Casio 5499 User manual

E-7
Mode Reference Guide
The mode you should select depends on what you want to do.
To do this: Enter this mode: See:
•View the current date in the Home City
•Configure Home City and daylight saving time (DST) settings
•Configure time and date settings
Timekeeping Mode E-13
Determine the temperature at your current location Thermometer Mode E-21
Use the stopwatch to measure elapsed time Stopwatch Mode E-25
Use the countdown timer Countdown Timer Mode E-27
View the current time in one of 48 cities (31 time zones) around the globe World Time Mode E-29
•Set an alarm time
•Turn the hourly time signal on or off Alarm Mode E-32
E-6
Illumination ………………………………………………………………………………………………… E-35
To turn on illumination manually …………………………………………………………………… E-35
To change the illumination duration ……………………………………………………………… E-35
To enable or disable auto light……………………………………………………………………… E-37
Button Operation Tone …………………………………………………………………………………… E-39
To enable or disable the button operation tone ………………………………………………… E-39
Troubleshooting …………………………………………………………………………………………… E-40
Specifications ……………………………………………………………………………………………… E-43
E-5
Using the Stopwatch ……………………………………………………………………………………… E-25
To enter the Stopwatch Mode ……………………………………………………………………… E-25
To perform an elapsed time operation …………………………………………………………… E-26
To pause at a split time……………………………………………………………………………… E-26
To measure two finishes …………………………………………………………………………… E-26
Using the Countdown Timer ……………………………………………………………………………… E-27
To enter the Countdown Timer Mode……………………………………………………………… E-27
To specify the countdown start time ……………………………………………………………… E-27
To perform a countdown timer operation ………………………………………………………… E-28
To stop the alarm …………………………………………………………………………………… E-28
Checking the Current Time in a Different Time Zone………………………………………………… E-29
To enter the World Time Mode …………………………………………………………………… E-29
To view the time in another time zone …………………………………………………………… E-29
To specify standard time or daylight saving time (DST) for a city ……………………………… E-30
To swap your Home Time and World Time Cities ……………………………………………… E-31
Using the Alarm …………………………………………………………………………………………… E-32
To enter the Alarm Mode …………………………………………………………………………… E-32
To set an alarm time ………………………………………………………………………………… E-33
To test the alarm …………………………………………………………………………………… E-33
To turn an alarm and the Hourly Time Signal on and off………………………………………… E-34
To stop the alarm …………………………………………………………………………………… E-34
E-4
Contents
About This Manual …………………………………………………………………………………………… E-2
Things to check before using the watch ………………………………………………………………… E-3
Mode Reference Guide ……………………………………………………………………………………… E-7
General Functions (All Modes)…………………………………………………………………………… E-10
Timekeeping ………………………………………………………………………………………………… E-13
Configuring Home City Settings ………………………………………………………………………… E-14
To configure Home City settings …………………………………………………………………… E-14
To change the daylight saving time (summer time) setting……………………………………… E-15
Configuring Current Time and Date Settings ………………………………………………………… E-16
To change the current time and date settings …………………………………………………… E-16
Hand Home Position Adjustment ……………………………………………………………………… E-19
To adjust home positions …………………………………………………………………………… E-19
Taking Temperature Readings …………………………………………………………………………… E-21
To take temperature readings ……………………………………………………………………… E-21
To calibrate the temperature sensor ……………………………………………………………… E-23
Specifying Temperature Unit …………………………………………………………………………… E-24
To specify the temperature unit …………………………………………………………………… E-24
E-3
Things to check before using the watch
1. Check the Home City and the daylight saving time (DST) setting.
Use the procedure under “To configure Home City settings” (page E-14) to configure your Home City and
daylight saving time settings.
Important!
•Proper World Time Mode data depends on correct Home City, time, and date settings in the
Timekeeping Mode. Make sure you configure these settings correctly.
2. Set the current time.
See “Configuring Current Time and Date Settings” (page E-16).
The watch is now ready for use.
E-2
About This Manual
•Depending on the model of your watch, digital display text appears
either as dark figures on a light background, or light figures on a dark
background. All examples in this manual are shown using dark figures
on a light background.
•Button operations are indicated using the letters shown in the
illustration.
•Note that the product illustrations in this manual are intended for
reference only, and so the actual product may appear somewhat
different than depicted by an illustration.
E-1
ENGLISH
Congratulations upon your selection of this CASIO watch.
Warning!
•The measurement functions built into this watch are not intended for taking measurements that
require professional or industrial precision. Values produced by this watch should be considered
as reasonable representations only.
•Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any damage or loss
suffered by you or any third party arising through the use of your watch or its malfunction.
MO1607-EA © 2016 CASIO COMPUTER CO., LTD.
Operation Guide 5499

E-15
5. After all of the settings are the way you want, press Ato exit the setting screen.
•The DST indicator appears to indicate that daylight saving time is turned on.
Note
•After you specify a city code, the watch will use UTC* offsets in the World Time Mode to calculate
the current time for other time zones based on the current time in your Home City.
* Coordinated Universal Time, the world-wide scientific standard of timekeeping.
The reference point for UTC is Greenwich, England.
To change the daylight saving time (summer time) setting
1. In the Timekeeping Mode, hold down Auntil ADJ appears in the
lower display.
•When you release A(after ADJ appears), SET will be flashing in
the upper display.
2. Press C.
•This will cause the DST indicator to appear in the upper display and
the DST setting of the currently selected Home City to appear in the
lower display.
3. Press Dto toggle the DST setting between daylight saving time (ON) and standard time (OFF).
4. After all of the settings are the way you want, press Ato exit the setting screen.
•The DST indicator appears to indicate that daylight saving time is turned on.
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
E-14
Configuring Home City Settings
There are two Home City settings: actually selecting the Home City and selecting either standard time or
daylight saving time (DST).
To configure Home City settings
1. In the Timekeeping Mode, hold down Auntil ADJ appears in the
lower display.
•When you release A(after ADJ appears), SET will be flashing in
the upper display. This is the setting mode.
•The watch will exit the setting mode automatically if you do not
perform any operation for about two or three minutes.
2. Use D(East) and B(West) to scroll through the available city codes.
•Keep scrolling until the city code you want to select as your Home
City is shown in the lower display.
•For details about city codes, see the “City Code Table” at the back
of this manual.
3. Press C.
•This will cause the DST indicator to appear in the upper display and
the DST setting of the currently selected Home City to appear in the
lower display.
4. Press Dto toggle the DST setting between daylight saving time (ON)
and standard time (OFF).
•Note that you cannot switch between standard time and daylight
saving time (DST) while UTC is selected as your Home City.
City code and city name
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
DST indicator
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
E-13
Timekeeping
Use the Timekeeping Mode to set and view the current time and date.
•Each press of Ain the Timekeeping Mode will change digital display contents as shown below.
Timekeeping
Mode
Hour hand
Day of week
Minute hand
Month Day
Second hand
Seconds
Date Screen
Seconds
Hour : MinutesPM indicator
Time Screen
A
E-12
2. Holding down Bagain as you press Cwill cause the hands to return to their normal positions (normal
timekeeping).
Note
•Watch button functions are the same regardless of whether the hands are moved out of the way or at
their normal positions.
•Changing to another mode will cause the hands to move back to their normal positions.
•The hands also will move back to their normal positions automatically if no operation is performed for
about one hour.
E-11
Moving the Hands Out of the Way for Better Viewing
You can use the procedure below to temporarily move the hour and minute hands out of the way to better
view what is on the display.
•This operation can be performed in any mode. In the case of a setting mode (setting flashing on the
screen), the hands will move out of the way automatically, even if you do not perform the operation
below.
1. While holding down B, press C.
•This will cause the hour and minute hands to move to a location where they do not block your view
of the digital display.
Example: When the current time is 10:08
Flashes while the hands
are moved out of the way.
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
E-10
General Functions (All Modes)
The functions and operations described in this section can be used in all of the modes.
Auto Return Features
•The watch will automatically return to the Timekeeping Mode if you do not perform any button operation
for a particular amount of time in each mode.
Mode Name Approximate Elapsed Time
Alarm 3 minutes
Thermometer 1 to 2 minutes
Setting screen (digital setting flashing) 3 minutes
Initial Screens
•When you enter the Timekeeping, Alarm, or World Time Mode, the data you were viewing when you last
exited the mode appears first.
Scrolling
•The Dand Bbuttons are used on the setting screen to scroll through data on the digital display. In
most cases, holding down these buttons during a scroll operation scrolls through the data at high
speed.
E-9
•The dial hand indicates the watch’s current mode.
Stopwatch Mode Countdown Timer Mode
Alarm Mode World Time Mode
C
C
C
E-8
Selecting a Mode
•The illustration below shows which buttons you need to press to navigate between modes.
•To return to the Timekeeping Mode from any other mode, hold down Cfor about two seconds.
Timekeeping Mode
Thermometer Mode
Dial hand
C
C
D
Operation Guide 5499

E-23
To calibrate the temperature sensor
1. Take a reading with another measurement device to determine the
exact current temperature.
2. With the watch in the Timekeeping Mode, press Dto enter the
Thermometer Mode.
3. Hold down Afor about two seconds until the temperature reading
disappears from the upper display. Release Aat this time, which will
cause the temperature reading to flash, which indicates the setting
mode.
4. Use D(+) and B(–) to calibrate the temperature value with the reading of another instrument.
•Each press of a button changes the temperature value in units of 0.1°C (0.2°F).
•To return the currently flashing value to its initial factory default setting, press Dand Bat the same
time.
5. Press Ato return to the Thermometer Mode.
Thermometer Precautions
Temperature measurements are affected by your body temperature (while you are wearing the watch),
direct sunlight, and moisture. To achieve a more accurate temperature measurement, remove the watch
from your wrist, place it in a well ventilated location out of direct sunlight, and wipe all moisture from the
case. It takes approximately 20 to 30 minutes for the case of the watch to reach the actual surrounding
temperature.
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
E-22
Temperature
•Temperature is displayed in units of 0.1°C (or 0.2°F).
•The displayed temperature value changes to ---°C (or °F) if a
measured temperature falls outside the range of –10.0°C to 60.0°C
(14.0°F to 140.0°F). The temperature value will reappear as soon as
the measured temperature is within the allowable range.
Display Units
You can select either Celsius (°C) or Fahrenheit (°F) for the displayed temperature value. See “To specify
the temperature unit” (page E-24).
Temperature Sensor Calibration
The temperature sensor built into the watch is calibrated at the factory and normally require no further
adjustment. If you notice serious errors in the temperature readings produced by the watch, you can
calibrate the sensor to correct the errors.
Important!
•Incorrectly calibrating the temperature sensor can result in incorrect readings.
Carefully read the following before doing anything.
–
Compare the readings produced by the watch with those of another reliable and accurate thermometer.
– If adjustment is required, remove the watch from your wrist and wait for 20 or 30 minutes to give the
temperature of the watch time to stabilize.
Temperature
E-21
Taking Temperature Readings
This watch uses a temperature sensor to measure temperature.
To take temperature readings
1. While in the Timekeeping Mode, press Dto enter the Thermometer
Mode.
•TEMP will appear in the lower display and temperature
measurement will start. After about one second, the measurement
reading will appear in the upper display.
•The watch will continue to take temperature readings every five
seconds for one or two minutes.
2. Press Dto return to the Timekeeping Mode.
•The watch will return to the Timekeeping Mode automatically if you
do not perform any operation for about one or two minutes after
entering the Thermometer Mode.
Temperature
E-20
•The dial hand must point to 12 o’clock.
•The watch will return to regular timekeeping automatically if you do not perform any operation for
about two or three minutes. Any changes you have made to settings up to that point will be saved.
2. Use D(+) and B(–) to adjust the position of the currently selected hand.
•Holding down either button will cause the hand to move at high speed. Once started, high-speed
hand movement will continue even if you release the button. To stop high-speed hand movement,
press any button.
•The second hand and dial hand will automatically stop high-speed movement after they complete
one revolution. The minute hand will stop automatically after 12 revolutions.
