CDVI RSIP Assembly instructions

The installer’s choice
cdvigroup.com
ENGLISH
EN
RSIP
RS-232 to TCP/IP
Converter

2
cdvigroup.com
EN
RSIP
RS-232 to TCP/IP Converter
INSTALLATION MANUAL
EN
RSIP
RS-232 to TCP/IP Converter
INSTALLATION MANUAL
RSIP is a sleek and compact Serial-to-Ethernet device server,
providing quick and easy Ethernet connectivity to virtually any
device or machine with a serial interface.
Ethernet Interface
• Interface: 10Base-T /100Base-T (Auto-sensing)
• Speed: 10/100 Mbps
• Connector: RJ45
• Protocols: UDP, TCP, ARP, Telnet, ICMP, SNMP, DHCP,
BOOTP, TFTP, Auto IP, HTTP, Telnet Com Port Control
Serial Interface
• Baud Rate: 300bps to 921.6 Kbps
• Characters: 7 or 8 data bits
• Stop Bits: 1 or 2
• Parity: Odd, even, more
• Modem Control Signals: DTR, DSR/DCD
• Flow Control: XON/XOFF (software), CTS/RTS (hardware)
Serial Connectors
• Single-port: DB9F (DCE Pinned)
LED Indicators
• Power/Status, Link, Activity, Serial RX Activity & TX Activity
Power Requirements
• Input Voltage: 5V at mini-USB-B jack
• Input Voltage: 5-15 VDC at DB9F pin 9
• Power Consumption: 1.3W max w/o PoE,
2.0W max with PoE
Security
• 128/192/256-bit AES Encryption
• Temperature Range: -40° to 85°C (-40° to 185° F)
CT-V900-A CUT VIEW
LAN/WAN Connection
Red Wire
Black Wire
Set power supply
Jumper to “L”
Set the network
Jumper at “LOW”
and EOL jumper
must be installed
RSIP
RS-232 to
TCP/IP Converter
M L
“B”Type USB port
Use the provided power cable for
CT-V900-A that do not have power
supply jumper setting.
1] PRODUCT PRESENTATION 2] NOTES AND RECOMMENDATIONS
3] MOUNTING INSTRUCTION
• Emissions
FCC Part 15, Subpart B, Class B
EN55022, Class B
EN61000-3-2, EN61000-3-3
ICES-003 Issue 4
AS/NZS, CISPR22
• Immunity
EN55024, EN61000-4-2, EN6100-4-3, EN61000-4-4,
EN61000-4-5, EN61000-4-6, EN61000-4-8, EN61000-4-11
• Agency Approvals
UL 60950-1, 2nd Edition
CAN/CSA C22.2 No. 60950-1-07,2nd Edition
CE, VCCI, C-Tick
IEC 60950-1 2005, 2nd Edition

3
cdvigroup.com
EN
RSIP
RS-232 to TCP/IP Converter
INSTALLATION MANUAL
EN
RSIP
RS-232 to TCP/IP Converter
INSTALLATION MANUAL
Download from our web site (cdvi.ca/Download_
Center.aspx) and install the "DeviceInstaller"
application.
Once RSIP installed and power up
1. Start the «DeviceInstaller» application.
(Program Files/Lantronix/DeviceInstaller4.4/
DeviceInstaller)
2. Double click on "XDT232"
4] SOFTWARE CONFIGURATION
1. Double click on "Web Conguration"
2. then click on "Home" button.
Windows Security will appear, type default user
name and password
• User name: admin
• Password (All caps): PASS
• Click OK
1. 2.
1.
2.

4
cdvigroup.com
EN
RSIP
RS-232 to TCP/IP Converter
INSTALLATION MANUAL
EN
RSIP
RS-232 to TCP/IP Converter
INSTALLATION MANUAL
1. Click on "Serial Settings" tab
2. Set Baud rate to 19200 (CT-900-A default
setting)
3. Enable "Pack Control" to 12 msec
4. Set Flush Mode ›
Flush Input Buffer ›
With Active Connect put "Yes"
Flush Output Buffer ›
With Active Connect put "Yes"
5. Keep the default setting for the rest
6. Click OK
Click on "Connection" tab
• Keep the default setting
(The port number must be defined in ALL
controllers connected to that RSIP module.
To set the port number in the CTV-900-A
controller, go to the controller properties
window, tab «configuration» (by default is
1001, see diagram below).
1. 2.
3.
4.
CTV-900-A
Controller properties window

