Carrier WEATHERMAKER 50TFQ004 Dimensions and installation guide

Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 04-53500018-01 Printed in U.S.A. Form 50TFQ-8SI Pg 1 9-05 Replaces: 50TFQ-6SI
Book 1 4
Tab 5a 5 a
Installation, Start-Up and
Service Instructions
CONTENTS
Page
SAFETY CONSIDERATIONS .........................1
INSTALLATION ...................................1-41
Step 1 — Provide Unit Support ......................1
• ROOF CURB
• SLAB MOUNT
• ALTERNATE UNIT SUPPORT
Step 2 — Field Fabricate Ductwork ..................2
Step 3 — Install Condensate Drain Line
and External Trap .................................2
Step 4 — Rig and Place Unit .........................2
• POSITIONING
Step 5 — Make Electrical Connections ..............7
• FIELD POWER SUPPLY
• FIELD CONTROL WIRING
• DEFROST BOARD
• HEAT ANTICIPATOR SETTINGS
Step 6 — Adjust Factory-Installed Options .........17
• DISCONNECT SWITCH
• CONVENIENCE OUTLET
• NOVAR CONTROLS
• MANUAL OUTDOOR-AIR DAMPER
• PREMIERLINK™ CONTROL
• OPTIONAL ECONOMI$ER IV AND ECONOMI$ER2
• ECONOMI$ER IV STANDARD SENSORS
• ECONOMI$ER IV CONTROL MODES
Step 7 — Adjust Indoor-Fan Speed .................29
• DIRECT-DRIVE MOTORS
• BELT-DRIVE MOTORS
PRE-START-UP .....................................42
START-UP .......................................42-45
SERVICE ........................................45-47
TROUBLESHOOTING ............................48-51
INDEX ..............................................52
START-UP CHECKLIST .......................... CL-1
SAFETY CONSIDERATIONS
Installation and servicing of air-conditioning equipment can
be hazardous due to system pressure and electrical compo-
nents. Only trained and qualified service personnel should
install, repair, or service air-conditioning equipment.
Untrained personnel can perform basic maintenance func-
tions of cleaning coils and filters and replacing filters. All other
operations should be performed by trained service personnel.
When working on air-conditioning equipment, observe precau-
tions in the literature, tags and labels attached to the unit, and
other safety precautions that may apply.
Follow all safety codes. Wear safety glasses and work
gloves. Use quenching cloth for unbrazing operations. Have
fire extinguisher available for all brazing operations.
INSTALLATION
Unit is shipped in the vertical discharge configuration. To
convert to horizontal configuration, remove horizontal duct
opening covers. Using the same screws, install covers on duct
openings in basepan of unit with the insulation-side down.
Seals around duct openings must be tight.
Step 1 — Provide Unit Support
ROOF CURB — Assemble and install the accessory roof
curb in accordance with instructions shipped with the curb.
See Fig. 1. Install insulation, cant strips, roofing felt, and
counter flashing as shown. Ductwork must be attached to the
curb, not to the unit. If electric or control power is to be routed
through the basepan, be sure to choose the appropriate acces-
sory kit. See Fig. 1. Attach the accessory thru-the-bottom ser-
vice connections to the basepan and roof curb in accordance
with the accessory installation instructions. Connections must
be installed before the unit is set on the roof curb.
The roof curb should be level. This is necessary for the unit
drain to function properly. Unit leveling tolerances are shown
in Fig. 2. Refer to Accessory Roof Curb Installation Instruc-
tions for additional information, as required.
Before performing service or maintenance operations on
unit, turn off main power switch to unit and tag disconnect.
Ensure voltage listed on unit data plate agrees with electri-
cal supply provided for the unit. Electrical shock could
cause serious personal injury.
IMPORTANT: The gasketing of the unit to the roof curb
is critical for watertightness. Install gasket supplied with
the roof curb as shown in Fig. 1. Improperly applied
gasket can also result in air leaks and poor unit
performance.
50TFQ004-007
Single-Package Rooftop
Heat Pump Units

2
SLAB MOUNT (Horizontal Units Only) — Provide a level
concrete slab that extends a minimum of 6 in. beyond the unit
cabinet. Install a gravel apron in front of the condenser coil air
inlet to prevent grass and foliage from obstructing airflow.
NOTE: Horizontal units may be installed on a roof curb if
required.
ALTERNATE UNIT SUPPORT — When the curb or
adapter cannot be used, support unit with sleepers using unit
curb or adapter support area. If sleepers cannot be used, sup-
port the long sides of the unit with a minimum of 3 equally
spaced 4-in. x 4-in. pads on each side.
Step 2 — Field Fabricate Ductwork — Secure all
ducts to the roof curb and building structure on vertical dis-
charge units. Do not connect ductwork to the unit. For horizon-
tal applications, field-supplied flanges should be attached to
horizontal discharge openings and all ductwork should be at-
tached to the flanges. Insulate and weatherproof all external
ductwork, joints, and roof openings with counterflashing and
mastic in accordance with applicable codes.
Ducts passing through an unconditioned space must be
insulated and covered with a vapor barrier.
If a plenum return is used on a vertical unit, the return
should be ducted through the roof deck to comply with applica-
ble fire codes.
A minimum clearance is not required around ductwork.
Cabinet return-air static pressure (a negative condition) should
not exceed 0.35 in. wg with economizer or 0.45 in. wg without
economizer.
Step 3 — Install Condensate Drain Line and
External Trap — Condensate drain connections are locat-
ed on the bottom and side of the unit. Unit discharge connec-
tions do not determine the use of drain connections; either
drain connection can be used with vertical or horizontal dis-
charge units.
When using the standard side drain connection, make sure
the plug in the alternate bottom connection is tight before
installing the unit.
To use the bottom drain connection for a roof curb installa-
tion, relocate the factory-installed plug from the bottom con-
nection to the side connection. The center drain plug looks like
a star connection, but can be removed using a 1/2-in. socket
drive extension. See Fig. 3. The piping for the condensate drain
and external trap can be completed after the unit is in place.
All units must have an external trap for condensate drain-
age. Install a trap at least 4 in. deep and protect against freeze-
up. If the drain line is installed downstream from the external
trap, pitch the line away from the 50TFQ unit at 1/4in. per ft of
run. Do not use a pipe size smaller than the unit connection.
See Fig. 4.
Step 4 — Rig and Place Unit — Inspect the unit for
transportation damage, and file any claim with the transporta-
tion agency. Keep the unit upright and do not drop it. Spreader
bars are not required if top crating is left on the unit, and rollers
may be used to move the unit across a roof. Level by using the
unit frame as a reference. See Table 1 and Fig. 5 for additional
information. Operating weight is shown in Table 1 and Fig. 5.
Lifting holes are provided in base rails as shown in Fig. 5
and 6. Refer to rigging instructions on the unit.
POSITIONING — Maintain clearance around and above the
unit to provide proper airflow and service access. See Fig. 6.
A properly positioned unit will have the following clearanc-
es: 1/4-in. clearance between the roof curb and base rails on
each side and front of the unit; 1/4-in. clearance between the
roof curb and rear of unit. (See Fig. 1, section C-C.)
Do not install the unit indoors. Do not locate the unit air in-
lets near exhaust vents or other sources of contaminated air.
Although the unit is weatherproof, guard against water from
higher level runoff and overhangs.
After the unit is in position, remove the polyethylene ship-
ping wrapper and top crating.
All panels must be in place when rigging. Unit is not
designed for handling by a fork truck. Damage to unit may
result.

3
ROOF CURB
ACCESSORY A UNIT SIZE
CRRFCURB001A01 1′-2″
[356] 50TFQ004-007
CRRFCURB002A01 2′-0″
[610]
NOTES:
1. Roof curb accessory is shipped disassembled.
2. Insulated panels.
3. Dimensions in [ ] are in millimeters.
4. Roof curb: galvanized steel.
5. Attach ductwork to curb (flanges of duct rest on
curb).
6. Service clearance: 4 ft on each side.
7. Direction of airflow.
8. Connector packages CRBTMPWR001A01 and
002A01 are for thru-the-curb type gas. Packages
CRBTMPWR003A01 and 004A01 are for thru-the-
bottom type gas connections.
CONNECTOR
PKG. ACCY. BC
DALT
DRAIN
HOLE
GAS POWER CONTROL ACCESSORY
PWR
CRBTMPWR001A01
1′-911/16″
[551]
1′-4″
[406]
13/4″
[44.5]
3/4″
[19] NPT
3/4″[19] NPT
1/2″
[12.7]
NPT
1/2″
[12.7]
NPT
CRBTMPWR002A01 11/4″[31.7]
CRBTMPWR003A01 1/2″
[12.7] NPT 3/4″[19] NPT
CRBTMPWR004A01 3/4″
[19] NPT 11/4″[31.7]
Fig. 1 — Roof Curb Details

