CDA FF660 Quick start guide

Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY
T : 01949 862 012 F : 01949 862 003 E : [e-mail] W : www.cda.eu
www.cda.eu
FF660
Freestanding
Frost Free
Fridge Freezer
Installation, Use and Maintenance

2
Important
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note
that CDA reserve the right to invalidate the guarantee supplied with
this product following incorrect installation or misuse of the appliance.
This appliance is not designed to be used by people (including
children) with reduced physical, sensorial or mental capacity, or
who lack experience or knowledge about it, unless they have had
supervision or instructions on how to use the appliance by someone
who is responsible for their safety.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number

3
CE Declarations of Conformity:
This appliance has been designed, constructed and marketed in
compliance with safety requirements of EEC Directive 2006/95/EEC
(Low voltage) and requirements of EMC Directive 2004/108/EEC.
This appliance has been manufactured to the strictest standards and
complies with all applicable legislation, including Electrical safety (LVD)
and Electromagnetic interference compatibility (EMC). Parts intended
to come into contact with food conform to EEC/89/109.4
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must not be disposed
of as urban waste. It must be taken to a special local authority
dierentiated waste collection centre or to a dealer providing this
service.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health deriving from
inappropriate disposal and enables the constituent materials to be
recovered to obtain significant savings in energy and resources. As a
reminder of the need to dispose of household appliances separately,
the product is marked with a crossed-out wheeled dustbin.

4
Important
• Never store inflammable or explosive items and strong
corrosive acids or alkalis in the appliance.
• This is a household appliance, which is produced in
accordance with the national standard. It is intended for
food storage only, not for storage of blood, medicine and
biological products.
• To prevent risk of fire, keep the appliance away from
petrol or any other inflammable items.
• To prevent risk of electromagnetic interference or other
accidents, do not place a microwave oven on top of
the refrigerator or use any electric appliance inside the
refrigerator.
• Do not allow children to play with or near the appliance.
The internal surface of freezer compartment is very cold
when the appliance is running. Do not touch the surface
especially with wet hands.
• Do not splash water onto the appliance. Keep it away
from places of high humidity that may have adverse eect
on the electric insulation performance.
• Please remove the door, door seal and shelves before
disposal of the old appliance and put them away in a safe
place to prevent children from being entrapped.

5
Before First Use
You must allow the fridge to settle for at least twenty four hours
prior to switching the power on.
It is recommended that you clean the interior of the appliance prior to
first use, using a solution of bicarbonate of soda and warm water and
then thoroughly drying the interior.
The fridge may have an odour to it at first use. This will disappear as
the appliance cools.
Please note:
The appliance will work continuously until it comes down to the
correct temperature.
It takes two to three hours for the fridge and freezer to reach
temperatures appropriate to store food.
If the appliance is switched o, you should allow five minutes
before switching it on again to prevent unnecessary damage to the
compressor.

6
Fridge Use
• Never put liquids in the refrigerator uncovered.
• Never put hot foods in the refrigerator. Warm food should be
allowed to cool to room temperature before being put into the
refrigerator.
• Nothing should obstruct the air inlets in the rear wall of the
refrigerator, as this will cause frost and possible condensation
problems which will be dicult to remove.
• Make sure food is clean and any extra water is wiped away before
putting into the fridge.
• Wrap or cover food before putting into the fridge. This will help
prevent the loss of moisture, keep food fresh and avoid unpleasant
odours.
• Sort foods prior to storing. Any foods to be used soon should be
stored at the front of the shelf to prevent deterioration caused by
the door being open for prolonged periods.
• Do not overfill the fridge. There should be sucient space between
the foods to allow the cool air to circulate.
• Thawing frozen foods in the fridge compartment will help to keep
the temperature low and save energy.
• Only open the door for as long as is necessary. Leaving the
door open for long periods will aect the temperature inside the
appliance and waste energy.
• Ensure all compartments are fully closed after use.

7
Freezer Use
•The freezer compartments are designed to store only frozen food.
•Never put hot or warm foods in the freezer, allow them to cool fully
before putting them into the freezer.
•Follow the instructions on the food packaging for storage of frozen
food. If no information is provided, foods should not be stored for
more than three months after the purchase date.
•Store food in small packages (ideally less than 2.5kg). This reduces
the freezing time and improves the quality of the food after thawing.
•Wrap food before putting into the freezer. To stop the wrapping
sticking together, ensure it is dry.
•Label the food before freezing with information including type of
food and dates of storage and expiry.
•Once food is thawed, it must not be refrozen unless it has been
completely cooked. Only defrost as much food as is required
to prevent wastage.
•Bottled or canned drinks should not be stored in the freezer
compartment as they could explode.
•Check the rating plate to confirm the maximum amount of fresh food
that can be frozen within a 24 hour period.
Do not attempt to freeze more than the maximum amount.

