38YZA (60Hz)
Deluxe 12 SEER Split-System
Heat Pump with Puron
®
Refrigerant
Sizes 024 thru 060
Carrier’s technological leadership
has risen to a new level with the
development of the 38YZA Heat
Pump, the outdoor section of a
superior split heat pump system. This
leadership effort has yielded a
product that appeals to consumers for
all of its unique benefits.
Puron®, the environmentally sound
refrigerant — The first unique feature
of the 38YZA is the environmentally
sound nature of Puron, which provides
the homeowner with additional peace
of mind because their heating and
cooling system’s refrigerant has zero
ozone-depletion potential.
Second, thanks to the performance
advantage of Puron, the 38YZA is
extremely efficient. In fact, the
38YZA features some of the lowest
energy usages of single speed heat
pumps available from Carrier.
Maximum performance and
efficiency are made possible through
the use of the FX4A and FV4A fan
coils, Custom Made for Puron
applications.
Third, the cost of service will
potentially be reduced in the future as
the industry’s older refrigerant, R-22
is gradually phased out through
Federally legislated production
limitations.
FEATURES/BENEFITS
PressureGuard™/Ease of
Installation — Another unique feature
of the WeatherMaker 38YZA is the
patent-pending PressureGuard™,
which enables the use of line sets
currently employed across the
industry. For retrofit applications,
PressureGuard prevents mandatory
replacement of line sets. For new
INTRODUCING THE WEATHERMAKER 38YZA HEAT PUMP
FEATURING PURON
®
THE ENVIRONMENTALLY SOUND REFRIGERANT

2
HEAT PUMP SYSTEM
Model number nomenclature
38YZA 024
Electric Heat Pump
Nominal Capacity
024 — 24,000 Btu 042 — 42,000 Btu
030— 30,000 Btu 048 — 48,000 Btu
036— 36,000 Btu 060 — 60,000 Btu
301
Packaging
Series
Electrical
3—208/230-1
installations, line sets currently in stock
for R-22 applications can also be used in
WeatherMaker 38YZA applications.
Silencer System/Quiet Operation —
The Silencer System features the
InViroFlow™ design, energy-efficient
fan and motor, sound hood and
discharge muffler. The InViroFlow
Design improves airflow patterns and
requires less energy. The energy
efficient fan and fan motor add to quiet
operation while moving air more
efficiently. The sound hood muffles
noise from the operation. The discharge
muffler minimizes low frequency
sound and pressure pulsation generated
by the compressor discharge gas.
Compressor — The 38YZA features
the efficient Copeland Scroll
compressor, specially designed for
Puron applications, with its thicker
shell, and an anti-reverse rotation device
for superior reliability and quiet
operation. In addition, each compressor
is mounted on rubber isolators for
additional sound reduction. The scroll
compressor will start under most system
loads, thus eliminating the need for start
assisting components. Continuous
operation is approved
down to -30°F (-34.4°C) in the heating
mode and down to 55°F (12.8°C) in
the cooling mode. (See heating and
cooling performance tables.) The scroll
compressor is covered with a standard
10-year limited warranty.
Patented-Pending Accumulator/
Reliable Operation — Unique to the
WeatherMaker 38YZA is the patent-
pending accumulator, which ensures an
oil rich flow of refrigerant to the
compressor. This oil return is beneficial
especially on start up when compressor-
protecting lubrication is needed most.
Built-In Reliable Components —
The 38YZA’s principal feature of
compressor protection is further
enabled by a high pressure switch; a
discharge temperature switch for
compressor overtemperature
protection; and a low pressure switch
for loss of charge protection. Reliable
operationisalsooptimized witha heavy
duty, quiet and easy to service reversing
valve.
Defrost Control Board — This board
incorporates a built-in 5-minute
compressor time-delay relay, defrost
relay, defrost timer, and low-voltage
terminal board. The defrost control
is a time/temperature initiation/
termination control which includes 3
field-selectable time periods of 30,
50, and 90 minutes.
Thermostatic Expansion Valve (TXV)
— This unit must be installed with a
Puron TXV on the indoor coil. The FX4
and FV4 indoor fan coils come factory
equipped with a bi-flow Puron TXV.
When installed in this application, no
further change is required. If any other
indoor fan coil or furnace coil is used,
an accessory bi-flow Puron TXV must
be installed. See accessory list in this
publication for correct part number.
WeatherArmor III System includes
three components:
—Casing steelisgalvanized andcoated
with a layer of zinc phosphate. A
modifiedpolyesterpowdercoatingis
thenappliedand bakedon, providing
each unit with a hard, smooth finish
that will last for many years.
—All screws on cabinet exterior are
SermaGuard coated for a long-
lasting, rust-resistant, quality
appearance.
—The coil is protected with an
enhanced coil guard. With spacing
of 3/8-in. and construction of coated
12 gage wire, the guard helps protect
from inclement weather (hail),
vandalism, and incidental damage.
Unit Design —All units are equipped
with totally enclosed fan motors for
greater reliability under rain and snow
conditions. The large, wraparound coil
uses copper tubing and enhanced sine
wave aluminum fins and is designed for
optimum heat transfer during heating
and cooling. The vertical air discharge
carries the sound and air up and away
from adjacent patio areas and foliage.
Rows of composite coils can be cleaned
with a common garden hose.
External Service Valves —Both service
valves are the brass, back seating type
with sweat connections. Each valve
has a service port for ease of checking
operating refrigerant pressures. The
suction service port provides for ease
of checking operating pressure in the
heating mode.
Limited Warranty
—Standard
1-year limited warranty on all parts,
with an additional 9-year limited
warranty on the compressor.
This heat pump can be part of a Comfort Heat Pump System which
can provide up to 15 degree higher heating supply air temperatures,
as well as up to 30 times more humidity removal in cooling mode.
A Comfort Heat Pump System requires the use of a 40FKA (Fan
Coil with Thermidistat Control), or an FV4A Fan Coil with a B-
series Thermidistat Control. See the Comfort Heat Pump System
Product Introduction (CD and 40FKA Product Data) for more
information.

3
Physical data
† Charge quantity is for 15 ft of interconnecting tubing. For tubing lengths other than 15 ft, see Residential Split-Systems Long-Line Application Guideline for
additional refrigerant requirements.
NOTE: 1. See unit Installation Instructions for proper installation.
RECOMMENDED TUBE DIAMETERS
METERING DEVICE
UNIT SIZE-SERIES 024-30 030-30 036-30 042-30 048-30 060-30
OPERATING WEIGHT (Lb)
144 189 206 213 258 287
COMPRESSOR
Manufacturer
Copeland
Type Scroll
REFRIGERANT Puron
Control TXV (Cooling)
Charge (Lb) @ 15 Ft† 5.25 5.375 8.375 8.63 13.25 13.25
CONDENSER FAN Propeller Type, Direct Drive
Air Discharge Vertical
Air Quantity (CFM) 1900 2400 2800 2800 3300 3300
Motor HP 1/8 1/5 1/5 1/5 1/4 1/4
Motor RPM 1100 825 825 825 1100 1100
CONDENSER COIL Copper Tube, Aluminum Plate Fin
Face Area (Sq Ft) 10.83 12.12 18.18 12.12 18.18 18.18
Fins per In. 25 25 25 20 20 20
Rows 111222
Circuits 224345
VALVE CONNECTION (In. ID) Sweat
Vapor 5/8 3/4 3/4 7/8 7/8 7/8
Liquid 3/8
UNIT
SIZE
LIQUID TUBE DIAMETER (IN.) VAPOR TUBE DIAMETER (IN.)
0 to 50 Ft
Tube Length Alternate 0 to 50 Ft Tube Length Alternate RST* (Not Permitted)
024 3/8 3/8 5/8 3/4 ACR 3/4
030 3/8 3/8 3/4 7/8 1-1/8
036 3/8 3/8 3/4 7/8 1-1/8
042, 048 3/8 3/8 7/8 7/8 3/4 and 1-1/8
060 3/8 3/8 1-1/8 7/8 3/4
* RST — Refrigeration Service Tubing, standard refrigerant grade tubing.
NOTES:
1. Tube diameters are for lengths up to 50 ft. For tubing lengths greater than 50 ft, consult the Application Guideline and Service Manual for Residential Split-
System Air Conditioners and Heat Pumps using Puron Refrigerant.
2. Refrigerant tubes and indoor coils must be evacuated to 500 microns to minimize contamination and moisture in the system.
UNIT
SIZE SERIES OUTDOOR PISTON INDOOR TXV* REQUIRED SUBCOOLING (°F)
024 30 46 KSATX0201HSZ 11
030 30 49 KSATX0201HSZ 11
036 30 57 KSATX0301HSZ 14
042 30 59 KSATX0301HSZ 11
048 30 61 KSATX0401HSZ 10
060 30 73 KSATX0501HSZ 12
* TXV must be installed when indoor coil is not equipped with a Puron approved TXV. TXV listed is for any approved coil
combination. All TXVs are Puron specific bi-flow, hard shutoff.
M
A
N
U
F
A
C
T
U
R
E
R
C
E
R
T
I
F
I
E
D
T
O
A
R
I
A
S
C
O
M
P
L
Y
I
N
G
W
I
T
H
A
R
I
S
T
A
N
D
A
R
D
2
4
0
U
N
I
T
A
R
Y
H
E
A
T
P
U
M
P
E
Q
U
I
P
M
E
N
T
®
CERTIFICATION APPLIES ONLY WHEN THE
COMPLETE SYSTEM IS LISTED WITH ARI.
REGISTERED
QUALITY SYSTEM
As an ENERGY STAR® Partner, Carrier Corporation has deter-
mined that this product meets the ENERGY STAR® guidelines
for energy efficiency.
Meets GREEN SEAL Environmental Criteria for high energy efficiency,
low noise, and recycled packaging. Does not use an ozone depleting
substance during manufacturing, or as a refrigerant. (See Combination
Ratings for exceptions to Green Seal certification.)

4
Accessories
† For indicator light function, thermostat specified must be used and wired according to service alarm Installation Instructions.
‡ Must be applied on coils not equipped with Puron TXV.
* Do not use in zoning heat pump applications.
† This plate is designed to cover surrounding wall area located behind thermostat.
‡ Thermostat conversion kit is a 24-vac accessory that can turn a 4-wire thermostat application into a 5-wire application. This kit can also be used to replace
a broken thermostat wire, or add an extra wire when needed.
** Outdoor temperature sensor is an accessory for all Carrier electronic thermostats, except the non-programmable air conditioner version and builder’s
thermostats. It allows the temperature at a remote location (outdoors) to be displayed on the thermostat.
The outdoor air temperature sensor
must be used with the dual fuel thermostat.
The outdoor air temperature sensor is included with the Thermidistat Control and dual fuel thermostat.
ORDERING
NUMBER DESCRIPTION
KAATD0101TDR
Time-Delay Relay — All Sizes
KSALA0301410 Low-Ambient Pressure Switch — All Sizes
KAAFT0101AAA Evaporator Freeze Thermostat — All Sizes
KHAIR0101AAA Isolation Relay — All Sizes
KSAHS1501AAA Start Capacitor and Relay — Sizes 024–042
KSAHS1601AAA Start Capacitor and Relay — Sizes 048, 060
Standard Start Assist — PTC — Sizes 024–048
KAACS0201PTC Start Assist — PTC — Size 060
KAACH1201AAA Crankcase Heater — Sizes 024–042
Standard Crankcase Heater — Sizes 048, 060
KHAOT0301FST Outdoor Thermostat — All Sizes
KHAOT0201SEC Secondary Outdoor Thermostat — All Sizes
KHASA0101AAA† Service Alarm — All Sizes
KHAIC0101AAA Interface Control (Optimizer II®) — All Sizes
KSATX0201HSZ‡ Bi-Flow TXV (Hard Shutoff) — Size 024, 030
KSATX0301HSZ‡ Bi-Flow TXV (Hard Shutoff) — Sizes 036, 042
KSATX0401HSZ‡ Bi-Flow TXV (Hard Shutoff) — Size 048
KSATX0501HSZ‡ Bi-Flow TXV (Hard Shutoff) — Size 060
KH45LG140 (RCD) Filter Drier— Suction Line — Sizes 024–036
KH45LG141 (RCD) Filter Drier— Suction Line — Sizes 042–060
KHALS0401LLS Liquid-Line Solenoid Valve — All Sizes
KSASF0101AAA Support Feet — 4 in. — All Sizes
KHASS0206MPK Snow Stand — All Sizes
KAACF0801MED Coastal Filter — All Sizes
THERMOSTAT/SUBBASE PKG DESCRIPTION
TSTATCCNHP01-B
Thermostat — Auto Changeover, Non-Programmable, °F/°C, 2-Stage Heat, 1-Stage Cool
TSTATCCPHP01-B Thermostat — Auto Changeover, 7-Day Programmable, °F/°C, 2-Stage Heat, 1-Stage Cool
TSTATCCBHP01*
Builder’s Thermostat — Heat Pump, Non-Programmable, °F/°C, 2-Stage Heat, 1-Stage Cool,
Manual Changeover
TSTATXXSEN01-B** Outdoor Air Temperature Sensor
TSTATCCPDF01-B*
Dual Fuel Thermostat — Auto Changeover, 7-Day Programmable, °F/°C, Includes Outdoor Sensor
(TSTATXXSEN01-B)
TSTATCCPRH01-B*
Thermidistat™ Control — Non-Programmable/Programmable Thermostat with Humidity Control
(For use in Dual Fuel, AC, HP, and 2S applications. Includes Outdoor Air Temperature Sensor.)
TSTATXXNBP01† Backplate for Non-Programmable Thermostat
TSTATXXPBP01† Backplate for Programmable Thermostat and Thermidistat™ Control
TSTATXXBBP01† Backplate for Builder’s Thermostat
TSTATXXCNV10‡ Thermostat Conversion Kit (4 to 5 Wire) — 10 Pack

