Caso Sound & Cool User manual

1 Operating Manual
1.1General
Please read the information contained herein so that you can become familiar with
your device quickly and take advantage of the full scope of its functions.
Your Sound & Cool will serve you for many years if you handle it and care for it
properly.
We wish you a lot of pleasure in using it!
1.2Information on this manual
These Operating Instructions are a component of the Sound & Cool (referred to
hereafter as the Device) and provide you with important information for the initial
commissioning, safety, intended use and care of the device. The Operating
Instructions must be available at all times at the device. This Operating Manual must
be read and applied by every person who is instructed to work with the device: •
Commissioning •Operation
•Troubleshooting and/or •Cleaning
Keep the Operating Manual in a safe place and pass it on to the subsequent owner
along with the device.
1.3Warning notices
The following warning notices are used in the Operating Manual concerned here.
DANGER
A warning notice of this level of danger indicates a potentially dangerous
situation.
If the dangerous situation is not avoided, this can lead to death or serious injuries.
►Observe the instructions in this warning notice in order to avoid the danger of
death or serious personal injuries.
►Risk Of Fire Or Explosion. Flammable Refrigerant Used. To Be Repaired Only By
Trained Service Personnel. Do Not Puncture Refrigerant Tubing
►
WARNING
A warning notice of this level of danger indicates a possible dangerous
situation.
If the dangerous situation is not avoided, this can lead to serious injuries.
►Observe the instructions in this warning notice in order to avoid the personal
injuries.

►Keep clear of obstruction all ventilation openings in the appliance enclosure or in
the structure for building-in.
►Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
►Do not damage the refrigerant circuit.
►Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
►Risk Of Fire Or Explosion. Flammable Refrigerant Used. Consult Repair
Manual/Owner’s Guide Before Attempting To Install or Service This Product. All
Safety Precautions Must be Followed
►Risk Of Fire Or Explosion. Dispose Of Properly In Accordance With Federal Or
Local Regulations. Flammable Refrigerant Used.
►To reduce the risk of fire or electric shock, do not expose this apparatus to rain or
moisture.
►Apparatus with Class I shall be connected to a MAINS socket outlet with a protective
earthing connection.
►To prevent injury, this apparatus must be securely attached to the floor/wall in
accordance with the installation instructions.
ATTENTION
A warning notice of this level of danger indicates a possible dangerous
situation.
If the dangerous situation is not avoided, this can lead to slight or moderate injuries.
►Observe the instructions in this warning notice in order to avoid the personal
injuries.
►that changes or modification not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
PLEASE NOTE
A notice of this kind indicates additional information, which will simplify the handling
of the machine.
This product has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
product generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this product does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of
the following measures:

—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
1.4Limitation of liability
All the technical information, data and notices with regard to the installation,
operation and care are completely up-to-date at the time of printing and are compiled
to the best of our knowledge and belief, taking our past experience and findings into
consideration.
No claims can be derived from the information provided, the illustrations or
descriptions in this manual. The manufacturer does not assume any liability for
damages arising as a result of the following: •Non-
observance of the manual
•Uses for non-intended purposes •Technical alterations, modifications of the
device
•Improper repairs •Use of unauthorized spare parts
Modifications of the device are not recommended and are not covered by the
guarantee.
All translations are carried out to the best of our knowledge. We do not assume any
liability for translation errors, not even if the translation was carried out by us or on
our instructions. The original German text remains solely binding.
1.5Copyright protection
This document is copyright protected. Braukmann GmbH reserves all the rights,
including those for photomechanical reproduction, duplication and distribution using
special processes (e.g. data processing, data carriers, data networks), even partially.
Subject to content and technical changes.
1.6EU declaration of conformity
Hereby, Braukmann GmbH, declares that the radio equipment type [790] is in
compliance with Directive 2014/53/EU. The full text of the EU declaration of
conformity is available at the following internet address: http://www.caso-
germany.de/nc/service/dokumente-download/
2 Safety
This chapter provides you with important safety notices when handling the device.
The device corresponds with the required safety regulations. Improper use can result
in personal or property damages.

2.1Intended use
This device is only intended for use in enclosed spaces for cooling of food and
beverages.
This device is intended for use in the household and for similar applications such as:
•in kitchens for employees in shops, offices, and other commercial areas; in
B&Bs,
•in agricultural estates;
•by customers in hotels, motels and other residential establishments.
Uses for a different purpose or for a purpose which exceeds this description are
considered incompatible with the intended or designated use.
WARNING
Danger due to unintended use! Dangers can emanate from the device if it is
used for an unintended use and/or a different kind of use.
►Use the device exclusively for its intended use.
WARNING
►Observe the procedural methods described in this Operating Manual.
Claims of all kinds due to damages resulting from unintended uses are excluded.
The User bears the sole risk.
2.2 General Safety information
PLEASE NOTE
Please observe the following general safety
notices with regard to the safe handling of the
device.
►Examine the device for any visible external
damages prior to using it. Never put a damaged
device into operation.
►If the connection lead is damaged, you will need to
have a new connection lead installed by an
authorized electrician.
►This device may be used by children aged 8 and above, if
they are supervised or have been instructed at to the safe

use of the device and have understood the resulting
hazards.
►Cleaning and maintenance by the user must not be
performed by children unless they are at least 8 years old
and are supervised. Children are not allowed to play with
the device.
►The device and its connecting cable must be kept away
from children who are less than 8 years old.
►The device may be used by individuals with reduced
physical, sensory or mental capabilities or a lack of
experience and / or knowledge of their use if they are
supervised or have been instructed at to the safe use of
the device and have understood the resulting hazards.
►Only qualified electricians, who have been trained
by the manufacturer, may carry out any repairs that
may be needed. Improperly performed repairs can
cause considerable dangers for the user.
Please note
►Only customer service departments authorized by
the manufacturer may carry out repairs on the
device during the guarantee period, as otherwise
the guarantee entitlements will be null and void in
the event of any subsequent damages.
►Defective components must always be replaced
with original replacement parts. Only such parts will
guarantee that the safety requirements are fulfilled.
►Pull the drawers out at the handle. Be careful not to
get caught between the drawers and the device.
►Do not place unstable objects in the upper part of
the device (heavy objects, water containers). If

these fall over and fluid escapes, electrical
components could be damaged.
►Do not store perishable food in the device.
►This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference,
and
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
►
2.3 Sources of danger
2.3.1 Risk of fire / flammable materials used.
Danger of burns or of explosion
DANGER
There is a danger of burns and explosion due to
excess pressure that is created in the event the
device is not used properly.
Observe the following safety notices to avoid dangers
of burns or an an explosion:
Warning: Risk of fire / flammable materials
used.
►Do not store explosive substances such as aerosol
cans with a flammable propellant in this device.
DANGER

►Blowing gas inside the unit is flammable.
►Do not damage the cooling circuit of the device.
►Do not use electrical devices inside the device.
►Do not use mechanical devices or other means to
accelerate the defrosting process.
►Never use the device to store or dry flammable
materials. Never clean appliance parts with
flammable fluids. The fumes can create a fire
hazard or explosion.
►Do not store or use gasoline or any other
flammable vapours and liquids in the vicinity of this
or any other appliance. The fumes can create a fire
hazard or explosion.
►The mains plug must be plugged firmly into the
connection socket on the bottom of the device,
otherwise there is a risk of fire.
2.3.2 Dangers due to electrical power
Mortal danger due to electrical power!
Mortal danger exists when coming into contact with
live wires or subassemblies! Observe the following
safety notices to avoid dangers due to electrical
power:
►If the connection lead is damaged, you will need to
have a special connection lead installed by an
authorized electrician.
►Do not operate this device if its power cable or plug
is damaged, if it does not work properly or if it is
damaged or has been dropped.

