Centrios 1713164 - Storm Blue User manual

Freetalk Bluetooth Speakerphone
USER GUIDE
Three Colours Available!
1713164 - Storm Blue | 1713168 - Titanium | 1713169 - Pure White

2
Contents
1. About Bluetooth Speakerphone ..............................................................................................3
2. About Bluetooth Technology ....................................................................................................3
3. Getting to Know Your Bluetooth Speakerphone ...............................................................3
4. Appearance and Functions........................................................................................................4
5. Charging Your Bluetooth Speakerphone ..............................................................................4
6. Turning ON/OFF the Speakerphone .....................................................................................5
7. Pairing .................................................................................................................................................5
8. Connection/Link between Speakerphone and Mobile Phone .....................................6
9. Disconnection between Speakerphone and Mobile Phone ........................................... 6
10. Using the Speakerphone ........................................................................................................... 6
11. MultiPoint Feature .........................................................................................................................8
12. Low Voltage Protection of Battery ........................................................................................ 9
13. Restore to Default Setting .......................................................................................................9
14. LED Indication ..............................................................................................................................10
15. Care and Maintenance ................................................................................................................ 11
16. Safety Information ...................................................................................................................... 11
17. Product Specification .................................................................................................................12

3
1. About Bluetooth Speakerphone
This versatile Bluetooth speakerphone is specially designed for the user to enjoy the convenience and
freedom of wireless communication. Dual capacity for use on desk-top like a conference speakerphone
and in-car like a hands-free car kit. Advanced built-in microphone with D.S.P. solution for Echo Cancellation &
Noise Suppression that gives you impeccable full duplex sound quality.
2. About Bluetooth Technology
Bluetooth wireless technology is set to revolutionize the personal connectivity by providing freedom from
wired connections-enabling links and connectivity between notebook/laptop, mobile phones, portable
handheld devices and other Bluetooth enabled devices within 10 meters. Utilizing global sound & digital
data 2.4GHz ISM transmission, it makes for global communication in a way you’ve never dreamed of!
3. Getting to Know Your Bluetooth Speakerphone
To use your Bluetooth speakerphone, please follow these simple steps:
(1) Charge your speakerphone. Prior to using the speakerphone, it is recommended to charge the battery
fully for the first time. Normal full charge time is 3 hrs. (approx.)
(2) Place your speakerphone and a Bluetooth-enabled mobile phone within 1 meter for pairing.
(3) Ensure your speakerphone and mobile phone is placed within 10 meters Bluetooth sensing distance.
(Obstruction could cause shorter sensing distance.)

4
4. Appearance and Function
(1) Speaker (4) Charging Socket (5-pin USB) (7) Volume Increase (V+)
(2) Microphone (5) Mute Button (8) Volume Decrease (V-)
(3) LED (6) MFB Button (Multi-Function Button)
5. Charging Your Bluetooth Speakerphone
The Bluetooth speakerphone comes with a rechargeable battery. Prior to using the speakerphone, it is
recommended to charge the battery fully for the first time. Normal full charge time is 3 hrs. (approx.)
IMPORTANT:
(1) Charging indication will be delayed for a few minutes if the speakerphone has not been used for a
long time or the battery is drained.
(2) To prolong durability of the battery, it’s recommended to charge the speakerphone whenever low
battery is encountered. When battery becomes low, LED will flash red every 3 seconds. Under low

5
battery condition, if speakerphone is continuously used, it will decrease the durability of the battery as
well as standby time and cause longer charge time than normal 3 hrs. Also, the speakerphone will power off.
(3) The red LED will flash on while charging and flash off when charging is completed.
6. Turning ON/OFF the Speakerphone
Power On: When speakerphone is under off mode, press and hold the “MFB” for 4 seconds until you hear
a short beep. The blue LED will flash 5 times, and then the speakerphone will automatically connect to the
last connected mobile phone.
Power Off: When the speakerphone is in standby mode, press and hold the “MFB” button for 4 seconds
until you hear a short beep. The red LED will flash 5 times before powering off.
7. Pairing
Prior to using the speakerphone for the first time, you must pair it with a Bluetooth-enabled mobile phone.
The steps below describe pairing instructions for a typical Bluetooth-enabled mobile phone.
(1) Place the speakerphone and mobile phone no more than 1 meter apart.
(2) Ensure the speakerphone is under OFF mode.
(3) Press and hold the “MFB” button for 6 seconds until the LED flash red and blue alternatively, it is now
ready for pairing.
(4) Activate the Bluetooth function on your mobile phone and search for accessible Bluetooth device by
referring to your mobile phone user guide for details.
(5) Select “Centrios 1713164/8/9” from the list.
(6) Enter the pre-programmed code “0000” and press “OK” to pair the speakerphone and the phone.
When pairing is completed, the blue and red LED stop flashing, the speakerphone is under the
standby mode with the blue LED flashes in every 3 seconds.
(7) Press “Return” to go back to your mobile phone’s main menu. Please place the mobile phone and the
speakerphone within 10 meters sensing distance. You should now be able to make and receive calls

6
using your speakerphone.
NOTE: If the pairing cannot be completed within 2 minutes after the pairing mode is activated, the
speakerphone will power off automatically. Please repeat steps above to pair the speakerphone and mobile
phone again.
8. Connection/Link between Speakerphone and Mobile Phone
After pairing is completed, speakerphone is always under standby mode. Before you place or answer a call,
if the headset icon is not shown on phone screen, please follow the steps below to activate the Bluetooth
connection/link through your mobile phone or speakerphone until the headset icon is on the screen.
(1) On phone: Select the “Centrios 1713164/68/69” from the paired list on your phone screen.
(2) On speakerphone: Press “MFB” briefly and select “Accept” on phone screen to accept connection.
9. Disconnection between Speakerphone and Mobile Phone
When you need to connect your speakerphone with another Bluetooth-enabled mobile phone, please fol-
low the steps below to disconnect the speakerphone with the pre-paired mobile phone.
(1) Power off the speakerphone.
(2) Select “Disconnecting” on the Bluetooth device list of your mobile phone to remove the connection.
NOTE: When losing the connection/link, the speakerphone will be automatically powered off in 10 minutes.
The blue LED will flash twice every 3 seconds when the speakerphone is not connected with mobile phone.
10. Using the Speakerphone
(1) Answering a Call
When receiving a phone call, short press the “MFB” button briefly to answer the call.
(2) Ending a Call
Press the “MFB” button briefly to end a call.
(3) Reject a Call

7
When you hear the ringing tone, press and hold the “MFB” button for 2 seconds to reject the call.
(4) Voice Dial
If your mobile phone is voice dialing enabled, under standby mode, press the “MFB” button briefly and
say the voice tag after you hear a beep.
NOTE: Please make sure to record voice tag into the mobile phone before using voice dial function.
Functionality varies depending on the mobile phone models. Please refer to your mobile phone user guide
for details.
(5) Last Number Re-Dialing
Under standby mode, press the “MFB” button twice briefly for last number redial.
(6) Adjusting the Volume
During a call, press the “V+” or “V-” buttons repeatedly until you reach the desired volume level.
(7) Mute & Disactivate Mute
a. Mute: During a call, short press the “MUTE” button briefly to mute the speakerphone. The red LED
will flash on during mute mode.
b. Disactivate Mute: Short press the “MUTE” button briefly during mute mode to restore sound to the
speakerphone.
(8) Transferring Calls
a. Speakerphone to Mobile Phone: During a call, press both of “V+” and “V-” buttons, and the call is
routed to your mobile phone.
b. Mobile Phone to Speakerphone: Press both “V+” and “V-” buttons to route thecall to speakerphone.
(9) Hold the Call
During a call, press the “MFB” button twice to hold the phone call. Press “MFB” button twice again to
resume conversation.
(10) Answer the Second Call
a. When receiving a second call, press “MFB” button twice to hold the first call on line and answer the
second call.