5
Accessory usage guideline
* For tubing line sets between 50 and 175 ft and/or 20 ft elevation difference between indoor and outdoor units, refer to the Application Guideline and Service Man-
ual for Residential Split-System Air Conditioners and Heat Pumps using Puron Refrigerant.
† Required for all applications.
Accessory description and usage (Listed alphabetically)
1. Coastal Filter
A mesh screen inserted under the top cover and inside the base pan to protect the condenser coil from salt damage without restricting airflow.
SUGGESTED USE: In geographic areas where salt damage could occur.
2. Compressor Start Assist — Capacitor and Relay
Start capacitor and start relay gives “hard” boost to compressor motor at each start-up.
SUGGESTED USE: Installations where interconnecting tube length exceeds 50 ft.
Installations where outdoor design temperature exceeds 105°F (40.6°C).
Units installed with Low-Ambient Pressure Switch.
3. Compressor Start Assist — PTC Type
Solid state electrical device which gives a “soft” boost to the reciprocating compressor at each start-up.
SUGGESTED USE: Installations with marginal power supply.
4. Crankcase Heater
An electric resistance heater which mounts to the base of the compressor to keep the lubricant warm during off cycles. Improves compressor lubrication on restart and minimizes chance
of refrigerant slugging. May or may not include a thermostat control.
SUGGESTED USE: When interconnecting tube length exceeds 50 ft.
When unit will be operated below 55°F (12.8°C) outdoor air temperature. (Use with Low-Ambient Pressure Switch.)
All commercial installations.
5. Evaporator Freeze Thermostat
An SPST temperature actuated switch which stops unit operation when evaporator reaches freeze-up conditions.
SUGGESTED USE: All units to which Low-Ambient Pressure Switch has been added.
6. Filter Drier— Suction Line
A device for removing contaminants from refrigerant circulating in a heat pump system; 2-direction flow for heat pumps.
SUGGESTED USE: Split-system heat pumps.
7. Interface Control (Optimizer II®)
An electric control for controlling a heat pump and gas or oil furnace system for maximum energy savings. It allows heat pump to operate down to a predetermined economic balance
point temperature, then switches to allow furnace operation only below that temperature. KHAIC0101AAA requires outdoor thermostat (Item 11) to be adjusted for economic balance
point temperature.
SUGGESTED USE: For heat pump and gas- or oil-fired furnace combination systems unless Duel Fuel Thermostat or Thermidistat™ Control is used.
8. Isolation Relay
An SPDT relay which switches the Low-Ambient Controller out of the outdoor fan motor circuit when the heat pump switches to heating mode.
SUGGESTED USE: All heat pumps where Low-Ambient Pressure Switch has been added.
9. Liquid-Line Solenoid Valve (LSV)
An electrically operated shutoff valve to be installed at the outdoor unit and which stops and starts refrigerant liquid flow in response to compressor operation. Maintains a column of
refrigerant liquid ready for action at next compressor operation cycle.
SUGGESTED USE: In long-line applications. (Refer to the Residential Split-System Long-Line Application Guideline and Service Manual.)
10. Low-Ambient Pressure Switch
A long life pressure switch which is mounted to outdoor unit service valve. It is designed to cycle the outdoor fan motor in order to maintain head pressure within normal operating
limits (approximately 200 psig to 365 psig). The control will maintain working head pressure at low-ambient temperatures down to 0°F (–17.8°C) when properly installed.
SUGGESTED USE: Cooling operation at outdoor temperatures below 55°F (12.8°C).
11. Outdoor Air Temperature Sensor
A device that allows the temperature at a remote location (outdoors) to be displayed at the thermostat.
SUGGESTED USE: All Carrier programmable thermostats.
12. Outdoor Thermostat
An SPDT temperature actuated switch which turns on supplemental electric heaters when outdoor air temperature drops below set point.
SUGGESTED USE: Heat pump installations with multiple-stage supplemental heaters.
13. Secondary Outdoor Thermostat
An SPDT temperature actuated switch which turns on third stage of supplemental electric heaters when outdoor air temperature drops below the second-stage set point.
SUGGESTED USE: Heat pump installations where 3-stage operation of supplemental heaters is desired.
14. Service Alarm
A current-sensing lockout relay which provides immediate notification that compressor is not operating during a call for heating or cooling. Used with proper room thermostat, a
thermostat signal is turned on signifying service is required. This can minimize electrical cost increase due to operation of supplemental heaters only.
SUGGESTED USE: As a feature to notify owner immediately when the system is not operating most efficiently.
15. Snow Stand
Coated wire rack which supports unit 18 in. above mounting pad to allow for drainage from unit base.
SUGGESTED USE: Heat pump installations in heavy snowfall areas.
Heat pump installations in snowdrift locations.
Heat pump installations in areas of prolonged subfreezing temperatures.
All commercial installations.
16. Support Feet
Four stick-on plastic feet which raise the unit 4 in. above the mounting pad. This allows sand, dirt, and other debris to be flushed from the unit base; minimizes corrosion.
SUGGESTED USE: Coastal installations.
Windy areas or where debris is normally circulating.
Rooftop installations.
ACCESSORY
REQUIRED FOR LOW-AMBIENT
APPLICATIONS
(BELOW 55°F)
REQUIRED FOR LONG-LINE
APPLICATIONS*
(OVER 50 FT)
Crankcase Heater
Yes Yes
Evaporator FreezeThermostat Yes No
Compressor Start Assist — Capacitor and Relay Yes Yes
Puron Low Ambient Pressure Switch Yes No
Wind Baffle
See Low-Ambient
Pressure Switch Instructions No
Support Feet Recommended No
Puron Hard ShutoffTXV Yes† Yes†
Puron Liquid-Line SolenoidValve for Heating No See Long-Line
Application Guideline

6
Accessory description and usage (Listed alphabetically) continued
17. Thermostatic Expansion Valve (TXV) — Bi-Flow
A modulating flow control valve which meters refrigerant liquid flow rate into the evaporator in response to the superheat of the refrigerant gas leaving the evaporator. Kit includes
valve, adapter tubes, external equalizer tube.
SUGGESTED USE: Required for all installations.
18. Time-Delay Relay
An SPST delay relay which briefly continues operation of the indoor blower motor to provide additional cooling after the compressor cycles off.
SUGGESTED USE: For improved efficiency ratings for certain combinations of indoor and outdoor units. (Refer to ARI Unitary Directory.)
Required for use on all zoning systems.
Electrical data
* Permissible limits of the voltage range at which unit will operate satisfactorily. Operation outside these limits may result in unit failure.
† Time-delay fuse or Circuit Breaker.
‡ Length shown is as measured 1 way along the wire path between the unit and the service panel for voltage drop not to exceed 2%.
** If wire is applied at ambient greater than 30°C (86°F), consult Table 310-16 of the NEC (ANSI/NFPA 70). The ampacity of nonmetallic-sheathed cable (NM),
trade name ROMEX, shall be that of 60°C (140°F) conductors, per the NEC (ANSI/NFPA 70) Article 336-26.
If other than uncoated (non-plated), 60° or 75°C (140° or 167°F) insulation, copper wire (solid wire for 10 AWG and smaller, stranded wire for larger than
10 AWG) is used, consult applicable tables of the NEC (ANSI/NFPA 70).
NOTE: Control circuit is 24v on all units and requires external power source. Copper wire must be used from service disconnect to unit. All motors/compressors
contain internal overload protection.
Sound power
UNIT SIZE-
SERIES V-PH OPER VOLTS* COMPR FAN
FLA MCA
MIN
WIRE
SIZE
60°C/75°C**
MAX
LENGTH
(Ft)
60°C/75°C‡
MAX FUSE†
OR
CKT BKR
AMPSMax Min LRA RLA
024-30
208-230-1 253 197
61.0 13.5 0.8 17.7 14/14 44/42 25
030-30 72.5 14.7 1.1 19.5 14/14 39/37 30
036-30 83.0 19.3 1.1 25.2 12/12 50/48 35
042-30 104.0 21.1 1.1 27.5 10/10 71/68 40
048-30 109.0 20.5 1.4 27.0 10/10 74/70 40
060-30 158.0 27.6 1.4 35.9 8/8 86/82 60
FLA — Full Load Amps
LRA — Locked Rotor Amps
MCA — Minimum Circuit Amps
RLA — Rated Load Amps
UNIT
SIZE–
SERIES
SOUND
LEVEL
(dBA) A –WEIGHTED SOUND POWER LEVELS (dBA) WITHIN OCTAVE BAND SHOWN 125 250 500 1000 2000 4000 8000
024-30 73 47.0 59.5 62.5 61.0 57.5 53.0 45.0
030-30 73 50.0 53.5 61.0 63.5 56.5 50.0 41.0
036-30 74 50.0 56.0 61.0 67.0 60.0 54.0 46.5
042-30 73 54.5 61.5 64.0 61.5 59.5 55.5 47.0
048-30 76 50.0 61.5 66.5 65.5 63.5 60.5 51.5
060-30 76 51.0 62.0 65.0 66.5 62.5 60.5 54.5

7
Dimensions
A99087
21/2
"
19/16
"
AIR DISCHARGE
43/16
"
3/8IN. DIA.
LIQUID LINE CONN
13/4
"
215/16
"
FIELD POWER SUPPLY CONN 7/8IN. DIA HOLE WITH
11/8IN. DIA KNOCKOUT
AND 13/8IN. DIA KNOCKOUT
10 1/2
"
FGA
FIELD CONTROL SUPPLY CONN 7/8IN. DIA HOLE
AIR DISCHARGE
AIR DISCHARGE
AIR IN
AIR IN
AIR IN
HDIA VAPOR LINE CONN
3/8IN. DIA TIEDOWN
KNOCKOUTS (2) PLACES IN BASEPAN B
11/4
"
M
ACCESS
PANEL
L
K
C
D
E
J
C
L
1.Allow 30 in. clearance to service side of unit, 48 in. above unit, 6 in.
on one side, 12 in.on remaining side, and 24 in. between units for proper airflow. Minimum outdoor operating ambient in cooling mode is 55°F (unless low ambient control is used) max 125°F.2.Maximum outdoor operating ambient in heating mode is 66°F.3.Series designation is the 13th position of the unit model number.4.Center of gravity .5.
NOTES:
DIMENSIONS (IN.)
UNIT
SIZE SERIES UNIT DIMENSIONS MINIMUM MOUNTING
PAD DIMENSIONS
ABCDEFGHJKLMSupport Feet Snow Stand
024 0 33-13/16 22-1/2 27-1/2 2-13/16 6-15/16 21-1/2 27-7/8 5/8 8-3/16 12 13-3/4 12 20 x 27 24 x 28 030 0 27-13/16 30 34-15/16 4 9-3/4 15-1/2 21-7/8 3/4 8-3/16 14 13-1/8 13-3/4 26 x 32 31 x 35 036 0 39-13/16 30 34-15/16 4 9-3/4 15-1/2 33-7/8 3/4 8-3/16 16-1/8 14-3/8 14-1/4 26 x 32 31 x 35 042 0 27-13/16 30 34-15/16 4 9-3/4 15-1/2 21-7/8 7/8 8-3/16 16-1/4 14 13-1/8 26 x 32 31 x 35 048 0 39-13/16 30 34-15/16 4 9-3/4 27-1/2 33-7/8 7/8 8-3/16 16-1/4 14-1/4 14-1/2 26 x 32 31 x 35 060 0 39-13/16 30 34-15/16 4 9-3/4 27-1/2 33-7/8 7/8 8-3/16 16 13-3/4 13-3/4 26 x 32 31 x 35

8
A99086E
38YZA BALANCE POINT WORKSHEET
BUILDING HEAT LOSS, 1000 BTU/HR
UNIT INTEGRATED HEATING CAPACITY, 1000 BTU/HR
Printed in U.S.A.
OUTDOOR TEMPERATURE, ˚F
-10 0 10 20 30 40 50 60 70 80
70 60 50 40 30 20 10
KW
BASED ON INDOOR ENT. AIR AT
70˚F AND AT RATED CFM
80
38YZA030 FX4A030
38YZA036 FX4A036
38YZA048 FX4A048
38YZA024 FX4A030
38YZA060 FX4A060
38YZA042 FX4A042
23.4
20.5 17.6
14.7 11.7
8.8
5.9 2.9
NOTE: The performance shown includes the PressureGuard™ cycling the outdoor fan. The ambient temperature that the outdoor fan cycles depends on the outdoor/indoor combination, indoor airflow, installation practices, and system maintenance, all of which affect system performance.

