CTK-671 MIDI Implementation
CASIO Computer Electronical Musical Instrument Division
August 1, 2001

1
CTK-671 MIDI Implementation
Contents
* 1. MIDI Message Send and Receive
o1.1 Note Off/On
+ 1.1.1 Note Off
+ 1.1.2 Note On
o 1.2 Control Change
+1.2.1 Bank Select
+ Bank Select MSB
+ Bank Select LSB
+ 1.2.2 Modulation
+ 1.2.3 Data Entry
+ Data Entry MSB
+ Data Entry LSB
+ 1.2.4 Volume
+ 1.2.5 Pan
+ 1.2.6 Expression
+ 1.2.7 DSP Parameter
+ DSP Parameter 0
+ DSP Parameter 1
+ DSP Parameter 2
+ DSP Parameter 3
+ DSP Parameter 4
+ DSP Parameter 5
+ DSP Parameter 6
+ DSP Parameter 7
+ 1.2.8 Hold1
+ 1.2.9 Sostenuto
+ 1.2.10 Soft
+ 1.2.11 Filter Resonance
+ 1.2.12 Release Time
+ 1.2.13 Attack Time
+ 1.2.14 Filter Cutoff
+ 1.2.15 Vibrato Rate
+ 1.2.16 Vibrato Depth
+ 1.2.17 Vibrato Delay
+ 1.2.18 Reverb Send
+ 1.2.19 Chorus Send
+ 1.2.20 NRPN
+ NRPN LSB
+ NRPN MSB
+ 1.2.20.1 Filter Cutoff
+ 1.2.20.2 Filter Resonance
+ 1.2.21 RPN
+ RPN LSB
+ RPN MSB
+ 1.2.21.1 Pitch Bend Sensitivity
+ 1.2.21.2 Fine Tune
+ 1.2.21.3 Coarse Tune
+ 1.2.21.4 Modulation Depth
+ 1.2.21.5 Null
+ 1.2.22 All Sound Off
+ 1.2.23 Reset All Controllers
o 1.3 Mode Message
+ 1.3.1All Notes Off
+ 1.3.2 Omni Off
+ 1.3.3 Omni On
+ 1.3.4 Mono
+ 1.3.5 Poly
o 1.4 Program Change
o 1.5 Channel Aftertouch
o 1.6 Pitch Bend
o 1.7 Active Sensing
o 1.8 System Exclusive
+ 1.8.1 Universal Realtime
+ 1.8.1.1 Master Volume
+ 1.8.1.2 Master Balance
+ 1.8.1.3 Master Fine Tuning
+ 1.8.1.4 Master Coarse Tuning
+ 1.8.1.5 Reverb Parameter
+ Type
+ Time
+ 1.8.1.6 Chorus Parameter
+ Type
+ Rate
+ Depth
+ Feedback
+ Send To Reverb
+ 1.8.1.7 GM System Message
+ GM System On
+ GM System Off
+ GM2 System On
+ 1.8.2 CTK-671 Format System Exclusive Message
* 2. CTK-671 System Exclusive Message Format
o 2.1 Format
+ 2.1.1 CTK-671 System Exclusive Message
+ 2.1.2 Message Structure
o 2.2 Individual Parameter Operations
o 2.3 Parameter Set Transfer Modes
+ 2.3.1 Communication Modes
+ 2.3.2 One-way Mode Communication Flow
+ 2.3.3 Handshake Mode Communication Flow
* 3. Parameter List
o 3.1 Command Parameter
+ 3.1.1 Parameter Set Overview
+ 3.1.2 Command Parameter List
+ 3.1.2.1 System Exclusive Format
+ 3.1.2.2 Parameter List
+ 3.1.3 Song / Rhythm Pattern Command Parameter List
+ 3.1.3.1 System Exclusive Format
+ 3.1.3.2 Parameter List
o 3.2 Patch Parameter
+ 3.2.1 Parameter Set Overview
+ 3.2.2 Patch Common Parameter List
+ 3.2.2.1 System Exclusive Format
+ 3.2.2.2 Parameter List
+ MIDI Parameter
+ Tune / Mix Parameter
+ System Chorus
+ System Reverb
+ Master Equalizer
+ DSP Patch Parameter
+ DSP Type parameter
+ 3.2.3 Patch Part Parameter List
+ 3.2.3.1 System Exclusive Format
+ 3.2.3.2 Parameter List
+ Basic parameter
+ Tune / Mix parameter
+ Tone parameter
+ LFO Parameter
+About the Part Mode

2
CTK-671 MIDI Implementation
1. MIDI Message Send and Receive
Send: MIDI messages are not sent in the demo mode.
Receive: MIDI messages are not received in the demo and song mode.
1.1 Note Off/On
1.1.1 Note Off
Format: 9nH kkH 00H
8nH kkH **H (receive only)
n: MIDI Channel Number
kk: Key Number
1.1.2 Note On
Format: 9nH kkH vvH
n: MIDI Channel Number
kk: Key Number
vv: Velocity
Send: When the keyboard is played, when Auto Accompaniment is played, and when
song data is played back. In the case of accompaniment data, this message is
sent only when Accomp MIDI Out is turned on.
Receive: This message is received over the MIDI channels that correspond to each of
the parts.
Any part whose mixer channel is turned off is not received.
1.2 Control Change
Format: BnH ccH vvH
n: MIDI Channel Number
cc: Control Number
vv: Value
Send: When the CTK-671 pedal is operated and when a parameter is changed by a
control panel operation.
Also sent when the same parameter is changed by an accompaniment function or
song function.
Receive: Changes the CTK-671 setup or corresponding parameter.
1.2.1 Bank Select
• Bank Select MSB
Format: BnH 00H vvH
n: MIDI Channel Number
vv: Value
• Bank Select LSB
Format: BnH 20H **H
n: MIDI Channel Number
Send: When a tone is selected.
See the "Tone List" of the CTK-671 User's Guide for details.
Receive: Switches the CTK-671 tone bank number, but the tone is not actually changed
until Program Change is received.
See the section titled "1.4 Program Change" in this document, and the "Tone
List" in the CTK-671 User's Guide.
* 4. Parameter Set List
o 4.1 User Tone Parameter Set
+ System Exclusive Format
o 4.2 User DSP Parameter Set
+ System Exclusive Format
o 4.3 Song Data
+ System Exclusive Format
o 4.4 User Rhythm Pattern
+ System Exclusive Format
o 4.5 Registration Data
+ System Exclusive Format
* 5. DSP Parameter List
* 6. Setting Values and Send/Receive Values
6.1.1.1 Off/On Setting Value Table
6.1.1.2 Slow/Fast Setting Value Table
6.1.1.3 Rotate/Break Setting Value Table
6.1.1.4 -24 - 0 - 24 Setting Value Table
6.1.1.5 -64 - 0 - 63 Setting Value Table
6.1.1.6 Pan Setting Value Table
6.1.1.7 -99 - 0 - 99 Setting Value Table
6.1.1.8 Type 0 to Type 7 Setting Value Table
6.1.1.9 Master EQ Type Setting Value Table
6.1.1.10 ReverbType Setting Value Table
6.1.1.11 Chorus Type Setting Value Table
6.1.1.12 Equalizer Low Frequency Setting Value Table
6.1.1.13 Equalizer Mid Frequency Setting Value Table
6.1.1.14 Equalizer High Frequency Setting Value Table
6.1.1.15 Equalizer Gain Setting Value Table
6.1.1.16 DSPAlgorithm ID Table
* 7. MIDI Implementation Notation

3
CTK-671 MIDI Implementation
1.2.2 Modulation
Format: BnH 01H vvH
n: MIDI Channel Number
vv: Value
Send: This message is never sent.
Receive: Adds to the currently sounding voice vibrato of a depth specified by the value.
In the case of a tone that already has vibrato applied, receipt of this message
increases the vibrato depth.
1.2.3 Data Entry
• Data Entry MSB
Format: BnH 06H vvH
n: MIDI Channel Number
vv: Value
• Data Entry LSB
Format: BnH 26H vvH
n: MIDI Channel Number
vv: Value
Send: When there is a change in the parameters allocated to NRPN and RPN.
Receive: Changes the parameters allocated to NRPN and RPN.
1.2.4 Volume
Format: BnH 07H vvH
n: MIDI Channel Number
vv: Value
The setting value is the same as the value that is sent and received.
Send: When there is a change in Part Volume.
Receive: Changes Part Volume.
1.2.5 Pan
Format: BnH 0AH vvH
n: MIDI Channel Number
vv: Value
For information about the relationship between setting values and send/receive
values, see the "6.1.1.6 Pan Setting Value Table" in the section of this document
titled "6. Setting Values and Send/Receive Values."
Send: When there is a change in Part Pan.
Receive: Changes Part Pan.
1.2.6 Expression
Format: BnH 0BH vvH
n: MIDI Channel Number
vv: Value
The setting value is the same as the value that is sent and received.
Send: When there is a change in the Expression value caused by accompaniment.
Receive: Changes the Expression value.
1.2.7 DSP Parameter
• DSP Parameter 0
Format: BnH 10H vvH
• DSP Parameter 1
Format: BnH 11H vvH
• DSP Parameter 2
Format: BnH 12H vvH
• DSP Parameter 3
Format: BnH 13H vvH
• DSP Parameter 4
Format: BnH 50H vvH
• DSP Parameter 5
Format: BnH 51H vvH
• DSP Parameter 6
Format: BnH 52H vvH
• DSP Parameter 7
Format: BnH 53H vvH
n: MIDI Channel Number
The MIDI channel that manipulates a DSP parameter by a control change is called
the “Global Channel.” The initial factory default Global Channel setting is 0 (MIDI
Channel 1).
The Global Channel cannot be changed by a control panel operation. You need to
use a System Exclusive Message to change the Global Channel.
For more information, see the explanation about the Global Channel in the section
of this document titled "System Exclusive Message."
vv: Value
The range for a value that can be sent and received by any of the parameters is 0 to
127. Note, however, that the parameter values that can actually be set and the
corresponding send value differs according to parameter.
The same values are used for DSP parameter operations using System Exclusive
Messages. For more information, see the explanation about DSP parameters in the
section of this document titled "System Exclusive Messages."
Send: When the DSP Parameter value is changed.
Receive: Changes the DSP Parameter value.
Any received message corresponding to a parameter whose number exceeds the
currently selected number of DSP parameters is ignored.
1.2.8 Hold1
Format: BnH 40H vvH
n: MIDI Channel Number
vv: Value
For information about the relationship between setting values and send/receive
values, see the "6.1.1.1 Off/On Setting ValueTable" in the section of this document
titled "6. Setting Values and Send/Receive Values."
Send: When the sustain operation is assigned to the assignable jack and the pedal
connected to the assignable jack is operated, or when song data containing a
sustain operation is played back.
Receive: Performs an operation equivalent to a sustain pedal operation.
1.2.9 Sostenuto
Format: BnH 42H vvH
n: MIDI Channel Number
vv: Value
For information about the relationship between setting values and send/receive
values, see the "6.1.1.1 Off/On Setting ValueTable" in the section of this document
titled "6. Setting Values and Send/Receive Values."
Send: When the sostenuto operation is assigned to the assignable jack and the pedal
connected to the assignable jack is operated, or when song data containing a
sostenuto is played back.