8
Control Panel
A: Fridge temperature
display
B: Freezer temperature
display
C: Super cool light
D: Holiday light
E: Fridge key
F: Freezer key
G: Holiday key
H: Super freeze light
J: Alarm light
K: Super cool key
L: Super freeze key
M: Alarm key
Fig. 1
B
A
G
F
E
D
C
L
K
J
H
M

9
Setting the Fridge Temperature
The fridge temperature may be set between 2°C and 8°C.
• Touch the “Fridge” key several times, until the required temperature
for the fridge compartment flashes in the “Fridge temperature”
display.
• When the display stops flashing this temperature will be set.
Setting the Freezer Temperature
The freezer temperature may be set between -24°C and -14°C.
• Touch the “Freezer” key several times, until the required
temperature for the freezer compartment flashes in the “Freezer
temperature” display.
• When the display stops flashing this temperature will be set.
Super Cool Function
The “Super cool” function can be used to chill large quantities of fresh
food as quickly as possible.
• When this is switched on the fridge temperature setting drops to
2°C.
• This function runs for 6 hours before automatically switching o for
your convenience. Alternatively, it can be manually switched o
after less than 6 hours.
To switch the super cool function on
Touch the “Super cool” key once. The setting is confirmed by the
“Super cool” light illuminating.

10
To switch the super cool function o
Either: Touch the “Super cool” OR “Fridge” key once.
Or: The “Super cool” function automatically switches o after 6
hours.
In either case, the fridge temperature reverts back to the setting
before “Super cool” was switched on.
Super Freeze Function
The “Super freeze” function can be used to freeze large quantities of
fresh food as quickly as possible. For best results, switch the “Super
freeze” function on 12 hours prior to introducing large quantities of
food to be frozen.
• When this is switched on the freezer temperature setting drops to
-24°C.
• This function runs for 24 hours before automatically switching o
for your convenience. Alternatively, it can be manually switched o
after less than 24 hours.
To switch the super freeze function on
Touch the “Super freeze” key once. The setting is confirmed by the
“Super freeze” light illuminating.
To switch the super freeze function o
Either: Touch the “Super freeze” OR “Freezer” key once.
Or: The “Super freeze” function automatically switches o after
24 hours.

11
In either case, the freezer temperature reverts back to the setting
before “Super freeze” was switched on.
Chilled Water Dispenser
The chilled water dispenser is used to dispense chilled water without
the need to open the fridge door each time.
Fitting and removal
Before fitting the chilled water dispenser to the fridge door, ensure
that the draught seal around the chilled water chute in the fridge door
is correctly located.
• The seal may have become turned inside-out when the chilled
water dispenser was previously removed.
• Referring to fig. 2 (below), the inner ring of the seal should be
pointing downward before the water dispenser is fitted.
• If the inner ring is pointing upward it may be pushed down to its
correct orientation by gentle finger pressure alone.
Note: There is a slit in this seal to ease fitting: This is not a fault.
Fig. 2

12
Fitting
To fit the chilled water dispenser into
the fridge door:
• Line it up with its locating lugs,
ensuring that the exit spout at the
bottom enters the chute in the door
(Fig. 3).
• Slide the chilled water dispenser
downwards to lock it into position
(Fig. 4).
Removal
To remove the chilled water dispenser,
reverse the steps described above for
fitting it.
Note: The fitting of the chilled water
dispenser may be sti when new but it
will become easier with use.
Fig. 4
Fig. 3

13
Fig. 5
Filling the chilled water dispenser
To fill the chilled water dispenser:
• Ensure the dispenser is securely
fitted to the door.
• Open the hinged lid and fill with clean
cold water (Fig. 5).
• Do not use the dispenser for any
liquids other than plain still water.
• Do not add hot liquid to the water
dispenser, this would add excessive
heat to the refrigerator and may
contribute to frost forming.
• Close the lid and close the fridge
door.