5
cdvigroup.com
EN
RSIP
RS-232 to TCP/IP Converter
INSTALLATION MANUAL
EN
RSIP
RS-232 to TCP/IP Converter
INSTALLATION MANUAL
1. Click on "Network" tab
Define IP configuration
(The IP address must be defined in ALL
controllers connected to that RSIP module.
To set the IP address in the CTV-900-A
controller, go to the controller properties
window, tab «configuration» (see diagram
below).
2.
3. To set the IP address in the CTV-900-A
controller, go into the properties of the
controller and the «configuration» tab.
4. Click "Apply Setting"
You are done.
1.
2.
3.
CTV-900-A
Controller properties window

6
cdvigroup.com
EN
RSIP
RS-232 to TCP/IP Converter
INSTALLATION MANUAL
EN
RSIP
RS-232 to TCP/IP Converter
INSTALLATION MANUAL
5] WARRANTY - TERMS & CONDITIONS
The “5 Year Warranty” is offered by CDVI exclusively for CDVI products featuring the logo “5 Year Warranty”, and supplied by
authorized CDVI dealers participating in the offer. You can obtain the address of the local authorized dealer participating in the offer by
contacting CDVI or a local CDVI subsidiary. The “5 Year Warranty” is only applicable to hidden defects detected during the lifetime of
the product, as dened by the CDVI Group (5 years or 200 000 operations - whichever of the two expires rst).
The “5 Year Warranty” conditions shall not modify the sales conditions between CDVI and its customers.
DURATION OF THE OFFER:
• This offer is valid from July 1st 2010; CDVI reserves the right to terminate this offer without prior notice.
• However, any product already registered up to the date of withdrawal of the offer will remain eligible for the
“5 Year Warranty”.
• The warranty applies only to the available products mentioned in the above statement.
CONDITIONS :
• Hidden defects are guaranteed for an unlimited shelf life (period of time before use).
• To be eligible for the “5 Year Warranty”, the product must be registered at CDVI within one month of its
delivery to the end user, by completing in and returning back the “warranty” form by fax, email or post to
the local CDVI subsidiary. This information may also be registered on line at www.cdvigroup.com.
• Only the issue of the “5 Year Warranty” certicate by CDVI can conrm product registration; CDVI may not
be held responsible in the event of loss or non-presentation of the form.
• The “5 Year Warranty” only applies to products installed by a skilled and experienced personal with the
necessary trade qualications to install according to the highest standards, respecting the standards,
instructions and guidelines dened by CDVI and according to the maximum recommended specications.
• To enable CDVI to determine whether a product is eligible to claim for the “5 Year Warranty”, after prior
issue of a return of materials authorization number (RMA) by CDVI, the customer must return the product
and all of its accessories in the original packaging with a copy of its invoice. The transport fees shall be paid
by the customer and the package must be returned to CDVI or to a CDVI authorized repair centre.
• Eligibility for the “5 Year Warranty” cover must be conrmed by CDVI.
• The “5 Year Warranty” only covers the replacement or repair of the parts acknowledged as faulty by CDVI.
• CDVI reserves the right to respect its obligation by replacing the product or the parts acknowledged as faulty
by a standard part replacement or by a product or new parts, or by an updated or improved version of the
product with identical or similar functionalities.
• In respect of the applicable law, CDVI cannot be held responsible for material or immaterial damages caused
to goods or to third parties and as a direct or indirect result of the installation, utilization, product faults or
poor functioning of a device.
• The “5 Year Warranty” is non-assignable and non-transferrable; only the person who registered the
aforementioned warranty may benet from the warranty.
• The “5 Year Warranty” is limited to the eligible product and is strictly limited to the conditions in effect on
the date of purchase by the customer.

7
cdvigroup.com
EN
RSIP
RS-232 to TCP/IP Converter
INSTALLATION MANUAL
EN
RSIP
RS-232 to TCP/IP Converter
INSTALLATION MANUAL
NOT COVERED BY THE “5 YEAR WARRANTY”:
• Any product which has undergone even the slightest modication or change;
• Any product which has been installed and/or used with any auxiliary device not supplied by CDVI;
• Any product which has been used for demonstrations or display;
• Any product or its elements considered as “consumables” such as fuses, lights and batteries for example;
• Failure or malfunctioning as a result of an accident, poor storage conditions, unsuitable assembly, bad
utilization or handling, poor maintenance, unsuitable repair or intervention.
• Any call-out and installation fees (for assembly and dismantling) as well as transport costs (to and from the
repair centre) and maintenance fees.
THE INSTALLER’S RESPONSIBILITIES:
When registering the 5 Year Warranty on line, the installer is responsible for the information supplied. In case of errors, the 5 Year
Warranty will not be applicable.
NOTES:
