CDA hc9625 Reference manual

Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY
T : 01949 862 012 F : 01949 862 003 E : [email protected] W : www.cda.eu
hc9625 Ceramic Hob
Manual for Installation, Use and Maintenance

2
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note
that CDA reserve the right to invalidate the guarantee supplied with
this product following incorrect installation or misuse of the appliance
or use in a commercial environment.
This appliance is not designed to be used by people (including
children) with reduced physical, sensorial or mental capacity, or
who lack experience or knowledge about it, unless they have had
supervision or instructions on how to use the appliance by someone
who is responsible for their safety.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number
CE Declarations of Conformity:
This appliance has been manufactured to the strictest standards and
complies with all applicable legislation, including Electrical safety (LVD)
2006/95/EC and Electromagnetic interference compatibility (EMC)
2004/108/EC. Parts intended to come into contact with food conform
to 89/109/EC.

3
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must be taken to a special
local authority waste collection centre or to a dealer providing
appliance recycling services.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health. It also
enables the constituent materials to be recovered, saving both energy
and resources. As a reminder of the need to dispose of household
appliances separately, the product is marked with a crossed-out
wheeled dustbin.

4
User Information
Please note:
• Ceramic hobs become hot and remain hot during and immediately
after use. Do not touch the hob until it has been allowed to cool.
• Keep children away from the appliance when in use.
• Never put cooking foil or plastic materials on the ceramic surface
when the hob is hot. These materials could melt and cause damage
to the hob.
• Never use the hob top for storage.
• Pan handles should never stand out beyond the edge of the
worktop. This will help ensure children cannot reach them.
• Do not use pans with rough bases (e.g. cast iron) as these may
scratch the hob surface.
• Do not switch on the zones without cookware in place.
• Do not lean over the hob when it is in use.
• Follow the cleaning instructions carefully.
• Ensure the base of the saucepan is clean and dry before placing it
on the hob to prevent damage to the surface of the hob.
• After use, please ensure that the control knobs are in the ‘O”
position.
• This hob (Class 3) has been designed for use only as a cooking
appliance. Any other use (e.g. heating rooms) should be
considered incorrect and therefore dangerous.
• The appliance is not intended to be operated by any means of an
external timer or separate remote-control system.
Important
• Do not use the hob if the glass surface is cracked or damaged, to
prevent risk of electric shock. Disconnect it from the power supply.

5
Using Your Hob
Zones:
1. Front left: 1/2.2kW - 140/210mm dual
2. Centre left: 1.2kW - 140mm
3. Centre right: 0.7/1.7kW - 120/180mm dual
4. Front right: 1.2kW - 140mm
5. Touch control panel
Fig. 1
2
1
3
4
5

6
Touch control
1. Zone indicator key
2. Zone display
3. Zone indicator
4. Dual zone indicator
5. Dual zone key
6. Increase key
7. Decrease key
8. Timer display
9. Timer key
10. Timer zone indicator
11. Minute minder indicator
12. Childlock key
13. Childlock indicator
14. Power key
Fig. 2 3
11
97 14
42 1 5 6 8 10 12 13

7
Fig. 3
Hi-light cooking
zone Ø 140mm
Second element
Hi-light double zone
Fig. 4
How to Use the Hob
The ceramic surface of the hob allows
fast transmission of heat vertically from
the heating elements under the glass to
the pans on the hob top.
The heat does not spread horizontally,
so the hob top remains relatively cool
only a few centimetres from the zone in
use.
Please note:
The heating elements are equipped
with a temperature limiter that will
switch the element o to prevent
damage to the hob.
The temperature limiter may also operate when incorrect pans
are used or pans are poorly positioned. This will aect cooking
performance.
The temperature limiter can be seen in the zone as the straight line
out from the centre of the element. This is not a fault with the hob.
To switch the hob on:
Touch and hold until the zone displays show “0”.
Please note:
If a zone is not selected or the timer set within approximately 10
seconds, the hob will automatically switch o.

8
To switch on a zone:
Once the hob is switched on, touch for the zone required. The
zone indicator will switch on to confirm the zone is active.
EITHER: Touch and hold to select the power level from 1 (minimum)
to 9 (maximum). The power level selected will show on the
zone display.
OR: Touch and hold to select the power level from 9 to 1. The
zone will remain active for approximately ten seconds to
allow for adjustment.
To adjust the power level once set:
Touch for the zone required. The zone indicator will switch on to
confirm the zone is active.
Touch and hold or until the required power level shows on the
zone display.
To use the dual zone:
The dual zones are formed from two separate coils.
Touch at any time to switch the dual zone on or o when the zone is
switched on for either of the dual zones.
The dual zone indicator will switch on when the dual zone is on.
To switch o a zone:
Touch for the zone required.
Touch and hold until the zone display shows “0.”
The zone display will show “0” for 10 seconds, then H to indicate the
residual heat.