3. Press Ato exit home position correction and return to regular timekeeping.
Note
•After performing home position adjustment, enter the Timekeeping Mode and check to make sure that
the analog hands and the upper display indicate the same time. If they do not, perform home position
adjustment again.
E-19
Hand Home Position Adjustment
Strong magnetism or impact can cause the hands of the watch to go out of alignment.
•Home position adjustment is not necessary when the analog time and digital time are the same time in
the Timekeeping Mode.
To adjust home positions
1. In the Timekeeping Mode, hold down Aand keep it depressed for
about five seconds until H.SET appears on the lower display.
•When you release Aafter H.SET appears, the second hand will
move to 12 o’clock. This indicates the second hand home position
adjustment mode.
•Though ADJ will appear in the lower display about two seconds
after you hold down A, do not release the button yet. Keep it
depressed until H.SET appears.
•Use the Cbutton to select a hand for adjustment. Each press of
Ccycles in sequences from the second hand, to the hour and
minute hands, and then the dial hand. Selecting a hand causes it to
move to 12 o’clock and the content of the upper display changes as
shown in the table below.
Upper display Selected hand
Flashing 00 Second hand
Flashing 0:00 Hour and minute hands
Flashing SUB Dial hand
•If the selected hand does not move exactly to 12 o’clock, perform step 2 below to adjust it.
Dial hand
l
l
l
l
l
l
l
l
l
l
l
l
E-18
Note
•While the 12-hour format is selected for timekeeping, a P(PM) indicator will appear for times from
noon to 11:59 p.m. No indicator appears for times from midnight to 11:59 a.m. With 24-hour format,
time is displayed from 0:00 to 23:59, without any P(PM) indicator.
•The watch’s built-in full automatic calendar makes allowances for different month lengths and leap
years. Once you set the date, there should be no reason to change it except after you have the
watch’s batteries replaced.
•The day of the week changes automatically when the date changes.
E-17
2. Press Cto move the flashing in the sequence shown below to select the other settings.
Illumination Duration
(page E-35)
Button Operation Tone
On/Off (page E-39)
City Code
(page E-14)
DST
(page E-15)
12/24-Hour
Format Seconds Hour Minutes
Day Month Year
CCC
CCCC
C
C
C
C
•The following steps explain how to configure timekeeping settings only.
3. When the timekeeping setting you want to change is flashing, use Dand/or Bto change it as
described below.
Screen To do this: Do this:
Toggle between 12-hour (12H) and 24-hour (24H)
timekeeping. Press D.
Reset the seconds to 00
(If the current seconds count is between 30 and 59,
one is added to the minute count).
Press D.
Change the hour or minutes
Use D(+) and B(–).
Change the year, month, or day
4. After all of the settings are the way you want, press Ato exit the setting screen.
E-16
Configuring Current Time and Date Settings
You can use the procedure below to adjust the Timekeeping Mode time and date settings if they are off.
Changing the digital Home City data should cause the analog time setting to change accordingly. If the
analog time does not indicate the digital time, check the home positions of the hands and make
adjustments if necessary (page E-19).
To change the current time and date settings
1. In the Timekeeping Mode, hold down Auntil ADJ appears in the
lower display.
•When you release A(after ADJ appears), SET will be flashing in
the upper display.
City code
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
Operation Guide 5499

E-31
To swap your Home Time and World Time Cities
1. In the World Time Mode, use Dto select the city you want to use as your new Home City.
2. To swap, press Aand Bat the same time.
Aand B
•This will make the World Time City you selected in step 1 (NYC (NEW YORK)) your new Home City.
•Your previous Home City (TYO (TOKYO)) will be your new World Time City.
E-30
To specify standard time or daylight saving time (DST) for a city
1. In the World Time Mode, use D(East) to scroll through the available
city codes.
•Keep scrolling until the city code whose standard time/daylight
saving time setting you want to change is shown in the lower
display.
2. To toggle between summer time (DST indicator in the upper display)
and standard time (DST indicator not displayed), hold down A.