4
NOTES:
1. Dimension in ( ) is in millimeters.
2. Hook rigging shackles through holes in base rail, as shown in detail
‘‘A.’’ Holes in base rails are centered around the unit center of grav-
ity. Use wooden top skid when rigging to prevent rigging straps
from damaging unit.
3. Unit weights do not include economizer. See Table 1 for econo-
mizer weights.
All panels must be in place when rigging. Unit is not designed for
handling by a fork truck.
50TFQ
UNIT
SIZE
OPERATING
WEIGHT
DIMENSIONS
‘‘A’’ ‘‘B’’ ‘‘C’’
lb kg in. mm in. mm in. mm
004 500 227 73.69 1872 35.50 902 33.31 847
005 520 236 73.69 1872 35.50 902 33.31 847
006 550 249 73.69 1872 35.50 902 33.31 847
007 590 268 73.69 1872 35.50 902 33.31 847
Fig. 5 — Rigging Details
MAXIMUM ALLOWABLE
DIFFERENCE (in.)
A-B B-C A-C
0.5 1.0 1.0
Fig. 2 — Unit Leveling Tolerances
DRAIN PLUGHORIZONTAL
DRAIN OUTLET
NOTE: Drain plug is shown in factory-installed position.
Fig. 3 — Condensate Drain Connection
NOTE: Trap should be deep enough to offset maximum unit static dif-
ference. A 4-in. trap is recommended.
Fig. 4 — Condensate Drain Piping Details

5
Table 1 — Physical Data
LEGEND
*Weight of 14-in. roof curb.
†Single phase/three phase.
NOTE: The 50TFQ units have a loss-of-charge switch located in the liquid line.
50TFQ UNIT SIZE 004 005 006 007
NOMINAL CAPACITY (tons) 3456
OPERATING WEIGHT (lb)
Unit 500 520 550 590
Economizer
EconoMi$er IV 50 50 50 50
Roof Curb* 115 115 115 115
COMPRESSOR Hermetic
Quantity 1111
Oil (oz) 45 54 50 54
REFRIGERANT TYPE R-22
Operating Charge (lb-oz)
Circuit 1 5-1 6-0 8-0 11-2
Circuit 2 ————
OUTDOOR COIL Enhanced Copper Tubes, Aluminum Lanced Fins, Acutrol™ Metering Device
Rows...Fins/in. 1...17 1...17 2...17 2...17
Total Face Area (sq ft) 10.31 14.58 12.25 16.53
OUTDOOR FAN Propeller Type
Nominal Cfm 4000 4000 4000 4000
Quantity...Diameter (in.) 1...22.0 1...22.0 1...22.0 1...22.0
Motor Hp...Rpm 1/4...1100 1/4...1100 1/4...1100 1/4...1100
Watts Input (Total) 325 325 325 325
INDOOR COIL Enhanced Copper Tubes, Aluminum Double-Wavy Fins, Acutrol Metering Device
Rows...Fins/in. 2...15 2...15 3...15 3...15
Total Face Area (sq ft) 4.24.25.55.5
INDOOR FAN Centrifugal Type
Quantity...Size (in.) Std 1...10 x 10 1...10 x 10 1...11 x 10 1...10 x 10
Alt 1...10 x 10 1...10 x 10 1...10 x 10 —
High-Static 1...10 x 10 1...10 x 10 1...10 x 10 1...10 x 10
Type Drive Std Direct Direct Direct Belt
Alt Belt Belt Belt —
High-Static Belt Belt Belt Belt
Nominal Cfm 1200 1600 2000 2400
Maximum Continuous Bhp Std .34 .75 1.20 2.40
Alt 1.00 1.00 1.30/2.40† —
High-Static 2.40 2.40 2.90 2.90
Motor Frame Size Std 48 48 48 56
Alt 48 48 56 —
High-Static 56 56 56 56
Nominal Rpm High/Low Std 860/800 1075/970 1075/970 —
Alt 1620 1620 1725 —
High-Static 1725 1725 1725 1725
Fan Rpm Range Std — — — 1070-1460
Alt 760-1000 770-1175 878-1192 —
High-Static 1075-1455 1075-1455 1300-1685 1300-1685
Motor Bearing Type Ball Ball Ball Ball
Maximum Allowable Rpm 2100 2100 2100 2100
Motor Pulley Pitch Diameter Min/Max (in.) Std — — — 2.8/3.8
Alt 1.9/2.9 1.9/2.9 2.4/3.4 —
High-Static 2.8/3.8 2.8/3.8 3.4/4.4 3.4/4.4
Nominal Motor Shaft Diameter (in.) Std 1/21/21/25/8
Alt 1/21/25/8—
High-Static 5/85/85/85/8
Fan Pulley Pitch Diameter (in.) Std ———4.5
Alt 4.5 4.0 4.5 —
High-Static 4.54.54.54.5
Belt, Quantity...Type...Length (in.) Std — — — 1...A...40
Alt 1...A...34 1...A...34 1...A...39 —
High-Static 1...A...39 1...A...39 1...A...40 1...A...40
Pulley Center Line Distance (in.) Std — — — 14.7-15.5
Alt 10.0-12.4 10.0-12.4 14.7-15.5 —
High-Static 10.0-12.4 10.0-12.4 14.7-15.5 14.7-15.5
Speed Change per Full Turn of
MovablePulleyFlange(rpm) Std ———80
Alt 48 70 80 —
High-Static 65 65 60 60
Movable Pulley Maximum Full Turns
From Closed Position Std ——— 5
Alt 555—
High-Static 6655
Factory Setting Std ——— 3
Alt 333—
High-Static 31/231/231/231/2
Factory Speed Setting (rpm) Std ———1225
Alt 856 932 1035 —
High-Static 1233 1233 1416 1416
Fan Shaft Diameter at Pulley (in.) 5/85/85/85/8
HIGH-PRESSURE SWITCH (psig)
Standard Compressor Internal Relief (Differential) 450 ± 50
Cutout 428
Reset (Auto.) 320
LOSS-OF-CHARGE SWITCH (psig)
Cutout 7±3
Reset (Auto.) 22 ± 7
FREEZE-PROTECTION THERMOSTAT (F)
Opens 30 ± 5
Closes 45 ± 5
OUTDOOR-AIR INLET SCREENS Cleanable. Quantity and size depend on options selected.
RETURN-AIR FILTERS Throwaway
Quantity...Size (in.) 2...16 x 25 x 2
Bhp — Brake Horsepower

6
Fig. 6 — Base Unit Dimensions

7
Step 5 — Make Electrical Connections
FIELD POWER SUPPLY — All units except 208/230-v
units are factory wired for the voltage shown on the nameplate.
If the 208/230-v unit will be connected to a 208-v power sup-
ply, the transformer must be rewired by disconnecting the
black wire from the 230-v terminal on the transformer and
connecting it to the 200-v terminal from the transformer.
Refer to the unit label diagram for additional information.
Pigtails are provided for field wire connections. Use factory-
supplied splices or a UL (Underwriters’ Laboratories)
approved copper/aluminum connector.
When installing units, provide a disconnect per the
NEC. All field wiring must comply with the NEC and local
requirements.
Install field wiring as follows:
1. Install conduit through the side panel openings. For units
without electric heat, install conduit between the discon-
nect and control box.
2. Install power lines to terminal connections as shown in
Fig. 7.
3. For units with electric heat, refer to Table 2 and Accessory
Electric Heat Installation Instructions.
During operation, voltage to compressor terminals must be
within the range indicated on the unit nameplate (also see
Tables 3A and 3B). On 3-phase units, voltages between phases
must be balanced within 2% and the current within 10%. Use
the formula shown in Tables 3A and 3B and Note 2, on page 12
to determine the percentage of voltage imbalance. Operation
on improper line voltage or excessive phase imbalance consti-
tutes abuse and may cause damage to electrical components.
Such operation invalidates any applicable Carrier warranty.
NOTE: If the unit is mounted on a roof curb and the electrical
power will be run up “thru-the-bottom,” be sure to choose the
proper accessory kit shown in Fig. 1. This kit, available from
your local distributor, ensures a reliable watertight connection.
Refer to the thru-the-bottom accessory installation instructions
for information on wiring the unit.
Unit cabinet must have an uninterrupted, unbroken electri-
cal ground to minimize the possibility of personal injury if
an electrical fault should occur. This ground may consist of
electrical wire connected to unit ground lug in control com-
partment, or conduit approved for electrical ground when
installed in accordance with NEC (National Electrical
Code), ANSI/NFPA (American National Standards Insti-
tute/National Fire Protection Association) 70 (latest year),
and local electrical codes. Failure to follow this warning
could result in the installer being liable for personal injury
of others.

8
21 11
C
23 13 YEL
BLK
FIELD POWER SUPPLY
DISCONNECT
PER NEC
EQUIPMENT
GROUND
21 11
C
23 13
BLU
YEL
BLK TO COMP
BLU 24
IFC
FIELD POWER SUPPLY
DISCONNECT
PER NEC
EQUIPMENT
GROUND
21 11
C
23 13 BLU
YEL
BLK
FIELD POWER SUPPLY
DISCONNECT
PER NEC
TO COMP
EQUIPMENT
GROUND
21 11
C
23 13
13
IFC
46
BLU
BLU
YEL
BLK
FIELD POWER SUPPLY
DISCONNECT
PER NEC
TO COMP
EQUIPMENT
GROUND
21 11
C
23 13 YEL
BLK
FIELD POWER SUPPLY
DISCONNECT
PER NEC
EQUIPMENT
GROUND
BLU
(BLU)
TO COMP
23 13
IFC
21 11
21 11
C
23 13 YEL
BLK
FIELD POWER SUPPLY
DISCONNECT
PER NEC
EQUIPMENT
GROUND
BLU TO
TB2
LEGEND
Fig. 7 — Power Wiring Connections
C—Contactor
COMP — Compressor
IFC — Indoor Fan Contactor
NEC — National Electrical Code
TB — Terminal Block
208/230-1-60
208/230-3-60
460-3-60
(SIZES 006 AND 007)
208/230-3-60
(SIZES 004 AND 005)
460-3-60
(SIZES 004 AND 005)
575-3-60
(SIZE 004 AND 005)
575-3-60
(SIZES 006 AND 007)

9
Table 2 — Electric Heating Capacities
*Two heater packages required to provide kW indicated.
†Use CRSINGLE004A00 for units with convenience outlet.
**Use CRSINGLE005A00 for units with convenience outlet.
††Use CRSINGLE002A00 for units with convenience outlet.
***Use CRSINGLE002A00 for units with high-static motor
and convenience outlet.
NOTES:
1. The rated heater voltage is 240 and 480 v. If power distribution voltage varies from rated heater voltage, heater kW will vary accordingly.
2. To determine heater kW at voltages other than those shown in table, use the following formula:
Heater kW new =Heater kW rated x (unit power distribution voltage/rated heater voltage)2
As an example:
For a 16 kW heater rated at 240 v with a power distribution voltage of 215 v
kW new =16 kW (215/240)2
kW new =12.8 kW (rating at 215 v)
50TFQ
UNIT
SIZE
VOLTAGE
(60 Hz)
ACCESSORY
kW
ACCESSORY HEATER
PART NUMBER
CRHEATER ---A00
SINGLE POINT BOX
PACKAGE NO.
CRSINGLE---A00
004
208/230/240
(single phase)
3.3/ 4.0/ 4.4
4.9/ 5.8/ 6.5
6.5/ 8.0/ 8.7
7.9/ 9.6/10.5
9.8/11.6/13.0*
001
002
003
004
002 &002
—
—†
004
004
004**
208/230/240
(3 phase)
3.3/ 4.0/ 4.4
4.9/ 5.8/ 6.5
6.5/ 8.0/ 8.7
7.9/ 9.6/10.5
12.0/14.7/16.0
001
002
003
004
005
—
—
—
—
002
460/480
(3 phase)
5.5/ 6.0
8.1/ 8.8
10.6/11.5
12.9/14.0
006
007
008
009
—
—
—
—
005
208/230/240
(single phase)
3.3/ 4.0/ 4.4
6.5/ 8.0/ 8.7
9.8/11.6/13.0*
13.1/16.0/17.4*
15.8/19.3/21.0*
001
003
002 &002
003 &003
004 &004
—†
004
004
005
005
208/230/240
(3 phase)
4.9/ 5.8/ 6.5
6.5/ 8.0/ 8.7
12.0/14.7/16.0
15.8/19.3/21.0*
002
003
005
004 &004
—
—
002
003
460/480
(3 phase)
5.5/ 6.0
10.6/11.5
12.9/14.0
21.1/23.0*
006
008
009
008 &008
—
—
—
—
006
208/230/240
(single phase)
4.9/ 5.8/ 6.5
6.5/ 8.0/ 8.7
9.8/11.6/13.0*
13.1/16.0/17.4*
15.8/19.3/21.0*
002
003
002 &002
003 &003
004 &004
004
004
005
005
005
208/230/240
(3 phase)
4.9/ 5.8/ 6.5
7.9/ 9.6/10.5
12.0/14.7/16.0
15.8/19.3/21.0*
19.9/24.3/26.5*
002
004
005
004 &004
004 &005
—
—††
002
003
003
460/480
(3 phase)
5.5/ 6.0
10.6/11.5
12.9/14.0
21.1/23.0*
23.4/25.5*
006
008
009
008 &008
008 &009
—
—
—
—
—
007
208/230/240
(3 phase)
4.9/ 5.8/ 6.5
7.9/ 9.6/10.5
12.0/14.7/16.0
15.8/19.3/21.0*
19.9/24.3/26.5*
002
004
005
004 &004
004 &006
—***
002
002
003
003
460/480
(3 phase)
5.5/ 6.0
10.6/11.5
12.9/14.0
21.1/23.0*
23.4/25.5*
006
008
009
008 &008
008 &009
—
—
—
—
—

10
Table 3A — Electrical Data (Units Without Electrical Convenience Outlet)
NOTE: Legend and Notes for Electrical Data are on page 12.
50TFQ
UNIT
SIZE
NOMINAL
V-PH-Hz
IFM
TYPE
VOLTAGE
RANGE
COMPRESSOR
(each) OFM
FLA
IFM
FLA
ELECTRIC
HEAT* POWER SUPPLY DISCONNECT SIZE†
Min Max RLA LRA Nominal
kW** FLA MCA MOCP FLA LRA
004
(3 Tons)
208/230-1-60
STD 187 254 16.4 96.0 1.5 3.1
— — 25.5/ 25.5 30/ 30†† 25/ 25 107/107
3.3/ 4.4 15.9/18.3 45.4/ 48.4 50/ 50†† 43/ 46 123/125
4.9/ 6.5 23.6/27.1 55.0/ 59.4 60/ 60†† 52/ 56 131/184
6.5/ 8.7 31.3/36.3 64.6/ 70.9 70/ 80 61/ 66 138/143
7.9/10.5 38.0/43.8 73.0/ 80.3 80/ 90 68/ 75 145/151
9.8/13.0 47.1/54.2 84.4/ 93.3 90/100 79/ 87 154/161***
ALT 187 254 16.4 96.0 1.5 4.9
— — 26.9/ 26.9 30/ 30†† 26/ 26 111/111
3.3/ 4.4 15.9/18.3 46.8/ 49.8 50/ 50†† 45/ 47 127/130
4.9/ 6.5 23.6/27.1 56.4/ 60.8 60/ 70 53/ 57 135/138
6.5/ 8.7 31.3/36.3 66.0/ 72.3 70/ 80 62/ 68 143/148
7.9/10.5 38.0/43.8 74.4/ 81.7 80/ 90 70/ 77 149/155
9.8/13.0 47.1/54.2 85.8/ 94.7 90/100 80/ 89 158/166***
208/230-3-60
STD 187 254 10.2 75.0 1.5 3.1
— — 17.8/ 17.8 20/ 20†† 17/ 17 86/ 86
3.3/ 4.4 9.2/10.6 29.3/ 31.0 30/ 35†† 28/ 30 95/ 97
4.9/ 6.5 13.6/15.6 34.8/ 37.3 35/ 40†† 33/ 35 100/102
6.5/ 8.7 18.0/20.9 40.3/ 43.9 45/ 45†† 38/ 42 104/107
7.9/10.5 21.9/25.3 45.1/ 49.4 50/ 50†† 43/ 47 108/111
12.0/16.0 33.3/38.5 59.4/ 65.9 60/ 70 56/ 62 119/124
ALT 187 254 10.2 75.0 1.5 4.9
— — 19.2/ 19.2 20/ 20†† 19/ 19 90/ 90
3.3/ 4.4 9.2/10.6 30.7/ 32.4 35/ 35†† 30/ 31 100/101
4.9/ 6.5 13.6/15.6 36.2/ 38.7 40/ 40†† 35/ 37 104/106
6.5/ 8.7 18.0/20.9 41.7/ 45.3 45/ 50†† 40/ 43 108/111
7.9/10.5 21.9/25.3 46.5/ 50.8 50/ 60†† 44/ 48 112/116
12.0/16.0 33.3/38.5 60.8/ 67.3 70/ 70 57/ 63 124/129
HIGH-STATIC 187 254 10.2 75.0 1.5 5.8
— — 20.1/ 20.1 25/ 25†† 20/ 20 120/120
3.3/ 4.4 9.2/10.6 31.6/ 33.3 35/ 35†† 31/ 32 129/130
4.9/ 6.5 13.6/15.6 37.1/ 39.6 40/ 40†† 36/ 38 133/135
6.5/ 8.7 18.0/20.9 42.6/ 46.2 45/ 50†† 41/ 44 138/141
7.9/10.5 21.9/25.3 47.4/ 51.7 50/ 60†† 45/ 49 142/145
12.0/16.0 33.3/38.5 61.7/ 68.2 70/ 70 58/ 64 153/158
460-3-60
STD 414 508 4.8 40.0 0.8 1.7
— — 8.1 15†† 8 45
6.0 7.2 17.1 20†† 16 52
8.8 10.6 21.4 25†† 20 55
11.5 13.8 25.4 30†† 24 59
14.0 16.8 29.1 30†† 27 62
ALT 414 508 4.8 40.0 0.8 2.1
— — 8.9 15†† 9 48
6.0 7.2 17.9 20†† 17 55
8.8 10.6 22.2 25†† 21 59
11.5 13.8 26.2 30†† 25 62
14.0 16.8 29.9 30†† 28 65
HIGH-STATIC 414 508 4.8 40.0 0.8 2.6
— — 9.4 15†† 9 62
6.0 7.2 18.4 20†† 18 70
8.8 10.6 22.7 25†† 22 73
11.5 13.8 26.7 30†† 25 76
14.0 16.8 30.4 35†† 29 79
575-3-60
STD 518 632 3.8 31.0 0.8 1.7 — — 6.4 15†† 6 35
ALT 518 632 3.8 31.0 0.8 2.1 — — 7.1 15†† 7 37
HIGH-STATIC 518 632 3.8 31.0 0.8 2.6 — — 7.5 15†† 7 49
005
(4 Tons)
208/230-1-60
STD 187 254 29.1 132.0 1.5 3.5
— — 41.4/ 41.4 45/ 45†† 39/ 39 143/143
3.3/ 4.4 15.9/18.3 61.3/ 64.3 70/ 70 58/ 60 159/161
6.5/ 8.7 31.3/36.3 80.5/ 86.8 90/ 90 75/ 81 174/179
9.8/13.0 47.1/54.2 100.3/109.1 110/110 93/102 190/197
13.1/17.4 63.0/72.5 120.1/132.0 125/150 112/123 206/215
15.8/21.0 76.0/87.5 136.4/150.8 150/175 127/140 219/230
ALT 187 254 29.1 132.0 1.5 4.9
— — 42.8/ 42.8 45/ 45†† 41/ 41 147/147
3.3/ 4.4 15.9/18.3 62.7/ 65.7 70/ 70 59/ 62 163/166
6.5/ 8.7 31.3/36.3 81.9/ 88.2 90/ 90 77/ 83 179/184
9.8/13.0 47.1/54.2 107.7/110.5 110/125 95/103 194/202
13.1/17.4 63.0/72.5 121.5/133.4 125/150 113/124 210/220
15.8/21.0 76.0/87.5 137.8/152.2 150/175 128/141 223/235
208/230-3-60
STD 187 254 16.8 91.0 1.5 3.5
— — 26.0/ 26.0 30/ 30†† 25/ 25 102/102
4.9/ 6.5 13.6/15.6 43.0/ 45.5 45/ 50†† 41/ 43 115/117
6.5/ 8.7 18.0/20.9 48.5/ 52.1 50/ 60†† 46/ 49 120/123
12.0/16.0 33.3/38.5 67.6/ 74.1 70/ 80 63/ 69 135/140
15.8/21.0 43.9/50.5 80.9/ 89.1 90/ 90 76/ 83 146/152
ALT 187 254 16.8 91.0 1.5 4.9
— — 27.4/ 27.4 30/ 30†† 27/ 27 106/106
4.9/ 6.5 13.6/15.6 44.4/ 46.9 45/ 50†† 42/ 45 120/122
6.5/ 8.7 18.0/20.9 49.9/ 53.5 50/ 60†† 47/ 51 124/127
12.0/16.0 33.3/38.5 69.0/ 75.5 70/ 80 65/ 71 140/145
15.8/21.0 43.9/50.5 82.3/ 90.5 90/100 77/ 85 150/157
HIGH-STATIC 187 254 16.8 91.0 1.5 5.8
— — 28.3/ 28.3 30/ 30†† 28/ 28 136/136
4.9/ 6.5 13.6/15.6 45.3/ 47.8 50/ 50†† 43/ 46 149/151
6.5/ 8.7 18.0/20.9 50.8/ 54.4 60/ 60†† 48/ 52 154/157
12.0/16.0 33.3/38.5 69.9/ 76.4 70/ 80 66/ 72 169/174
15.8/21.0 43.9/50.5 83.2/ 91.4 90/100 78/ 86 180/186***

11
Table 3A — Electrical Data (Units Without Electrical Convenience Outlet) (cont)
NOTE: Legend and Notes for Electrical Data are on page 12.
50TFQ
UNIT
SIZE
NOMINAL
V-PH-Hz
IFM
TYPE
VOLTAGE
RANGE
COMPRESSOR
(each) OFM
FLA
IFM
FLA
ELECTRIC
HEAT* POWER SUPPLY DISCONNECT SIZE†
Min Max RLA LRA Nominal
kW** FLA MCA MOCP FLA LRA
005
(4 Tons)
(cont)
460-3-60
STD 414 508 8.4 50.0 0.8 1.8
— — 13.1 15†† 13 56
6.0 7.2 22.1 25†† 21 63
11.5 13.8 30.4 35†† 29 70
14.0 16.8 34.1 35†† 32 73
23.0 27.7 47.7 50†† 45 84
ALT 414 508 8.4 50.0 0.8 2.1
— — 13.4 15†† 13 58
6.0 7.2 22.4 25†† 21 65
11.5 13.8 30.7 35†† 29 72
14.0 16.8 34.4 35†† 32 75
23.0 27.7 48.0 50†† 45 86
HIGH-STATIC 414 508 8.4 50.0 0.8 2.6
— — 13.9 15†† 14 72
6.0 7.2 22.9 25†† 22 80
11.5 13.8 31.2 35†† 29 86
14.0 16.8 34.9 35†† 33 89
23.0 27.7 48.5 50†† 45 100
575-3-60
STD 518 632 6.7 37.0 0.8 1.8 — — 10.5 15†† 10 42
ALT 518 632 6.7 37.0 0.8 2.1 — — 10.7 15†† 10 43
HIGH-STATIC 518 632 6.7 37.0 0.8 2.6 — — 11.1 15†† 11 55
006
(5 Tons)
208/230-1-60
STD 187 254 26.7 170.0 1.5 5.9
— — 40.8/ 40.8 45/ 45†† 39/ 39 184/184
4.9/ 6.5 23.6/27.1 70.3/ 74.7 80/ 80 66/ 70 208/211
6.5/ 8.7 31.3/36.3 79.9/ 86.2 80/ 90 75/ 81 215/220***
9.8/13.0 47.1/54.2 99.7/108.5 100/110 93/102 231/238***
13.1/17.4 63.0/72.5 119.5/131.4 125/150 112/123 247/257***
15.8/21.0 76.0/87.5 135.8/150.2 150/175 127/140 260/272***
ALT 187 254 26.7 170.0 1.5 8.8
— — 48.5/ 48.5 50/ 50†† 48/ 48 222/222
4.9/ 6.5 23.6/27.1 78.0/ 82.4 80/ 90 75/ 79 246/249
6.5/ 8.7 31.3/36.3 87.6/ 93.9 90/100 84/ 90 253/258***
9.8/13.0 47.1/54.2 107.4/116.2 110/125 102/110 269/276***
13.1/17.4 63.0/72.5 127.2/139.1 150/150 121/131 285/294***
15.8/21.0 76.0/87.5 143.5/157.9 150/175 135/149 298/309***
208/230-3-60
STD 187 254 15.4 124.0 1.5 5.9
— — 26.7/ 26.7 30/ 30†† 26/ 26 138/138
4.9/ 6.5 13.6/15.6 43.7/ 46.2 45/ 50†† 42/ 44 152/154
7.9/10.5 21.9/25.3 54.0/ 58.3 60/ 60†† 51/ 55 160/163
12.0/16.0 33.3/38.5 68.3/ 74.8 70/ 80 65/ 70 171/177
15.8/21.0 43.9/50.5 81.5/ 89.8 90/ 90 77/ 84 182/189***
19.9/26.5 55.2/63.8 95.7/106.4 100/110 90/100 193/202***
ALT 187 254 15.4 124.0 1.5 5.8
— — 26.6/ 26.6 30/ 30†† 26/ 26 169/169
4.9/ 6.5 13.6/15.6 43.6/ 46.1 45/ 50†† 42/ 44 182/184
7.9/10.5 21.9/25.3 53.9/ 58.2 60/ 60 51/ 55 191/194
12.0/16.0 33.3/38.5 68.2/ 74.7 70/ 80 64/ 70 202/207
15.8/21.0 43.9/50.5 81.4/ 89.7 90/ 90 77/ 84 213/219***
19.9/26.5 55.2/63.8 95.6/106.3 100/110 90/ 99 224/233***
HIGH-STATIC 187 254 15.4 124.0 1.5 7.5
— — 28.3/ 28.3 30/ 30†† 28/ 28 188/188
4.9/ 6.5 13.6/15.6 45.3/ 47.8 50/ 50†† 44/ 46 201/203
7.9/10.5 21.9/25.3 55.6/ 59.9 60/ 60†† 53/ 57 210/213
12.0/16.0 33.3/38.5 69.9/ 76.4 70/ 80 66/ 72 221/226
15.8/21.0 43.9/50.5 83.1/ 91.4 90/100 79/ 86 232/238***
19.9/26.5 55.2/63.8 97.3/108.0 100/110 92/101 243/252***
460-3-60
STD 414 508 7.7 59.6 0.8 3.2
— — 13.6 15†† 13 67
6.0 7.2 22.6 25†† 22 75
11.5 13.8 30.9 35†† 29 81
14.0 16.8 34.6 35†† 33 84
23.0 27.7 48.3 50†† 45 95
25.5 30.7 52.0 60†† 49 98
ALT 414 508 7.7 59.6 0.8 2.6
— — 13.0 15†† 13 82
6.0 7.2 22.0 25†† 21 89
11.5 13.8 30.3 35†† 29 96
14.0 16.8 34.0 35†† 32 99
23.0 27.7 47.7 50†† 45 110
25.5 30.7 51.4 60†† 48 113
HIGH-STATIC 414 508 7.7 59.6 0.8 3.4
— — 13.8 15†† 14 92
6.0 7.2 22.8 25†† 22 99
11.5 13.8 31.1 35†† 30 105
14.0 16.8 34.8 35†† 33 108
23.0 27.7 48.5 50†† 46 119
25.5 30.7 52.2 60†† 49 122
575-3-60
STD 518 632 6.2 49.4 0.8 3.2 — — 11.0 15†† 11 56
ALT 518 632 6.2 49.4 0.8 2.6 — — 10.5 15†† 10 67
HIGH-STATIC 518 632 6.2 49.4 0.8 3.4 — — 11.1 15†† 11 75

