Central Pneumatic 95030 Installation manual

3” PNEUMATIC
POLISHER KIT
Model 95030
SET UP AND OPERATING INSTRUCTIONS
Diagrams within this manual may not be drawn proportionally.
Due to continuing improvements, actual product may differ slightly from the product described herein.
Distributed exclusively by Harbor Freight Tools®.
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Copyright©2006 by Harbor Freight Tools®. All rights reserved. No portion of this
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
Revised 11h

SKU 95030 For technical questions, please call 1-800-444-3353. PAGE 2
PRODUCT SPECIFICATIONS
Operating Air Pressure 90 PSI
Air Consumption 3.1 CFM @ 90 PSI
Free Speed 2,000 RPM
Air Inlet Size 1/4”- 18 NPT
Recommended Air Hose Diameter 3/8” @ 90 PSI
Disc Attachment Type Hook & Loop
Required Air Inlet Screen 20-Mesh (Included)
Additional Features Rear Air Exhaust
Accessories Open End Wrench (Qty. 1)
Foam Pad (Qty. 2)
Bufng Pad (Qty. 1)
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures, parts list and assembly
diagram. Keep your invoice with this manual. Write the invoice number on the inside
of the front cover. Keep this manual and invoice in a safe and dry place for future refer-
ence.
UNPACKING
When unpacking, check to make sure that all the parts and accessories listed on
page 9 are included, and the product is intact and undamaged. If any parts are miss-
ing or broken, please call Harbor Freight Tools at the number shown on the cover of this
manual as soon as possible.
SAFETY WARNINGS AND PRECAUTIONS
WARNING! Use eye and hearing protection.1. Always wear ANSI-approved
safety impact glasses and full face shield when using this Polisher Kit. Also,
wear ANSI approved hearing protection. Other people in the work area must
also wear appropriate ANSI approved safety equipment.
Keep work area clean.2. Cluttered areas invite accidents.
Stay within air pressure capacity.3. Never operate the Polisher Kit above 90
PSI.
Observe work area conditions.4. Keep work area well lit. Do not use pneumatic
tools in the presence of ammable gases or liquids.
Keep children away.5. Children must never be allowed in the work area. Do not
let them handle machines, tools, extension cords, or air hoses.
Store idle equipment.6. When not in use, tools must be stored in a dry location to
inhibit rust. Always lock up tools and keep out of reach of children.

SKU 95030 For technical questions, please call 1-800-444-3353. PAGE 3
Use the right tool for the job.7. Do not attempt to force a small tool or attach-
ment to do the work of a larger industrial tool. There are certain applications for
which this tool was designed. It will do the job better and more safely at the rate
for which it was intended. Do not modify this tool, and do not use this tool for a
purpose for which it was not intended. Only use the included Foam and Bufng
pads with this Polisher. Never use sanding or grinding accessories.
Dress properly.8. Do not wear loose clothing or jewelry as they can be caught in
moving parts. Protective, electrically non-conductive clothes and non-skid foot-
wear are recommended when working. Wear restrictive hair covering to contain
long hair.
Do not overreach.9. Keep proper footing and balance at all times. Do not reach
over or across running tools or air hoses.
Disconnect air hose and release any built-up air pressure.10. Never service
the Polisher Kit or disassemble with the air hose attached. Always release any
built-up air even after disconnecting hose. Disconnect the Polisher Kit when not
in use.
Avoid unintentional starting.11. Be sure the Trigger (8) is in the OFF position
when not in use and before plugging in. Do not carry any tool with your nger on
the Trigger, whether it is attached to an air source or not.
Stay alert.12. Watch what you are doing. Use common sense. Do not operate any
tool when you are tired or distracted.
Periodically check your work to make sure that the workpiece is not being13.
damaged.
Check for damaged parts.14. Before using any tool, any part that appears dam-
aged should be carefully checked to determine that it will operate properly and
perform its intended function. Check for alignment and binding of moving parts,
any broken parts, and any other condition that may affect proper operation. Any
part that is damaged should be properly repaired or replaced by a qualied tech-
nician. Do not use the tool if the Trigger does not operate properly.
Replacement parts and accessories.15. This product is to be repaired and ser-
viced only by a qualied technician. When this product is serviced, only identical
replacement parts should be used. Use of any other parts will void the warranty.
Only use accessories intended for use with this tool. Approved accessories are
available from Harbor Freight Tools.
Do not operate tool if under the inuence of alcohol or drugs. 16. Read warning
labels if taking prescription medicine to determine if your judgement or reexes
are impaired while taking drugs. If there is any doubt, do not operate the tool.