4
CTK-671 MIDI Implementation
Receive: Performs an operation equivalent to a sostenuto pedal operation.
1.2.10 Soft
Format: BnH 43H vvH
n: MIDI Channel Number
vv: Value
For information about the relationship between setting values and send/receive
values, see the "6.1.1.1 Off/On Setting ValueTable" in the section of this document
titled "6. Setting Values and Send/Receive Values."
Send: When the soft operation is assigned to the assignable jack and the pedal connected
to the assignable jack is operated, or when song data containing a soft operation
is played back.
Receive: Performs an operation equivalent to a soft pedal operation.
1.2.11 Filter Resonance
Format: BnH 47H vvH
n: MIDI Channel Number
vv: Value
For information about the relationship between setting values and send/receive
values, see the "6.1.1.5 -64 - 0 - 63 Setting Value Table" in the section of this document
titled "6. Setting Values and Send/Receive Values."
Send: When Filter Resonance is changed.
Receive: Changes Filter Resonance.
1.2.12 Release Time
Format: BnH 48H vvH
n: MIDI Channel Number
vv: Value
For information about the relationship between setting values and send/receive
values, see the "6.1.1.5 -64 - 0 - 63 Setting Value Table" in the section of this document
titled "6. Setting Values and Send/Receive Values."
Send: When Release Time is changed.
Receive: Changes Release Time.
1.2.13 Attack Time
Format: BnH 49H vvH
n: MIDI Channel Number
vv: Value
For information about the relationship between setting values and send/receive
values, see the "6.1.1.5 -64 - 0 - 63 Setting Value Table" in the section of this document
titled "6. Setting Values and Send/Receive Values."
Send: When Attack Time is changed.
Receive: Changes Attack Time.
1.2.14 Filter Cutoff
Format: BnH 4AH vvH
n: MIDI Channel Number
vv: Value
For information about the relationship between setting values and send/receive
values, see the "6.1.1.5 -64 - 0 - 63 Setting Value Table" in the section of this document
titled "6. Setting Values and Send/Receive Values."
Send: When Filter Cutoff is changed.
Receive: Changes Filter Cutoff.
1.2.15 Vibrato Rate
Format: BnH 4CH vvH
n: MIDI Channel Number
vv: Value
For information about the relationship between setting values and send/receive
values, see the "6.1.1.5 -64 - 0 - 63 Setting Value Table" in the section of this document
titled "6. Setting Values and Send/Receive Values."
Send: When Vibrato Rate is changed.
Receive: Changes Vibrato Rate.
1.2.16 Vibrato Depth
Format: BnH 4DH vvH
n: MIDI Channel Number
vv: Value
For information about the relationship between setting values and send/receive
values, see the "6.1.1.5 -64 - 0 - 63 Setting Value Table" in the section of this document
titled "6. Setting Values and Send/Receive Values."
Send: When Vibrato Depth is changed.
Receive: Changes Vibrato Depth.
1.2.17 Vibrato Delay
Format: BnH 4EH vvH
n: MIDI Channel Number
vv: Value
For information about the relationship between setting values and send/receive
values, see the "6.1.1.5 -64 - 0 - 63 Setting Value Table" in the section of this document
titled "6. Setting Values and Send/Receive Values."
Send: When Vibrato Delay is changed.
Receive: Changes Vibrato Delay.
1.2.18 Reverb Send
Format: BnH 5BH vvH
n: MIDI Channel Number
vv: Value
The setting value is the same as the value that is sent and received.
Send: When Reverb Send is changed.
Receive: Changes Reverb Send.
1.2.19 Chorus Send
Format: BnH 5DH vvH
n: MIDI Channel Number
vv: Value
The setting value is the same as the value that is sent and received.
Send: When Chorus Send is changed.
Receive: Changes Chorus Send.
1.2.20 NRPN
• NRPN LSB
Format: BnH 62H vvH
n: MIDI Channel Number
vv: Value
• NRPN MSB

5
CTK-671 MIDI Implementation
Format: BnH 63H vvH
n: MIDI Channel Number
vv: Value
1.2.20.1 Filter Cutoff
Format: BnH 62H 20H 63H 01H 06H mmH 26H **H
n: MIDI Channel Number
mm: Value
For information about the relationship between setting values and receive values,
see the "6.1.1.5 -64 - 0 - 63 Setting Value Table" in the section of this document
titled "6. Setting Values and Send/Receive Values."
Send: This message is never sent.
Receive: Changes Filter Cutoff.
1.2.20.2 Filter Resonance
Format: BnH 62H 21H 63H 01H 06H mmH 26H **H
n: MIDI Channel Number
mm: Value
For information about the relationship between setting values and receive values,
see the "6.1.1.5 -64 - 0 - 63 Setting Value Table" in the section of this document
titled "6. Setting Values and Send/Receive Values."
Send: This message is never sent.
Receive: Changes Filter Resonance.
1.2.21 RPN
• RPN LSB
Format: BnH 64H vvH
n: MIDI Channel Number
vv: Value
• RPN MSB
Format: BnH 65H vvH
n: MIDI Channel Number
vv: Value
1.2.21.1 Pitch Bend Sensitivity
Format: BnH 64H 00H 65H 00H 06H mmH 26H **H
n: MIDI Channel Number
mm: Value 0 - 24
The setting value is the same as the value that is sent and received.
Send: This message is never sent.
Receive: Changes Pitch Bend Sensitivity.
1.2.21.2 Fine Tune
Format: BnH 64H 01H 65H 00H 06H mmH 26H llH
n: MIDI Channel Number
mm: Value MSB
ll: Value LSB
For information about the relationship between setting values and send/receive
values, see the "6.1.1.7 -99 - 0 - 99 Setting Value Table" in the section of this document
titled "6. Setting Values and Send/Receive Values."
Send: When Channel Fine Tune is changed.
Receive: Changes Channel Fine Tune.
1.2.21.3 Coarse Tune
Format: BnH 64H 02H 65H 00H 06H mmH 26H 00H
n: MIDI Channel Number
mm: Value
For information about the relationship between setting values and send/receive
values, see the "6.1.1.4 -24 - 0 - 24 Setting Value Table" in the section of this document
titled "6. Setting Values and Send/Receive Values."
Send: When Channel Coarse Tune is changed.
Receive: Changes Channel Coarse Tune.
1.2.21.4 Modulation Depth
Format: BnH 64H 05H 65H 00H 06H mmH 26H 00H
n: MIDI Channel Number
mm: Value
The setting value is the same as the value that is sent and received.
Send: This message is never sent.
Receive: Changes Modulation depth.
1.2.21.5 Null
Format: BnH 64H 7FH 65H 7FH
n: MIDI Channel Number
Send: This message is never sent.
Receive: Deselects RPN.
1.2.22 All Sound Off
Format: BnH 78H 00H
n: MIDI Channel Number
Send: This message is never sent.
Receive: Stops all voices that are sounding.
1.2.23 ResetAll Controllers
Format: BnH 79H 00H
n: MIDI Channel Number
Send: When the song function is used.
Receive: Sets initial controller values shown below.
---------------------------------------------------------------------------------------
Message Controller Values
---------------------------------------------------------------------------------------
Control Change 01H Modulation 00H
0BH Expression 00H
40H Hold1 00H
42H Sostenuto 00H
43H Soft 00H
65H/64H RPN MSB/LSB 7FH-7FH
63H/62H NRPN MSB/LSB 7FH-7FH
Channel Pressure 00H
Pitch Bend Change 40H/00H
1.3 Mode Message
1.3.1 All Notes Off
Format: BnH 7BH 00H
n: MIDI Channel Number

6
CTK-671 MIDI Implementation
1.3.2 Omni Off
Format: BnH 7CH 00H
n: MIDI Channel Number
1.3.3 Omni On
Format: BnH 7DH 00H
n: MIDI Channel Number
1.3.4 Mono
Format: BnH 7EH 00H
n: MIDI Channel Number
1.3.5 Poly
Format: BnH 7FH 00H
n: MIDI Channel Number
Send: These messages are never sent.
Receive: Receipt of any of these messages releases (same as releasing the keyboard
key) the currently sounding voice.
1.4 Program Change
Format: CnH ppH
n: MIDI Channel Number
pp: Program Number
Send: When a tone is selected.
See the "Tone List" of the CTK-671 User's Guide for details.
Receive: Changes the tone and Part Mode (explained below) of the part corresponding
to the MIDI channel.
The selected tone is determined by the program value of this message and the
Bank Select message value received prior to this message.
See the "Tone List" in the CTK-671 User's Guide for information about actually
selecting tones, etc.
Also note that receipt of this message can also change the Part Mode parameter
at the same time. For details, see "About the Part Mode," which is located in the
section of this document named "3.2.3 Patch Part Parameter List."
1.5 Channel Aftertouch
Format: DnH vvH
n: MIDI Channel Number
vv: Value
Send: This message is never sent.
Receive: Receipt of this message adds vibrato to the voice that is sounding. Details of
the effect differ according to the tone setting.
1.6 Pitch Bend
Format: EnH llH mmH
n: MIDI Channel Number
ll: Value LSB
mm: Value MSB
Send: This message is never sent.
Receive: Receipt of this message changes the pitch of the currently sounding voice.
The range of the change depends on the Pitch Bend Sensitivity set by RPN.
1.7Active Sensing
Format: FEH
Send: This message is never sent.
Receive: If some MIDI message is not received within a preset amount of time after this
message is received, all currently sounding CTK-671 voices are released and the
controller is reset.
1.8 System Exclusive
Format: F0H....F7H
1.8.1 Universal Realtime
Format: F0H 7FH....F7H
1.8.1.1 Master Volume
Format: F0H 7FH 7FH 04H 01H llH mmH F7H
mm: Value MSB
The setting value is the same as the value that is sent and received.
Send: This message is never sent.
Receive: Changes the Master Volume parameter.
Note that the Master Volume parameter cannot be changed on the CTK-671.
1.8.1.2 Master Balance
Format: F0H 7FH 7FH 04H 02H llH mmH F7H
mm: Value MSB
For information about the relationship between setting values and send/receive
values, see the "6.1.1.6 Pan Setting Value Table" in the section of this document
titled "6. Setting Values and Send/Receive Values."
Send: This message is never sent.
Receive: Changes the Master Pan parameter.
Note that the Master Pan parameter cannot be changed by a control panel
operation.
1.8.1.3 Master Fine Tuning
Format: F0H 7FH 7FH 04H 03H 00H mmH F7H
mm: Value MSB
For information about the relationship between setting values and send/receive
values, see the "6.1.1.7 -99 - 0 - 99 Setting Value Table" in the section of this document
titled "6. Setting Values and Send/Receive Values."
Send: When the Fine Tune parameter is changed.
Receive: Changes the Fine Tune parameter.
1.8.1.4 Master Coarse Tuning
Format: F0H 7FH 7FH 04H 04H llH mmH F7H
mm: Value MSB
For information about the relationship between setting values and send/receive
values, see the "6.1.1.4 -24 - 0 - 24 Setting Value Table" in the section of this document
titled "6. Setting Values and Send/Receive Values."
Send: When the Transpose parameter is changed.
Receive: Changes the Transpose parameter.
1.8.1.5 Reverb Parameter
Format: F0H 7FH 7FH 04H 05H 01H 01H 01H 01H 01H ppH vvH F7H
pp: Parameter