9
To switch the hob o:
Touch and hold at any time.
Zone Settings:
Booster:
The hob is equipped with a booster function, which allows a zone to
run at maximum power for a preset period of time before returning to
the required power level. These times are shown in the table.
To set the booster:
Once the hob is switched on, touch for the zone required. The zone
indicator will switch on to confirm the zone is active.
Touch so the zone display shows “9”.
Touch so the zone display shows “A”.
Touch and hold to set the required power level.
Power Level Type of Cooking
0 Switched o
1/2 For melting (butter/chocolate) or keeping food warm
2/3 Keeping food hot or to heat small quantites of liquid
3/4 Heating large quantities of liguid (sauces etc.)
4/5 Slow boiling e.g. spaghetti, soups, stews, potatoes
6/7 Gentle frying
7/8 Browning meats, frying fish. omelettes
9 Fast frying steaks
Cooking Zone Power
Level 1 2 3 4 5 6 7 8 9
Fast Heating Time 1 min. 3 min. 5 min. 6min.
30sec.
8 min.
30sec.
2 min.
30 sec.
3 min.
30 sec.
4 min.
30 sec. N/A

10
To adjust the power level when the booster is set:
Touch for the zone required.
Touch and hold or until the required power level shows on the
zone display.
To cancel the booster:
Touch for the zone required.
Touch and hold until the zone display shows “0”.
Then touch and hold or until the required power level shows on
the zone display. “A” will no longer show on the zone display.
The Timer/ Minute Minder:
The timer allows you to preset the length of time any of the zones
will be on, between a minimum of one minute and a maximum of 99
minutes. The timer can be used on each zone separately and can
also be used as a minute minder, to countdown the time without using
any of the zones.
To set the timer:
Switch on the zone and set the power level.
Whilst the dot is showing on the zone display, touch . The timer
display will show “00” and the timer zone indicator will switch on to
show which zone timer is being set.
To set the time from zero, touch and hold until the required cooking
time shows on the display.
To go straight to 30 minutes, touch .
Then touch either or to adjust the time further.

11
To change the timer once set:
Touch for the required zone.
Touch . The remaining time for the active zone will show on the
timer display.
Touch or to adjust the time.
To cancel the timer once set:
Touch to activate the timer, then touch to reduce the time required
until the zone display shows “0”.
Please note:
If you cancel the timer, the zone will continue at the set power level
until it is switched o as described above.
At the end of the set time:
The zone will switch o.
The timer display will flash “00” and the timer indicator will flash, then
will switch o if no other timers have been set.
The zone display will show “H” to indicate the residual heat.
The hob will beep for approximately 2 minutes. To switch o the
beep, touch any key.
If no other zones are in use, then the hob will switch o automatically.
To set the minute minder:
Touch . The timer display will show “00” and the minute minder
indicator will switch on.
To set the time from zero, touch and hold until the required time
shows on the display.

12
To go straight to 30 minutes, touch .
Then touch either or to adjust the time further.
If the minute minder is set, the hob will switch o after ten seconds,
and the minute minder will continue to run.
Please note:
The timer will start as soon as the time has been set.
If more than one zone timer is set, the timer display will show the
countdown for the last timer set.
If more than one timer is set, touch repeatedly to cycle through each
of the timers set. The timer indicators will show which timer is being
displayed.
Safety Features
The childlock:
The hob is equipped with a childlock to lock all the controls except
for safety reasons. This can be used when the hob is o or during
cooking.
To set the childlock:
Touch to switch the hob on.
Touch and hold for approximately 2 seconds. The childlock
indicator light will switch on.
To turn o the childlock:
Touch and hold for approximately 2 seconds. The childlock
indicator light will switch o.

13
Please note:
If the hob has been turned o whilst the childlock is on, touch then
touch and hold for approximately two seconds to switch o the
childlock.
Residual Heat Indicators:
The hob is equipped with residual heat indicators to warn when any of
the zones are still hot to the touch after cooking.
An “H” will show in the relevant zone display after cooking until the
zone is at a safe temperature to touch.
Please note:
You should avoid touching the zones when the hob is in use, or when
an “H” is showing on the zone display.
In the event of a power cut, the residual heat indicators will not
illuminate after the power supply is restored so extra care must be
taken.
Temperature Limiter:
The hob is equipped with a temperature limiting sensor that adjusts
the power output of the hob if the bottom of the cookware becomes
too hot, preventing damage to the cookware and to the hob itself.

14
Auto-stop Protection:
The hob is equipped with a sensor that will switch o the zone after
a factory set period of time if no keys are touched once the zone is
switched on.
Power Level of Cooking
Zones
Operation Time Limit
1 6 hours
2 6 hours
3 5 hours
4 5 hours
5 4 hours
6 90 minutes
7 90 minutes
8 90 minutes
9 90 minutes

15
Ecient Use of Your Hob
The hob is equipped with zones of dierent sizes, designed to
accommodate most shapes and sizes of pan. For best results, only
use pans with flat bottoms and choose appropriate zones depending
on the sizes of the pans. The most ecient use of the hob is shown
below, where the pans and zones are correctly chosen.
Use pan lids where possible to minimize the energy usage of your
appliance.
Turn o each zone a few minutes before the end of cooking time.
The residual heat in the zones will continue to cook the food for the
remaining cooking time.
It is very important that the pans used on the hob are made of a
suitable material and have the correct type of base. The base should
be flat and smooth, as any rough part on the pan base could scratch
the ceramic hob top.
fig.2
Zone Size Minimum Pan Size (cm) Maximum Pan Size (cm)
140 mm 11 16
180 mm 15 20
120 / 180 mm dual 9 / 15 14 / 20
140 / 210 mm dual11 / 18 16 / 23

16
Choose pans which are between the sizes recommended in the table
above, and with bases that are as non-reflective as possible, e.g. dull
and dark.
Only pans recommended for use on ceramic hobs should be used.
Pans with aluminium bases may leave silver streaks or spots on the
hob. Glassware and pans with rough circular machined bases should
not be used
Care and Maintenance
Always disconnect the appliance from the power supply before
undertaking any cleaning or maintenance.
You should use a non-abrasive cleaner to clean the hob top. Any
abrasive cleaner (including Cif) will scratch the surface and could
erase the control panel markings.
Do not use steel wool, abrasive sponges or sharp utensils such as
knives to clean the hob as these could damage the hob. The hob
surface and the pans must be clean.
Carefully remove any food remains (especially those containing sugar),
dirt etc. as soon as is possible after spillage - using a ceramic hob
scraper if necessary whilst the zone is still hot.
Sugar/syrup mixtures could permanently pit the hob surface if left to burn
on. Once they have cooled and hardened they become increasingly

17
dicult to remove.
All cleaner residues should be removed with a damp cloth.
Important:
• Steam cleaners must not be used when cleaning this appliance.
Mains electrical voltage: 230 – 240Vac, 50 Hz
Total rated electrical consumption: 6.3 kW
If your hob is not working:
1. Check that the control knobs are switched on.
2. Check that the mains supply has not been switched o.
3. Check that the fuse in the consumer unit has not blown.
Types of residues Clean with Cleaning advice
Light Cleaning sponge and
soft cloth
Wipe over the zone to be cleaned with a sponge and hot
water, and then wipe o with a soft dry cloth.
Accumulated baked-on stains/
dirt, sugar spills or melted
plastics
Cleaning sponge or
glass scraper and soft
cloth
Wipe over the zone to be cleaned with a sponge and hot
water, using a ceramic scraper to remove any large marks
or stains and then wipe o with a soft dry cloth.
Rings and hard water residues White vinegar and soft
cloth
Pour a small amount of warm white vinegar onto the stain,
leave it to stand, and then wipe o with a soft dry cloth.
fast frying steaks

18
Mains Electricity Connection
Warning! This appliance must be earthed
We recommend that the appliance is connected by a qualified
electrician, who is a member of the N.I.C.E.I.C. and who will comply
with the I.E.T. and local regulations.
This appliance is intended to be
connected to fixed wiring and is not
suitable for connection to a 13A plug
or 13A supply.
This appliance is intended to be
connected to fixed wiring by a
double pole switch, having a contact
separation of at least 3mm in all poles.
The switch must be positioned no
further than 2m from the appliance.
Please note:
• The mains cable must only be
replaced by a qualified electrician
or service engineer and must be of
equivalent or better rating
(i.e. 2.5 mm² HO5RR-F).
• This appliance is intended to be
connected to the mains supply with a
cable of cross section area 2.5 mm2.
Fig. 5
N
E
L
Fig. 6
LN E

19
A larger cable may not fit the terminal connections.
• The marking of the current rating of the fuse or circuit breaker
protecting this appliance should be marked on the socket outlet.
• Assembly and electrical connection should be carried out by
specialised personnel.
• When installing this product we recommend you seek the help of
another individual.
Fitting the Hob
Unpacking the hob:
Take care not to lose or mishandle any parts.
Fitting position of the hob:
This appliance must be installed a minimum of 50mm from any back
wall and a minimum of 180mm away from any adjacent vertical surfaces,
e.g. a tall cupboard end panel. This may be reduced to 100mm if the
adjacent surface is resistant to fire (tiles or steel, for example). These
dimensions are shown in Fig. 7.
If fitting a cooker hood above the hob:
If a cooker hood is to be installed above the hob, the height of the hood
above the hob must be at least 600mm (650mm is recommended) (Fig.
8). If the instructions supplied with the hood dictate that the hood must
be installed at a height greater than 600mm, then that height is the
minimum required.

20
Wall furniture requirements:
The minimum height of any cabinet immediately above the hob is
900mm. The minimum height of any adjacent units (including light
pelmets) is 400mm, unless they are manufactured from a material
resistant to fire (steel, for example)
Notes:
• Do not position this appliance above a refrigeration unit. The heat
generated may cause the refrigeration unit to fail.
• This appliance is designed to be installed into cabinet units capable
of withstanding temperatures of 65°C or greater above ambient
temperature.
• If there is no oven to be built in below the hob, an isolation shelf
should be fitted to protect the user from high temperatures. If the hob
is to be installed above a working drawer, then a partition should be
fitted to protect the contents and user from the heat generated during
use. This should be fitted 100mm below the hob.
• Never place perishable foods in the cupboard below the appliance.