12
Table 3A — Electrical Data (Units Without Electrical Convenience Outlet) (cont)
LEGEND
*Heaters are field installed only.
†Used to determine minimum disconnect size per NEC.
**Heater capacity (kW) is based on heater voltage of 208 v, 240 v and 480 v.
If power distribution voltage to unit varies from rated heater voltage, heater
kW will vary accordingly.
††Fuse or HACR circuit breaker.
***Optional disconnect switch is unavailable.
NOTES:
1. In compliance with NEC requirements for multimotor and combination load
equipment (refer to NEC Articles 430 and 440), the overcurrent protective
device for the unit shall be fuse or HACR breaker.
2. Unbalanced 3-Phase Supply Voltage
Never operate a motor where a phase imbalance in supply voltage is
greater than 2%.
Use the following formula to determine the percent of volt-
age imbalance.
%Voltage Imbalance
Example: Supply voltage is 460-3-60.
AB =452 v
BC =464 v
AC =455 v
Determine maximum deviation from average voltage.
(AB) 457 – 452 =5v
(BC) 464 – 457 =7v
(AC) 457 – 455 =2v
Maximum deviation is 7 v.
Determine percent of voltage imbalance.
%Voltage Imbalance =100 x
=1.53%
This amount of phase imbalance is satisfactory as it is below the maximum
allowable 2%.
50TFQ
UNIT
SIZE
NOMINAL
V-PH-Hz
IFM
TYPE
VOLTAGE
RANGE
COMPRESSOR
(each) OFM
FLA
IFM
FLA
ELECTRIC HEAT* POWER SUPPLY DISCONNECT
SIZE†
Min Max RLA LRA Nominal
kW** FLA MCA MOCP FLA LRA
007
(6 Tons)
208/230-3-60
STD 187 254 22.7 146.0 1.4 5.8
— — 35.6/ 35.6 40/ 40†† 34/ 34 190/190
4.9/ 6.5 13.6/15.6 52.6/ 55.1 60/ 60†† 50/ 52 204/206
7.9/10.5 21.9/25.3 63.0/ 67.2 70/ 70 60/ 63 212/215
12.0/16.0 33.3/38.5 77.2/ 83.7 80/ 90 73/ 79 223/229
15.8/21.0 43.9/50.5 90.5/ 98.7 100/100 85/ 92 234/241***
19.9/26.5 55.2/63.8 104.6/115.3 110/125 98/108 245/254***
HIGH-STATIC 187 254 22.7 146.0 1.4 7.5
— — 37.3/ 37.3 40/ 40†† 36/ 36 209/209
4.9/ 6.5 13.6/15.6 54.3/ 56.8 60/ 60†† 52/ 54 223/225
7.9/10.5 21.9/25.3 64.7/ 68.9 70/ 70 62/ 65 231/234
12.0/16.0 33.3/38.5 78.9/ 85.4 80/ 90 75/ 81 242/248***
15.8/21.0 43.9/50.5 92.2/100.4 100/110 87/ 94 253/260***
19.9/26.5 55.2/63.8 106.3/117.0 110/125 100/110 264/273***
460-3-60
STD 414 508 11.4 73.0 0.7 2.6
— — 17.6 20†† 17 95
6.0 7.2 26.6 30†† 25 102
11.5 13.8 34.8 35†† 33 109
14.0 16.8 38.6 40†† 36 112
23.0 27.7 52.2 60†† 49 123
25.5 30.7 55.9 60†† 52 126
HIGH-STATIC 414 508 11.4 73.0 0.7 3.4
— — 18.4 20†† 18 105
6.0 7.2 27.4 30†† 26 112
11.5 13.8 35.6 40†† 34 118
14.0 16.8 39.4 40†† 37 121
23.0 27.7 53.0 60†† 50 132
25.5 30.7 56.7 60†† 53 135
575-3-60 STD 518 632 9.1 58.4 0.7 2.6 — — 14.0 15†† 14 76
HIGH-STATIC 518 632 9.1 58.4 0.7 3.4 — — 14.7 15†† 14 84
FLA — Full Load Amps
HACR — Heating, Air Conditioning and Refrigeration
IFM — Indoor Fan Motor
LRA — Locked Rotor Amps
MCA — Minimum Circuit Amps
MOCP — Maximum Overcurrent Protection
NEC — National Electrical Code
OFM — Outdoor Fan Motor
RLA — Rated Load Amps
=100 x max voltage deviation from average voltage
average voltage
Average Voltage =452 +464 +455
3
=1371
3
=457
IMPORTANT: If the supply voltage phase imbalance is more than 2%,con-
tact your local electric utility company immediately.
7
457

13
Table 3B — Electrical Data (Units With Electrical Convenience Outlet)
NOTE: Legend and Notes for Electrical Data are on page 15.
50TFQ
UNIT
SIZE
NOMINAL
V-PH-Hz
IFM
TYPE
VOLTAGE
RANGE
COMPRESSOR
(each) OFM
FLA
IFM
FLA
ELECTRIC
HEAT* POWER SUPPLY DISCONNECT SIZE†
Min Max RLA LRA Nominal
kW** FLA MCA MOCP FLA LRA
004
(3 Tons)
208/230-1-60
STD 187 254 16.4 96.0 1.5 3.1
— — 30.3/ 30.3 35/ 35†† 30/ 30 112/112
3.3/ 4.4 15.9/18.3 50.2/ 53.2 60/ 60†† 48/ 51 128/130
4.9/ 6.5 23.6/27.1 59.8/ 64.2 60/ 70 57/ 61 135/139
6.5/ 8.7 31.3/36.3 69.4/ 75.7 70/ 80 66/ 72 143/148
7.9/10.5 38.0/43.8 77.8/ 85.1 80/ 90 74/ 81 150/156***
9.8/13.0 47.1/54.2 89.2/ 98.1 90/100 84/ 92 159/166***
ALT 187 254 16.4 96.0 1.5 4.9
— — 31.7/ 31.7 35/ 35†† 32/ 32 116/116
3.3/ 4.4 15.9/18.3 51.6/ 54.6 60/ 60†† 50/ 53 132/134
4.9/ 6.5 23.6/27.1 61.2/ 65.6 70/ 70 59/ 63 140/143
6.5/ 8.7 31.3/36.3 70.8/ 77.1 80/ 80 68/ 73 147/152
7.9/10.5 38.0/43.8 79.2/ 86.5 80/ 90 75/ 82 154/160***
9.8/13.0 47.1/54.2 90.6/ 99.5 100/110 86/ 94 163/170***
208/230-3-60
STD 187 254 10.2 75.0 1.5 3.1
— — 22.6/ 22.6 25/ 25†† 23/ 23 91/ 91
3.3/ 4.4 9.2/10.6 34.1/ 35.8 35/ 40†† 34/ 35 100/101
4.9/ 6.5 13.6/15.6 39.6/ 42.1 40/ 45†† 39/ 41 104/106
8.5/ 8.7 18.0/20.9 45.1/ 48.7 50/ 50†† 44/ 47 109/112
7.9/10.5 21.9/25.3 49.9/ 54.2 50/ 60†† 48/ 52 113/116
12.0/16.0 33.3/38.5 64.2/ 70.7 70/ 80†† 61/ 67 124/129
ALT 187 254 10.2 75.0 1.5 4.9
— — 24.0/ 24.0 30/ 30†† 25/ 25 95/ 95
3.3/ 4.4 9.2/10.6 35.5/ 37.2 40/ 40†† 35/ 37 104/106
4.9/ 6.5 13.6/15.6 41.0/ 43.5 45/ 45†† 40/ 43 109/111
6.5/ 8.7 18.0/20.9 46.5/ 50.1 50/ 60†† 45/ 49 113/116
7.9/10.5 21.9/25.3 51.3/ 55.6 60/ 60†† 50/ 54 117/120
12.0/16.0 33.3/38.5 65.6/ 72.1 70/ 80 63/ 69 128/134
HIGH-STATIC 187 254 10.2 75.0 1.5 5.8
— — 24.9/ 24.9 25/ 25†† 26/ 26 125/125
3.3/ 4.4 9.2/10.6 36.4/ 38.1 40/ 40†† 36/ 38 134/135
4.9/ 6.5 13.6/15.6 41.9/ 44.4 45/ 45†† 41/ 44 138/140
6.5/ 8.7 18.0/20.9 47.4/ 51.0 50/ 60†† 46/ 50 143/145
7.9/10.5 21.9/25.3 52.2/ 56.5 60/ 60†† 51/ 55 146/150
12.0/16.0 33.3/38.5 66.5/ 73.0 70/ 80 64/ 70 158/163
460-3-60
STD 414 508 4.8 40.0 0.8 1.7
— — 10.3 15†† 10 47
6.0 7.2 19.3 20†† 19 54
8.8 10.6 23.5 25†† 23 58
11.5 13.8 27.5 30†† 26 61
14.0 16.8 31.3 35†† 30 64
ALT 414 508 4.8 40.0 0.8 2.1
— — 11.1 15†† 11 50
6.0 7.2 20.1 25†† 20 57
8.8 10.6 24.3 25†† 24 61
11.5 13.8 28.3 30†† 27 64
14.0 16.8 32.1 35†† 31 67
HIGH-STATIC 414 508 4.8 40.0 0.8 2.6
— — 11.6 15†† 12 65
6.0 7.2 20.6 25†† 20 72
8.8 10.6 24.8 25†† 24 75
11.5 13.8 28.8 30†† 28 78
14.0 16.8 32.6 35†† 31 81
575-3-60
STD 518 632 3.8 31.0 0.8 1.7 — — 8.2 15†† 8 37
ALT 518 632 3.8 31.0 0.8 2.1 — — 8.8 15†† 9 39
HIGH-STATIC 518 632 3.8 31.0 0.8 2.6 — — 9.2 15†† 9 51
005
(4 Tons)
208/230-1-60
STD 187 254 29.1 132.0 1.5 3.5
— — 46.2/ 46.2 50/ 50†† 45/ 45 148/148
3.3/ 4.4 15.9/18.3 66.1/ 69.1 70/ 70 63/ 66 163/166
6.5/ 8.7 31.3/36.3 85.3/ 91.6 90/100 81/ 86 179/184
9.8/13.0 47.1/54.2 105.1/113.9 110/125 99/107 195/202
13.1/17.4 63.0/72.5 124.1/136.8 125/150 117/128 211/220
15.8/21.0 76.0/87.5 141.2/155.6 150/175 132/145 224/235
ALT 187 254 29.1 132.0 1.5 4.9
— — 47.6/ 47.6 50/ 50†† 46/ 46 152/152
3.3/ 4.4 15.9/18.3 67.5/ 70.5 70/ 80 65/ 67 168/170
6.5/ 8.7 31.3/36.3 86.7/ 93.0 90/100 82/ 88 183/188
9.8/13.0 47.1/54.2 106.5/115.3 110/125 101/109 199/206
13.1/17.4 63.0/72.5 126.3/138.2 150/150 119/130 215/225
15.8/21.0 76.0/87.5 142.6/157.0 150/175 134/147 228/240
208/230-3-60
STD 187 254 16.8 91.0 1.5 3.5
— — 30.8/ 30.8 35/ 35†† 31/ 31 107/107
4.9/ 6.5 13.6/15.6 47.8/ 50.3 50/ 60†† 46/ 49 120/122
6.5/ 8.7 18.0/20.9 53.3/ 56.9 60/ 60†† 51/ 55 125/127
12.0/16.0 33.3/38.5 72.4/ 78.9 80/ 80 69/ 75 140/145
15.8/21.0 43.9/50.5 85.7/ 93.9 90/100 81/ 89 150/157
ALT 187 254 16.8 91.0 1.5 4.9
— — 32.2/ 32.2 35/ 35†† 32/ 32 111/111
4.9/ 6.5 13.6/15.6 49.2/ 51.7 50/ 60†† 48/ 50 125/127
6.5/ 8.7 18.0/20.9 54.7/ 58.3 60/ 60†† 53/ 56 129/132
12.0/16.0 33.3/38.5 73.8/ 80.3 80/ 90 71/ 76 144/150
15.8/21.0 43.9/50.5 87.1/ 95.3 90/100 83/ 90 155/162
HIGH-STATIC 187 254 16.8 91.0 1.5 5.8
— — 33.1/ 33.1 35/ 35†† 33/ 33 141/141
4.9/ 6.5 13.6/15.6 50.1/ 52.6 60/ 60†† 49/ 51 154/156
6.5/ 8.7 18.0/20.9 55.6/ 59.2 60/ 60†† 54/ 57 159/161
12.0/16.0 33.3/38.5 74.7/ 81.2 80/ 90 72/ 78 174/179
15.8/21.0 43.9/50.5 88.0/ 96.2 90/100 84/ 91 184/191***

14
Table 3B — Electrical Data (Units With Electrical Convenience Outlet) (cont)
NOTE: Legend and Notes for Electrical Data are on page 15.
50TFQ
UNIT
SIZE
NOMINAL
V-PH-Hz
IFM
TYPE
VOLTAGE
RANGE
COMPRESSOR
(each) OFM
FLA
IFM
FLA
ELECTRIC
HEAT* POWER SUPPLY DISCONNECT SIZE†
Min Max RLA LRA Nominal
kW** FLA MCA MOCP FLA LRA
005
(4 Tons)
(cont)
460-3-60
STD 414 508 8.4 50.0 0.8 1.8
— — 15.3 20†† 15 58
6.0 7.2 24.3 25†† 23 66
11.5 13.8 32.5 35†† 31 72
14.0 16.8 36.3 40†† 34 75
23.0 27.7 49.9 50†† 47 86
ALT 414 508 8.4 50.0 0.8 2.1
— — 15.6 20†† 15 60
6.0 7.2 24.6 25†† 24 67
11.5 13.8 32.8 35†† 31 74
14.0 16.8 36.6 40†† 35 77
23.0 27.7 50.2 60†† 47 88
HIGH-STATIC 414 508 8.4 50.0 0.8 2.6
— — 16.1 20†† 16 75
6.0 7.2 25.1 30†† 24 82
11.5 13.8 33.3 35†† 32 88
14.0 16.8 37.1 40†† 35 91
23.0 27.7 50.7 60†† 48 102
575-3-60
STD 518 632 6.7 37.0 0.8 1.8 — — 12.2 15†† 12 44
ALT 518 632 6.7 37.0 0.8 2.1 — — 12.4 15†† 12 45
HIGH-STATIC 518 632 6.7 37.0 0.8 2.6 — — 12.8 15†† 13 57
006
(5 Tons)
208/230-1-60
STD 187 254 26.7 170.0 1.5 5.9
— — 45.6/ 45.6 50/ 50†† 45/ 45 189/189
4.9/ 6.5 23.6/27.1 75.1/ 79.5 80/ 80 72/ 76 213/216
6.5/ 8.7 31.3/36.3 84.7/ 91.0 90/100 81/ 86 220/225***
9.8/13.0 47.1/54.2 104.3/113.3 110/125 99/107 236/243***
13.1/17.4 63.0/72.5 124.3/136.2 125/150 117/128 252/261***
15.8/21.0 76.0/87.5 140.6/155.0 150/175 132/145 265/276***
ALT 187 254 26.7 170.0 1.5 8.8
— — 48.5/ 48.5 50/ 50†† 48/ 48 222/222
4.9/ 6.5 23.6/27.1 78.0/ 82.4 80/ 90 75/ 79 246/249
6.5/ 8.7 31.3/36.3 87.6/ 93.9 90/100 84/ 90 253/258***
9.8/13.0 47.1/54.2 107.4/116.2 110/125 102/110 269/276***
13.1/17.4 63.0/72.5 127.2/139.1 150/150 121/131 285/294***
15.8/21.0 76.0/87.5 143.5/157.9 150/175 135/149 298/309***
208/230-3-60
STD 187 254 15.4 124.0 1.5 5.9
— — 31.5/ 31.5 35/ 40†† 32/ 32 143/143
4.9/ 6.5 13.6/15.6 48.5/ 51.0 50/ 60†† 47/ 50 157/159
7.9/10.5 21.9/25.3 58.8/ 63.1 60/ 70 57/ 61 165/168
12.0/16.0 33.3/38.5 73.1/ 79.6 80/ 90 70/ 76 176/181
15.8/21.0 43.9/50.5 86.3/ 94.6 90/100 82/ 90 187/193***
19.9/26.5 55.2/63.8 100.5/111.2 110/125 95/105 198/207***
ALT 187 254 15.4 124.0 1.5 5.8
— — 31.4/ 31.4 35/ 35†† 32/ 32 174/174
4.9/ 6.5 13.6/15.6 48.4/ 50.9 50/ 60†† 47/ 50 187/189
7.9/10.5 21.9/25.3 58.7/ 63.0 60/ 70 57/ 61 195/199
12.0/16.0 33.3/38.5 73.0/ 79.5 80/ 80 70/ 76 207/212
15.8/21.0 43.9/50.5 86.2/ 94.5 90/100 82/ 90 217/224***
19.9/26.5 55.2/63.8 100.4/111.1 110/125 95/105 229/237***
HIGH-STATIC 187 254 15.4 124.0 1.5 7.5
— — 33.1/ 33.1 35/ 35†† 34/ 34 193/193
4.9/ 6.5 13.6/15.6 50.1/ 52.6 60/ 60†† 49/ 52 206/208
7.9/10.5 21.9/25.3 60.4/ 64.7 70/ 70 59/ 63 214/218
12.0/16.0 33.3/38.5 74.7/ 81.2 80/ 80 72/ 78 226/231
15.8/21.0 43.9/50.5 87.9/ 96.2 90/100 84/ 92 236/243***
19.9/26.5 55.2/63.8 102.1/112.8 110/125 97/107 248/256***
460-3-60
STD 414 508 7.7 59.6 0.8 3.2
— — 15.8 20†† 16 70
6.0 7.2 24.8 25†† 24 77
11.5 13.8 33.1 35†† 32 83
14.0 16.8 36.8 40†† 35 86
23.0 27.7 50.4 60†† 48 97
25.5 30.7 54.2 60†† 51 100
ALT 414 508 7.7 59.6 0.8 2.6
— — 15.2 20†† 15 84
6.0 7.2 24.2 25†† 24 91
11.5 13.8 32.5 35†† 31 98
14.0 16.8 36.2 40†† 35 101
23.0 27.7 49.8 60†† 47 112
25.5 30.7 53.6 60†† 51 115
HIGH-STATIC 414 508 7.7 59.6 0.8 3.4
— — 16.0 20†† 16 94
6.0 7.2 25.0 25†† 24 101
11.5 13.8 33.3 35†† 32 107
14.0 16.8 37.0 40†† 36 110
23.0 27.7 50.6 60†† 48 121
25.5 30.7 54.4 60†† 51 124
575-3-60
STD 518 632 6.2 49.4 0.8 3.2 — — 12.7 15†† 13 57
ALT 518 632 6.2 49.4 0.8 2.6 — — 12.2 15†† 12 69
HIGH-STATIC 518 632 6.2 49.4 0.8 3.4 — — 12.9 15†† 13 77

15
Table 3B — Electrical Data (Units With Electrical Convenience Outlet) (cont)
LEGEND
*Heaters are field installed only.
†Used to determine minimum disconnect size per NEC.
**Heater capacity (kW) is based on heater voltage of 208 v, 240 v and 480 v.
If power distribution voltage to unit varies from rated heater voltage, heater
kW will vary accordingly.
††Fuse or HACR circuit breaker.
***Optional disconnect switch is unavailable.
NOTES:
1. In compliance with NEC requirements for multimotor and combination load
equipment (refer to NEC Articles 430 and 440), the overcurrent protective
device for the unit shall be fuse or HACR breaker.
2. Unbalanced 3-Phase Supply Voltage
Never operate a motor where a phase imbalance in supply voltage is
greater than 2%.
Use the following formula to determine the percent of volt-
age imbalance.
%Voltage Imbalance
Example: Supply voltage is 460-3-60.
AB =452 v
BC =464 v
AC =455 v
Determine maximum deviation from average voltage.
(AB) 457 – 452 =5v
(BC) 464 – 457 =7v
(AC) 457 – 455 =2v
Maximum deviation is 7 v.
Determine percent of voltage imbalance.
%Voltage Imbalance =100 x
=1.53%
This amount of phase imbalance is satisfactory as it is below the maximum
allowable 2%.
50TFQ
UNIT
SIZE
NOMINAL
V-PH-Hz
IFM
TYPE
VOLTAGE
RANGE
COMPRESSOR
(each) OFM
FLA
IFM
FLA
ELECTRIC
HEAT* POWER SUPPLY DISCONNECT SIZE†
Min Max RLA LRA Nominal
kW** FLA MCA MOCP FLA LRA
007
(6 Tons)
208/230-3-60
STD 187 254 22.7 146.0 1.4 5.8
— — 40.4/ 40.4 45/ 45†† 40/ 40 195/195
4.9/ 6.5 13.6/15.6 57.4/ 59.9 60/ 60†† 56/ 58 208/211
7.9/10.5 21.9/25.3 67.8/ 72.0 70/ 80 65/ 69 217/220
12.0/16.0 33.3/38.5 82.0/ 88.5 90/ 90 78/ 84 228/233***
15.8/21.0 43.9/50.5 95.3/103.5 100/110 90/ 98 239/245***
19.9/26.5 55.2/63.8 109.4/120.1 110/125 103/113 250/259***
HIGH-STATIC 187 254 22.7 146.0 1.4 7.5
— — 42.1/ 42.1 45/ 45†† 42/ 42 214/214
4.9/ 6.5 13.6/15.6 59.1/ 61.6 60/ 70 58/ 60 227/229
7.9/10.5 21.9/25.3 69.5/ 73.7 70/ 80 67/ 71 236/239
12.0/16.0 33.3/38.5 83.7/ 90.2 90/100 80/ 86 247/252***
15.8/21.0 43.9/50.5 97.0/105.2 100/110 92/100 258/264***
19.9/26.5 55.2/63.8 111.1/121.8 125/125 105/115 269/278***
460-3-60
STD 414 508 11.4 73.0 0.7 2.6
— — 19.7 20†† 19 97
6.0 7.2 28.7 30†† 28 104
11.5 13.8 37.0 40†† 35 111
14.0 16.8 40.7 45†† 39 114
23.0 27.7 54.4 60†† 51 125
25.5 30.7 58.1 60†† 55 128
HIGH-STATIC 414 508 11.4 73.0 0.7 3.4
— — 20.5 25†† 20 107
6.0 7.2 29.5 30†† 29 114
11.5 13.8 37.8 40†† 36 121
14.0 16.8 41.5 45†† 40 124
23.0 27.7 55.2 60†† 52 134
25.5 30.7 58.9 60†† 56 137
575-3-60 STD 518 632 9.1 58.4 0.7 2.6 — — 15.8 20†† 16 78
HIGH-STATIC 518 632 9.1 58.4 0.7 3.4 — — 16.4 20†† 16 85
FLA — Full Load Amps
HACR — Heating, Air Conditioning and Refrigeration
IFM — Indoor Fan Motor
LRA — Locked Rotor Amps
MCA — Minimum Circuit Amps
MOCP — Maximum Overcurrent Protection
NEC — National Electrical Code
OFM — Outdoor Fan Motor
RLA — Rated Load Amps
=100 x max voltage deviation from average voltage
average voltage
Average Voltage =452 +464 +455
3
=1371
3
=457
IMPORTANT: If the supply voltage phase imbalance is more than 2%,con-
tact your local electric utility company immediately.
7
457

16
FIELD CONTROL WIRING — Install a Carrier-approved
accessory thermostat assembly according to installation
instructions included with the accessory. Locate the thermostat
assembly on a solid wall in the conditioned space to sense aver-
age temperature.
NOTE: If using a Carrier electronic thermostat, set the thermo-
stat configuration for “non-heat pump operation.” This family
of products does not require an O terminal to energize the
reversing valve.
Route the thermostat cable or equivalent single leads of
colored wire from the subbase terminals to the low-voltage
connections on the unit (shown in Fig. 8 and 9) as described in
Steps 1 through 3 below.
NOTE: For wire runs up to 50 ft, use no. 18 AWG (American
Wire Gage) insulated wire (35 C minimum). For 50 to 75 ft,
use no. 16 AWG insulated wire (35 C minimum). For over
75 ft, use no. 14 AWG insulated wire (35 C minimum). All
wire larger than no. 18 AWG cannot be directly connected to
the thermostat and will require a junction box and splice at the
thermostat.
1. Connect the thermostat wires to the screw terminals of
the low voltage connection board.
2. Pass the control wires through the hole provided in the
corner post.
3. Feed the wire through the raceway built into the corner
post to the 24-v barrier located on the left side of the
control box. See Fig. 10. The raceway provides the UL-
required clearance between the high-voltage and low-
voltage wiring.
DEFROST BOARD — The defrost board timer is set for a
30 minute defrost cycle from the factory. To adjust to a 50 or
90 minute cycle, remove the wire connected to the 30 minute
quick connect on the defrost board. See Fig. 11. Connect the
lead to the 50 or 90 minute quick connect on the defrost board,
depending on the application.
HEAT ANTICIPATOR SETTINGS — Set the first-stage
heat anticipator setting at 0.8 and set the second-stage heat
anticipator setting at 0.3.
WIRE
CONNECTIONS
TO
LOW-VOLTAGE
SECTION
(CONNECTION
BOARD)
COOL STAGE 1
FAN
HEAT STAGE 1
COOL STAGE 2
HEAT STAGE 2
24 VAC HOT
24 VAC COM
N/A
OUTDOOR AIR
SENSOR
Y1/W2
G
W/W1
Y/Y2
O/W2
R
C
S1
S2
THERMOSTAT DIPSWITCH SETTINGS
R
G
Y1
Y2
W1
W2
C
IPD/X
ON
OFF
ABCD
LEGEND
NOTE: Underlined letter indicates active thermostat output when
configured for A/C operation.
Fig. 8 — Low-Voltage Connections With or
Without Economizer or Two-Position Damper
Field Wiring
W2
C
Y1
G
R
Y2
W1
C
G
R
Y2
W1
X
W2
C
Y1
G
R
Y2
W1
X
24 VAC
RMTOCC
CMPSAFE
FSD
NOT USED
C
X
SFS
THERMOSTAT CONTROL
CONNECTION
BOARD
BOARD
CONNECTION
CONTROL
Fig. 9 — Low Voltage Connections
(Units with PremierLink™ Controls)
Fig. 10 — Field Control Wiring Raceway
Fig. 11 — Defrost Board

17
Step 6 — Adjust Factory-Installed Options
DISCONNECT SWITCH — The optional disconnect switch
is non-fused. The switch can be locked in place for safety
purposes. The disconnect switch is only available for limited
applications. See electrical data tables on pages 10-15 for dis-
connect switch usage.
CONVENIENCE OUTLET — An optional convenience out-
let provides power for rooftop use. For maintenance personnel
safety, the convenience outlet power is off when the unit dis-
connect is off. Adjacent unit outlets may be used for service
tools. An optional “Hot Outlet” is available from the factory as
a special order item.
NOVAR CONTROLS — Optional Novar controls (ETM 3051)
are available for replacement or new construction jobs.
MANUAL OUTDOOR-AIR DAMPER — The outdoor-air
hood and screen are attached to the basepan at the bottom of
the unit (for shipping).
Assembly:
1. Determine the amount of ventilation required for build-
ing. Record the amount for use in Step 8.
2. Remove the filter access panel by raising the panel and
swinging it outward. The panel is now disengaged from
the track and can be removed. No tools are required to
remove the filter access panel. Remove the outdoor-air
opening panel. Save the panels and screws. See Fig. 12.
3. Separate the hood and screen from the basepan by remov-
ing the screws and brackets securing them. Save all
screws and discard the brackets.
4. Replace the outdoor air opening panel.
5. Place the hood on the front of the outdoor air opening
panel. See Fig. 13 for hood details. Secure the top of the
hood with the 6 screws removed in Step 3. See Fig. 14.
6. Remove and save the 8 screws (4 on each side) from the
sides of the manual outdoor-air damper.
7. Align the screw holes on the hood with the screw holes
on the side of the manual outdoor-air damper. See Fig. 13
and 14. Secure the hood with the 8 screws from Step 6.
8. Adjust the minimum position setting of the damper blade
by adjusting the manual outdoor-air adjustment screws on
the front of the damper blade. See Fig. 12. Slide the blade
vertically until it is in the appropriate position determined
by Fig. 15. Tighten the screws.
9. Remove and save the screws currently on the sides of
hood. Insert the screen. Secure the screen to the hood us-
ing the screws. See Fig. 14.
10. Replace the filter access panel. Ensure that the filter
access panel slides along the tracks and is securely
engaged.
SCREWS
(SIDE)
MANUAL
OUTDOOR-AIR
ADJUSTMENT
SCREWS DAMPER
BLADE
FILTER
ACCESS
PANEL
OUTDOOR AIR
OPENING
PANEL
Fig. 12 — Damper Panel with Manual
Outdoor-Air Damper Installed
Fig. 13 — Outdoor-Air Hood Details

18
PREMIERLINK™ CONTROL — The PremierLink control-
ler is compatible with Carrier Comfort Network® (CCN) de-
vices. This control is designed to allow users the access and
ability to change factory-defined settings, thus expanding the
function of the standard unit control board. Carrier’s diagnostic
standard tier display tools such as Navigator™ or Scrolling
Marquee can be used with the PremierLink controller.
The PremierLink controller (see Fig. 16 and 17) requires the
use of a Carrier electronic thermostat or a CCN connection for
time broadcast to initiate its internal timeclock. This is neces-
sary for broadcast of time of day functions (occupied/
unoccupied). No sensors are supplied with the field-mounted
PremierLink control. The factory-installed PremierLink con-
trol includes only the supply-air temperature (SAT) sensor and
the outdoor air temperature (OAT) sensor as standard. An in-
door air quality (CO2) sensor can be added as an option. Refer
to Table 4 for sensor usage. Refer to Fig. 18 for PremierLink
controller wiring. The PremierLink control may be mounted in
the control panel or an area below the control panel.
NOTE: PremierLink controller versions 1.3 and later are
shippedinSensormode.Ifusedwithathermostat,thePre-
mierLink controller must be configured to Thermostat mode.
Install the Supply Air Temperature (SAT) Sensor —When
the unit is supplied with a factory-mounted PremierLink con-
trol, the supply-air temperature (SAT) sensor (33ZCSENSAT)
is factory-supplied and wired. The wiring is routed from the
PremierLink control over the control box, through a grommet,
into the fan section, down along the back side of the fan, and
along the fan deck over to the supply-air opening.
The SAT probe is wire-tied to the supply-air opening (on the
horizontal opening end) in its shipping position. Remove the
sensor for installation. Re-position the sensor in the flange of
the supply-air opening or in the supply air duct (as required by
local codes). Drill or punch a 1/2-in. hole in the flange or duct.
Use two field-supplied, self-drilling screws to secure the sensor
probe in a horizontal orientation.
NOTE: The sensor must be mounted in the discharge airstream
downstream of the cooling coil and any heating devices. Be
sure the probe tip does not come in contact with any of the unit
or heat surfaces.
Outdoor Air Temperature (OAT) Sensor — When the unit is
supplied with a factory-mounted PremierLink control, the
outdoor-air temperature (OAT) sensor is factory-supplied and
wired.
Install the Indoor Air Quality (CO2)Sensor — Mount the
optional indoor air quality (CO2) sensor according to manufac-
turer specifications.
A separate field-supplied transformer must be used to pow-
er the CO2sensor.
Wire the CO2sensor to the COM and IAQI terminals of J5
on the PremierLink controller. Refer to the PremierLink Instal-
lation, Start-up, and Configuration Instructions for detailed
wiring and configuration information.
SCREW
HOLES
(TOP)
HOOD
HOOD
SCREEN
LOCATION
(SCREEN
NOT
SHOWN)
Fig. 14 — Optional Manual Outdoor-Air
Damper with Hood Attached
Fig. 15 — Outdoor Air Damper Position Setting

19
Fig. 16 — PremierLink™ Controller
PREMIERLINK
CONTROL
HINGED
DOOR
PANEL
Fig. 17 — PremierLink Controller (Installed)

20
Table 4 — PremierLink™ Sensor Usage
*PremierLink control requires Supply Air Temperature sensor 33ZCSENSAT and
Outdoor Air Temperature sensor HH79NZ017 — Included with factory-installed PremierLink control;
field-supplied and field-installed with field-installed PremierLink control.
NOTES:
1. CO2Sensors (Optional):
33ZCSENCO2 — Room sensor (adjustable). Aspirator box is required for duct mounting of the sensor.
33ZCASPCO2 — Aspirator box used for duct-mounted CO2room sensor.
33ZCT55CO2 — Space temperature and CO2room sensor with override.
33ZCT56CO2 — Space temperature and CO2room sensor with override and set point.
2. All units include the following Standard Sensors:
Outdoor-Air Sensor — 50HJ540569 — Opens at 67 F, closes at 52 F, not adjustable.
Mixed-Air Sensor — HH97AZ001 — (PremierLink control requires Supply Air Temperature sensor 33ZCSENSAT
and Outdoor Air Temperature Sensor HH79NZ017)
Compressor Lockout Sensor — 50HJ540570 — Opens at 35 F, closes at 50 F.
APPLICATION OUTDOOR AIR
TEMPERATURE SENSOR
RETURN AIR
TEMPERATURE SENSOR
OUTDOOR AIR
ENTHALPY SENSOR
RETURN AIR
ENTHALPY SENSOR
Dry Bulb
Temperature with
PremierLink*
(PremierLink
requires4-20mA
Actuator)
Included —
HH79NZ017 ———
Differential Dry Bulb
Temperature with
PremierLink*
(PremierLink
requires4-20mA
Actuator)
Included —
HH79NZ017
Required —
33ZCT55SPT
or Equivalent
——
Single Enthalpy with
PremierLink*
(PremierLink
requires4-20mA
Actuator)
Included —
Not Used —Required — HH57AC077 —
Differential Enthalpy
with PremierLink*
(PremierLink
requires4-20mA
Actuator)
Included —
Not Used —Required — HH57AC077
Required —
HH57AC078
TB-1
R
Y1
Y2
W1
W2
G
C
X
1
2
3
4
5
6
7
8
TB-3
1
2
3
4
5
6
7
8
TB-2
1
2
3
4
5
6
7
8
J6
ANAL OG
J5
0-20mAIN
J4
DISCRETE
J1
PWR
J2
COMMS
J9
0-20 mA
J8
Relays
HK50AA039
BRN
BRN WHT
WHT
RED
PNK
PNK
ORNORN
ORN
ORN
GRA
GRA
ORN
RED
J7
PP/MP
WHT
BLK
RED
RED
PNK
WHT
BLK
PNK
WHT
BLU
ORN
YEL
GRN
BRN
BRN
RED
RED
BRN
BRN
BLK
BLK
BRN
BRN
BLU
BLU
1
2
3
4
5
6
7
8
9
10
11
12
1
2
3
4
5
6
7
8
9
10
11
12
PNK
PNK
VIO
VIO
GRA
ORN
PNK
PNK
GRA
GRA
GRA
SAT
BRN
ORN
BLK
RED
Space Temp./ Set
Point Adjustment
Indoor Air
Quality Sensor
OAT
PNK
VIO
YEL
YEL
BLU
BLU
Economi$er2
4 - 20mA
BLK
RED
WHT
PremierLink
GRN
YEL
BLU
BLU
BLU
Outdoor Air
Quality Sensor
Power Exhaust/Energy Recycler
CCN
Comm.
RMTOCC
SFS
CMPSAFE
FSD
RTU Terminal
Board
TR TR1
SR
23
+
+
S
RED
BRN
BLK
RED
GRAY
GRAY
OUTDOOR AIR
ENTHALPY SENSOR
RETURN AIR
ENTHALPY
SENSOR
LEGEND
COMMS — Communications
OAT — Outdoor Air Temperature Sensor
PWR — Power
RTU — Rooftop Unit
SAT — Supply Air Temperature Sensor
TB — Terminal Block
Fig. 18 — Typical PremierLink Controls Wiring