9
Combination ratings*
UNIT SIZE-
SERIES INDOOR UNIT CFM††
ARI STANDARD RATINGS*
Cooling Heating
TC
Seasonal Efficiency SEER
EER
High-Temp Low-Temp
HSPF
Factory-
Supplied
Enhance-
ment Standard Rating
Field-Supplied
Accessory‡
Puron
TXV Puron TXV & TDR** TC COP TC COP
024-30
FX4ANF030† 825 24,400 TXV+TDR 12.00 — — 10.30 24,600 3.28 15,500 2.24 7.40‡‡
40FKA/FK4CNF002 700 24,400 TDR — 13.00 — 11.10 23,800 3.42 14,900 2.32 7.50‡‡
40FKA/FK4CNF003 700 24,400 TDR — 13.50 — 11.35 23,800 3.42 14,800 2.34 7.50‡‡
CC5A/CD5AA036 825 24,400 NONE — — 12.00 10.20 23,000 3.12 15,600 2.22 7.20‡‡
CD5AW036 825 24,400 NONE — — 12.00 10.20 23,000 3.12 15,500 2.22 7.20‡‡
CE3AA036 750 24,200 NONE — — 12.00 10.15 24,000 3.10 15,400 2.16 7.00‡‡
CF5AA036 825 24,200 NONE — — 11.70 10.20 23,200 3.14 15,500 2.20 7.20‡‡
CG5AA036 825 24,200 NONE — — 11.70 10.20 23,200 3.14 15,500 2.20 7.20‡‡
CJ5A/CK5A/CK5BA036 825 24,400 NONE — — 12.00 10.25 24,000 3.26 15,600 2.24 7.40‡‡
CJ5A/CK5A/CK5BT036 825 24,400 NONE — — 12.00 10.25 24,000 3.26 15,600 2.24 7.40‡‡
CJ5A/CK5A/CK5BW036 825 24,400 NONE — — 12.00 10.25 24,000 3.26 15,600 2.24 7.40‡‡
CK3BA036 825 24,400 NONE — — 12.00 10.25 24,000 3.26 15,600 2.24 7.40‡‡
F(A,B)4AN(F,C)030 825 24,000 TDR — 11.70 — 10.15 24,400 3.16 15,400 2.20 7.20‡‡
FC4BNF030 825 24,000 TDR — 11.70 — 10.15 24,400 3.16 15,400 2.20 7.20‡‡
FG3AAA036 825 24,000 NONE — — 11.50 10.10 24,200 3.16 15,500 2.18 7.20‡‡
FK4CNF001 700 24,400 TDR — 13.00 — 11.10 23,800 3.26 14,900 2.28 7.40‡‡
FV4ANF002 700 24,400 TXV+TDR 13.00 — — 11.10 24,000 3.40 14,900 2.32 7.60
FV4ANF003 700 24,400 TXV+TDR 13.50 — — 11.35 24,000 3.42 14,800 2.34 7.60
COILS + 58MVP060-14 VARIABLE SPEED FURNACE
CC5A/CD5AA036 800 24,800 TDR — 13.00 — 11.10 24,000 3.40 15,000 2.32 7.60
CJ5A/CK5A/CK5BA036 800 24,800 TDR — 13.00 — 11.10 24,000 3.40 15,000 2.32 7.60
CJ5A/CK5A/CK5BW036 800 24,800 TDR — 13.00 — 11.10 24,000 3.40 15,000 2.32 7.60
CK3BA036 800 24,800 TDR — 13.00 — 11.10 24,000 3.40 15,000 2.32 7.50‡‡
COILS + 58MVP080-14 VARIABLE SPEED FURNACE
CD5AW036 800 25,000 TDR — 13.00 — 11.30 24,000 3.44 14,900 2.36 7.60
CJ5A/CK5A/CK5BW036 800 25,000 TDR — 13.00 — 11.30 24,000 3.44 14,900 2.36 7.60
COILS + 58MVP080-20 VARIABLE SPEED FURNACE
CD5AW036 937 25,000 TDR — 12.70 — 10.80 24,200 3.44 15,400 2.32 7.60
CJ5A/CK5A/CK5BW036 937 25,000 TDR — 12.70 — 10.80 24,600 3.44 15,400 2.32 7.60
COILS + 58MVP100-20 VARIABLE SPEED FURNACE
CD5AW036 937 25,000 TDR — 13.00 — 11.20 24,600 3.52 15,200 2.38 7.70
CJ5A/CK5A/CK5BW036 937 25,000 TDR — 13.00 — 11.20 24,600 3.52 15,200 2.38 7.60
COILS + 58U(H,X)V060-12 VARIABLE SPEED FURNACE
CC5A/CD5AA036 700 24,400 TDR — 13.00 — 11.15 23,200 3.32 14,800 2.30 7.50‡‡
CD5AW036 700 24,400 TDR — 13.00 — 11.15 23,200 3.32 14,800 2.30 7.50‡‡
CJ5A/CK5A/CK5BA036 700 24,400 TDR — 13.00 — 11.15 23,200 3.32 14,800 2.30 7.50‡‡
CJ5A/CK5A/CK5BW036 700 24,400 TDR — 13.00 — 11.15 23,200 3.32 14,800 2.30 7.50‡‡
CK3BA036 700 24,400 TDR — 13.00 — 11.15 23,400 3.32 14,800 2.30 7.50‡‡
COILS + 58U(H,X)V080-16 VARIABLE SPEED FURNACE
CD5AW036 875 25,000 TDR — 13.00 — 11.30 24,200 3.48 15,000 2.38 7.60
CJ5A/CK5A/CK5BW036 875 25,000 TDR — 13.00 — 11.30 24,200 3.48 15,000 2.38 7.60
030-30
FX4ANF030† 1050 28,400 TXV+TDR 12.30 — — 10.75 29,000 3.40 18,500 2.40 7.80
40FKA/FK4CNF002 875 28,400 TDR — 13.50 — 12.15 28,000 3.64 17,600 2.56 8.20
40FKA/FK4CNF003 875 28,400 TDR — 13.80 — 12.00 28,000 3.54 17,600 2.52 8.00
CC5A/CD5AA036 1050 28,400 NONE — — 12.20 10.70 29,000 3.34 18,500 2.38 7.70
CD5AW036 1050 28,400 NONE — — 12.20 10.70 29,000 3.34 18,500 2.38 7.70
CE3AA036 1050 28,000 NONE — — 12.20 10.60 28,800 3.28 18,500 2.34 7.60
CF5AA036 1050 28,400 NONE — — 12.20 10.65 29,000 3.32 18,500 2.36 7.60
CG5AA036 1050 28,400 NONE — — 12.20 10.65 29,000 3.32 18,500 2.36 7.60
CJ5A/CK5A/CK5BA036 1050 28,400 NONE — — 12.20 10.75 29,000 3.40 18,600 2.40 7.80
CJ5A/CK5A/CK5BT036 1050 28,400 NONE — — 12.20 10.75 29,000 3.40 18,600 2.40 7.80
CJ5A/CK5A/CK5BW036 1050 28,400 NONE — — 12.20 10.75 29,000 3.40 18,600 2.40 7.80
CK3BA036 1050 28,400 NONE — — 12.20 10.75 29,000 3.40 18,600 2.40 7.80
F(A,B)4AN(F,C)036 1050 28,000 TDR — 11.80 — 10.35 29,200 3.28 18,700 2.32 7.60
FC4BNF036 1050 28,000 TDR — 11.80 — 10.35 29,200 3.28 18,700 2.32 7.60
FG3AAA036 1050 28,000 NONE — — 12.00 10.55 28,800 3.26 18,500 2.34 7.60
FV4ANF002 875 28,400 TXV+TDR 13.50 — — 12.15 28,000 3.64 17,600 2.56 8.20
FV4ANF003 875 28,400 TXV+TDR 13.80 — — 12.00 28,000 3.56 17,700 2.52 8.10
FX4ANF036 1050 28,400 TXV+TDR 12.00 — — 10.50 28,000 3.38 18,700 2.38 7.80
COILS + 58MVP060-14 VARIABLE SPEED FURNACE
CC5A/CD5AA036 1000 27,400 TDR — 12.80 — 11.25 28,600 3.52 18,100 2.48 8.00
CJ5A/CK5A/CK5BA036 1000 27,400 TDR — 13.00 — 11.25 28,600 3.52 18,100 2.48 8.00
COILS + 58MVP080-14 VARIABLE SPEED FURNACE
CC5A/CD5AA036 1000 27,400 TDR — 12.80 — 11.40 28,600 3.54 18,000 2.50 8.00
CJ5A/CK5A/CK5BA036 1000 27,200 TDR — 13.00 — 11.40 28,600 3.54 18,000 2.50 8.00
See notes on pg. 13.