14
Dispensing chilled water
• Before dispensing water, ensure
that the lock switch above the water
dispenser is in the unlocked position
(Fig. 6).
• Press your glass gently against the
dispensing lever (“A” in Fig. 7).
• Dispensing will stop when the glass is
taken away.
Cleaning the chilled water dispenser
The chilled water dispenser should be
removed from the door for cleaning. It
is best cleaned with a mild washing up
liquid solution, then either dried with a
soft cloth or left to drain naturally.
While the water dispenser is out of
the door its chute in the door can be
cleaned carefully with a mild washing
up liquid solution on a damp cloth.
A
Fig. 7
Fig. 6

15
Holiday Mode
This appliance is equipped with a holiday mode, which switches the
fridge to 15°C and leaves the freezer running. This maintains frozen
food during a holiday, and reduces the energy used by the fridge.
This setting is not suitable for use when there is food in the fridge.
To switch the holiday mode on
• Touch and hold the “Holiday” key for 3 seconds. The “Holiday” light
will illuminate to confirm holiday mode is activated and the “Fridge
temperature” display will show “-”.
To switch the holiday mode o
• Touch the “Holiday”, “Super cool” OR “Fridge” key once.
The fridge temperature reverts back to the setting before “Holiday”
mode was switched on.

16
Door Open Alarm
This appliance is equipped with an alarm to alert you if a door is left
open.
In the event that a door is left open for more than two minutes the
appliance will give three beeps once a minute, for ten minutes and
the “ALARM” light will illuminate; this continues until both doors are
properly shut, or until the “Alarm” key is touched.
Defrosting the Fridge
The fridge is cooled by convection using cold air forced through
channels at the rear of the fridge. No defrosting is required.
Defrosting the Freezer
The freezer is frost free and as such is designed not to require
defrosting.
Changing the Light
LED lighting is used in this fridge due to its long life expectancy. In the
unlikely event of light failure this is not user-replaceable. If the light
fails, contact CDA Customer Care.

17
Care and Cleaning
Always disconnect the appliance from the power supply before
any cleaning or maintenance.
The fridge sections should be cleaned using a solution of bicarbonate
of soda and lukewarm water.
Do not use abrasive products or detergents. After washing, rinse and
dry thoroughly.
Clean the shelves and balconies separately by hand with soap and
water. Do not put them in the dishwasher.
Once cleaning is complete, then reconnect the power.
Keep the door gaskets clean. If damaged, the gaskets should be
replaced.
If the appliance is not used for prolonged periods of time, unplug and
clean the appliance. The door should be left slightly open to prevent
the formation of mildew and smell.

18
Troubleshooting
If you have any problems with your appliance, you should check
the troubleshooting prior to calling CDA Customer Care to prevent
unnecessary service calls and potential cost.
The appliance is not working
Check:
• There is power to the appliance.
• The house fuses are intact and the fuse in the plug has not blown.
• The fridge is not in “Holiday” mode (“Holiday” light should not be
illuminated on the control panel).
• The plug socket is functioning correctly. To check this, plug another
electrical appliance in to see if the socket is working.
• The temperature of the room is adequate (10°C or above).
The appliance is working, but not very well
Check:
• The appliance is not overloaded.
• The temperature is set to an appropriate level.
• The doors close properly.
• The cooling system at the rear of the appliance is clean and free of
dust, and not touching the rear wall.
• There is enough ventilation at the side and rear walls.
• The temperature of the room is adequate (10°C or above).

19
The appliance is noisy
Check:
• The appliance is level and stable.
• The side and rear walls are clear, and there is nothing resting on the
appliance.
Note: The cooling gas in the refrigerator will make a slight bubbling
noise, even when the compressor is not running.
The freezer gives ten long beeps at minute intervals and/or the
“Alarm” light illuminates, freezer temperature display shows “-”
The most likely cause is that the freezer is too warm.
• Touching the “Alarm” key for 3 seconds will display the highest
temperature the freezer has reached.
• To cancel the alarm, touch the “Alarm” key briefly.
• If a large quantity of food has only recently been added to the
freezer, it is likely that the temperature will resolve itself shortly.
Ensure that the “Super freeze” function is used to help this.
• If there is no obvious cause for the alarm sounding, contact CDA
Customer Care (details on back cover).

20
Installation
This appliance must never be installed close to heat sources, e.g.
heating elements, cookers or in damp places.
• The plug should be fully accessible at all times.
• To ensure the appliance is level, you should use the height
adjustable feet at the front of the appliance.
• The cooling system at the rear of the appliance must not touch the
rear wall.
• The appliance must be installed with adequate ventilation. Ensure
that there is 10cm clearance above the appliance, and that there is a
minimum space of 7.5cm between the rear of the appliance and the
wall.
Fitting the Door Handles
For safety in transit, this appliance is supplied with the door handles
left for the user to fit. To do this:
• Lever the plastic blanking plugs out of the handle fixing holes on
the left side of he doors.
• Use the special fixing screws supplied in a plastic bag within the
appliance to secure the handles in position.
• Fit the decorative screw covers.