7
CTK-671 MIDI Implementation
• Type
Format: F0H 7FH 7FH 04H 05H 01H 01H 01H 01H 01H 00H vvH F7H
vv: Value
For information about the relationship between setting values and send/receive
values, see the "6.1.1.10 Reverb Type Setting Value Table" in the section of this
document titled "6. Setting Values and Send/Receive Values."
Send: When the Reverb Type parameter is changed.
Receive: Changes the Reverb Type parameter.
• Time
Format: F0H 7FH 7FH 04H 05H 01H 01H 01H 01H 01H 01H vvH F7H
vv: Value
The setting value is the same as the value that is sent and received.
Send: When the Reverb Time parameter is changed.
Receive: Changes the Reverb Time parameter.
1.8.1.6 Chorus Parameter
Format: F0H 7FH 7FH 04H 05H 01H 01H 01H 01H 02H ppH vvH F7H
pp: Parameter
• Type
Format: F0H 7FH 7FH 04H 05H 01H 01H 01H 01H 02H 00H vvH F7H
vv: Value
For information about the relationship between setting values and send/receive
values, see the "6.1.1.11 Chorus Type Setting Value Table" in the section of this
document titled "6. Setting Values and Send/Receive Values."
Send: When the Chorus Time parameter is changed.
Receive: Changes the Chorus Time parameter.
• Rate
Format: F0H 7FH 7FH 04H 05H 01H 01H 01H 01H 02H 01H vvH F7H
vv: Value
For information about the relationship between setting values and send/receive
values, see the "6.1.1.11 Chorus Type Setting Value Table" in the section of this
document titled "6. Setting Values and Send/Receive Values."
Send: When the Chorus Rate parameter is changed.
Receive: Changes the Chorus Rate parameter.
• Depth
Format: F0H 7FH 7FH 04H 05H 01H 01H 01H 01H 02H 02H vvH F7H
vv: Value
The setting value is the same as the value that is sent and received.
Send: When the Chorus Depth parameter is changed.
Receive: Changes the Chorus Depth parameter.
• Feedback
Format: F0H 7FH 7FH 04H 05H 01H 01H 01H 01H 02H 03H vvH F7H
vv: Value
The setting value is the same as the value that is received.
Send: This message is never sent.
Receive: Changes the Chorus Feedback parameter.
The Chorus Feedback parameter cannot be changed by a control panel operation.
• Send To Reverb
Format: F0H 7FH 7FH 04H 05H 01H 01H 01H 01H 02H 04H vvH F7H
vv: Value
The setting value is the same as the value that is received.
Send: This message is never sent.
Receive: Changes the Chorus Send To Reverb parameter.
The Chorus Send to Reverb parameter cannot be changed by a control panel
operation.
1.8.1.7 GM System Message
• GM System On
Format: F0H 7FH 7FH 09H 01H F7H
Send: This message is never sent.
Receive: Puts the sound source into a preset GM sound source mode.
• GM System Off
Format: F0H 7FH 7FH 09H 02H F7H
Send: This message is never sent.
Receive: Returns the sound source to the CTK-671 mode.
• GM2 System On
Format: F0H 7FH 7FH 09H 03H F7H
Send: This message is never sent.
Receive: Though the CTK-671 does not support GM2, receipt of the GM2 System On
message has the same result as receipt of the GM System On message.
1.8.2 CTK-671 Format System Exclusive Message
Format: F0H 44H 11H 01H....F7H
For more information, see the section of this document titled "2. CTK-671 System
Exclusive Message Format."
2. CTK-671 System Exclusive Message Format
2.1 Format
CTK-671 SysEx operations are classified as Parameter type for send and receive of an
individual parameter, and Parameter Set type for bulk send and receive of a set of
parameters.
These SysEx types can be further broken down into parameter categories according
to the item being transferred.

8
CTK-671 MIDI Implementation
2.1.1 CTK-671 System Exclusive Message
+ -------------Individual Parameter Transfer -- + -- Command - + - Version
+ - DSP
+ - Song/Rhythm
+ - Patch -+ Common - +-MIDI
+-Tune/Mix
+-Sys Chorus
+-Sys Reverb
+-Master EQ
+-DSP
+ Part -------- + -Basic
+ -Tune/Mix
+ -Tone
+ -LFO
+ - User Tone
+ - User DSP
+ -------------Parameter Set Bulk Transfer ---- + -- User Tone
+ - User DSP
+ - Song
+ - User Rhythm Pattern
+ - Registration
The operation type of a message is determined in accordance with the value of the
"Action" field of the CTK-671 SysEx message. The basic format for all operation type
messages is described in "2.1.2 Message Structure," below.
2.1.2 Message Structure
The CTK-671 System Exclusive Message Format is formed using the 14 fields described
below.
Whether or not a particular field is included in a message and the length of each field
depends on the message.
SYSEX MAN MOD dev act/cat prm ilen/dlen ps <index> <data> <sum> EOX
---------- ------ ------- ----- ---- ---- ----- ---- ----- ---- ---------- --------- --------- ------
1 2 3 4 56 78910 11 12 1314
The act field describes the action that the message performs. The meanings of the <index>
and <data> fields differ according to the value of the act field. The following describes
each of the fields in detail.
1 .......SYSEX : System Exclusive message Status
Format : 11110000
System Exclusive message Status = F0H
2 .......MAN : Manufacturer's ID
Format : 01000100
CASIO Manufacturer's ID = 44H
3 .......MOD : Model ID
Format : 00010001, 00000001 (MSB, LSB)
This field contains a two-byte value (MSB, LSB) that indicates the keyboard model ID.
CTK-671 Model ID MSB = 11H
LSB = 01H
4 .......dev : MIDI DeviceID 00H - 1FH,7FH
Format : 0ddddddd
The contents of this field in a received message are compared with the CTK-671
MIDI Device ID, and the incoming message is recognized only when the two IDs
match.
The default value for this field is 10H.
When a message containing 7FH is received, the message is always recognized
regardless of the CTK-671 ID setting.
MIDI Device ID is a Patch Parameter data item, and it can be changed using a
System Exclusive Message. In such a case, the Device ID of the MIDI System
Exclusive Message must be set to 7FH before it is sent.
5/6 ....act/cat : Action/Category
Format : 0aaacccc
aaa = Action (3bit)
This field indicates the action being performed by the System Exclusive Message.
0H.....IPC Individual Parameter Change
1H.....IPR Individual Parameter Request
2H.....BDS Oneway Parameter Set Bulk Send
3H.....BDR Oneway Parameter Set Bulk Request
4H.....HDS Handshake Parameter Set Bulk Send
5H.....HDR Handshake Parameter Set Bulk Request
6H.....Reserved
7H.....HDA,HDJ,HDE,NOP Communication Control (for Handshake)
cccc = Category (4bit)
Categories indicate the type of data handled by the System Exclusive Message.
The Model ID numbers on the left correspond to the categories, and the applicable
communication operation (Action) is shown on the right.
ID Action
c Category act = 0 1 2 3 4 5 6 7
--------------------------------------------------------------------------------
0H .... Command A A - - - - - -
1H .... Patch A A - - - - - -
2H .... User Tone - - A A A A - A
9H .... User DSP A A A A A A - A
AH.... Song Data - - A A A A - A
BH.... Rhythm Pattern - - A A A A - A
CH ...Registration - - A A A A - A
A ......Available
- ....... Not Available
7 .......prm : Parameter ID
Format : 0ppppppp
The Parameter ID field indicates the parameter type.
See the "Parameter List" below for details about parameter types.
When transferring individual parameters individually (as opposed to bulk transfer),
this field is used to identify the parameter by its parameter ID.
In any other case, this field is filled with the value 00H.
8/9 ....ilen/dlen : index length / data length
Format : 0iiddddd
This field indicates the size of the subsequent <index> field (11) and <data> field
(12).
The index length (ii) indicates the index field length, which is always the following,
regardless of the act (action) value.
ii : index byte size - 1 (3 when index is 4 bytes)
ddddd indicates the size of each data unit (parameter) of the <data> field.
In the case of the Request and Control messages, which do not contain any data,
this value becomes 0.
• When act = 3(BDR), 5(HDR), or 7(Control)
ddddd .... 0
• When act = 0 (Individual Parameter Change)
ddddd: data bit size - 1 (00000 when data is 1 bit; 11111 when data is 32 bits)
• When act = 2 or 4 (Parameter Set Bulk Send)
16-bit unit transfer, always as shown below.
ddddd .... data bit size - 1 = 01111