10
UNIT SIZE-
SERIES INDOOR UNIT CFM††
ARI STANDARD RATINGS*
Cooling Heating
TC
Seasonal Efficiency SEER
EER
High-Temp Low-Temp
HSPF
Factory-
Supplied
Enhance-
ment Standard Rating
Field-Supplied
Accessory‡
Puron
TXV Puron TXV & TDR** TC COP TC COP
030-30
COILS + 58MVP080-20 VARIABLE SPEED FURNACE
CD5AW036 1000 27,400 TDR — 12.50 — 11.25 28,600 3.52 18,100 2.48 8.00
CJ5A/CK5A/CK5BW036 1000 27,400 TDR — 12.80 — 11.25 28,600 3.52 18,100 2.48 8.00
COILS + 58MVP100-20 VARIABLE SPEED FURNACE
CD5AW036 1000 27,600 TDR — 13.00 — 11.65 28,400 3.60 17,900 2.54 8.10
CJ5A/CK5A/CK5BW036 1000 27,600 TDR — 13.00 — 11.65 28,400 3.60 17,900 2.54 8.10
COILS + 58U(H,X)V060-12 VARIABLE SPEED FURNACE
CC5A/CD5AA036 1000 27,000 TDR — 13.00 — 11.50 28,200 3.48 17,800 2.48 8.00
CJ5A/CK5A/CK5BA036 1012 27,000 TDR — 13.00 — 11.50 28,200 3.48 17,800 2.48 8.00
COILS + 58U(H,X)V080-16 VARIABLE SPEED FURNACE
CC5A/CD5AA036 1000 27,400 TDR — 13.00 — 11.40 28,600 3.54 18,000 2.50 8.00
CJ5A/CK5A/CK5BA036 1020 27,200 TDR — 13.50 — 11.70 28,000 3.52 17,700 2.50 8.00
COILS + 58U(H,X)V100-20 VARIABLE SPEED FURNACE
CD5AW036 1000 27,600 TDR — 13.50 — 11.75 28,400 3.64 17,900 2.56 8.20
CJ5A/CK5A/CK5BW036 1035 27,600 TDR — 13.50 — 11.75 28,400 3.64 17,900 2.56 8.20
036-30
FX4ANF036† 1275 34,000 TXV+TDR 12.50 — — 10.40 37,000 3.48 23,600 2.50 8.00
40FKA/FK4CNF003 1275 34,000 TDR — 13.50 — 11.75 35,200 3.54 22,200 2.62 8.20
40FKA/FK4CNF005 1275 35,000 TDR — 14.00 — 12.25 35,000 3.82 22,400 2.74 8.50
CC5A/CD5AA042 1275 34,000 NONE — — 12.00 10.40 36,600 3.40 23,400 2.48 7.80
CC5A/CD5AC048 1275 34,000 NONE — — 12.00 10.60 36,200 3.34 23,200 2.46 7.70
CC5A/CD5AW042 1275 34,000 NONE — — 12.00 10.60 36,400 3.40 23,200 2.50 7.80
CC5A/CD5AW048 1275 34,000 NONE — — 12.00 10.70 36,400 3.50 23,400 2.52 8.00
CD5AA048 1275 34,000 NONE — — 12.00 10.50 36,600 3.46 23,400 2.50 8.00
CE3AA042 1275 34,000 NONE — — 12.00 10.70 36,600 3.50 23,400 2.54 8.00
CE3AA048 1275 34,400 NONE — — 12.50 10.90 36,600 3.56 23,200 2.56 8.10
CF3AA036 1275 34,000 NONE — — 12.00 10.60 36,400 3.42 23,200 2.50 8.00
CF5AA048 1275 34,400 NONE — — 12.50 10.85 36,000 3.48 23,200 2.54 8.00
CG5AA048 1275 34,000 NONE — — 12.50 10.75 36,200 3.46 23,200 2.52 8.00
CJ5A/CK5A/CK5BA042 1275 34,000 NONE — — 12.00 10.65 36,600 3.50 23,400 2.54 8.00
CJ5A/CK5A/CK5BA048 1275 34,000 NONE — — 12.50 10.70 36,800 3.56 23,400 2.56 8.10
CJ5A/CK5A/CK5BT042 1275 34,000 NONE — — 12.00 10.65 36,600 3.50 23,400 2.54 8.00
CJ5A/CK5A/CK5BT048 1275 34,000 NONE — — 12.50 10.70 36,800 3.56 23,400 2.56 8.10
CJ5A/CK5A/CK5BW048 1275 34,000 NONE — — 12.50 10.70 36,800 3.56 23,400 2.56 8.10
CK3BA048 1275 34,000 NONE — — 12.50 10.70 36,800 3.56 23,400 2.56 8.10
F(A,B)4AN(F,B,C)042 1275 34,000 TDR — 12.00 — 10.50 36,800 3.46 23,400 2.50 8.00
FC4BN(F,B)042 1275 34,000 TDR — 12.00 — 10.50 36,800 3.46 23,400 2.50 8.00
FV4ANF003 1050 34,000 TXV+TDR 13.50 — — 11.75 35,200 3.54 22,200 2.62 8.20
FV4ANF005 1050 35,000 TXV+TDR 14.00 — — 12.25 35,000 3.82 22,400 2.74 8.50
FX4ANF042 1200 34,400 TXV+TDR 12.50 — — 10.75 36,800 3.58 23,400 2.56 8.20
COILS + 58MVP040-14 VARIABLE SPEED FURNACE
CC5A/CD5AA042 1000 34,000 TDR — 13.20 — 11.70 35,800 3.48 22,600 2.60 8.00
CD5AA048 1000 34,000 TDR — 13.30 — 11.75 36,000 3.54 22,600 2.62 8.10
CJ5A/CK5A/CK5BA042 1000 34,000 TDR — 13.20 — 11.70 23,200 3.48 22,600 2.60 8.00
CJ5A/CK5A/CK5BA048 1000 34,000 TDR — 13.30 — 11.75 36,000 3.54 22,600 2.62 8.10
CJ5A/CK5A/CK5BW048 1200 34,600 TDR — 13.00 — 11.50 36,800 3.62 23,200 2.64 8.20
COILS + 58MVP060-14 VARIABLE SPEED FURNACE
CC5A/CD5AA042 1200 34,400 TDR — 13.00 — 11.35 36,800 3.54 23,200 2.60 8.10
CD5AA048 1000 34,000 TDR — 13.20 — 11.75 36,000 3.52 22,600 2.62 8.10
CJ5A/CK5A/CK5BA042 1200 34,200 TDR — 13.00 — 11.35 36,800 3.54 23,200 2.60 8.10
CJ5A/CK5A/CK5BA048 1000 34,000 TDR — 13.20 — 11.75 36,000 3.52 22,600 2.62 8.10
COILS + 58MVP080-14 VARIABLE SPEED FURNACE
CC5A/CD5AA042 1225 34,200 TDR — 13.00 — 11.50 36,600 3.56 23,000 2.62 8.10
CJ5A/CK5A/CK5BA042 1225 34,200 TDR — 13.00 — 11.50 36,600 3.56 23,000 2.62 8.10
CJ5A/CK5A/CK5BA048 1000 34,000 TDR — 13.40 — 11.85 36,000 3.54 22,600 2.64 8.20
COILS + 58MVP080-20 VARIABLE SPEED FURNACE
CC5A/CD5AA042 1000 34,200 TDR — 13.00 — 11.35 36,800 3.54 23,200 2.60 8.10
CD5AA048 1000 34,200 TDR — 12.70 — 11.35 37,000 3.60 23,200 2.62 8.20
CJ5A/CK5A/CK5BA042 1200 34,200 TDR — 13.00 — 11.35 36,800 3.54 23,200 2.60 8.10
CJ5A/CK5A/CK5BA048 1000 34,000 TDR — 13.20 — 11.75 36,000 3.52 22,600 2.62 8.10
COILS + 58MVP100-20 VARIABLE SPEED FURNACE
CC5A/CD5AA042 1200 34,600 TDR — 13.30 — 11.75 36,400 3.62 23,000 2.66 8.30
CJ5A/CK5A/CK5BA042 1200 34,600 TDR — 13.30 — 11.75 36,400 3.62 23,000 2.66 8.30
Combination ratings* continued
See notes on pg. 13.

11
UNIT SIZE-
SERIES INDOOR UNIT CFM††
ARI STANDARD RATINGS*
Cooling Heating
TC
Seasonal Efficiency SEER
EER
High-Temp Low-Temp
HSPF
Factory-
Supplied
Enhance-
ment Standard Rating
Field-Supplied
Accessory‡
Puron
TXV Puron TXV & TDR** TC COP TC COP
036-30
COILS + 58MVP120-20 VARIABLE SPEED FURNACE
CC5A/CD5AA042 1000 34,200 TDR — 13.50 — 11.95 35,600 3.52 22,400 2.62 8.10
CD5AA048 1000 34,000 TDR — 13.50 — 12.00 35,800 3.58 22,400 2.64 8.20
CJ5A/CK5A/CK5BA042 1000 34,200 TDR — 13.50 — 11.95 35,600 3.52 22,400 2.62 8.10
CJ5A/CK5A/CK5BA048 1000 34,000 TDR — 13.50 — 12.00 35,800 3.58 22,400 2.64 8.20
CJ5A/CK5A/CK5BW048 1200 34,600 TDR — 13.40 — 11.85 36,600 3.70 23,000 2.68 8.30
COILS + 58U(H,X)V060-12 VARIABLE SPEED FURNACE
CC5A/CD5AA042 1050 34,000 TDR — 13.10 — 11.65 36,000 3.50 22,800 2.60 8.10
CD5AA048 1050 34,200 TDR — 13.20 — 11.75 36,200 3.58 22,800 2.64 8.20
CJ5A/CK5A/CK5BA042 1050 34,000 TDR — 13.10 — 11.65 36,000 3.50 22,800 2.60 8.10
CJ5A/CK5A/CK5BA048 1050 34,200 TDR — 13.20 — 11.75 36,200 3.58 22,800 2.64 8.20
COILS + 58U(H,X)V080-16 VARIABLE SPEED FURNACE
CC5A/CD5AA042 1225 34,000 TDR — 13.00 — 11.55 36,600 3.58 23,000 2.64 8.20
CD5AA048 1050 34,600 TDR — 13.20 — 11.75 36,800 3.68 23,000 2.66 8.30
CJ5A/CK5A/CK5BA042 1225 34,600 TDR — 13.00 — 11.55 36,600 3.58 23,000 2.64 8.20
CJ5A/CK5A/CK5BA048 1050 34,200 TDR — 13.50 — 11.95 36,000 3.62 22,600 2.66 8.30
COILS + 58U(H,X)V100-20 VARIABLE SPEED FURNACE
CC5A/CD5AA042 1225 35,000 TDR — 13.50 — 11.90 36,400 3.66 22,800 2.68 8.40
CD5AA048 1050 34,400 TDR — 14.00 — 12.25 35,800 3.66 22,400 2.68 8.40
CJ5A/CK5A/CK5BA042 1225 34,600 TDR — 13.50 — 11.90 36,400 3.66 22,800 2.68 8.40
CJ5A/CK5A/CK5BA048 1050 34,400 TDR — 14.00 — 12.25 35,800 3.66 22,400 2.68 8.40
COILS + 58U(H,X)V120-20 VARIABLE SPEED FURNACE
CD5AA048 1050 34,400 TDR — 14.00 — 12.15 36,000 3.64 22,400 2.68 8.40
CJ5A/CK5A/CK5BA048 1050 34,400 TDR — 14.00 — 12.15 36,000 3.64 22,400 2.68 8.40
CJ5A/CK5A/CK5BW048 1275 35,000 TDR — 13.50 — 12.00 36,600 3.72 22,800 2.70 8.40
042-30
FX4ANF042† 1400 40,500 TXV+TDR 12.00 — — 10.25 41,500 3.40 26,600 2.42 7.60
40FKA/FK4CNF003 1225 40,500 TDR — 13.00 — 11.10 40,000 3.32 25,400 2.44 7.60
40FKA/FK4CNF005 1225 41,000 TDR — 13.50 — 11.55 40,000 3.56 25,200 2.56 8.00
CC5A/CD5AC048 1400 39,600 NONE — — 12.00 10.10 39,500 3.04 26,200 2.32 7.00‡‡
CC5A/CD5AW048 1500 40,000 NONE — — 12.00 10.25 40,500 3.28 26,400 2.38 7.60
CD3(A,B)A048 1500 40,000 NONE — — 12.00 10.25 40,500 3.28 26,400 2.38 7.60
CD5A/CD5BA048 1500 40,000 NONE — — 12.00 10.25 40,500 3.28 26,400 2.38 7.60
CE3AA048 1400 40,500 NONE — — 12.00 10.35 41,500 3.32 26,400 2.40 7.60
CJ5A/CK5A/CK5BA048 1400 40,000 NONE — — 12.00 10.30 41,500 3.34 26,400 2.40 7.60
CJ5A/CK5A/CK5BW048 1400 40,000 NONE — — 12.00 10.30 41,500 3.34 26,400 2.40 7.60
CK3BA048 1400 40,000 NONE — — 12.00 10.30 41,500 3.34 26,400 2.40 7.60
F(A,B)4AN(F,B,C)048 1400 40,000 TDR — 12.00 — 10.25 41,500 3.34 26,600 2.42 7.60
FC4BN(F,B)048 1400 40,500 TDR — 12.00 — 10.25 41,500 3.38 26,600 2.42 7.60
FV4ANF003 1225 40,500 TXV+TDR 13.00 — — 11.00 40,500 3.36 25,400 2.46 7.70
FV4ANF005 1100 41,000 TXV+TDR 13.50 — — 11.55 40,000 3.56 25,200 2.56 8.10
COILS + 58MVP040-14 VARIABLE SPEED FURNACE
CC5A/CD5AW048 1400 40,000 TDR — 12.50 — 10.80 40,500 3.32 25,600 2.44 7.60
CJ5A/CK5A/CK5BW048 1400 40,000 TDR — 12.50 — 10.80 40,500 3.32 25,600 2.44 7.60
COILS + 58MVP080-14 VARIABLE SPEED FURNACE
CD5AA048 1400 40,000 TDR — 12.70 — 10.90 40,500 3.34 25,600 2.44 7.60
CJ5A/CK5A/CK5BA048 1500 40,000 TDR — 12.70 — 10.90 40,500 3.34 25,600 2.44 7.60
CK3BA048 1500 40,000 TDR — 12.70 — 10.90 40,500 3.34 25,600 2.44 7.60
COILS + 58MVP080-20 VARIABLE SPEED FURNACE
CD5AA048 1400 40,000 TDR — 12.50 — 10.75 40,500 3.32 25,600 2.42 7.60
CJ5A/CK5A/CK5BA048 1500 40,000 TDR — 12.50 — 10.75 40,500 3.32 25,600 2.42 7.60
CK3BA048 1500 40,000 TDR — 12.50 — 10.75 40,500 3.32 25,600 2.42 7.60
COILS + 58MVP100-20 VARIABLE SPEED FURNACE
CD5AA048 1400 40,000 TDR — 13.00 — 11.10 40,500 3.36 25,400 2.46 7.60
CJ5A/CK5A/CK5BA048 1500 40,000 TDR — 13.00 — 11.10 40,500 3.36 25,400 2.46 7.60
CJ5A/CK5A/CK5BW048 1500 40,000 TDR — 12.50 — 10.80 40,500 3.32 25,600 2.44 7.60
CK3BA048 1500 40,000 TDR — 13.00 — 11.10 40,500 3.36 25,400 2.46 7.60
COILS + 58MVP120-20 VARIABLE SPEED FURNACE
CC5A/CD5AW048 1400 40,000 TDR — 13.00 — 11.05 40,500 3.36 25,400 2.46 7.60
CJ5A/CK5A/CK5BW048 1500 40,000 TDR — 13.00 — 11.05 40,500 3.36 25,400 2.46 7.60
COILS + 58U(H,X)V080-16 VARIABLE SPEED FURNACE
CD5AA048 1400 40,000 TDR — 12.70 — 10.90 40,500 3.34 25,600 2.44 7.60
CJ5A/CK5A/CK5BA048 1500 40,000 TDR — 12.70 — 10.90 40,500 3.34 25,600 2.44 7.60
CK3BA048 1500 40,000 TDR — 12.70 — 10.90 40,500 3.34 25,600 2.44 7.60
Combination ratings* continued
See notes on pg. 13.

