CDA VK902 Quick start guide

Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY
T : 01949 862 012 F : 01949 862 003 E : [e-mail] W : www.cda.eu
www.cda.eu
VK902 Compact
Combination
Microwave Oven
Installation, Use and Maintenance

2
Contents
• Important product and safety information - p3
• Before first usage instructions - p6
• Control panel layout - p7
• Using your appliance - p8
• Setting the clock - p9
• Setting the minute minder - p9
• Functions - p9
• Semi-automatic cooking - p12
• Automatic cooking - p13
• Safety key lock - p14
• Internal lighting - p15
• Operating time limiter - p15
• Care and maintenance - p16
• Cleaning - p18
• Installation - p20
• Mains electricity connection - p22

3
Important
This appliance must only be used for the purpose for which it is
intended, i.e. domestic cooking. Any other use could be dangerous
and may lead to premature failure of the appliance.
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note
that CDA reserve the right to invalidate the guarantee supplied with
this product following incorrect installation or misuse of the appliance.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
User information:
• Ovens become hot during and immediately after use.
•The oven door can become very hot during operation.
•After use, please ensure that the oven is switched ‘O’.
•Keep children away from the appliance when in use, and
immediately after use.
•Keep the oven door closed whilst grilling.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number

4
EU Declarations of Conformity:
This oven has been designed, constructed and marketed in
compliance with safety requirements of EU Directive 2014/35/EU (LVD)
and requirements of EU Directive 2014/30/EU (EMC).
Parts intended to come into contact with food conform to 1935/2004/
EC.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EU DIRECTIVE 2012/19/EU.
At the end of its working life, the product must not be disposed
of as urban waste. It must be taken to a special local authority
dierentiated waste collection centre or to a dealer providing this
service.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health deriving from
inappropriate disposal and enables the constituent materials to be
recovered to obtain significant savings in energy and resources. As a
reminder of the need to dispose of household appliances separately,
the product is marked with a crossed-out wheeled dustbin.

5
Important
• Read the user instructions carefully before using the
oven for the first time.
•Follow the instructions for first use of the oven.
•Clean the oven regularly.
•Remove spills as soon as they occur.
•Always use oven gloves when removing shelves and
trays from the oven.
•Do not allow children near the oven when in use.
•Do not allow fat or oils to build up on the oven shelves,
grill pan or oven base.
•Do not place any cooking utensils or plates directly on
the oven base.
•Always grill with the oven door closed.
•Do not grill food containing fat without using the grill pan
grid.
•Do not cover the pans, grids or the oven walls with
aluminium foil.
•Do not use the oven tray for roasting.
•Do not perform maintenance or cleaning of the oven
without first switching o the electricity supply. If the
oven has recently been used, allow to cool.
•Do not place hot enamel parts in water. Leave them to
cool first.
•Do not allow vinegar, coee, milk, saltwater, lemon or
tomato juice to remain in contact with enamel parts.
•Do not use abrasive cleaners or powders that will scratch
the surface of the enamel or stainless steel.

6
•Do not attempt to repair the internal workings of your
oven.
•Do not cover the oven floor with aluminium foil.
Before first use
First use
Before using the oven for the first time we recommend that, with
the power supply o, you clean the oven with soapy water. Once
done, rinse carefully, remove all accessories from the appliance and
then heat on the below programme at maximum temperature for the
specified time. A slightly unpleasant smell may be produced, caused
by grease remaining on the oven element from the production
process.
30 minutes full grill with rear element and fan
Please note:
This oven has been fitted with a cooling fan to achieve maximum
eciency and to maintain low surface temperatures. The cooling fan
will switch on automatically when the oven switches on. It is normal
for the cooling fan to run for an hour or more after use, depending on
the duration, temperature and type of cooking programme used.
•The oven light remains on for every cooking function.
•Do not switch o the oven if you have set a programme for
semi-automatic or automatic cooking as this will cancel the
programme.
•We recommend preheating the grill for 5 minutes before each use.

