CE-Link HCD0101 User manual

DVI+Audio to HDMI Converter
USER MANUAL
T e c h n i c a l S u p p o r t :

DVI+Audio to HDMI Converter
1
Table of Contents
1.0 Introduction . . . ... . . . . 2
2.0 Specifications ... 3
3.0 Package Contents ...4
4.0 Panel Descriptions ..4
5.0 Conection Diagram..............................................................5
6.0 Troubleshooting ..5
7.0 Limited Warranty .....6

DVI+Audio to HDMI Converter
2
DVI + Audio to HDMI Converter
Mo d e l N o : HCD0101
DearCustomer
Thanks for your purchase of the DVI Audio to HDMI Converter from CE-LINK. For
optimum performance and safety, please read these instructions carefully before
connecting,operatingoradjustingthisproduct.Pleasekeepthismanualforfuture
reference.
1.0 INTRODUCTION
The CE-LINK s converter is designed to make your A/V equipment use more
comfortable, more productive and less expensive.Itconverts a digitalDVI signal
and toslink audio and digital audio input to an HDMI format allowing the viewing or
switchingofadigitalAVsignalonanHDMIsystem.
The DVI+Audio to HDMI Converter is an unique device that combines digital video
(DVI) and digital audio into HDMI to seamlessly integrate into the modern home
theaters. This product not only meets the ideal image of the HDTV but also
meets t h e n ee d o f the e n th us ias ts requirementforaudio. BecauseIttransmits
theaudiosignalbytoslinkaudioanddigitalaudio.
ThisDVI+Audi oto HDMI Converter offer solutionsfor noise,sp a ce and se curi ty
concerns,datacentercontrol,information-distribution,conference-room
presentation, school and corporate training environments.
1.1 LIABILITY STATEMENT
Every effort has been made to ensure that this product is free of defects. China
Electronics Technology Limited cannot be held liable for the use of this hardware
or any direct or indirect consequential damages arising from its use. It is the
responsibility of the user of the hardware to check that it is suitable for his/her
requirements and that it is installed correctly. All rights reserved.No parts of this
manu al ma y b e r e pr odu c ed o r t ran s mitt ed b y a n y f o r m o r m ean s e le c t ro n ic o r
mec h anic a l, inc lu d i ng p ho toc opyi ng , re c ordin g o r b y a n y i nfo rmat io n s t orag e o r
retrieval system without the written consent of the publisher.
China Electronics Technology Limited reserves the right to revise any of its
hardware and software following its policy to modify and/or improve its products
where necessary or desirable. This statement does not affect the legal rights of
theuserinanyway.
Allthird party trademarks and copyrights are recognized.The CE-LINK logo is the
registered trademarks of China Electronics Technology Limited.

DVI+Audio to HDMI Converter
3
1.2 FEATURES
The series of the Converter have many features that enable them to perform in a
superiormanner.Amongthosefeaturesyouwillfind:
lSupports HDCP
lHDMI compliant
lToslink Audio and Digital Audio input/output
lSupports HDTV resolutions
lEasy to Use: Install in seconds, no need of setting.
lSupports resolutions up to 1080p, 2K, and 1920 x 1200
lEncodes digital audio onto the video signal for HDMI™v i d e o a n d a u d io
lAllows you to connect computers or other sources with DVI output and SPDIF
to an HDMI display
2.0 SPECIFICATIONS
Signal Inputs/Output
InputVideoSignal 1.2 volts p-p
InputDDCSignal 5 volts p-p (TTL)
Output Video HDMI+HDCP1.0/1.1
Video format supported
VGA 640x480,800x600,1024x768,1920x1200
DTV/HDTV 480i/576i/480p/576p/720p/1080i/1080P
Connector
HDMI Connector type A (19 pin) female
DVI Connector DVI-I (29 pin) female (digital only)
AudioConnector T o s l i n k A u d i o a n d D i g i t a l A u d i o
Operating Frequency
Frequency Up to165MHz
Resolutions(HDTV)
Interlaced(50&60Hz) 480i,576i,1080i
Progressive(50&60Hz) 480p,576p,720p,1080p
Mechanical
Size(W-H-D) 5"W x 1"H x 4"D
Weightforshipping 2 lbs
Warranty
Limited Warranty 1 Year Parts and Labor
Environmental
Operating Temperature 0 to +70
Operating Humidity 10% to 85 % RH (no condensation)
Storage Temperature - 1 0 to +80
Storage Humidity 5% to 90 % RH (no condensation)
Power Requirement
ExternalPowerSupply 5V DC@2A
Power Consumption 5 watts (max)