9
CTK-671 MIDI Implementation
10 .....ps : Parameter Set Number
Format : 0nnnnnnn, 0mmmmmmm (LSB, MSB)
This field is a 2-byte (LSB, MSB) value indicating the Parameter Set number
(00mmmmmmmnnnnnnn) being transferred.
11 .....<index> Parameter Index Number (option)
• When act = 0 (IPC) or 1 (IPR)
This field contains a supplementary number that points to data when parameters
are arrayed.
An <index> can be anywhere from one to four bytes long, and its role is defined on
a case-by-case basis in accordance with the category indicated by cat and the
song number indicated by Parameter ID.
In the case of preset number, part number, and key number parameters that all
have the same ID, for example, these <index> values would be used to specify
each of the parameters.
• When act = 2 (BDS) or 4 (HDS)
In this case, <index> is a 3-byte fixed field that shows a packet number (sequential
number starting from 00) identifying the packet into which the Parameter Set is
divided for transfer, and the size of the <data> field that follows the <index> field.
i[0] ... 0nnnnnnn Packet Number LSB (NNNNNNNnnnnnnn = Packet Number)
i[1] ... 0NNNNNNN Packet Number MSB
As explained in the <data> field section, 128 bytes can be send per
packet, so received data can contain <Parameter Set start address> +
<Packet Number> * 128.
i[2] ... 0LLLLLLL data length / 3
As mentioned in the explanation of the <data> field, the length of the
<data> field is always a multiple of 3, so the length value is divided by 3.
• When act = 3 (BDR) or 5 (HDR)
This field is always empty.
• When act = 7 (HDA, HDJ, HDE, NOP)
In this case, the <index> field length is fixed at 1 byte, and it indicates the control
messages used for handshaking as shown below.
See "Bulk Dump" for information about this operation.
i[0] = 0000cccc
cccc Control Message
------
0000 EOD Oneway/Handshake Bulk Dump End of Data (End of Data)
0001 HDA Handshake Bulk Dump Acknowledge (Handshake Data Receive
Successful)
0010 HDR Handshake Bulk Dump Reject (Handshake Data Rejected)
0011 HDE Handshake Bulk Dump Error (Handshake Data Error)
:
1111 NOP (No Operation)
12 .....<data> Parameter Data (when action = Parameter Change/Send)
• When act = 1 (IPR), 3 (BDR), 5 (HDR), or 7 (HDA, HDJ, HDE, NOP)
This field is always empty.
• When act = 0 (IPC)
Indicates the parameter itself. The length varies in accordance with the data size
indicated by the dlen field, as shown below.
This field is not included in a parameter request.
ddddd + 1 <data> fields
-----------------------------------+---------------------------
1 - 7 1
8 - 14 2
15 - 21 3
22 - 28 4
29 - 32 5
Each block of data is packed from the lowest order byte first. In the case of multiple-
byte data, the lowest weighted bit is the LSB of the first <data> block, and the
highest weighted bit is the MSB of the final <data> block. The following shows an
example of how data would be divided for transfer in the case of 32-bit data.
7 6543210
----------------------------------------------------------------------------------
data0: 0 [bit06] [bit05] [bit04] [bit03] [bit02] [bit01] [bit00]
data1: 0 [bit13] [bit12] [bit11] [bit10] [bit09] [bit08] [bit07]
data2: 0 [bit20] [bit19] [bit18] [bit17] [bit16] [bit15] [bit14]
data3: 0 [bit27] [bit26] [bit25] [bit24] [bit23] [bit22] [bit21]
data4: 0 0 0 0 [bit31] [bit30] [bit29] [bit28]
• When act = 2 (BDS) or 4 (HDS)
When a bulk data transfer operation is performed, the Parameter Set data to be
transferred is read sequentially in 16-bit units starting from the top address. Read
valuesare divided into 3-byte segments as shownbelow, and thensent in sequence.
The following is the conversion format, which is the same as individual parameter
16-bit transfer explained above.
Memory Image 16 bits
MSB: abcccccc
LSB: cddddddd
<data> Field 3 bytes
data0: 0ddddddd
data1: 0ccccccc
data2: 000000ab
Note, however, that a Parameter Set of 128 bytes or less can be sent using a
single packet, and anything greater than 128 bytes is divided among multiple
packets.
This means the maximum length of a <data> field is as shown below.
128/2 * 3 = 192 bytes
Only one Parameter Set can be transferred per session, and data from different
Parameter Sets cannot be mixed within a single packet, even when sending multiple
Parameter Sets.
Different Parameter Sets are always divided into separate packets.
13 .....<sum> Check Sum
• When act = 0 (IPC), 1 (IPR), 3 (BDR), 5 (HDR), or 7 (HDA, HDJ, HDE, NOP)
This field is always empty.
• When act = 2 (BDS) or 4 (HDS)
In this case, the <sum> field contains a value, which, when added to the total
value of the <data> field, makes the lower seven bits 0.
The receiving side checks if this is true, and performs error handling (re-request,
etc.) if it is not.
14 .....EOX : End of System Exclusive Message
Format : 11110111
End of System Exclusive message Status = F7H
2.2 Individual Parameter Operations
There are two individual parameter operations: Individual Parameter Transfer and
Individual Parameter Request.
During a single session, an Individual Parameter Request (IPR) can be responded to by
returning an Individual Parameter Change (IPC) or by simply sending an IPC.
Receipt of an IPR causes the corresponding parameter IPC to be sent back.
Receipt of an IPC causes a change of the corresponding parameter value.
An Individual Parameter Change can also be used to issue some command to the CTK-
671, and the Individual Parameter Request can be used to check CTK-671 status
information.
➝

10
CTK-671 MIDI Implementation
Receiving Device Sending Device Operation
----------------------- --------------------- ---------------------------------------
IPR ➝Send Request (Optional)
IPC Data Transfer
See "Parameter List" in this document for information about which parameters can
actually be sent.
2.3 Parameter Set Transfer Modes
2.3.1 Communication Modes
Parameter Sets can be transferred by bulk dump, using the types of message exchanges
described below.
• One-way mode Parameter Set send/receive
• One-way mode Parameter Set send request send/receive
• Handshake mode Parameter Set send/receive
• Handshake mode Parameter Set send request, receive rejected, error notification send/
receive
With the One-way mode, the sending device sends data and ends the session without
paying any attention to the response of the receiving device. This mode is best for one-
way transfers from a sequencer or similar device.
With the Handshake mode, after the sending device sends the data, it confirms response
from the receiving device and then advances to the next session. This is a high-speed
mode in which there is no time wasted waiting.
See "Parameter Set" in this document for information about how Parameter Sets are
actually allocated.
In order to ensure maximum speed for bulk dumping of a Parameter Set, the data format
used is different from that used for Individual Parameter Change. Data is transferred as-
is, using the CTK-671 memory image.
One Parameter Set can be transferred per session.
A large Parameter Set can be divided into multiple packets for transfer. In this case,
<index> field packet numbers are used.
When transferring multiple groups of small Parameter Sets, each Parameter Set must be
allocated to its own packet. Multiple Parameter Sets cannot be included within the same
packet.
2.3.2 One-way Mode Communication Flow
A session starts with the receiving device sending a request using a BDR, or with the
sending device sending BDS data. The session ends after transfer of all of the data in
the Parameter Set being transferred by the sending device is complete.
When the CTK-671 receives a BDR, it sends back the applicable Set as a BDS. When
the CTK-671 receives a BDS, it changes the corresponding Parameter Set value.
Data is divided into multiple packets of 256 bytes or less each, and transfers them at
fixed intervals (20 msec).
A final EOD informs the receiving device that the session is ended.
Receiving Device Sending Device Operation
----------------------- --------------------- ------------------------------
BDR ➝Send Request (Optional)
BDS Data Transfer
20 msec or greater interval
BDS Data Transfer
20 msec or greater interval
BDS Data Transfer
20 msec or greater interval
:
:EOD Data Transfer
2.3.3 Handshake Mode Communication Flow
A session starts with the receiving device sending a request using an HDR, or with the
sending device sending HDS data.
The sending device does not send the next packet until it receives an ACK from the
receiving device. The maximum wait time is at least 100 msec. Failure of a response to
arrive within the wait time (at least 100 msec) is treated as a timeout error, and data
communication is terminated.
The sending device resends the last data if the receiving device returns an HDE (error)
due to checksum mismatch, incompatible data structure, or some other reason. If an
error repeats a number of times (undefined), either the sending device or the receiving
device sends an HDJ to terminate the session.
A session ends after the sending device sends all the Parameter Sets, and sends a final
EOD in response to an HAD (ACK) from the sending device.
Receiving Device Sending Device Operation
----------------------- --------------------- -----------------------------
HDR ➝Send Request (Optional)
HDS Data Send
HDA ➝Acknowledge
HDS Data Send
HDA ➝Acknowledge
:
:
HDA ➝Acknowledge
EOD End Of Data
The same packet is resent when a checksum mismatch or incompatible data structure
error is detected.
Receiving Device Sending Device Operation
----------------------- --------------------- -----------------------------
HDR ➝Send Request (Optional)
HDS Data Send
HDA ➝Acknowledge
HDS Data Send
HDE ➝Acknowledge
HDS Data Re-send
:
:
HDE ➝Acknowledge
EOD End Of Data
Data send is canceled whenACK is not received.
Receiving Device Sending Device Operation
----------------------- --------------------- -----------------------------
HDR ➝Send Request (Optional)
HDS Data Send
HDA ➝Acknowledge
HDS Data Send
HDJ ➝Rejection
(Send Canceled)
The session can be canceled for any reason by sending an HDJ. The HDJ can be sent
by the sending device or the receiving device. The bulk dump session is terminated
immediately upon receipt of an HDJ.
Receiving Device Sending Device Operation
----------------------- --------------------- -----------------------------
HDR ➝Send Request (Optional)
HDS Data Send
HDA ➝Acknowledge
HDS Data Send
:
HDJ ➝Data Receive Rejected
(Send Canceled)
➝
➝
➝
➝
➝
➝
➝
➝
➝
➝
➝
➝
➝
➝
➝
➝