Danger
►If the power cable is damaged, it will need to be
replaced by the manufacturer or his service agency or a
similar qualified person, to avoid any dangers.
►Do not open the housing on the device under any
circumstances. There is a danger of an electrical
shock if live connections are touched and the
electrical or mechanical structure is altered. In
addition, functional faults on the device can also
occur.
►Do not clean the device with a spray / liquid and do
not place the device in an environment where the
device can get wet or splashed with liquid. There is
a risk of a short circuit.
3 Commissioning
This chapter provides you with important safety notices during the initial
commissioning of the device. Observe the following notices to avoid dangers and
damages:
3.1Safety information
WARNING
Personal and property damages can occur during commissioning of the
device!
Observe the following safety notices to avoid such dangers:
►Packaging materials may not be used for playing. There is a danger of
suffocation.
►Transport, unpack and use two persons to set down the device because of the
heavy weight of the device.
3.2Delivery scope and transport inspection
As a rule, the Sound & Cool is delivered with the following components:

•Sound & Cool •power cord •1 slot for power cord •1 audio line
•4 partitions •2 sliding inserts •Operating Instructions
Please note
►Examine the shipment for its completeness and for any visible damages.
►Immediately notify the carrier, the insurance and the supplier about any
incomplete shipment or damages as a result of inadequate packaging or due to
transportation.
3.3Unpacking
To unpack the device, proceed as follows:
•Remove the device out of the carton and remove the
packaging material.
•The appliance may be title by a max angle of 45 °, otherwise the cooling system
can be damaged.
•Clean the interior surface with lukewarm water using a soft cloth.
•After at least 12 hours, plugging the appliance into the wall outlet, than place food
or beverages in the appliance.
Please note
►Only remove the blue protective film shortly before setting up the device in the
location where it will be used, to prevent scratches and dirt accumulations.
3.4Disposal of the packaging
The packaging protects the device against damages during transit. The packaging
materials are selected in accordance with environmentally compatible and recycling-
related points of view and can therefore be recycled. Returning the packaging back
to the material loop saves raw materials and reduces the quantities of accumulated
waste. Take any packaging materials that are no longer required to “Green Dot”
recycling collection points for disposal.
Please note
►If possible, keep the original packaging for the device for the duration of the
guarantee period of the device, in order that the device can be re-packaged
properly in the event of a guarantee claim.
3.5Setup
3.5.1 Setup location requirements:
In order to ensure the safe and trouble-free operation of the device, the setup
location must fulfil the following prerequisites:

•Place your appliance on a floor that is strong enough to support the appliance
when it is fully loaded.
•Locate the appliance away from direct sunlight and sources of heat (stove, heater,
radiator, etc.). Direct sunlight may affect the acrylic coating and heat sources may
increase electrical consumption.
•Ambient temperature below 16°C or above 38°C will hinder the performance of
the appliance.
•This unit is not designed for use in a garage or any other outside installation.
•Do not set up the device in a hot, wet or extremely damp environment or near
flammable material.
•The device requires an adequate flow of air in order to operate correctly. Leave a
clearance of 45 cm around the appliance.
•Do not cover up any openings on the device and do not block these off.
•The electrical socket must be easily accessible so that the power lead can be
disconnected easily, in the case of an emergency.
•The installation and assembly of this device in non-stationary setup locations (e.g.
on ships) must be carried out by specialist companies / electricians, provided
they guarantee the prerequisites for the safe use of this
device.
•For energy saving reasons please ensure that the
drawers are closed when the appliance is turned on.
•Adjust the adjustable feet, so that the device is placed
even.
3.6Electrical connection
In order to ensure the safe and trouble-free operation of
the device, the following instructions must be observed for
the electrical connection:
•Before connecting the device, compare the connection data (voltage and
frequency) on the rating plate with those of your electrical network. This data
must agree in order that no damages occur in the device. If in doubt, ask your
qualified electrician.
•The electrical outlet must be protected by a 16A safety cut-out switch.
•Do not bend the power cord. Make sure that the power cable is undamaged and
has not been installed under or over hot or sharp surfaces.
•The connection between the device and the electrical network may employ a 3
meter long (max.) extension cable with a cross-section of 1.5 mm². The use of
multiple plugs or gangs is prohibited because of the danger of fire that is involved
with this.

