence to: Carrier Consumer Relations Department P.O. Box 4808 Syracuse, NY 13221
PLACE
FIRST-CLASS
STAMP
HERE
PO BOX 173244 DENVER CO 80217-3244
Thanks for taking the time to fill out this questionnaire. Your answers will be used for market research studies and reports — and will help us better serve you in the future. They will also allow you to receive important mailings and special offers from a number of fine companies whose products and services relate directly to the specific interests, hobbies, and other information indicated above. Through this selective program, you will be able to obtain more information about activities in which you are involved and less about those in which you are not. Please check here if, for some reason, you would prefer
not
to participate in this opportunity.
If you have comments or suggestions about our product please write to:
To help us understand our customers’ lifestyles, please indicate the interests and activities in which you or your spouse enjoy participating on a regular basis:  Please check all that apply to your household: Using the numbers in the above list, please indicate the 3 most important activities for: 01. Bicycling Frequently 02. Golf 03. Physical Fitness/Exercise 04. Running/Jogging 05. Snow Skiing Frequently 06. Tennis Frequently 07. Camping/Hiking 08. Fishing Frequently 09. Hunting/Shooting 10. Power Boating 11. Sailing 12. House Plants 13. Grandchildren 14. Needlework/Knitting 15. Vegetable Gardening 16. Flower Gardening 17. Sewing
35. Gourmet Cooking 36. Wines 37. Coin/Stamp Collecting 38. Collectibles/Collections 39. Our Nation’s Heritage 40. Real Estate Investments 41. Stock/Bond Investments 42. Entering Sweepstakes 43. Casino Gambling 44. Science Fiction 45. Wildlife/Environmental Issues 46. Dieting/Weight Control 47. Science/New Technology 48. Self Improvement 49. Walking for Health 50. Watching Sports on TV
18. Crafts 19. Automotive Work 20. Electronics 21. Home Workshop/Do It Yourself 22. Recreational Vehicles 23. Stereo, Records/Tapes/CDs 24. Buy Pre-Recorded Videos 25. Avid Book Reading 26. Bible/Devotional Reading 27. Health/Natural Foods 28. Photography 29. Home Furnishing/Decorating 30. Attending Cultural/Arts Events 31. Fashion Clothing 32. Fine Art/Antiques 33. Foreign Travel 34. Travel in the USA
You Spouse
Carrier Consumer Relations Department P.O. Box 4808 Syracuse, NY 13221 or call 1-800-C-A-R-R-I-E-R 
1. Regularly Purchase Items Through the Mail 2. Military Veteran in Household 3. Member of Frequent Flyer Program
4. Support Health Charities 5. Subscribe to Cable TV 6. Have a Microwave Oven 7. Have a CD Player
8. Have a VCR 9. Use a Personal Computer 10. Have a Dog 11. Have a Cat
19 20 21
Fold Along This Line First

6

7
ALL WORK UNDER THE TERMS OF THIS WARRANTY SHALL BE
PERFORMED DURING NORMAL WORKING HOURS. ALL
REPLACEMENT PARTS, WHETHER NEW OR REMANUFACTURED,
ASSUME AS THEIR WARRANTY PERIOD ONLY THE REMAINING TIME
PERIOD OF THIS WARRANTY.