11
CTK-671 MIDI Implementation
Receiving Device Sending Device Operation
----------------------- --------------------- -----------------------------
HDR ➝Send Request (Optional)
HDA ➝Acknowledge
HDS Data Send
HDA ➝Acknowledge
HDS Data Send
:HDJ Data Send Rejected
See "4. Parameter Set List" in this document for information about how Parameter Sets
can actually be sent.
3. Parameter List
This list shows the parameters that can be transferred individually using System Exclusive
Messages.
• Note 1
Any parameter that has "r" to the right of its Parameter ID number is a read-only
parameter that can be used for obtaining status information only.A parameter with "w"
next to its Parameter ID is a write-only parameter, which is used for commands, etc.
• Note 2
All values in the Parameter List are hexadecimal, unless specifically noted otherwise.
• Note 3
Receipt of a value outside a specified range causes the value marked "Default" to
be used instead.
3.1 Command Parameter
3.1.1 Parameter Set Overview
The parameters defined here mainly execute commands and indicate statuses. Values
indicate the pointer to a command or a status.
3.1.2 Command Parameter List
3.1.2.1 System Exclusive Format
+ ---------------------+ ------------------------------------------------------------------ +
Field Value
+ ----- + ------------ + ------------------------------------------------------------------ +
01 SYSEX F0
02 MAN 44
03 MOD 11, 01
04 dev 00 to 1F, or 7F
05 act 0(IPC), 1(IPR)
06 cat Command = 0
07 prm 00 - 7F
08 ilen 0
09 dlen bit size - 1
10 ps LSB,MSB = 00, 00
11 <index> 00
12 <data> See "2.1 Format."
13 <sum> None
14 EOX F7
+ ----- + ------------ + ------------------------------------------------------------------ +
3.1.2.2 Parameter List
ParamID Parameter bit Value Default Setting Value (Decimal)
--------------------------------------------------------------------------------------------------------------------
00r Model Version ID 8 00 0 00 = CTK671
This is the version number of models with the same System Exclusive Model ID = 11-01.
This value is used to specify the model for a parameter send request from an external
source.
03w Part DSP Cancel 10 0000 - FFFF 0 Bit0....Part1
Bit1....Part2
:
Bit15...Part16
0...Nop
1...DSP cancel
This is a request to look up and cancel the tone status of parts whose bits are set. It does
this by canceling the DSP Line selection of the parts whose corresponding bit is 1.
If the selected tone is an Advanced Tone, receipt of a DSP Line Cancel changes the
tone to its corresponding Normal Tone and then turns off the DSP Line.
When a NormalTone or User Tone is selected, the tone is not changed, but if the DSP
Line is on the DSP side, it is changed to Thru.
3.1.3 Song / Rhythm Pattern Command Parameter List
3.1.3.1 System Exclusive Format
+-----------------------+--------------------------------------------------------------------+
Field Value
+--------+-------------+--------------------------------------------------------------------+
01 SYSEX F0
02 MAN 44
03 MOD 11, 01
04 dev 00 to 1F, or 7F
05 act 0(IPC), 1(IPR)
06 cat Command = 0
07 prm 00 - 7F
08 ilen 0
09 dlen bit size - 1
10 ps LSB,MSB = 00, 00
11 <index> Song Number 0000 to 0001 or
Rhythm Number 0000 to 0003
00 when not needed
12 <data> See "2.1 Format."
13 <sum> None
14 EOX F7
+-----------------------+--------------------------------------------------------------------+
3.1.3.2 Parameter List
ParamID Parameter bit Value Default Setting Value (Decimal)
--------------------------------------------------------------------------------------------------------------------
----- Sequencer and Rhythm Pattern Data Command
21w Song Delete 8 0 - 1 0 Song Number
22w Rhythm Delete 8 0 - 3 0 Rhythm Number
23r Free Size 20 0 - FFFFFFFF 0 Free size (bytes)
This parameter reserves rhythm pattern and song memory space. The Song Number
and Rhythm Number specifications are not necessary.
--- Rhythm Information Parameter (index = Rhythm Number 0 - 3)
24r Rhythm Size 20 0 - FFFFFFFF 0 Rhythm size (bytes)
25r Rhythm Name A 20 0 - FFFFFFFF
556e7469 MSB is first
character.
26r Rhythm Name B 20 0 - FFFFFFFF
746c6564 MSB is first
character.
--- Song Information Parameter (index = Song Number 0 - 1)
27r Song Size 20 0 - FFFFFFFF 0 Song size (bytes)
28r Song Name A 20 0 - FFFFFFFF
556e7469 MSB is first
character.
29r Song Name B 20 0 - FFFFFFFF
746c6564 MSB is first
character.
3.2 Patch Parameter
3.2.1 Parameter Set Overview
The patch parameter is a temporary area that controls the operational status of the sound
source.
➝
➝
➝

12
CTK-671 MIDI Implementation
Note, however, that voices that are already sounding are maintained.
Since this parameter has virtually no affect on DSP output, reverberating sound within
the DSP and the LoFi noise generator signal continue to be output, even when the
"Cancel" setting is selected.
• System Chorus
ParamID Parameter bit Value Default Setting Value (Decimal)
--------------------------------------------------------------------------------------------------------------------
10 Chorus Macro Num 5 00 - 0F 02 0 - 15
Selects the System Chorus preset type.
Receipt of GM On selects Chorus3.
Operation of this type value is also linked with the following parameters, and changes
them to prescribed values.
See "6.1.1.11 Chorus Type Setting Value Table."
11 Chorus Level 7 00 - 7F 40 0 - 127
12 Chorus Rate 7 00 - 7F 03 0 - 127
13 Chorus Depth 7 00 - 7F 13 0 - 127
14 Chorus Feedback 7 00 - 7F 00 0 - 127
Sets System Chorus feedback amount.
15 Chorus Tone 7 00 - 7F 7F 0 - 127
Adjusts the System Chorus timbre.
• System Reverb
ParamID Parameter bit Value Default Setting Value (Decimal)
--------------------------------------------------------------------------------------------------------------------
18 Reverb Macro Num 5 00 - 0F 04 0 - 15
Selects the System Reverb preset type.
Receipt of GM On selects Hall2.
Operation of this type value is also linked with the following parameters, and changes
them to prescribed values.
See "6.1.1.10 Reverb Type Setting Value Table."
19 Reverb Level 7 00 - 7F 40 0 - 127
1A
Reverb Time/Del Feedback 7 00 - 7F 40 0 - 127
1B Reverb ER Level 7 00 - 7F 40 0 - 127
1C Reverb Hi Damp 7 00 - 7F 40 0 - 127
1D Reverb Tone 7 00 - 7F 7F 0 - 127
• Master Equalizer
ParamID Parameter bit Value Default Setting Value (Decimal)
--------------------------------------------------------------------------------------------------------------------
20 Master EQ Macro Num 5 00 - 13 00
Selects the Master EQ preset type.
Receipt of GM On selects Standard.
Operation of this type value is also linked with the following parameters, and changes
them to prescribed values.
See "6.1.1.9 Master EQ Type Setting Value Table."
21 MasEq Lo Freq 7 00 - 7F 40 0 - 2
Selects the Master EQ low-range cutoff frequency.
See the "6.1.1.12 Equalizer Low Frequency Setting ValueTable."
22 MasEq Lo Gain 7 00 - 40 - 7F 40 -12 - 0 - +12
Selects the Master EQ low-range gain.
See the "6.1.1.15 Equalizer Gain Setting Value Table."
23 MasEq Mid-Lo Freq 7 00 - 7F 40 0 - 7
Selects the Master EQ mid frequency.
See the "6.1.1.13 Equalizer Low Frequency Setting ValueTable."
Mixer settings, synthesizer function, DSP function and other editable parameters are
also included in this function.
The contents of this area are rewritten whenever preset data or user data is selected.
The parameters in this area are written into the user area whenever data is written into
the user data area.
3.2.2 Patch Common Parameter List
This list shows parameters that are common for each part.
3.2.2.1 System Exclusive Format
+ ---------------------+ ------------------------------------------------------------------ +
Field Value
+ ----- + ------------ + ------------------------------------------------------------------ +
01 SYSEX F0
02 MAN 44
03 MOD 11, 01
04 dev 00 to 1F, or 7F
05 act 0(IPC), 1(IPR)
06 cat Patch = 1
07 prm 00 - 7F
08 ilen 0
09 dlen bit size - 1
10 ps LSB,MSB = 00, 00
11 <index> 00
12 <data> See "2.1 Format."
13 <sum> None
14 EOX F7
+ ----- + ------------ + ------------------------------------------------------------------ +
3.2.2.2 Parameter List
• MIDI Parameter
ParamID Parameter bit Value Default Setting Value (Decimal)
--------------------------------------------------------------------------------------------------------------------
00 MIDI Device ID 7 00 - 1F 10 0 - 31
This parameter sets the SysEx Device ID.
01 MIDI Global Ch 4 00 - 0F 00 1 - 16
• Tune / Mix Parameter
ParamID Parameter bit Value Default Setting Value (Decimal)
--------------------------------------------------------------------------------------------------------------------
04 Master Fine Tune 8 00 - FF 80 -100 - 0 - 99cent
See the "6.1.1.7 -99 - 0 - 99 Setting Value Table."
05 Master Coarse Tune 7 28 - 58 40 -24 - 0 - 24semi
See the "6.1.1.4 -24 - 0 - 24 Setting Value Table."
08 Master Volume 7 00 - 7F 7F 0 - 127
09 Master Pan 7 00 - 7F 40 -64 - 0 - 64
See the "6.1.1.6 Pan Setting Value Table."
0A Chorus Send To Reverb 7 00 - 7F 00 0 - 127
This specifies the volume of data sent from System Chorus to System Reverb.
0B DSP Line Cancel 1 0 - 1 0 0...Normal
1...DSP Cancel
DSP Cancel corresponds to the control panel's DSP Off/On setting. Specifying "Cancel"
for this value forces disabling of DSP input for all voices, and produces sounds through
the system.