•This unit is not designed to be installed in an RV or used with an inverter.
•The electrical safety of the device is only guaranteed if the device is connected to
a properly installed protective conductor system. Operations using an electrical
outlet without a protective conductor are prohibited. If in doubt, have the house
installation checked over by a qualified electrician. The manufacturer cannot be
made responsible for damages that are caused by a missing or damaged
protective conductor.
Options to connect the power cord
1) Plug the mains plug into a ground socket below the device.
2) Place power cord under carpet, to avoid stumbling over the cord.
3) Slot power cord through the supplied slot for the power cord.
Danger
►The mains plug must be plugged firmly into the connection socket on the bottom
of the device, otherwise there is a risk of fire.
4 Design and Function
This chapter provides you with important safety notices on the design and function of
the device.
4.1Complete overview

(1) glass panel (2) inner space, left drawer (3) movable inserts
(4) partition (5) left drawer (6) control panel
(7) inner space, right drawer (8) adjustable foot (9) right drawer
(10) logo (11) rear board
(12) USB interface (13) connection socket for mains plug
(14) audio line
5 Operation and Handing
This chapter provides you with important notices with regard to operating the device.
5.1Operating elements and displays
A control panel for the refrigerator zone
1 Eco mode

2 left cooling drawer, temperature regulation
3 display
4 right cooling drawer, temperature regulation
5 lock/ child protection for control panel of refrigerator zone
B control panel for music player
6 mode for selection of music source
7 previous music title
8 reduce volume
9 plus volume
10 next music title
11 lock / child protection for control panel of music play, play and pause
Please note
►Refrigerator and Music Player share the same display zone.
►When the music player is on, the setting of cooling drawer can be unlocked by
pressing for 3 seconds.
5.2Operation of the device
Temperature Setting.
Plug in the power plug.
Press the unlock key for 3 seconds.
Press for setting of temperature (1-12) of left drawer.
Press for setting of temperature (1-12) of right drawer.
With OF the respective drawer can be switched off.
When the Sound & Cool is switched on you can change the temperature of the
drawers by unlocking the panel for the drawers. Press for 3 seconds and

then set desired temperature. The two control panels are working independently
from each other.
The temperature in the device depends on the room temperature, the quantity of
bottles/ amount of food and the chosen temperature. Please note that your device is
intended to cool food and beverages. The maximum temperature that can be
reached inside the device cannot be significantly ABOVE the ambient temperature at
the setup location.
When you open the drawer the actual temperature is displayed.
Please note
►The device beeps when the drawers is opened too long and the display shows DR
to remind you to close the drawer.
►Let the device work for 2 hours before placing food/beverages into the device.
►If not further operation is performed within 2 seconds, then the displayed
temperature is confirmed and stops flashing.
Eco Mode
Press button for 3 seconds until ECO is displayed. The temperature for
both drawers is set to 5 °C automatically.
5.3Charging via USB
As soon as the device is switched on, you can charge via the two USB ports.
5.4Instruction for storage of food / beverages in the device:
•It is important to store food / beverages properly.
•Do not store food in the device which is easliyl addled at low temperatures, such
as bananas, tropical frutis. They may discolor and the vitamin content may be
reduced.
•Do not place hot food / beverages into the device. Let them cool down before
placing into the device. The adding of hot food / beverages would affect the
temperature of the device and affect the freshness of other food / beverages.
•Do not open the device too frequently as this will allow warm air to enter the
device and the inside temperature will rise.
•Store food in containers and bags so that the smelle and taste of the food will not
be influenced.
•Food such as fruit and vegetables shall be cleaned before storage. This is also
recommened for the packaging of food. So other food will not be affected.

•Bottles have to be tightly placed to prevent them form tilting when the drawers are
opened.
•Do not place tall cans/canisters, otherwise the drawer cannot be closed properly.
•The partions of the drawers can be removed and the inserts can be move, to store
different types of food.
•The left and right drawer can be controlled inpedently. Adjust the temperature
according to the food.
•Do not overfill the device so that the internal air circulation is not intered.
5.5Sound Bar
The Sound Bar is switched off when the device is switched on. Press for 3
seconds to unlock the control panel and to activate the music player. Buzzer alarms
and the control panel is flashing. The display of drawer shows the chosen music
source.
Example for music source: USB
Press Modus to choose music-source:
BL = Bluetooth LINE = external audio mode USB =
USB
1) Connection via bluetooth
The display shows choosen music source and broadcast it in English language. For
example: Bluetooth Mode. Select desired mode with your mobile/tablet and connect
with the device. If phone requires password then input “0000”. When the connection
is successfully arranged then the Sound & Cool is working as external speaker for
your mobile/tablet. When the connection is disconnected the voice prompts this for
example “bluetooth disconnected.“
After 5 minutes the connection will be resettet. The connection will automatically be
reconnection when your mobile/tablet will come back to range of the device.
2) External audio mode/ AUX mode

The display shows „LINE“ and
the voice prompts: “external
audio mode“. The Sound & Cool
can be used as external audio of
your mobile / tablet by inserting a
3,5 mm audio cable for
connection with your
mobile/tablet. Then you can
control the music using your
mobile/tablet.
In this mode the control panel of
the device cannot be used for
switching to previous/ next title,
use yor mobile/tablet for this.
3) USB mode
“USB“ is displayed. Connect the your device to upper USB port. The Sound & Cool
supports MP3/WMA/APE/FLAC/WAV Voice prompts “USB
Mode“. The Sound & Cool will play the music from your USB
device.
When the connection is disconnected the voice prompts this
“USB disconnected.“
Only the upper USB port is suitable for playing of music.
Pause of Music
To pause the music player you have 2 options:
•Press Pause/Play on your external device (your mobile/tablet).
•Press for 3 seconds to unlock the control panel and again to pause the
music player. The display shows: . With you can restart the player
and the display shows:
Selection of music title

Press for 3 seconds to unlock control panel. With > you can select the
next song, the display shows „-I“ for 2 seconds. With < you can select the previous
song, the display shows „I-„ for 2 seconds.
After 2 seconds the display returns to audio mode.
In external audio mode/AUX mode you cannot use the < and > on the control panel.
Volume adjustment
There are 16 levels of volume. Default volume is level 8. Wth + and –you can adjust
the level. After 2 seconds the display returns to audio mode.
The control panel of the music player. will be locked automatically after 10 seconds
without operation. You can turn off the music player by pressing for 6
seconds. After 3 seconds the control panel is locked and after additional 3 seconds
the display shows “OFF”. Then music player is off.
5.6 Charging via USB
via upper USB port you can play music an charge your
device (mobile)
via AUX port you can play music
via lower USB port you can charge your device (mobile)
5.7 Rating plate
The rating plate with the connection and performance data is
placed here:
6 Cleaning and Maintenance
This chapter provides you with important notices with regard to cleaning and
maintaining the device. Please observe the notices to prevent damages due to
cleaning the device incorrectly and to ensure trouble-free operation.
6.1Safety information
Attention

Please observe the following safety notices, before you commence with cleaning the
device:
►Prior to commissioning, clean the appliance thoroughly.
Attention
►Switch the Sound & Cool off prior to cleaning it and unplug the plug from the wall
power outlet. Remove all all food / beverages.
►Be careful during cleaning of the USB/AUX ports at the side of the device. Clean
them only with dry cloth. Do not use wet cloth or spray for cleaning of these ports.
►Do not clean the device with spray / liquid and do not place the device in
environment where the device may become wet or splashed with moisture. There
is a risk of a short circuit.
►Do not use any aggressive or abrasive cleaning agents or solvents.
►Do not scrape off stubborn dirt with hard items.
6.2Cleaning
Unplug the device. Remove food / beverages and accessories (inserts / partitions)
from the device.
Mains Plug, USB and AUX ports shall be cleaned only with dry , soft
cloth.
Clean surfaces and drawers with soft cloth and neutral cleaning
solvent. Do not use hot water. Thoroughly dry device after cleaning.
Clean the gasket of the drawers regularly to make sure that drawers
close properly. Use water only for cleaning of the gasket of the
drawers.
You can remove the drawer for cleanging. Remove inserts and partitions. Move
drawer upside and back to remove it. Clean drawer, inserts and partitions with soft
cloth.

6.3Defrost
The device automatically defrosts. Condensated water will be collected in a tray and
will automatically evaporate by compressor heat.
6.4Moving the appliance
Turn off the appliance first and then unplug the unit from the wall outlet.
Remove all content. Shurely tape down all lose items inside your appliance.
Tape drawers shut. Fix the drawer with tape. The appliance may be title by a max
angle of 45 °, otherwise the cooling system can be damaged..
Troubleshooting
This chapter provides you with important notices with regard to operating the device.
Observe the following notices to avoid dangers and damages:
6.5Safety notices
Attention
►Only qualified electricians, who have been trained by the manufacturer, may carry
out any repairs on electrical equipment.
►Improperly performed repairs can cause considerable dangers for the user and
damages to the device.
6.6Fault indications and rectification of faults
The following table assists in localizing and rectifying minor faults.
Fault
Possible Cause
Device does not operate.
Not plugged in using different voltage. The circuit
breaker tripped or a blown fuse.
Your device is not cold enough or it
does not reach the adjusted
temperature. Compressor does not
stop to work.
Check the temperature control setting.
External environment may require a higher setting.
The door is open too often. The door is not closed
completely. The door seal does not seal properly.
The device does not have the correct clearance.
Device is over filled.
Vibrations.
Check to assure that the device is level.
The device seems to make to
much noise
The device is not level.
- Components are loose - Device touches the wall
The door will not close properly.
The device is not level.
The seal is weak. Device is over filled.

Control panel does not show
anything..
Electronic defect. Contact the customer service.
Buttons do not work.
Control panel is damaged.
Compressor will not start
Room temperature is lower than desired
temperature.
Dew on the surface of device：
The surface of wine cabinet especially the door
appear some frost if item in a damp room. This is
due to the moisture in the air coming into contact
with the device. Please wipe it away with dry cloth.
Liquid sound
The sound of compressor when starts or stops
working. The flowing sound of refrigerant in the
refrigeration system. The evaporating sound of
refrigerant in the evaporator
Condensation formed inside the
cabinet
Under the environment with high level of humidity
or the drawer has been left open for a long period
or opened frequently, wipe off the drawer and walls
and close the drawer as long as possible.
Attention
►If you are unable to solve the problem with the steps shown above, please contact
Customer Service.
7 Disposal of the Old Device
Old electric and electronic devices frequently still contain valuable materials.
However, they also contain damaging substances, which were necessary for
their functionality and safety. If these were put in the non-recyclable waste or
were handled incorrectly, they could be detrimental to human health and the
environment. Therefore, do not put your old device into the non-recyclable waste
under any circumstances.
Please note
►Utilise the collection point, established in your town, to return and recycle old
electric and electronic devices. If necessary, contact your town hall, local refuse
collection service or your dealer for information.
►Blowing gas inside the unit is flammable. The disposal of this flammable material
should be in accordance with national regulations.
►Ensure that your old device is stored safely away from children until it is taken
away: Remove the drawer doors, the partitions and the movable inserts in the
inner space, so that children cannot be accidentalyinjured.