CARRIER WILL NOT BE RESPONSIBLE FOR: 
1. Normal maintenance as outlined in the installation and servicing instructions or
owner's manual including coil cleaning, filter cleaning and/or replacement and
lubrication.
2. Damage or repairs required as a consequence of faulty installation or application
by others.
3. Failure to start due to voltage conditions, blown fuses, open circuit breakers or
other damages due to the inadequacy or interruption of electrical service.
4. Damage or repairs needed as a consequence of any misapplication, abuse,
improper servicing, unauthorized alteration or improper operation.
5. Damage as a result of floods, winds, fires, lightning, accidents, corrosive
atmosphere or other conditions beyond the control of CARRIER.
6. Parts not supplied or designated by CARRIER.
7. CARRIER products installed outside the continental U.S.A., Alaska, Hawaii and
Canada.
8. Electricity or fuel costs or increases in electricity or fuel costs from any reason
whatsoever including additional or unusual use of supplemental electric heat.
9. ANY SPECIAL, INDIRECT OR CONSEQUENTIAL PROPERTY OR COMMER-
CIAL DAMAGE OF ANY NATURE WHATSOEVER. Some states do not allow the
exclusion of incidental or consequential damages, so the above limitation may not
apply to you.
ONE-YEAR WARRANTY—This CARRIER product is warranted to be free
from defects in material and workmanship under normal use and
maintenance for a period of 1 year from the date of original installation,
whether or not actual use begins on that date. A new or remanufactured
part to replace any defective part will be provided at Carrier’s sole option
without charge for the part itself, PROVIDED the defective part is returned
to our distributor. This warranty applies only to the product in its original
installation location and is voided if the product is reinstalled elsewhere.
THIS WARRANTY DOES NOT INCLUDE LABOR or other costs incurred
for diagnosing, repairing, removing, installing, shipping, servicing or
handling of either defective parts or replacement parts. SUCH COSTS
MAY BE COVERED BY a separate warranty provided by the installer.
EXTENDED 4-YEAR WARRANTY ON COMPRESSOR ONLY—During the
second through fifth years after the date of original installation, CARRIER
further warrants the compressor against defects in material or workmanship
undernormaluseandmaintenance. Aneworremanufacturedcompressorwill
beprovidedatCarrier'ssoleoption underthesameconditionsasstatedinthe
1-YEAR WARRANTY.
LIMITATIONS OF WARRANTIES—ALL IMPLIED WARRANTIES
(INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY) ARE
HEREBY LIMITED IN DURATION TO THE PERIOD FOR WHICH EACH
LIMITED WARRANTY IS GIVEN. SOME STATES DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE
ABOVE LIMITATIONS MAY NOT APPLY TO YOU. THE EXPRESSED
WARRANTIES MADE IN THIS WARRANTY ARE EXCLUSIVE AND MAY
NOT BEALTERED, ENLARGED, OR CHANGED BY ANY DISTRIBUTOR,
DEALER, OR OTHER PERSON WHATSOEVER.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Extended Protection Limited Warranty
Form No. 530-001 (Rev. 3/80)

FIRST:
SECOND:
THIRD:
Contact the installer. You may find his name on the product or in your
Homeowner's Packet. If his name is not known, call your builder if
yours is a new residence.
Contact the nearest CARRIER distributor. (See telephone yellow pages.)
Contact:
CARRIER CORPORATION
Consumer Relations Department 
P.O. Box 4808
Syracuse, New York 13221
1-800-CARRIER (227-7437)
CARRIER CORPORATION
IF YOUR UNIT DOES NOT WORK, FOLLOW THESE STEPS IN ORDER: 

Unit Model No. 
Date of Installation 
Name of Owner
Unit Serial No. 
Installed by 
Address of Installation
®
Fig. 5—50JS Warranty

8

9
FIRST:
SECOND:
THIRD:
Contact the installer. You may find his name on the product or in your
Homeowner's Packet. If his name is not known, call your builder if
yours is a new residence.
Contact the nearest CARRIER distributor. (See telephone yellow pages.)
Contact:
CARRIER CORPORATION
Consumer Relations Department 
P.O. Box 4808
Syracuse, New York 13221
1-800-CARRIER (227-7437)
CARRIER CORPORATION
IF YOUR UNIT DOES NOT WORK, FOLLOW THESE STEPS IN ORDER:

Unit Model No. 
Date of Installation 
Name of Owner
Unit Serial No. 
Installed by 
Address of Installation
®
First Name Initial Last Name Street  City
Apt. No. 
State ZIP Code