SKU 95030 For technical questions, please call 1-800-444-3353. PAGE 4
Maintenance.17. The maintenance outlined in the “Maintenance” section should be
performed regularly. For your safety, this product should be serviced or repaired
regularly only by a qualied technician.
Compressed air only.18. Use clean, dry, regulated, compressed air at 90 PSI.
Never use oxygen, carbon dioxide, combustible gases, or any other bottled gas
as a power source for this tool.
Always grip the Polisher rmly with 19. both hands when operating the tool.
Industrial applications must follow OSHA requirements.20.
Maintain labels and nameplates on the Polisher Kit.21. These carry important
information. If unreadable or missing, contact Harbor Freight Tools for a replace-
ment.
Only use polishing accessories rated for 2,000 RPM or greater.22.
WARNING!23. The warnings, cautions, and instructions discussed in this instruc-
tion manual cannot cover all possible conditions and situations that may occur. It
must be understood by the operator that common sense and caution are factors
which cannot be built into this product, but must be supplied by the operator.
SAVE THESE INSTRUCTIONS
AIR LINE CONNECTIONS
REGULATOR
FIGURE A FILTER
OILER
Polisher
For best service, you should incorporate an oiler, regulator, and in-line lter, as
shown in the diagram below. Hoses, couplers, oilers, regulators, and lters are
all available at Harbor Freight Tools. NOTE: If an automatic oiler is not used, put
3-5 drops of pneumatic Tool Oil (not included) in the tool’s quick connector before
each use. (See Figure A.)

SKU 95030 For technical questions, please call 1-800-444-3353. PAGE 5
ASSEMBLY INSTRUCTIONS
QUICK CONNECTOR
(NOT INCLUDED)
FIGURE B
INLET BUSHING
(13)
1. Prior to use, the Polisher requires the attachment of a 1/4” - 18 NPT Quick Con-
nector (not included) to its Inlet Bushing (13). To do so, make sure the screen
Air Filter is properly seated in the Inlet Bushing. Wrap approximately 3” of pipe
thread sealer tape (not included) around the male threads of the Quick Connec-
tor. Then, rmly tighten the Quick Connector into the Inlet Bushing.
(See Figure B.)
AIR SUPPLY HOSE
(NOT INCLUDED)
OPEN END WRENCH
(30)
3” PAD
(29)
FOAM PAD (31) OR BUFFING PAD (32)
FIGURE C
TRIGGER
(8)
REGULATOR
(14)
2. Use the accessory Open End Wrench (30) to hold the Planet Gear Seat (22) in
place. Then, rmly hand screw the 3” Pad (29) onto the Clamp Nut.
(See Figure C.)
If applying a3. polish (not included) to the workpiece, install the Foam Pad (31)
onto the 3” Pad (29). If bufng the workpiece, install the Bufng Pad (32) onto
the 3” Pad. (See Figure C.)
REV 06j

SKU 95030 For technical questions, please call 1-800-444-3353. PAGE 6
OPERATING INSTRUCTIONS
WARNING! Use eye and hearing protection. Always wear ANSI-approved safety
impact glasses and full face shield when using this Polisher Kit. Also, wear ANSI
approved hearing protection. Other people in the work area must also wear ap-
propriate ANSI approved safety equipment.
Whenever possible, secure the workpiece in place, using a vise or clamps (not1.
included).
Prior to polishing a workpiece, make sure its surface has been thoroughly2.
cleaned and is free of dust, dirt, oil, grease, etc.
Apply about two tablespoons of wax (not included) evenly on the previously3.
installed Foam Pad (31). Do not apply the wax directly on the surface of the
workpiece. The amount of wax needed will vary according to the size of the
workpiece being polished. NOTE: Avoid using too much wax. For additional
applications of wax to the Foam Pad, reduce the amount of wax. The Foam Pad
will not absorb as much wax in subsequent applications. (See Figure C.)
Connect the air supply hose (not included) to the previously installed Quick Con-4.
nector on the Polisher. Always position the air hose so it will not damage the
surface being worked on. Turn on the air compressor, and set its regulator at 90
PSI. Do not exceed 90 PSI. (See Figure C.)
IMPORTANT:5. Always start and stop the Polisher while it is held rmly against
the surface of the workpiece. Failure to do so may result in the Foam Pad (31)
being thrown from the 3” Pad (29). (See Figure C.)
Grip the Polisher rmly with both hands. Then, squeeze the Trigger (8) to start 6.
the Polisher. NOTE: The speed of the Polisher may be increased by turning its
Regulator (14) counterclockwise. (See Figure C.)
Allow the Foam Pad (31) to spin up to full speed. Then begin applying wax to the7.
workpiece. Apply the wax to all at surfaces with broad, sweeping strokes in a
criss-cross pattern. Apply the wax evenly over the surface of the workpiece, and
add additional wax as needed. (See Figure C.)
After the wax has been applied to the workpiece surface, release pressure on the8.
Trigger (8) to turn off the Polisher. Turn off the air compressor. Then squeeze
the Trigger of the Polisher to release any remaining air pressure in the tool and
compressed air system. (See Figure C.)
Remove the Foam Pad (31) from the 3” Pad (29) of the tool. With the Foam Pad9.
in your hand, apply the wax to all hard to reach areas of the workpiece.
(See Figure C.)
Allow sufcient time for the wax to dry on the workpiece surface.10.

SKU 95030 For technical questions, please call 1-800-444-3353. PAGE 7
Install the Bufng Pad (32) onto the 3” Pad (29). 11. (See Figure C.)
Connect the air supply hose to the Quick Connector on the Polisher. Turn on the12.
air compressor, and set its regulator at 90 PSI. Do not exceed 90 PSI.
(See Figure C.)
IMPORTANT:13. Always start and stop the Polisher while it is held rmly against
the surface of the workpiece. Failure to do so may result in the Bufng Pad (32)
being thrown from the 3” Pad (29). (See Figure C.)
Grip the Polisher rmly with both hands. Then, squeeze the Trigger (8) to start 14.
the Polisher. NOTE: The speed of the Polisher may be increased by turning its
Regulator (14) counterclockwise. (See Figure C.)
Allow the Bufng Pad (32) to spin up to full speed. Then begin polishing the 15.
workpiece surface by lightly bufng off the wax residue in a circular pattern. Con-
tinue polishing until all the wax residue is removed. (See Figure C.)
After the wax has been removed from the workpiece surface, release pressure16.
on the Trigger (8) to turn off the Polisher. Turn off the air compressor. Then
squeeze the Trigger of the Polisher to release any remaining air pressure in the
tool and compressed air system. (See Figure C.)
Remove the Bufng Pad (32) from the 3” Pad (29) of the tool. With the Bufng 17.
Pad in your hand, remove the wax from all hard to reach areas of the workpiece.
(See Figure C.)
INSPECTION, MAINTENANCE, AND CLEANING
WARNING! Always wear ANSI-approved safety impact goggles when performing
any inspection, maintenance, or cleaning procedures.
WARNING! Prior to performing any inspection, maintenance, or cleaning of the Pol-
isher Kit, make sure to disconnect the air hose from the tool. Then, squeeze the
Trigger (8) again to release any compressed air in the system and tool.
Before each use:1. Inspect the general condition of the Polisher Kit. Check for
misalignment or binding of moving parts, damaged parts, and any other condition
that may affect the tool’s safe operation. If abnormal noise or vibration occurs,
have the problem corrected before further use.
Do not use damaged tools and equipment.
NOTE:2. The most common error when polishing a workpiece is applying too
much wax. If the Foam Pad (31) becomes too saturated with wax, polishing will