12
UNIT SIZE-
SERIES INDOOR UNIT CFM††
ARI STANDARD RATINGS*
Cooling Heating
TC
Seasonal Efficiency SEER
EER
High-Temp Low-Temp
HSPF
Factory-
Supplied
Enhance-
ment Standard Rating
Field-Supplied
Accessory‡
Puron
TXV Puron TXV & TDR** TC COP TC COP
042-30
COILS + 58U(H,X)V100-20 VARIABLE SPEED FURNACE
CC5A/CD5AW048 1400 40,000 TDR — 13.10 — 11.15 40,500 3.40 25,400 2.48 7.60
CJ5A/CK5A/CK5BW048 1500 40,000 TDR — 13.10 — 11.15 40,500 3.40 25,400 2.48 7.60
COILS + 58U(H,X)V120-20 VARIABLE SPEED FURNACE
CC5A/CD5AW048 1400 40,000 TDR — 13.10 — 11.15 40,500 3.40 25,400 2.48 7.60
CJ5A/CK5A/CK5BW048 1500 40,000 TDR — 13.10 — 11.15 40,500 3.40 25,400 2.48 7.60
048-30
FX4ANF048† 1400 45,000 TXV+TDR 12.00 — — 10.75 48,000 3.42 28,400 2.34 8.00
40FKA/FK4CNB006 1400 46,500 TDR — 13.50 — 12.05 48,000 3.76 27,600 2.54 8.30
40FKA/FK4CNF005 1400 45,500 TDR — 13.00 — 11.60 47,500 3.58 27,800 2.46 8.20
CC5A/CD5AA060 1650 44,500 NONE — — 12.00 10.60 48,000 3.22 28,400 2.26 7.70
CC5A/CD5AW060 1668 44,500 NONE — — 12.00 10.80 48,000 3.40 28,400 2.34 8.00
CC5A/CD5AW060 1400 45,500 NONE — — 12.00 10.90 48,500 3.52 28,600 2.38 8.20
CD3(A,B)A060 1650 44,000 NONE — — 12.00 10.60 48,000 3.22 28,400 2.26 7.70
CE3AA060 1400 45,500 NONE — — 12.00 10.80 48,500 3.40 28,400 2.34 8.00
CJ5A/CK5A/CK5BA060 1400 45,000 NONE — — 12.00 10.75 48,000 3.50 28,600 2.38 8.00
CJ5A/CK5A/CK5BX060 1400 45,500 NONE — — 12.00 10.90 48,500 3.52 28,600 2.38 8.20
CK3BA060 1400 45,000 NONE — — 12.00 10.75 48,500 3.50 28,600 2.38 8.00
F(A,B)4AN(F,B,C)060 1400 44,000 TDR — 11.50 — 10.20 48,500 3.32 29,000 2.26 7.60
FB4ANB070 1400 46,000 TDR — 12.00 — 10.90 48,000 3.54 28,600 2.38 8.00
FC4BN(F,B)060 1400 44,500 TDR — 11.50 — 10.20 48,000 3.32 29,000 2.26 7.60
FC4BNB070 1400 46,000 TDR — 12.00 — 10.90 48,000 3.54 28,600 2.38 8.00
FV4ANB006 1400 46,500 TXV+TDR 13.50 — — 12.05 48,000 3.76 27,600 2.54 8.30
FV4ANF005 1400 45,500 TXV+TDR 13.00 — — 11.60 47,500 3.58 27,600 2.46 8.20
FX4ANB060 1400 45,500 TXV+TDR 12.20 — — 10.90 48,000 3.54 28,600 2.38 8.10
COILS + 58MVP080-20 VARIABLE SPEED FURNACE
CC5A/CD5AA060 1400 44,000 TDR — 12.50 — 10.90 48,000 3.44 28,200 2.36 8.00
CC5A/CD5AW060 1400 44,500 TDR — 12.50 — 11.10 48,000 3.48 28,200 2.38 8.00
CJ5A/CK5A/CK5BA060 1400 44,000 TDR — 12.50 — 10.90 47,500 3.44 28,200 2.36 8.00
CJ5A/CK5A/CK5BX060 1400 44,500 TDR — 12.50 — 11.10 48,000 3.48 28,200 2.38 8.00
CK3BA060 1400 44,000 TDR — 12.50 — 10.90 48,000 3.44 28,200 2.36 8.00
COILS + 58MVP100-20 VARIABLE SPEED FURNACE
CC5A/CD5AA060 1400 44,500 TDR — 13.00 — 11.25 47,500 3.50 27,800 2.40 8.00
CC5A/CD5AW060 1400 45,000 TDR — 13.00 — 11.45 48,000 3.54 27,800 2.44 8.20
CJ5A/CK5A/CK5BA060 1400 44,500 TDR — 13.00 — 11.25 47,500 3.50 27,800 2.40 8.00
CJ5A/CK5A/CK5BX060 1400 45,000 TDR — 13.00 — 11.45 48,000 3.54 27,800 2.44 8.20
CK3BA060 1400 44,500 TDR — 13.00 — 11.25 47,500 3.50 27,800 2.40 8.00
COILS + 58MVP120-20 VARIABLE SPEED FURNACE
CC5A/CD5AA060 1400 44,500 TDR — 13.00 — 11.30 47,500 3.52 27,800 2.40 8.00
CC5A/CD5AW060 1400 45,000 TDR — 13.00 — 11.70 48,000 3.54 27,800 2.42 8.20
CJ5A/CK5A/CK5BA060 1400 44,500 TDR — 13.00 — 11.30 47,500 3.52 27,800 2.40 8.00
CJ5A/CK5A/CK5BX060 1400 45,000 TDR — 13.00 — 11.70 48,000 3.54 27,800 2.42 8.20
CK3BA060 1400 44,500 TDR — 13.00 — 11.30 47,500 3.52 27,800 2.40 8.00
COILS + 58U(H,X)V100-20 VARIABLE SPEED FURNACE
CC5A/CD5AA060 1400 45,000 TDR — 13.00 — 11.70 47,500 3.58 27,400 2.46 8.20
CC5A/CD5AW060 1400 45,500 TDR — 13.00 — 11.90 47,500 3.62 27,400 2.50 8.20
CJ5A/CK5A/CK5BA060 1400 45,000 TDR — 13.00 — 11.70 47,500 3.58 27,400 2.46 8.20
CJ5A/CK5A/CK5BX060 1400 45,500 TDR — 13.00 — 11.90 47,500 3.62 27,400 2.50 8.20
CK3BA060 1400 45,000 TDR — 13.00 — 11.70 47,500 3.58 27,400 2.46 8.20
COILS + 58U(H,X)V120-20 VARIABLE SPEED FURNACE
CC5A/CD5AA060 1400 44,500 TDR — 13.00 — 11.55 47,500 3.56 27,600 2.44 8.20
CC5A/CD5AW060 1400 45,500 TDR — 13.00 — 11.75 47,500 3.60 27,600 2.48 8.20
CJ5A/CK5A/CK5BA060 1400 44,500 TDR — 13.00 — 11.55 47,500 3.56 27,600 2.44 8.20
CJ5A/CK5A/CK5BX060 1400 45,500 TDR — 13.00 — 11.75 47,500 3.60 27,600 2.48 8.20
CK3BA060 1400 44,500 TDR — 13.00 — 11.55 47,500 3.56 27,600 2.44 8.20
060-30
FX4ANB060† 1750 57,000 TXV&TDR 12.00 — — 10.20 60,000 3.44 37,800 2.46 7.80
40FKA/FK4CNB006 1750 58,000 TDR — 12.50 — 10.75 59,500 3.56 37,000 2.54 8.00
CC5A/CD5AW060 1750 56,000 NONE — — 12.00 10.45 58,000 3.26 36,800 2.42 7.60
CJ5A/CK5AX060 1750 56,500 NONE — — 12.00 10.55 59,000 3.44 37,000 2.50 7.80
FB4ANB070 1750 57,000 TDR — 12.00 — 10.20 60,000 3.44 37,800 2.46 7.80
FC4BNB070 1750 57,000 TDR — 12.00 — 10.20 60,000 3.44 37,800 2.46 7.80
FV4ANB006 1750 57,500 TXV&TDR 12.50 — — 10.75 60,000 3.56 37,000 2.54 8.00
COILS + 58U(H,X)V100-20 VARIABLE SPEED FURNACE
CC5A/CD5AW060 1750 56,000 TDR — 12.50 — 10.35 58,000 3.26 36,800 2.40 7.60
CJ5A/CK5A/CK5BX060 1750 56,500 TDR — 12.50 — 10.55 59,000 3.42 37,000 2.48 8.00
COILS + 58U(H,X)V120-20 VARIABLE SPEED FURNACE
CC5A/CD5AW060 1750 55,500 TDR — 12.20 — 10.15 58,000 3.22 37,200 2.38 7.60
CJ5A/CK5A/CK5BX060 1750 56,500 TDR — 12.50 — 10.45 59,000 3.40 37,200 2.48 8.00
Combination ratings* continued
See notes on pg. 13.

13
* Ratings are net values reflecting the effects of circulating fan heat. Supplemental electric heat is not included. Ratings are based on:
Cooling Standard: 80°F (27°C) db 67°F (19°C) wb indoor entering air temperature and 95°F (35°C) db air entering outdoor unit.
High-Temp Heating Standard: 70°F (21°C) db indoor entering air temperature and 47°F (8°C) db 43°F (6°C) wb air entering outdoor unit.
Low-Temp Heating Standard: 70°F (21°C) db indoor entering air temperature and 17°F (–9°C) db 15°F (–10°C) wb air entering outdoor unit.
† Outdoor section/indoor section combination tested in accordance with DOE test procedures for heat pumps. Ratings for other combinations are determined
under DOE computer simulation procedures.
‡ Based on computer simulation. TXV must be Puron compatible and hard shutoff type.
** In most cases, only 1 method should be used to achieve TDR function. Using more than 1 method in a system may cause degradation in performance. Use
either the accessory Time-Delay Relay KAATD0101TDR or a furnace equipped with TDR. All Carrier furnaces are equipped with TDR except for the 58GFA.
†† Indoor Airflow
‡‡ This combination does not achieve the minimum HSPF of 7.6 required for Green Seal certification.
SEER — Seasonal Energy Efficiency Ratio TC — Total Capacity (Btuh)
COP — Coefficient of Performance TDR — Time-Delay Relay
HSPF — Heating Seasonal Performance Factor TXV — Thermostatic Expansion Valve
EER — Energy Efficiency Ratio