8
b. When receiving a second call, press “MFB” button once to end the first call and answer the second call.
(11) Reject the Second Call
When receiving a second call, press and hold the “MFB” button for 2 seconds to reject the second call.
(12) Switch Between 2 Phone Calls
a. When having 2 calls on the line, press “MFB” button twice to switch between these 2 phone calls.
b. When having 2 calls on the line, press “MFB” button once to end the first call and stay with your
mobile phone.
11. MultiPoint Feature
(1) Activate Multipoint Connection
The default setting of speakerphone’s multipoint function is off. Please activate the multipoint function
for connecting with 2 mobile phones in the same time.
a. Multipoint On: Under standby mode, press and hold “V+” button for 3 seconds until you hear a beep.
After turning on the multipoint function, the speakerphone will automatically connect to the last 2
mobile phones that has been paired before.
b. Multipoint Off: Under standby mode, press and hold “V-” button for 3 seconds until you hear a beep.
The speakerphone will turn off the multipoint function and power off automatically. When power on
the speakerphone again, it will only connect to the last connected Bluetooth device.
(2) Multipoint Pairing
a. First mobile phone: Pair the speakerphone with one of the Bluetooth-enabled mobile phones.
b. Second mobile phone: Power off the speakerphone. Press and hold the “MFB” button for 6 seconds
to enter pairing mode again to pair and connect with the second mobile phones.
c. Connect with the first paired mobile phone to the speakerphone by pressing the “MFB” button
briefly.
(3) Multipoint Connection/Link with 2 Mobile Phones
After the multipoint function is activated, please follow the steps below to connect 2 Bluetooth

9
enabled mobile phones at the same time.
a. When the speakerphone is on, it will automatically search and connect the last 2 mobile phones
that have been connected before.
b. Under standby mode, press and hold “V+” button for 3 seconds until you hear a beep, then the
speakerphone will automatically connect the last 2 mobile phone that have been connected before.
(4) Using the Secondary Mobile Phone Through Speakerphone
When connected with 2 Bluetooth mobile phones, the first connected one is primary phone that can
use the “MFB” button for voice dial and redial. The second connected phone is secondary phone that
will use “V+” button for voice dial and redial.
a. Voice Dial: Press “V+” button once to activate the secondary phone’s voice dialing function.
b. Re-Dialing: Press “V+” button twice to redial the last outgoing number of secondary phone.
NOTE:
(1) When the speakerphone is in Multipoint mode and connected to only 1 mobile phone, it can also enter
voice dial function by press “V+” button once, or make last outgoing number re-dialing by press “V+”
button twice.
(2) The Multipoint speakerphone can be paired with 2 mobile phones at the same time. When one of them
receives an incoming call, the other phone will be disconnected from speakerphone but resume
connection automatically after the first one has finished the phone call.
12. Low Voltage Protection of Battery
When the voltage of battery decreased to 3.3V, the red LED will flash in every 3 seconds, and the
speakerphone will be power off automatically when the voltage under 3.0V.
13. Restore to Default Setting
Please follow the steps below to reset the speakerphone to its original setting and remove all the previous
pairing and connection.

10
(1) Ensure the speakerphone is under standby mode.
(2) Press and hold both of “V+” and “V-” buttons for 10 seconds until the blue and red LED flash 5 times,
then the speakerphone will resume standby mode. The speakerphone is now back to original setting,
and after powering on the speakerphone again, it will enter pairing mode automatically.
NOTES: If the speakerphone is connected with a mobile phone before restore to default setting, it will
enter pairing mode automatically after restored to default. If the speakerphone was not connected to a mo-
bile phone before restore to default setting, it will be under standby mode after restored to default setting.
14. LED Indication
Speakerphone Status Red LED Blue LED Sound
Off Mode Off Off
Power On 5 pulses One beep
Power Off 5 pulses One beep
Standby Flash on every 4 sec.,
Off after 5 minutes.
Standby – Low Voltage Flashing 2 beeps
every minute
Live in Use Flash on alternately Flash on every 2 sec.
Pairing in Progress
Pairing Completed 5 pulses One beep
Charging in Progress Steady on
Charging Completed Off Off

11
15. Care and Maintenance
(1) Do not expose the speakerphone to liquid, moisture or humidity, as it is not waterproof.
(2) Do not use abrasive cleaning solvents to clean the speakerphone.
(3) Do not expose the speakerphone to high temperature, as it may result in an explosion.
(4) Do not expose the speakerphone to sharp objects to avoid scratching and damage.
(5) Do not attempt to disassemble the speakerphone, as it does not contain serviceable components.
(6) If you do not use the speakerphone for long periods of time, be sure to store it in a dry place, free
from extreme temperature, humidity and dust.
16. Safety Information
(1) Check local laws regarding use of a mobile phone and speakerphone while driving. If you use the
speakerphone while driving, ensure your attention and focus remains on your responsibility of driving
safely.
(2) Never allow children to play with the speakerphone. Small parts may be a choking hazard.
(3) Observe all signs that require an electrical device or RF radio product to be switched off in the
designated areas. These could include hospitals, blasting areas, and potentially explosive atmospheres.
(4) Turn off your speakerphone prior to boarding an aircraft. Do not use your speaker
phone in an aircraft.
(5) Never place or store the speakerphone over the area of the automobile’s safety airbag deployment, or
it may cause serious injury when a safety airbag deploys.

12
17. Product Specification
Bluetooth Compliance: Bluetooth V2.1+EDR
Operating Frequency Band: 2.4GHz ~ 2.48GHz unlicensed ISM band
Output Power: Class 2, up to 10 meters
Support Profiles: HSP and HFP Profiles
Support Multiple Paired Device: Memorize paired data of 8 Bluetooth phones
Stand-by Time: Up to 980 hours/ 40 days
Talk Time: Up to 10-12 hours
Battery Charging Time: About 3 hours
Charger Voltage: DC5.0V, 400mA
Battery: 650mA, BL-5B (Rechargeable Lithium-Ion Battery)

13
ORBYX ELECTRONICS WARRANTY
ORBYX Electronics warrants that this product will be free from defects
in materials and workmanship for a period of one (1) year from the date
of purchase. Within this period, simply take the product and your proof of
purchase to any ORBYX Electronics store or dealer and the product will be
repaired without charge for parts and labour. ORBYX Electronics reserves
the right to charge for transportation. Any product which has been subject to
misuse or accidental damage is excluded from this warranty.
This warranty is only applicable to a product purchased through ORBYX
Electronics’ company owned stores and dealers and to a product that is
presented for repair in a country where ORBYX Electronics offers the product
for sale. While this warranty does not confer any legal rights other than those
set out above, you may have additional statutory rights which will vary under
the laws of the various countries, states, province and other governmental
entities in which ORBYX Electronics operates. This warranty is subject to all
statutory rights you may have in the country of purchase.
Limited Warranty
© 2009 ORBYX Electronics.
All Rights Reserved.
Imported in Canada for
Orbyx Electronics,
Concord, Canada, L4K 4M3
Manufactured in China
For product support please contact
www.orbyxelectronics.com
The FCC Wants You To Know
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses, and can radiate radio frequency energy and,
if not installed or used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures: 1) reorient or relocate the receiving antenna; 2) increase
the separation between the equipment and the receiver; 3) connect the
equipment to an outlet on a circuit different from that to which the receiver is
connected; 4) consult the dealer or an experienced radio/TV technician for
additional suggestions.
Any changes or modications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment. Where
shielded interface cables have been provided with the product or specied
additional components or accessories elsewhere dened to be used with the
installation of the product, they must be used in order to ensure compliance
with FCC regulation.
Industry Canada-ICES-003
CAUTION
To comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules, this device must only be installed on computer equipment certied
to comply with the Class B limits.
This Class B digital apparatus complies with Canadian ICES-003.