13
CTK-671 MIDI Implementation
24 MasEq Mid-Lo Gain 7 00 - 40 - 7F 40 -12 - 0 - +12
Selects the Master EQ mid-range gain.
See the "6.1.1.15 Equalizer Gain Setting Value Table."
25 MasEq Mid-Hi Freq 7 00 - 7F 40 0 - 7
Selects the Master EQ mid-high frequency type.
See the "6.1.1.13 Equalizer Mid Frequency Setting Value Table."
26 MasEq Mid-Hi Gain 7 00 - 40 - 7F 40 -12 - 0 - +12
Selects the Master EQ mid-high range gain.
See the "6.1.1.15 Equalizer Gain Setting Value Table."
27 MasEq Hi Freq 7 00 - 7F 40 0 - 2
Selects the Master EQ high-range cutoff frequency.
See the "6.1.1.14 Equalizer High Frequency Setting Value Table."
28 MasEq Hi Gain 7 00 - 40 - 7F 40 -12 - 0 - +12
Selects the Master EQ high-range gain.
See the "6.1.1.15 Equalizer Gain Setting Value Table."
• DSP Patch Parameter
This block also stores values when the DSP Type orTone is changed.
ParamID Parameter bit Value Default Setting Value (Decimal)
--------------------------------------------------------------------------------------------------------------------
2C DSP Type Number 7 00 - 7F 00 0 - 99 Preset
100 - 109 User
Selects the DSP Type.
Receipt of GM On selects "014 Delay."
127 is stored when a tone-associated DSP is read into the DSP area.
2D DSP Hold 1 0 - 1 0 0...Off
1...On
2E DSP Level 7 00 - 7F 64 0 - 127
2F DSP Pan 7 00 - 7F 40 -64 - 0 - 63
See the "6.1.1.6 Pan Setting Value Table."
• DSP Type parameter
The value of this parameter is rewritten whenever the DSP Type orTone is changed.
ParamID Parameter bit Value Default Setting Value (Decimal)
--------------------------------------------------------------------------------------------------------------------
30 DSP Name A 20 0 - FFFFFFFF 556e7469 MSB is first character.
31 DSP Name B 20 0 - FFFFFFFF 746c6564 MSB is first character.
These parameters change the DSP name. One character is indicated by each byte.
32r DSPAlgorithm ID 7 00 - 3F 00 0 - 63
This value is the DSP algorithm ID, which cannot be changed at the user level.
Changing the DSPType orTone Number causes the algorithm ID of the main DSP to
be copied automatically to this area.
See "6.1.1.16 DSP Algorithm ID Table."
33 DSP Chorus Send 7 00 - 7F 40 0 - 127
34 DSP Reverb Send 7 00 - 7F 40 0 - 127
DSP Type Independent Parameters
The eight parameters listed below are DSP User Parameters that can be set from the
control panel, while the next 16 parameters are Internal Parameters that cannot be
edited on the control panel. The range of these parameter values is 0 to 127, regardless
of the DSPalgorithm. However, the parameters that are available depend on the DSP
algorithm, which means that not all User Parameters and Internal Parameters are
necessarily available as a particular DSP's parameters.
See the "DSP Parameter List" for details about parameters and their contents.
ParamID Parameter bit Value Default Setting Value (Decimal)
--------------------------------------------------------------------------------------------------------------------
38 DSP User Parameter0 7 00 - 7F - 0 - 127
39 DSP User Parameter1 7 00 - 7F - 0 - 127
3A DSP User Parameter2 7 00 - 7F - 0 - 127
3B DSP User Parameter3 7 00 - 7F - 0 - 127
3C DSP User Parameter4 7 00 - 7F - 0 - 127
3D DSP User Parameter5 7 00 - 7F - 0 - 127
3E DSP User Parameter6 7 00 - 7F - 0 - 127
3F DSP User Parameter7 7 00 - 7F - 0 - 127
40 DSP Internal Param00 7 00 - 7F - 0 - 127
41 DSP Internal Param01 7 00 - 7F - 0 - 127
42 DSP Internal Param02 7 00 - 7F - 0 - 127
43 DSP Internal Param03 7 00 - 7F - 0 - 127
44 DSP Internal Param04 7 00 - 7F - 0 - 127
45 DSP Internal Param05 7 00 - 7F - 0 - 127
46 DSP Internal Param06 7 00 - 7F - 0 - 127
47 DSP Internal Param07 7 00 - 7F - 0 - 127
48 DSP Internal Param08 7 00 - 7F - 0 - 127
49 DSP Internal Param09 7 00 - 7F - 0 - 127
4A DSP Internal Param10 7 00 - 7F - 0 - 127
4B DSP Internal Param11 7 00 - 7F - 0 - 127
4C DSP Internal Param12 7 00 - 7F - 0 - 127
4D DSP Internal Param13 7 00 - 7F - 0 - 127
4E DSP Internal Param14 7 00 - 7F - 0 - 127
4F DSP Internal Param15 7 00 - 7F - 0 - 127
3.2.3 Patch Part Parameter List
This list shows parameters that are specific for each part.
3.2.3.1 System Exclusive Format
+ ---------------------+ ------------------------------------------------------------------ +
Field Value
+ ----- + ------------+ ------------------------------------------------------------------ +
01 SYSEX F0
02 MAN 44
03 MOD 11, 01
04 dev 00 to 1F, or 7F
05 act 0(IPC), 1(IPR)
06 cat Patch = 1
07 prm 00 - 7F
08 ilen 0
09 dlen bit size - 1
10 ps Parameter Set Number LSB,MSB = 00, 00
11 <index> Part Number(00-0F)
12 <data> See "2.1 Format."
13 <sum> None
14 EOX F7
+ ----- + ------------+ ------------------------------------------------------------------ +
3.2.3.2 Parameter List
• Basic parameter
ParamID Parameter bit Value Default Setting Value (Decimal)
--------------------------------------------------------------------------------------------------------------------
50 Tone Number E 000 - 189 Tone Number
This value is the tone number allocated to this part.

14
CTK-671 MIDI Implementation
000 - 063 Panel NormalTone
064 - 0C7 Panel DSP Tone
0C8 - 147 Panel GM Tone
148 - 151 Drum
180 - 189 UserTone
51 Part Octave Shit 3 2 - 6 4 -2 - 0 - 2 Oct
52 Part Enable 1 0 - 1 1 0...Disable (Off)
1...Enable (On)
53 Part Mode 1 0 - 1 0 0...Melody
1...Rhythm
Sets the melody and rhythm modes of the part play operation.
• Tune / Mix parameter
ParamID Parameter bit Value Default Setting Value (Decimal)
--------------------------------------------------------------------------------------------------------------------
54 Pitch Fine Tune 8 00 - FF 80 -99 - 0 - 99cent
55 Pitch Coarse Tune 7 28 - 58 40 -24 - 0 - 24semi
56 Volume 7 00 - 7F 7F 0 - 127
57 Accomp Volume 7 00 - 7F 7F 0 - 127
58 Bend Range 7 00 - 18 02 0 - +24
59 Pan 7 00 - 7F 40 -64 - 0 - 63
• Tone parameter
ParamID Parameter bit Value Default Setting Value (Decimal)
--------------------------------------------------------------------------------------------------------------------
60 Tone Name A 20
0 - FFFFFFFF 556e7469 MSB is first character.
61 Tone Name B 20
0 - FFFFFFFF 746c6564 MSB is first character.
These parameters change the tone name. One character is indicated by each byte.
64 Line Select 1 0 - 1 0 0...Thru
1...DSP
65 Tone Octave Shit 3 2 - 6 4 -2 - 0 - +2 Oct
66 ToneAttack Time 7 00 - 7F 40 -64 - 0 - +63
67 Tone Release Rate 7 00 - 7F 40 -64 - 0 - +63
68 Tone DCF Cutoff 7 00 - 7F 40 -64 - 0 - +63
69 Tone DCF Resonance 7 00 - 7F 40 -64 - 0 - +63
6A Chorus Send 7 00 - 7F 00 0 - 127
6B Reverb Send 7 00 - 7F 32 0 - 127
6C Tone Level 7 00 - 7F 7F 0 - 127
6D Tone Touch Sens 7 00 - 7F 40 -64 - 0 - +63
• LFO Parameter
ParamID Parameter bit Value Default Setting Value (Decimal)
--------------------------------------------------------------------------------------------------------------------
7A LFO Wave 4 0 - 3 0 LFO Waveform
0....Triangle
1....Saw Up
2....Square
3....Sin
7B LFO Delay 7 00 - 7F 40 -64 - 0 - 64
7C LFO Rate 7 00 - 7F 40 -64 - 0 - 64
7D LFO Pitch Depth 7 00 - 7F 40 -64 - 0 - 64
7E LFO Modulation Sens 7 00 - 7F 00 0 - 127
This parameter adjusts the depth of the LFO effect when the Modulation MIDI Control
Change is received.
7F LFO Aftertouch Sens 7 00 - 7F 00 0 - 127
This parameter adjusts the depth of the LFO effect when MIDI Channel Aftertouch is
received.
• About the Part Mode
Each of the CTK-671' parts has a parameter called "Part Mode," which can be set to
either Melody mode or Rhythm mode. Melody tones must be set to the Melody mode,
while drum maps used for rhythm tones must be set to the Rhythm mode.
The Part Mode parameter can be changed using a System Exclusive message (see the
section of this document titled "CTK-671 System Exclusive Format"). The Part Mode
parameter can also be changed by receipt of a Program Change message in accordance
with the Bank number specified by a Bank Select message.
Operation at this time depends on the receiving MIDI channel, as indicated below.
Operation when Bank Select/Program change is received over channel other than
Channel 10
If the Bank Select MSB is 78H, 7EH, or 7FH, receipt of Program Change switches to
the Rhythm mode.
For any other Bank Select MSB, receipt of the Program Change message changes to
the Melody mode.
Operation when Bank Select/Program change is received over Channel 10
If the Bank Select MSB is 78H, 7EH, or 7FH, receipt of Program Change message
switches to the Rhythm mode.
If the Bank Select MSB is 41H, 42H, 43H, 44H, 45H, 46H, or 79H, receipt of Program
Change changes to the Melody mode.
For any other Bank Select MSB, receipt of the Program Change message does not
change the Play Mode.
4. Parameter Set List
This list shows the Parameter Sets that can be transferred using System Exclusive
Message Bulk Dump.
4.1 User Tone Parameter Set
• System Exclusive Format
+ ---------------------+ ---------------------------------------------------------------------------------- +
Field Value
+ ----- + ------------+ ---------------------------------------------------------------------------------- +
01 SYSEX F0
02 MAN 44
03 MOD 11, 01
04 dev 00 to 1F, or 7F
05 act 2(BDS), 3(BDR), 4(HDS), 5(HDR), 7(Control)
06 cat Tone = 2
07 prm 00 - 7F
08 ilen See "2.1 Format."
09 dlen See "2.1 Format."
10 ps Indicates the tone number being transferred.
User Tones 01 to 10 correspond to 0180H to 0189H.
See "Tone Number" in the "3.2.3 Patch Part Parameter List."
11 <index> See "2.1 Format."
12 <data> See "2.1 Format."
13 <sum> See "2.1 Format."
14 EOX F7
+ ----- + ------------+ ---------------------------------------------------------------------------------- +
4.2 User DSP Parameter Set
• System Exclusive Format