14
Detailed cooling capacities*
Multipliers for Determining the Performance With Other Indoor Sections.
EVAPORATOR
AIR CONDENSER ENTERING AIR TEMPERATURES °F 75 85 95 105 115 125
CFM EWB
Capacity
MBtuh† Total Sys-
tem
Kw**
Capacity
MBtuh† Total Sys-
tem
Kw**
Capacity
MBtuh† Total Sys-
tem
Kw**
Capacity
MBtuh† Total Sys-
tem
Kw**
Capacity
MBtuh† Total Sys-
tem
Kw**
Capacity
MBtuh† Total Sys-
tem
Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38YZA024-30 Outdoor Section With FX4ANF030 Indoor Section
700
72 28.6 14.1 1.81 27.2 13.6 2.02 25.7 13.0 2.26 24.1 12.4 2.51 22.4 11.8 2.78 20.5 11.2 3.06
67 26.2 17.7 1.80 24.9 17.2 2.01 23.6 16.6 2.24 22.1 16.0 2.49 20.5 15.4 2.75 18.8 14.7 3.03
63†† 24.4 17.3 1.79 23.2 16.7 2.00 22.0 16.2 2.22 20.6 15.6 2.47 19.1 14.9 2.73 17.5 14.2 3.01
62 24.0 21.2 1.79 22.8 20.7 1.99 21.6 20.1 2.22 20.3 19.5 2.47 18.9 18.7 2.73 17.6 17.6 3.01
57 23.0 23.0 1.78 22.1 22.1 1.99 21.1 21.1 2.22 20.0 20.0 2.46 18.9 18.9 2.73 17.6 17.6 3.01
825
72 29.2 14.9 1.85 27.8 14.3 2.06 26.2 13.8 2.30 24.5 13.2 2.55 22.7 12.6 2.82 20.7 11.9 3.10
67 26.8 19.1 1.84 25.4 18.5 2.05 24.0 18.0 2.28 22.5 17.4 2.53 20.8 16.7 2.80 19.0 16.0 3.07
63†† 25.0 18.6 1.83 23.7 18.0 2.04 22.4 17.4 2.27 21.0 16.8 2.51 19.4 16.2 2.78 17.8 15.5 3.05
62 24.6 23.1 1.83 23.4 22.5 2.04 22.2 21.8 2.26 20.9 20.9 2.51 19.7 19.7 2.78 18.3 18.3 3.06
57 24.2 24.2 1.83 23.1 23.1 2.04 22.1 22.1 2.26 20.9 20.9 2.51 19.6 19.6 2.78 18.2 18.2 3.06
950
72 29.7 15.6 1.89 28.2 15.1 2.10 26.5 14.5 2.34 24.8 14.0 2.59 22.9 13.4 2.86 20.9 12.7 3.14
67 27.2 20.4 1.88 25.8 19.8 2.09 24.3 19.3 2.32 22.8 18.7 2.57 21.1 18.0 2.84 19.2 17.3 3.11
63†† 25.4 19.8 1.87 24.1 19.2 2.08 22.7 18.6 2.31 21.2 18.0 2.55 19.7 17.3 2.82 18.0 16.6 3.09
62 25.2 24.8 1.87 24.0 24.0 2.08 22.8 22.8 2.31 21.6 21.6 2.56 20.2 20.2 2.83 18.8 18.8 3.11
57 25.1 25.1 1.87 24.0 24.0 2.08 22.8 22.8 2.31 21.6 21.6 2.56 20.3 20.3 2.83 18.8 18.8 3.11
Indoor
Section Size Cooling Indoor
Section Size Cooling Capacity Power Capacity Power
FX4ANF 030 1.00 1.00 CJ5A/CK5A/CK5BW 036 1.02 0.95
40FKA/FK4CNF 002 1.00 0.92 CK3BA 036 1.02 0.95
003 1.00 0.91 COILS + 58MVP080-14 VARIABLE SPEED FURNACE
CC5A/CD5AA 036 1.00 1.01 CD5AW 036 1.02 0.93
CD5AW 036 1.00 1.01 CJ5A/CK5A/CK5BW 036 1.02 0.93
CE3AA 036 0.99 1.00 COILS + 58MVP080-20 VARIABLE SPEED FURNACE
CF5AA 036 0.99 1.01 CD5AW 036 1.02 0.99
CG5AA 036 0.99 1.01 CJ5A/CK5A/CK5BW 036 1.02 0.99
CJ5A/CK5A/CK5BA 036 1.00 1.01 COILS + 58MVP100-20 VARIABLE SPEED FURNACE
CJ5A/CK5A/CK5BT 036 1.00 1.01 CD5AW 036 1.02 0.96
CJ5A/CK5A/CK5BW 036 1.00 1.01 CJ5A/CK5A/CK5BW 036 1.02 0.96
CK3BA 036 1.00 1.01 COILS + 58U(H,X)V060-12 VARIABLE SPEED FURNACE
F(A,B)4AN(F,C) 030 0.98 1.00 CC5A/CD5AA 036 1.00 0.93
FC4BNF 030 0.98 1.00 CD5AW 036 1.00 0.93
FG3AAA 036 0.98 1.01 CJ5A/CK5A/CK5BA 036 1.00 0.93
FK4CNF 001 1.04 0.93 CJ5A/CK5A/CK5BW 036 1.00 0.93
FV4ANF 002 1.00 0.93 CK3BA 036 1.00 0.93
003 1.00 0.91 COILS + 58U(H,X)V080-16 VARIABLE SPEED FURNACE
COILS + 58MVP060-14 VARIABLE SPEED FURNACE CD5AW 036 1.02 0.94
CC5A/CD5AA 036 1.02 0.95 CJ5A/CK5A/CK5BW 036 1.02 0.94
CJ5A/CK5A/CK5BA 036 1.02 0.95 — — —
See notes on pg. 19.

15
Multipliers for Determining the Performance With Other Indoor Sections.
See notes on pg. 19.
EVAPORATOR
AIR CONDENSER ENTERING AIR TEMPERATURES °F 75 85 95 105 115 125
CFM EWB
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38YZA030-30 Outdoor Section With FX4ANF030 Indoor Section
900
72 33.3 17.1 2.02 31.7 16.5 2.24 29.9 15.9 2.49 28.0 15.2 2.76 25.5 14.4 3.04 23.1 13.6 3.35
67 31.2 22.4 2.02 29.4 21.7 2.23 27.8 21.1 2.48 26.1 20.4 2.75 24.0 19.6 3.04 21.7 18.7 3.35
63†† 29.3 21.9 2.01 27.7 21.2 2.23 26.2 20.6 2.47 24.6 19.9 2.75 22.9 19.1 3.05 20.9 18.3 3.39
62 29.0 27.5 2.01 27.4 26.7 2.22 26.1 25.9 2.47 24.7 24.7 2.75 23.0 23.0 3.04 21.0 21.0 3.35
57 28.5 28.5 2.00 27.1 27.1 2.22 25.9 25.9 2.47 24.4 24.4 2.74 22.8 22.8 3.04 21.0 21.0 3.35
1050
72 33.6 18.0 2.08 31.9 17.4 2.30 30.0 16.7 2.54 28.1 16.0 2.81 25.9 15.3 3.11 23.2 14.4 3.41
67 31.5 24.0 2.07 30.0 23.4 2.29 28.0 22.6 2.53 26.2 21.9 2.80 24.0 21.1 3.09 22.1 20.3 3.42
63†† 29.7 23.4 2.06 27.9 22.6 2.28 26.4 22.0 2.53 24.8 21.3 2.80 23.0 20.5 3.10 20.9 19.6 3.43
62 29.6 29.4 2.06 28.1 28.1 2.28 26.8 26.8 2.53 25.1 25.1 2.80 23.6 23.6 3.10 21.4 21.4 3.40
57 29.6 29.6 2.06 28.0 28.0 2.28 26.6 26.6 2.53 25.1 25.1 2.80 23.4 23.4 3.09 21.4 21.4 3.40
1200
72 33.8 18.8 2.13 32.0 18.1 2.35 30.1 17.5 2.60 28.1 16.8 2.86 25.8 16.0 3.16 23.3 15.2 3.47
67 31.8 25.5 2.13 30.1 24.9 2.34 28.4 24.2 2.59 26.3 23.4 2.85 24.3 22.5 3.15 22.0 21.4 3.46
63†† 29.9 24.8 2.12 28.1 24.0 2.33 26.5 23.3 2.58 24.9 22.6 2.85 23.0 21.7 3.15 21.0 20.7 3.48
62 30.3 30.3 2.12 28.8 28.8 2.34 27.4 27.4 2.59 25.7 25.7 2.85 23.9 23.9 3.15 22.0 22.0 3.47
57 30.3 30.3 2.12 28.7 28.7 2.34 27.2 27.2 2.58 25.6 25.6 2.85 23.8 23.8 3.15 21.7 21.7 3.46
Indoor
Section Size Cooling Indoor
Section Size Cooling Capacity Power Capacity Power
FX4ANF 030 1.00 1.00 CJ5A/CK5A/CK5BA 036 0.96 0.93
40FKA/FK4CNF 002 1.00 0.90 COILS + 58MVP080-14 VARIABLE SPEED FURNACE
003 1.00 0.91 CC5A/CD5AA 036 0.96 0.92
CC5A/CD5AA 036 1.00 1.01 CJ5A/CK5A/CK5BA 036 0.96 0.92
CD5AW 036 1.00 1.01 COILS + 58MVP080-20 VARIABLE SPEED FURNACE
CE3AA 036 0.99 1.01 CD5AW 036 0.96 0.93
CF5AA 036 1.00 1.01 CJ5A/CK5A/CK5BW 036 0.96 0.93
CG5AA 036 1.00 1.01 COILS + 58MVP100-20 VARIABLE SPEED FURNACE
CJ5A/CK5A/CK5BA 036 1.00 1.01 CD5AW 036 0.97 0.91
CJ5A/CK5A/CK5BT 036 1.00 1.01 CJ5A/CK5A/CK5BW 036 0.97 0.91
CJ5A/CK5A/CK5BW 036 1.00 1.01 COILS + 58U(H,X)V060-12 VARIABLE SPEED FURNACE
CK3BA 036 1.00 1.01 CC5A/CD5AA 036 0.95 0.90
F(A,B)4AN(F,C) 036 0.99 1.03 CJ5A/CK5A/CK5BA 036 0.95 0.90
FC4BNF 036 0.99 1.03 COILS + 58U(H,X)V080-16 VARIABLE SPEED FURNACE
FG3AAA 036 0.99 1.01 CC5A/CD5AA 036 0.96 0.92
FV4ANF 002 1.00 0.90 COILS + 58U(H,X)V100-20 VARIABLE SPEED FURNACE
003 1.00 0.91 CD5AW 036 0.97 0.90
FX4ANF 036 1.00 1.03 CJ5A/CK5A/CK5BW 036 0.97 0.90
COILS + 58MVP060-14 VARIABLE SPEED FURNACE CJ5A/CK5A/CK5BA 036 0.96 0.89
CC5A/CD5AA 036 0.96 0.93 —— —
Detailed cooling capacities* continued