7
Control panel
A: On/O sensor F: Function selection sensor
B: Function down sensor G: Clock/Timer sensor
C: Function up sensor H: Safety key lock sensor
D: Oven light sensor I: Confirm/Pause sensor
E: Temperature/microwave power selection sensor
Fig. 1
A B C D E F G H I
Prompt area Function display
Time displayTemperature display
Safety key lock
Time
Oven light
Timer
Cooking time
End of
cooking time
Fig. 2

8
Using the touch controls
The touch controls should be used with the flat of your finger, rather
than the fingertip.
Switching the appliance on and o
To switch the appliance on
Touch and hold the ‘On/O’ sensor for approximately 3 seconds
and until the appliance beeps. The steam function indicator on the
display will illuminate as well as the temperature display.
To switch the appliance o
Touch and hold the “On/O” sensor for approximately 3 seconds
and until the oven beeps. All displays except for the time display
should extinguish.
Please note: To switch the appliance o completely, i.e. before
cleaning it, you will need to switch it o at the mains isolation switch.
Fig. 3

9
Setting the clock
Upon first switching on the mains supply to the appliance the clock
will show 0.00. To set the time, simply press the clock/timer sensor
(G) so that the clock symbol in the time display flashes. Then, use the
function up sensor (C) and the function down sensor (B) to set the
time appropriately. Wait 5 seconds or press the confirm/pause sensor
(I) to confirm. The oven must be in standby mode to adjust the time.
Setting the minute minder
Before starting a function, touch the clock/timer sensor (G) until the
timer symbol ( ) flashes. Then, use the function up sensor (C) and the
function down sensor (B) to set the desired time. Press the confirm/
pause sensor (I) to confirm the selection and begin counting down.
Please note: Not pressing the confirm/pause sensor (I) will cancel the
minute minder. Once the time has elapsed and the acoustic signal is
sounding it can be stopped by pressing the on/o sensor (A) or the
clock/timer sensor (G). The following function table indicates which
functions allow for the minute minder to be used.
Selecting a function
A list of functions and their specification is below and on page 10.
Icon Function
Preset
（ ℃）
Time
（ min ）
Adjustable
Microwave power
Microwave
1645W /1900-100W
Microwave
1738W 180 10
1100 W/
1645W / 10
Top grill
1750W 180
Default
2850W
1750W
Defrost
2850W
Power temperature
Preset
and grill
rear element
Microwave
（ W ）
800
400
400
/
power
1645W/
Microwave +
+ fan
Rear
element+fan
fan
Top grill +
rear element
Top grill +
+fan
1680W
Adjustable
temperature range
/
110-180 °C
/
50-250°C
range
200-600W
180 10400 110-180 °C 200-600W
/
/
180 / 50-250°C /
180 / 50-250°C /
180 / 50-250°C /
Default
Default
Default
Minute minder
YES
YES
YES
YES
NO
NO
NO
NO

10
To select a function and begin cooking
With the appliance on, use the function up sensor (C) or the function
down sensor (B) to select the desired function. The function’s preset
temperature will appear in the temperature display area, if applicable.
If you are ready to begin cooking, press the confirm/pause sensor (I).
To pause a function
Simply press the confirm/pause sensor (I) whilst the appliance is in use.
This will allow you to suspend operation temporarily. To resume the
function, simply press the confirm/pause sensor (I) once more.
Whilst the appliance is paused you can adjust the temperature,
where available, without aecting the running time of the function.
Instructions for setting the temperature are on page 11.
To change a function (including mid-operation)
You can switch functions (including whilst a function is paused) by
pressing and holding the function selection sensor (F) for 5 seconds.
Choose a new function and press the confirm/pause sensor (I).
Icon Function
Preset
（ ℃）
Time
（min ）
Adjustable
Microwave power
Microwave 1645W /1900-100W
Microwave
1738W 180 10
1100 W/
1645W / 10
Top grill 1750W 180 Default
2850W
1750W
Defrost
2850W
Power temperature
Preset
and grill
rear element
Microwave
（W）
800
400
400
/
power
1645W/
Microwave +
+ fan
Rear
element+fan
fan
Top grill +
rear element
Top grill +
+fan
1680W
Adjustable
temperature range
/
110-180 °C
/
50-250°C
range
200-600W
180 10400 110-180 °C 200-600W
/
/
180 / 50-250°C /
180 / 50-250°C /
180 / 50-250°C /
Default
Default
Default
Minute minder
YES
YES
YES
YES
NO
NO
NO
NO

11
To stop a function
Simply press and hold the on/o sensor (A) for approximately 2
seconds.
To adjust the temperature on a function
A function’s preset temperature will appear in the temperature display
area, if applicable (see function table on pages 9-10). To adjust the
temperature, follow the steps below:
•Press the temperature selection sensor (E) whilst the function
symbol is flashing. The ‘°C’ after the temperature should flash to
indicate that temperature adjustment is available.
•Next, use the function up sensor (C) or the function down sensor
(B) to set the required temperature.
•When you are ready to begin cooking, press the confirm/pause
sensor (I).
To adjust the microwave power level
A function involving the microwave setting will have pre-set
power levels for the microwave. This can be adjusted to suit your
requirements with the exception of the defrost function by following
the steps below:
•Select a function, if required, that uses the microwave setting (see
function table on pages 9-10).
•Next, press the temperature/microwave power selection sensor
(E). The microwave power symbol ( ) in the prompt area should
flash.
•Use the function up sensor (C) or the function down sensor (B) to
set the required microwave power level.
•If you are ready to begin cooking, press the confirm/pause sensor
(I).

12
Semi-automatic cooking
This function allows for a cooking time to be set. When the set time
elapses, the oven will switch the set function o and an acoustic
signal will sound to alert the user.
To switch on semi-automatic cooking
•Switch the appliance on, if not already so. Select the desired
function, but do not start it.
•Next, press the clock/timer sensor (G) until the cooking time
symbol ( ) is flashing. The time display should show ‘0.00’.
•Use the function up sensor (C) and the function down sensor (B) to
set the desired length of cooking time. When the desired amount
is set, press the confirm/pause sensor (I).
The set time will now be saved and the function will deactivate after
it. The cooking time symbol ( ) and the temperature display will
flash and an acoustic signal will sound. To cancel the signal and
stop the flashing displays, press the on/o sensor (A) and the clock/
timer sensor (G) simultaneously. They will stop automatically after 30
seconds.
To switch o semi-automatic cooking
•Press the confirm/pause sensor (I). Then press the clock/timer
sensor (G) until the cooking time symbol ( ) is flashing.
•Return the time to ‘0.00’ using the function down sensor (B).
Press the confirm/pause sensor once this has been done. This is
not available on all functions (i.e. those that have a fixed, or no,
cooking time).

13
Automatic cooking
This function allows for a duration and an end time to be set for
cooking. With this, the oven will start cooking automatically due to
the set duration determining how long before the end time that the
function will activate and begin cooking. For example, if you set the
cooking duration to 1 hour, and the end time to 15:30, then the oven
will activate the function at 14:30. When the set time elapses, the oven
will switch the set function o and an acoustic signal will sound.
To switch on automatic cooking
•Switch the appliance on, if not already so.
•Set the cooking time as per the section ‘Semi-automatic cooking’,
but do not press the confirm/pause sensor (I). Next, press the
clock/timer sensor (G) until the end of cooking time symbol ( ) is
flashing.
•Use the function up sensor (C) and the function down sensor (B) to
set the desired end time. When the desired time is set, press the
confirm/pause sensor (I). The time remaining until cooking starts
will show on the time display.
When the set end time has been reached the end of cooking
time symbol ( ) and the temperature display will flash and an
acoustic signal will sound. To cancel the signal and stop the flashing
displays, press the on/o sensor (A) and the clock/timer sensor (G)
simultaneously. They will stop automatically after 30 seconds.
To switch o automatic cooking
•Press the clock/timer sensor (G) three times or until the end of
cooking time symbol ( ) is flashing.

14
•Return the time to ‘0.00’ using the function down sensor (B). Press
the confirm/pause sensor (I) once this has been done.
Please note: The cooking time can be set between 0 and 10 hours.
The end of cooking time can be set to 24 hours ahead of the current
time minus the cooking time. If an end of cooking time is set, then this
will take priority, for example over the current time, on the time display.
We recommend that you supervise the first few cooks to ensure
that the length of the functions and their temperatures suit your
requirements. Like this, you can make any necessary adjustments for
future functions.
Safety key lock
This appliance is equipped with a safety key lock to prevent
accidental use. The safety key lock can be activated when the
appliance is in standby mode (i.e. just the clock displayed) or whilst a
function is running.
To activate the safety key lock
Simply press and hold the safety key lock sensor (H) for approximately
5 seconds. The prompt area (fig. 2) will display a padlock symbol. All
sensors will now be temporarily disabled. Any touch of the sensors,
other than the safety key lock sensor (H) will cause the padlock
symbol to flash as a reminder that the control panel is locked.
To deactivate the safety key lock
Simply press and hold the safety key lock sensor (H) for approximately

15
5 seconds. The padlock symbol in the prompt area should extinguish
and the control panel will now be unlocked.
Interior lighting
The interior lighting will come on automatically when the oven is in
use but can be turned on and o as you so wish. The light will also
turn on after opening the oven door. The light can be turned on when
the oven is in standby without a function in operation. Simply press
the oven light sensor (D) to operate the light as necessary. The light
bulb symbol in the prompt area (fig. 2) will illuminate to indicate when
the interior light is on.
Please note: The light will always be on when the defrost function is
active due to it being used to provide gentle heat.
The light can not be operated whilst the safety key lock is active.
Operating time limiter
Each temperature, when used outside of semi and automatic cooking,
has an operating time limiter to help to prevent damage to the internal
components of this appliance. After a certain working time at given
temperatures the appliance with switch the function o automatically.
The temperatures and associated maximum operating times are listed
in the table below.
Maximum operating hoursTemperature
20-120 °C
121-200 °C
201-250 °C
24
6
4

16
Please note: The cooking time can be set between 0 and 10 hours.
The end of cooking time can be set to 10 hours ahead of the current
time. If an end of cooking time is set, then this will take priority, for
example over the current time, on the time display.
We recommend that you supervise the first few cooks to ensure
that the length of the functions and their temperatures suit your
requirements. Like this, you can make any necessary adjustments for
future functions.
Care and maintenance
It is important, before carrying out any cleaning or maintenance,
that you disconnect or switch o the appliance at the power
supply. If the oven has been in use, let the cavity and any
elements cool down suciently before attempting any cleaning or
maintenance.
Removing the appliance door
In order to allow for easier access into the oven cavity for cleaning, it
is possible to remove the door. Before removing the door, ensure that
you have an area prepared in which you can place the removed door.
This area should ideally be protected by something like a folded, dirt-
free, towel to help prevent damage to surfaces and the door.
•Open the door fully
•Lift and tilt the safety catch part of the hinge (fig.5) so that it is fully
extended and points towards the door.
•Close the door most of the way, lift it slightly and then pull it, safely

17
but firmly, towards you.
Replacing the appliance door
•Hold the door to the appliance in
the closed position and manoeuvre
the hinges so that the part of the
hinge, highlighted by the star in fig.
6, inserts into the hinge slot in the
cavity frame.
•Next, ensure the notch on the
underside of the hinge sits on the
lip of the hinge slot. Open the door
fully. Each hinge should be seated
in the same way as the hinge in
fig. 7. If it is not, follow the steps for
removing the door and try replacing
it again.
•Finally, lift the safety catch part
of the hinges back into place so
that they are lying flat against the
hinges.
Please note: If the hinge safety catches
are not in the correct place then the
door and/or appliance may receive
damage when attempting to close the
door.
Fig. 5
Fig. 6
Fig. 7

18
Interior lighting
If the bulb in your appliance should fail, please contact CDA Customer
Care to arrange a service visit. The bulb and appliance must not be
serviced by anyone except a CDA authorised service agent.
Cleaning
IMPORTANT
•Before any maintenance is started involving electrical parts,
the appliance must be disconnected from the power supply.
•If the oven has been in use, let the oven cavity and the heating
elements cool down before attempting any maintenance.
•Steam cleaners must not be used when cleaning this appliance.
•Once care and maintenance is complete, ensure that all parts
are correctly replaced before using the oven.
•Do not store flammable material in the oven.
•Do not allow grease or food particles to build up around the
door.
The oven exterior
As the oven has a stainless steel or enamel surface, you should use a
nonabrasive cleaner. Any abrasive cleaner (including Cif) will scratch
the surface and could erase the control panel markings.
Inside of Oven
It is recommended that the interior of the oven be cleaned after
every use using suitable products, especially if any spillage has
occurred. The shelves can be removed and washed by hand or in the
dishwasher.

19
Stainless steel
Stainless steel can be eectively cleaned by simply using a dilute
solution of water and mild detergent and drying to a shine with a
clean cloth. Proprietary stainless steel cleaners are available. We
recommend a clean microfibre cloth for cleaning stainless steel
surfaces.
Grill
When used regularly, the grill element does not need cleaning as the
intense heat will burn o any splashes. The interior ceiling may need
regular cleaning, which should be done with warm water, detergent
and a sponge. If the grill is not used regularly, it should be run for 10
minutes every month to burn o any splashes, in order to reduce the
risk of fire.
IMPORTANT:
When correctly installed, your product meets all safety
requirements laid down for this type of product. However, special
care should be taken around the rear or the underneath of the
appliance as these areas are not designed or intended to be
touched and may contain sharp or rough edges that could cause
injury.

20
Installation
The appliance can be installed under a worktop or in a wall unit (open
or closed) with the appropriate dimensions for recessed installation.
Centre the oven in the unit, ensuring that there is as much of a gap
as possible, for ventilation purposes, between the appliance and the
surrounding unit. The material of the unit supporting the appliance
must be heat resistant (or covered with a heat resistant material). For
greater stability, attach the oven to the unit with four screws through
the holes provided on the side panels.
If the appliance is to be installed under a worktop, ensure the top rail
has been removed to provide free airflow around the product.
Do not use your appliance immediately after moving it from a
cold location, as condensation may cause a malfunction. Wait
approximately 1-2 hours before use.
Installation diagrams are on page 21.