DVI+Audio to HDMI Converter
4
Regulatory Approvals
Converter Unit FCC,CE,UL
PowerSupply UL,CE,FCC
Accessories Adapter
ACPower Adapter US standard, UK standard and so on
User Manual English Version
Note: Specifications are subject to change without notice.
3.0 PACKAGE CONTENTS
Beforeattemptingtousethisunit,pleasecheckthepackagingandmakesurethe
followingitems arecontainedintheshippingcarton:
1) Main unit (different models have different P/N).
2) 5V DC Power Supply.
3) User sManual.
Note: Please retain the original packing material in the case of needing to
return the unit. If you find any items are missing, contact China Electronics
Technology Limited immediately. Please have the model number,serial
number and invoice available for reference when you call.
4.0 PANEL DESCRIPTIONS
Pleasestudythe paneldrawings below and become familiarwith the signal
in pu t( s ), o ut p ut (s ) a n d p owe r re q ui re me n t s.
5.0 CONNECT AND OPERATE
Before installation, please make sure alldevices you wish toconnect have been

DVI+Audio to HDMI Converter
5
turnedoff.
1) Connect the AC adapter to the Converter spowerinput(Donotplugthe
adapter into an AC outlet yet).
2) Connect the appropriate cables to the source device and then the converter.
3) Connect the output cables to the Converter and then to the destination device.
4) Plug the Power Adapter into a working AC outlet.
5) Power on all input and output devices.
6)The DVI-HDCP input signal should now be available to all devices connected to
the device outputs.
Attention: Insert / Extract cable gently.
5.1 CONNECTION DIAGRAM
6.0 Non-HDCP Compliant Devices
If a DVI device does not appear to work, make certain that the device is HDCP
compliant. Anon-HDCPcompliantDVI devicewillnot work with a signalthat has
HDCP encoding present.
6.1 Cable Length
Ifyouneedtospanadistanceofgreaterthan3mtoreachtheconverter,purchase
CE-LINK sRepeaterwhichwillallowyoutoextendacablerunupto40musing
premium cable.
7.0 LIMITED WARRANTY
ShouldanyconsumerproductfromChina Electronics TechnologyLimited faildue
to defects in materials or workmanship within one year from the date of the
original sale to the end-user, China Electronics Technology Limited guarantees

DVI+Audio to HDMI Converter
6
that we will replace the defective product at no cost.Freight charges for the
replacement unit will be paid by the customers. A copy of the invoice showing the
ite m n u m ber a n d d at e o f p u rc h as e ( pr oo f- of -p u rc h as e ) m us t b e s u b mit t e d w it h t he
defective unit to constitute a valid in-warranty claim.
Units that fail after the warranty period has expired may be returned to the factory
for repair at a nominal charge, if not damaged beyond the point of repair. All
freight charges for out-of-warranty returns for repair are the responsibility of the
customer.Units returned for repair must have a Return Authorization Number
assigned by the factory.
This is a limited warranty and is not applicable for products which,in our opinion,
have been damaged, altered, abused, misused, or improperly installed. China
Electronics Technology Limited makes no other warranties either expressed or
implied, including limitation warranties as to merchantability or fitness for a
particular purpose. Additionally, there are no allowances or credits available for
serviceworkorinstallationperformedinthefieldbytheenduser.
Notice
China Electronics Technology Limited reserves the right to make changes in the
hardware, packaging and any accompanying documentation without prior written
notice.