16
Detailed cooling capacities* continued
Multipliers for Determining the Performance With Other Indoor Sections.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38YZA036-30 Outdoor Section With FX4NF036 Indoor Section
1050
72 40.3 20.0 2.55 38.3 19.3 2.84 36.2 18.5 3.16 34.0 17.7 3.51 31.6 16.8 3.88 28.8 15.8 4.26
67 37.2 25.6 2.55 35.4 24.9 2.84 33.4 24.1 3.15 31.4 23.2 3.50 29.1 22.3 3.86 26.6 21.4 4.24
63†† 34.6 24.9 2.54 32.9 24.1 2.83 31.1 23.3 3.14 29.1 22.5 3.48 27.0 21.6 3.84 24.7 20.6 4.21
62 34.2 31.0 2.54 32.5 30.2 2.83 30.8 29.3 3.14 28.9 28.3 3.48 27.0 27.0 3.84 25.1 25.1 4.22
57 33.1 33.1 2.54 31.8 31.8 2.82 30.3 30.3 3.14 28.7 28.7 3.48 27.0 27.0 3.84 25.1 25.1 4.22
1275
72 41.0 21.1 2.64 38.9 20.4 2.93 36.8 19.6 3.26 34.4 18.8 3.61 31.9 17.9 3.97 29.1 16.9 4.36
67 37.9 27.8 2.64 36.0 27.0 2.93 34.0 26.2 3.24 31.8 25.4 3.59 29.5 24.5 3.95 26.9 23.4 4.33
63†† 35.4 27.0 2.63 33.6 26.2 2.92 31.6 25.4 3.23 29.6 24.5 3.57 27.4 23.5 3.93 25.0 22.5 4.31
62 35.1 34.0 2.63 33.4 33.0 2.92 31.7 31.7 3.23 30.0 30.0 3.57 28.1 28.1 3.94 26.0 26.0 4.32
57 34.8 34.8 2.63 33.3 33.3 2.92 31.7 31.7 3.23 30.0 30.0 3.57 28.1 28.1 3.94 26.0 26.0 4.32
1500
72 41.4 22.2 2.73 39.3 21.5 3.02 37.1 20.7 3.34 34.6 19.8 3.70 32.1 18.9 4.06 29.2 18.0 4.45
67 38.4 29.9 2.72 36.5 29.1 3.01 34.4 28.3 3.33 32.1 27.4 3.68 29.7 26.4 4.04 27.1 25.2 4.42
63†† 35.8 28.9 2.72 34.0 28.1 3.01 32.0 27.2 3.32 29.9 26.3 3.66 27.6 25.3 4.02 25.2 24.1 4.40
62 36.0 36.0 2.72 34.4 34.4 3.01 32.7 32.7 3.33 30.9 30.9 3.67 28.9 28.9 4.03 26.7 26.7 4.42
57 36.0 36.0 2.72 34.4 34.4 3.01 32.7 32.7 3.33 30.9 30.9 3.67 28.9 28.9 4.03 26.7 26.7 4.42
Indoor
Section Size Cooling Indoor
Section Size Cooling Capacity Power Capacity Power
40FKA/FK4CNF 003 1.00 0.89 CJ5A/CK5A/CK5BA 042 1.01 0.92
005 1.03 0.89 048 1.00 0.89
CC5A/CD5AA 042 1.00 1.00 COILS + 58MVP080-20 VARIABLE SPEED FURNACE
CC5A/CD5AC 048 1.00 0.98 CC5A/CD5AA 042 1.01 0.93
CC5A/CD5AW 042 1.00 0.98 CD5AA 048 1.01 0.94
048 1.00 0.98 CJ5A/CK5A/CK5BA 042 1.01 0.93
CD5AA 048 1.00 0.99 048 1.00 0.89
CE3AA 042 1.00 0.98 COILS + 58MVP100-20 VARIABLE SPEED FURNACE
048 1.01 0.97 CC5A/CD5AA 042 1.02 0.91
CF3AA 036 1.00 0.98 CJ5A/CK5A/CK5BA 042 1.02 0.91
CF5AA 048 1.01 0.97 COILS + 58MVP120-20 VARIABLE SPEED FURNACE
CG5AA 048 1.00 0.98 CC5A/CD5AA 042 1.01 0.88
CJ5A/CK5A/CK5BA 042 1.00 0.98 CD5AA 048 1.00 0.88
048 1.00 0.98 CJ5A/CK5A/CK5BA 042 1.01 0.88
CJ5A/CK5A/CK5BT 042 1.00 0.98 048 1.00 0.88
048 1.00 0.98 CJ5A/CK5A/CK5BW 048 1.02 0.90
CJ5A/CK5A/CK5BW 048 1.00 0.98 COILS + 58U(H,X)V060-12 VARIABLE SPEED FURNACE
CK3BA 048 1.00 0.98 CC5A/CD5AA 042 1.00 0.90
F(A,B)4AN(F,B,C) 042 1.00 0.99 CD5AA 048 1.01 0.90
FC4BN(F,B) 042 1.00 0.99 CJ5A/CK5A/CK5BA 042 1.00 0.90
FV4ANF 003 1.00 0.89 048 1.01 0.90
005 1.03 0.89 COILS + 58U(H,X)V080-16 VARIABLE SPEED FURNACE
FX4ANF 042 1.01 0.98 CC5A/CD5AA 042 1.00 0.92
COILS + 58MVP040-14 VARIABLE SPEED FURNACE CD5AA 048 1.02 0.92
CC5A/CD5AA 042 1.00 0.89 CJ5A/CK5A/CK5BA 042 1.02 0.92
CD5AA 048 1.00 0.89 048 1.01 0.89
CJ5A/CK5A/CK5BA 042 1.00 0.89 COILS + 58U(H,X)V100-20 VARIABLE SPEED FURNACE
048 1.00 0.89 CC5A/CD5AA 042 1.03 0.90
CJ5A/CK5A/CK5BW 048 1.02 0.92 CD5AA 048 1.01 0.87
COILS + 58MVP060-14 VARIABLE SPEED FURNACE CJ5A/CK5A/CK5BA 042 1.02 0.90
CC5A/CD5AA 042 1.01 0.93 048 1.01 0.87
CD5AA 048 1.00 0.89 COILS + 58U(H,X)V120-20 VARIABLE SPEED FURNACE
CJ5A/CK5A/CK5BA 042 1.01 0.93 CD5AA 048 1.01 0.87
048 1.00 0.89 CJ5A/CK5A/CK5BA 048 1.01 0.87
COILS + 58MVP080-14 VARIABLE SPEED FURNACE CJ5A/CK5A/CK5BW 048 1.03 0.90
CC5A/CD5AA 042 1.01 0.92 — — —
See notes on pg. 19.

17
Multipliers for Determining the Performance With Other Indoor Sections.
See notes on pg. 19.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38YZA042-30 Outdoor Section With FX4ANF042 Indoor Section
1225
72 48.6 24.2 3.11 46.0 23.2 3.46 43.6 22.4 3.86 40.9 21.4 4.30 38.1 20.4 4.77 34.8 19.2 5.27
67 45.3 31.3 3.09 42.9 30.3 3.45 40.4 29.3 3.84 38.0 28.3 4.27 35.4 27.3 4.74 32.5 26.1 5.24
63†† 42.4 30.5 3.07 40.1 29.5 3.43 38.0 28.6 3.82 35.8 27.6 4.26 33.4 26.6 4.73 30.8 25.5 5.24
62 41.8 38.1 3.07 39.7 37.0 3.42 37.7 36.0 3.82 35.6 34.9 4.26 33.4 33.4 4.73 31.2 31.2 5.25
57 40.6 40.6 3.06 38.9 38.9 3.42 37.2 37.2 3.82 35.4 35.4 4.26 33.5 33.5 4.74 31.3 31.3 5.25
1400
72 49.0 25.1 3.19 46.3 24.1 3.54 43.8 23.2 3.94 41.1 22.3 4.37 38.1 21.2 4.84 34.8 20.0 5.34
67 45.9 33.1 3.17 43.4 32.1 3.52 40.7 31.0 3.91 38.2 30.1 4.34 35.5 29.0 4.81 32.5 27.8 5.31
63†† 42.9 32.2 3.15 40.5 31.2 3.50 38.4 30.2 3.90 36.1 29.3 4.33 33.6 28.2 4.80 30.8 27.0 5.31
62 42.5 40.5 3.14 40.3 39.3 3.50 38.3 38.1 3.90 36.3 36.3 4.34 34.2 34.2 4.81 31.9 31.9 5.32
57 42.0 42.0 3.14 40.0 40.0 3.50 38.3 38.3 3.90 36.4 36.4 4.34 34.3 34.3 4.82 32.0 32.0 5.33
1575
72 49.3 26.0 3.26 46.5 25.0 3.61 43.9 24.1 4.01 41.2 23.1 4.44 38.1 22.0 4.91 35.3 21.0 5.43
67 46.2 34.8 3.24 43.7 33.8 3.60 40.9 32.7 3.98 38.3 31.7 4.42 35.6 30.6 4.88 33.0 29.5 5.41
63†† 43.2 33.8 3.22 40.8 32.7 3.57 38.6 31.8 3.97 36.2 30.7 4.40 33.7 29.6 4.88 30.9 28.3 5.38
62 43.1 42.6 3.22 40.9 40.9 3.57 39.1 39.1 3.98 37.1 37.1 4.41 34.8 34.8 4.89 32.3 32.3 5.40
57 43.0 43.0 3.22 41.0 41.0 3.58 39.2 39.2 3.98 37.1 37.1 4.42 34.9 34.9 4.90 32.4 32.4 5.41
Indoor
Section Size Cooling Indoor
Section Size Cooling Capacity Power Capacity Power
FX4ANF 042 1.00 1.09 COILS + 58MVP080-20 VARIABLE SPEED FURNACE
40FKA/FK4CNF 003 1.00 1.00 CD5AA 048 0.99 1.02
005 1.01 0.98 CJ5A/CK5A/CK5BA 048 0.99 1.02
CC5A/CD5AC 048 0.98 1.07 CK3BA 048 0.99 1.02
CC5A/CD5AW 048 0.99 1.08 COILS + 58MVP100-20 VARIABLE SPEED FURNACE
CD3(A,B)A 048 0.99 1.08 CD5AA 048 0.99 1.00
CD5A/CD5BA 048 0.99 1.08 CJ5A/CK5A/CK5BA 048 0.99 1.00
CE3AA 048 1.00 1.08 CJ5A/CK5A/CK5BW 048 0.99 1.02
CJ5A/CK5A/CK5BA 048 0.99 1.08 CK3BA 048 0.99 1.00
CJ5A/CK5A/CK5BN 048 0.99 1.08 COILS + 58MVP120-20 VARIABLE SPEED FURNACE
CJ5A/CK5A/CK5BW 048 0.99 1.08 CC5A/CD5AW 048 0.99 1.00
CK3BA 048 0.99 1.08 CJ5A/CK5A/CK5BW 048 0.99 1.00
F(A,B)4AN(F,B,C) 048 0.99 1.07 COILS + 58U(H,X)V080-16 VARIABLE SPEED FURNACE
FC4BN(F,B) 048 1.00 1.09 CD5AA 048 0.99 1.01
FV4ANF 003 1.00 1.00 CJ5A/CK5A/CK5BA 048 0.99 1.01
005 1.01 0.98 CK3BA 048 0.99 1.01
COILS + 58MVP040-14 VARIABLE SPEED FURNACE COILS + 58U(H,X)V100-20 VARIABLE SPEED FURNACE
CC5A/CD5AW 048 0.99 1.02 CC5A/CD5AW 048 0.99 0.99
CJ5A/CK5A/CK5BW 048 0.99 1.02 CJ5A/CK5A/CK5BW 048 0.99 0.99
COILS + 58MVP080-14 VARIABLE SPEED FURNACE COILS + 58U(H,X)V120-20 VARIABLE SPEED FURNACE
CD5AA 048 0.99 1.01 CC5A/CD5AW 048 0.99 0.99
CJ5A/CK5A/CK5BA 048 0.99 1.01 CJ5A/CK5A/CK5BW 048 0.99 0.99
CK3BA 048 0.99 1.01 — — —
Detailed cooling capacities* continued

18
Detailed cooling capacities* continued
Multipliers for Determining the Performance With Other Indoor Sections
See notes on pg. 19.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38YZA048-30 Outdoor Section With FX4ANF048 Indoor Section
1400
72 56.2 28.0 3.40 53.8 27.1 3.77 51.2 26.2 4.18 48.5 25.2 4.64 45.6 24.2 5.15 42.5 23.1 5.71
67 52.0 36.1 3.36 49.8 35.2 3.73 47.4 34.2 4.14 44.9 33.2 4.60 41.9 32.0 5.08 39.0 30.9 5.64
63†† 48.6 35.2 3.33 46.5 34.2 3.69 44.2 33.2 4.11 41.6 32.1 4.55 39.1 31.0 5.05 36.4 29.9 5.62
62 48.0 43.9 3.32 45.8 42.8 3.68 43.8 41.8 4.11 41.5 40.6 4.56 39.0 39.0 5.06 36.7 36.7 5.61
57 46.7 46.7 3.31 44.9 44.9 3.68 43.0 43.0 4.09 41.1 41.1 4.55 39.1 39.1 5.06 36.8 36.8 5.63
1600
72 57.2 29.3 3.50 54.6 28.4 3.87 52.0 27.4 4.29 48.8 26.3 4.72 45.8 25.3 5.23 42.6 24.1 5.78
67 53.0 38.4 3.46 50.3 37.3 3.82 47.8 36.3 4.23 45.3 35.3 4.68 42.5 34.2 5.19 39.2 32.9 5.72
63†† 49.5 37.3 3.42 47.0 36.2 3.78 44.7 35.2 4.19 42.3 34.2 4.65 39.4 32.9 5.13 36.6 31.7 5.69
62 49.1 47.0 3.42 46.9 45.8 3.79 44.6 44.4 4.19 42.4 42.4 4.65 40.1 40.1 5.14 37.5 37.5 5.69
57 48.3 48.3 3.41 46.3 46.3 3.77 44.6 44.6 4.20 42.3 42.3 4.64 40.1 40.1 5.15 37.7 37.7 5.71
1800
72 57.5 30.3 3.58 54.8 29.3 3.95 52.1 28.4 4.37 48.9 27.3 4.81 45.9 26.2 5.31 42.5 25.1 5.86
67 53.4 40.4 3.54 51.0 39.4 3.91 48.1 38.3 4.31 45.5 37.3 4.77 42.7 36.1 5.27 39.7 35.0 5.83
63†† 49.9 39.1 3.51 47.7 38.2 3.88 45.0 37.0 4.28 42.5 35.9 4.73 39.9 34.9 5.24 37.0 33.6 5.81
62 49.8 49.4 3.51 47.6 47.6 3.87 45.5 45.5 4.28 43.3 43.3 4.74 41.2 41.2 5.26 38.5 38.5 5.81
57 49.8 49.8 3.51 47.7 47.7 3.88 45.6 45.6 4.29 43.5 43.5 4.75 40.9 40.9 5.24 38.4 38.4 5.79
Indoor
Section Size Cooling Indoor
Section Size Cooling Capacity Power Capacity Power
FX4ANF 048 0.99 1.06 COILS + 58MVP100-20 VARIABLE SPEED FURNACE
FV4ANF 005 1.00 1.00 CC5A/CD5AA 060 0.98 1.01
40FKA/FK4CNB 006 1.02 0.98 CC5A/CD5AW 060 0.99 1.01
40FKA/FK4CNF 005 1.00 1.00 CJ5A/CK5A/CK5BA 060 0.98 1.01
CC5A/CD5AA 060 0.98 1.06 CJ5A/CK5A/CK5BX 060 0.99 1.01
CC5A/CD5AW 060 0.98 1.06 CK3BA 060 0.98 1.01
CC5A/CD5AW 060 1.00 1.06 COILS + 58MVP120-20 VARIABLE SPEED FURNACE
CD3(A,B)A 060 0.97 1.06 CC5A/CD5AA 060 0.98 1.01
CE3AA 060 1.00 1.06 CC5A/CD5AW 060 0.99 0.99
CJ5A/CK5A/CK5BA 060 0.99 1.06 CJ5A/CK5A/CK5BA 060 0.98 1.01
CJ5A/CK5A/CK5BX 060 1.00 1.06 CJ5A/CK5A/CK5BX 060 0.99 0.99
CK3BA 060 0.99 1.06 CK3BA 060 0.98 1.01
F(A,B)4AN(F,B,C) 060 0.97 1.10 COILS + 58U(H,X)V100-20 VARIABLE SPEED FURNACE
FB4ANB 070 1.01 1.06 CC5A/CD5AA 060 0.99 0.98
FC4BN(F,B) 060 0.98 1.10 CC5A/CD5AW 060 1.00 0.98
FC4BNB 070 1.01 1.06 CJ5A/CK5A/CK5BA 060 0.99 0.98
FV4ANB 006 1.02 0.98 CJ5A/CK5A/CK5BX 060 1.00 0.98
FX4ANB 060 1.00 1.06 CK3BA 060 0.99 0.98
COILS + 58MVP080-20 VARIABLE SPEED FURNACE COILS + 58U(H,X)V120-20 VARIABLE SPEED FURNACE
CC5A/CD5AA 060 0.97 1.04 CC5A/CD5AA 060 0.98 0.99
CC5A/CD5AW 060 0.98 1.03 CC5A/CD5AW 060 1.00 0.99
CJ5A/CK5A/CK5BA 060 0.97 1.04 CJ5A/CK5A/CK5BA 060 0.98 0.99
CJ5A/CK5A/CK5BX 060 0.98 1.03 CJ5A/CK5A/CK5BX 060 1.00 0.99
CK3BA 060 0.97 1.04 CK3BA 060 0.98 0.99

19
Detailed cooling capacities* continued
Multipliers for Determining the Performance With Other Indoor Sections
* Detailed cooling capacities are based on indoor and outdoor unit at the same elevation per ARI standard 210/240-94. If additional tubing length and/or
indoor unit is located above outdoor unit, a slight variation in capacity may occur.
† Total and sensible capacities are net capacities. Blower motor heat has been subtracted.
‡ Sensible capacities shown are based on 80°F (27°C) entering air at the indoor coil. For sensible capacities at other than 80°F (27°C), deduct 835 Btuh
(245 kw) per 1000 CFM (480 L/S) of indoor coil air for each degree below 80°F (27°C), or add 835 Btuh (245 kw) per 1000 CFM (480 L/S) of indoor coil air
per degree above 80°F (27°C).
** System kw is total of indoor and outdoor unit kilowatts.
†† At TVA rating indoor condition (75°F edb/63°F ewb). All other indoor air temperatures are at 80°F edb.
EWB—Entering Wet Bulb
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38YZA060-30 Outdoor Section With FX4ANB060 Indoor Section
1750
72 69.2 34.7 4.68 66.0 33.5 5.17 63.2 32.5 5.74 60.2 31.4 6.37 56.5 30.1 7.04 52.3 28.6 7.77
67 64.9 45.1 4.63 61.9 43.9 5.13 58.8 42.6 5.68 55.7 41.4 6.29 52.2 40.0 6.95 48.4 38.5 7.68
63†† 61.1 44.2 4.60 58.0 42.8 5.08 55.5 41.7 5.65 52.5 40.4 6.26 49.3 39.0 6.93 45.6 37.4 7.66
62 60.3 55.1 4.59 57.3 53.6 5.07 54.6 52.3 5.62 51.7 50.8 6.23 48.8 48.8 6.90 45.8 45.8 7.64
57 58.7 58.7 4.57 56.2 56.2 5.06 54.0 54.0 5.61 51.5 51.5 6.23 48.9 48.9 6.91 45.9 45.9 7.65
2000
72 69.9 36.1 4.79 66.5 34.9 5.29 63.6 33.9 5.85 60.5 32.8 6.48 56.6 31.4 7.14 52.3 29.9 7.87
67 65.6 47.8 4.75 62.5 46.6 5.24 59.4 45.3 5.79 56.0 44.0 6.40 52.4 42.6 7.06 49.1 41.3 7.82
63†† 61.8 46.7 4.71 59.0 45.4 5.20 56.0 44.1 5.75 52.9 42.8 6.36 49.5 41.4 7.03 45.8 39.7 7.76
62 61.3 58.8 4.70 58.2 57.1 5.19 55.9 55.7 5.76 53.2 53.2 6.37 50.4 50.4 7.06 47.3 47.3 7.80
57 60.6 60.6 4.70 57.9 57.9 5.18 55.5 55.5 5.74 52.9 52.9 6.35 50.1 50.1 7.03 46.9 46.9 7.77
2250
72 70.3 37.4 4.90 67.3 36.4 5.41 63.8 35.1 5.96 60.6 34.1 6.58 56.6 32.6 7.24 52.2 31.1 7.96
67 66.0 50.3 4.86 62.9 49.1 5.35 59.7 47.8 5.90 56.2 46.4 6.50 53.2 45.2 7.19 49.7 43.8 7.96
63†† 62.3 49.0 4.82 59.8 47.9 5.33 56.3 46.4 5.86 53.1 45.1 6.47 49.7 43.5 7.13 45.8 41.9 7.86
62 62.2 61.8 4.82 59.2 59.2 5.30 57.0 57.0 5.87 54.3 54.3 6.49 51.3 51.3 7.17 48.5 48.5 7.95
57 62.1 62.1 4.82 59.3 59.3 5.31 56.7 56.7 5.86 54.0 54.0 6.47 51.0 51.0 7.15 48.2 48.2 7.92
Indoor
Section Size Cooling Indoor
Section Size Cooling Capacity Power Capacity Power
FX4ANB 060 0.99 1.04 COILS + 58U(H,X)V100-20 VARIABLE SPEED FURNACE
40FKA/FK4CNB 006 1.01 1.00 CC5A/CD5AW 060 0.97 1.00
CC5A/CD5AW 060 0.97 1.02 CJ5A/CK5A/CK5BX 060 0.98 1.00
CJ5A/CK5A/CK5BX 060 0.98 1.02 COILS + 58U(H,X)V120-20 VARIABLE SPEED FURNACE
FB4ANB 070 0.99 1.04 CC5A/CD5AW 060 0.97 1.01
FC4BNB 070 0.99 1.04 CJ5A/CK5A/CK5BX 060 0.98 1.01
FV4ANB 006 1.00 1.00 —— —

20
Heat pump heating performance
Multipliers for Determining the Performance With Other Indoor Sections
INDOOR
AIR OUTDOOR COIL ENTERING AIR TEMPERATURES °F –3 7 172737475767
EDB CFM
Capacity
(MBtuh) Total Pwr Capacity (MBtuh) Total Pwr Capacity (MBtuh) Total Pwr Capacity (MBtuh) Total Pwr Capacity (MBtuh) Total Pwr Capacity (MBtuh) Total Pwr Capacity (MBtuh) Total Pwr Capacity (MBtuh) Total Pwr
Total Int* Kw† Total Int* Kw† Total Int* Kw† Total Int* Kw† Total Int* Kw† Total Int* Kw† Total Int* Kw† Total Int* Kw†
38YZA024-30 Outdoor Section With FX4ANF030 Indoor Section
65 700 10.9 10.0 1.85 13.0 11.9 1.86 15.3 14.0 1.89 17.8 15.8 1.93 20.7 18.8 1.99 23.9 23.9 2.05 27.5 27.1 2.29 28.8 28.8 2.38
825 11.1 10.2 1.90 13.2 12.1 1.88 15.5 14.2 1.90 18.1 16.1 1.92 21.0 19.1 1.96 24.3 24.3 2.02 27.7 27.7 2.23 28.9 28.9 2.27
950 11.2 10.3 1.95 13.3 12.3 1.92 15.7 14.4 1.92 18.3 16.3 1.93 21.3 19.4 1.96 24.7 24.7 2.00 28.2 28.2 2.21 29.0 29.0 2.20
70 700 10.9 9.98 1.95 12.9 11.8 1.96 15.2 13.8 2.00 17.6 15.6 2.04 20.4 18.6 2.10 23.5 23.5 2.16 26.7 26.7 2.41 28.3 28.3 2.49
825 11.0 10.1 1.99 13.1 12.0 1.99 15.4 14.0 2.00 17.9 15.9 2.03 20.8 18.9 2.07 24.0 24.0 2.12 27.3 27.3 2.35 28.7 28.7 2.41
950 11.2 10.3 2.05 13.3 12.2 2.02 15.6 14.2 2.02 18.1 16.1 2.03 21.1 19.2 2.06 24.4 24.4 2.11 27.7 27.7 2.32 29.2 29.2 2.35
75 700 10.8 9.95 2.06 12.8 11.8 2.07 15.0 13.7 2.11 17.4 15.5 2.15 20.2 18.4 2.21 23.2 23.2 2.28 26.3 26.3 2.53 27.8 27.8 2.62
825 11.0 10.1 2.10 13.0 11.9 2.09 15.3 13.9 2.11 17.7 15.7 2.14 20.6 18.7 2.18 23.7 23.7 2.24 26.8 26.8 2.47 28.5 28.5 2.54
950 11.1 10.3 2.15 13.2 12.1 2.13 15.5 14.1 2.12 18.0 16.0 2.14 20.8 19.0 2.17 24.1 24.1 2.22 27.7 27.3 2.44 28.5 28.5 2.46
Indoor
Section Size Heating Indoor Section Size Heating Capacity Power Capacity Power
FX4ANF 030 1.00 1.00 CJ5A/CK5A/CK5BW 036 0.98 0.94
40FKA/FK4CNF 002 0.97 0.93 CK3BA 036 0.98 0.94
003 0.97 0.93 COILS + 58MVP080-14 VARIABLE SPEED FURNACE
CC5A/CD5AA 036 0.93 0.98 CD5AW 036 0.98 0.93
CD5AW 036 0.93 0.98 CJ5A/CK5A/CK5BW 036 0.98 0.93
CE3AA 036 0.98 1.03 COILS + 58MVP080-20 VARIABLE SPEED FURNACE
CF5AA 036 0.94 0.99 CD5AW 036 0.98 0.94
CG5AA 036 0.94 0.99 CJ5A/CK5A/CK5BW 036 1.00 0.95
CJ5A/CK5A/CK5BA 036 0.98 0.98 COILS + 58MVP100-20 VARIABLE SPEED FURNACE
CJ5A/CK5A/CK5BT 036 0.98 0.98 CD5AW 036 1.00 0.93
CJ5A/CK5A/CK5BW 036 0.98 0.98 CJ5A/CK5A/CK5BW 036 1.00 0.93
CK3BA 036 0.98 0.98 COILS + 58U(H,X)V060-12 VARIABLE SPEED FURNACE
F(A,B)4AN(F,C) 030 0.99 1.03 CC5A/CD5AA 036 0.94 0.93
FC4BNF 030 0.99 1.03 CD5AW 036 0.94 0.93
FG3AAA 036 0.98 1.02 CJ5A/CK5A/CK5BA 036 0.94 0.93
FK4CNF 001 0.97 0.97 CJ5A/CK5A/CK5BW 036 0.94 0.93
FV4ANF 002 0.98 0.94 CK3BA 036 0.95 0.94
003 0.98 0.94 COILS + 58U(H,X)V080-16 VARIABLE SPEED FURNACE
COILS + 58MVP060-14 VARIABLE SPEED FURNACE CD5AW 036 0.98 0.93
CC5A/CD5AA 036 0.98 0.94 CJ5A/CK5A/CK5BW 036 0.98 0.93
CJ5A/CK5A/CK5BA 036 0.98 0.94 — — —
See notes on pg. 25.
