“TRAKTORPRO2”
SettingManual
EN
XW-DJ1MIDIMAPPING
CHART

TRAKTORPRO2
Before importing this MIDI setting file, we recommend
backing up using the procedure below so that the current
settings can be restored if necessary.
★This operation is not necessary for users who use
「TRAKTOR PRO 2」
for the first time.
EN-１
■Required a computor which “TRAKTOR PRO 2” is installed.
■“TRAKTOR PRO 2” functions can be controlled by XW-DJ1, but
all functions are not supported. Please make your own setting as
necessary. Refer the “TRAKTOR PRO 2 Manual(PDF)” which is
included with “TRAKTOR PRO 2” .
■Refer “MIDI MAPPING CHART” at the end of this Setting Manual
to control “TRAKTOR PRO 2” by XW-DJ1’s buttons, volumes.
BackingupthecurrentMIDIsettingfile
(Notice)
■“TRAKTOR PRO 2” is a product of Native Instruments
GmbH. Please direct any questions and/or inquiries
concerning this software to native instruments and refer
the “TRAKTOR PRO 2 Manual (PDF)” which is included
with “TRAKTOR PRO 2” .
■Please note that CASIO will accept no responsibility
whatsoever for damages resulting from downloading or
installing this MIDI setting file. Users should take full
responsibility for downloading, installing and using this
files.
■The specifications of this setting file are subject to
change without notice.
■Please note that this service may be terminated
without notice.
(Disclaimer)
■Please note that CASIO will accept no responsibility
whatsoever for loss or damage to the customer’ s
computer caused by the operations based on the
information in this Guide. It is advised to use this
information at your own risk and on your own
responsibility.
Start up “TRAKTOR PRO 2” .
Select “Export” on the bottom left of screen.
Click “OK” after checking the items which you want to
back up on “Select Categories to Export” list.
Select “Preferences” on the top right of screen.
1.
2.
4.
Save it in the desired location after giveing a file identifiable
name.
5.
3.
CASIO provides a MIDI setting file for the Native
Instruments “TRAKTOR PRO 2” Dj software and
“TRAKTOR PRO 2” can be controlled from XW-DJ1
by importing this MIDI setting file.

Select “Import” on the bottom left of screen.
Select “Preferences” on the top right of screen.
(When Windows PC, “Preferences” starts automatically.)
Start up “TRAKTOR PRO 2” .
1.
2.
4.
5.
3.
■Click “Audio Device Settings” checkbox,
then click “OK” .
6. Select MIDI setting file saved in step 1.
Then Click “OK” .
ImportingaMIDIsettingfile
EN-2
Download a MIDI setting file for “TRAKTOR PRO 2” and
save it to the location below where “TRAKTOR PRO 2”
is installed. (When you use “TRAKTOR PRO 2” application
for first time, start up and close “TRAKTOR PRO2”
application once, then go to step 1.
In case of Windows OS, “ASIO Driver software” exclusive
for XW-DJ1. Please install it with reference to the separate
Tutorial Manual (Page 11 - 12).
(This operation is not necessary for MAC OS-X.)
■Windows PC
Library / Document / Native Instruments /
Traktor x.x.x / Settings
■MAC OS-X
Home (User) / Document / Native Instruments/
Traktor x.x.x / Settings
Use a USB cable (Corresponding to High Speed) to
connect to your computor and press the (power)
button to turn on power.
7.
TRAKTORPRO2
■After step 6 process, select “Audio Setup” and “Output
Routing” in “Preferences” list on the left. Then set them
in reference to below. (Only at the first time)
■Select “Controller Manager” and check “Device
Setup” contents.
8.
■Select “In-Port” and “Out-Port” . Then set them
to “XW-DJ1” (In case of MAC OS-X) respectively.
MIDI setting with XW-DJ1.
- Device :
「Casio XW-DJ1 - 」
Windows PC
「Casio MIDI In」
「Casio MIDI Out」
AUDIO setting with XW-DJ1.
(When Windows PC, “Audio Device” shows “Casio ASIO Driver(ASIO)” .)
[Audio Setup]
[Output Routing]
[Output Routing]
「Mixing Mode」 →Internal
「Output Monitor - L 」 → Analogue 3
「Output Monitor - R 」 → Analogue 4
「Output Master - L 」 → Analogue 1
「Output Master - R 」 → Analogue 2
memo
[Audio Setup]
「Audio Device」 →Casio XW-DJ1
Audio out
■When MAC OS-X