•Using the World Time Mode to change the DST setting of the
city code that is selected as your Home City also will change the
Timekeeping Mode time DST setting.
•Note that you cannot switch between standard time/daylight saving
time (DST) while UTC is selected as the World Time City.
•Note that the standard time/daylight saving time (DST) setting
affects only the currently selected time zone. Other time zones are
not affected.
DST indicator
Hold down A
E-29
Checking the Current Time in a Different Time Zone
You can use the World Time Mode to view the current time in one of 31 time zones (48 cities) around the
globe. The city that is currently selected in the World Time Mode is called the “World Time City”.
•You also can swap the current World Time City and Home Time City in the World Time Mode (page E-31).
To enter the World Time Mode
Use Cto select the World Time Mode as shown on page E-8.
•The current city code and city name will scroll across the lower
display. After that, the city code will remain shown in the lower display.
You can scroll the city code and city name again by pressing A.
•The hour, minute, and second hands will indicate the current
Timekeeping Mode time.
To view the time in another time zone
In the World Time Mode, use D(East) to scroll through city codes.
•To change the city code to UTC, press Band Dat the same time.
Current time in the currently
selected World Time City
World Time Mode
Hour and minute
Currently selected
World Time City
Second
E-28
To perform a countdown timer operation
DDD D A
Start Stop (Resume) (Stop) Reset
•Before starting a countdown timer operation, check to make sure that a countdown operation is not
already in progress (indicated by the seconds counting down). If it is, press Dto stop it and then A
to reset to the countdown start time.
•An alarm sounds for 10 seconds when the end of the countdown is reached. This alarm will sound in all
modes. The countdown time is reset to its starting value automatically after the alarm sounds.
To stop the alarm
Press any button.
E-27
Using the Countdown Timer
The countdown timer can be configured to start at a preset time and sound an alarm when the end of the
countdown is reached.
To enter the Countdown Timer Mode
Use Cto select the Countdown Timer Mode as shown on page E-8.
To specify the countdown start time
1. Enter the Countdown Timer Mode.
•If a countdown is in progress (indicated by the seconds counting
down), press Dto stop it and then press Ato reset to the current
countdown start time.
•If a countdown is paused, press Ato reset to the current
countdown start time.
2. Hold down Auntil the minute setting of the current countdown start
time starts to flash. This is the setting screen.
3. Use D(+) and B(–) to change the minute.
4. Press Ato exit the setting screen.
Countdown Timer
Mode
Minutes Seconds
Countdown time
E-26
To perform an elapsed time operation
DDDDA
Start Stop (Resume) (Stop) Reset
To pause at a split time
DAADA
Start Split
(SPL appears in
the lower display.)
Split release Stop Reset
To measure two finishes
DAD A A
Start Split
First runner finishes.
(SPL appears in the
lower display.)
Display time of first
runner
Stop
Second runner
finishes.
Split release
Display time of
second runner
Reset
Note
•The Stopwatch Mode can indicate elapsed time up to 23 hours, 59 minutes, 59.99 seconds.
•Once started, stopwatch timing continues until you press Dto stop it, even if you exit the Stopwatch
Mode to another mode and even if timing reaches the stopwatch limit defined above.
1/10
seconds
Elapsed time
measurement stopped
1/100
second
E-25
Using the Stopwatch
The stopwatch measures elapsed time, split times, and two finishes.
To enter the Stopwatch Mode
Use Cto select the Stopwatch Mode as shown on page E-8.
Dial handHours
Seconds 1/100 second
One
second
Stopwatch
Mode
Minutes
E-24
Specifying Temperature Unit
Use the procedure below to specify the temperature unit to be used in the Thermometer Mode.
Important!
When TOKYO is selected as the Home City, the temperature unit is set
automatically to Celsius (°C). This setting cannot be changed.
To specify the temperature unit
1. In the Timekeeping Mode, press Dto enter the Thermometer Mode.
2. Hold down Afor about two seconds until the temperature reading
disappears from the upper display. Release Aat this time, which will
cause the temperature reading to flash, which indicates the setting
mode.