15
CTK-671 MIDI Implementation
+ ---------------------+ --------------------------------------------------------------------------------------+
Field Value
+ ----- + ------------ + --------------------------------------------------------------------------------------+
01 SYSEX F0
02 MAN 44
03 MOD 11, 01
04 dev 00 to 1F, or 7F
05 act 2(BDS), 3(BDR), 4(HDS), 5(HDR), 7(Control)
06 cat DSP = 9
07 prm 00 - 7F
08 ilen See "2.1 Format."
09 dlen See "2.1 Format."
10 ps Indicates the DSP number being transferred.
User DSP 01 to 10 correspond to 0064H to 006DH.
See "DSP Type Number" in the “3.2.3 Patch Part
Parameter List.”
11 <index> See "2.1 Format."
12 <data> See "2.1 Format."
13 <sum> See "2.1 Format."
14 EOX F7
+ ----- + ------------ + --------------------------------------------------------------------------------------+
4.3 Song Data
• System Exclusive Format
+ ---------------------+ --------------------------------------------------------------------------------------+
Field Value
+ ----- + ------------ + --------------------------------------------------------------------------------------+
01 SYSEX F0
02 MAN 44
03 MOD 11, 01
04 dev 00 to 1F, or 7F
05 act 2(BDS), 3(BDR), 4(HDS), 5(HDR), 7(Control)
06 cat Song = A
07 prm 00
08 ilen See "2.1 Format."
09 dlen See "2.1 Format."
10 ps Indicates the song number being transferred.
Song 0 and 1 correspond to 0000H and 0001H.
See "DSP Type Number" in the "3.2.3 Patch Part
Parameter List."
11 <index> See "2.1 Format."
12 <data> See "2.1 Format."
13 <sum> See "2.1 Format."
14 EOX F7
+ ----- + ------------ + --------------------------------------------------------------------------------------+
4.4 User Rhythm Pattern
• System Exclusive Format
+ ---------------------+ --------------------------------------------------------------------------------------+
Field Value
+ ----- + ------------ + --------------------------------------------------------------------------------------+
01 SYSEX F0
02 MAN 44
03 MOD 11, 01
04 dev 00 to 1F, or 7F
05 act 2(BDS), 3(BDR), 4(HDS), 5(HDR), 7(Control)
06 cat DSP = B
07 prm 00 - F
08 ilen See "2.1 Format."
09 dlen See "2.1 Format."
10 ps Indicates the rhythm number being transferred.
User Rhythms 01 to 04 correspond to 0000H to 0003H.
See "DSP Type Number" in the "3.2.3 Patch Part
Parameter List."
11 <index> See "2.1 Format."
12 <data> See "2.1 Format."
13 <sum> See "2.1 Format."
14 EOX F7
+ ----- + ------------ + --------------------------------------------------------------------------------------+
4.5 Registration Data
• System Exclusive Format
+ ---------------------+ --------------------------------------------------------------------------------------+
Field Value
+ ----- + ------------+ --------------------------------------------------------------------------------------+
01 SYSEX F0
02 MAN 44
03 MOD 11, 01
04 dev 00 to 1F, or 7F
05 act 2(BDS), 3(BDR), 4(HDS), 5(HDR), 7(Control)
06 cat DSP = C
07 prm 00 - 7F
08 ilen See "2.1 Format."
09 dlen See "2.1 Format."
10 ps Indicates the Registration number being transferred.
Registration 0-1 to 3-4 correspond to 0000H to 000FH.
See "DSP Type Number" in the "3.2.3 Patch Part
Parameter List."
11 <index> See "2.1 Format."
12 <data> See "2.1 Format."
13 <sum> See "2.1 Format."
14 EOX F7
+ ----- + ------------+ --------------------------------------------------------------------------------------+
5. DSP Parameter List
This list shows the parameters for each of the DSP algorithms.
• U0 to U7 indicate User Parameters 0 to 7, while I00 to I15 indicate Internal Parameters
00 to 15.
• In the case of parameters for which no setting range is indicated, receipt of a value
from 0 to 127 is assigned as-is to the parameter.
Algorithm 00 (00H) : Auto Pan
• U0 Rate
• U1 Depth
Algorithm 01 (01H) : Tremolo
• U0 Rate
• U1 Depth
Algorithm 02 (02H) : 2BandEQ
• U0 Low Frequency - See the "6.1.1.12 Equalizer Low Frequency Setting Value
Table."
• U1 Low Gain - See the "6.1.1.15 Equalizer Gain Setting ValueTable."
• U2 High Frequency - See the "6.1.1.14 Equalizer High Frequency Setting Value
Table."
• U3 High Gain - See the "6.1.1.15 Equalizer Gain Setting ValueTable."
Algorithm 03 (03H) : 3BandEQ
• U0 Low Frequency - See the "6.1.1.12 Equalizer Low Frequency Setting Value
Table."
• U1 Low Gain - See the "6.1.1.15 Equalizer Gain Setting Value Table."
• U2 Mid Frequency - See the "6.1.1.13 Equalizer Mid Frequency Setting Value
Table."
• U3 Mid Gain - See the "6.1.1.15 Equalizer Gain Setting Value Table."
• U4 High Frequency - See the "6.1.1.14 Equalizer High Frequency Setting Value
Table."
• U5 High Gain - See the "6.1.1.15 Equalizer Gain Setting Value Table."
Algorithm 04 (04H) : LFO Wah
• U0 Input Level
• U1 Resonance
• U2 Manual
• U3 LFO Rate
• U4 LFO Depth

16
CTK-671 MIDI Implementation
Algorithm 05 (05H) : Auto Wah
•U0 Input Level
•U1 Resonance
•U2 Manual
•U3 Depth See the "6.1.1.5 -64 - 0 - 63 Setting ValueTable."
•I00 Sensitivity
Algorithm 06 (06H) : Compressor
•U0 Depth
•U1 Attack
•U2 Release
•U3 Level
•I00 Threshold Adjusts the Compressor threshold level.
Algorithm 07 (07H) : Limiter
•U0 Limit
•U1 Attack
•U2 Release
•U3 Level
Algorithm 08 (08H) : Distortion
•U0 Gain
•U1 Low
•U2 High
•U3 Level
Algorithm 09 (09H) : Stereo Phaser
•U0 Resonance
•U1 Manual See the "6.1.1.5 -64 - 0 - 63 Setting Value Table."
•U2 Rate
•U3 Depth
•U4 Wet Level
Algorithm 10 (0AH) : Phaser
•U0 Resonance
•U1 Manual See the "6.1.1.5 -64 - 0 - 63 Setting Value Table."
•U2 Rate
•U3 Depth
•U4 Wet Level
Algorithm 11 (0BH) : Rotary
•U0 Speed
•U1 Break See the "6.1.1.3 Rotate/Break Setting Value Table."
•U2 Fall Accel
•U3 Rise Accel
•U4 Slow Rate
•U5 Fast Rate
Algorithm 12 (0CH) : Drive - Rotary
•U0 Overdrive Gain
•U1 Overdrive Level
•U2 Speed See the "6.1.1.2 Slow/Fast Setting Value Table."
•U3 Break See the "6.1.1.3 Rotate/Break Setting Value Table."
•U4 Fall Accel
•U5 Rise Accel
•U6 Slow Rate
•U7 Fast Rate
Algorithm 13 (0DH) : Enhancer
•U0 Low Frequency
•U1 Low Gain
•U2 High Frequency
•U3 High Gain
Algorithm 14 (0EH) : Ring Modulator
•U0 OSC Frequency
•U1 LFO Rate
•U2 LFO Depth
•U3 Wet Level
•U4 Dry Level
Algorithm 15 (0FH) : LoFi
•U0 Noise Level 1
•U1 Noise Density 1
•U2 Noise Level 2
•U3 Noise Density 2
•U4 Tone
•U5 Resonance
•U6 Bass See the "6.1.1.5 -64 - 0 - 63 Setting Value Table."
•U7 Level
Algorithm 16 (10H) : 1 Phase Chorus
•U0 LFO Rate
•U1 LFO Depth
•U2 Feedback See the "6.1.1.5 -64 - 0 - 63 Setting Value Table."
•U3 Wet Level
Algorithm 17 (11H) : Sin 2-Phase Chorus
•U0 LFO Rate
•U1 LFO Depth
•U2 Feedback See the "6.1.1.5 -64 - 0 - 63 Setting Value Table."
•U3 Wet Level
Algorithm 18 (12H) : 3-Phase Chorus
•U0 Rate1
•U1 Depth1
•U2 Rate2
•U3 Depth2
•U4 Wet Level
Algorithm 19 (13H) : Tri 2-Phase Chorus
•U0 LFO Rate
•U1 LFO Depth
•U2 Feedback See the "6.1.1.5 -64 - 0 - 63 Setting Value Table."
•U3 Wet Level
Algorithm 20 (14H) : Stereo Delay 1
•U0 Delay Time
•U1 Wet Level
•U2 Feedback
•U3 High Damp
•U4 Ratio L
•U5 Ratio R
Algorithm 21 (15H) : Stereo Delay 2
•U0 Delay Time
•U1 Wet Level
•U2 Feedback
•U3 High Damp
•U4 Ratio L
•U5 Ratio R
Algorithm 22 (16H) : 3-Tap Delay
•U0 Delay Time
•U1 Wet Level
•U2 Feedback
•U3 High Damp
•U4 Ratio L
•U5 Ratio C
•U6 Ratio R
Algorithm 23 (17H) : Gate Reverb
•U0 LPF
•U1 HPF
•U2 Feedback
•U3 High-Damp
•U4 Diffusion
•U5 Wet Level
•U6 Dry Level

17
CTK-671 MIDI Implementation
Algorithm 24 (18H) : Reverse Gate Reverb
• U0 LPF
• U1 HPF
• U2 Feedback
• U3 High-Damp
• U4 Diffusion
• U5 Wet Level
• U6 Dry Level
Algorithm 25 (19H) : Reflection
• U0 Type See the 6.1.1.8 "Type 0 to Type 7 Setting Value Table."
• U1 Wet Level
• U2 Feedback
• U3 Tone
Algorithm 26 (1AH) : Flanger
• U0 LFO Rate
• U1 LFO Depth
• U2 Feedback See the "6.1.1.5 -64 - 0 - 63 Setting ValueTable."
• U3 Wet Level
Algorithm 27 (1BH) : Reverb
• U0 Tone
• U1 Time
• U2 High-Damp
• U3 ER Level
• U4 Wet Level
Algorithm 28 (1CH) : 2-Tap Delay
• U0 Delay Time
• U1 Wet Level
• U2 Feedback
• U3 High-Damp
• U4 Ratio L
• U5 Ratio R
◆The multi algorithms (M00 to M31) listed below are combinations of the algorithms
described above. Parameter operations and other details are the same as the previous
algorithms, so there is no separate explanation provided here.
Algorithm M00 (20H) : Multi00
• U0 Chorus Rate
• U1 Chorus Depth
• U2 Chorus Feedback
• U3 Chorus Wet Level
• U4 Delay Time
• U5 Delay Wet Level
• U6 Delay Feedback
• U7 Delay High-Damp
• I06 Delay Ratio L
• I07 Delay Ratio R
Algorithm M01 (21H) : Multi01
• U0 Chorus Fast Rate
• U1 Chorus Fast Depth
• U2 Chorus Slow Rate
• U3 Chorus Slow Depth
• U4 Chorus Wet Level
• U5 Delay Time
• U6 Delay Wet Level
• U7 Delay Feedback
• I03 Delay High-Damp
• I04 Delay Ratio L
• I05 Delay Ratio C
• I06 Delay Ratio R
Algorithm M02 (22H) : Multi02
• U0 Phaser Resonance
• U1 Phaser Manual
• U2 Phaser Rate
• U3 Phaser Depth
• U4 Chorus Rate 1
• U5 Chorus Depth 1
• U6 Chorus Rate 2
• U7 Chorus Depth 2
• I03 Phaser Wet Level
• I06 Chorus Wet Level
Algorithm M03 (23H) : Multi03
• U0 Flanger LFO Rate
• U1 Flanger LFO Depth
• U2 Flanger Feedback
• U3 Flanger Wet Level
• U4 Delay Time
• U5 Delay Wet Level
• U6 Delay Feedback
• U7 Delay High-Damp
• I06 Delay Ratio L
• I07 Delay Ratio R
Algorithm M04 (24H) : Multi04
• U0 Phaser Resonance
• U1 Phaser Manual
• U2 Phaser Rate
• U3 Phaser Depth
• U4 Phaser Wet Level
• U5 Delay Time
• U6 Delay Wet Level
• U7 Delay Feedback
• I05 Delay High-Damp
• I06 Delay Ratio L
• I07 Delay Ratio R
Algorithm M05 (25H) : Multi05
• U0 Enhancer Low Frequency
• U1 Enhancer Low Gain
• U2 Enhancer High Frequency
• U3 Enhancer High Gain
• U4 Chorus LFO Rate
• U5 Chorus LFO Depth
• U6 Chorus Feedback
• U7 Chorus Wet Level
Algorithm M06 (26H) : Multi06
• U0 Enhancer Low Frequency
• U1 Enhancer Low Gain
• U2 Enhancer High Frequency
• U3 Enhancer High Gain
• U4 Delay Time
• U5 Delay Wet Level
• U6 Delay Feedback
• U7 Delay High-Damp
• I06 Delay Ratio L
• I07 Delay Ratio R
Algorithm M07 (27H) : Multi07
• U0 Enhancer Low Frequency
• U1 Enhancer Low Gain
• U2 Enhancer High Frequency
• U3 Enhancer High Gain
• U4 Flanger LFO Rate
• U5 Flanger LFO Depth
• U6 Flanger Feedback
• U7 Flanger Wet Level
• I06 Flanger Delay Time L
• I07 Flanger Delay Time R