1. Mr. 2. Mrs. 3. Ms. 4. Miss
Date of Installation: Month Day Year
Date of birth of person whose name appears above: Month Year
Important! For proper registration, please fill in the  model number, and serial number of this product: A. Model Number:  B. Serial Number: What type of product is this? A. Price paid for this product (excluding installation charges and sales tax): B. Price paid for installation: Name of company that sold you this product: When did you acquire your product?
1. Upon purchase of a new dwelling. 2. To replace an older system of the same brand. 3. To replace an older system of another brand. 4. Within a year after purchasing a dwelling with no central air. 5. 2-4 years after buying a dwelling with no central air system. 6. Over 4 years after buying a dwelling with no central air system. If you replaced an older system, approximately how old was that system? 1. Don’t know 2. 1-5 years 3. 6-8 years 4. 9-11 years 5. 12-14 years If this is a replacement, what brand did you previously own? 1. Central Air Conditioner 2. Gas Furnace 3. Oil Furnace 4. Electric Furnace 5. Heat Pump
$ .00 $ .00
1. Amana 2. Bryant  3. Carrier  4. Day & Night 5. Heil 
6. Janitrol 7. Lennox 8. Payne 9. Rheem 10. Ruud
11. Snyder 12. Tempstar 13. Trane 14. York 15. Other __________ 
6. 15-17 years 7. 18-20 years 8. 21-24 years 9. Over 24 years
What factors most influenced your selection of this product? (Check a maximum of two.) 1. Brand reputation 2. Dealer reputation 3. Previous experience with products of this brand 4. Previous experience with this dealer  5. Price 
Excluding yourself, what is the SEX and AGE (in years) of children and other adults living in your household? Marital Status:   Occupation: Which group describes your annual family income? 1. Under $15,000 2. $15,000-$19,999 3. $20,000-$24,999 4. $25,000-$29,999 5. $30,000-$34,999 6. $35,000-$39,999 Education: (please check those which apply) Which credit cards do you use regularly? For your primary residence, do you: 
1. No one else in household 
1. Married 2. Divorced/Separated 3. Widowed
4. Never Married (Single)
Homemaker  Professional/Technical Upper Management/Executive Middle Management Sales/Marketing Clerical or Service Worker Tradesman/Machine Oper./Laborer Retired Student 
. . . . . . . . . . . .
. . . . . . . .
. . . . .
. . . . . . . . .
. . . . . . . . . . .
. . . . . . .
. . .
. . . . . . . . . . . . . . 
. . . . . . . . . . . . . . 
Self Employed/Business Owner 
7. $40,000-$44,999 8. $45,000-$49,999 9. $50,000-$59,999 10. $60,000-$74,999 11. $75,000-$99,999 12. $100,000 & over
Some High School or Less Completed High School Vocational/Technical School Some College Completed College  Some Graduate School Completed Graduate School 1. American Express, Diners Club 2. MasterCard, Visa, Discover 3. Department Store, Oil Company, etc. 4. Do not use credit cards 1. Own a House? 2. Own a Townhouse or Condominium? 3. Rent a House? 4. Rent an Apartment, Townhouse or Condominium?
10.
. . . . . .
. . . . . . . .
. . . . . .
. . . . . . . . . . .
. . . . . . . . .
. . . . . . . .
. . . . . .
10
9 8 7 6 5 4 3 2 1
18 17 16 15 14 13 11
6. Energy efficiency 7. Location of dealer 8. Dealer’s installation policy 9. Friend’s/relative’s recommendation 10. Contractor’s/dealer’s recommendation 11. Other ____________________
1. 1.
Age
years
Female
2.
Male
2. years
You 1.
2. 3. 4. 5. 6. 7.
Spouse

