Caterlite DF824 User manual

Model • Modèle • Modell • Modello • Modelo • Malli:
DF824
Induction
hob
Instruction manual
DF824_UK_A5_v1_20180703.indb 1 2018/7/3 16:19

2
UK Telephone Helpline: 0845 146 2887
Safety Tips
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove any
components on this product.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- BS EN Codes of Practice
- Fire Precautions
- IEE Wiring Regulations
- Building Regulations
• Caution! Hot surface!
• DO NOT immerse the appliance in water.
• DO NOT leave the appliance unattended during operation.
• DO NOT move the appliance during cooking or with hot
cookware on top of it.
• DO NOT use cookware with a diameter less than 12cm.
• DO NOT place empty cookware on the appliance.
• DO NOT place any magnetic objects on the glass surface
during operation.
• DO NOT place metal objects/utensils on the appliance as they
may become hot during operation.
• People with a pacemaker fitted should not use the appliance
and keep a minimum of 60cm from the appliance during
operation.
• Always switch off and disconnect the power supply to the
appliance when not in use.
• Not suitable for outdoor use.
• If the glass surface is cracked disconnect from the power
supply and consult your Caterlite agent or recommended
qualified technician.
DF824_UK_A5_v1_20180703.indb 2 2018/7/3 16:19

3
UK
Telephone Helpline: 0845 146 2887
• Keep all packaging away from children. Dispose of the
packaging in accordance to the regulations of local authorities.
• If the power cord is damaged, it must be replaced by a
Caterlite agent or a recommended qualified technician in order
to avoid a hazard.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Caterlite recommend that this appliance is PAT tested on an
annual basis to ensure the product remains safe.
• non-ionizing electromagnetic radiation.
Introduction
Please take a few moments to carefully read through this manual. Correct maintenance and operation of
this machine will provide the best possible performance from your Caterlite product.
Pack Contents
The following is included:
• Caterlite Touch Control Double Induction Hob - 3kW • Instruction manual
Caterlite prides itself on quality and service, ensuring that at the time of packaging the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your Caterlite dealer immediately.
Induction Cooking
Induction cooking is a very efficient method of cooking as it reduces heat loss between the pan and the
atmosphere by as much as 40%. This makes it extremely energy efficient, as well as offering immediate
heat-up, unlike traditional heating methods which require time to get to temperature.
The Induction cooker works by creating a magnetic field within suitable cookware, which causes an
instant build-up of heat to cook the food.
Installation
Place the unit on a heat-resistant surface. Avoid placing it on or close to easy flammable materials.
Maintain a distance of 20cm (7 inches) between the appliance and walls or other objects for ventilation.
DF824_UK_A5_v1_20180703.indb 3 2018/7/3 16:19

4
UK Telephone Helpline: 0845 146 2887
Cookware
Suitable cookware includes:
• All magnetic pans such as Vogue Stainless Steel or
Triwall pans.
• Mild steel or plain steel (black iron) pans
• Enamelled/non-enamelled cast iron and iron pans
Unsuitable cookware includes:
• Cookware with a diameter of less than 12cm
• Ceramic or glass cookware
• Stainless steel, aluminium, bronze or copper
cookware unless marked as suitable for induction
cooking
• Cookware with feet
• Cookware with a rounded bottom (e.g. wok)
Control Panel
BOOST
key
LOCK
key
FUNCTION
key
Increase
key
On/Off key with
indicator light
LCD display Decrease
key
Heating
indicator light
Temperature
indicator light
Timer
indicator light
Operation
1. Place suitable cookware on to the centre of the glass plate.
2. Connect the appliance to the mains power supply. The On/Off indicator light illuminates.
3. Press the On/Off key to turn the appliance on. “----“ starts to flash on the display.
4. Press the FUNCTION key and your appliance will start to work with the default power level “1200” (w)
shown on the display.
NOTE: If unsuitable cookware or no cookware is present the appliance will beep
constantly before switching off.
The appliance will work by either running at a Power level or a Temperature.
When running at a fixed temperature, the power to the pan will reduce as the
pan heats up.
5. Press the FUNCTION key to cycle between the Power and Temperature functions.
6. Press the Increase or Decrease key to change the level of each function.
Function Level Increments Default
Power 500w to 1500w 100w/200w/300w 1200w
Temperature 60°C to 240°C 20°C 200°C
DF824_UK_A5_v1_20180703.indb 4 2018/7/3 16:19

5
UK
Telephone Helpline: 0845 146 2887
7. To turn one zone off, press and hold the
Decrease key. To turn both zones off, just
press the On/Off key.
• To lock/unlock the control panel, press and
hold the lock key.
• This appliance has an overheat protection
function. If the pan becomes too hot the
appliance will switch off, a buzzer will sound
and the display will show “E2”. Should this
happen, allow the appliance to cool before
restarting.
• Fan will continue to run while the glass surface
temperature is over 80°C.
Using the timer
• When in Power or Temperature mode, press
the FUNCTION key again to enter/view the
timer.
• Press the Increase or Decrease key to change
the timer.
Function Level Increments Default
Timer 0 to 180min 5min 0min
• When the set time expires, the appliance will
switch off automatically.
Boost function
• For faster cooking press the boost key. The left
zone will work at 2000W while right zone at
1000W.
• Put your pan on the left zone for fast cooking.
• The Boost mode can only last 10 minutes.
Afterwards, the left zone will work at 1800W
automatically.
Cleaning, Care &
Maintenance
Disconnect from the power
supply and allow the appliance
to cool before cleaning.
• Use warm, soapy water and a damp cloth to
clean the appliance.
• DO NOT use abrasive cleaners or pads.
• Dry thoroughly after cleaning.
• A CATERLITE dealer or qualified technician
should carry out repairs if required.
Troubleshooting
Fault Probable Cause Solution
The unit is not working The unit is not switched on Check the unit is plugged in correctly and
switched on
Plug and lead are damaged Call Caterlite agent or qualified technician
Fuse in the plug has blown Replace the plug fuse
Power supply Check power supply
Unsuitable cookware Replace with suitable cookware
“E0” on Display Unsuitable cookware / no
cookware
Replace with suitable cookware
“E1” on Display Appliance has overheated Check ventilation slots for blockages. Allow to
cool before attempting to use again.
“E2” on Display Temperature of pan is too
high (Pan is dry or empty)
Remove cookware. Allow to cool before
attempting to use again.
“E3” on Display Input voltage is too high/
low
Make sure the mains power supply is suitable
for the appliance.
DF824_UK_A5_v1_20180703.indb 5 2018/7/3 16:19

6
UK Telephone Helpline: 0845 146 2887
Technical Specifications
Model Voltage Power
(max.) Current
Power
range
(for both
zones)
Temperature
range
Dimensions
h x w x d (mm) Weight
DF824 220-240V
50/60Hz 3000W 12.5A 500-1500W 60-240°C 56 x 608 x 370 6.8 kg
Electrical Wiring
This appliance is supplied with a 3 pin, moulded, BS1363 plug and lead, with a 13 amp fuse as standard.
The plug is to be connected to a suitable mains socket.
This appliance is wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Compliance
The WEEE logo on this product or its documentation indicates that the product must
not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and
environmentally safe recycling process. For further information on how to dispose of
this product correctly, contact the product supplier, or the local authority responsible for
waste disposal in your area.
Caterlite parts have undergone strict product testing in order to comply with regulatory
standards and specifications set by international, independent, and federal authorities.
Caterlite products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of Caterlite.
Every effort is made to ensure all details are correct at the time of going to press, however, Caterlite reserves the right to
change specifications without notice.
DF824_UK_A5_v1_20180703.indb 6 2018/7/3 16:19

DECLARATION OF CONFORMITY
• Conformiteitsverklaring • Déclaration de conformité • Konformitätserklärung • Dichiarazione di conformità •
• Declaración de conformidad • Declaração de conformidade
Equipment Type • Uitrustingstype • Type
d'équipement • Gerätetyp •Tipo di apparecchiatura •
Tipo de equipo • Tipo de equipamento
Touch Control Double Induction Hob - 3kW
Model • Modèle • Modell • Modello • Modelo • Malli
DF824
Application of Council Directives(s)
Toepassing van Europese Richtlijn(en) • Application
de la/des directive(s) du Conseil • Anwendbare EU-
Richtlinie(n) • Applicazione delle Direttive •
Aplicación de la(s) directiva(s) del consejo •
Aplicação de directiva(s) do Conselho
Low Voltage Directive (LVD) 2014/35/EU
EN 60335-1:2012 + AC:2014 + A11:2014 + A12:2017 +
A13:2017
EN 60335-2-36:2002 + A1:2004 + AC:2007 + A2:2008 +
A11:2012
EN62233:2008
Electro-Magnetic Compatibility (EMC) Directive 2014/30/EU
EN 55014-1:2017
EN 55014-2:2015
EN 61000-3-2:2014
EN 61000-3-3:2013
Restriction of Hazardous Substances Directive (RoHS)
2011/65/EU
Producer Name • Naam fabrikant • Nom du
producteur • Name des Herstellers • Nome del
produttore • Nombre del fabricante • Nome do
fabricante
Caterlite
Producer Address • Adres fabrikant • Adresse du
producteur • Anschrift des Herstellers • Indirizzo del
produttore • Dirección del fabricante • Endereço do
fabricante
Fourth Way,
Avonmouth,
Bristol,
BS11 8TB
United Kingdom
I, the undersigned, hereby declare that the equipment specified above conforms to the above Directive(s) and Standard(s).
Ik, de ondergetekende, verklaar hierbij dat de hierboven gespecificeerde uitrusting goedgekeurd is volgens de bovenstaande
Richtlijn(en) en Standaard(en).
Je soussigné, confirme la conformité de l'équipement cité dans la présente à la / aux Directive(s) et Norme(s) ci-dessus
Ich, der/die Unterzeichnende, erkläre hiermit, dass das oben angegebene Gerät der/den oben angeführten Richtlinie(n) und Norm(en)
entspricht.
Il sottoscritto dichiara che l'apparecchiatura di sopra specificata è conforme alle Direttive e agli Standard sopra riportati.
El abajo firmante declara por la presente que el equipo arriba especificado está en conformidad con la(s) directiva(s) y estándar(es)
arriba mencionadas.
Eu, o abaixo-assinado, declaro que o equipamento anteriormente especificado está em conformidade com a(s) anter
ior(es) Directiva(s)
e Norma(s)
Date • Data • Date • Datum • Data • Fecha • Data
13/06/2018
Signature • Handtekening • Signature • Unterschrift
Firma • Firma • Assinatura
Full Name • Volledige naam • Nom et prénom • Vollständiger Name •
Nome completo • Nombre completo • Nome por extenso
Ashley Hooper
Position • Functie • Fonction • Position • Qualifica • Posición • Função
Technical & Quality Manager
DF824_UK_A5_v1_20180703.indb 7 2018/7/3 16:19

DF824_UK_A5_v1_20180703
DF824_UK_A5_v1_20180703.indb 8 2018/7/3 16:19