18
CTK-671 MIDI Implementation
Algorithm M08 (28H) : Multi08
• U0 Chorus LFO Rate
• U1 Chorus LFO Depth
• U2 Chorus Feedback
• U3 Chorus Wet Level
• U4 Flanger LFO Rate
• U5 Flanger LFO Depth
• U6 Flanger Feedback
• U7 Flanger Wet Level
Algorithm M09 (29H) : Multi09
• U0 Chorus LFO Rate
• U1 Chorus LFO Depth
• U2 Chorus Feedback
• U3 Chorus Wet Level
• U4 Tremolo Rate
• U5 Tremolo Depth
Algorithm M10 (2AH) : Multi10
• U0 Phaser Resonance
• U1 Phaser Manual
• U2 Phaser Rate
• U3 Phaser Depth
• U4 Phaser Wet Level
• U5 Auto Pan Rate
• U6 Auto Pan Depth
Algorithm M11 (2BH) : Multi11
• U0 Compressor Depth
• U1 Compressor Attack
• U2 Compressor Level
• U3 Lo-Fi Noise 1
• U4 Lo-Fi Noise 2
• U5 Lo-Fi Tone
• U6 Lo-Fi Resonance
• U7 Lo-Fi Bass
• I00 Compressor Threshold
• I01 Compressor Release
• I02 Lo-Fi Noi1 Thrs
• I03 Lo-Fi Noi2 Thrs
• I04 Lo-Fi Level
Algorithm M12 (2CH) : Multi12
• U0 Ring OSC Frequency
• U1 Ring LFO Rate
• U2 Ring LFO Depth
• U3 Ring Wet Level
• U4 Ring Dry Level
• U5 Chorus LFO Depth
• U6 Delay Time
• U7 Delay Wet Level
• I00 Chorus LFO Rate
• I01 Chorus Feedback
• I02 Chorus Wet Level
• I09 Delay Feedback
• I10 Delay High-Damp
• I11 Delay Ratio L
• I12 Delay Ratio R
Algorithm M13 (2DH) : Multi13
• U0 Ring OSC Frequency
• U1 Ring LFO Rate
• U2 Ring LFO Depth
• U3 Ring Wet Level
• U4 Ring Dry Level
• U5 Distortion Gain
• U6 Distortion Tone
• U7 Distortion Level
Algorithm M14 (2EH) : Multi14
• U0 Lo-Fi Noise1
• U1 Lo-Fi Noise2
• U2 Lo-Fi Tone
• U3 Lo-Fi Resonance
• U4 Reflection Type
• U5 Reflection Wet Level
• U6 Reflection Feedback
• U7 Reflection Tone
• I00 Lo-Fi Noi1 Dens
• I01 Lo-Fi Noi2 Dens
• I02 Lo-Fi Bass
• I03 Lo-Fi Level
Algorithm M15 (2FH) : Multi15
• U0 Distortion Gain
• U1 Distortion Low
• U2 Distortion Tone
• U3 Distortion Level
• U4 Lo-Fi Noise1
• U5 Lo-Fi Noise2
• U6 Lo-Fi Tone
• U7 Lo-Fi Resonance
• I12 Lo-Fi Noi1 Dens
• I13 Lo-Fi Noi2 Dens
• I14 Lo-Fi Bass
• I15 Lo-Fi Level
Algorithm M16 (30H) : Multi16
• U0 Od Gain
• U1 Od Level
• U2 Rot Speed
• U3 Rot Slow Rate
• U4 Rot Fast Rate
• U5 Reflection Wet Level
• U6 Reflection Feedback
• U7 Reflection Tone
• I09 Rot FallAccel
• I10 Rot Rise Accel
• I11 Rot Break
• I12 Reflection Type
Algorithm M17 (31H) : Multi17
• U0 Rot Speed
• U1 Rot Break
• U2 Rot Slow Rate
• U3 Rot Fast Rate
• U4 Reflection Wet Level
• U5 Reflection Feedback
• U6 Reflection Tone
• I10 Rot FallAccel
• I11 Rot Rise Accel
• I12 Reflection Type
Algorithm M18 (32H) : Multi18
• U0 Compressor Depth
• U1 Compressor Attack
• U2 Compressor Level
• U3 Enhancer Low Gain
• U4 Enhancer High Gain
• U5 Delay Time
• U6 Delay Wet Level
• U7 Delay Feedback
• I00 Compressor Threshold
• I01 Compressor Release
• I06 Enhancer Low Frequency
• I07 Enhancer High Frequency
• I10 Delay High-Damp
• I11 Delay Ratio L
• I12 Delay Ratio R

19
CTK-671 MIDI Implementation
Algorithm M19 (33H) : Multi19
• U0 Compressor Depth
• U1 Compressor Attack
• U2 Compressor Release
• U3 Compressor Level
• U4 Delay Time
• U5 Delay Wet Level
• U6 Delay Feedback
• U7 Delay High-Damp
• I00 Compressor Threshold
• I03 Delay Ratio L
• I04 Delay Ratio R
Algorithm M20 (34H) : Multi20
• U0 Phaser Resonance
• U1 Phaser Manual
• U2 Phaser Rate
• U3 Phaser Depth
• U4 Chorus LFO Rate
• U5 Chorus LFO Depth
• U6 Auto Pan Rate
• U7 Auto Pan Depth
• I03 Phaser Wet Level
• I04 Chorus Feedback
Algorithm M21 (35H) : Multi21
• U0 Wah Resonance
• U1 Wah Manual
• U2 Wah Depth
• U3 Chorus LFO Rate
• U4 Chorus LFO Depth
• U5 Delay Time
• U6 Delay Wet Level
• U7 Delay Feedback
• I00 Wah Sens
• I04 Chorus Feedback
• I05 Chorus Wet Level
• I10 Delay High-Damp
• I11 Delay Ratio L
• I12 Delay Ratio R
Algorithm M22 (36H) : Multi22
• U0 Wah Resonance
• U1 Wah Manual
• U2 Wah LFO Rate
• U3 Wah LFO Depth
• U4 Chorus LFO Depth
• U5 Delay Time
• U6 Delay Wet Level
• U7 Delay Feedback
• I02 Chorus Feedback
• I03 Chorus Wet Level
• I06 Chorus LFO Rate
• I09 Delay High-Damp
• I10 Delay Ratio L
• I11 Delay Ratio R
Algorithm M23 (37H) : Multi23
• U0 Compressor Depth
• U1 Compressor Attack
• U2 Compressor Level
• U3 Chorus LFO Rate
• U4 Chorus LFO Depth
• U5 Reflection Wet Level
• U6 Reflection Feedback
• U7 Reflection Tone
• I00 Compressor Threshold
• I01 Compressor Release
• I02 Chorus Feedback
• I16 Reflection Type
Algorithm M24 (38H) : Multi24
• U0 Distortion Gain
• U1 Distortion Low
• U2 Distortion Hi
• U3 Distortion Level
• U4 Chorus LFO Depth
• U5 Delay Time
• U6 Delay Wet Level
• U7 Delay Feedback
• I01 Chorus LFO Rate
• I02 Chorus Feedback
• I09 Delay High-Damp
• I10 Delay Ratio L
• I11 Delay Ratio R
Algorithm M25 (39H) : Multi25
• U0 Compressor Depth
• U1 Distortion Gain
• U2 Distortion Low
• U3 Distortion Hi
• U4 Distortion Level
• U5 Delay Time
• U6 Delay Wet Level
• U7 Delay Feedback
• I00 Compressor Threshold
• I01 Compressor Attack
• I02 Compressor Release
• I03 Compressor Level
• I07 Delay High-Damp
• I08 Delay Ratio L
• I09 Delay Ratio R
Algorithm M26 (3AH) : Multi26
• U0 Wah Manual
• U1 Wah Depth
• U2 Distortion Gain
• U3 Distortion Tone
• U4 Distortion Level
• U5 Delay Time
• U6 Delay Wet Level
• U7 Delay Feedback
• I00 Wah Sens
• I04 Wah Resonance
• I06 Distortion Low
• I09 Delay High-Damp
• I10 Delay Ratio L
• I11 Delay Ratio R
Algorithm M27 (3BH) : Multi27
• U0 Wah Manual
• U1 Wah LFO Rate
• U2 Wah LFO Depth
• U3 Distortion Gain
• U4 Distortion Level
• U5 Delay Time
• U6 Delay Wet Level
• U7 Delay Feedback
• I02 Wah Resonance
• I04 Distortion Low
• I05 Distortion Hi
• I08 Delay High-Damp
• I09 Delay Ratio L
• I10 Delay Ratio R
