Cellinx CamPilot URH350A-5M User manual

1
IP 5MP Dome Camera
CamPilot URH350A-5M
User Manual
CamPilot URH350A
Screw, Anchor
- An adaptor and a LAN cable are not included in the product.
Wrench
(Disassembling ans
assembling camera)
1/1.8" Sony IMX178 sensor (ExmorR, STARVIS)
4.5mm Fixed Lens
Day & Night (ICR) / WDR / DNR
IR LED (12 EA)
5MP resolution at 30 FPS
Multi-codec support : H.265 / H.264 / MJPEG
Multi-stream with variable resolution & frame
1st stream : H.265 or H.264 or MJPEG @ 5MP~VGA
2nd stream : H.265 or H.264 or MJPEG @ D1~CIF
Stream based motion detection
Multi-codec audio support : G.711
Two-way audio supported (Full Duplex)
Alarm Input (1ch) / Output (1ch)
micro SD / SDHC card support
Power : DC 12V / PoE (IEEE802.3af)
Mount
Plate
Template
(for plate)
Mount
Bolts and Nuts
Template
(for bolts and nuts)
Before installing and using the product,
please read this manual carefully.
Be sure to keep it handy for later reference.
Overview
Accessories

2
Precaution
WARNING
TO PREVENT THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTIONS
■ Do not modify
Do not modify the case, as it may be dangerous and cause damages.
■Do not put objects inside the unit
Make sure that no metal objects or flammable substances get inside the camera. It could cause
fire, short-circuits or damages.
■ Be careful when handling the unit.
To prevent damage, do not drop the camera or subject it to strong shock or vibration.
■ Install away from electric or magnetic fields.
■ Protect from humidity, dust and high temperature.
An additional case that is temperature-controllable, damp-proof and waterproof is required for
outdoor use.
■ Cleaning
Dirt can be removed from the case only by wiping it with a soft cloth moistened with a soft
detergent solution.
■ Mounting Surface
The mounting surface material must be strong enough to support the camera.
■ CamPilot URH350A can be used for surveillance purpose.
Be thoroughly informed of related regulations prior to installation to ensure compliance with such
regulations

3
Overview
Features and Appearances
URH350A is an IP camera that transmits real-time high-resolution digital video and
audio data with H.265 high compression rate over Internet or Intranet.
Top view
Side view

4
Overview
▌Image Sensor & Optical Functions
Image Sensor
Image Sensor Size
Resolutions
Effective Pixels
S/NRatio
Shutter Speed
Function
Lens
IRLED
▌Video & Audio
Compression Type H.265 or H.264 or MJPEG
2592x1944 / 2048x1536 / 1080p / 720p / 1024x576 /
640x360 / D1 / 4CIF / VGA / CIF / QVGA / QCIF
Bitrate 32Kbps ~ 10Mbps
Frame Rate 30FPS @ 2592x1944
Streaming H.265 DualStreamor Simultaneous H.265 / H.264 / MJPEG
Bi-Directional Audio Tw o way (Full duplex)
Compression Type G.711
Audio Input Line level input. Nominal input level is 1.0 VRMS.
Audio Output Line level output. Nominal output level 1.0 VRMS.
▌External I/O
AlarmInput
AlarmOutput
Local Storage
Factory Default Button
▌Network
Ethernet
Protocol
▌Software
OS
Web Browser
SDK
Security
▌General
Operating Temperature
Power Requirement
Camera Adjust
Weight
Material
▌Cable A & B
A Type
B Type
Sony IMX178 (ExmorR, Starvis)
1/1.8 inch 6.44M(effective format 1/2 inch 5M)
5M@ 30fps
2592 (H) × 1944 (V) Approx. 5Mpixels
Application Protocol
TCP, UDP, IP, HTTP, DHCP, DNS, ICMP, ARP, IPv4 / IPv6
DDNS, NTP, SNMP, Syslog, UPnP, Bonjure, ZeroConf
RTP/RTSP, Onvif, Genetec Protocol
4.5mmFixed Lens
12EA
Min. Illumination
Video
Resolutions
Audio
Color : 1.0 lux
B/W : 0.5 lux
more than 50dB (AGCoff)
1/30(25) ~ 1/60,000sec
TDN/ DNR/ WDR
1ch. Dry Contact
1ch. Relay Output
Micro SD/ SDHCCard support up to 64 GB
Restore to default setting (Network, Password and etc)
10/100 Based-T, RJ-45 Connector
0.5 kg
Embedded OS (Linux)
AluminumDie-casting (IP66)
Ethernet. DC12V Jack
Ethernet. DC12V Jack. Audio In/Out. AlarmIn/Out
IE8.0 or above
Onvif, Genetec Protocol, Cellinx SDK 4.0
MD5 Password / iptables (firewall)
-10°C~ 55°C/ 14°F ~ 131°F
DC12V / PoE(IEEE802.3af)
3 Axis

5
Connection
1. Mounting and Assembling
•Mount and assemble in one of three ways below.
Fig.1. Mounting directly
on the fixed side
Fig.2. Using the mount plate
Fig.3. Using the mount bolts & nuts
Adjusting the direction of camera
(Rotating the 3-axis gimbal)

6
Internet
or
Intranet
Connection
2. Connectors
• Power: DC12V 1 A (or above) adaptor (Ø 5.5x2.1 jack)
- If a PoE network device( by IEE802.3af) is used, it is not necessary to connect the power.
• Network: connect to a switching hub (RJ45 connector)
3. IP address setup
•Refer to p.7~8 (Network)
Hub
Connection Configuration
Monitoring PC
Local Network
External Network
LAN Cable
Router
CamPilot URH350A
CamPilot URH350A
CamPilot URH350A
Network
Power
Power
Power
Power
Monitoring PC

7
Network
Setting an IP address
Change the network setting value with the program “NVTManagement”
1. NVTManagement execution
• Execute the file “NVTManagement.exe”
2. IP address setup
• Click the button “NVT Scan”, select the model.
• Input the IP address, Subnet Mask, Gateway and DNS Server IP address, click the button
“Apply”
• If you don’t have a proper IP address, ask the network administrator.

8
Network
3. Accessing to CamPilot URH350A with a web browser
Open a web browser on a monitoring PC and enter the IP address assigned to a CamPilot
URH350A as following
Example> http://192.168.1.2
• The page as below shows up after the connection is completed.
ID / Password :
root / pass (Initial Value)
Login button :
it enables you to move to the Web
Monitoring Page. On checking the
Setting box and clicking the button,
you can move to the Web Setting
Page.
Guest Login :
you can move to the Web
Monitoring Page as “guest”
Refer to the document “URH350A_Web_Manual.pdf” for the Web server.
▶The Initial Page
▶Web Monitoring Page