Select “Preferences” on the top right of screen.
Select “Controller Manager”.
Complete to delete device after clicking “Yes” on
the confirmation screen.
Crossfader setting
■Select “Mixer” in “Preferences” list on the left.
9.
FILTER and FX setting on Deck A and B in
“TRAKTOR PRO 2” main screen.
■FILTER (A / B DECK) →“ON”
■“A” DECK “FX” →“FX-1”
“B” DECK “FX” →“FX-2”
If the other MIDI setting file have been imported to
“TRAKTOR PRO 2”, XW-DJ1 might not work properly.
Delete the other MIDI setting file which already
imported on it with reference to the following steps.
10.
Close “TRAKTOR PRO 2” and reboot the power
of XW-DJ1. Then start “TRAKTOR PRO 2” again.
11.
DeletetheotherMIDIsettingfile
1.
2.
Select device in “Device” (in “Device Setup” ) and
click “Edit” →“DELETE” .
3.
4.
■Turn on the power of XW-DJ1 first. Then, start “TRA
KTOR PRO 2” . If you launch them in reverse order,
you may not be able to controll “TRAKTOR PRO 2” by
XW-DJ1 or no sound may be output.
■If you launch them in reverse order, close “TRAKTOR
PRO 2” and turn off the power of XW-DJ1. Then,turn on
the power of XW-DJ1 first. Then, start “TRAKTOR PRO 2”.
EN-3
TRAKTORPRO2
Company, product, technology, and other names used
herein are trademarks or service marks of others.
- For mixing play (Gentle) →Smooth side
- For scratch play (Sharp) →Sharp side
■Adjust the Crossfader curve setting.
■Click “Close” to close “Preferences” window.

C1
C2
C3
C4
C5
C6
D1
D2
D3
D4
D5
D6
D7
C1 C2 C3 C4 C5 C6
S1
S1
B
B
D1 D2 D3 D4 D5 D6 D7
C1 C2 C3 C4 C5 C6 D1 D2 D3 D4 D5 D6 D7
V2
V1
V1
V3
V2
V5
J1
J1
V5
V3
V4
V4
V5
S2
S2
S1 S2
A
A
EFFECT
AREA
(GROUP)
FX “◀”EFFECT 1 ON/OFF Select EFFECT 1’s effect type
Select EFFECT 2’s effect type
Select EFFECT 3’s effect type
EFFECT 2 ON/OFF
EFFECT 3 ON/OFF
LOOP length x 1/2 Set “MANUAL LOOP IN” point
Set “MANUAL LOOP OUT” pointLOOP length x 2
Set and Play “CUE 3”
Set and Play “CUE 2”
Set and Play “CUE 1”
Delete “CUE 3” point
Delete “CUE 2” point
Delete “CUE 1” point
Moves in the rewind direction.
Moves in the fast forward direction.
Fixes the (musical) key of the song.
Starts or pauses playback
Returns to the last set CUE point.
Song is played back when the CUP button is released.
Returns to the last set CUE point.
Song is played back when the CUE button is pressed.
Syncs with the speed (BPM) of the opposite side deck.
LOOP ON/OFF LOOP ON/OFF
FX “▶”
LOOP “1/2”
LOOP
LOOP “ x 2”
CUE 3
CUE 2
CUE 1
PLAY/PAUSE
SET(CUP)
CUE
SYNC
MASTER
HEADPHONE
FILTER
JOG platter
Abutton Used to select the “A” deck to be controlled by the JOG platter.
Used to select the “B” deck to be controlled by the JOG platter.
B button
Enables scratch and backspin operations
Adjust the MASTER OUT volume
When “S1” →ON
(V1) = CROSSFADER
(V2) = FX DRY/WET adjust
( + SHIFT button : FX PARAMETER )
When “S2” →ON
(V1) = FX DRY/WET adjust
( + SHIFT button : FX PARAMETER )
(V2) = CROSSFADER
Adjust the HEADPHONE OUT volume
Rotating to the right results in high pass filter (treble only output) function, while rotating to the left results
in low pass filter (bass only output) function.
Up and Down the cursor on browser list
Load the song which is selected in browser list
FX
LOOP
AREA
DECK
CONTROL
AREA
= ON = ON
FunctionSilk name (With SHIFT button)
(S2=OFF) (S1=OFF)
MIDIMAPPING
CHART
■“TRAKTOR PRO 2” functions can be
controlled by XW-DJ1, but all functions of
“TRAKTOR PRO 2” are not supported.
Please make your own setting as necessary.
■This MIDI MAPPING file supports “2 Track
decks” mode on “TRAKTOR PRO 2” .