12
6. Heat Recovery Ventilator 7. Thermostat 8. Zoning
You 1.
2. 3. 4. 5. 6. 7. 8. 9.
Spouse
1. 1.
Age
years
Female
2.
Male
2. years
®
19
ALL WORK UNDER THE TERMS OF THIS WARRANTY SHALL BE
PERFORMED DURING NORMAL WORKING HOURS. ALL
REPLACEMENT PARTS, WHETHER NEW OR REMANUFACTURED,
ASSUME AS THEIR WARRANTY PERIOD ONLY THE REMAINING TIME
PERIOD OF THIS WARRANTY.
CARRIER CORPORATION WILL NOT BE RESPONSIBLE FOR:
1. Normal maintenance as outlined in the installation and servicing instructions or
owner's manual including coil cleaning, filter cleaning and/or replacement and
lubrication.
2. Damage or repairs required as a consequence of faulty installation or application
by others.
3. Failure to start due to voltage conditions, blown fuses, open circuit breakers or
other damages due to the inadequacy or interruption of electrical service.
4. Damage or repairs needed as a consequence of any misapplication, abuse,
improper servicing, unauthorized alteration or improper operation.
5. Damage as a result of floods, winds, fires, lightning, accidents, corrosive
environments or other conditions beyond the control of CARRIER.
6. Parts not supplied or designated by CARRIER.
7. CARRIER products installed outside the continental U.S.A., Alaska, Hawaii, and
Canada.
8. Electricity or fuel costs or increases in electricity or fuel costs for any reason
whatsoever including additional or unusual use of supplemental electric heat.
9. ANY SPECIAL, INDIRECT OR CONSEQUENTIAL PROPERTY OR COMMER-
CIAL DAMAGE OF ANY NATURE WHATSOEVER. Some states do not allow the
exclusion of incidental or consequential damages, so the above limitation may not
apply to you.
LIMITED ONE-YEAR WARRANTY—This CARRIER product is warranted
to be free from defects in material and workmanship under normal use and
maintenance for a period of one year from the date of original installation,
whether or not actual use begins on that date. A new or remanufactured
part to replace any defective part will be provided, within a reasonable time
after return of the defective part, at Carrier’s sole option without charge for
the part itself, PROVIDED the defective part is returned to our distributor.
This warranty applies only to the product in its original installation location
and is voided if the product is reinstalled elsewhere.
THIS WARRANTY DOES NOT INCLUDE LABOR or other costs incurred
for diagnosing, repairing, removing, installing, shipping, servicing or
handling of either defective parts or replacement parts. SUCH COSTS
MAY BE COVERED BY a separate warranty provided by the installer.
EXTENDED LIMITED NINE-YEAR WARRANTY ON COMPRESSOR
ONLY—During the second through tenth years after the date of original
installation, CARRIER further warrants the compressor against defects in
material and workmanship under normal use and maintenance. A new or
remanufactured compressor willbe provided at Carrier's soleoption under
the sameconditionsasstated in the One-YearWarranty.
LIMITATION OF WARRANTIES—ALL IMPLIED WARRANTIES
(INCLUDING IMPLIED WARRANTIES OF FITNESS AND
MERCHANTABILITY) ARE HEREBY LIMITED IN DURATION TO THE
PERIOD FOR WHICH THE LIMITED ONE YEAR WARRANTY IS GIVEN.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATIONS MAY NOT
APPLY TO YOU. THE EXPRESS WARRANTIES MADE IN THIS
WARRANTYAREEXCLUSIVE ANDMAYNOTBEALTERED, ENLARGED,
OR CHANGED BY ANY DISTRIBUTOR, DEALER, OR OTHER PERSON
WHATSOEVER.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Extended Protection Limited Warranty
Form No. 530-050 (New 10-89)
Detach & Mail Product Registration Card – RETAIN THIS WARRANTY CERTIFICATE
Fig. 6—50JX Warranty

10

11

TO OBTAIN INFORMATION ON PARTS: Consult your installing dealer or classified section of your local telephone directory under the
“Heating Equipment’’ or “Air Conditioning Contractors & Systems’’ heading for dealer listing by brand name.
Have available the Model No., Series Letter, & Serial No. of your equipment to ensure correct replacement part.
Carrier Corporation Indianapolis, Indiana 46231
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations .
Copyright 1999 Carrier Corporation Form: OM50-26 Replaces: NEW Printed in the U.S.A. 11-99 PC 101 Catalog No.565-060
INSTALLATION DATA
Date Installed
Dealer Name
Address
City
State Zip
Telephone
UNIT DATA
Product No.
Model No.
Serial No.
Heater, if applicable:
Part No.
Kilowatt Rating