SKU 95030 For technical questions, please call 1-800-444-3353. PAGE 8
be more difcult and will take longer. Applying too much wax may also reduce
the life of the Foam Pad. If the Foam Pad continually comes off the 3” Pad (29)
during use, too much wax has been applied.
To clean the Polishing Kit:3. Wipe the exterior of the Polisher with a clean, damp
cloth, using a mild detergent. Do not immerse the tool in liquids. The Foam Pad
(31) and Bufng Pad (32) may be washed and dried at medium heat.
When storing:4. Always store the Polishing Kit in a clean, dry, safe location out of
reach of children. Always remove the Foam Pad (31) and Bufng Pad (32) from
the Polisher when not in use. This will allow the pads to dry and retain their origi-
nal shape. To prolong the life of the pads, store the pads face up.
CAUTION!5. All maintenance, service, and repairs not mentioned in this manual
must only be performed by a qualied service technician.
TROUBLESHOOTING
Problem Possible Solution
Polisher does not turn on when Trigger is
squeezed.
Firmly squeeze the Trigger.1.
Turn air compressor on and set its regulator to 902.
PSI.
Secure all compressed air system connections3.
and make sure that there are no leaks.
Clean the air and oil lters in the air compressor.4.
Clean Air Filter within the Inlet Bushing of the5.
Polisher.
Foam Pad and/or Bufng Pad continually
comes off 3” Pad when tool is in use.
Thoroughly clean Pad. Thereafter, apply less wax to
Foam Pad.
Releasing the Trigger on the Polisher does not
turn off the tool.
Turn off the air compressor. Release any remaining
compressed air from the system and tool. Do not
use the tool until a qualied service technician repairs
the tool.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN
THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY
REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES
THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED
TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISKS AND LIABILITY ARISING OUT OF
HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT
OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.

SKU 95030 For technical questions, please call 1-800-444-3353. PAGE 9
PARTS LIST AND ASSEMBLY DIAGRAM
Part Description
1 Motor Housing
2 O-Ring
3 Throttle Valve
4 O-Ring
5 O-Ring (4)
6 Reverse Bushing
7 Valve Spring
8 Trigger
9 Spring Pin
10 Exhaust Diffuser
11 Mufer Screw (2)
Part Description
12 O-Ring
13 Inlet Bushing
14 Regulator
15 Bearing (2)
16 Rear End Plate
17 Spring Pin (2)
18 Cylinder
19 Rotor Blade (4)
20 Rotor
21 Front End Plate
22 Planet Gear Seat
Part Description
23 Planet Gear Spindle (3)
24 Planet Gear (3)
25 Needle Bearing (3)
26 Internal Gear
27 Ball Bearing (2)
28 Clamp Nut
29 3” Pad
30 Open End Wrench
31 Foam Pad (2)
32 Bufng Pad
Note: Some parts are listed and shown for illustration purposes only, and are not avail-
able individually as replacement parts.

SKU 95030 For technical questions, please call 1-800-444-3353. PAGE 10
90 DAY WARRANTY
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality
and durability standards, and warrants to the original purchaser that this product is free
from defects in materials and workmanship for the period of 90 days from the date of
purchase. This warranty does not apply to damage due directly or indirectly, to misuse,
abuse, negligence or accidents, repairs or alterations outside our facilities, criminal
activity, improper installation, normal wear and tear, or to lack of maintenance. We shall
in no event be liable for death, injuries to persons or property, or for incidental, contingent,
special or consequential damages arising from the use of our product. Some states do
not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation of exclusion may not apply to you. This warranty is expressly in lieu of all other
warranties, express or implied, including the warranties of merchantability and tness.
To take advantage of this warranty, the product or part must be returned to us with
transportation charges prepaid. Proof of purchase date and an explanation of the complaint
must accompany the merchandise. If our inspection veries the defect, we will either
repair or replace the product at our election or we may elect to refund the purchase price
if we cannot readily and quickly provide you with a replacement. We will return repaired
products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning
the product.
This warranty gives you specic legal rights and you may also have other rights which
vary from state to state.
3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • [phone]
REV 11h
