Cellink ANT465 User manual

INSTALLATION GUIDE
ANT465 15 ELEMENT
YAGI ANTENNA NEXT G
NOTE: cable must be kept clear of the reflector.
NOTE: Drain Hole must be on this side.
NOTE: These connectors must be covered with a waterproofing substance.
1/ Taking note of the antenna drain hole - slide the antenna Ubolts over the vertical boom
and tighten the nuts.
2/ Attach the feed cable (not supplied) to the antenna and run it down to the equipment.
Secure the cable to the vertical boom with cable ties (not supplied).
3/ Fit mating connector to the feed cable and attach test equipment. Check for a suitable
signal level.
If the signal level is unsatisfactory - loosen the angle adjustment screw on the angle
bracket and adjust the antenna angle for the best signal.
4/ Replace the angle adjustment screws and lock the antenna angle into place.
5/ Seal the connector union with a waterproofing compound. Vertical Mounting Boom
Ubolts
Waterproofing on connectors
NOTE: Cable must be kept in
close to the boom and clear of
the antenna elements.
Angle
adjustment
screw
20.0°
Email: [email protected]
Phone: [phone] Fax: [phone] Web: www.cellink.com.au
ANT465

-30
-25
-20
-15
-10
-5
0
5
010 20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
250
260
270
280
290
300
310
320
330
340 350
ANT465
15 ELEMENT YAGI NEXT G
ANT 465 Yagi is designed for use in a Next G fixed site installation for
Wireless Voice / Broadband Data Access.
The antenna offers 15 dBi of gain across the band 824-894 MHz.
It comes angle adjustment bracket allowing +/-20 degrees of angle
adjustment in the Vertical plane. The bracket suits up to 50mm
mounting tube.
Electrical
Frequency:
Gain (dSi):
824-894 MHz
15
Mechanical
Construction: Welded Aluminium consrtuction.
Grey powder coated.
Tuned Bandwth:
Operating VSWR:
Input lmp:
Vertical Beamwth:
Horizontal Beamwth:
FJB Ratio:
• Reflector length.
Horizontal
71 MHz
<1.5:1
50 ohms (Nominal)
32 '
32'
18 dB
Length (m):
'Width (m):
Weight (kg):
Termination:
Projected Area.
Wind loading @160 KPH;
Mounting:
1.156
0.18
0.6
Cable tail with N-Type
Female Receptacle.
0.05008 SQM
6.08 KG
Angle Bracket suits
25-50mm T u bing
VerticalMHZ
20.0'
"
780 790 800 810 820 830 840 850 860 870 880 890 900 910
1.1
1.0
1.2
1.3
1.4
1.5
Email: [email protected]
Phone: [phone] Fax: [phone] Web: www.cellink.com.au
-30
-20
-15
-10
-5
0
010 20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
250
260
270
280
290
300
310
320
330
340 350
-25
5