3. Press Cto display the current temperature unit in the upper display.
4. Press Dto toggle the temperature unit between °C (Celsius) and °F
(Fahrenheit).
5. After the setting is the way you want, press Ato exit the setting
screen.
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
Operation Guide 5499

E-39
Button Operation Tone
When enabled, the button operation tone sounds any time you press one of the watch’s buttons. You can
enable or disable the button operation tone as desired.
•Even if you disable the button operation tone, the alarm, and Hourly Time Signal all operate normally.
To enable or disable the button operation tone
1. In the Timekeeping Mode, hold down Auntil ADJ appears in the
lower display.
•When you release A(after ADJ appears), SET will be flashing in
the upper display.
2. Use Dto cycle through settings on the lower display until the current
button operation tone setting (MUTE or KEY ) is shown.
•See the sequence in step 2 of the procedure under “To change the
current time and date settings” (page E-16) for information about
how to scroll through setting screens.
3. Press Dto toggle the button operation tone setting between enabled
(KEY ) and disabled (MUTE).
4. After the setting is the way you want, press Ato exit the setting
screen.
Note
•The mute indicator is displayed in all modes when the button
operation tone is disabled.
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
Mute indicator
E-38
Auto light precautions
•Illumination may not turn on if the face of the watch is more than 15 degrees above
or below parallel. Make sure that the back of your hand is parallel to the ground.
•Illumination turns off after the preset illumination duration (page E-35), even if you keep
the watch pointed towards your face.
•Static electricity or magnetic force can interfere with proper operation of auto light.
If illumination does not turn on, try moving the watch back to the starting position
(parallel with the ground) and then tilt it back towards your face again. If this does
not work, drop your arm all the way down so it hangs at your side, and then bring it
back up again.
•You may notice a very faint clicking sound coming from the watch when it is shaken
back and forth. This sound is caused by mechanical operation of auto light, and
does not indicate a problem with the watch.
E-37
Note
•Auto light is always disabled, regardless of its enabled/disabled setting, when any one of the following
conditions exists.
While an alarm is sounding
During sensor measurement
To enable or disable auto light
In the Timekeeping Mode, hold down Bfor about three seconds to
toggle auto light between enabled (LT shown in the lower display) and
disabled (LT not displayed).
•The auto light enabled indicator (LT) is on the lower display in all
modes while auto light is enabled.
•Auto light remains enabled for about six hours. After that disables
automatically.
Illumination Precautions
•Illumination may be hard to see when viewed under direct sunlight.
•Illumination will not turn on while an alarm is sounding, while high-speed hand movement is in progress,
while a sensor is taking a reading. Illumination will turn on if Bis pressed between sensor reading
operations.
•Illumination turns off automatically whenever an alarm sounds.
•Frequent use of illumination runs down the batteries.
Auto light enabled
indicator
E-36
3. Press Dto toggle the illumination duration between three seconds (LT3 displayed) and 1.5 seconds
(LT1 displayed).
4. After all of the settings are the way you want, press Ato exit the setting screen.
About Auto Light
While Auto Light is enabled, illumination will turn on whenever you
position your wrist as described below in any mode.
Moving the watch to a position that is parallel to the ground and
then tilting it towards you more than 40 degrees causes
illumination to turn on.
Warning!
•Always make sure you are in a safe place whenever you are reading the display of the watch
using auto light. Be especially careful when running or engaged in any other activity that can
result in accident or injury. Also take care that sudden illumination by auto light does not startle
or distract others around you.
•When you are wearing the watch, make sure that auto light is disabled before riding on a bicycle
or operating a motorcycle or any other motor vehicle. Sudden and unintended operation of auto
light can create a distraction, which can result in a traffic accident and serious personal injury.
More than
40°
Wear the watch on the
outside of your wrist
E-35
Illumination
The face of the watch is illuminated for easy reading in the dark. The auto
light turns on illumination automatically when you angle the watch
towards your face.
•Auto light must be enabled (page E-37) for it to operate.
To turn on illumination manually
Press Bin any mode (except when a flashing setting screen is
displayed) to turn on illumination.
•You can use the procedure below to select either 1.5 seconds or three
seconds as the illumination duration. When you press B, the
illumination will remain on for about 1.5 seconds or three seconds,
depending on the current illumination duration setting.
•The above operation turn on illumination regardless of whether auto
light is enabled or disabled.
•Illumination is disabled while configuring sensor measurement mode
settings.
To change the illumination duration
1. In the Timekeeping Mode, hold down Auntil ADJ appears in the lower display.
•When you release A(after ADJ appears), SET will be flashing in the upper display.
2. Use Cto cycle through the settings on the upper display until the current illumination duration (LT1 or
LT3) is shown.
•See the sequence in step 2 of the procedure under “To change the current time and date settings”
(page E-16) for information about how to scroll through setting screens.
E-34
To turn an alarm and the Hourly Time Signal on and off
1. In the Alarm Mode, use Dto select an alarm or the Hourly Time Signal.
2. When the alarm or the Hourly Time Signal you want is selected, press Ato turn it on and off.
•
The alarm on indicator (when any alarm is on), snooze alarm indicator
(when the snooze alarm is on), and the Hourly Time Signal on indicator
(when the Hourly Time Signal is on) are shown on the upper display in
all modes.
To stop the alarm
Press any button.
Alarm on
indicator
Snooze alarm
indicator
Hourly time signal
on indicator
E-33
To set an alarm time
1. In the Alarm Mode, use Dto scroll through the alarm screens in the
lower display until the one you want to change is shown.
AL1 AL2 AL3
SIG SNZ AL4
DD
DD
DD
2. Hold down Auntil the hour digits of the alarm setting start to flash in the upper display.
•This is the setting screen.
3. Press Cto move the flashing between the hour and minute settings.
4. While a setting is flashing, use D(+) and B(–) to change it.
•When setting the alarm time using the 12-hour format, take care to set the time correctly as a.m. (no
indicator) or p.m. (Pindicator).
5. Press Ato exit the setting screen.
To test the alarm
In the Alarm Mode, hold down Dto sound the alarm.
Alarm ON/OFF
indicator
E-32
Using the Alarm
You can set five independent daily alarms. When an alarm is turned on,
an alarm will sound for about 10 seconds each day when the time in the
Timekeeping Mode reaches the preset alarm time. This is true even if the
watch is not in the Timekeeping Mode. One of the daily alarms is a
snooze alarm. The snooze alarm will sound every five minutes up to
seven times or until it is turned off.
You can also turn on an Hourly Time Signal, which will cause the watch
to beep twice every hour on the hour.
To enter the Alarm Mode
Use Cto select the Alarm Mode as shown on page E-8.
•The lower display will show the currently selected alarm number (AL1
to AL4, or SNZ), or the hourly time signal indicator (SIG).
•When you enter the Alarm Mode, the data you were viewing when you
last exited the mode appears first.
Alarm time
(Hour : Minutes)
Alarm number
or SIG
Alarm Mode
Operation Guide 5499

L-3
City
Code City UTC Offset/ GMT Differential
DEL Delhi +5.5
KTM Kathmandu +5.75
DAC Dhaka +6
RGN Yangon +6.5
BKK Bangkok +7
SIN Singapore
+8
HKG Hong Kong
BJS Beijing
TPE Taipei
SEL Seoul +9
TYO Tokyo
ADL Adelaide +9.5
GUM Guam +10
SYD Sydney
NOU Noumea +11
WLG Wellington +12
•This table shows the city codes of this watch.
(As of January 2016)
•The rules governing global times (GMT
differential and UTC offset) and summer time
are determined by each individual country.
L-2
City Code Table
City
Code City UTC Offset/ GMT Differential
PPG Pago Pago –11
HNL Honolulu –10
ANC Anchorage –9
YVR Vancouver –8
LAX Los Angeles
YEA Edmonton –7
DEN Denver
MEX Mexico City –6
CHI Chicago
NYC New York –5
YHZ Halifax –4
YYT St. Johns –3.5
SCL Santiago –3
RIO Rio De Janeiro
FEN Fernando de
Noronha –2
RAI Praia –1
City
Code City UTC Offset/ GMT Differential
UTC
0LIS Lisbon
LON London
MAD Madrid
+1
PAR Paris
ROM Rome
BER Berlin
STO Stockholm
ATH Athens
+2CAI Cairo
JRS Jerusalem
MOW Moscow +3
JED Jeddah
THR Tehran +3.5
DXB Dubai +4
KBL Kabul +4.5
KHI Karachi +5
L-1E-44
World Time: 48 cities (31 time zones)
Other: daylight saving time/standard time
Alarms: 5 daily alarms (with one snooze alarm); Hourly Time Signal
Illumination: LED (light-emitting diode); Selectable illumination duration (approximately 1.5 seconds or
3 seconds); Auto Light
Other: Button operation tone on/off; Hand shifting (to view digital display)
Battery: Two silver oxide batteries (Type: SR927W)
Approximate battery operating time: 2 years under the following conditions:
•1 illumination operation (1.5 seconds) per day
•Alarm: 10 seconds/day
•Temperature readings: Once/week
Frequent use of illumination runs down the batteries. Particular care is required when using auto light
(page E-38).
Specifications are subject to change without notice.
E-43
Specifications
Accuracy at normal temperature: ±15 seconds a month
Digital Timekeeping:
Hour, minutes, seconds, p.m. (P), month, day, day of the week
Time format: 12-hour and 24-hour
Calendar system: Full Auto-calendar pre-programmed from the year 2000 to 2099
Other: Two display formats (month, day or time); Home City code (can be assigned one of 48 city
codes); standard time / daylight saving time (summer time)
Analog Timekeeping: Hour, minutes (hand moves every 10 seconds), seconds
Thermometer:
Measurement and display range: –10.0 to 60.0°C (or 14.0 to 140.0°F)
Display unit: 0.1°C (or 0.2°F)
Measurement timing: Every five seconds in the Thermometer Mode
Other: Calibration; Selectable measurement unit
Temperature Sensor Precision:
±2°C (±3.6°F) in range of –10°C to 60°C (14.0°F to 140.0°F)
Stopwatch:
Measuring unit: 1/100 second
Measuring capacity: 23:59’ 59.99”
Measuring modes: Elapsed time, split time, two finishes
Countdown Timer:
Measuring unit: 1 second
Countdown range: 60 minutes
Setting ranges: Countdown start time (1 to 60 minutes, 1-minute increments)
E-42
Battery
■Why is the low battery alert flashing?
Battery power is low. Watch operations are disabled while the low battery
alert is flashing on the lower display.
If the low battery alert disappears after battery power recovers but then
starts to flash again after a short while, it means that you need to have
the watch’s batteries replaced.
l
l
l
l
l
l
l
l
l
l
l
l
Low battery alert
E-41
Temperature
Measurement
•If ERR appears while a measurement operation is being performed in a sensor mode, restart the
measurement. If ERR appears on the lower display again, it can mean there is something wrong with
the sensor.
•If ERR keeps appearing during measurement, it could mean there is a problem with the applicable
sensor.
World Time Mode
■The time for my World Time City is off in the World Time Mode.
This could be due to incorrect switching between standard time and daylight saving time.
See “To specify standard time or daylight saving time (DST) for a city” (page E-30) for more information.
E-40
Troubleshooting
Time Setting
■ Why is the current time setting off by a couple of hours?
Your Home City setting may be wrong (page E-14). Check your Home City setting and correct it, if necessary.
■ Why is the current time setting off by one hour?
You may need to change your Home City’s standard time/daylight saving time (DST) setting. Use the
procedure under “To change the current time and date settings” (page E-16).
Sensor modes
■ Why can’t I change the temperature unit setting?
The temperature unit setting is always Celsius (°C) whenever TOKYO is selected as the Home City. In
this case, the setting cannot be changed.
■Why does “ERR” appear while a sensor operation is in progress?
Subjecting the watch to strong impact can cause sensor malfunction or improper contact of internal
circuitry. When this happens, ERR (error) will appear on the lower display and sensor operations will be
disabled.
Operation Guide 5499
